Towards Constructive Abduction

Solving Abductive Problems with Constraint Programming

Antoni Lig˛eza

AGH - University of Science and Technology, al. Mickiewicza 30, 30-059 Krakow, Poland

Keywords:

Abduction, Constraint Programming, Model-based Diagnosis, Consistency-based Reasoning.

Abstract:

Abduction can be considered as a principal way of reasoning for problem solving. Abductive inference consists

in generation of hypotheses which explain — or logically imply — the phenomenon under investigation in

view of accessible background knowledge and are consistent with all other observations. Looking for such

hypotheses is typically performed with a spectrum of trial-and-error or search methods and tools. In case

of purely logical statements the hypotheses take the form of a set of facts, both positive and negative ones.

For example, in case of model based diagnostic reasoning, such diagnostic hypotheses can be generated by

consistency based reasoning with minimal search effort. In more complex cases, where values of certain

variables are to be found, pure backtracking search becomes inefﬁcient. In this paper we attempt to put

forward such abductive inference into a formal framework of Constraint Programming in order to enable the

use of constraint propagation techniques. The main idea behind this approach is to make abduction more

constructive. The discussion is illustrated with a diagnostic example of a multiplier-adder system.

1 INTRODUCTION

Abduction can be considered as one of principal ways

of reasoning for problem solving. Abductive infer-

ence consists in search for hypotheses which satisfy

some required conditions. For example, in case of

diagnostic reasoning they should explain — or logi-

cally imply — the phenomenon under investigation,

i.e. the observed failure. Note that accessible back-

ground knowledge must be taken into account and our

hypotheses must be consistent with all the knowledge

and observations.

Looking for such abductive hypotheses is typi-

cally performed with a spectrum of trial-and-error or

search methods and tools. In case of purely logi-

cal statements the hypotheses take the form of a set

of facts, both positive and negative ones. In case of

Model-Based Diagnostic Reasoning (MBDR) (Ham-

scher et al., 1992) such diagnostic hypotheses can

be generated by Consistency-Based Reasoning (CBR)

(Reiter, 1987) with reasonable search effort. In more

complex cases, where values of certain variables are

to be found as well, a pure search (.e.g. Backtrack-

ing depth-ﬁrst search or search on AND-OR graphs)

becomes inefﬁcient.

In this paper we attempt to put such abductive in-

ference into a formal framework of Constraint Pro-

gramming in order to enable the use of constraint

propagation techniques. The main aim is to make

abduction more constructive; this means that (i) the

hypotheses found should be more precise, and (ii) in-

consistent hypotheses should be eliminated in a more

efﬁcient way. The ideas are illustrated with a diagnos-

tic example of multiplier-adder system.

Existing methods of formal description of diag-

nostic inference are diversiﬁed. There are algebraic,

graph-based, and logical expert-like or model-based

diagnostic approaches. Some of the popular models

include Consistency-Based Reasoning (Reiter, 1987;

Hamscher et al., 1992; Lig˛eza, 2004), logical causal

graphs (Lig˛eza and Fuster-Parra, 1997; Lig˛eza, 2004),

and many other (Davis and Hamscher, 1992; Kor-

bicz et al., 2004). A recent survey of various ap-

proaches is given by (Travé-Massuyès, 2014). Fol-

lowing classical CBR, this paper explores mainly the

abductive approach and it is focused on employing

Constraint Programming for developing constructive

abduction, where purely logical abductive hypotheses

are enriched with exact numerical solutions.

The main point of interest in this work is the

role of Constraint Programming in abductive problem

solving, and mainly in diagnosis of technical systems.

An in-depth analysis of applying Constraint Program-

ming in modeling diagnostic reasoning is carried out.

352

Lig˛eza, A..

Towards Constructive Abduction - Solving Abductive Problems with Constraint Programming.

In Proceedings of the 7th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2015) - Volume 2: KEOD, pages 352-357

ISBN: 978-989-758-158-8

Moreover, a kind of Constraint Problem Solving ap-

proach is investigated with the ultimate goal of prun-

ing inconsistent behaviors.

The paper is organized as follows. In Section 2

we explain the nature of abduction from logical point

of view. In Section 3 a simple motivation example

is presented in detail. Section 4 covers some mini-

mal information on Constraint Programming. Finally,

Section 5 presents the main proposal of this paper, i.e.

constructive solution to abduction.

