Identifying Pairs of Terms with Strong Semantic Connections

in a Textbook Index

James Geller

, Shmuel T. Klein

and Yuriy Polyakov

Department of Computer Science, NJIT, Newark NJ, U.S.A.

Department of Computer Science, Bar Ilan University, Ramat Gan, 52900, Israel

Keywords: Ontology, Semantic Relationships, Textbook Index, Security Concepts, Semantically Correlated Terms.

Abstract: Semantic relationships are important components of ontologies. Specifying these relationships is work-

intensive and error-prone when done by experts. Discovering domain concepts and strongly related pairs of

concepts in a completely automated way from English text is an unresolved problem. This paper uses index

terms from a textbook as domain concepts and suggests pairs of concepts that are likely to be connected by

strong semantic relationships. Two textbooks on Cyber Security were used as testbeds. To show the

generality of the approach, the index terms from one of the books were used to generate suggestions for

where to place semantic relationships using the bodies of both textbooks. A good overlap was found.

1 INTRODUCTION

Ontologies are becoming increasingly popular, in a

number of research areas, e.g., in Medical

Informatics. The NCBO BioPortal (Musen et al.,

2012) currently houses 443 ontologies (BioPortal,

2015). However, building them remains a hard

problem for any ontology that is of a practically

useful size. Many approaches have been reported,

e.g., automated methods (Hindle, 1990; Hearst,

1992; Wiebke, 2004, Cimiano et al., 2005), and

ontologies built by hand (Caracciolo, 2006).

Different variations and hybrid methods exist.

One approach that deserves specific mention is to

construct several small ontologies and then use

alignment algorithms to combine them into a large

one (Jain et al., 2013). Another approach is to leave

the ontology building to experts, but to provide them

with tools to make it easier (Geller et al., 2014).

Our general approach to ontology construction is

to make maximal use of already existing semi-

formal sources, as this is easier for the expert than to

start with an “empty page,” yet likely more

successful than trying to extract concepts from

completely unstructured text (Wali et al., 2013). In

older work (An et al., 2007) we used tables of data

hidden in the Deep Web, which are hard to access.

Thus, we have turned to another source of semi-

formal data for ontology construction, namely

textbook indexes. A review of the indexes of several

textbooks indicates that their terms provide an

excellent starting point for an ontology for the

subject domain of each book. We note that our use

of the word “concept” includes not only object

concepts but a reification of tasks, processes, events,

etc. The primary domain of our research is Cyber

Security (Sections 4.2 ̶ 4.6). Thus,

encryption is a

process, an

attack should be viewed as an event, etc.

Many textbooks have sub-index-terms which can

be translated into hierarchical relationships between

main terms and associated subterms (that need to be

validated by an expert). In previous work (Wali et

al., 2013), we investigated several methods for

finding IS-A relationships between concepts. That is

not the topic of this paper.

The harder problem in ontology building is to

insert the correct semantic (also called lateral)

relationships into the ontology. These go beyond the

basic hierarchical relationships (e.g., subclass, IS-A,

kind-of, part-of) and beyond the local attributes of

concepts.

In Cyber Security, examples of semantic

relationships would be defends, certifies, detects,

etc. Thus a virus scan program detects computer

viruses. In an ontology with the concepts

virus scan

program

and computer virus the detects relationship

would point from the former to the latter. The

problem of including semantic relationships in an

ontology is not specific to Cyber Security.

Geller, J., Klein, S. and Polyakov, Y..

Identifying Pairs of Terms with Strong Semantic Connections in a Textbook Index.

In Proceedings of the 7th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2015) - Volume 2: KEOD, pages 307-315

ISBN: 978-989-758-158-8

307

To restate the problem, given a backbone of

concepts, connected by IS-A or similar hierarchical

links, the question is what semantic relationships

should be added to this backbone. Handing the

backbone to a human expert and asking her to

provide the semantic relationships is not practical.

If a textbook index contains

concepts,

there could potentially be a relationship between any

pair of those concepts. Given that there are

unique pairs of distinct concepts, an

expert would need to review 244,650 pairs.

Furthermore, many concepts are connected to

multiple other concepts by the same or different

semantic relationships.

