AMBIT-SE: Towards a User-aware Semantic Enterprise Search Engine

Giacomo Cabri, Stefano Gaddi and Riccardo Martoglia

University of Modena and Reggio Emilia, Modena, Italy

Keywords:

User-awareness, Enterprise Search Engine, Information Retrieval, Text Analysis, Semantic Knowledge and

Similarity.

Abstract:

Search engines represent one of the most exploited tools both in our everyday life and in our work. In this

paper we propose a user-aware semantic enterprise search engine called AMBIT-SE. It is “enterprise” in the

sense that it is focused on the search in enterprise websites; the “semantic” aspect is related to the fact that

it exploits not an exact word match, but relies also on the meaning of the words by means of synonyms and

related terms; ﬁnally, to produce query results it takes into account also the user information, which turns out to

be very useful to improve the search. We explain how our system works and report the results of experiments

on different websites.

1 INTRODUCTION

In today’s enterprises the need for providing appropri-

ate means to search for speciﬁc information in inter-

nal and public repositories is more and more increas-

ing. This goal is twofold: from the one hand, enabling

employees to ﬁnd the needed information in a short

time is not only useful to reduce the global time need

to carry out a task, but also to decrease the frustration

of long searches; on the other hand, precise and rel-

evant answers to customers that exploit the company

web sites for both searching for information and in-

teracting with the company can grant a high degree of

customer satisfaction.

In this context, two aspects that can improve the

relevance of the search results are semantics (Man-

gold, 2007) and user-awareness (Xiang et al., 2010).

Semantics can be useful to overcome the limitations

of a syntactic approach, which is often exploited but

leads to a reduced number of results. User-awareness

can be useful to tailor the search results on the base

of the context of the user that performs a query or a

request. As far as we know, there are no enterprise

search engine that exploits both aspects in a single

approach.

Starting from this consideration, this paper pro-

poses a user-aware semantic enterprise search engine

that was built with this goal in mind, describing in de-

tail its architecture and how it works. The search en-

gine is called AMBIT-SE (AMBIT Search Engine).

It is not a generic search engine, but a search en-

gine dedicated to an enterprise website. We exploit

semantic techniques to improve the search: instead

of a pure syntactic matching between the query key-

words and the words in the available documents, we

rely on their meaning and take into account synonyms

and related terms. Moreover, the main innovation of

our approach is to exploit user information to further

improve the search results. In fact, the approach we

propose takes advantage of textual information, cer-

tainly the primary component of the documents that

should be presented / suggested to users, and also one

of the main information characterizing user proﬁles

(think, for instance, to the contents of user browsing

history, to the description of users’ interests, and so

on).

Our innovative approach is based on text analy-

sis, semantic retrieval and user-aware techniques and

leads to the following achievements:

• its semantic features are powerful enough to pro-

vide enhanced searching effectiveness over stan-

dard search techniques;

• thanks to user awareness, search results actually

reﬂect the user’s preferences and needs;

• it is general, ﬂexible and able to process multilin-

gual information;

• it is devised for IT SMEs, providing them with

easy-to-apply methods that do not require big in-

vestments or knowledge prerequisites, allowing

them to query for the information they need in the

way they are used to.

Cabri, G., Gaddi, S. and Martoglia, R.

AMBIT-SE: Towards a User-aware Semantic Enterprise Search Engine.

In Proceedings of the 12th International Conference on Web Information Systems and Technologies (WEBIST 2016) - Volume 2, pages 98-108

ISBN: 978-989-758-186-1

This paper is organized as follows. First, we

present an overview of the proposed search engine

(Section 2). Then, we explain how our approach an-

alyzes the documents that can be “searchable” by the

users (Section 3), and how it deﬁnes which documents

must be retrieved to satisfy the user’s query (Sec-

tion 4). We report the results of the experiments car-

ried out on our system (Section 5). Finally, before the

conclusions (Section 7) we report some related work

(Section 6).

2 SYSTEM OVERVIEW

In this section we present an overview of the proposed

semantic enterprise search engine. Figure 1 proposes

the workﬂow of AMBIT-SE, which is composed by a

series of coordinated ofﬂine and online processes.

First of all, AMBIT-SE performs a Document

analysis phase, in which any textual information

available in the documents that will need to be re-

trieved (e.g. web pages for a given site) and in the

documents useful to determine the user’s behaviour

and preferences (such as e-mails, web pages viewed,

proﬁle information, past search queries, etc.) is ex-

tracted and processed. The workﬂow starts by using a

Web Crawler to retrieve the raw data of all the docu-

ments that must be searchable, such as the web pages

belonging to a portal. All of these ﬁles are then sub-

mitted to the actual analysis process, which consists

of the following steps:

1. The textual content of all ﬁles is extracted;

2. The language of each ﬁle is determined;

3. The content is divided into paragraphs, and each

paragraph is divided into lines of text;

4. Each line of text is divided into “Tokens” (single

terms);

5. The “Stem” (dictionary form of a term) and “Part

of speech” value (basic type of term) of each token

is determined;

6. Terms classiﬁed as nouns are preserved;

7. Nouns are processed with word sense disam-

biguation algorithms, in order to be able to com-

pute synonyms and related terms information

from a thesaurus;

8. The weight of each noun, corresponding to its

containing document, is calculated.

