An Empirical Study on the Perception of Metamodel Quality

Georg Hinkel

, Max Kramer

, Erik Burger

, Misha Strittmatter

and Lucia Happe

Forschungszentrum Informatik (FZI), Haid-und-Neu-Straße 10-14, Karlsruhe, Germany

Karlsruhe Institute of Technology (KIT), Am Fasanengarten 5, Karlsruhe, Germany

Keywords:

Metamodel, Perception, Empirical Study.

Abstract:

Despite the crucial importance of metamodeling for Model- Driven Engineering (MDE), there is still little dis-

cussion about the quality of metamodel design and its consequences in model-driven development processes.

Presumably, the quality of metamodel design strongly affects the models and transformations that conform to

these metamodels. However, so far surprisingly few work has been done to validate the characterization of

metamodel quality. A proper characterization is essential to automate quality improvements for metamodels

such as metamodel refactorings. In this paper, we present an empirical study to sharpen the understanding of

the perception of metamodel quality. In the study, 24 participants created metamodels of two different domains

and evaluated the metamodels in a peer review process according to an evaluation sheet. The results show that

the perceived quality was mainly driven by the metamodels completeness, correctness and modularity while

other quality attributes could be neglected.

1 INTRODUCTION

In Model-Driven Engineering (MDE), models are not

only used to document the design of a system, but also

to perform analyses, to run simulations, or to gener-

ate implementation code. To support such automated

transformations, individual model instances have to

conform to a metamodel that is expressed using a

meta-modeling language. All textual and visual ed-

itors for models and all transformations to other mod-

els or code depend directly or indirectly on this meta-

model. As a result, all development steps that involve

the usage or development of an editor or transforma-

tion are affected by the metamodel. Thus, metamod-

els are central artifacts of many MDE processes and

tools.

The inﬂuence of metamodels on MDE processes

and artifacts, as well as the quality of metamodels,

has, however, not been studied and discussed enough

in the community. There is no clear notion of meta-

model quality in literature. Software quality stan-

dards, such as ISO/IEC 25010, are only partly ap-

plicable since these standards are intended for com-

plete software products and systems, but not for de-

velopment artifacts such as metamodels. The quality

characteristics of these standards can only be used to

clarify which quality aspects of a metamodel are con-

sidered, but they do not explain how. Furthermore,

they cannot be used to determine how a general notion

of metamodel quality is assembled from these quality

characteristics. In order to agree on a common notion

of quality for metamodels, and in order to eventually

measure it, it is an important step to characterize how

the quality of metamodels is perceived.

In literature, however, existing characterizations

of metamodel quality, such as those from Bertoa et al.

(Bertoa and Vallecillo, 2010), have not been validated

on an empirical basis. Further tools exist that cor-

rect metamodel design ﬂaws (L

opez-Fern

andez et al.,

2014), but they are only based on personal experi-

ence and expertise, without a proper validation. In

particular, it is not clear whether the improvement of

some quality attributes will have an impact on the

overall quality of a metamodel at all. Therefore, a

validated characterization of metamodel quality is es-

sential for automated quality improvements, such as

refactorings.

The idea in this paper is that developers assess the

metamodel quality based on all their experience with

model-driven tools. Thus, the quality of the meta-

models is not restricted to a particular application

domain, such as particular analysis methods, model

transformation, or instance creation. Rather, we try to

assess the quality of metamodels as a whole.

This approach is beneﬁcial especially in platform

projects where concrete applications are not entirely

clear at the beginning of the project. For example, the

Neurorobotics-platform of the Human Brain Project

Hinkel, G., Kramer, M., Burger, E., Strittmatter, M. and Happe, L.

An Empirical Study on the Perception of Metamodel Quality.

DOI: 10.5220/0005632001450152

In Proceedings of the 4th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2016), pages 145-152

ISBN: 978-989-758-168-7

145

(HBP) tries to support neuroscientists in integrating

neuronal networks into robot controllers to provide

validation methods for neuronal network models and

models of the neurophysiology. First neurophysiol-

ogy models have been created with the pragmatics to

simulate them in the platform (Hinkel et al., 2015).

