Trust-based Dynamic RBAC

Tamir Lavi

and Ehud Gudes

1,2

The Open University, Ra’anana, Israel

Ben-Gurion University, Beer-Sheva, 84105, Israel

Keywords:

Trust-Based Access Control, RBAC, Privacy-Preservation, Role Delegation.

Abstract:

A prominent feature of almost every computerized system is the presence of an access control module. The

Role Based Access Control (RBAC) model is among the most popular in both academic research and in

practice, within actual implementation of many applications and computer infrastructures. The RBAC model

simpliﬁes the way that a system administrator controls the assignment of permissions to individuals by as-

signing permissions to roles and roles to users. The growth in web applications which enable the access of

world-wide and unknown users, expose these applications to various attacks. This led few researchers to sug-

gest ways to incorporate trust within RBAC to achieve even better control over the assignment of users to

roles, and permissions within roles, based on the user trust level. In this work, we present a new trust-based

RBAC model which improves and reﬁnes the assignment of permissions to roles with awareness of the user

trust and reputation. After describing the basic model, called TDRBAC for Trust-based Dynamic RBAC, we

describe ways to deal with issues like privacy-preservation and delegation of roles with the consideration of

user’s trust.

1 INTRODUCTION

Managing access control in a computerized system

can be a simple task as long as there are a few users

or entities to control. However, with the growth of the

number of entities within a web based system, and the

exponential growth of the number of its users, there is

a need to ﬁnd better ways to manage access to web ap-

plications. Several access control models have been

suggested over the years to simplify access control

management, one of those is the Role Based Access

Control(RBAC) model. RBAC is probably the most

common, widely accepted and most widespread both

in academic research and in actual implementation of

many web systems. RBAC allows the assignment of

users to roles and the assignment of roles to permis-

sions, as opposed to direct assignment of users to per-

missions. However as web applications become more

open (e.g. Google, Amazon, etc.) and their users are

spread world-wide and are often unknownin advance,

those web application get exposed to various attacks.

The basic RBAC model may not be sufﬁcient and a

more reﬁned model which assigns permissions also

based on Trust is needed. In this paper, we propose

such a new model called Trust-based Dynamic RBAC

(TDRBAC).

Previous studies of trust-based access control such

as Ray et. al (Chakraborty and Ray, 2006) change the

assignment of roles to users based on their trust level.

However, the permissions within a role remain the

same. We believe that such assignment is too coarse

and a more reﬁned model is needed. For example two

physicians may be assigned to a role of Doctor but

their permissions may differ based on their trust level.

In this paper we propose such a reﬁned model called

TDRBAC for Trust-based Dynamic RBAC. In TDR-

BAC, we incorporate traditional RBAC with aware-

ness to the user trust level in a way that maintains

the advantages of RBAC as a well-deﬁned permis-

sion management model, and utilizing the trust level

of the system entities to control permission assign-

ment in a more reﬁned granularly and a more dynamic

way. TDRBAC reduces the need to maintain and con-

trol user to role assignment over time, by allowing

ﬂexibility and resilience to the changes in the user’s

trust level within the assignment of the roles to selec-

tive permissions. The model is designed to deny per-

missions from a user when her trust level decreases,

while granting more permissions when the trust level

increases.

To enhance TDRBAC usability we propose two

important extensions. The ﬁrst extension provides

privacy, and the second one enables user rights del-

egation with trust awareness.

Lavi, T. and Gudes, E.

Trust-based Dynamic RBAC.

DOI: 10.5220/0005687503170324

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 317-324

ISBN: 978-989-758-167-0

317

The rest of the paper is organized as follows: In

the next section we provide the background and dis-

cuss related work. In Section 3 we deﬁne and explain

the basic model of TDRBAC and then we present a

comprehensive example that demonstrate the usage of

the proposed model. In Section 4 we discuss the ex-

tensions for privacy-preservation and user rights del-

egation. In Section 5 we conclude this work and dis-

cuss future work.

