Are Large Scale Training Images or Discriminative Features Important

for Codebook Construction?

Veerapathirapillai Vinoharan

and Amirthalingam Ramanan

Computer Centre, University of Jaffna, Jaffna, Sri Lanka

Department of Computer Science, Faculty of Science, University of Jaffna, Jaffna, Sri Lanka

Keywords:

Bag-of-Features, Object Recognition, Incremental Learning, Discriminative Features, Visual Codebook.

Abstract:

Advances in machine learning and image feature representations have led to great progress in pattern recog-

nition approaches in recognising up to 1000 visual object categories. However, the human brain solves this

problem effortlessly as it can recognise about 10000 to 100000 objects with a small number of examples. In

recent years bag-of-features approach has proved to yield state-of-the-art performance in large scale evalua-

tions. In such systems a visual codebook plays a crucial role. For constructing a codebook researchers cover

a large-scale of training image set. But this brings up the issue of scalability. A large volume of training data

becomes difﬁcult to process whereas the high dimensional image representation could make many machine

learning algorithms become inefﬁcient or even a breakdown. In this work we investigate whether the dominant

bag-of-features approach used in object recognition will continue signiﬁcantly to improve with large training

image set or not. We have validated a one-pass clustering algorithm to construct visual codebooks for object

classiﬁcation tasks on the PASCAL VOC Challenge image set. Our testing results show that adding more

training images do not contribute signiﬁcantly to increase the performance of classiﬁcation but it increases

the overall model complexity in terms of increased storage requirement and greater computational time. This

study further suggests an alternative view to the community working with the patch-based object recognition

to enforce retaining more discriminative descriptors rather than the reminiscent of the BIG data hypothesis.

1 INTRODUCTION

The bag-of-features approach (Csurka et al., 2004),

(Karmakar et al., 2015) is a popular technique for

representing image content. In such a system a vi-

sual codebook plays a crucial role. An important is-

sue with the visual codebook representation is its dis-

criminative power and dimensionality. Most of the

visual codebooks that are used in larger evaluations

consist of 10,000 codewords. This higher dimension-

ality curses the subsequent classiﬁer training proce-

dure. Thus, most of the object recognition systems ex-

pect the histogram representation of a bag-of-feature

approach to be more compact while maintaining the

discriminative power.

The long-term goal of computer vision in object

recognition is to achieve near human levels of recog-

nition. Changes in pose, lighting, occlusion, clutter,

intra-class differences, inner-class variances, defor-

mations, background that varies relative to the viewer,

large number of images and several object categories

make the problem of recognition highly challenging.

Humans develop the invariance of an object so as to

easily recognise different sized objects, orientation,

illumination, and perspective objects. Whenever an

object is seen, the human brain extracts the features

without considering the size, orientation, illumina-

tion, perspective, and the object is remembered by

its shape and inherent features (Kim, 2011). More-

over, an incremental learning method is adapted by

the human visual processing system. When a new in-

stance of an existing object category is seen the pre-

vious knowledge base is updated using new invari-

ants. It has been proposed by (Ullman et al., 2002),

the human visual system encoded features of inter-

mediate complexity that are class-speciﬁc is selected

for encoding images within a class of related images.

The popular approach in artiﬁcial visual object recog-

nition is to use local information extracted at sev-

eral points or patches in the image. In such a sys-

tem the construction of a visual codebook is often

performed from thousands of images and each im-

age averagely contains hundreds or even one thousand

patch-based interest points described in a higher di-

mensional space of at least one thousand codewords,

in order to capture sufﬁcient information for efﬁcient

Vinoharan, V. and Ramanan, A.

Are Large Scale Training Images or Discriminative Features Important for Codebook Construction?.

DOI: 10.5220/0005676201930198

In Proceedings of the 5th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2016), pages 193-198

ISBN: 978-989-758-173-1

193

classiﬁcation. A major bottleneck lies in handling

such massive scale of datasets.