2 ABDUCTION

Abduction can be considered as a principal way of

reasoning for problem solving. Roughly speaking,

abduction consists in stating hypotheses that possibly

imply the facts observed to be true. Hence, the so-

called abductive inference consists in generation of

hypotheses which explain — or logically imply — the

phenomenon under investigation taking into account

all accessible background knowledge. The generated

hypotheses must also be consistent with all other ob-

servations.

Looking for such hypotheses in abductive reason-

ing is typically performed with a spectrum of trial-

and-error or search methods and tools. In case of

purely logical statements the hypotheses take the form

of a set of facts, both positive and negative ones. For

example, in case of Model-Based Diagnostic Reason-

ing (MBDR) such diagnostic hypotheses can be gen-

erated by Consistency-Based Reasoning (CBR) with

reasonable search effort.

Consider the following rule:

α =⇒ β, β

. (1)

In fact, this is a basic scheme for abductive inference.

Knowing that α =⇒ β, and observing that β holds, a

possible explanation of it is α.

Note that abduction is not a legal inference rule,

i.e. one preserving logical consequence. In our case,

α is not the logical consequence of the antecedents.

However, it is still a kind of production rule, often

used in practice. The main use of abduction is the

search for hypotheses explaining the current observa-

tions.

A general scheme of abductive reasoning is as fol-

lows. Consider a theory SD (System Description;

this is a set of logical formulas describing in a for-

mal way behavior of the system under discourse i.e.

background knowledge) and a set OBS of some cur-

rent observations to be explained. Abduction consists

in ﬁnding a set EXP of explanatory hypotheses, such

that:

• SD ∪ EXP |= OBS, i.e. the hypotheses fully ex-

plain current observations taking into account

knowledge about the system SD,

• SD ∪EXP must be consistent.

Typically, it is also required that EXP is minimal, i.e.

only the absolutely necessary hypotheses are speci-

ﬁed within EXP. Further, if several competitive hy-

potheses are available, the most likely ones may be

selected with some auxiliary tests, heuristics or statis-

tical information.

Note that, abductive reasoning, although might

provide invalid conclusions, constitutes a useful,

practical way of guessing potential solutions to prob-

lem stated by system description, current observa-

tions, and question for the reasons for them. It is

a natural way of diagnostic inference (both medical

and technical), and can be applied in puzzle solving,

constraint problem solving, and crime mystery solv-

ing

. Abduction, in order to be efﬁcient, must be com-

bined with reasonable search procedure and elimina-

tion method for incorrect solutions.

In case of diagnostic reasoning, abduction is of-

ten performed by detection and elimination of in-

consistencies, i.e the so-called Consistency-Based

Reasoning (CBR). The main idea of Model-Based

Consistency-Based Diagnosis was presented in the

seminal paper (Reiter, 1987), and widely explored in

(Reiter, 1987; Hamscher et al., 1992; Lig˛eza, 2004;

Davis and Hamscher, 1992; Korbicz et al., 2004). It

rests in generation of diagnostic hypotheses stating

which components of the system may be faulty (ab-

duction), so that assuming them faulty explains the

current observations with the model in mind in a con-

sistent way (deduction).

More precisely, taking into account the back-

ground knowledge, i.e. System Description SD and

the current observations OBS one looks for the so-

called conﬂict sets — these are sets of components

such that assuming all of them working correct is in-

consistent with the observations. In fact, we look for

such minimal sets and there may be several such sets.

Now, by assuming that at least one of the elements of

each minimal conﬂict set is faulty leads to regaining

consistency. Simultaneously, a set containing one ele-

ment from any minimal conﬂict set (the so-called hit-

ting set (Reiter, 1987)) form a hypothetical diagnosis

— a possible explanation of the observed misbehav-

ior.

In the next section we analyze such an approach

in a more detailed way.

Note that, contrary to what was stated in the books, it

was abduction — not deduction — as the principal way of

reasoning applied by Sherlock Holmes (Lig˛eza, 2006), p.

31.

Towards Constructive Abduction - Solving Abductive Problems with Constraint Programming

353

3 MOTIVATION EXAMPLE

In this section we brieﬂy recall a classical diagnostic

example of a feed-forward arithmetic circuit. This is

the multiplier-adder example presented in the seminal

paper by R. Reiter (Reiter, 1987). This example was

further re-explored in numerous papers, including se-

lected readings (Hamscher et al., 1992) and diagnos-

tic handbook (Chapter (Lig˛eza, 2004)). It was further

explored in the discussion carried out in domain liter-

ature concerning comparative analysis of diagnostic

approaches (Cordier and et al., 2000b; Cordier and

et al., 2000a; Travé-Massuyès, 2014). Here we shall

base on an in-depth analysis presented in (Lig˛eza

and Ko

scielny, 2008), and also explored in (Lig˛eza,

2009).