2 BACKGROUND AND RELATED

WORK

The RBAC model was deﬁned in 1992 by Ferraiolo

et al (Ferraiolo and Kuhn, 1992), and later formal-

ized in (Sandhu et al., 1996) by Sandhu et al, as a dis-

cretionary access control approach that is more suit-

able to the secure processing needs of non-military

systems. RBAC was rapidly adopted both in practice

and in theory studies. RBAC offers an efﬁcient man-

agement of user’s permissions, an effective enforce-

ment of need-to-know access control principles and

simpliﬁed auditing of user’s permissions for regula-

tory compliance. On the other hand, RBAC is often

considered outdated, expensive to implement and un-

able to accommodate real-time environmental states

as access control parameters. A recent survey con-

ducted by Fernandez et al (Condori-Fern´andez et al.,

2012) questioned RBAC assumptions and strengths,

and revealed some interesting ﬁndings. The survey

shows 48% of agreement among the respondents, that

changes affecting the assignment of users to roles, and

roles to permissions, happen frequently and may be-

come either an overwhelming task, or may lead to

violations of the need-to-know policies in enterprise

applications. We believe that within large-scale open

applications that phenomena could be even more dis-

ruptive (the survey did not include open applications).

Another dynamic change that RBAC itself is not suf-

ﬁcient to handle, is the change in the user’s trust

level over time, while it is expected that an access

control system should not disregard low user trust

when granting access to sensitive permissions. To

overcome the lack of ﬂexibility of RBAC, new ac-

cess control models have been introduced, including

Attributes Based Access Control (ABAC) (Jin et al.,

2012b)(Coyne and Weil, 2013), ABAC/RBAC hybrid

approach such as (EmpowerID, 2013), (Rajpoot et al.,

2015) and RABAC (Jin et al., 2012a).

The idea of incorporating trust into an access

control model was discussed before by several re-

searchers. In ABAC type model, integrating trust can

be achieved simply by considering the user trust as

an attribute within the system (Smari et al., 2014).

RBAC on the other hand is a rigid model and by that

place a challenge for combining trust awareness. The

access control model suggested in (Deng and Zhou,

2012), offers a set of equations to compute the user

trust level in relation to a speciﬁc corresponding ob-

ject. Both the user nodes and resource nodes are

assigned a trust level using a trust evaluation algo-

rithm which makes the model quite far from the sim-

ple RBAC model. The TrustBAC model, described

in (Chakraborty and Ray, 2006), deﬁnes the required

trust level that the user must have in order to be as-

signed to a speciﬁc role. If the user does not meet the

required trust level of a speciﬁc role, the role assign-

ment is denied and another role is assigned to the user.

This may lead to a too simple model which may cause

proliferation of roles. Another more sophisticated

model was proposed by Chen and Crampton (Chen

and Crampton, 2011). Their model deﬁnes quanti-

tative factors on various components of the RBAC

model and also introduce the notion of ”Mitigation”

that allow a speciﬁc permission to be allowed under

speciﬁc requirement in case that the trust level of the

user does not meet the minimum risk threshold. The

model considers several mitigation strategies which

can be used to compute the risk level for using a per-

mission based on multiple paths between the user and

the permission. Again this deviates from the simple

RBAC structure and may impair the robust structure

of RBAC and interfere with the important RBAC fea-

ture of simpliﬁed user’s permission auditing.

TDRBAC on the other hand offers a way to in-

corporate users’s trust considerations while preserv-

ing the robust skeleton of RBAC as a role-centric ac-

cess control. It provides a compromise between the

too simple model of TrustBAC and the complex mod-

els of (Deng and Zhou, 2012) and (Chen and Cramp-

ton, 2011). In TDRBAC, as in RBAC, thepermissions

explicitly deﬁne the modes of access and enable sim-

pliﬁed auditing (Kuhn et al., 2010).

