Unsupervised Framework for Interactions Modeling between Multiple
Objects
Ali Al-Raziqi and Joachim Denzler
Computer Vision Group, Friedrich Schiller University of Jena, Jena, Germany
Keywords:
Interaction Detection, Multiple Object Tracking, Unsupervised Clustering, Hierarchical Dirichlet Processes.
Abstract:
Extracting compound interactions involving multiple objects is a challenging task in computer vision due to
different issues such as the mutual occlusions between objects, the varying group size and issues raised from
the tracker. Additionally, the single activities are uncommon compared with the activities that are performed
by two or more objects, e.g., gathering, fighting, running, etc. The purpose of this paper is to address the prob-
lem of interaction recognition among multiple objects based on dynamic features in an unsupervised manner.
Our main contribution is twofold. First, a combined framework using a tracking-by-detection framework for
trajectory extraction and HDPs for latent interaction extraction is introduced. Another important contribu-
tion is the introduction of a new dataset, the Cavy dataset. The Cavy dataset contains about six dominant
interactions performed several times by two or three cavies at different locations. The cavies are interacting
in complicated and unexpected ways, which leads to perform many interactions in a short time. This makes
working on this dataset more challenging. The experiments in this study are not only performed on the Cavy
dataset but we also use the benchmark dataset Behave. The experiments on these datasets demonstrate the
effectiveness of the proposed method. Although the our approach is completely unsupervised, we achieved
satisfactory results with a clustering accuracy of up to 68.84% on the Behave dataset and up to 45% on the
Cavy dataset.
1 INTRODUCTION
Activity recognition is a very important task in com-
puter vision and has many applications such as video
surveillance and animal monitoring systems. Com-
puter vision can help the biologists to understand and
recognize the behavior of animals in the videos. Ac-
tivity recognition can be roughly divided into three
categories. The first category is single activity, in
which the activity is performed by only a unique
object without interacting with any other objects
(Ohayon et al., 2013; Guha and Ward, 2012; De-
laitre et al., 2011). In many situations, single activ-
ities are uncommon compared with the activities per-
formed by several active objects e.g. gathering, chas-
ing, fighting, running, etc. The second category is
pair activity which includes the interaction between
two objects. Pair-activity methods can be classified
into two approaches. The first approach performs seg-
menting and tracking the body parts (heads, hands,
legs, etc.) of two objects to discover the interactions
between them e.g. high five, kiss, hand shake, etc
(Patron-Perez et al., 2010; Dong et al., 2011; Kong
and Jia, 2012; Li et al., 2011). This may be un-
feasible for low image resolution and occlusions in
surveillance videos. In the Cavy dataset which is in-
troduced for the first time in this study, it is difficult
to segment cavy parts to discover the interactions be-
tween the cavies. The second category is character-
ized by tracking the whole body of objects to extract
the interactions between objects, e.g. gathering, scat-
tering, leaving, etc (Zhou et al., 2011; Sato and Ag-
garwal, 2004; Blunsden et al., 2007). The third cate-
gory is group activity which refers to the interaction
among multiple objects (two or more objects) within
a specific distance. In group activity methods, the
scene has to be divided into subgroups, interaction in
each group are then analyzed and recognized, e.g. In-
Group, Approach, WalkTogether, Fight, etc, (Bluns-
den and Fisher, 2009; Cheng et al., 2014; Kim et al.,
2014; Ni et al., 2009; Lin et al., 2010; Yin et al., 2012;
M
¨
unch et al., 2012; Zhang et al., 2012). Generally,
activities involving multiple active objects are consid-
ered as a group activity. As an example, scattering
activity consists of multiple running individuals.
Figure 1 shows some scenarios where various ob-
jects in a scene are interacting with each other in Cavy
Al-Raziqi, A. and Denzler, J.
Unsupervised Framework for Interactions Modeling between Multiple Objects.
DOI: 10.5220/0005680705090516
In Proceedings of the 11th Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2016) - Volume 4: VISAPP, pages 509-516
ISBN: 978-989-758-175-5
Copyright
c
2016 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
509
(a) Approach (b) Fight (c) InGroup
(a) Approach (b) Fight (c) InGroup
Figure 1: Interactions between multiple persons on the
Cavy and the Behave datasets (Blunsden and Fisher, 2010).