However, we also want to encourage neuroscientists

to analyze or automatically optimize these neurophys-

iology models and are thus looking for criteria that

the (meta-)models have to fulﬁll. Moreover, the HBP

is designed for a total duration of ten years. During

this period of time, it is likely that the metamodel will

degrade unless extra effort is spent for its refactor-

ings (Lehman, 1974; Lehman et al., 1997). For such

refactorings, it is important to understand the facets

of metamodel quality.

In this paper, we present the design and results of

an empirical study on the characterization of meta-

model quality perception: 24 professional develop-

ers and students assessed the overall quality and indi-

vidual quality characterstics by completing 89 copies

of a questionnaire. We performed correlation tests

and show that out of 10 individual characteristics

only modularity, completeness, and correctness had

a signiﬁcant inﬂuence on the perception of overall

metamodel quality within our study. Our empirical

study provides insights on how developers perceive

the quality of metamodels. All results and support-

ing material such as the questionnaires are available

online

The remainder of this paper is structured as fol-

lows: Section 2 explains the experiment setup. Sec-

tion 3 presents the results from our empirical study.

Section 4 discusses threats to validity. Section 5 ex-

plains our plans for future work. Finally, Section 6

discusses related work before Section 7 concludes the

paper.

2 EXPERIMENT SETUP

We performed a controlled experiment to obtain man-

ual assessments of metamodel quality. In order to

eliminate unwanted effects of metamodel properties

that may inﬂuence the quality assessment but that are

not important when measuring metamodel quality, the

participants also created the metamodels to be judged

in this controlled setting. The 24 participants created

metamodels for two domains. Each domain was de-

scribed in a text and the participants were asked to

design a metamodel according to it. The participants

https://sdqweb.ipd.kit.edu/wiki/Metamodel Quality

sdqweb.ipd.kit.edu/wiki/Metamodel Quality

consisted of professional researchers as well as stu-

dents from a practical course on MDE. They were

randomly assigned to the domains, ensuring a balance

between the domains.

The ﬁrst domain concerned user interfaces of mo-

bile applications. Participants were asked to create

a metamodel that would be able to capture designs

of the user interface of mobile applications so that

these user interface descriptions could later be used

platform-independently. The participants created the

metamodel according to a domain description in nat-

ural language from scratch. We refer to creating the

metamodel of this mobile applications domain as the

Mobiles scenario.

The second domain was business process model-

ing. Here, the participants were given a truncated

metamodel of the Business Process Modeling Lan-

guage and Notation (BPMN) (The Object Manage-

ment Group, 2011) where the packages containing

conversations and collaborations had been removed.

The original metamodel can be found in the BPMN

packages of the Eclipse project. The task for the

participants was to reproduce the missing part of

the metamodel according to a textual description of

the requirements for the collaborations and conversa-

tions. We refer to the task of completing this meta-

model as the BPMN scenario.

After creating the metamodel, all participants

were given several metamodels for the same domain

that were created by other participants and rated their

quality according to a questionnaire. In a next step,

the participants were given the textual description of

the domain that they were not creating a metamodel

for and evaluated the quality of several metamodels

for that scenario.

Given the limited time-box of the experiment, not

all of the participants returned an equal amount of

ﬁlled questionnaires.

The questionnaire asked the participants to eval-

uate the perceived overall quality of the metamod-

els as well as evaluations on the following quality

attributes: complexity, understandability, modularity,

conciseness, completeness, correctness, changability,

consistency, instance creation and transformation cre-

ation, adapted from Bertoa et al. (Bertoa and Valle-

cillo, 2010). The participants were asked to rate the

quality attributes on a six level Likert-scale.

3 RESULTS

We have received 89 responses for our evaluation

sheet out of which 46 are assessing the quality of 11

metamodels in the Mobiles domain and 43 are assess-

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

146

ing the quality of 12 metamodels in the BPMN do-

main. All evaluation sheets assess the overall qual-

ity of the metamodels as well as the quality attributes

we mentioned in Section 2. The assessment could be

done in the grades very bad (-5), bad (-3), slightly

bad (-1), slightly good (+1), good (+3) and very good

(+5). For Complexity, a good Complexity means that

the metamodel is simple, i.e. perceived as not com-

plex. The quality attributes were brieﬂy described in

the questionnaire, though understandability was in-

troduced as the degree in which a metamodel is self-

describing.