3 THE TDRBAC MODEL

3.1 TDRBAC Elements

We rely on the common deﬁnition of the following:

user, role, operation, object, permission, and in ad-

dition lets deﬁne:

Deﬁnition 1. Let userTrust be a real number in the

range of [0, 1] that represent a user expectation to

act in an honest manner as expected when 0 means

that the user is expected to abuse the system and 1

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

318

means that the user is fully trusted. userTrust is a

user property.

We denote: user.userTrust ∈ [0, 1].

Deﬁnition 2. Let permissionTrust be a real number

in the range of [0, 1] that represent the minimum level

of trust that a user must have in order to use the per-

mission, in a speciﬁc role to permission assignment

(see RPA deﬁnition below).

We denote: permissionTrust ∈ [1, 0].

3.2 Assignments

Deﬁnition 3. Let URA be user to role assignment. a

user can be assigned to many roles in many-to-many

relation.

We denote: URA ⊆ USERS × ROLES.

Table 1: URA assignment example.

USER ROLE

Mike Manager

Joe Guest

Lisa Admin

Deﬁnition 4. Let RPA be role to permission assign-

ment. A role can be assigned to many permissions in

a many-to-many relation. Each role to permission as-

signment has a trust level.

We denote: RPA ⊆ ROLES × PERMISSION× [0, 1].

The range [0,1] represent the RPA trust level which

represent the minimum trust level that the user must

have in order use this permission in this role.

Table 2: RPA Assignment Example.

ROLE PERMISSION Trust

Manager Can assign roles to users 0.9

Guest Read public posts 0

Admin Change system conﬁgurations 1

3.3 How TDRBAC Works

When a user requests to perform some operation on a

system resource, the Authorization Center (AC) ver-

iﬁes that the user is assigned to a role with the cor-

responding permission. If the user is not assigned to

any role with a corresponding permission, the request

is rejected. If a corresponding permission was found,

the AC will consider the RPA trust level: If the RPA

trust level is 0, then the request is granted and there is

no need to calculate the user trust. Otherwise, the AC

will calculate the user trust and allow the request only

if the user trust level is greater or equal to the RPA

trust level.

3.4 Dealing with Collisions

In some cases, users may be assigned to more than

one role in a speciﬁc session. For example, a sales

person can also be a board member and get assigned

to two different roles. The common approach to han-

dle multiple roles for each user is to restrict the user to

select speciﬁc role for each new session. For example,

the user must deﬁne whether she is acting as a ”board

member” or as a ”sales person” once the session is

created. That leads to a massive overhead on system

usage and while it’s expected on high sensitive sys-

tems, it could be very interfering in normal systems.

Therefore we believe that the model should handle a

multiple roles assignments in a speciﬁc session.

A collision is a situation when a speciﬁc permis-

sion is restricted from the user in one RPA when

the RPA.trustLevel is greater than the userTrust

level, and it is granted by another RPA when the

RPA.trustLevel is lesser than the userTrust level. In

a case of collision, the decision to grant or reject the

user’s request is based on a predeﬁned security policy.

The Security Ofﬁcer can decide to reject the permis-

sion if there is at least one RPA with a greater corre-

sponding RPA.trust than the userTrust, or she can de-

cide to accept any permission request once there is at

least one RPA with a lesser corresponding RPA.trust

than the userTrust.

The selected policy should be considered very

carefully. The simple-minded approach would be to

allow the permission if there is at least one corre-

sponding RPA that allows it, but later in this paper

we show that this approach may provoke a security

breach by allowing the user a subset of permissions

that the user could use to induce an attack or abuse

the system even with a low level of trust.

3.5 TDRBAC in Action (Detailed

Scenario)

In order to demonstrate TDRBAC usage we will show

an access control policy for a technical customer sup-

port system. To leverage the ﬂexibility of TDRBAC

we want to have a small number of roles and let the

trust level to allow speciﬁc permission in the limits of

the role. In our system, we have only three roles:

• Customer

• Support agent

• Administrator

A customer can create issues (a case ticket) to de-

scribe a problem, a bug or request and close the ticket

once it is resolved. Once the user gain more trust we

Trust-based Dynamic RBAC

319

can assign more permission to the user, like adding

ﬁles to the issue.