For better visibility, refer to the web version.
Figure 2: A set of frames taken from different views and
different time with changing the illumination.
and Behave datasets (Blunsden and Fisher, 2010).
It can be observed that most of the previous meth-
ods share two common characteristics. First, at a
high level, most of them implement the same frame-
work according to which motion/appearance features
are extracted. Second, supervised machine learning
method are used to classify the interactions. In many
of the activity recognition categories, the number of
involved objects cannot be determined beforehand.
Furthermore, the exact number of activities is usu-
ally a prerequisite for classification, which is often
unavailable especially for new videos to be analyzed.
Hence, using an unsupervised method is a necessity
in such situations to extract the interactions.
Our proposed approach incorporates the capabil-
ities of the Hierarchical Dirichlet Processes (HDP)
with spatio-temporal dynamic features based on the
trajectories to tackle the problem of interactions be-
tween objects. The main contribution of this paper is
twofold:
1. A combined framework using a tracking-by-
detection method for trajectory extraction and
Table 1: The dominant interactions performed by two or
three cavies at different locations on the Cavy dataset.
Interaction Description
Approach
One object approaches to
another(s) object(s)
RunTogether Objects walking together
Split Object(s) split from one another
Ingroup
Several objects are close to each
other and with small moving
Fight Objects fighting each other
Follow Object(s) following other
HDPs for latent interaction extraction is intro-
duced.
2. The introduction of the Cavy dataset
1
, which con-
tains six dominant interactions performed several
times by two or three cavies at different locations
as shown in Figure 2 and table 1.
The Cavy dataset can be useful in many disciplines, in
addition to computer vision, since the dataset is taken
at various time, it may help the biologists to study and
monitor the cavies behavior in specific periods.
For unsupervised clustering tasks, HDP has been
widely used in many fields such as text analysis (Teh
et al., 2006), traffic scene analysis and action recogni-
tion (Kuettel et al., 2010; Krishna and Denzler, 2014;
Krishna et al., 2013) and yielded significant results.
In this paper, we apply for the first time HDP to the
group activity recognition problem.
The rest of this paper is organized as follows. In
Sect. 2 we provide a brief overview of the existing
literature on interaction recognition. Sect. 3 describes
the interaction modeling. Sect. 4 discusses the applied
HDP model, and the corresponding inference proce-
dure. The experiments conducted on the Cavy and the
Behave datasets are described in Sect. 5 along with re-
sults.
2 RELATED WORK
In this work, we focus on the interaction detection
between multiple objects. The related work can be
divided into two categories, supervised and unsuper-
vised learning methods.
Supervised Learning, In (Yang et al., 2013), the au-
thors used a graph framework to analyze the interac-
tion between parts of an object. The body parts and
objects are represented as nodes of graphs, the parts
are tracked to extract the temporal features and the
1
Available at http://www.inf-cv.uni-jena.de/Group/
Staff/M Sc ++Ali+M +Al Raziqi.html
VISAPP 2016 - International Conference on Computer Vision Theory and Applications
510
network analysis provide the spatial features. They
then use Support Vector Machine (SVM) and a Hid-
den Markov Model to classify the interactions of the
object’s parts. In (Zhou et al., 2011), the authors
analyzed the interaction between objects based on
Granger Causality Test. The GCT causality mea-
sures the effect of the objects on each other. In (Ni
et al., 2009), the authors divided the individuals into
subgroups and cluster them using k-means algorithm.
The causality is analyzed with respect to individual,
pair, and inter-group activity. Finally, classifiers such
as Nearest Neighbor (NN) and SVM are used for
group activity classification.
Another relevant approach is introduced in (Kim
et al., 2014), where the authors recognize group ac-
tivities by detecting meaningful groups. This is done
by defining Group Interaction Zone (GIZ). Group ac-
tivities in each GIZ can be illustrated by attraction and
repulsion properties which are represented by the rel-
ative distance during k frames. Furthermore, the study
in (Cheng et al., 2014) presented a new approach in
different semantic layers: individual, pair and group.
Motion and appearance features are extracted from
those layers. For the appearance features, Histograms
of Oriented Gradients (HoG) are extracted for each
object in the group and Delaunay triangulation is used
to extract the whole group features.
