Study of Improved BP Algorithm based on Gradient Descent and

Numerical Optimization

Qiuhong Sun

1, 2

, Weihong Bi

and Xinhang Xu

YanShan University, Qinhuangdao 066004, China

Hebei University of Science and Technology, Shijiazhuang 050000, China

State Grid Hebei Electric Power Research Institute, Shijiazhuang 050000, China

sunqiuhong@hebust.edu.cn

Keywords: Gradient Descent, Numerical Optimization, Improved BP Algorithm.

Abstract: Studied limitations exist in BP model, and discussed the proposed improved algorithm based on BP neural

network. Respectively, from the third of the aspects discussed based on improved gradient descent

algorithm and improved algorithm based on numerical optimization. Research results showed that the

comprehensive method is better than the standard BP algorithm in terms of the number of iterations, the

training time and the mean square error and the like, of additional momentum and adaptive outstanding

performance parameter method. Researches showed that the Marquardt-Levenberg algorithm neural

network convergence fastest training times at least.

1 INTRODUCTION

Along with the application of information

management system indifferent fields, the data are

continuously stored in the database. Among them,

people expect to find out potential knowledge that

will help them make decisions. The emergence and

development of data mining are just based on this

expectation. As a midpoint of different subject

studies, data mining involves a great deal of subjects

such as database, statistic, machine learning,

artificial intelligence, high performance computing,

pattern recognition and data visualization etc.

Among them, artificial neural network is widely

used due to its ability of inherent non-linear

processing, adaptive learning and high fault-

tolerance.

BP neural network is a feedforward network, the

most representative type of network. This class is a

multilayer neural network model that map neural

network, using a minimum variance of learning, is

one of the most widely used neural network model.

Multilayer Perceptron network is a kind of three or

more sectors of neural networks. A typical

multilayer perceptron network is three, feedforward

class network, namely: input layer, hidden layer

(also called intermediate layer), the output layer.

Each neuron between adjacent layers achieves full

connection, that is, each neuron and the next layer

on layer of each neuron to achieve full connection,

and each connection between neurons is not. In

practical applications, BP network can be used for

classification, regression and time series forecasting

and other data mining applications, and pattern

recognition problem research, nonlinear mapping

problem, such as handwriting recognition, image

processing, predictive control, function

approximation, data compression and so on.

2 LIMITATIONS OF THE

ALGORITHM

In data mining field, although BP network model is

currently the most widely used network model, gets

good benefits in practical application, and is

maturing in theory, but it also has its own limitations

and shortcomings, its uncertainty performance in the

training process. These limitations are mainly

concentrated in three areas: slow convergence and

easy to fall into local minima and completely unable

to train a network phenomenon.

In recent years, many researchers made many

useful improvements on BP network, put forward a

number of algorithms to improve the program, such

as rapid BP propagation algorithm, the extended

Kalman filter algorithm, the second-order

452

Xu X., Bi W. and Sun Q.

Study of Improved BP Algorithm based on Gradient Descent and Numerical Optimization.

DOI: 10.5220/0006028404520456

In Proceedings of the Information Science and Management Engineering III (ISME 2015), pages 452-456

ISBN: 978-989-758-163-2

optimization algorithm, the optimal filtering method,

and so on. Its main purpose is to avoid falling into

local minima and improve the convergence rate.

Improve people based on the standard BP algorithm

performed faster convergence than the standard

gradient method of dozens or even hundreds of

times. But they still are not universally applicable,

both have their own advantages or defects.

Because a good prospect of artificial neural

networks in data mining, and success stories in the

practical application, at home and abroad have

carried out the neural network data mining for

theoretical research. In artificial neural networks,

back-propagation algorithm based on BP neural

network has occupied a very important position, so

the last decade, many researchers have done a

thorough study and proposed many improved

algorithm and architecture optimization strategy.

Which means learning algorithms based on neural

network model, to find a neural network connection

weights adjustment algorithm, and meet the

requirements of the study sample, but also has a

faster learning speed. The main goal of improved

algorithm is how to reduce the limitations of BP

network, speed up training networks in the actual

application of data mining process, to avoid falling

into local minima, while enhancing the ability of

other important network. The structure optimization

strategy refers to specific application problems to

find an optimal network structure, mainly on how to

determine the number of hidden layers and the

number of hidden nodes of each hidden layer, and

enhance the generalization capability of the network.