An agent can be assigned to an issue, view and

instruct the customer to resolve it. As the agent gains

more trust, we can assign advanced capabilities like

control the customer desktop in order to resolve is-

sues.

An administrator can change system properties

and conﬁguration and manage users and roles. In our

system, the user ”root” is always assign to the admin-

istrator role and is always fully trusted.

Another capability that we have in our support

system is the ”Knowledge-Base”. The KB is a set of

articles with known bugs and issues that the agents

can use to share resolutions with each other. Once an

agent gets an issue for which he has no solution, he

can browse the KB to search for a solution. A trusted

customer can also get access to the KB, and trusted

agent can add or edit articles in the KB.

The complete set of permissions is as follows:

• A customer can:

– Create a new issue

– Add comments to own issues

– Add ﬁles (like logs, screenshots etc.)

– Close own issues

– Collaborate on issues of other users

– Browse the knowledge-base

– Can create more than one issue in 24 hours (to

avoid spam)

• An agent can:

– Take ownership on an issue

– View customer desktop

– Gain control on customer desktop and ﬁles sys-

tem

– Resolve an issue

– Add comments to issues

– Assign issues to other agents

– Add article to the knowledge-base

– Edit articles in the knowledge-base

– Delete article on the knowledge-base

– Gain control on customer desktop and ﬁles

• An administrator can:

– Change system conﬁguration

– Register new users

– Manage users details

– Manage user’s roles

The next step is to assign a trust level to each per-

mission. The most basic capabilities, which any new

user must have, will be assigned to a trust level of

0. As the permission is more advanced, we assign a

higher trust. New users in our system starts with a

trust level of 0.

Table 3 list the ﬁnal RPA of our system:

Table 3: RPA Assignment.

ROLE PERMISSION Trust

Customer Create a new issue 0

Add comments to own issues 0

Close own issues 0

Browse the KB 0.25

Create more than 0.25

one issue in 24h

Add ﬁles to an issue 0.75

Collaborate on issues 1

of other users

Agent Resolve an issue 0

Add comments to issues 0

Add ﬁles to an issue 0.25

Add article to the KB 0.25

Assign issues to other agents 0.5

Edit articles in the KB 0.5

Take ownership on an issue 0.75

View customer desktop 0.75

Delete article on the KB 0.75

Control on customer 1

desktop/ﬁles

Admin Register new users 0.25

Manage users details 0.75

Change system conﬁguration 1

Manage user’s roles 1

As is shown in the example above, our model of

access control allows managing just a few number of

roles, and yet getting the ﬂexibility and dynamic per-

mission assignment that by other access control mod-

els will most likely require more roles to manage such

as: basic customer and advanced customer or new

agent and veteran agent. Nevertheless, a user cannot

gain any permission that is not part of her roles.

Permissions that are essential for the role are set

with the RPA

rust of 0, that is to insure that users get

the minimum required permission for the role they are

assigned to. As the users gain more trust, they also

gain access to more sensitive or strong permissions.

The problem of assigning trust level to permissions is

dealt in more detail in Section 3.7.

3.6 Calculating userTrust

TDRBAC does not restrict, nor dictate, the way of

calculating the user trust level. Many models suggest

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

320

a way of calculating a user trust level based on the

user history, experience and recommendation, see for

example (Ray and Chakraborty, 2004). Yet, it is ex-

pected that trust level of a user would be calculated as

close as possible to runtime, each time that the user is

asking to use a permission. To improve performance

the trust calculation function can use cached data and

avoid re-calculation of user trust in each access oper-

ation. (For example, the user trust calculation can use

the same value for the next 5 minutes, assuming that

in 5 minutes there would be no major change in the

user trust level.) The system administrator must be

aware that a malicious user can exploit the time dif-

ference of user trust calculation to perform illegal ac-

tions before losing her permissions due to the loss of

trust. Note that the trust model may also take into ac-

count the number of times the user was denied access

to permissions. If this number is high it may indicates

an intrusion attempt by a low trust user.