Unsupervised Learning, In the work presented
in (Al-Raziqi et al., 2014), the authors have devel-
oped an HDP-based interaction extraction approach
in which the optical flow is extracted in the whole
image without object localization or trajectories mo-
tion analysis. Another interesting method which tried
to tackle this problem is described in (Zhu et al.,
2011). The authors extracted features such as ap-
pearance, causality and feedback based on GCT and
leant an extended probabilistic Latent Semantic Anal-
ysis (pLSA). Then, pLSA used to categorize new se-
quences.
Unlike many of the approaches described above,
our approach integrates an unsupervised clustering
method, namely HDP, with optical flow based on mo-
tion trajectories to identify the interactions of multiple
objects without further knowledge.
3 INTERACTIONS MODELING
The interaction is an activity performed by several ob-
jects within a specific region. Figure 3 shows the main
steps of our approach. In order to perform object in-
teraction modeling, as a preliminary step, a reliable
and accurate tracker is required. Since the objects
in the Cavy dataset are not annotated by bounding
Sequence
Tracking
Flow Words
Extraction
Dictionary
(a) Representation
HDP
Model
Interactions
Bag-of-WordsClips
Flow Word
Count
.....
2540 3
24 12
28
.....
3568
Flow Word
Count
.....
8560 203
985 102
2
.....
15840
(b) Clustering
Figure 3: Our framework for interaction detection: (a) Ob-
jects tracking to extract the trajectories, low-level visual fea-
tures inside bounding boxes and build the dictionary with all
possible flow words. (b) Divided the video sequence into
short clips. Local flow motions are computed for each clip.
Each clip is represented by a Bag-of-Words. HDP is used
to extract the interactions between the objects.
boxes (BB), we cannot start with ground truth ob-
ject positions and trajectories, but have to compute
this information from the data itself. This makes the
Cavy data set a very challenging one since the con-
secutive interaction detection step must deal with er-
rors in the previous tracking step. The set of detec-
tions (BB) are generated by background subtraction
method using Gaussian Mixture Model (GMM) pre-
sented in (Zivkovic, 2004).
Due to this simple detection method, errors in the
detection cannot be avoided, such as missing, false,
merging or splitting objects. Examples are shown in
Figure 6. To mitigate the effect of wrong or missing
detections, we apply a two-stage graph method pre-
sented in (Jiang et al., 2012). The result of the track-
ing algorithm are trajectories of all objects, e.g. the
i th object trajectory is represented from time 1 to k
as: T
k
i
= [x
1
i
,x
2
i
,..., x
k
i
], where T
k
i
is a sub-trajectory of
the object i
0
s trajectory in k frames and x
i
is a center
of mass coordinate (x, y) of a particular object. The
average distance is computed using Euclidean dis-
tance between the sub-trajectories which consists of
the largest value k for which the length of the trajec-
tories of object i equals that of object j.
D
i, j
=
1
k
||T
k
i
T
k
j
|| (1)
Subsequently, optical flow inside the BBs regions
is computed using the TV-L
1
algorithm (Zach et al.,
2007), if the D
i, j
is below a user defined threshold
Unsupervised Framework for Interactions Modeling between Multiple Objects
511
. This threshold depends on the kind of interactions
to be identified by the system and is application de-
pended. The video sequence is then divided into short
and equally sized clips without overlap. In each clip,
optical flow is quantized into eight directions (flow
words). The optical flow features can be defined as
X=(x, y, u, v), where (x, y) is the location of a par-
ticular pixel in the image, and (u, v) are the flow val-
ues. Following the approaches are described in (Kuet-
tel et al., 2010; Krishna and Denzler, 2014), all clips
are represented by accumulated flow words over their
frames. Finally, a dictionary is built with all possible
flow words.
4 HIERARCHICAL DIRICHLET
PROCESSES
HDP was first presented for clustering words in doc-
uments based on words co-occurrence to infer the la-
tent topics (Teh et al., 2006). Specifying the number
of topics beforehand is impractical. So, in HDP the
number of clusters (topics) is extracted automatically
from the data and a set of hyper-parameters (α, γ and
η). Figure 4 shows the basic HDP model.