We analyzed the correlations between the qual-

ity attributes and performed an analysis of variance

(ANOVA) on the questionnaire responses. We did

this for each of the scenarios separately and once for

both of them combined, adding the scenario itself as

another inﬂuence factor. Unfortunately, not all of

the questionnaires were complete, so we had to omit

about half of the questionnaires for the ANOVA due

to some missing entries.

In the remainder of this section, we present the

results for the correlation analysis in order to reason

about the validity of our results and on future study

designs in Section 3.1. Afterwards, we present our

ﬁndings from the Mobiles scenario in Section 3.2,

from the BPMN scenario in Section 3.3 and present

the results of an ANOVA spanning over both domains

for a generalization of the results in Section 3.4.

3.1 Correlation between Quality

Attributes

The responses that we got from our experiment al-

low us to analyze how well the quality attributes de-

scribe the metamodel quality in our experiment in

general. Therefore, we printed the correlations of the

quality attributes to each other in Table 1. The table

shows Pearson correlation coefﬁcients, but as the Lik-

ert scale is equidistant, this coincides with the Spear-

man correlation coefﬁcient. The analysis of these

correlations allow us to reason on the design of fu-

ture empirical studies with regard to the quality at-

tributes that we are asking from participants. Ideally,

the quality attributes should be orthogonal to each

other, each describing different aspects of the meta-

model with no correlation to other aspects. Thus, Ta-

ble 1 should show ones on the diagonal and zeroes

elsewhere. However, some correlations may always

be introduced by random. But if the correlations be-

tween the quality attributes get too big, they invalidate

the ANOVA in the subsequent sections. To highlight

strong correlations (ρ > 0.5) between different quality

attributes, we have printed them in bold.

The strongest correlation by far can be observed

between completeness and correctness. This seems

reasonable since completeness can be seen as a form

of correctness. In fact, some studies treat complete-

ness and correctness as one quality attribute. We

can support this methodology for metamodels since

these quality attributes have a very strong correlation

(ρ = 0.73). On the other hand, understandability and

conciseness also often go together but only showed a

weaker correlation (ρ = 0.56). Here, we argue that

these quality attributes are perceived signiﬁcantly dif-

ferent and thus should not be recorded together.

Only three other strong correlations have been

found within our experiment. Instance creation

strongly correlates with both transformations and

complexity. However, since this correlation is not as

strong as the correlation between completeness and

correctness and even more importantly, the creation of

transformations does not correlate with the complex-

ity, we argue that it is better to treat these two quality

attributes separately. Furthermore, there is a correla-

tion between complexity and understandability. This

is also reasonable and supports the intuition that com-

plex metamodels are hard to understand. However,

this correlation is by far not as strong as the correla-

tion between completeness and correctness and there-

fore have their right as separated quality attributes.

As a result, we argue that the quality attributes that

we used for our experiment to evaluate aspects of the

metamodel quality are valid except that completeness

and correctness should have been treated as a single

quality attribute. We will use this insight in the design

of future experiments.

3.2 Important Quality Attributes in the

Mobiles Scenario

In the Mobiles scenario, the second most important

quality attribute was the completeness of the meta-

model (p = 0.00013). This may be caused by the fact

that the Mobile domain as presented to the partici-

pants apparently seemed very complex and thus many

metamodels were perceived as incomplete. It seems

surprising that the inﬂuence of a metamodels correct-

ness is not even signiﬁcant on the 10%-level but this

may be due to the fact that completeness and cor-

rectness of the metamodels were strongly correlated

(ρ = 0.83) making completeness and correctness to

some extend interchangeable.

A remarkable result is that the modularity has had

a more signiﬁcant inﬂuence on the overall perceived

quality of the Mobiles metamodels in our experiment

(p = 8.25 ·10

−5

). Conciseness, understandability and

complexity also showed signiﬁcant inﬂuences at the

An Empirical Study on the Perception of Metamodel Quality

147

Table 1: Correlations of Quality Attributes, strong correlations (|ρ| > 0.5) in bold.