The basic, intuitive schema of the system is pre-

sented in Figure 1.

A

B

D

C

E

3

2

3

Y

X

3

Z

12

10

G

F

m3

m2

m1

a1

a2

Figure 1.

The system is composed of two layers. The ﬁrst

one contains three multipliers m1, m2, and m3, and

receiving the input signals A, B, C, D and E. The sec-

ond layer is composed of two adders, namely a1 and

a2, producing the output values of F and G. Only in-

puts (of the ﬁrst layer) and outputs of the system (of

the second layer) are directly observable. The inter-

mediate variables, namely X, Y and Z, are hidden and

cannot be observed.

Observe that the current state of the system is de-

ﬁned by the input values; they are: A=3, B=2, C=2,

D=3 and E=3. It is easy to check — under the as-

sumption of correct work of all the system elements

— that the outputs should be F=12 and G=12. Note

also that they should be equal to each other, which is

due to the symmetry of the system and the symmetry

of the input vales; this observation will be important

for the analysis and we shall see later on why.

Now, since the current value of F is incorrect,

namely F=10, the system is faulty. At least one of

its components must be faulty

. At this stage, for

In Model-Based Diagnosis it is typically assumed that

faulty behavior is caused by a fault of a named component

or a simultaneous fault of a set of such components; no

faults caused by faulty links, parameter setting or the in-

ternal structure are considered.

simplicity, we consider only correct components and

faulty ones; no details about the type of fault are taken

into consideration so far.

In order to perform diagnostic reasoning let us

start with abduction (Lig˛eza, 2004), (Lig˛eza and Ko

cielny, 2008); we shall try to build a conﬂict set speci-

fying hypothetical faulty elements; in other words we

search for a Disjunctive Conceptual Faults; DCF for

short (Lig˛eza and Ko

scielny, 2008).

Note that the value of F is inﬂuenced by the inputs

(observed) and the work of elements m1, m2 and a1

all of them are located in the signal path having direct

inﬂuence on the value of F. In other words, one can

say that there is direct causal dependency of inﬂuence

of m1, m2 and a1 on F. If all the three elements work

correctly, then the output would be correct. Since it

is not, we can conclude that a DCF

is observed: at

least one of the elements {m1, m2, a1} must be faulty.

Formally, we have

DCF

= {m1, m2, a1}

(2)

Note that, at this stage of reasoning only m1 and a1

are satisfactory explanations for the observed fault;

m2 alone is not a good explanation, because it is not

consistent with the observation G=12.

A further analysis leads to detection of DCF

(Lig˛eza and Ko

scielny, 2008): under the assumed

manifestations one of the elements {m1, a1, a2, m3}

must also be faulty.

In order to explain the origin of DCF

let us notice

that if all the four elements were correct, then Z=C*E

calculated by m3 must be equal to 6, and since G is

observed to be 12, Y (calculated backwards and un-

der the assumption that a2 works correctly) must also

equal 6; hence, if m1 is correct, then X must be 6

as well, and if a1 is correct F would be equal to 12.

Since it is not the case, at least one of the mentioned

components must be faulty. So we have the following

disjunctive conceptual fault:

DCF

= {m1, a1, a2, m3}

(3)

Note that the type of DCF

and DCF

are different;

this is due to their origin (or character). DCF

is of

causal type — all the elements directly inﬂuence the

conﬂicting variable. On the other hand, DCF

is of

constraint type; this is a kind of mathematical con-

straint which must be satisﬁed, but there is not neces-

sary causal dependency between the components and

the value of the faulty variable (F). This observation

(and fault classiﬁcation) will be used later on, when

we pass to qualitative analysis.

Note that if both the outputs were incorrect (e.g.

F=10 and G=14), then, in general case one can ob-

serve DCF

, DCF

and DCF

, where:

DCF

= {m2, m3, a2}.

(4)

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

354

The DCF

is a causal type conﬂict.

Note also, that whether the constraint-type DCF

is a valid conﬂict may depend on the observed out-

puts. For example, if F=10 and G=10 (both out-

puts are incorrect but equal), then the structure and

equations describing the work of the system does not

lead to a conceptual fault (Cordier and et al., 2000a;

Cordier and et al., 2000b).