A related issue is the issue of dynamic enforce-

ment. When the trust level decreases, one loses access

but what happens to the accesses already performed?

In a transaction system (like a Database transaction)

one may require that the entire transaction be per-

formed with a single trust level, if such a loss of

trust has happened, the entire transaction should be

aborted.

3.7 Computing Trust of Role to

Permission Assignment

There are two key components in our model: One is

the calculation of the user trust level. Obviously, if the

user’s trust is not genuine, the complete model looses

it’s credibility. Yet, as previously explained, TDR-

BAC does not dictate the way of calculating the user

trust level. The second is the trust level that is cho-

sen for each Role to Permission Assignment (RPA).

Choosing high level of trust for each permission can

lead to a low usability while too low trust could lead

to an untrustworthy and vulnerable system. Proper

assignment of RPA should balance between usability

and security. To improve system usability, we should

consider to assign the lower trust level possible, hence

having the permissions accessible to as many users as

possible. On the other hand we must prevent low-

trusted users to perform dangerous or sensitive oper-

ations that can cause damage to the system.

The deﬁnition of the RPA can be done by the secu-

rity administrator based on accumulated expertise and

experience, however a more systematic methodology

is desired. Next we propose such methodology based

on information collected during system operation. In

order to formulate the process of permissions trust as-

signment we need to add the following deﬁnitions:

Deﬁnition 5. Let Incident be a scenario where a user

perform a set of operations that leads to a security

breach, as system shutdown, data loss or data manip-

ulation.

Deﬁnition 6. Let Damage(Incident) be a real num-

ber in the range of [0, 1] that represents the projec-

tion of an Incident on the system, when 0 means that

the incident does not effect the system, and 1 means a

complete destruction or system breakdown. In a com-

mercial system, the Damage should be calculated by

the ﬁnancial loss, and the cost to repair the damage.

The value of Damage should be normalized by the to-

tal cost that the organization can handle. In a non-

commercial system (such as military system) the value

of Damage reﬂect the damage of an incident based on

risk assessment.

In the process described below we use the Damage

as highly correlated with the required Trust level.

Deﬁnition 7. Let common(permission) be a real

number in the range of [0, 1] that represent the usage

probability of a speciﬁc permission within the sys-

tem. A more commonly used permission should be

assigned to a lower value of trust as possible while

less common permission, with requirement for a high

level of trust would have a smaller effect on the over-

all system usability.

In practice Common may be learned from the sys-

tem logs.

Deﬁnition 8. Let PER(Incident) be a subset of per-

missions, that are needed by a user to cause an

Incident.

We Denote: Per(Incident) ⊆ PERMISSIONS

With the abovedeﬁnitions we look for a procedure

that will assign an ”optimal” match of trust levels to

permissions. One may deﬁne the optimality criteria

in different ways, but in general, the trust of a permis-

sion shuld increase with the incident damage it was

involved with, and decreases with its commonality.

The tradeoff between these two factors is to be deter-

mined by the security administrator. While we have

not fully investigated the complexity of the algorithm

to solve this optimality problem, below we suggest a

simple and practical heuristic for the trust assignment.

The procedure is as follows:

1. Sort all Incidents by the value of the damage in

descending order, such that Incident with high

value of damage is ordered before an Incident

with a lower level of damage.

2. Sort all permissions by the value of common in

ascending order, such that permission that is less

Trust-based Dynamic RBAC

321

usable is ordered before a more commonly used

permission.

3. initialize all permissions to a minimal trust value

(as determined by the security administrator)

4. Set i = 0

5. For the subset of permissions PER(Incident

)

if the there is no permission with a trust level

of Damage(Incident

) or higher, than assign trust

level of Damage(Incident

) to the ﬁrst permission

in the subset of permission (in the ”common” or-

der).