The data structure containing all the document

analysis results will be referred to as “Website(s) se-

mantic glossary”. At the same time, the documents

that constitute the user’s proﬁle, such as all of the web

pages he has visited, are analyzed in the same way,

resulting in a “User semantic glossary”. Both glos-

saries are then compared with document similarity al-

gorithms (see “Semantic glossaries computation and

comparison” in the ﬁgure), and a “Proﬁle ranking” is

determined, symbolizing how relevant the retrievable

documents are in relation to the user’s preferences.

The AMBIT-SE online phase allows users to

search through the retrievable data index with differ-

ent kinds of queries, resulting in a “Query ranking”.

The two rankings are then normalized and merged,

so that the ﬁnal ranking of the retrieved ﬁles will

take into account both the query relevance and the

user’s preferences based on the results of the afore-

mentioned process.

The software is written in Java and exploits several

Open-source programs and libraries. The currently

supported languages for all operations are: English,

Italian, Spanish, German, French, Finnish, Dutch,

Polish.

The following sections (Section 3 for document

analysis and Section 4 for document retrieval) provide

in-depth information on each step of the text process-

ing pipeline, illustrating the theory behind them and

the techniques used to execute them.

3 DOCUMENT ANALYSIS

3.1 Crawling

At the beginning of the crawling process, the “Web

crawling” module creates a document data store

(“Raw document data” in Figure 1) containing the

raw data of the documents which will be analyzed by

the document analysis steps together with the details

about their source. In order to extract retrievable doc-

ument data we employ different type of crawlers:

• The Web Crawler handles HTTP and HTTPS, and

is used to crawl Internet, intranet and extranet

sites;

• The File Crawler handles local or remote ﬁle sys-

tems; It can retrieve local document data by crawl-

ing the local ﬁle system and the NFS and CIFS

mount points, and remote document data using the

following protocols: CIFS/SMB, FTP, FTPS.

The raw document data store contains, among the

others, the following ﬁelds for each of the documents:

Title, Content, URL, File Name, Meta Description,

Meta Keywords, Host name, Subdomain, Backlink

Count (i.e. number of incoming links). All of the

crawling operations are handled by the Open-source

AMBIT-SE: Towards a User-aware Semantic Enterprise Search Engine

Visited

URLs

Online&process (Document Re t rieval)

Query

Semantic query

processing

Offline&process (Document Analysis)

Semantic glossaries

computation and4

comparison

Normalization

1. <…>

2. <...>

...

1. <…>

2. <...>

...

Query

ranking

User4profile

ranking

1. <…>

2. <...>

...

Final

ranking

User

semantic glossary

Web

crawling

Home

URL(s)

Raw document

data

Websi te(s)4

semantic glossary

Figure 1: The main processes of the AMBIT-SE user-aware semantic enterprise search engine.

enterprise class search engine software, OpenSearch-

Server

3.2 Extraction, Language and

Paragraphs

In this further step the text contained within each doc-

ument needs to be extracted, an operation that can

vary greatly depending on the format of each doc-

ument; for instance, extracting text from an HTML

ﬁle implies excluding every tag, script and comment

within. Next, AMBIT-SE determines the language

of each ﬁle, because there are slight variations in

the workﬂow based on it. Then, the extracted con-

tent of each ﬁle is divided into paragraphs, and each

paragraph into lines of text; this will allow the ﬁnal

ranking to show not only which documents the user

is most interested in, but also which paragraphs and

lines within have affected this result the most. In par-

ticular, the system will show a text snippet of the high-

est rated paragraph when presenting a document to

the user.

All of these preliminary operations are taken

care of by components of the Open-source software

GATE

3.3 Tokenization, Stemming and Parts

of Speech

The next analysis step is tokenization, i.e. the process

of breaking the stream of text up into terms, phrases,

symbols, or other meaningful elements called to-

kens. In this case, it is performed by a language-

independent Java function that implements methods

for ﬁnding the location of boundaries in text, and then

http://www.opensearchserver.com/

https://gate.ac.uk/

splits it accordingly in order to divide it into single

terms and symbols.

The list of tokens becomes input for the stem-

ming, which is the process of determining the dic-

tionary form, called stem, for a given term. Stem-

ming is language-dependent; in AMBIT-SE we sup-

port 17 languages: English, German, Arabic, Chi-

nese, Danish, Spanish, Finnish, French, Dutch, Hun-

garian, Italian, Norwegian, Portuguese, Romanian,

Russian, Swedish, Turkish. Also, stopwords are re-

moved.

In addition, the tokens are subjected to POS tag-

ging, where each term is marked as corresponding to

a particular Part Of Speech. Simply put, the tagger

identiﬁes terms as nouns, verbs, adjectives, adverbs,

etc. Only the terms classiﬁed as nouns are considered

relevant, and will thus be preserved for the rest of the

procedure.

In this case, both stemming and POS tagging are

taken care of by TreeTagger

, a tool for annotating

text with part-of-speech and lemma information. To

make use of TreeTagger, the TT4J

(TreeTagger for

Java) Open-source wrapper is employed.