The PASCAL VOC challenge imageset (Evering-

ham et al., 2010) has become a benchmark dataset in

many computer vision tasks. In such challenges, par-

ticipants normally request to increase the number of

training images to train their model in a better way

in order to achieve higher recognition rate. It can be

observed that there is a steady increase in the train-

ing set of this image set over the years 2007 to 2012

consisting nearly 2000 to 6000 images amidst the fact

that the number of object categories remains the same

as 20. This is an important issue that we are focusing

on this paper whether such object recognition system

will continue to improve with increasing large num-

ber of training images for achieving slightly increased

classiﬁcation rate or is it worth to focus on the selec-

tion of discriminative features and the development of

better object models.

We optimise the process of constructing code-

books with less memory requirement and speeding

up the approach while maintaining compactness and

discriminative power in recognition. Our technique

constructs a codebook by acquiring information about

objects in a sequential way. The strategy that we use

to design discriminant codebook is by updating an ini-

tially constructed codebook over sequentially arriving

training images, and the output classiﬁer accounts for

the class-speciﬁc discriminant features. At the arrival

of each of the training images belonging to an interest

or non-interest object category, only the novel infor-

mation in the codebook will be absorbed as additional

entries. The construction of a codebook in this con-

text is achieved by extending the resource allocating

codebook (RAC) technique proposed by (Ramanan

and Niranjan, 2010). The proposed approach in this

paper constructs a codebook for a large-scale object

recognition task without the favour of machines that

have become fast enough in constructing a codebook

on relatively large-scale descriptors.

The rest of this paper is structured as follows.

Section 2 brieﬂy describes the background needed

for our work. Section 3 brieﬂy describes the objec-

tives of our research. Section 4 summarises differ-

ent methods used to construct a codebook with com-

pactness and discriminative power that have been car-

ried out in recent years. Section 5 explains the pro-

posed methodology in achieving incremental learning

method and constructing codebook with compactness

and discriminative power. Section 6 describes the ex-

perimental setup and testing results which support our

claim. Finally, section 7 concludes this paper.

2 BACKGROUND

2.1 Bag-of-Feature Approach

The bag-of-features (BoF) approach is widely used

in image scene classiﬁcation and object recognition

tasks in computer vision (Ramanan and Niranjan,

2011). The pseudocode of bag-of-features approach

is given in Algorithm 1

Algorithm 1: BoF representation for images.

for all image do

interestPts ← detectPts(image)

descriptors ← describePts(interestPts)

end for

codebook ← quantizePts(descriptors(trainingImages))

for all image do

BOF ← computeHist(codebook, descriptors(image))

end for

In such approach, visual codebooks are created

as follows. After extracting a large number of lo-

cal patch descriptors (e.g., SIFT descriptors (Lowe,

2004) from a set of training images, a clustering

method (e.g., K-means) is often used to group these

descriptors into K clusters, where K is a predeﬁned

parameter. The center of each cluster is called the

“visual word” or “codeword”, and a set of codewords

forms a codebook. Each image descriptor is then la-

beled with the most similar codeword according to the

Euclidean distance, and the image is characterised by

a K-dimensional histogram of the number of occur-

rences of each codeword. In fact, the size and ef-

fectiveness of the codebook has a critical impact on

recognition performance.

2.2 Resource-Allocating Codebook

The Resource-Allocating Codebook (RAC) (Ra-

manan and Niranjan, 2010) is a simple and ex-

tremely fast way to construct a codebook by using a

one-pass process, which simultaneously achieves in-

creased discrimination and a drastic reduction in the

computational needs.

RAC starts by arbitrarily assigning the ﬁrst data

item as an entry in the codebook. When a subse-

quent data item is processed, its minimum distance

to all entries in the current codebook is computed us-

ing an appropriate distance metric. If this distance

is smaller than the predeﬁned threshold r (radius of

the hypersphere), the current codebook is retained and

no action is taken with respect to the processed data

item. If the smallest distance to codewords exceeds

the threshold, including the current data item as the

ICPRAM 2016 - International Conference on Pattern Recognition Applications and Methods

194

additional entry, creates a new entry in the codebook.