The composition of the three disjunctive concep-

tual faults can be presented with use of an OR-matrix

for the diagnosed system (see Table 1): It deﬁnes the

Table 1: An OR binary diagnostic matrix for the adder sys-

tem (the lower level).

DCF m1 m2 m3 a1 a2

DCF

1 1 1

DCF

1 1 1 1

DCF

1 1 1

component elements for particular DCF-s for DCF

DCF

, and DCF

In the analyzed case, i.e. F being faulty and

G correct, the ﬁnal diagnoses for the considered

case are calculated as reduced elements of the Carte-

sian product of DCF

= {m1, m2, a1} and DCF

{m1, m3, a1, a2} (Lig˛eza and Ko

scielny, 2008). There

are the following potential diagnoses: D

= {m1},

= {a1}, D

= {a2, m2} and D

= {m2, m3}. They

all are shown in Figure 2.

{ a1 , m1 , m2 }

{ a1 , a2 , m1 , m3 }

D

1

D

2

D

4

D

3

Figure 2: Generation of potential diagnoses.

Note that so far only binary faults were considered

(i.e. a component may be faulty or not). In (Lig˛eza

and Ko

scielny, 2008) and further in (Lig˛eza, 2009)

an attempt at introducing qualitative diagnoses was

undertaken. After calculation of possible binary di-

agnoses their qualitative forms were considered, and

with use of inference rules representing simple con-

straints inconsistent qualitative diagnoses were elim-

inated. In the next section a still more precise, in-

depth, numerical analysis will be carried out. The

model of the system will be used as constraints. The

binary logical diagnoses (i.e. faulty or correct) will

be replaced with exact numerical characteristics.

4 CONSTRAINT

PROGRAMMING

In this section a brief note on Constraint Program-

ming is presented. We aim at explaining the basic

ideas of this promising technology for solving com-

plex, combinatorial problems. Our presentation is

based on (Lig˛eza, 2009).

A Constraint Satisfaction Problem (CSP) is one

where the goal consists in ﬁnding a legal assignment

of values to a set of predeﬁned variables so that a set

of given constraints is satisﬁed.

More formally, after (Dechter, 2003) let X =

, X

, . . . , X

} denote a set of variables, V =

, V

, . . . , V

} is a set of domains for the variables

in X and C is a set of constraints. Each constraint

is given by a pair (S

, R

), where S

is referred to as

the scope (or scheme) and consists of a selection of

variables from X, while R

is a relation deﬁned over a

Cartesian Product of domains appropriate for the vari-

ables in the scope. The Constraint Satisfaction Prob-

lem is given by the triple (X , V, C).

A solution to CSP given by (X, V, C) is any as-

signment of values to variables of X of the form

= v

, X

= v

, . . . , X

= v

}, such that v

∈ V

and for any constraint in (S

, R

) ∈ C, R

is satisﬁed

by the appropriate projection of the solution vector

, v

, . . . , v

) over variables of S

. Obviously, all the

constraints must be satisﬁed, and there can be more

one or many solutions; no solution may exist for an

over-constrained problem.

If the domains of V are ﬁnite (e.g. binary or dec-

imals digits are allowed) we speak about Finite Do-

mains (FD) problems. Obviously, such problems suf-

fer from combinatorial explosion while attempting at

solving them. Constraint Programming (CP) is a set

of techniques (or a technology) for efﬁcient dealing

which constraints.

The basic technique for solving a CSP given by

(X, V, C) consists in subsequent assignment of admis-

sible values to variables of X (e.g. by backtracking

search); the order is chosen in an arbitrary way, and it

can inﬂuence how fast a solution is found.

In order to improve search efﬁciency both heuris-

tics and strategies are used. The most typical strate-

gies are based on (i) variable ordering, (ii) values or-

dering, and (iii) look-ahead techniques. Especially

the look-ahead strategies can improve search efﬁ-

ciency. The principal idea is that the algorithm looks

how current decisions will affect the future search.