For text analysis, the corpus is divided into M sep-
arated documents where each document contains a
set of unordered words N
m
, denoted as x
m,n
, where
m [1, M] and n [1, N
m
]. Hence, each document is
represented by its words.
In our case, we follow (Krishna and Denzler,
2014; Al-Raziqi et al., 2014; Kuettel et al., 2010),
where the corpus, documents and words correspond
to the video sequence, short equal sized clips, and op-
tical flow respectively. Generally, for a given input
video, optical flow features are extracted from each
pair of successive frames. Then, the video sequence
is divided into short clips. Each clip is represented by
accumulated a Bag-of-Words (see Section 3).
The HDP in this work uses Dirichlet Process (DP)
to infer the interactions at two levels. The global list
of interactions G
0
is generated in the first DP level,
where G
0
is a prior distribution over the video. In the
second DP, specific interactions G
m
are drawn from
the global list G
0
for each clip. The interactions might
be shared among different G
m
. Formally, we write the
generative HDP formulation
G
0
| γ,H DP(γ,H)
G
m
| α,G
0
DP(α,G
0
) for m [1,M].
(2)
In Eq 2, the hyper-parameters α and γ are called
the concentration parameters and the parameter H is
called the base distribution. Therefore, the observed
words x
m,n
are seen as being sampled from the mix-
ture priors φ
m,n
, which can be interpreted as being
drawn from a DP G
0
. The values of mixture com-
ponents are drawn from θ
k
. Consequently, this model
can be written as
θ
k
P(η) for k [1, )
φ
m,n
| α,G
m
G
m
for m [i,M],n [1,N
m
]
x
m,n
| φ
m,n
,θ
k
F(θ
φ
m,n
)
(3)
where M is the number of clips in the video, N
m
is the
number of words in clip m, P(·) and F(·) are the prior
distribution over topics and words respectively.
Consequently, given the observed flow words,
HDP infers the latent topics (interactions) which is
called Bayesian inference. Following the formulation
of (Krishna et al., 2013), the conditional probability
of the topic-word association for each iteration step is
evaluated as
p(φ
m,n
= k, α,γ,η,θ, H)
(n
¬m,n
m,k
+ αθ
k
).
n
¬m,n
k,t
+ η
n
¬m,n
k
+V.η
(4)
where n
m,k
, n
k,t
, and n
k
represent statistics of the
word-topic, topic-document and the topic-wise word
counts, respectively. The current word x
m,n
must be
excluded from that topic. The size of the dictionary
is represented by V . The probability of assignment
of the current flow word x
m,n
to a particular topic is
relative to the number of words previously associated
with that topic as shown in the first term of equation
4. The second term shows the effects of the hyper-
parameters α,γ and η on determining the number of
extracted topics and the possibility of creating a new
topic. In this paper, interactions are interpreted as
flow words which co-occur in the same clip. The
idea is that optical flow measured within the area of
a tracked object represent fine-grained details of the
activity which in combination with the respective ac-
tivity of the other object identifies the interaction.
5 EXPERIMENTS AND RESULTS
For evaluating the performance of our proposed
framework, we performed several experiments on two
different datasets, the Cavy dataset and the bench-
mark dataset Behave (Blunsden and Fisher, 2010) to
illustrate the effectiveness and capability of the HDP
in interaction extraction. Both datasets provide var-
ious challenging interactions of multiple objects as
shown in Figure 1.
As the Cavy dataset does not contain ground truth
in terms of interactions among objects, we marked
VISAPP 2016 - International Conference on Computer Vision Theory and Applications
512
Global interactions
One Interaction
One word
Interactions in clip
Figure 4: HDP model. Dirichlet Processes are used to gen-
erate the global interactions G
0
and G
m
which are drawn
from the global G
0
.
the semantically meaningful interactions in the scene
(clip-wise annotations). Then, similar to the proce-
dure in (Kuettel et al., 2010; Krishna and Denzler,
2014; Al-Raziqi et al., 2014), the output of our system
is manually mapped to the ground truth labels and the
performance measures are calculated. For the perfor-
mance evaluation, we use the accuracy
Accuracy =
T P + T N
T P + T N + FP + FN
(5)
where TP, FP, FN, and TN are True Positives, False
Positives, False Negatives, and True Negatives re-
spectively.