3.4 Term Weights

As in classic Information Retrieval (Baeza-Yates and

Ribeiro-Neto, 1999) the importance (weight) of each

term t in each document D of the document collection

D is estimated. We exploit tf-idf weighting, which is

the product of two statistics:

• TF: Term Frequency, which measures how fre-

quently a term occurs in a document. Since every

document D is different in length, it is possible

that a term t would appear much more times in

http://www.cis.uni-muenchen.de/

∼

schmid/tools/

TreeTagger/

https://reckart.github.io/tt4j/

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

100

long documents than in shorter ones. Thus, the

term frequency is divided by the document length

as a way of normalization:

tf(t, D) =

f(t, D)

len(D)

, (1)

where f(t, D) is the raw frequency of the term t

in the document D (number of times the term ap-

pears in the document), and len(D) is the total

number of terms in the document D;

• IDF: Inverse Document Frequency, which mea-

sures how important a term is. While comput-

ing TF, all terms are considered equally impor-

tant. However it is known that certain terms may

appear often but have little importance. Thus we

weigh down the frequent terms while scaling up

the rare ones, by computing the following:

idf(t, D) = log

|{D ∈ D : t ∈ D}|

, (2)

where N is the total number of unique documents

(among both the user’s and retrievable data col-

lections), and |{D ∈ D : t ∈ D}| is the number of

documents where the term t appears.

Then, tf-idf is calculated as:

tﬁdf(t, D,D ) = tf(t, D) · idf(t,D) (3)

3.5 Semantic Analysis and Thesauri

One of the main features of AMBIT-SE is the abil-

ity to exploit the semantics of the text, going be-

yond standard syntactical search engines. In partic-

ular, we want to extend the search to synonyms and

related terms of a given term. To handle this, we ex-

ploit WordNet

, a large lexical database where nouns,

verbs, adjectives and adverbs are grouped into sets

of cognitive synonyms (synsets), each expressing a

distinct concept. Synsets are interlinked by means

of conceptual-semantic and lexical relations, result-

ing in a network or meaningfully related words and

concepts. WordNet superﬁcially resembles a the-

saurus, in that it groups words together based on

their meanings. However, WordNet interlinks not just

word forms, but speciﬁc senses of words. Therefore,

AMBIT-SE ﬁrst performs Word Sense Disambigua-

tion (WSD) of the text.

Before discussing WSD, let us brieﬂy discuss the

structure of WordNet in order to explain how knowing

the synset(s) associated with a text will allow to easily

compute its synonyms and related terms. Synonyms

https://wordnet.princeton.edu/

Bookkeeping,

clerking

Acc oun ting,0

acc ountancy

Cost

acc ounting

Inventory

acc ounting

Single-entry

bookkeeping

Double-entry

bookkeeping

Hyponyms

Hypernym

Figure 2: Hypernym/hyponym hierarchy example.

are basically terms associated to the same synset; re-

lated terms are typically represented by their hyper-

nyms and hyponyms. In linguistics, a hyponym is a

term whose semantic ﬁeld is included within that of

another term, its hypernym. In simpler terms, a hy-

ponym shares a type of relationship with its hyper-

nym; on the other hand, a hyponym is a term whose

semantic ﬁeld is more speciﬁc than its hypernym. The

semantic ﬁeld of a hypernym, also known as a super-

ordinate, is broader than that of a hyponym. Figure 2

shows a small example: the terms “bookkeeping” and

“clerking” are synonyms, i.e. they belong to the same

synset. Terms “accounting” and “accountancy” con-

stitute their hypernym, while possible hyponyms are

“single-entry bookkeeping” and “double-entry book-

keeping”. By expliting this information, we will allow

users looking for “accounting” information to eas-

ily retrieve documents containing different but related

words like “bookkeeping”.

Please also note that, while the original WordNet

is strictly in English, our goal was to provide multilin-

gual semantic coverage. To this end, we also exploit

the custom WordNet versions available for the dif-

ferent languages that have been collected, extracted

and normalized in the Open Multilingual WordNet

project. In addition, we exploit the automatically ex-

tracted data from Wiktionary and the Unicode Com-

mon Locale Data Repository. This allows compar-

isons between different languages, as terms are repre-

sented by corresponding WordNet synset codes.

Getting back to WSD, to identify which sense of

word (i.e. meaning) is used in a sentence, the ex-

ploited algorithm evaluates the similarity between the

synsets a of each term to be disambiguated and the

synsets b of the other nearby terms. The (Leacock

and Chodorow, 1998) metric is used: this measure re-

lies on the length of the shortest path between two

synsets for their measure of similarity. We limit our

attention to hyponymy/hypernymy links and scale the

path length by the overall depth T of the taxonomy.

Path length similarity between synset a and synset

b is computed using the formula:

sim

= max

[−log (N

/2T )], (4)

http://compling.hss.ntu.edu.sg/omw/

AMBIT-SE: Towards a User-aware Semantic Enterprise Search Engine

101

Table 1: A small excerpt of semantic glossary (per-

document view).

!"#$%&'()

*&+%)

,-'.&(.)

(/)

0&123(4(/516/7)

OP0001%

bookkeeping%

00619230-n%

0.333%

0.135%

OP0005%

accounting%

00618734-n,%

13354985-n%%

1.098%

…%

where N

is the number of nodes in path p from a to

b, and T is the maximum depth of the taxonomy.

The result of the process is a disambiguation score

dis assigned to each synset code belonging to each

term: it is normalized between 0 and 1, and it rep-

resents the chances of that term having that sense in

that context. Only the synsets whose disambiguation

score exceeds a given threshold th

, i.e. dis > th

will be kept and stored as the result of the analysis.

3.6 Semantic Glossaries

The result of the analysis of the documents is stored

in a structure we call semantic glossary. In particu-

lar, the analysis of all the retrievable documents in the

collection is stored in the “Website(s) semantic glos-

sary”, while the analysis of the documents associated

with the user proﬁle (i.e. visited URLs, etc.) is stored

in the “User semantic glossary”; the two glossaries

share the same structure. Each glossary is composed

of two “views” which store:

• all the terms (and their synsets) in the documents

with their statistics (global view);

• the terms occurrences (and their synsets) in

each document with their statistics (per-document

view).