6. adjust i in 1 and repeat step 5.

Note that the procedure above insures that each in-

cident will cause at least one permission, usually the

less common one, to acquire a high trust level, while

the rest may stay in their lower trust levels.

4 TDRBAC EXTENSIONS

In the following section we propose two important ex-

tensions for the basic TDRBAC model:

• TDRBAC-P - extension for privacy-preservation

• TDRBAC-D - extension for delegation.

4.1 TDRBAC-P Extension for

Privacy-preservation

Privacy-preservation issues are becoming more and

more important these days as social networks and

large open systems raise crucial questions regarding

the usage of the user’s private data. Here we describe

an extension to TDRBAC dealing with the privacy is-

sue.

To address the concerns of privacy-preservationin

TDRBAC we incorporate the broadly used notion of

Purpose as proposed in (Yang et al., 2007). We deﬁne

purpose as follows:

Deﬁnition 9. Let Purpose be a reason for data col-

lection and data access. The purpose is ”well-

deﬁned”, that is to say that the purpose is unambigu-

ous in the model implementation. Purposes cannot

overlap or partially overlap.

Let PUR be the collection of purposes in the access

control policy.

We deﬁne Pi as a set of purposes: Pi =

{p1, p2, p3, . . .}|p ∈ PUR

We extend the RPA assignment to include the al-

lowed purposes:

Deﬁnition 10. RPA ⊆ ROLES × PERMISSIONS ×

PUR× [0, 1]

With each permission request, the system must

specify the purposes for which the permission is re-

quested. The permission request would be in the

form:

f(user, permission, purpose).

This deﬁnition enables the speciﬁcation of differ-

ent trust levels for different purposes for the same

(role,permission) pair. An example for an RPA as-

signment including purposes is shown in table 4

In case the trust level is not sufﬁcient for a speciﬁc

purpose, the request may be denied, or less private

data for a lower purpose may be returned. One useful

way of dealing with purposes in case of a of Read

access, is to allow two types of answers to a Read

request:

• Abstract Data - a modiﬁed version of the records

without any private data (such as: users identity,

medical details, students grades, etc.) Another

form of Abstract data may be a k-anonymizeddata

such as in (Bayardo and Agrawal, 2005).

• Detailed Data - The full detailed data as re-

quested by the user.

The way the AC behaves in this case is dependent

on the Privacy policy. If both the purpose and trust

level match, the access is permitted. If the purpose

match and the trust level is too low, the request may

be denied or the data used for a lower purpose may

be returned, if the trust level for the lower purpose is

sufﬁcient.

Usage Example

A doctor is requesting read access to patient lab

tests. The request purpose can be one of:

• p1 - For research purposes (low purpose)

• p2 - To write a prescription (high purpose)

The RPA for lab results are as speciﬁed in table 5.

The returned results in case of p1 is abstract data

(e.g - without the patient personal details). The re-

sults in case of p2 would be complete lab results. If

the doctor has a trust level of 0.4 and she request the

”write prescription” purpose, the system may return

only abstract data (lower the purpose) or deny the re-

quest.

4.1.1 Purpose Enforcement

When implementing the approach of purpose, the sys-

tem must enforce the purpose notion to avoid manip-

ulation of the permission request (Colombo and Fer-

rari, 2014). To achieve purpose enforcement, the sys-

tem should identify the actual use of the permission

in the time of the request and substitute the purpose

within the permission request. In the above example,

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

322

Table 4: RPA Assignment with Purposes.

Role Permission Purposes Trust

Administrative Assistant Read contacts details Schedule meetings 0.5

Engineer Access previous studies and researches Resolve system ﬂaws 0.5

CFO Access business plans Create budget plans 0.75

Table 5: RPA Assignment with Purposes.