5.1 Results on Cavy Dataset
The Cavy dataset is a new dataset introduced in this
work. The Cavy dataset contains a variety of con-
ditions that have been taken from a stationary cam-
era. As can be observed in Figure 2, sequences
are recorded from different views with changing il-
lumination and in different periods. It contains
16 sequences with 640 × 480 resolutions recorded
at 7.5 frames per second (fps) with approximately
31621506 frames in total (272 GB). The sequences
are recorded non-synchronously and stored in ppm
format. The Cavy dataset contains six dominant inter-
actions performed several times by two or three cavies
at different locations in the scene. Table 1 shows the
types of the interactions. Some interactions are easy
to distinguish, while others only differ a bit in exe-
cution period, velocity and the number of involved
cavies. In these experiments, we used eight sequences
with a total number of 159358 frames.
Results: As baseline experiments on the Cavy
Table 2: Confusion matrix representing the performance of
the HDP on the Cavy dataset.
A 0.5 0.03 0.05 0.00 0.00 0.00 0.41 61
S 0.01 0.28 0.03 0.00 0.01 0.00 0.67 75
I 0.03 0.01 0.4 0.00 0.02 0.00 0.54 373
FO 0.00 0.25 0.00 0.63 0.00 0.00 0.13 8
F 0.02 0.00 0.1 0.00 0.35 0.00 0.52 48
R 0.00 0.17 0.00 0.00 0.00 0.50 0.33 6
N 0.06 0.01 0.14 0.00 0.05 0.03 0.71 403
A S I FO F R N #
dataset, we first extract trajectories of objects and dy-
namic features. As next step, the optical flow is com-
puted inside the bounding boxes. Then, HDP is used
to extract the global interactions in the video. As next
step, the optical flow is computed inside the bounding
boxes.
For qualitative analysis of our method, Figure 5
shows the interactions extracted by the HDP model.
In Figure 5(a), interaction interpreted as one cavy ap-
proaches another one. Figure 5(b) represents one cavy
follows another one. Figure 5(c) shows two objects
are fighting each other. This wrong result is caused by
the detection error (split bounding box). Figure 5(d)
shows two objects close to each other (InGroup). The
interactions are performed by two or three cavies in
k frames and represented by flow words co-occurring
in the same clip.
Also we studied the effect of the hyper-parameters
of HDP (α and η) on the number of the extracted
interactions as depicted in Figure 7 (a). The hyper-
parameters (α and η) values ranging from 0.1 to 2,
and the clip length is 150 frames. As mentioned,
the hyper-parameter values control the number of ob-
tained topics (in our case interactions). As notice
from Figure 7 (a), the number of extracted interac-
tions has fluctuated significantly with increasing the
hyper-parameter values especially η. This is due to
the fact that the hyper-parameter η controls the prob-
ability of generating new interactions. It is crucial
mentioning that increasing the values of η does not al-
ways lead to the generation of new interactions. This
is likely due to the randomness in the Bayesian infer-
ence step.
Table 2 shows the quantitatively evaluation for the
selected interactions, Approach (A), Split (S), RunTo-
gether (R), Fight (F), InGroup (I), Follow (FO), No
(N). We add the field (No) which represents the false
positive and false negative of the particular interac-
tion, where the ground truth does not contain that in-
teraction. The last column in Table 2 represents the
number of instances of each category in the ground
truth.
In this experiment, the video divided into clips of
150 frames which achieved an average clustering of
up to 45 %. It is clear that there are different factors
Unsupervised Framework for Interactions Modeling between Multiple Objects
513
T
1
T
i-1
T
i
Trajectories
(a) Approach
(b) Follow
(c) Fight
(d) InGroup
Figure 5: The Cavy dataset. Illustration of different interac-
tions occur in k successive frames. Each row represents one
interaction extracted by HDP. The trajectories correspond
to the interactions. For better visibility, refer to the web
version.
that have an effect on the results, such as errors raised
from detector and tracker (missing, false, merged or
splitted objects) as shown in Figure 6. More precisely,
missing and merged object(s) issues lead to decrease
the TP, whereas the false detection increases the FP.
For instance, as can observed from Table 2, the high-
est false positive ratio is detected for the Split interac-
tion, while the interaction is not found in the ground
truth. Consequently, our method showed lower per-
formances for the Split interaction. Additionally, the
optical flow is probably not helpful in case of the fixed
objects which leads to increase the false negative. All
of these factors lead to degraded the performance of
our approach.