Thus, a method is needed to show to the expert

only a very small, well-chosen percentage of all

possible concept pairs, such that the concepts of

each pair are highly likely to be connected by a

meaningful semantic relationship. But how can an

algorithm guess this? The answer we suggest is that

if two concepts appear often close to each other in

the actual body of the textbook, then there is a good

chance that such a semantic relationship might exist.

Note that we are not determining whether it exists or

what it might be. This decision will be made by a

domain expert. We are only eliminating from the

view of the expert the large majority of pairs that are

not likely to be semantically connected.

The crucial question is to define what close to

each other in the actual body of the textbook means.

In this paper, we suggest using text units that are

semantically meaningful, which, for this

investigation, we have chosen as whole sentences.

Other possibilities exist, such as paragraphs.

The remainder of the paper is organized as

follows. In Section 2 we are reviewing related

literature. Section 3 describes our theory and

methodology. Section 4 describes preliminary tests

and then experiments with two Cyber Security

textbooks. Section 5 discusses the results, and

Section 6 contains Conclusions and Future Work.

2 RELATED WORK

Building ontologies by hand is difficult and time

consuming. For example, Caracciolo (2006) reports

on building an ontology called LoLaLi. To avoid

these difficulties, many attempts have been made to

derive ontologies directly from text. To make this

task easier, additional sources of information may be

used. Maedche and Staab (2000) combined text

mining with the use of a dictionary to create a

domain-specific ontology. Our work uses a listing

of index terms from a textbook instead of a

dictionary. Work on using a book index in ontology

building was reported by Pattanasri et al. (2007).

Examples of automated methods for building

ontologies are, e.g., Hindle (1990), Hearst (1992),

Wiebke (2004) and Cimiano et al. (2005). Hindle’s

work is based on the clustering approach and a

corpus of text. Hearst used a linguistic pattern

matching method by identifying a set of lexico-

syntactic patterns to find semantic relationships

between terms from large corpora of text. Wiebke

reported on a set-theoretical approach for creating

inheritance hierarchies. Cimiano et al.’s work is

based on the use of Formal Concept Analysis.

The application area of this work is the creation

of an ontology for Cyber Security. Several previous

efforts have gone into building such an ontology. A

summary appears in (Geller et al., 2014). However,

we mention work by Vigna et al. (2003),

Geneiatakis and Lambrinoudakis (2007), Herzog et

al. (2007), Fenz and Ekelhart (2009) and Meersman

et al. (2005). In previous work (Wali et al., 2013) we

extended the ontology of Herzog. In this paper, we

are focusing on the issue of existence and strength of

semantic (non-taxonomic) relationships between

Cyber Security concepts.

In the medical ontology domain, Lee et al.

(2004) describe a method for the automated

identification of the treatment relationship. Katsurai

et al. (2014) use tagged images to identify semantic

relationships. The use of co-occurrence information

in extending ontologies was reported by Novalija et

al. (2011). Their method assumes an additional

glossary, which our primary book did not provide.

3 METHODOLOGY

The problem we deal with can formally be defined

as follows. We are given a large more or less

homogeneous text

, for which an index has been

provided. The goal is to generate pairs of index

terms (a,b) that are most strongly correlated with

each other. If an automated way of compiling such a

list can be found, it could serve as input to experts

working on establishing semantic links among the

concepts of the ontology.

The challenge is to find the correct terms, which

discriminate between the given semantic contexts; it

is thus not sufficient for a pair of terms to co-occur

frequently. We suggest to follow the methodology of

(Bookstein and Klein, 1990), and to first partition

the given text

, for each index term a, into two

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

308

disjoint subsets, the first, which we shall denote by

, and its complement .

The set

will be the set of terms appearing in

the proximity of the term a under consideration, and

may thus be considered as those terms most strongly

connected with a.

There are several ways to define proximity. For

example, one could decide to extend the proximity

of a to the entire sentence in which a appears.

Another, definition, would be to choose an integer

threshold

, and define the proximity as the

set of all the terms within a range of

terms before

and after any occurrence of a. A third possibility

would be the intersection of the two preceding

choices. The threshold

could be chosen fixed, or

depending on the global frequency of the term a in

, and/or on the size of the current sentence. To

avoid the bias introduced by frequent terms, which

appear in the context of a just because they appear in

fact almost everywhere, we define, for each term

, its probability of occurrence in and :

(1)

where

denotes the frequency of occurrence

of the term b in the set

, is the size of the set

Y, and the addition of 1 to numerator and

denominator avoids a potential division by 0. As

measure of the correlation strength with term a, we

use the ratio of the above probabilities, multiplied by

an increasing function of the frequency:

(2)

which is well defined, since f

(b) ≠ 0.