Complexity

Understandability

Conciseness

Modularity

Consistency

Completeness

Correctness

Changability

Instance Creation

Transformations

Complexity (1.00) 0.39 0.55 -0.09 0.14 -0.14 -0.17 0.25 0.57 0.29

Understandability 0.39 (1.00) 0.56 0.34 0.24 0.13 0.19 0.19 0.45 0.10

Conciseness 0.55 0.56 (1.00) 0.15 0.24 0.14 0.20 0.24 0.36 0.25

Modularity -0.09 0.34 0.15 (1.00) 0.32 0.29 0.30 0.21 0.07 0.08

Consistency 0.14 0.24 0.24 0.32 (1.00) 0.46 0.37 0.19 0.23 0.15

Completeness -0.14 0.13 0.14 0.29 0.46 (1.00) 0.73 0.08 0.11 0.16

Correctness -0.17 0.19 0.20 0.30 0.37 0.73 (1.00) 0.10 0.07 0.08

Changability 0.25 0.19 0.24 0.21 0.19 0.08 0.10 (1.00) 0.28 0.34

Instance Creation 0.57 0.45 0.36 0.07 0.23 0.11 0.07 0.28 (1.00) 0.55

Transformations 0.29 0.10 0.25 0.08 0.15 0.16 0.08 0.34 0.55 (1.00)

5%-level (p = 0.02, 0.04, 0.04) but these results do

not withstand a Holm correction for multiple tests.

We believe this is due to the fact that we had few valid

questionnaires after having to cancel roughly half of

them (22) because of missing values.

3.3 Important Quality Attributes in the

BPMN Scenario

Unlike the Mobiles scenario, in the BPMN scenario

the participants had to extend a metamodel for a given

feature request. This task apparently was very dif-

ﬁcult for many participants, as the correctness has

by far the strongest signiﬁcance (p = 0.012) of all

quality attributes, followed by modularity (p = 0.022)

and completeness (p = 0.298). None of these signif-

icances withstands a Holm-correction, again partially

due to the low number of responses.

Comparing the results with the Mobiles scenario,

we can see much less signiﬁcances and higher p-

values, indicating that the perception of the quality

attributes is less clear. This may be due to the com-

plexity of the original BPMN metamodel.

3.4 Important Quality Attributes in

both Scenarios Combined

Taking the questionnaires of both experiment scenar-

ios together, we can get results that are to some ex-

tend independent from the scenario. In total, we had

to omit 44 responses in the ANOVA due to missing

entries. The resulting ANOVA table is depicted in Ta-

ble 2. The table shows the F statistic and the p-value

for the test that the underlying linear model is not de-

graded when the quality attribute is omitted. As we

perform multiple tests, we apply a Holm correction on

the resulting p-values. We used the usual signiﬁcance

codes, so ∗ ∗ ∗ stands for a signiﬁcance p < 0.001,

∗∗ for 0.001 < p < 0.01, ∗ for 0.01 < p < 0.05 and

· for 0.05 < p < 0.10 but apply them to the already

corrected p-values.

We have taken into account the scenario as an ad-

ditional factor in order to analyze whether the results

can be generalized from the scenario. The most im-

portant result from this analysis is that the inﬂuence of

the scenario is insigniﬁcant (p = 0.70). This means,

although the scenario of both of the experiments were

different in both domain and type (metamodel from

the scratch or extension to an existing one), the inﬂu-

ence factors of the quality attributes are much stronger

for the perception of the overall quality than the sce-

nario. This indicates that we can generalize the ﬁnd-

ings from this analysis of variance in some degree to

metamodels of any domain.

According to these results, the most important

quality attributes of a metamodel are its completeness

and correctness. These attributes also have a strong

correlation (ρ = 0.73) indicating that complete meta-

models are often also correct and vice versa. How-

ever, this result is hardly surprising.

Despite it is the metamodels most common appli-

cation, the instance creation is not among the most

signiﬁcant quality attributes but does not appear as

signiﬁcant. We believe this is a consequence from

the fact that instance creation was not correlated to

completeness or correctness in our experiment. Thus,

the instance creation is inﬂated by the fact that it is

very easy to create an instance of an overly simplistic

metamodel.

An interesting result is the strong inﬂuence of

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

148

Table 2: Results of the ANOVA for both scenarios combined.

