Subtopic Ranking based on Hierarchical Headings

Tomohiro Manabe

∗

and Keishi Tajima

Graduate School of Informatics, Kyoto University, Sakyo, Kyoto 606-8501, Japan

Keywords:

Subtopic Mining, Hierarchical Heading Structure, Web Search, Search Result Diversiﬁcation, Search Intent.

Abstract:

We propose methods for generating diversiﬁed rankings of subtopics of keyword queries. Our methods are

characterized by their awareness of hierarchical heading structure in documents. The structure consists of

nested logical blocks with headings. Each heading concisely describes the topic of its corresponding block.

Therefore, hierarchical headings in documents reﬂect the hierarchical topics referred to in the documents.

Based on this idea, our methods score subtopic candidates based on matching between them and hierarchical

headings in documents. They give higher scores to candidates matching hierarchical headings associated to

more contents. To diversify the resulting rankings, every time our methods adopt a candidate with the best

score, our methods exclude the blocks matching the candidate and re-score all remaining blocks and candi-

dates. According to our evaluation result based on the NTCIR data set, our methods generated signiﬁcantly

better subtopic rankings than query completion results by major commercial search engines.

1 INTRODUCTION

Web search queries are sometimes ambiguous and/or

referring to broad topics. To generate effective web

page rankings for such queries, search result diver-

siﬁcation techniques have been developed. Subtopic

mining is one of the most promising approaches to

search result diversiﬁcation. Diversiﬁcation meth-

ods based on subtopic mining ﬁrst extract subtopic

candidates of queries, then score and rank the can-

didates by their importance and their diversity from

the others, and ﬁnally returns a few pages for each

of the highly-ranked subtopic candidates. Because of

the importance of subtopic mining, competitions for

subtopic mining methods have been held as the NT-

CIR INTENT/IMine tasks subtopic mining subtasks

(Liu et al., 2014; Sakai et al., 2013; Song et al., 2011).

In general, documents contain hierarchical head-

ing structure reﬂecting their topic structure. Hierar-

chical headings structure consists of nested logical

blocks and each block has its heading. A heading

describes the topic of its associated block and the hi-

erarchical descendant blocks of the block. Because

of this feature of heading, hierarchical headings in

documents reﬂect topic structure of the documents.

For example, Figure 1 shows an example web page

about computer programming (one of the NTCIR top-

∗

Research Fellow of Japan Society for the Promotion of

Science

ics) containing hierarchical heading structure. In this

ﬁgure, each rectangle encloses a block and each em-

phasized text is a heading. The hierarchical headings

in this page reﬂect its topic structure. For example,

its ﬁrst level topic is computer programming, second

level topics are computer programming schools and

jobs, and the third level topics are computer program-

ming school courses and degrees. Hierarchical head-

ing structure of web pages are not obvious in general,

but we have recently developed a method for extract-

ing it (Manabe and Tajima, 2015).

In this paper, we propose methods to score hier-

archical blocks in documents then rank subtopic can-

didates based on the scores of corresponding blocks.

To the best of our knowledge, this is the ﬁrst paper

which discusses the use of detailed hierarchical head-

ing structure of web pages in subtopic mining. Our

basic idea is that more contents about a topic sug-

gests more importance of the topic. Our methods

score blocks based on the quantity of their contents,

then approximate the importance of a subtopic can-

didate by the summation of the scores of the blocks

in a corpus whose hierarchical headings describe the

candidate subtopic. To diversify resulting rankings,

our methods adopt a subtopic with the best score one-

by-one, and every time a subtopic is adopted, our

methods re-score all remaining blocks with remov-

ing blocks matching with subtopics that have been

already adopted. By this approach, the candidates

Manabe, T. and Tajima, K.

Subtopic Ranking based on Hierarchical Headings.

In Proceedings of the 12th International Conference on Web Information Systems and Technologies (WEBIST 2016) - Volume 2, pages 121-130

ISBN: 978-989-758-186-1

121

Computer programming.

All about computer programming skills.

Schools

Top schools for computer programming are ...

Courses

Speciﬁcally, the most famous courses are ...

Degrees

Some schools award degrees, e.g., ...

Jobs

Programming skills are required for jobs like ...

Figure 1: Example web page with hierarchical heading

structure. Each rectangle encloses block and each empha-

sized text is heading. Some long texts are replaced by dots.

matching with the blocks which also match with the

already-adopted subtopics lose their scores, and re-

sulting subtopic rankings get diversiﬁed.

The remainder of this paper is organized as fol-

lows. In the next section, we clarify our research tar-

gets. After that, we concisely survey related work.

We then explain our methods in Section 4. In Sec-

tion 5, we evaluate our methods on the publicly avail-

able NTCIR data set and compare the results with the

baselines generated by commercial web search en-

gines. Lastly, Section 6 concludes this paper.

2 DEFINITIONS

In this section, we clarify the deﬁnitions of our re-

search targets, namely subtopics of keyword queries

and hierarchical heading structure in documents.

2.1 Deﬁnition of Subtopics

We focus on subtopics explicitly represented by

subtopic strings deﬁned in the NTCIR-10 INTENT-

2 task as quoted below (Sakai et al., 2013).

A subtopic string of a given query is a

query that specializes and/or disambiguates

the search intent of the original query. If a

string returned in response to the query does

neither, it is considered incorrect.

As deﬁned above, each subtopic is associated to the

topic behind an original query. In INTENT-2 and in

this paper, a query means a keyword query composed

of an array of words.

The overview paper of the task in NTCIR-10 lists

some example subtopic strings (Sakai et al., 2013).