In the field of data mining, although BP network

model has been currently the most widely used

network model, made in the practical application of

the good benefits, but in theory are maturing, but it

also has its own limitations and shortcomings, its

uncertainty performance in the training process.

These limitations are mainly concentrated in the

following three aspects:

(1) slow convergence

(2) easy to fall into local minimum point

(3) there is a phenomenon that the network is

completely unable training

3 IMPROVED BP ALGORITHM

BASED ON GRADIENT

DESCENT

In recent years, many researchers BP network made

many useful improvements, put forward a number of

algorithms to improve the program, such as rapid BP

propagation algorithm, the extended Kalman filter

algorithm, the second-order optimization algorithm,

the optimal filtering method, and so on. Its main

purpose is to avoid falling into local minima and

improve the convergence rate. Improve people based

on the standard BP algorithm performed faster

convergence than the standard gradient method of

dozens or even hundreds of times. But they still are

not universally applicable, both have their own

advantages or defects.

Improved algorithm based on gradient descent.

Gradient descent method is standard on the basis of

the objective function by calculating the gradient

network weights and closing values corrected,

generally used only third-order gradient information

on weights and thresholds of the objective function.

Weights standard gradient descent values and

thresholds amended iterative process can be

expressed as:













kkk

WfWW 





(1)

Among them,





by the value of the ownership of

the network consisting of a vector and threshold, α is

the learning rate,









as the objective function

(instead of using the objective function using the

error function performance because sometimes

contains error than other items),







Wf

represents

the gradient of the objective function. Although the

standard BP algorithm to train the network provides

a simple and effective method, but because of the

training process as a smaller permanent α constant,

and thus slow convergence and local minimum

problems. To solve these problems, people made a

lot of improvements in the study algorithm BP

learning algorithm on the basis of its application.

More representative are the following:

(1) Additional Momentum Method.

when updating their weight and closing value ,

additional momentum, not only to consider the

role of error in the gradient, but also consider the

impact of trends in the error surface. It allows to

ignore small changes in properties on the

network. In the absence of additional momentum

effect, the network may be caught in shallow

local minima, with additional momentum effect

is likely to slip these minima.

This method is on the basis of the standard BP

algorithm, in every weight and the closing value plus

a proportional change in weight and the note of the

previous amount of change in value, and the reverse

propagation method to generate a new right value

change. Weights and closing iterative process value

Study of Improved BP Algorithm based on Gradient Descent and Numerical Optimization

453

Study of Improved BP Algorithm based on Gradient Descent and Numerical Optimization

453

correction can be expressed as:

  

kWmcpmckW

ijjiij





(2)













kbmcmckb

iii





(3)

Where k is the number of training, mc is the

momentum factor, and generally is about 0.95.

Substantive additional momentum law will affect

a recent change in weight, to pass through a

momentum factor. When the momentum factor

value is zero, change the weight is only produced

according to the gradient descent method; when the

momentum factor value is 1, the new weight change

is the last weight change, and produced according to

the gradient method changing portions were ignored.

To do this adjustment when the change will increase

the weight of the bottom surface toward the mean

direction error after momentum. When the network

weights into the flat area at the bottom of the error

surface, δ

will become very small, so,

 

kWkW

ijij

 1

, thereby preventing



01  kW

situation appears this will help the

network to jump out of local minima in the error

surface.

According to the design principles of additional

momentum, the weight correction cause too much

growth results in an error when the new weights was

canceled without being adopted, and stopped the

momentum effect, so the network does not enter the

larger error surface; when the new error rate of

change of its old value exceeds the maximum error

rate of change of a pre-set time, we have the right to

cancel the calculated value change. The maximum

error rate of change is generally get the value of

1.04, thus making additional momentum method of

training program design, you must add a condition to

determine the proper use of weights correction

formula. General training program for using the

momentum method to determine the conditions as

follows:

 

















，其他情况

当

kSSEkSSE

mc 1,95.0

04.11,0

(4)

Wherein, SSE (k) represents the output error of the

network timing k.

Additional momentum method can solve some

extent local minimum, appropriate to speed up the

convergence, but if improper initial iteration

direction, the train will be easy access to the

platform area, in the calculation process, also

because of some wrong adjustments while adding

momentum to adjust the rear misleading; the size of

the momentum factor which should be selected as

the training problem complexity increases and

decreases training otherwise prone to oscillation and

divergence, for practical applications, we should

take a smaller momentum factor.