This process is continued until all data items are seen

only once.

2.3 Support Vector Machine (SVM)

SVM is a well-known statistical learning method

(Cortes and Vapnik, 1995). In particular, it is effective

when the training data consists of a small number of

samples in high-dimensional spaces. The objective of

SVM learning is to ﬁnd a hyperplane that maximises

the inter-class margin of the training samples. Feature

vectors are projected into a high-dimensional space

by the kernel function.

3 OBJECTIVES

Discriminative power and compactness of a codebook

are important to control the model complexity. In this

regard we formulate the following:

• Not all training images contribute to the discrimi-

native power of a codebook. That is, a unique or

different image of the same class will contribute

to the construction of a codebook.

• The incremental construction of a codebook using

the training images is more appropriate to retain

discriminative features similar to the human visual

perceptual system than processing all the required

images.

4 RELATED WORK

There is an extensive body of literature in the area of

visual object recognition systems. (Zhu et al., 2012)

have investigated the question of whether existing fea-

ture detectors will continue to improve as data grows

or the development of better object detection models

is needed. The authors have found that additional data

does help, but only with correct regularisations and

treatment of noisy examples in the training data and

compositional mixtures (implemented via composed

part) that give a much better performance in recog-

nition. However, a straightforward but effective ap-

proach lies in the use of a codebook model. A com-

pact codebook can also be achieved by carefully se-

lecting the codewords from an initially constructed

large codebook (Kirishanthy and Ramanan, 2015).

(Yang et al., 2008) have proposed a uniﬁed code-

book generation that is integrated with classiﬁer train-

ing. Unlike clustering approaches that associate each

image feature with a single codeword in their ap-

proach, images are represented by means of visual

bits associated with different categories, i.e., an im-

age which can contain objects from multiple cate-

gories is represented using aggregates of visual bits

for each category that constitutes the semantic vo-

cabulary. These visual bits are augmented iteratively

to reﬁne visual words based on the learning perfor-

mance of the classiﬁer. The iterative process is carried

out until a desired performance is achieved. Harris

Laplace corner detectors are used in detecting inter-

est points and are described by SIFT descriptors. The

proposed framework is mainly evaluated on the PAS-

CAL VOC Challenge 2006 dataset which contains 10

visual challenges. Their training set consists of 100

randomly-selected images. Their framework outper-

forms the baseline K-means and SVM on every cate-

gory and demonstrates signiﬁcant improvements over

extremely-random classiﬁcation forest algorithm on 8

out of 10 classes.

(Li et al., 2008) have proposed an approach for

learning optimal compact codebook by selecting a

subset of discriminative codeword from a large code-

book. An initial codebook was constructed using K-

means clustering algorithm. Each codeword in this

codebook is then modeled by a spherical Gaussian

function through which an intermediate representa-

tion for each training image is obtained. A Gaussian

model for every object category is learned based on

this intermediate representation. Following this step,

an optimal codebook is constructed by selecting dis-

criminant codewords according to the learned Gaus-

sian model. The discriminative capability is mea-

sured either by likelihood ratio or by Fisher score.

Interest points in their experiments were detected by

the DoG detector and are described by SIFT descrip-

tors. Classiﬁcation is performed using SVM classi-

ﬁers with RBF kernel. The proposed framework is

mainly evaluated on the Caltech-4 dataset consisting

four object categories. In their experiment 100 images

were randomly choosen for training and the rest was

used for testing. They report superior performance

of object categorisation compared with traditional K-

means method with same size of codebooks.

(Winn et al., 2005) have proposed to optimise

codebooks by hierarchically merging visual words in

a pair-wise manner using the information bottleneck

principle from an initially constructed large code-

book. The ﬁnal visual words were represented by the

Gaussian Mixture Models of pixel appearance. Train-

ing images are convolved with different ﬁlter-banks

made of Gaussians and Gabor kernels to generate a set

of ﬁlter responses. The resulting ﬁlter responses are

clustered by K-means method with a large value of

Are Large Scale Training Images or Discriminative Features Important for Codebook Construction?