In particular, the glossary global view is an alpha-

betical sort of all the extracted terms, while the glos-

sary per-document view is a list of all the term oc-

currences in the documents, sorted by the document

ID, together with their statistics. A small excerpt of a

glossary per-document view is shown in Table 1: the

columns include the document ID (“Document”), the

contained term (“Term”), the WordNet synset code(s)

(“Synsets”) as derived from WSD, and the term fre-

quency (“tf”) and tf-idf weights as described in Sec-

tion 3.4.

As we will see in the next section devoted to doc-

ument retrieval, by means of the stored synset and

weight information, the content of the glossary allows

the similarity functions of AMBIT-SE to draw use-

ful knowledge from both the semantic (i.e. synonyms

and related terms computation) and the text retrieval

ﬁelds.

4 DOCUMENT RETRIEVAL

The ﬁnal goal of the document retrieval process in

AMBIT-SE is to effectively answer a given query Q

submitted by a user U; to this end, it takes into ac-

count all the semantic and user proﬁle information

available in the semantic glossaries produced by the

analysis process and generates a ranking of the avail-

able documents.

The computation of the document ranking is based

on ad-hoc similarity metrics:

• the similarity between the main terms of the avail-

able documents and those speciﬁed in the query;

• the similarity between the documents’ terms and

those associated with the user proﬁle (e.g. past

navigated documents).

Both similarities are based on a general document

similarity formula which we will detail in the follow-

ing section; ﬁnally, in Section 4.2 we will analyze

some further aspects regarding AMBIT-SE query pro-

cessing.

4.1 Document Similarity Computation

Building on previous research on text retrieval for

speciﬁc subject areas as software engineering (Berga-

maschi et al., 2015; Martoglia, 2011), bibliographi-

cal (Beneventano et al., 2015) and user-centric data

(Martoglia, 2015), we deﬁne the following document

similarity formula:

DSim(D

) =

∑

∈D

T Sim(t

j(i)

) · w

· w

j(i)

(5)

where:

j(i)

= argmax

∈D

(T Sim(t

)),

= t f

· id f

j(i)

= t f

j(i)

· id f

j(i)

and T Sim is a term similarity formula (see follow-

ing) taking into account the semantic information ex-

tracted from the semantic glossary. Simply put, the

similarity DSim(D

) between two documents D

and D

is determined by summing the maximum term

similarity score T Sim(t

j(i)

) between each pair of

terms belonging to different documents, multiplied by

the tf-idf weights of both.

We now proceed to deﬁne T Sim(t

) between

two terms t

and t

. In our semantic framework, t

and

can be:

• Synonyms, i.e. t

SYN t

, if a common synset a

is stored in the semantic glossary for both terms,

i.e. ∃a ∈ t

∩t

(note that this case includes equal

terms);

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

102

• Related, i.e. t

REL t

, if the synset similarity

sim

between two synsets a ∈ t

and b ∈ t

(Eq. 4)

exceeds a given threshold th

, i.e. ∃a ∈ t

,b ∈

|sim

> th

;

• Unrelated, otherwise.

The corresponding term similarity scores are as-

signed as follows:

T Sim(t

) =











1, if t

SYN t

r, if t

REL t

0, otherwise

, (6)

where r is an arbitrary value between 0 and 1. Please

note that synonym and related term information can

be computed ofﬂine for all the documents in the col-

lection and in the user proﬁle.

By applying Eq. 5 to the query Q and to each re-

trievable document D

of the user proﬁle U, we ob-

tain a “query ranking” and a “user proﬁle ranking”,

respectively, of retrievable documents D

in the col-

lection. The two rankings are then normalized and

merged in a ﬁnal ranking taking into account both the

user’s request and preferences.

4.2 Further Query Processing Aspects

Besides the techniques and features described in de-

tail in the previous sections, AMBIT-SE also offers

administrators the following ways to customize query

processing and presentation of results:

• Text Snippets, showing a custom-sized highest

rated portion of each document in the presented

ranking, plus any amount of surrounding text nec-

essary to reach the desired size; also, the tag used

to highlight words in results listings is parametra-

ble;

• Boosting Subqueries, to tweak the relevance score

of documents. For instance, a website administra-

tor could specify certain group of words, i.e. those

describing a new product, whose weight will be

promoted when found in both the user query and

a given retrievable document. The subqueries can

both bolster or lower a document’s score;

• Autocomplete, offering the most relevant sugges-

tions to the user on the basis of the semantic glos-

sary terms.

5 EXPERIMENTAL EVALUATION

This section illustrates and analyzes the results of sev-

eral tests performed on different kinds of websites.

Precision

Recall

Interp.2precision

Recall

Figure 3: Effects of interpolated precision on the P-R curve.

Since the description of the underlying index struc-

tures supporting semantic search is outside of the

scope of this paper, we will focus on effectiveness

analysis; anyway, please note that the current proto-

type has a response time of 40 ms on average on a

standard single-node conﬁguration.

5.1 Ranked Evaluation Method

The measures used for evaluation are precision and

recall, turned into measures of ranked lists by com-

puting them for each top k set of results, obtaining

a precision-recall curve (Baeza-Yates and Ribeiro-

Neto, 1999).

In particular, we compute the interpolated preci-

sion as:

interp

(r) = max

≥r

P(r

) (7)

The interpolated precision at a certain recall level r is

deﬁned as the highest precision found for any recall

level r

≥ r (see Figure 3).