(2) Adaptive Learning Rate Method.

The basic idea of this approach is the learning

rate η error changes should be based on

adaptively adjusted to make the connection

weights to adjust to changes in the direction of

error is reduced. Adaptive learning rate

adjustment criteria are: correction value check

weights really reduce the error function, if it fell,

then the selected learning rate value is small, you

can increase it by an amount; if not reducing

network error, then produced an overshoot, so

accordingly you should reduce the value of

learning rate. Specific adaptive learning rate

adjustment formula is as follows:







   



















其他情况

当

1,7.0

1,05.1

kSSEkSSEk



(5)

Wherein, SSE (k) represents the output error of the

network timing k.

In the standard BP algorithm, the learning rate α

in the training process remains constant. The basic

idea of adaptive learning rate law: maintaining the

stability of the training, so that each correction

weights for iterative steps as large as possible. The

process can be expressed as

















kkkk

WfWW 





(6)

Adaptive learning rate is conducive to shorten the

learning time. One of the important reasons for the

slow convergence standard BP algorithm is the

learning coefficient poor choice. The learning rate is

selected too small, too slow convergence; learning

rate is chosen too large, it is possible to amend

overdone, leading to network flapping diverge. The

research shows that, in a certain range to increase

the learning coefficient, can greatly speed up the

efficiency of learning, get more than the standard BP

algorithm converges faster. However, if









Wf

small, there are still a small amount of correction

weight problems, resulting in low learning rate.

(3) Additional Momentum and Adaptive Learning

Rate Binding Method.

Because of the additional momentum method can

alleviate network into local minima situation,

and adaptive learning rate method and can speed

up the convergence of the network, so some

ISME 2015 - Information Science and Management Engineering III

454

ISME 2015 - International Conference on Information System and Management Engineering

454

scholars both together to form a new algorithm

that additional momentum and adaptive learning

rate binding assay. Experimental results show

that the comprehensive method than the standard

BP algorithm in terms of the number of

iterations, the training time and the mean square

error and the like, of additional momentum and

adaptive outstanding performance parameter

method. This paper mainly uses this algorithm

can improve the performance of the neural

network can learn, and confirm the validity of

the algorithm in practical application.

4 IMPROVED ALGORITHM

BASED ON NUMERICAL

OPTIMIZATION

BP network training is essentially a nonlinear

objective function optimization problem. People

study of nonlinear optimization problem for several

hundred years ,and many traditional numerical

optimization method is also faster convergence, and

therefore it is natural to think of numerical

optimization algorithms based on BP network right

on the plant for training. Gradient descent method is

different, based on numerical optimization

algorithms using not only the first-order derivative

information of the objective function, and often use

the second derivative information of the objective

function. Such algorithms include quasi-Newton

method, Levenberg-Marquardt method and the

conjugate gradient method, which can be described

as unified





 



   

















tkkk

WSWW

WSWfWf



min

(7)

Among them, the ownership and the threshold

values of the network composed of vector





, the

search direction









by the composition of each

component W vector space,





is in









so that







1k

in the direction to achieve a very small

step. Thus, network optimization method weights

can be divided into the following two steps: a) First,

determine the current iteration of the best search

direction; b) finding the optimal iterative step in this

direction. Three methods discussed below, the

difference is different from the direction in the

search for the best choice.

(1) Quasi-Newton Method.

Quasi-Newton method is a common method for

fast optimization, convergence is faster than a

ladder degrees. Quasi-Newton method in the

search direction improvement over gradient

method, it is not only the use of the criterion

function gradient point in the search, but also

takes advantage of its second derivative matrix,

resulting in increased computational complexity.

There are typical BFGS algorithm and step

tangent algorithm (One step secant, OSS).

BFGS algorithms usually require very little

number of iterations will be able to converge, but

it each iteration of the computation and memory

requirements greater than the conjugate gradient

method. Wherein the BFGS algorithm in training

small network better, step algorithm is tangent

compromise conjugate gradient method and

quasi-Newton method, each step required

memory and computation are less than BFGS

algorithm.

(2) Conjugate Gradient Method.

When using the conjugate gradient vector to

determine the conjugate direction, said this

algorithm co reels gradient method. 1990 J.

Leonard and MA Kramer conjugate gradient

method and line search strategies together. In the

conjugate gradient method, conjugate direction

along the line search, convergence rate than the

general gradient descent method is much faster.