F-statistic p-value p-value corrected

Complexity 2.711 0.11 0.74

Understandability 8.21 0.0072 0.058 ·

Modularity 34.82 1.29 · 10

−6

1.29 · 10

−5

∗ ∗ ∗

Conciseness 1.040 0.32 1.00

Completeness 36.39 8.78 · 10

−7

9.66 · 10

−6

∗ ∗ ∗

Correctness 11.60 0.0018 0.016 ∗

Changability 1.77 0.19 1.00

Consistency 0.60 0.45 1.00

Instance Creation 0.09 0.77 1.00

Transformations 0.27 0.61 1.00

Scenario 0.15 0.70 1.00

modularity on a very high signiﬁcance level (p <

0.0001 after the HOLM correction). This is partic-

ularly interesting since many large metamodels like

the UML metamodel used by Eclipse (Version 2.1) or

many component models like Kevoree (Fouquet and

Daubert, 2012) or SOFA 2 (Bure

s et al., 2006) do

not employ any modularization, i.e. all metaclasses

are direct elements of a single root package. Here,

our results indicate that these metamodels could be

perceived as much better if they were introducing a

package structure.

4 THREATS TO VALIDITY

The threats to the validity of our experiment are di-

vided as usual into threats to internal and external va-

lidity. The internal validity refers to the systematic

bias we might have introduced in the experiment de-

sign and is discussed in Section 4.1. The external va-

lidity refers to the degree in which the ﬁndings from

our experiment can be generalized and are discussed

in Section 4.2.

4.1 Internal Validity

Our experiment only consisted of one appointment

in which the participants had to evaluate the meta-

models. Thus, we can exclude an inﬂuence of his-

tories, maturation or mortality. We have chosen the

groups creating metamodels for the Mobiles case and

the BPMN case randomly so that we can exclude an

inﬂuence of selection. The evaluations of the meta-

models were made by the participants so that we can

exclude a subject effect from ourselves.

Not all metamodels have, however, been evaluated

by all of the participants. Most metamodels have been

evaluated by three participants out of the 24 partici-

pants of our experiment. Having the participants eval-

uate more metamodels would have borne the risk of

getting less participants and of suffering from a strong

sequencing effect. We have chosen the metamodels to

be evaluated by the participants by random in order to

minimize this effect.

Even so, we may have faced an instrumenta-

tion or sequencing effect as the participants evalu-

ated the multiple metamodels of the same domain

where subsequent evaluations may be biased depend-

ing on the ﬁrst metamodel which they had to evalu-

ate. To minimize this, participants were not allowed

to change their opinion on previous metamodel eval-

uations. However, we assume that this effect is very

small since the order was chosen by random and sta-

tistically, most metamodels were rated by some par-

ticipants ﬁrst and rated last by others. Furthermore,

the participants only evaluated at maximum two meta-

models per scenario.

4.2 External Validity

The mobile metamodels and the BPMN metamodel

extensions were relatively small whereas in practice,

much larger metamodels are used. Therefore, we can-

not exclude the possibility that the correlations that

we observed are not present in larger metamodels.

Furthermore, the participants of our experiment

were academic professionals and students but we did

not have participants from industry. Therefore, we

cannot exclude the risk that the observed correlations

would not be observed outside an academic setting.

When we asked the participants to assess the qual-

ity of the metamodels, we did not provide a spe-

ciﬁc purpose or usage scenario for the metamodels.

Rather, we asked to assess the quality in a broader

perspective. The participants evaluated the metamod-

els directly after they created some metamodels them-

selves. This sequence of tasks may have introduced

an implicit tendency to assess the quality from the per-

spective of metamodel design and not, for example,

from the perspective of transformation engineering.

An Empirical Study on the Perception of Metamodel Quality

149

5 FUTURE WORK

In the future, we want to use the results from the em-

pirical study to evaluate the goodness of ﬁt of metrics

to quantitatively measure metamodel quality. Such a

set of metrics would allow developers to detect possi-

ble shortcomings of their metamodels in a very early

stage of the development. Here, the results of this pa-

per guide us in the selection of metrics to evaluate.