The rationale for interpolation is that the user is

willing to look at more records if both precision and

recall get better. The interpolated precision is mea-

sured at 11 recall levels of 0.0, 0.1, 0.2, ..., 1.0 (0, 10,

20, ..., 100 percent), then the arithmetic mean of the

obtained values is calculated (Bernardi, 2011).

5.2 Experimental Setting

Four heterogenous business-relevant websites were

selected for evaluation purposes; for each one of

them, an appropriate information need was estab-

lished by examining common searches performed in

the past.

• http://www.cobat.it/, a relatively small Italian

website that provides information and services for

disposing and recycling four problematic waste

categories: batteries and accumulators, tires, elec-

tric and electronic devices, and photovoltaic pan-

els. The established information need is to re-

trieve documents pertaining to the disposal of bat-

teries and accumulators.

AMBIT-SE: Towards a User-aware Semantic Enterprise Search Engine

103

Query&

Our&results!

Google!

Base&

Stem&

SynRels&

Stem&

Prof&

Stem&

Prof&

SynRels&

Stem&

HetProf&

Stem&

HetProf&

SynRels&

Q1&

0,54529!

0,53914!

0,55451!

0,63225!

0,80148!

0,56444!

0,75783!

0,53006!

Q2&

0,04242!

0,31009!

0,12454!

0,38424!

0,47474!

0,35351!

0,29737!

0,21818!

Q3&

0,32958!

0,32906!

0,48566!

0,43939!

0,80014!

0,45455!

0,73826!

0,39610!

Q4&

0,00000!

0,10909!

0,12542!

0,24242!

0,39882!

0,24242!

0,32553!

0,06061!

Q5&

0,08684!

0,08678!

0,13376!

0,38678!

0,46167!

0,34444!

0,24239!

0,08392!

Average&

0,20083!

0,27483!

0,28478!

0,41702!

0,58737!

0,39187!

0,47227!

0,25777!

!"!

!"#

!"$

!"%

!"&

!"'

!"(

!")

!"*

!"+

#"!

!"! !"# !"$ !"% !"& !"' !"( !") !"* !"+ #"!

Pre cision

Recall

,-./ 01/2 01/23430567/8.

01/23439:; <3430567/8. 01/2343=/19:;<3430567/8. >;;?8/

Figure 4: Test results for http://www.cobat.it/.

• http://evergreensmallbusiness.com/, an English

Blog that publishes different kinds of information

and advice for small businesses, all classiﬁed in

categories such as business taxes, management,

personal ﬁnance, etc. The established information

need is to retrieve articles pertaining to bookkeep-

ing.

• http://truegoods.com/, an English Indie online

shop that specializes on healthy and natural prod-

ucts. The established information need is to re-

trieve information on products belonging to the

pet-care category.

• http://www.gruppozatti.it/, an Italian authorized

car dealer which sells several brands of both new

and used cars. The established information need

is to retrieve different information about cars be-

longing to the used category.

For each information need, several plausible

queries were submitted to the system (we selected ﬁve

representative ones for this evaluation). We employ

different setups in order to evaluate the impact of the

different features of AMBIT-SE, as described below:

• Base: baseline setting, i.e. simple syntactical

search for exact keywords;

• Stem: Stemming and stopword removal are per-

formed;

• SynRels: Synonyms and related terms are also

taken into account, both for the query and when

processing the user proﬁle documents, if present;

• Prof: a User Proﬁle containing only documents

Query&

Our&results!

Google!

Base&

Stem&

SynRels&

Stem&

Prof&

Stem&

Prof&

SynRels&

Stem&

HetProf&

Stem&

HetProf&

SynRels&

Q1&

0,28400!

0,28003!

0,37134!

0,53033!

0,56539!

0,47710!

0,51782!

0,51363!

Q2&

0,00000!

0,11039!

0,32255!

0,06818!

0,49271!

0,07025!

0,38474!

0,09091!

Q3&

0,36519!

0,41652!

0,37863!

0,45101!

0,50202!

0,40363!

0,45740!

0,45990!

Q4&

0,09091!

0,35949!

0,09091!

0,55438!

0,09091!

0,42646!

0,15909!

Q5&

0,00000!

0,01653!

0,27722!

0,06061!

0,41804!

0,02597!

0,36979!

0,00000!

Average&

0,14802!

0,18287!

0,34185!

0,24021!

0,50651!

0,21357!

0,45124!

0,24471!

!"!

!"#

!"$

!"%

!"&

!"'

!"(

!")

!"*

!"+

#"!

!"! !"# !"$ !"% !"& !"' !"( !") !"* !"+ #"!

Pre cision

Recall

,-./ 01/2 01/23430567/8.

01/23439:; <3430567/8. 01/2343=/19:;<3430567/8. >;;?8/

Figure 5: Test results for http://evergreensmallbusiness.com/.

relevant to the information need is used to perform

searches;

• HetProf: a Heterogeneous User Proﬁle containing

documents relevant to the information need and

an equal number of irrelevant documents is used

to perform searches;

• Google: queries are run through the Google

search engine restricted to the considered docu-

ment set, for reference.

Please note that the ﬁrst baseline is also represen-

tative of the document retrieval techniques commonly

exploited by most commercial systems (see also re-

lated works).

5.3 Test Results

Figures 4 to 7 show a table containing the eleven-

point interpolated average precision values of all the

query results, and the corresponding average P-R

curve, for each of the considered websites.