195

Figure 1: The overall framework of the proposed technique to sequentially constructing visual codebook for an object-speciﬁc

category (e.g. horse).

K in the order of thousands. The learned cluster cen-

tre and their associated covariance deﬁne a universal

visual codebook. Following the construction of this

large codebook, a histogram is constructed over the

initial codebook which is processed by each region of

training images. A mapping between corresponding

histogram and pair-wise merging operation is used to

produce a much more compact visual codebook. The

proposed framework is mainly evaluated on the in-

house database with faces from Caltech dataset. Class

models are learned from a set of 240 manually seg-

mented and annotated images belonging to the nine

object categories. In order to measure the classiﬁca-

tion accuracy the image set is split into 50% training

and 50% test sets. Their framework yields an accu-

racy of 93%.

5 METHODOLOGY

The proposed sequential learning method to con-

structing codebook is extremely fast and efﬁcient

when compared to the approaches. The proposed

technique shows a better way to construct a compact

codebook while maintaining its discriminative power.

The following steps describe the process of sequen-

tially constructing a codebook:

Step 1: A randomly chosen image from a training

set is processed to extract the features and then

cluster those features using RAC technique

in a one-pass manner to construct an initial

codebook. Based on this codebook, images

are then represented as histograms for all

training and testing image sets. Thereafter, the

classiﬁcation rate is computed using a standard

classiﬁer.

Step 2: The subsequent image in the training set is

processed to extract features. If the smallest

distance to a codeword in the codebook ob-

tained in step 1 exceeds the radius of RAC,

the current feature is recorded as an additional

informative codeword that creates a new entry

in the codebook by updating the obtained

codebook in the step 1; otherwise no action

is taken with respect to the processed feature.

Based on the updated codebook images of

training and testing sets are represented as

histograms. The classiﬁcation rate is computed

using the same standard classiﬁer. This process

will be continued until all images have been

considered.

Figure 1 shows the overall framework of the

proposed technique to sequentially construct a vi-

sual codebook for an object-speciﬁc category and the

pseudocode of this approach is given in Algorithm 2.

The stopping criteria for Algorithm 2 can be imple-

mented either by processing sequentially all the im-

ages in the training set or when achieving a desired

classiﬁcation rate.

ICPRAM 2016 - International Conference on Pattern Recognition Applications and Methods

196

Algorithm 2: Sequentially constructing codebook.

Input: Training images (trImgs), Testing images

(teImgs)

Output: Visual codebook (CB), Classiﬁcation accu-

racy (rate)

for all img

∈ {trImgs, teImgs} do

interestPts ← detectPts(img

)

descrips ← describePts(interestPts)

end for

r ← predeﬁned value

// Initialise the codebook CB

D ← descrips(img

) //where img

∈ trImgs

CB ← D

i ← 1

for all img

∈ trImgs do

D ← descrips(img

)

j ← 1

while (j ≤ size(D)) do

if mink D

−CB k

> r

then

Create a new hypersphere of r such that,

CB ← {CB ∪ D

}

end if

j ← j + 1

end while

trainHist ←computeHist(CB, descrips(trImgs))

testHist ←computeHist(CB, descrips(teImgs))

rate

← classify(trainHist, testHist)

i ← i + 1

end for

6 TESTING RESULTS

We test our approach on PASCAL VOC 2007 Chal-

lenge dataset. It consists of 9963 images from 20

categories. For constructing visual codebooks, SIFT

features were clustered independently using K-means

with K = 250 (2K = 500) and RAC with r = 0.89. Ex-

periments in this work were mainly carried out to val-

idate our objectives. Table 1 shows the performance

comparison of BoF approach with K-means and RAC

whereas Table 2 details the classiﬁcation rate of RAC

with the proposed sequential learning technique.