Role Permission Purposes Trust

Doctor Read lab results Write 0.5

Doctor Read lab results prescription

Doctor Read lab results Research 0.3

when the doctor request permission to review lab re-

sults, the system should identify whether the doctor is

currently writing prescription to a patient and substi-

tute the purpose accordingly.

4.2 TDRBAC-D Extension for

Delegation

Delegation is the assignment of a role to a user. Nor-

mally, role assignments are performed by the secu-

rity ofﬁcer or administrators (”Administrative Dele-

gation”). However, sometimes we want to allow one

user to delegate his own roles to another user (”User

Delegation”). Administrative delegations are usually

permanent, while user delegations are usually tempo-

rary. From now, we refer to ”delegation” as user del-

egation.

The ability to delegate user roles to other users is

very important in large-scale open systems. By letting

the users to delegate their own roles, with the proper

limitation and trust awareness, we simplify the man-

agement of the user roles, and avoid too many admin-

istrative changes. Examples for constraints which can

be used in roles delegation are given by Crampton et

al in (Crampton and Khambhammettu, 2008).

To enable delegation which is Trust dependent, we

extend the basic model of TDRBAC as follows:

4.2.1 Deﬁnitions

Deﬁnition 11. Let delegator be a user who perform

role delegation to another user.

Deﬁnition 12. Let delegatee be a user who receive

role delegation from another user

Deﬁnition 13. Let delegationThreshold be a real

number in the range [0, 1]. The number repre-

sents the minimum trust level that the user (the del-

egator) must have in order to perform delegation

of a speciﬁc role to another user. We assign a

delegationThreshold to any role that we allow users

to delegate. A role that is not allowed for delegation

does not have a delegationThreshold value. We de-

note: delegationThreshold ∈ [0, 1]

Deﬁnition 14. Let delegatedTrust be a calculated

value based on the user trust level and the delegator

trust. When the user request a permission based on

a delegated role, we use the delegatedTrust value

instead of the userTrust.

Formula:

delegatedTrust = Delegator.userTrust ×

Delegatee.usertTrust

Deﬁnition 15. Let TRA be a delegationThreshold

to role assignment. An assignment of a trust level

threshold for any role that is eligible for delegation. A

role is eligible for delegation only if the delegator as-

signed to the role and has a trust level that is greater

or equals to the delegated threshold of the speciﬁc

role. We denote: TRA ⊆ role× delegationThreshold

Table 6 demonstrate TRA assignment

Table 6: TRA Assignment.

Role Delegation Threshold

Engineer 0.5

Director 0.8

Salesperson 0.6

Deﬁnition 16. Let DRA be delegated roles assign-

ment - A list of delegated roles performed by dele-

gators to delegatees. We denote: DRA ⊆ USER×

ROLE ×USER

Table 7 demonstrate DRA assignment

Table 7: DRA Assignment.

Delegator Role Delegatee

John Engineer Bob

Michael Director Lisa

Alice Salesperson Anna

4.2.2 Understanding TDRBAC-D

When a user requests a permission, the AC will ﬁrst

runs the basic TDRBAC function. If a direct user

to role assignment does not allow the permission re-

quested, the AC will run the delegation permission

functions by listing the delegated roles assignment

where the user is mentioned as Delegatee. Than the

Trust-based Dynamic RBAC

323

AC will verify that the assignment is valid. A valid

delegation must satisfy the following conditions:

1. The delegator is assigned to the role that is being

delegated.

2. The role is eligible for delegation.

3. The delegator trust level is greater or equal to the

delegationThreshold.

If the requested permission is listed in one of the valid

roles, than the permission is granted if the computed

delegatedTrust is greater or equals to the RPA trust

level.

5 CONCLUSIONS

The concept of Trust Aware role based access control

model was recognized in previous work. The chal-

lenge in this work was to preserve the strengths of the

well knownRBAC model as a role-centric access con-

trol. The model presented here shows a middle way in

that it provides a reﬁned enough level of trust aware-

ness based on permissions, yet it is simple, enables

simpliﬁed auditing and can be easily understood and

enforced. In addition to the basic model, two exten-

sions were presented, one for Privacy purposes, the

other for Delegation purposes.