Let us start by analyzing the http://www.cobat.it/

results (Figure 4). As expected, Google results fall be-

tween our Base and Stem setups, because Google pro-

grammatically establishes whether to use stemming

or not on a document by document basis: in this in-

stance, unconditional stemming was more effective.

Synonyms and related terms didn’t have a big effect

on their own, especially for Q1 and Q2, because they

already yielded very good results without, so the ad-

ditional records retrieved actually lowered precision

and thus decreased the score for the second query.

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

104

Query&

Our&results!

Google!

Base&

Stem&

SynRels&

Stem&

Prof&

Stem&

Prof&

SynRels&

Stem&

HetProf&

Stem&

HetProf&

SynRels&

Q1&

0,04849!

0,02857!

0,29184!

0,54697!

0,60435!

0,53496!

0,59215!

0,27273!

Q2&

0,08089!

0,21579!

0,26412!

0,62044!

0,71850!

0,61004!

0,76318!

0,18182!

Q3&

0,00000!

0,13943!

0,00000!

0,46807!

0,00000!

0,42199!

0,00000!

Q4&

0,00000!

0,39532!

0,33033!

0,67354!

0,49408!

0,66602!

0,49147!

0,00000!

Q5&

0,00000!

0,04206!

0,00000!

0,52799!

0,00000!

0,52095!

0,00000!

Average&

0,02588!

0,12794!

0,21355!

0,36819!

0,56260!

0,36221!

0,55795!

0,09091!

!"!

!"#

!"$

!"%

!"&

!"'

!"(

!")

!"*

!"+

#"!

!"! !"# !"$ !"% !"& !"' !"( !") !"* !"+ #"!

Pre cision

Recall

,-./ 01/2 01/23430567/8.

01/23439:; <3430567/8. 01/2343=/19:;<3430567/8. >;;?8/

Figure 6: Test results for http://truegoods.com/.

But on the other hand, they beneﬁted Prof and Het-

Prof setups greatly, because of the large number of

keywords contained within the documents associated

to the user proﬁles: for instance, the use of semantics

allowed to match different but very related terms like

“battery” and “accumulator”, a match that would go

unnoticed in a syntactic search.

Going to the second website (Figure 5), Google

obtained better results than both our Base and Stem

setups, especially because of the greater precision

achieved in Q1 and Q3; but the use of synonyms

and related terms made up for it with much better

results in Q2, Q4 and Q5, by exploiting a number

of terms correlations such as between “money” and

“bookkeeping”. Indeed, Q1 and Q3 are simple one-

word queries that will ﬁnd matches in any of the rel-

evant documents, while Q2, Q4 and Q5 are longer

and less direct, and thus harder to satisfy for a search

engine without additional information in the form of

synonyms and related terms. This is also apparent by

taking a look at the results of the Prof and HetProf

setups, which greatly improve in their SynRels varia-

tion.

Looking at the graph in Figure 6, Google yielded

good results up to the 0,4 recall mark, where the curve

plummets to 0,0 precision, meaning most of the rel-

evant documents were not retrieved; this is proba-

bly due to indexing issues with this speciﬁc website.

Our results in this instance are a good example of

how computationally determined input, in the form of

word stems, synonyms, related terms and proﬁle doc-

uments, can turn an apparently impossible query into

a manageable one. Google and the Base setup could

Query&

Our&results!

Google!

Base&

Stem&

SynRels&

Stem&

Prof&

Stem&

Prof&

SynRels&

Stem&

HetProf&

Stem&

HetProf&

SynRels&

Q1&

0,92350!

0,91351!

0,91243!

0,90953!

0,89566!

0,88889!

0,46875!

Q2&

0,00000!

0,65483!

0,00000!

0,80483!

0,00000!

0,64045!

0,09869!

Q3&

0,00000!

0,01818!

Q4&

0,00000!

0,00817!

0,00000!

0,02893!

0,00000!

0,01035!

0,00000!

Q5&

0,00000!

0,92603!

0,82039!

0,92460!

0,84677!

0,91804!

0,80909!

0,00000!

Average&

0,18470!

0,36791!

0,47938!

0,36741!

0,51801!

0,36274!

0,46976!

0,11712!

!"!

!"#

!"$

!"%

!"&

!"'

!"(

!")

!"*

!"+

#"!

!"! !"# !"$ !"% !"& !"' !"( !") !"* !"+ #"!

Pre cision

Recall

,-./ 01/2 01/23430567/8.

01/23439:; <3430567/8. 01/2343=/19:;<3430567/8. >;;?8/

Figure 7: Test results for http://www.gruppozatti.it/.

not retrieve any records for Q3, Q4 and Q5, since they

don’t include terms that match exactly the ones found

in the relevant documents; the Stem setup made Q4

into a succesful query, and the SynRels setup did the

same for Q3 and Q5, especially in conjunction with

Prof and HetProf (among the exploited terms corre-

lations, the very frequent one between “pet” and “an-

imal”).

Our ﬁnal test (Figure 7) considers a site whose

pages contain very little text, thus providing a differ-

ent task w.r.t. the others. As in most cases, Google

delivered good results only for Q1, the easiest query.

Much like the previous websites, a lot of complex

queries did not yield satisfactory results for Google

or Base; instead, the Stem setup and the SynRels setup

provide a lot of beneﬁts for Q5 and Q2, while Q3 and

Q4 were apparently too difﬁcult even with the addi-

tional input. Anyway, we see that, on mean, the effect

of the semantics and of the user proﬁle is evident from

the results even in this speciﬁc setting.