5.2 Results on Behave Dataset
Also we used the Behave dataset (Blunsden and
Fisher, 2010). Behave dataset consists of four video
sequences, and 76,800 frames in total and recorded
at 25 frames per second with a resolution of 640 ×
480 pixels. The Behave dataset provides different
challenging interactions include: InGroup, Approach,
WalkTogether, Split, Ignore, Following, Chase , Fight,
RunTogether, and Meet. The number of objects in-
volved in the interaction ranging from two to five.
Due to the limited number of annotated frames, (Kim
et al., 2014; Yin et al., 2012; Zhang et al., 2012;
M
¨
unch et al., 2012) used subsets of the categories to
demonstrate the performance of their methods. How-
(a) Split (b) False
(c) Missing (d) Merge
Figure 6: Illustration of the main tracking issues. (a) Split
object, which leads to discover interaction interpreted as
following. (b) Non-cavies object detected as cavy (false),
HDP discovers an interaction as gathering or as leaving. (c)
Missing of detecting and (d) Merge objects, in these cases
HDP will not be able to discover the interaction.
0.1
0.5
1
1.5
2
10
15
20
26
(a) Cavy dataset
# of interactions
η
α
0.1
0.5
1
1.5
2
10
20
30
40
(b) Behave dataset
# of interactions
η
α
Figure 7: Effects hyper-parameters α, η on number of ex-
tracted interactions. In each experiment, we change one of
the hyper-parameters while the other is held constant at 0.5
and vice versa. The clip size is 150 frames.
ever, we use the same subsets to compare our ap-
proach with their methods. In this study, we divided
the sequences into clips with size 150 frames and only
analyze clips for which ground truth are available. It
must be mentioned that Meet and Ignore categories
found just once and twice in the ground truth respec-
tively. Hence, these categories are excluded.
Results: Qualitatively, Figure 8 shows the set of
the probable interactions in one sequence. As ob-
served in Figure 8(a), one object follows another one
from the left corner to the right corner. Figure 8(b)
interpreted as one object approaches from the left cor-
ner to join other objects (converge to center). In Fig-
ure 8(c), the group splitted into two groups each one
VISAPP 2016 - International Conference on Computer Vision Theory and Applications
514
T
1
T
i-1
T
i
Trajectories
(a) Follow
(b) Approach
(c) Split
(d) Fight
Figure 8: Illustration of different interactions occur in k suc-
cessive frames.Each row represents one interaction, last col-
umn represents the extracted interaction using HDP.
Table 3: Confusion matrix represents the performance of
the HDP on the BEHAVE dataset.
I 0.54 0.13 0.16 0.03 0.03 0.00 0.10
A 0.11 0.68 0.16 0.05 0.00 0.00 0.00
W 0.03 0.14 0.75 0.06 0.00 0.03 0.00
S 0.13 0.13 0.00 0.67 0.00 0.00 0.07
FO 0.00 0.00 0.00 0.00 1 0.00 0.00
R 0.00 0.00 0.17 0.00 0.00 0.5 0.00
F 0.1 0.00 0.00 0.00 0.00 0.00 0.8
I A W S FO R F
walking into different directions and a set of objects
fighting each other as shown in Figure 8(d). It is worth
mentioning that the interactions a d in Figure 8 rep-
resented by flow words based on their co-occurrence
in the same clip. The spatial flow patterns is formed
by flow words at different coordinates in the frames.
For the quantitatively evaluation for the selected
categories, Approach (A), Split (S), WalkTogether (W),
RunTogether (R), Fight (F), InGroup (I), Follow (FO).
Table 3 shows the confusion matrix of HDP per-
formance. Our method demonstrated lower perfor-
mances for InGroup and RunTogether interactions.
Most likely due to that the optical flow is not worked
precisely with fixed objects. Addition to the highest
similarity and the spatial overlap between the interac-
tions.
For the comparison with previous work, we used
the same subsets from the Behave dataset and com-
pare directly with their results. We compared our ap-
proach with (Kim et al., 2014; Yin et al., 2012; M
¨
unch
Table 4: Interaction recognition comparison with (Kim
et al., 2014), (M
¨
unch et al., 2012) and (Yin et al., 2012).