The following intuition lies behind this

definition. The ratio of the probabilities can be

considered as a weight measuring the connection

strength of b to a. However, a term

appearing 3

times in

and 7 times in would have the same

ratio as a term

b for which these frequencies could

be 30 and 70; yet, the evidence for

b is stronger,

and this should be reflected. This leads to the idea of

a multiplicative factor. Taking

itself would

be too large in relation to the quotient, so we use its

logarithm, which can be considered proportional to

its information content. Adding 2 is a correction, to

avoid negative or 0 values.

Note that the notion of correlation defined by the

above procedure is not necessarily symmetric: a

term b might be among the most strongly related to a

term a, but this does not imply that a must also be in

the set of those terms most strongly connected to b.

This is obvious for text strings. The most strongly

related term to the phrase

once upon a is probably

time, but in the opposite direction, there could be

many terms that strongly relate to time. In this

research, we are operating with concepts as opposed

to text strings. However, a similar effect may be

observed here. The concept

steering wheel is

strongly connected to the concept

car (and truck,

etc.) However, car is strongly related to many other

car part concepts besides steering wheel.

A similar phenomenon has been noticed by

(Choueka et al, 1983), where terms are sorted

according to an attraction factor for the automatic

detection of idioms. It is also similar to the one-

sidedness of the Kullback-Leibler (1951)

divergence, a well-known metric measuring how far

two probability distributions are apart, and can be

made symmetrical in a similar way: Define the

connection strength of a pair of index terms (a,b) as

(3)

The set of pairs of terms (a,b) in L

, with ba ≠

is then sorted by non-increasing c(a,b), and the first

k elements of the sorted list are presented to the

expert. A simple implementation for all the term

pairs (a,b) in L

would thus require a time

complexity of O(|L|

log |L|) which may be reduced

to O(|L|

log k) by building a maximum-heap

according to the values c(a,b).

While we suggest that a high value of c(a,b)

implies a high correlation between a and b, we do

not claim that the converse implication is also true.

Thus, a pair of terms can have a low score c(a,b)

and yet be strongly connected, because we base the

score on co-occurrence, which might be indicative

of correlation, but is surely not the only criterion.

For example, the style of an author may prefer a

term over its synonym. While these two terms are

correlated, they will rarely appear together. We thus

are primarily interested in the top ranked pairs,

which we expect to be connected, and make no

specific prediction for the lower ranked pairs.

4 EXPERIMENTS

4.1 Preliminary Feasibility Test

To run a preliminary test of these ideas on a

generally available text, we chose the King James

Version of the Bible, consisting of 23,136 verses.

The term a has been chosen as

house or houses,

which together appear 1942 times, in 1637 verses.

Identifying Pairs of Terms with Strong Semantic Connections in a Textbook Index

309

At this preliminary stage, we used only

),(bc

that is,

this experiment was based on the understanding of

the directionality of relationships; moreover, we

wanted to assess the strength of using the pure ratio,

without the logarithmic term. The context was set to

the entire versein which the term occurs. As

expected, the terms with highest probabilities are

similar for the two sets:

the, of, and, house, to, in,

And

,... for T

and the, and, of, to, And, in, that,...

for T

. However, sorting the list by the ratio c

and

restricting it to terms occurring at least five times

yields the following list.

ratio

term

24.43

courts

16.11

wing

15.65

dedicated

14.09

beams

13.73

timber

13.2

build

Note that the first term on the list, courts,

appears there because of the expression courts of

the house of the LORD

; obviously, the term LORD

appears just as often in the same verses, but LORD

also appears in many other contexts, so it is not

typical of a context generated by the term house,

while

courts does qualify as highly related term.

In a second test, the chosen term was David, a

proper name. Details of this experiment are omitted

due to space reasons.

4.2 Textbook Preprocessing and

Cleaning

Encouraged by the results of the preliminary test, we

next applied it to the textbook Introduction to

Computer Security by Goodrich and Tamassia

(2011). We had access to the textbook as a PDF file,

however, extensive cleaning was required. The goal

of this preprocessing is to create two separate files.

One file contains the complete body of the textbook

organized into separate sentences. The other file

contains an alphabetical listing of all index terms.