6 RELATED WORK

In this section we report some work related to the

presented user-aware semantic enterprise search en-

gine. In Figure 8 we propose an analysis of the ex-

isting approaches (both academic and commercial),

classifying them on the base of two aspects: the user-

awareness and the semantics. As mentioned, most ap-

proaches do not consider together these aspects and/or

not strictly belonging to the enterprise search engine

AMBIT-SE: Towards a User-aware Semantic Enterprise Search Engine

105

User/Context Awareness

Semantic Analysis

Syntactic

Semantic

Non-aware

Aware

- Alfresco

- Solr

- …

User-aware

- AMBIT-SE

Context-aware:

- IBM Content Analytics

- Hyvonen et al., 2003

- Expert System

- Thesprasith and Jaruskulchai, 2014

- Haslhofer et al., 2013

- Carpineto and Romano, 2012

- Heflin and Hendler, 2000

Context aware:

- Coveo

- Falcarin et al., 2013

- Liu et al., 2004

- Cabri et al., 2003

Figure 8: A quadrant for user-aware semantic approaches.

category, so we will discuss related work in three sep-

arate subsections: semantic approaches, user-aware

approaches and enterprise search engines.

6.1 Semantic Approaches

A broad range of methods for semantic document

retrieval has been developed in the context of the

Semantic Web, as discussed in (Mangold, 2007), a

survey which covers approaches that exploit domain

knowledge to process search requests; the authors

present a large variety of domain knowledge utiliza-

tion that comprise automatic query expansion and

ontology-driven document retrieval.

The relative ineffectiveness of information re-

trieval systems is largely caused by the inaccuracy

with which a query formed by a few keywords

models the actual user information need; one well

known method to overcome this limitation is auto-

matic query expansion, whereby the user’s original

query is augmented by new features with a simi-

lar meaning (Carpineto and Romano, 2012). Differ-

ently from our approach, complex query expansion

techniques such as the ones discussed usually require

different parameters to be speciﬁed (as also stated

in (Abdou and Savoy, 2008)). Generally, there is no

single theory capable of ﬁnding the most appropriate

values (Abdou and Savoy, 2008) and therefore a long

process of manual tuning becomes necessary.

An increasing number of document retrieval sys-

tems make use of ontologies to help users clarify

their information needs and come up with semantic

representations of documents. In (Haslhofer et al.,

2013), a Simple Knowledge Organization System

(SKOS) based term expansion and scoring technique

that leverages labels and semantic relationships of

SKOS concept deﬁnitions is proposed.

Focusing on the necessity of manual intervention,

typical semantic retrieval techniques obtain good ef-

fectiveness levels only on manually annotated collec-

tions and/or with explicit user intervention. In (Thes-

prasith and Jaruskulchai, 2014), a query expansion

technique works on MEDLINE documents which

have been manually assigned to controlled MeSH

(Medical Subject Headings) vocabularies. The ad-

vanced indexing and retrieval method we propose for

AMBIT-SE, instead, exploits the semantics of the text

while remaining completely automatic.

6.2 User-aware Approaches

Several works in the literature have highlighted the

beneﬁts of managing context information and/or pro-

posed techniques and applications exploiting context-

awareness capabilities (Bolchini et al., 2011; Liu

et al., 2004; Cabri et al., 2003). In particular, a few

works are directed towards context modeling, repre-

sentation, and effective handling. For instance, (Bol-

chini et al., 2011) proposes to design a context man-

agement system which is not application-dependent,

while (Villegas and Mller, 2010) reports the result of

a study on various context modeling and management

approaches. (Liu et al., 2004) proposes a method to

derive a user proﬁle based on the search history and

on pre-determined category hierarchies. On the other

hand, standard search engines such as Google typi-

cally provide only very simple IP-address based lo-

calization of search results. Most of these approaches,

including the ones discussed above in the literature,

primarily focus on speciﬁc aspects such as external

user information or location, do not consider the se-

mantics of the context and/or rely on manual work in

order to classify and categorize users and documents.

6.3 Enterprise Search Engines

There is certainly a vast offer of enterprise search en-

gines on the market and in the literature.

The great majority of products does not exhibit

a strong focus on ontology-based semantic analysis,

relying instead on syntactic and hand-coded rules.

Some examples include Alfresco

, Solr

There are, of course, exceptions to this rule, such

as: the SHOE project (Heﬂin and Hendler, 2000),

which requires a domain-ontology where document

types correspond to ontology concepts; Expert Sys-

tem’s Cogito

, which provides automated disam-

biguation, classiﬁcation, entity extraction, and meta-

http://www.alfresco.com/

http://lucene.apache.org/solr/

http://www.expertsystem.com/it/cogito/

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

106

data. However, these systems have no notion of user

context. The same can’t be said for Coveo

, a tool

speciﬁcally oriented to exploit contextual knowledge

for dealing with information related to customers and

agents. No semantic information, however, is ex-

ploited.

On the other hand, there also a small number of

systems which exploit, even if in a sometimes lim-

ited way, semantic and context information. The On-

togator system (Hyvonen et al., 2003), which is part

of an image management and retrieval system, pro-

vides an interactive recommendation system which

allows the user to browse images based on ontolog-

ical properties. To exploit user contexts, it introduces

views to the ontology that rely on different concept

hierarchies, called “facets”. Each view represents a

speciﬁc information-need. IBM’s Content Analytics

with Enterprise Search

exploits a framework called

Unstructured Information Management Architecture

(UIMA), in order to build analytic applications and to

ﬁnd meanings, relationships and relevant facts hidden

in unstructured text. Context information is provided

by means of manual annotations. These approaches

require manual intervention on the documents and/or

adopt a still limited notion of context, i.e. they do not

exploit all of the data potentially available on the user,

such as the contents of any web page visited, attach-

ment downloaded, etc.