In particular, the results imply the necessity of met-

rics to measure the modularity of metamodels as well

as their completeness and correctness. Unfortunately,

the latter two quality attributes are very hard to mea-

sure. After all, a metamodel is a formalization of the

domain and to avoid duplicate concepts, it is often the

only one. This makes it difﬁcult to choose artifacts

that can be used to validate the completeness or cor-

rectness. Further, metamodels should abstract from

the real world so that completeness is always relative

to the application scenario of the models conforming

to a metamodel.

This situation is different for modularity. Ap-

proaches already exist to improve the modularity of

object-oriented design. We look forward to validate

metrics to measure the modularity of metamodels in

order to automatically improve their quality. Because

of the high inﬂuence of modularity to the overall qual-

ity, the experiment metamodels of the Mobiles sce-

nario are suitable to validate modularization metrics.

The combination of metamodels and a percep-

tion of their quality also yields other possibilities to

sharpen the understanding of quality in an MDE con-

text. In a ﬁrst step, we want to validate the usage of

metrics to measure metamodel quality. In a second

step, we want to analyze how the design of different

metamodels of the same domain affect subsequent ar-

tifacts such as model transformations and analyses.

With such artifacts, the metamodel quality can be val-

idated in terms of quality attributes of depending arti-

facts. Finally, the results can be combined to validate

whether the perception of metamodel quality is actu-

ally correct in the sense that the expected positive ef-

fects of e.g. modularity persist in artifacts like model

transformations and analyses.

Summing up, empirical experiments such as we

have performed for this paper yield a large amount of

valuable data that can be used for a series of hopefully

meaningful results.

6 RELATED WORK

Related work in the context of metamodel quality

mostly exists for the quantitative measurement of

metamodel quality in metrics by adoption of metrics

for UML class diagrams and more generally object-

oriented design. However, to the best of our knowl-

edge, the characterization of metamodel quality has

not yet been approached through the perception of

modeling experts.

Bertoa et al. (Bertoa and Vallecillo, 2010) deﬁne

a rich framework of quality attributes for metamod-

els. However, the quality attributes are not validated

in terms of how the quality attributes are perceived

and no analysis has been done on the correlations be-

tween the quality attributes.

opez et al. propose a tool and language to check

for properties of metamodels (L

opez-Fern

andez et al.,

2014). In their paper, they also provide a catalog of

negative properties, which they categorize in: design

ﬂaws, best practices, naming conventions and metrics.

They check for breaches of ﬁxed thresholds for the

following metrics: number of attributes per class, de-

gree of fan-in and -out, DIT and the number of direct

subclasses. However, their catalog stems from con-

ventions and experience and is not empirically evalu-

ated. Further, the negative properties are not related

to quality attributes.

epa et al. present a repository for metamodels,

models, and transformations (V

epa et al., 2006). The

authors apply metrics that were originally designed

for class diagrams onto metamodels from the reposi-

tory. The applied metrics are: several size metrics (as

a basis for other metrics), DIT, several number of fea-

tures per class metrics, number of inherited attributes

and attribute inheritance factor. For some of the met-

rics, V

epa et al. provide a rationale how they relate to

metamodel quality but no validation is given.

Williams et al. applied a variety of size metrics

onto a big collection of metamodels (Williams et al.,

2013). However, they did not draw any conclusions

with regards to quality.

Di Rocco et al. also applied metrics onto a large

set of metamodels (Di Rocco et al., 2014). Besides

the usual size metrics, they also feature the number

of isolated metaclasses and the number of concrete

immediately featureless metaclasses. Further, they

searched for correlations of the metrics among each

other. E.g., they found that the number of metaclasses

with super class is positively correlated with the num-

ber of metaclasses without features. Based on the

characteristics they draw conclusions about general

characteristics of metamodels. Their long-term goal

is to draw conclusions from metamodel characteris-

tics with regards to the impact onto tools and transfor-

mations which are based on the metamodel. However,

in this work, they did not correlate the metric results

to any quality attributes.

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

150

Gomez et al. propose an approach which aims

at evaluating the correctness and expressiveness of a

metamodel (G

omez et al., 2012). A metamodel is

considered correct, if it only allows valid instances.

Expressiveness is the degree in which it is able to ex-

press the instances it is supposed to. Their approach

automatically generates a (preferably small) set of in-

stances to evaluate these two criteria.