Due to the creativity of book authors in how they are

structurally expressing their ideas, and due to the

highly technical nature of the content, it is difficult

to create a single program or script that will perform

the cleaning. Thus, the cleaning process was

performed in a combination of manual steps and

regular expressions.

4.3 Processing the Index

To indicate the wide variety of ontological and

textual issues in the index, the following examples

will suffice. Many index terms are followed by

index-internal references to other index terms. The

index term is sometimes an acronym that is followed

by the keyword “see” and the expansion of the

acronym. In some cases, the acronym is the target of

a “see reference” and not the source. Some internal

references are genuine synonyms. Synonym

relationships are important elements of ontologies.

It is desirable to extract IS-A relationships from a

textbook index to support the creation of the

ontology backbone. (This is not the issue in this

paper.) A number of terms in the index are followed

by subterms, which could be related by IS-A

relationships to the main term.

However, the semantics of the relationship

between an index term and a subterm is often

oblique. Goodrich et al. are “relatively parsimonious

and disciplined” in their assignment of subterms in

the index. Many of their term-subterm pairs indeed

express an IS-A relationship. In other textbooks,

their authors included more but less well defined

relationships between terms and subterms.

Another issue with subterms is that sometimes

the subterm by itself is dependent, which means that

it is expected that the subterm is read together with

its main term. In other cases the subterm is

independent and defines a concept on its own.

A number of issues in processing an index are

textual, as opposed to ontological. For example,

many of the elements of L are multi-word index

terms. Some of those are just lists of juxtaposed

words, separated by blanks. However, other terms

appear with dashes between words. The

complicating factor is that some words have hyphens

(-) in the middle of the word because the word is at

the right margin of the textbook page and does not

fit in its entire length. These hyphens are textually

not distinguishable from dashes between words. In a

few cases, the authors of the index were not

consistent whether a term should be dashed or not.

Both formats appeared in the index. Some acronyms

look like words. Non-

ASCII characters appear in

foreign names.

As examples of internal references in the index,

we note that

Internet Protocol refers to IP. HIPAA

refers to

Health Insurance Portability and

Accountability Act

. Homeograph attack appears as

synonym of Unicode attack.

The term

biometric is followed by the two

subterms

identification and verification. The

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

310

intended reading is the concatenation, as in

biometric identification. For the term firewall, three

subterms exist:

application-layer, stateful, and

stateless. The intended reading is now the reverse

concatenation as in stateless firewall. While humans

can easily distinguish between these options, this is

not the case for a knowledge-poor algorithm.

The term

operating systems has nine subterms,

including

concepts, kernel and filesystem. Clearly,

concepts cannot stand by itself, because the

meaning of operating systems concepts is very

different from the meaning of

concepts. On the

other hand, filesystem can stand by itself. The

relationship between kernel and operating systems

is not an IS-A relationship, but a PART-OF.

Returning to the term filesystem, it appears as

one word in the index. However, as part of the term

Encrypting File System, it becomes a two-word

term. The term interface appears in its hyphenated

form as inter-<LF><CR>face because of the narrow

column it is in, but it does not stand for any kind of

face. GOT stands for Global Offset Table.

Transforming

GOT to lower case would change the

meaning to the get() operation. The Merkle-

Damgård construction

contains a non-ASCII å. As a

first approximation we chose to eliminate many such

complicating factors from our index, e.g., by using

the

ASCII equivalent Merkle-Damgard construction.

The resulting index contained 760 terms.

4.4 Processing the Body

Working with the body of the text required

additional adjustments. As a technical publication,

the textbook contains many formulas, some with

non-

ASCII characters such as π. As the focus was on

complete English sentences with a Subject – Verb –

[Object] structure, most titles and captions were

eliminated. Most numbers do not carry conceptual

weight, with a few exceptions such as

3.14159265…, thus numbers were eliminated.

Periods appear as sentence end-markers, in

abbreviations, in ellipses, etc. Hyphenation/dashes

cause similar problems as in the index. The hyphens

cannot be automatically removed as they are

legitimate in many cases, such as in

man-in-the-

middle attack

. Thus, file-system may become file

system

or filesystem, but maninthemiddle attack is

erroneous, and term inter-face (with inter- at the end

of the line) cannot become

inter face. Question

marks and exclamation points were treated just as

periods.