Based on the statistical t-tests performed on the

results of Table 1 and 2, we conclude that RAC and

K-means are of near performance, whereas the pro-

posed sequential learning technique outperforms the

RAC method, at the level of signiﬁcance 0.05. More-

over, on average about 13-22% of the training images

provided in PASCAL VOC 2007 is only needed to

construct a discriminative codebook for each binary

classiﬁcation tasks listed in Table 2. This proves that

not all images are required for constructing a discrim-

inative codebook in a similar way as the human visual

Table 1: Comparison of two codebook generation meth-

ods tested on a selected binary classiﬁcation tasks from the

PASCAL VOC 2007 dataset. K-means (KM) with K = 250

(2K = 500) and RAC codebook sizes nearly equal to 500.

The r of RAC was 0.89.

Object KM+SVM RAC+SVM

Aeroplane vs Bird 0.84 0.83

Aeroplane vs Boat 0.77 0.80

Aeroplane vs Horse 0.88 0.87

Aeroplane vs Sofa 0.88 0.87

Bicycle vs Motorbike 0.69 0.67

Bird vs Cat 0.77 0.73

Boat vs Bus 0.86 0.82

Boat vs TVmonitor 0.91 0.88

Bottle vs Pottedplant 0.68 0.64

Bus vs Train 0.71 0.70

Cat vs Dog 0.64 0.65

Chair vs Dog 0.83 0.81

Cow vs Sheep 0.66 0.63

Diningtable vs Pottedplant 0.58 0.61

Pottedplant vs TVmonitor 0.68 0.68

Train vs TVmonitor 0.89 0.85

Table 2: Classiﬁcation rate with codebook (CB) size and

number of training images for the proposed sequential

learning method with r = 0.89.

Object

#imgs #imgs CB

Ours

avail used size

Aeroplane vs Bird 568 34 279 0.87

Aeroplane vs Boat 419 22 236 0.80

Aeroplane vs Horse 525 58 341 0.90

Aeroplane vs Sofa 467 90 356 0.88

Bicycle vs Motorbike 488 22 274 0.68

Bird vs Cat 667 72 315 0.75

Boat vs Bus 367 46 303 0.84

Boat vs TVmonitor 437 14 165 0.89

Bottle vs Pottedplant 489 110 348 0.65

Bus vs Train 447 86 392 0.71

Cat vs Dog 758 30 247 0.65

Chair vs Dog 866 32 255 0.81

Cow vs Sheep 237 42 233 0.65

Diningtable vs Pottedplant 445 34 263 0.64

Pottedplant vs TVmonitor 501 132 373 0.70

Train vs TVmonitor 517 46 293 0.86

processing system. Furthermore, the proposed tech-

nique constructs a compact codebook which is around

60% size of the codebooks constructed either by K-

means or RAC method.

Limited experimentation with reordering of the

images was carried out to check the evolution of code-

book size and the classiﬁcation rates during the exe-

Are Large Scale Training Images or Discriminative Features Important for Codebook Construction?

197

cution. We report the mean classiﬁcation rates of ten

independent runs where each run is carried out by ﬁx-

ing the same total number of images considered in

Table 2 and by randomly shufﬂing the order of pres-

ence of the images in the process of constructing a

codebook. In the Aeroplane vs Horse example the

average size of codebook was 338±17 with a classiﬁ-

cation rate of 0.88±0.01, whereas for the Diningtable

vs Pottedplant example the size of the codebook and

classiﬁcation rate were 259±25 and 0.61±0.02, re-

spectively. While we have included the standard de-

viation for completeness, we noted that these are the

estimates of uncertainty for a very few trials. The

construction of a codebook using K-means algorithm

was performed in an average time of 16536 seconds,

while the proposed method required an average time

of 42 seconds only on a desktop computer with an In-

tel Core i5 running at 3.2GHz and 8GB of RAM.

7 DISCUSSION AND

CONCLUSION

This paper addresses the problem of object classiﬁ-

cation of images together with a sequential learning

technique. Our system starts to progress in extracting

features from the training images using SIFT algo-

rithm. These features are converted into a codebook

using an extended RAC method. The codewords then

serve to construct a histogram for representing an im-

age. These histograms are then fed into a binary SVM

classiﬁer to classify the objects. We construct the

codebook by sequentially processing images to retain

only the discriminative or rare features by allocating

new codewords using the extended RAC technique.