Category Our (Kim et al., 2014) (M
¨
unch et al., 2012) (Yin et al., 2012)
Approach 68.42 83.33 60 n/a
Split 66.42 100 70 93.10
WalkTogether 75.00 91.66 45 92.10
InGroup 53.73 100 90 94.3
Fight 80.00 83.33 n/a 95.10
Average 65.95 93.74 66.25 93.65
et al., 2012) with the selected group activities e.g. Ap-
proach, Split, WalkTogether, InGroup,Fight as shown
in Table 4. As can be seen from Table 4, despite the
fact that our approach is completely unsupervised, we
achieved a clustering accuracy close to (M
¨
unch et al.,
2012) of up to 65.95%. Unlike (M
¨
unch et al., 2012),
our approach extracted the interactions without prior
knowledge.
The essential benefits of our approach is that it is
able to extract the interactions automatically for the
new unseen videos without any further knowledge.
5.3 Implementation
The presented tracking framework was implemented
in C++ using the OpenCV library while the optical
flow computation and HDP modeling was realized
in MATLAB using the standard toolboxes. The ex-
periments are performed on a desktop computer In-
tel(R) Core(TM) i7-4770 CPU @ 3.40GHz and 32
GB RAM. The implementation parameters were set
as follows. The threshold distance for equation 1 was
35 pixels, see Sec. 3. For optical flow feature ex-
traction, the trajectories interval k was 10, see Sec.
3. The hyper-parameters (α and η) values in equa-
tion 4 ranging from 0.1 to 2, and the clip length is
150 frames corresponding to approximately 20 sec-
onds, see Sec. 4. The run time for inference process
depends on the video size and number of objects in-
teracting with each other in the scene (BB). The Eu-
clidean distance is computed between sub-trajectories
for every k frames, the time complexity for Euclidean
distance is O(n).
6 CONCLUSIONS AND FUTURE
WORK
The aim of this paper was to address the problem of
interaction among multiple objects. Our proposed ap-
proach incorporates the unsupervised clustering capa-
bilities of the HDP with the spatio-temporal features
to recognize the interactions of multiple objects with-
out prior knowledge. Furthermore, the Cavy dataset
is introduced in this work. The Cavy dataset is created
by capturing the interactions between three cavies.
Unsupervised Framework for Interactions Modeling between Multiple Objects
515
The Cavy dataset contains six dominant interactions
performed several times by two or three cavies at dif-
ferent locations. The challenging aspect of the the
Cavy dataset is that the cavies are behaving and inter-
acting in complicated and unexpected ways. The ex-
periments have been performed on the Cavy dataset
and the Behave dataset. Extensive experiments on
these datasets demonstrate the effectiveness of the
proposed method. Our approach achieved satisfactory
results with a clustering accuracy of up to 68.84% on
the Behave dataset and up to 45% on Cavy dataset.
In the future, robust tracker needs to be developed
to mitigate the tracker effects. Also the appearance-
based and trajectory-based features beside optical
flow could possibly be included.
REFERENCES
Al-Raziqi, A., Krishna, M., and Denzler, J. (2014). Detec-
tion of object interactions in video sequences. OGRW,
pages 156–161.
Blunsden, S., Andrade, E., and Fisher, R. (2007). Non para-
metric classification of human interaction. In PRIA,
pages 347–354. Springer.
Blunsden, S. and Fisher, R. (2009). Detection and classi-
fication of interacting persons. Machine Learning for
Human Motion Analysis: Theory and Practice, page
213.
Blunsden, S. and Fisher, R. (2010). The behave video
dataset: ground truthed video for multi-person behav-
ior classification. BMVA, 4:1–12.
Cheng, Z., Qin, L., Huang, Q., Yan, S., and Tian, Q. (2014).
Recognizing human group action by layered model
with multiple cues. Neurocomputing, 136:124–135.
Delaitre, V., Sivic, J., and Laptev, I. (2011). Learning
person-object interactions for action recognition in
still images. In NIPS, pages 1503–1511.
Dong, Z., Kong, Y., Liu, C., Li, H., and Jia, Y. (2011). Rec-
ognizing human interaction by multiple features. In
ACPR, pages 77–81.