URLs were treated like formulas and

deleted. Names containing diacritical marks were

reduced to

ASCII equivalents. U.S. was replaced by

US and other similar simplifications were

performed. Special characters such as ‘”,;:$*, etc.

were eliminated. Code examples, the micro tables of

content at the beginning of chapters and the

exercises and chapter notes at the end were deleted.

Bullet lists caused a considerable processing

effort as the authors were remarkably “variable” in

using them. In some cases, bullets were followed by

one or more complete sentences terminated by

periods. Those sentences could be maintained while

eliminating the bullet symbols (●). In other cases,

bullets were each followed by a head term, a colon,

and sentence without a final period. Following our

focus on complete sentences, these were deleted. In

other cases bullets were followed by incomplete

sentences. There were also numbered paragraph lists

and many numbered and unnumbered subsection

titles. Lastly, we found a few “true editorial

mistakes” in the textbook. In the end of this

cleaning process, 6019 sentences remained. Each

one of those sentences was stored as a single line in

ASCII file.

4.5 Results of Pilot Study on

Textbook 1

To investigate the viability of our approach, we

performed a pilot study on Goodrich et al. Our

algorithm generated a list of pairs of index terms,

sorted according to Section 3, still using only the

asymmetric

),(bc

but with the logarithmic factor.

To improve the quality of results and as a side

effect also the efficiency of computing them, we

pruned the index and eliminated any terms that

appeared fewer than k times in the body of the

textbook for some predetermined constant k. The

idea was that we wanted to concentrate on the main

domain concepts, whereas terms with frequencies

under a certain threshold may rather be sporadic

uses by the author of the text. We used

14=k .

Three experts in Cyber Security were chosen

from the faculty of NJIT. Each one has taught

security-related classes and is an active researcher.

They were given a randomized list of a total of 102

output pairs of our algorithm from the top, middle

and bottom of the result list, i.e., they were given

pairs of concepts considered highly connected,

weakly connected and “in between” by our

algorithm, in randomized order.

The experts were asked to perform the

high/medium/low ranking of the strength of

connection between pairs of concepts. The experts

were permitted to drop any pairs involving terms for

which they were not sure of the meaning. To

Identifying Pairs of Terms with Strong Semantic Connections in a Textbook Index

311

quantify the results of this experiment we computed

the inter-rater reliability using Cohen’s Kappa

(Cohen, 1960). Cohen’s Kappa (κ) measures the

agreement between two raters in a classification

task, involving a number of mutually exclusive

classes.

Table 1: Comparison Program with Experts.

First Evaluator Second Evaluator κ

Program Expert 1 12.02%

Program Expert 2 -3.04%

Program Expert 3 11.76%

AVG PROG 6.91%

Table 2: Comparison between Experts.

First Evaluator Second Evaluator κ

Expert 1 Expert 2 9.92%

Expert 1 Expert 3 19.31%

Expert 2 Expert 3 1.60%

AVG HUMAN 10.28%

Table 1 shows the inter-rater reliability between the

algorithm and the human experts in percent. We note

that it is legal for Cohen’s Kappa to be negative. To

put these low agreements into perspective, it is

however necessary to compare them with the inter-

rater reliability between pairs of human experts.

Table 2 shows these results.

Except for Expert 1 and Expert 3, who showed a

slightly better agreement (still low at about 20%) the

experts’ agreements are of the same order of

magnitude as the algorithm/expert agreements. Thus,

even though the results in Table 1 were

disappointing, Table 2 makes it clear that the task of

assigning semantic strength of connection to pairs of

concepts is difficult for experts as well. An

additional analysis of the pilot study results

indicated the following phenomena.

1. The program discovered idioms. Thus, the co-

occurrence of

IP and spoofing (23 times) was

primarily due to the fact that

IP spoofing is a

technical term by itself. We accommodated this

insight by collecting statistics of term pairs

appearing immediately next to each other.

2. The program discovered terms that frequently

co-occur in Cyber Security text, even though

they do not have a strong relationship with each

other. For example, the terms

availability and

integrity are not strongly related to each other,

but often co-occur in statements of desired

features of computer systems.

3. The program discovered pairs of concepts that

are closely connected by

IS-A relationships, but

ranked them low. For example

Linux and

operating system appeared weakly connected.