Towards Constructive Abduction - Solving Abductive Problems with Constraint Programming

355

5 ABDUCTION AS CONSTRAINT

PROGRAMMING

The key message of this section is to show that abduc-

tion can be solved in a constructive way with efﬁcient

approach of Constraint Programming. The multiplier-

adder example (presented in Section 3; see Figure 1)

will be used as an illustrative guideline. The obtained

diagnoses are more precise than in the case of purely

logical abduction of Consistency-Based Diagnosis. In

case of more than one potential diagnoses, the exact

values of variables can be used for further analysis,

and — if applicable — elimination of some spurious

diagnoses due to impossible values predicted by CP

or thanks to introduction of additional measurements

for conﬁrming or rejecting the generated values.

Let us refer to the multiplier-adder system as

presented in Figure 1 once again. As the starting

point consider the four logical potential diagnoses:

= {m1}, D

= {a1}, D

= {a2, m2} and D

{m2, m3}. They are logical in the sense that the only

information provided is of logical value: True if a di-

agnosis is valid or False if a diagnosis is invalid.

We shall build a constraint model for the diagnos-

tic case presented in Figure 1 so as more detailed, nu-

merical characteristics can be abducted.

First, the set of common observations is modeled

with simple constraints as follows

[...]

A #= 3,

B #= 2,

C #= 2,

D #= 3,

E #= 3,

F #= 10,

G #=12,

[...]

In this code excerpt comma is used to separate con-

straints, while #<op> (like #= or #>) is used to ex-

press constraints; several typical relations can be used

in place of <op>.

Now, consider the ﬁrst case of m1 being faulty. We

assume that a faulty multiplier produces the incorrect

output and its value can be expressed as multiplication

of the correct value by a factor K1/M1, where both the

numbers are integers. The model takes the following

form:

A * C * K1 #= X *M1,

B * D #= Y,

C * E #= Z,

X + Y #= F,

Y + Z #= G,

K1 #> 0, M1 #> 0.

The constraints are direct codes of SWI-Prolog; for

constraint modeling we use the clp(fd) package

The ﬁrst constraint models the fault of m1. For the

sake of operation in the domain of integers, M1 is

placed as a multiplication factor on the right-hand

side. The other constraints correspond directly to the

operation and connections of the components. The

produced output is:

X=4, Y=6, Z=6, K1=2, M1=3

and it can be easily checked by hand.

As the second case consider the diagnosis a1 be-

ing faulty. We assume that a this time it is the adder

that produces the incorrect output and its value can

be expressed as subtraction from the correct value a

factor A1 (an integer). The model takes the following

form:

A * C #= X,

B * D #= Y,

C * E #= Z,

X + Y - A1 #= F,

Y + Z #= G.

The fourth constraint models the fault of a1. The

other constraints correspond directly to the operation

and connections of the components. The produced

output is:

X=6, Y=6, Z=6, A1=2

and again, it can be easily checked by hand.

The third, a bit more complex case is the one of

active diagnosis {a2, m2}. The model for this case is

as follows:

A * C #= X,

B * D * K2 #= Y * M2,

C * E #= Z,

X + Y #= F,

Y + Z +A2 #= G,

K2 #> 0, M2 #> 0.

Variables K2/M2 model the multiplicative fault of m2

and variable A2 models the fault of a2. The produced

output is:

X=6, Y=4, Z=6, K2=2, M2=3, A2=2

and again, it can be easily checked by hand.

The fourth and perhaps the most complex case is

the one of active diagnosis {m2, m3}. Here we have to

introduce four variables, namely K2/M2 and K3/M3 for

modeling two multiplicative faults, namely the one of

m2 and m3, respectively. The model is as follows:

A * C #= X,

B * D * K2 #= Y * M2,

C * E * K3 #= Z * M3,

X + Y #= F,

Y + Z #= G,

K2 #> 0, M2 #> 0,

K3 #> 0, M3 #> 0.

The produced output is:

X=6, Y=4, Z=8, K2=2, M2=3, K3=4, M3=3

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

356

and again, it can be checked by hand.

In the above example we applied the simplest

methodology for constraint modeling applied to solv-

ing an abductive problem of ﬁnding detailed numeri-

cal characteristics — in fact numerical models — of

minimal diagnoses. The basic stages can be summa-

rized as follows:

• take a minimal diagnosis for detailed examina-

tion; it can be composed of k components,

• for any component deﬁne one or more (as in the

case of multipliers) variables with use of which

one can capture the idea of the misbehavior of the

component,

• deﬁne the domains of the variables (a set neces-

sary in CP with ﬁnite domains),

• deﬁne the constraints imposed on these variables

for the analyzed case, and ﬁnally

• using the intended deﬁnition of components in

presence of the assumed fault, deﬁne the con-

straints modeling the work of all the components

(the correct ones and the faulty ones).