In a typical training algorithm is the use of

learning rate determines the weight and step off

the updated values, and in most conjugate

gradient algorithm weights each step repeatedly

adjust, along with conjugate gradient line search

to determine the weights step. Conjugate

gradient method may be necessary to calculate or

store information on the second derivative has a

function of second-order method, compared with

the quasi-Newton method, its computational cost

is very low, and therefore very useful for large-

scale problems.

(3) Levenberg-Marquardt Algorithm.

Marquardt-Levenberg optimization algorithm

can be seen as a kind of quasi-Newton

approximation method. Conventional BP

algorithm correction weight values only when

the gradient of the error function of the weights,

ie the first derivative information. By the second

derivative of the error function were corrected

weights, can greatly accelerate the convergence

speed of BP network. This is the basic starting

point Quasi - Newton Method.

The objective function is assumed to be a network

error, so that by adjusting the minimum. By quasi-

Newton method, can be expressed as: where is the

Study of Improved BP Algorithm based on Gradient Descent and Numerical Optimization

455

Study of Improved BP Algorithm based on Gradient Descent and Numerical Optimization

455

Hessian matrix for the gradient, if it is assumed as a

function of the square and that there are













wewJwV



(8)

















wSwJwJwV



On the Gauss-Newton method,





assuming

approximately zero, while Marquardt-Levenberg

optimization algorithm further modified Gauss-

Newton method,

making







wewJlwJwJw

1





, where μ

is a scalar. It depends on μ, between the gradient

descent algorithm ( μ → ∞ ) and quasi-Newton

method (μ → 0) in two extreme cases change the

optimization.

5 CONCLUSION

Research results show that the comprehensive

method than the standard BP algorithm in terms of

the number of iterations, the training time and the

mean square error and the like, of additional

momentum and adaptive outstanding performance

parameter method.

As seen above, Marquardt-Levenberg algorithm

is dynamically adjusting the damping factor, is

changed according to the results of the iteration

convergence direction, so as to achieve the purpose

of decreasing the error. The key step of the

algorithm is to calculate the Jacobian matrix. Its

advantage is that when there are fewer number of

network weights converge very quickly, you can

make a shorter study time in practical applications.

Research show that the Marquardt-Levenberg

algorithm neural network convergence fastest

training times at least.

REFERENCES

Li chungui etc. Traffic Flow forcasting Algorithm using

Simulated Annealing Genetic BP Network.

Proceedings of 2010 International Conference on

Measuring Technology and Mechatronics Automation

2010.

Shan Li, Haibing Chen, JunXian Yun etc. Optimization

for Cyclosporine Blood Concentration Prediction

Based on Genetic Algorithm-BP Neutal Network.

Proceedings of Second International Conference on

Genetic and Evolutionary Computing. 2008.

Yu-min Chiang, Huei-min Chiang, Shang-yi Lin. The

Application of Ant Colony Optimization for Gene

Selection in Microarray-based Cancer Classification.

Proceedings of Seventh International Conference on

Machine Learing and Cybernetics. 2008.

Li Wang, Dong-qing Wang, Ning Ding. Research on BP

Neural Network Optimal Method Based on Improved

Ant Colony Algorithm. IEEE Computer Society

Proceedings of 2010 Second International Conference

on Computer Engineering and Applications. 2010.

Yan Zhao, Zhongjun Xiao, Jiayu Kang. Optimization

Design Based on Improved Ant Colony Algorithm for

PID Parameters of BP Neural Network. Proceedings

of 2010 2nd International Asia Conference on

Informatics in control, Automation and Robotics.

2010.

Yuxiang Shao, Qing Chen. Application Ant Colony

Neural Network in Lithology Recognition And

Prediction:Evidence from China. Proceedings of 2008

IEEE Pacific-Asia Workshop on Computational

Intelligence and Industrial Applications. 2008.

Wu Yuguo, Song Chongzhi. Design Optimization Based

on Neural Networks and Ant Colony Optimization.

Proceedings of 2007 Second IEEE Conference on

Industrial Electronics and Applications. 2007.

Yu-min Chiang, Huei-min Chiang, Shang-yi Lin. The

Application of Ant Colony Optimization for Gene

Selection in Microarray-based Cancer Classification.

Proceedings of Seventh International Conference on

Machine Learing and Cybernetics. 2008.

ISME 2015 - Information Science and Management Engineering III

456

ISME 2015 - International Conference on Information System and Management Engineering

456