This is counter-intuitive. We hypothesize that

after the fact was made known to the reader that

Linux IS-A operating system, it was assumed as

known and the more concrete term

Linux was

used most of the time. Another interpretation is

that Linux and operating system are indeed

not connected by a Cyber Security relationship,

but by a “general purpose relationship.”

4. The assumption of directionality of pairs was

NOT supported relative to human experts.

4.6 Two-Book Study with Symmetric

Similarity

To address the insights won in the pilot study, a

further study was designed, with the strength of

relationship measured by the symmetric distance in

equation (3). The second major change was that

instead of comparing the judgments of experts with

the output of the program, we chose a second

textbook (Solomon, 2006) but used the index terms

from the first textbook (Goodrich et al.). We argued

that if the algorithm discovers semantic relationships

in one textbook then it should discover the same

relationships in other textbooks on the same subject.

The results of this study were indeed

considerably better. However, the number of output

pairs for the second textbook was much smaller than

for the first textbook. Thus, Cohen’s Kappa could

not be used, as it assumes that both “classifiers” see

the same input data.

Instead, we divided the output of our algorithm

for Goodrich et al.’s book into three equal partitions

(top, medium and bottom). The top partition ended

up having 57 rows. Similarly, the output of our

algorithm for Solomon had a top partition of 13

rows. We then used Mean Average Precision to

determine the degree of overlap.

Mean Average Precision (MAP) is one of the

most widely used measures in Information Retrieval

(IR) to measure system effectiveness (Turpin and

Scholer, 2006) for ranked lists. MAP provides a

single metric to gauge the quality of a ranked list,

which is considered as a sequence of retrieved items

ordered by relevance. MAP computes the average

precisions, AP (in the sense of the technical terms

used in IR) over a number of queries that a system

executes and then derives their arithmetic mean. For

our case we are limiting ourselves to a single query.

To calculate the average precisions in each

query, the precision at a certain cut-off point in the

ranked list is computed, and then all precision values

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

312

are averaged. For example, if the cut-off point is the

nth position in the ranked list, the precisions for item

sets: {i

}, {i

, i

}, {i

, i

}…{ i

, i

, …, i

} will

be computed, where i

is the kth item in the ranked

list. The average precision is computed with:

()

kkP



)(Rel)(

(4)

N is the number of correct items, n is the number of

retrieved items, and k is the rank in the sequence of

retrieved items. P(k) is the precision at the cut-off k

in the list. Rel(k) is an indicator function, which =1

if the item at rank k is correct, 0 otherwise.

Table 3 shows the top 13 pairs that are given as

output by our algorithm for the Solomon textbook.

Column 1 contains the row number. Columns 2 and

3 are the two resulting terms. Column 4 is a binary

column that indicates whether this pair appears in

the first 57 rows of the Goodrich et al. output. As the

first four pairs of Solomon all appear in Goodrich et

al, the average precision is computed as follows:

AP = (1/1+2/2+3/3+4/4+5/7+6/13)/6

=0.86

(5)

Thus the Average Precision comes out to 86%.

While this result is not directly comparable to

Cohen’s Kappa in the previous study, it is

considerably stronger than the results found there.

Notably, the first four strongly related pairs of

Solomon are contained in the top results from

Goodrich et al. Two lines in Table 3 require special

consideration. DOS is an acronym for denial of

service. Thus, this example indicates synonym

discovery by the algorithm. Unix and DES were

considered unrelated by our domain expert (YP).

Presumably, the cut-off at “13” was chosen too low

down in the table to cover only strongly related pairs

of concepts.

5 DISCUSSION

This research has gained new insights into the

difficulty of defining semantic relationships in an

ontology in a way that is agreed to by domain

experts. In the pilot study (Section 4.4) experts were

specifically not asked what the relationship between

pairs of terms is. Automatically deriving the

relationships between concepts from text is the final

goal. This research was limited to asking the

question which pairs of concepts are strongly

enough connected to even attempt to derive them.

Yet the results show that experts widely disagree on

Table 3: Relationship ranking for Solomon.

TERM 1 TERM 2 Y/N

1 plaintext ciphertext Y

2 biometric authentication Y

3 public key cryptography Y

4 password dictionary attack Y

5 cryptography RSA N

6 HTTP HTML N

7 spoofing IP Y

8 public key RSA N

9 signature certificate N

10 TCP IP N

11 denial of service DOS N

12 Unix DES N

13 plaintext one time pad Y

this question. However, the results of comparing the

relationships derived automatically from two

textbooks with one index were highly encouraging.