Garcia et al. developed a set of domain spe-

ciﬁc metamodel quality metrics for multi-agent sys-

tems modelling languages (Garc

ıa-Magari

no et al.,

2009). They propose three metrics: availability,

speciﬁcity and expressiveness. These metrics take

domain knowledge into account, e.g., the “number

of necessary concepts” or the “number of model ele-

ments necessary for modelling the system of the prob-

lem domain”.

Leitner et al. propose complexity metrics for do-

main models of the software product line ﬁeld as well

as feature models (Leitner et al., 2012). A feature

model (Czarnecki and Eisenecker, 2000) is used to

express variability. In its simplest form it is a tree

with mandatory and optional nodes. More complex

constraints are also possible using excludes or feature

sets. A domain model is a DSL which also describes

variability. However, domain models are not as con-

strained by their metamodels as it is the case with fea-

ture models. The authors argue, that the complexity of

both, feature and domain models, inﬂuences the over-

all quality of the model, but especially usability and

maintainability. They show the applicability of their

metrics, but do not validate the inﬂuence between the

metrics and quality.

Vanderfeesten et al. published work on qual-

ity and quality metrics for business process models

(Vanderfeesten et al., 2007). They present a great

number of metrics in their work. Some of them

are so speciﬁc they can only be applied to business

quality models, others are quite general and can be

applied to metamodels or even graphs in general.

They assess the relation metric results and error oc-

currences (Mendling and Neumann, 2007; Mendling

et al., 2007a; Mendling et al., 2007b), between met-

ric results and manual quality assessments (S

anchez-

Gonz

alez et al., 2010) or to both (Vanderfeesten et al.,

2008). However, transferring the relation between

metrics and quality attributes to metamodels is sim-

ilarly problematic as it is with metrics for object-

oriented design. Business process models are used

for very speciﬁc purposes. They describe business

processes in the real world. They are used for docu-

mentation, communication, can be analyzed and sim-

ulated. The usage of metamodels is primarily instan-

tiation into models. Thus, if some of the metrics for

business process models can also be applied to meta-

models, it cannot be assumed that their correlations to

quality attributes still hold.

7 CONCLUSION

In this paper, we have described an empirical study

to enhance the understanding of metamodel quality

perception. We had a total of 24 participants, both

students and professionals. The results from analyz-

ing 89 questionnaires evaluating 23 metamodels of

two domains shows that the perception of metamodel

quality was mainly depending on completeness, cor-

rectness and modularity where other quality attributes

like the consistency of the metamodel did not show

a signiﬁcant inﬂuence. The chosen quality attributes

have shown only few correlations and are therefore

a good starting point for the design of future experi-

ments. As the inﬂuence of the domain was not signif-

icant for the perception of metamodel quality, we ar-

gue that our results are independent from the domains

modeled in the scope of our experiment and thus can

be generalized to other domains as well.

The signiﬁcance of modularity for the quality per-

ception of a metamodel is a signal to many metamod-

els used today in industry and academia that often ig-

nore this quality attribute. Furthermore, we want to

use the results to push the development and evalua-

tion of metrics to measure the metamodel quality au-

tomatically.

ACKNOWLEDGEMENTS

This research has received funding from the European

Union Seventh Framework Programme (FP7/2007-

2013) under grant agreement no. 604102 (Human

Brain Project) and the Helmholtz Association of Ger-

man Research Centers.

REFERENCES

Bertoa, M. F. and Vallecillo, A. (2010). Quality attributes

for software metamodels. In Proceedings of the

13th TOOLS Workshop on Quantitative Approaches

in Object-Oriented Software Engineering (QAOOSE

2010).

Bure

s, T., Hnetynka, P., and Pl

sil, F. (2006). Sofa 2.0:

Balancing advanced features in a hierarchical compo-

nent model. In Proceedings of the fourth International

Conference on Software Engineering Research, Man-

agement and Applications, pages 40–48. IEEE.

An Empirical Study on the Perception of Metamodel Quality

151

Czarnecki, K. and Eisenecker, U. W. (2000). Generative

Programming. Addison-Wesley, Reading, MA, USA.

Di Rocco, J., Di Ruscio, D., Iovino, L., and Pierantonio,

A. (2014). Mining metrics for understanding meta-

model characteristics. In Proceedings of the 6th In-

ternational Workshop on Modeling in Software Engi-

neering, MiSE 2014, pages 55–60, New York, NY,

USA. ACM.