Guha, T. and Ward, R. K. (2012). Learning sparse represen-
tations for human action recognition. IEEE Transac-
tions on, Pattern Analysis and Machine Intelligence,
34(8):1576–1588.
Jiang, X., Rodner, E., and Denzler, J. (2012). Multi-
person tracking-by-detection based on calibrated
multi-camera systems. In Computer Vision and
Graphics, pages 743–751. Springer.
Kim, Y.-J., Cho, N.-G., and Lee, S.-W. (2014). Group activ-
ity recognition with group interaction zone. In ICPR,
pages 3517–3521.
Kong, Y. and Jia, Y. (2012). A hierarchical model for human
interaction recognition. In ICME, pages 1–6.
Krishna, M. and Denzler, J. (2014). A combination of
generative and discriminative models for fast unsuper-
vised activity recognition from traffic scene videos. In
Proceedings of the IEEE (WACV), pages 640–645.
Krishna, M., K
¨
orner, M., and Denzler, J. (2013). Hierarchi-
cal dirichlet processes for unsupervised online multi-
view action perception using temporal self-similarity
features. In ICDSC, pages 1–6.
Kuettel, D., Breitenstein, M. D., Van Gool, L., and Fer-
rari, V. (2010). What’s going on? discovering spatio-
temporal dependencies in dynamic scenes. In CVPR,
pages 1951–1958.
Li, B., Ayazoglu, M., Mao, T., Camps, O., Sznaier, M., et al.
(2011). Activity recognition using dynamic subspace
angles. In CVPR, pages 3193–3200.
Lin, W., Sun, M.-T., Poovendran, R., and Zhang, Z. (2010).
Group event detection with a varying number of group
members for video surveillance. IEEE Transactions
on CSVT, 20(8):1057–1067.
M
¨
unch, D., Michaelsen, E., and Arens, M. (2012). Support-
ing fuzzy metric temporal logic based situation recog-
nition by mean shift clustering. In KI 2012: Advances
in Artificial Intelligence, pages 233–236. Springer.
Ni, B., Yan, S., and Kassim, A. (2009). Recognizing human
group activities with localized causalities. In CVPR,
pages 1470–1477.
Ohayon, S., Avni, O., Taylor, A. L., Perona, P., and Egnor,
S. R. (2013). Automated multi-day tracking of marked
mice for the analysis of social behaviour. Journal of
neuroscience methods, 219(1):10–19.
Patron-Perez, A., Marszalek, M., Zisserman, A., and Reid,
I. (2010). High five: Recognising human interactions
in tv shows.
Sato, K. and Aggarwal, J. K. (2004). Temporal spatio-
velocity transform and its application to tracking and
interaction. Computer Vision and Image Understand-
ing, 96(2):100–128.
Teh, Y. W., Jordan, M. I., Beal, M. J., and Blei, D. M.
(2006). Hierarchical dirichlet processes. Journal of
the american statistical association, 101(476).
Yang, G., Yin, Y., and Man, H. (2013). Human object inter-
actions recognition based on social network analysis.
In AIPR, pages 1–4.
Yin, Y., Yang, G., Xu, J., and Man, H. (2012). Small group
human activity recognition. In ICIP, pages 2709–
2712.
Zach, C., Pock, T., and Bischof, H. (2007). A duality based
approach for realtime tv-l 1 optical flow. In Pattern
Recognition, pages 214–223. Springer.
Zhang, C., Yang, X., Lin, W., and Zhu, J. (2012). Recogniz-
ing human group behaviors with multi-group causali-
ties. In WI-IAT, volume 3, pages 44–48.
Zhou, Y., Ni, B., Yan, S., and Huang, T. S. (2011). Recog-
nizing pair-activities by causality analysis. ACM TIST,
2(1):5.
Zhu, G., Yan, S., Han, T. X., and Xu, C. (2011). Gener-
ative group activity analysis with quaternion descrip-
tor. In Advances in Multimedia Modeling, pages 1–11.
Springer.
Zivkovic, Z. (2004). Improved adaptive gaussian mixture
model for background subtraction. In ICPR, volume 2,
pages 28–31.
VISAPP 2016 - International Conference on Computer Vision Theory and Applications
516