We note that our processing of the body of the

textbooks implied a loss of important structural

information, due to the attempt to concentrate on

whole sentences as units of mental semantic

processing. It was observed that there were several

cases where an index term appeared in a short

subsection title of a textbook. Presumably, the

following subsection was primarily about this index

term. However, surprisingly, the index term never

appeared in the subsection.

Many of the ontological and textual problems

were “solved by hand.” Ideally it should be possible

to automate the process to the point that a universal

index processing program takes an index as input

and produces (disconnected) parts of an ontology as

output. As noted above, this might be impossible

without additional knowledge sources. Thus, an

automated program cannot determine from the term

“firewall” and the subterm “stateless” whether it is

“stateless firewall” or “firewall stateless,” only one

of which is grammatically correct in English. The

universal index processing program would need to

consult the text of the book to determine the order.

6 CONCLUSIONS AND FUTURE

WORK

Deriving semantic relationships automatically from

English text is hard. However, using textbooks with

well-defined index terms makes some aspects of this

task easier. While inter-rater reliability was found to

be very low, good results were obtained when

working with two textbooks even though we used

Identifying Pairs of Terms with Strong Semantic Connections in a Textbook Index

313

the index of one of them only applied to the body of

both of them. Future work will involve:

1) Applying the relationship discovery

algorithm to longer relevant text.

2) Performing symmetric experiments by using

the index of Solomon’s textbook with the

text of Goodrich et al.’s textbook.

3) Integrating the two indexes into one index

and repeating the experiments.

4) Running experiments with human subjects

asking them to specify what the relationship

is between two strongly connected concepts.

5) In the intermediate term, implementing the

universal index processing program.

Overall, we are keeping the longer term goal in

mind of finding what the actual relationships are,

between the discovered pairs of concepts. Sentences

with pairs of strongly connected index terms are

likely to contain additional words that are indicative

of possible relationships. As noted, cases were

observed where an index term appeared in a

subsection title but nowhere in the subsection. Thus,

one needs to assume that human readers mentally

concatenate the index term with one or more

sentences of that subsection. This connection needs

to be recovered at all levels of the section hierarchy.

ACKNOWLEDGEMENTS

This work is partially funded by NSF grant

DUE1241687. We thank Pearson and Addison-

Wesley for making their textbooks available, and Dr.

Curtmola and Dr. Rohloff, our domain experts.

REFERENCES

An, Y. J., Geller, J., Wu, Y., Chun, S. A.. 2007, Automatic

Generation of Ontology from the Deep Web. Proc.

DEXA '07, Regensburg, Germany.

BioPortal, 2015. http://bioportal.bioontology.org/.

Bookstein A., Klein S.T., 1990. Information Retrieval

Tools for Literary Analysis, in Database and Expert

Systems Applications, edited by A M. Tjoa, Springer

Verlag, Vienna 1-7.

Caracciolo C., 2006. Designing and Implementing an

Ontology for Logic and Linguistics, Literary &

Linguistic Computing, vol. 21, pp. 29-39.

Choueka Y., Klein S.T., Neuvitz E., 1983. Automatic

Retrieval of Frequent Idiomatic and Collocational

Expressions in a Large Corpus, Journal Assoc.

Literary and Linguistic Computing, Vol. 4, 34-38.

Cimiano P., Hotho A., Staab S., 2005. Learning concept

hierarchies from text corpora using formal concept

analysis, J. Artif. Int. Res., vol. 24, pp. 305-339.

Cohen J., 1960. A coefficient of agreement for nominal

scales. Educational and Psychological Measurement

20 (1): 37–46. doi: 10.1177/001316446002000104.

Fenz S., Ekelhart A., 2009. Formalizing information

security knowledge, in Proc. of the 4th Int. Symposium

on Information, Computer, and Communications

Security, Sydney, Australia: ACM, 183 – 194.

Geller, J., Chun, S., and Wali, A., 2014. A Hybrid

Approach to Developing a Cyber Security Ontology.

In: Proc. of the 3rd Int. Conf. on Data Management

Technol. and Applicat., pp. 377-384, Vienna, Austria.