Our test results show that it is worth to select discrim-

inative features, instead of increasing the number of

training images, to yield better classiﬁcation rate by

means of a compact codebook.

In the literature of BoF approach, the codeword

size is manually selected by the user and is com-

monly deﬁned up to tens of thousands for ensuring

enough information encoding. However, such a huge

size of codewords causes an enormous computational

cost. To create a discriminative BoF representation,

we present a technique that well approximates the dis-

tribution of visual words in an image and the out-

put classiﬁer accounting for class-speciﬁc discrimi-

nant features. Thus, this paper suggests an alterna-

tive view to the research community working with the

patch-based object recognition to emphasize the re-

taining of more discriminative descriptors rather than

the reminiscent of the BIG data hypothesis.

REFERENCES

Cortes, C. and Vapnik, V. (1995). Support-vector networks.

Machine learning, 20(3):273–297.

Csurka, G., Dance, C., Fan, L., Willamowski, J., and Bray,

C. (2004). Visual categorization with bags of key-

points. In Workshop on statistical learning in com-

puter vision, volume 1, pages 1–2.

Everingham, M., Eslami, S. M. A., Gool, L. V., Williams,

C. K. I., Winn, J., and Zisserman, A. (2010). The PAS-

CAL Visual Object Classes VOC Challenge. Interna-

tional Journal of Computer Vision (IJCV), 88(2):303–

338.

Karmakar, P., Teng, S. W., Lu, G., and Zhang, D. (2015).

Rotation invariant spatial pyramid matching for im-

age classiﬁcation. In Proceedings of the International

Conference on Digital Image Computing: Techniques

and Applications (DICTA), pages 653–660.

Kim, S. (2011). Robust object categorization and segmenta-

tion motivated by visual contexts in the human visual

system. EURASIP Journal on Advances in Signal Pro-

cessing.

Kirishanthy, T. and Ramanan, A. (2015). Creating compact

and discriminative visual vocabularies using visual

bits. In International Conference on Digital Image

Computing: Techniques and Applications (DICTA),

pages 258–263.

Li, T., Mei, T., and Kweon, I. S. (2008). Learning optimal

compact codebook for efﬁcient object categorization.

In IEEE Workshop on Applications of Computer Vi-

sion, pages 1–6.

Lowe, D. (2004). Distinctive image features from scale-

invariant keypoints. International journal of computer

vision, 60(2):91–110.

Ramanan, A. and Niranjan, M. (2010). A one-pass

resource-allocating codebook for patch-based visual

object recognition. In IEEE International Workshop

on Machine Learning for Signal Processing, pages

35–40.

Ramanan, A. and Niranjan, M. (2011). A review of code-

book models in patch-based visual object recogni-

tion. Journal of Signal Processing Systems, Springer,

68(3):333–352.

Ullman, S., Vidal-Naquet, M., and sali, E. (2002). Visual

features of intermediate complexity and their use in

classiﬁcation. Nature neuroscience, 5(7):682–687.

Winn, J., Criminisi, A., and Minka, T. (2005). Object cat-

egorization by learned universal visual dictionary. In

IEEE International Conference on Computer Vision,

volume 2, pages 1800–1807.

Yang, L., Jin, R., Sukthankar, H., and Jurie, F. (2008). Uni-

fying discriminative visual codebook generation with

classiﬁer training for object category recognition. In

proceeding of IEEE conference on Computer Vision

and Pattern Recognition (CVPR 2008), pages 1–8.

Zhu, X., Vondrick, C., Ramanan, D., and Fowlkes, C.

(2012). Do we need more training data or better mod-

els for object detection? In British Machine Vision

Conference (BMVC).

ICPRAM 2016 - International Conference on Pattern Recognition Applications and Methods

198