7 CONCLUSIONS

In this paper we have presented AMBIT-SE, a se-

mantic enterprise search engine that takes advan-

tage of user-awareness. To this purpose, the en-

gine exploits textual information (coming from sev-

eral sources) about the user, and builds a User se-

mantic glossary, which is exploited to enable effec-

tive user-aware searches on the retrievable informa-

tion, stored in the Website semantic glossary. We have

tested it with different real websites; the results show

that our combined exploitation of synonyms, related

terms and user information leads to very good per-

formance, much better than standard syntactic (enter-

prise) search engines.

With regard to future work, we aim at further op-

timizing the employed similarity metrics and testing

our approach with a wider range of websites. Indeed,

the reported experiments consider a good number of

cases with different features, but more tests can be

useful to further conﬁrm the validity of our approach.

http://www.coveo.com/

https://www.ibm.com/

ACKNOWLEDGEMENTS

This work was supported by the project “Algo-

rithms and Models for Building context-dependent

Information delivery Tools” (AMBIT) co-funded by

Fondazione Cassa di Risparmio di Modena (SIME

2013.0660).

REFERENCES

Abdou, S. and Savoy, J. (2008). Searching in medline:

Query expansion and manual indexing evaluation. Inf.

Process. Manage., 44(2):781–789.

Baeza-Yates, R. A. and Ribeiro-Neto, B. (1999). Mod-

ern Information Retrieval. Addison-Wesley Longman

Publishing Co., Inc., Boston, MA, USA.

Beneventano, D., Bergamaschi, S., and Martoglia, R.

(2015). Exploiting semantics for searching agricul-

tural bibliographic data. Journal of Information Sci-

ence.

Bergamaschi, S., Martoglia, R., and Sorrentino, S. (2015).

Exploiting semantics for ﬁltering and searching

knowledge in a software development context. Knowl-

edge and Information Systems, 45(2):295–318.

Bernardi, R. (2011). Digital libraries: Ranked evaluation.

Bolchini, C., Orsi, G., Quintarelli, E., Schreiber, F. A.,

and Tanca, L. (2011). Context modeling and con-

text awareness: steps forward in the context-addict

project. Bulletin of the Technical Committee on Data

Engineering, 34:47–54.

Cabri, G., Leonardi, L., Mamei, M., and Zambonelli,

F. (2003). Location-dependent Services for Mo-

bile Users. IEEE Transactions on Systems, Man,

and Cybernetics-Part A: Systems And Humans,

33(6):667–681.

Carpineto, C. and Romano, G. (2012). A survey of auto-

matic query expansion in information retrieval. ACM

Comput. Surv., 44(1):1:1–1:50.

Haslhofer, B., Martins, F., and Magalh

aes, J. a. (2013).

Using skos vocabularies for improving web search.

In Proceedings of the 22Nd International Conference

on World Wide Web, WWW ’13 Companion, pages

1253–1258.

Heﬂin, J. and Hendler, J. (2000). Searching the web with

shoe. In Artiﬁcial Intelligence for Web Search. Papers

from the AAAI Workshop.

Hyvonen, E., Saarela, S., and Viljanen, K. (2003). Ontoga-

tor: combining view- and ontology-based search with

semantic browsing. In Proceedings of XML Finland.

Leacock, C. and Chodorow, M. (1998). Combining local

context and wordnet similarity for word sense identi-

ﬁcation. In WordNet: An electronic lexical database.

Liu, F., Yu, C., and Meng, W. (2004). Personalized web

search for improving retrieval effectiveness. IEEE

Trans. on Knowl. and Data Eng., 16(1):28–40.

Mangold, C. (2007). A survey and classiﬁcation of semantic

search approaches. In Semantics and Ontology.

AMBIT-SE: Towards a User-aware Semantic Enterprise Search Engine

107

Martoglia, R. (2011). Facilitate IT-Providing SMEs in Soft-

ware Development: a Semantic Helper for Filtering

and Searching Knowledge. In SEKE, pages 130–136.

Martoglia, R. (2015). Ambit: Semantic engine foundations

for knowledge management in context-dependent ap-

plications. In SEKE, pages 146–151.

Thesprasith, O. and Jaruskulchai, C. (2014). Query ex-

pansion using medical subject headings terms in the

biomedical documents. In Intelligent Information and

Database Systems - 6th Asian Conference, ACIIDS

2014, Bangkok, Thailand, April 7-9, 2014, Proceed-

ings, Part I, pages 93–102.

Villegas, N. M. and Mller, H. A. (2010). Managing dy-

namic context to optimize smart interactions and ser-

vices. In Chignell, M., Cordy, J., Ng, J., and Yesha, Y.,

editors, The Smart Internet, volume 6400 of Lecture

Notes in Computer Science, pages 289–318. Springer

Berlin Heidelberg.

Xiang, B., Jiang, D., Pei, J., Sun, X., Chen, E., and Li, H.

(2010). Context-aware ranking in web search. In Pro-

ceedings of the 33rd International ACM SIGIR Con-

ference on Research and Development in Information

Retrieval, SIGIR ’10, pages 451–458.

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

108