Fouquet, F. and Daubert, E. (2012). Kevoree project.

http://www.kevoree.org/. [Online; accessed 10-

October-2013].

Garc

ıa-Magari

no, I., G

omez-Sanz, J., and Fuentes-

Fern

andez, R. (2009). An evaluation framework for

mas modeling languages based on metamodel metrics.

Agent-Oriented Software Engineering IX, pages 101–

115.

omez, J. J. C., Baudry, B., and Sahraoui, H. (2012).

Searching the boundaries of a modeling space to test

metamodels. Software Testing, Veriﬁcation, and Vali-

dation, 2008 International Conference on, 0:131–140.

Hinkel, G., Groenda, H., Vannucci, L., Denninger, O.,

Cauli, N., and Ulbrich, S. (2015). A Domain-Speciﬁc

Language (DSL) for Integrating Neuronal Networks

in Robot Control. In 2015 Joint MORSE/VAO Work-

shop on Model-Driven Robot Software Engineering

and View-based Software-Engineering.

Lehman, M., Ramil, J., Wernick, P., Perry, D., and Turski,

W. (1997). Metrics and laws of software evolution-the

nineties view. In Software Metrics Symposium, 1997.

Proceedings., Fourth International, pages 20–32.

Lehman, M. M. (1974). Programs, cities, students: Limits

to growth? (Inaugural lecture - Imperial College of

Science and Technology ; 1974). Imperial College of

Science and Technology, University of London.

Leitner, A., Weiß, R., and Kreiner, C. (2012). Analyzing

the complexity of domain model representations. In

Proceedings of the 19th International Conference and

Workshops on Engineering of Computer Based Sys-

tems (ECBS), pages 242–248.

opez-Fern

andez, J. J., Guerra, E., and de Lara, J. (2014).

Assessing the quality of meta-models. In Proceedings

of the 11th Workshop on Model Driven Engineering,

Veriﬁcation and Validation (MoDeVVa), page 3.

Mendling, J. and Neumann, G. (2007). Error metrics for

business process models. In Proceedings of the 19th

International Conference on Advanced Information

Systems Engineering, pages 53–56.

Mendling, J., Neumann, G., and van der Aalst, W. (2007a).

On the correlation between process model metrics

and errors. In Tutorials, posters, panels and indus-

trial contributions at the 26th international confer-

ence on Conceptual modeling-Volume 83, pages 173–

178. Australian Computer Society, Inc.

Mendling, J., Neumann, G., and Van Der Aalst, W. (2007b).

Understanding the occurrence of errors in process

models based on metrics. In On the Move to Meaning-

ful Internet Systems 2007: CoopIS, DOA, ODBASE,

GADA, and IS, pages 113–130. Springer.

anchez-Gonz

alez, L., Garc

ıa, F., Mendling, J., Ruiz, F.,

and Piattini, M. (2010). Prediction of business process

model quality based on structural metrics. In Concep-

tual Modeling–ER 2010, pages 458–463. Springer.

The Object Management Group (2011). Business process

model and notation 2.0. http://www.bpmn.org/.

Vanderfeesten, I., Cardoso, J., Mendling, J., Reijers, H. A.,

and van der Aalst, W. (2007). Quality metrics for busi-

ness process models. BPM and Workﬂow handbook,

144.

Vanderfeesten, I., Reijers, H. A., Mendling, J., van der

Aalst, W. M., and Cardoso, J. (2008). On a quest for

good process models: the cross-connectivity metric.

In Advanced Information Systems Engineering, pages

480–494. Springer.

epa, E., B

ezivin, J., Bruneli

ere, H., and Jouault, F. (2006).

Measuring model repositories. In Proceedings of the

1st Workshop on Model Size Metrics.

Williams, J. R., Zolotas, A., Matragkas, N. D., Rose, L. M.,

Kolovos, D. S., Paige, R. F., and Polack, F. A. (2013).

What do metamodels really look like? In Proceedings

of the ﬁrst international Workshop on Experiences and

Empirical Studies in Software Modelling (EESSMod),

pages 55–60.

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

152