In future work we like to investigate the RPA com-

putation problem we described in section 3.7 further

and evaluate it under various simulation conditions.

We also plan to combine the model extensions and

test the model in a real-life scenario of a large com-

pany.

REFERENCES

Bayardo, R. J. and Agrawal, R. (2005). Data privacy

through optimal k-anonymization. In Data Engineer-

ing, 2005. ICDE 2005. Proceedings. 21st Interna-

tional Conference on, pages 217–228. IEEE.

Chakraborty, S. and Ray, I. (2006). Trustbac: integrating

trust relationships into the rbac model for access con-

trol in open systems. In Proceedings of the eleventh

ACM symposium on Access control models and tech-

nologies, pages 49–58. ACM.

Chen, L. and Crampton, J. (2011). Risk-aware role-based

access control. In Security and Trust Management -

7th International Workshop, STM 2011, Copenhagen,

Denmark, June 27-28, 2011, Revised Selected Papers,

pages 140–156.

Colombo, P. and Ferrari, E. (2014). Enforcement of pur-

pose based access control within relational database

management systems. IEEE Trans. Knowl. Data Eng.,

26(11):2703–2716.

Condori-Fern´andez, N., Franqueira, V. N., and Wieringa,

R. (2012). Report on the survey of role-based access

control (rbac) in practice.

Coyne, E. and Weil, T. R. (2013). Abac and rbac: Scal-

able, ﬂexible, and auditable access management. IT

Professional, 15(3):14–16.

Crampton, J. and Khambhammettu, H. (2008). Delegation

in role-based access control. Int. J. Inf. Sec., 7(2):123–

136.

Deng, W. and Zhou, Z. (2012). A ﬂexible rbac model based

on trust in open system. In Intelligent Systems (GCIS),

2012 Third Global Congress on, pages 400–404.

EmpowerID, w. p. (2013). Best practices in enterprise au-

thorization: The rbac/abac hybrid approach.

Ferraiolo, D. and Kuhn, R. (1992). Role-based access con-

trol. In In 15th NIST-NCSC National Computer Secu-

rity Conference, pages 554–563.

Jin, X., Krishnan, R., and Sandhu, R. (2012a). A role-based

administration model for attributes. In Proceedings of

the First International Workshop on Secure and Re-

silient Architectures and Systems, pages 7–12. ACM.

Jin, X., Krishnan, R., and Sandhu, R. S. (2012b). A

uniﬁed attribute-based access control model covering

dac, mac and rbac. DBSec, 12:41–55.

Kuhn, D. R., Coyne, E. J., and Weil, T. R. (2010). Adding

attributes to role-based access control. Computer,

43(6):79–81.

Rajpoot, Q. M., Jensen, C. D., and Krishnan, R. (2015).

Integrating attributes into role-based access control.

In Data and Applications Security and Privacy XXIX,

pages 242–249. Springer.

Ray, I. and Chakraborty, S. (2004). A vector model of

trust for developing trustworthy systems. In In Eu-

ropean Symposium on Research in Computer Security

, Sophia Antipolis (France, pages 260–275. Springer-

Verlag.

Sandhu, R. S., Coyne, E. J., Feinstein, H. L., and Youman,

C. E. (1996). Role-based access control models. Com-

puter, 29(2):38–47.

Smari, W. W., Clemente, P., and Lalande, J. (2014). An

extended attribute based access control model with

trust and privacy: Application to a collaborative crisis

management system. Future Generation Comp. Syst.,

31:147–168.

Yang, N., Barringer, H., and Zhang, N. (2007). A purpose-

based access control model. In Proceedings of the

Third International Symposium on Information Assur-

ance and Security, IAS 2007, August 29-31, 2007,

Manchester, United Kingdom, pages 143–148.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

324