Geneiatakis D., Lambrinoudakis C., 2007. An ontology

description for SIP security flaws, Comput. Commun.,

vol. 30, pp. 1367-1374.

Goodrich M. T., Tamassia R., 2011. Introduction to

Computer Security, Addison Wesley.

Hearst M. A., 1992. Automatic acquisition of hyponyms

from large text corpora, in Proceedings of the 14th

conference on Computational linguistics – Vol. 2

Nantes, France: Assoc. for Computational Linguistics.

Herzog A., Shahmehri N., Duma C.. 2007. An Ontology

of Information Security, Information Security and

Privacy. 1(4), pp. 1-23.

Hindle D., 1990. Noun classification from predicate-

argument structures, in Proc. of the 28th Ann. Meeting

of Association for Computational Linguistics

Pittsburgh, Pennsylvania: Ass. for Comp. Linguistics.

Jain P., Hitzler P., Sheth A. P., Verma K., Yeh P. Z., 2013.

Ontology alignment for linked open data, in Proc. of

the 9th Int. Conference on the Semantic Web - Volume

Part I Shanghai, China: Springer-Verlag.

Katsurai M., Ogawa T., Haseyama M., 2014. A Cross-

Modal Approach for Extracting Semantic

Relationships Between Concepts Using Tagged

Images. IEEE Trans. on Multimedia 16(4):1059-1074.

Kullback S., Leibler R. A., 1951. On information and

sufficiency. Annals of Math. Statistics 22 (1): 79–86.

Lee C. H., Koo C., Na J. C., 2004. Automatic

Identification of Treatment Relations for Medical

Ontology Learning: An Exploratory Study. In

Knowledge Organization and the Global Information

Society: Proc. of the Eighth International ISKO

Conference. Ergon Verlag, Wurzburg, Germany, pp.

245-250.

Maedche A., Staab S., 2000. Mining Ontologies from

Text, in Knowledge Engineering and Knowledge

Management Methods, Models, and Tools, 12th

International Conference, EKAW 2000. Lecture Notes

in Computer Science, Volume 1937, pp. 189-202.

Meersman R., Tari Z., Kim A., Luo J., Kang M., 2005.

Security Ontology for Annotating Resources, in On

the Move to Meaningful Internet Systems 2005:

CoopIS, DOA, and ODBASE. vol. 3761: Springer, pp.

1483-99.

Musen M. A., Noy N.F., Shah N. H., Whetzel P. L., Chute

C.G., Story M.A., Smith B., NCBO team, 2012. The

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

314

National Center for Biomedical Ontology. J Am Med

Inform Assoc. Mar-Apr;19(2):190-5.

Novalija I., Mladenić D., Bradeško L., 2011, OntoPlus:

Text-driven ontology extension using ontology

content, structure and co-occurrence information.

Knowledge-Based Systems, 24(8), pp. 1261–1276.

Pattanasri N., Jatowt A., Tanaka K., 2007. Context-aware

search inside e-learning materials using textbook

ontologies, in Proc. of the Joint 9th Asia-Pacific Web

and 8th Int. Conf. on Web-age Inform. Management,

appeared as: Advances in data and web management,

LNCS 4505, Springer-Verlag, pp 658-669.

Salomon D., 2006. Foundations of Computer Security,

Springer Verlag, London, ISBN 978-1-8462-8193-8.

Turpin A., Scholer F., 2006. User performance versus

precision measures for simple search tasks, in

Proceedings of the 29th annual international ACM

SIGIR conference on Research and development in

information retrieval, Seattle, WA, 2006, pp. 11-18.

Vigna G., Kruegel C., Jonsson E., Undercoffer J., Joshi

A., Pinkston J., 2003. Modeling Computer Attacks:

An Ontology for Intrusion Detection, in Recent

Advances in Intrusion Detection. vol. 2820: Springer

Berlin Heidelberg, pp. 113-135.

Wali, A., Chun, S. A., Geller, J. 2013. A Bootstrapping

Approach for Developing Cyber Security Ontology

Using Textbook Index Terms. Proc. International

Conference on Availability, Reliability and Security

(ARES), University of Regensburg, Germany.

Wiebke P., 2004. A Set-Theoretical Approach for the

Induction of Inheritance Hierarchies, Electron Notes

Theor Comput Sci, vol. 53, pp. 13-13.

Identifying Pairs of Terms with Strong Semantic Connections in a Textbook Index

315