The ﬂow (links) between the component are deﬁned

by the appropriate use of deﬁned input-output and in-

ternal variables. Note that the direction of ﬂow, or

causality is not of interest here, and one does not need

to bother about that. In fact, what we look for is a sta-

ble, numerical solution consistent with the diagnoses

and the observations. Such a model may be used for

further analysis and elimination of unfeasible diag-

noses.

In case of many potential diagnoses, the procedure

should be repeated for each diagnosis.

6 CONCLUSIONS

The paper presents a note on applying Constraint Pro-

gramming for enriching abductive reasoning with ex-

act (numerical) knowledge. In this way not only log-

ical or qualitative solutions are obtained (of the form

yes/no), but detailed numerical characteristics of the

generated solutions are provided. This kind of ap-

proach we call constructive abduction.

The models presented in Section 5 were relatively

simple, and provided for all four diagnoses separately.

But it seems straightforward to build one, general

model by introducing another ﬁve binary variables for

representing if a component is faulty or not. In this

way appropriate subset of all constraints can be made

active, while inappropriate constraints are eliminated.

Finally, the focus of the paper was on a diagnostic

example, but it seems that this kind of approach can

be applied in a wide spectrum of abductive problems.

ACKNOWLEDGMENTS

The presented research was carried out within

AGH University of Science and Technology Internal

Project No. 11.11.120.859.

REFERENCES

Cordier, M.-O. and et al. (2000a). Ai and automatic con-

trol approaches of model-based diagnosis: Links and

underlying hypotheses. In Edelmayer, A. M., editor,

Preprints: SAFEPROCESS 2000, 4th IFAC Sympo-

sium on Fault Detection, Supervision and Safety for

Technical Processes, pages 274–279. IFAC.

Cordier, M.-O. and et al. (2000b). A comparative analysis of

ai and control theory approaches to model-based diag-

nosis. In Horn, W., editor, ECAI’2000. 14th European

Conference on Artiﬁcial Intelligence, pages 136–140.

IOS Press.

Davis, R. and Hamscher, W. (1992). Model-Based Reason-

ing: Troubleshooting, pages 3–24. Morgan Kaufmann

Publishers, San Mateo, CA.

Dechter, R. (2003). Constraint Processing. Elsevier Sci-

ence.

Hamscher, W., Console, L., and de Kleer, J., editors (1992).

Readings in Model-Based Diagnosis. Morgan Kauf-

mann, San Mateo, CA.

Korbicz, J., Ko

scielny, J., Kowalczuk, Z., and Cholewa, W.,

editors (2004). Fault Diagnosis. Models, Artiﬁcial In-

telligence, Applications. Springer-Verlag, Berlin.

Lig˛eza, A. (2004). Selected Methods of Knowledge Engi-

neering in System Diagnosis, chapter 16, pages 633–

668. In: (Korbicz et al., 2004). Springer-Verlag.

Lig˛eza, A. (2006). Logical Foundations for Rule-Based Sys-

tems. Springer-Verlag, Berlin, Heidelberg.

Lig˛eza, A. (2009). A Constraint Satisfaction Framework

for Diagnostic Problems, pages 255–262. Control and

Computer Science. Information Technology, Control

Theory, Fault and System Diagnosis. Pomeranian Sci-

ence and Technology Publisher PWNT, Gda

nsk.

Lig˛eza, A. and Fuster-Parra, P. (1997). And/or/not causal

graphs – a model for diagnostic reasoning. Ap-

plied Mathematics and Computer Science, Vol. 7, No.

1:185–203.

Lig˛eza, A. and Ko

scielny, J. M. (2008). A new approach

to multiple fault diagnosis. combination of diagnostic

matrices, graphs, algebraic and rule-based models. the

case of two-layer models. Int. J. Appl. Math. Comput.

Sci., 18(4):465–476.

Reiter, R. (1987). A theory of diagnosis from ﬁrst princi-

ples. Artiﬁcial Intelligence, 32:57–95.

Travé-Massuyès, L. (2014). Bridges between diagnosis the-

ories from control and ai perspectives. In Korbicz, J.

and Kowal, M., editors, Intelligent Systems in Tech-

nical and medila Diagnosis, pages 3–28. Springer-

Verlag.

Towards Constructive Abduction - Solving Abductive Problems with Constraint Programming

357