If the original query is “harry potter”, “harry potter

philosophers stone movie” is a true subtopic string

that specializes the original query. On the other hand,

“harry potter hp” is not a subtopic string because

it neither specializes nor disambiguates the original

query. If the original query is “ofﬁce”, “ofﬁce work-

place” is a subtopic string that disambiguates the orig-

inal query, but “ofﬁce ofﬁce” is not. Note that true

subtopic strings may not include the original queries.

For example, “aliens vs predators” is a true subtopic

string of the original query “avp”.

2.2 Deﬁnition of Heading Structure

For ranking of subtopics, we use hierarchical heading

structure of documents. We deﬁne the structure and

its components as summarized below (Manabe and

Tajima, 2015).

Heading: A heading is a highly summarized descrip-

tion of the topic of a part of a document.

Block: As explained above, a heading is associated

with a block, a clearly speciﬁed part of a document.

We consider neither a block that consists only of its

heading nor a block without its heading. An entire

document is also a block because it is clearly speciﬁed

and we can regard its title or URL as its heading.

Hierarchical Heading Structure: A block may con-

tain another block entirely, but two blocks never par-

tially overlap. All blocks in a document form a hier-

archical heading structure whose root is the root block

representing the entire document.

3 RELATED WORK

Generally, a term topic has two meanings in informat-

ics (He et al., 2012). One is an implicit topic repre-

sented by a (fuzzy) set of terms (Jiang and Ng, 2013;

Hu et al., 2012), and the other is an explicit topic

represented by a short string like a keyword query.

Our research target is explicit topics. In particular, we

focus on subtopics of the topics behind the keyword

queries input by users. For mining such subtopics, we

need four component technologies. They are namely

subtopic candidate extraction, extraction of their fea-

tures, and subtopic ranking and diversiﬁcation based

on the features. We survey related work on these tech-

nologies in this order.

3.1 Subtopic Candidate Extraction

This step is not the topic of this paper. However, we

brieﬂy survey related work on this step for reference.

Query recommendation/suggestion/completion

by search engines generates many related queries of

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

122

the original queries. They are very popular resources

of subtopic candidate strings (Luo et al., 2014;

Yu and Ren, 2014; Ullah et al., 2013; Xue et al.,

2013; Ullah and Aono, 2014; Wang et al., 2013b;

Xia et al., 2013), and the snapshots of them for the

NTCIR-10 INTENT-2 task (Sakai et al., 2013) is

publicly available. We also adopted them as baseline

subtopics. Google Insights and Google keywords

generator are similar services (Xue et al., 2013).

Raw query logs of search engines (Luo et al., 2014;

Bouchoucha et al., 2014; Ullah et al., 2013; Wang

et al., 2013b; Xia et al., 2013) must also be useful.

Disambiguation pages in Wikipedia contain mul-

tiple subtopics of many ambiguous article titles of

Wikipedia, and are very well-organized by humans.

Therefore, they are also a very popular resource of

subtopic candidate strings (Wang et al., 2013b; Xia

et al., 2013; Luo et al., 2014; Yu and Ren, 2014; Xue

et al., 2013; Wang et al., 2013b; Xia et al., 2013).

Redirect pages and tables of contents in Wikipedia

must also be useful (Xia et al., 2013).

Of course, search result documents themselves

can be a resource of subtopic candidate strings. Meth-

ods based on frequently occurring words (Yamamoto

et al., 2014; Oyama and Tanaka, 2004; Wang et al.,

2013b; Wang et al., 2013a; Zheng et al., 2012;

Zheng et al., 2011), words frequently co-occurring

with query keywords (Wang et al., 2013d), pseudo-

relevance feedback (Bouchoucha et al., 2014), syntac-

tic patterns (Kim and Lee, 2015), search result sum-

maries (Xue et al., 2013) have been proposed.

Titles (Oyama and Tanaka, 2004; Yamamoto

et al., 2014), anchor texts of in-links (Xue et al., 2013;

He et al., 2012), and explicitly tagged top-level head-

ings (H1 nodes) of HTML documents (Xue et al.,

2013) all describe the topics of the entire documents.

Therefore, they may be important as subtopic candi-

date strings. Their idea is similar to ours, but they do

not use detailed hierarchical heading structure. In ad-

dition, we use it for ranking candidate subtopic strings

in this paper, not for extracting the candidates.

The QDMiner system extracts query dimensions

each of which refers to one important aspect of the

original query (Dou et al., 2011). The system is based

on list extraction from web pages. Their idea of query

dimension is highly relevant to the idea of subtopic,

and therefore some existing methods extract them as

components of subtopic candidate strings (Bah et al.,

2014; Ullah et al., 2013).

3.2 Subtopic Feature Extraction

Similarly to most existing document ranking meth-

ods, many existing methods of subtopic feature ex-

traction are based on term frequency (TF) and/or doc-

ument frequency (DF) of subtopic strings or their

component terms (Kim and Lee, 2015; Yamamoto

et al., 2014; Wang et al., 2013d; Zheng et al., 2012;

Das et al., 2012). TF means the number of its oc-

currences in a document, and DF means the number

of documents that contain it. The occurrences in some

types of document metadata, e.g., document titles, an-

chor text of in-links, and top-level headings, are more

important than other occurrences (Yamamoto et al.,

2014; Xue et al., 2013).

Similarity between subtopic candidate strings and

their search result documents or their original queries

is a popular feature (Luo et al., 2014; Moreno and

Dias, 2014; Zheng et al., 2012; Das et al., 2012).

The document coverage of a subtopic candidate

string is the weighted summation of the scores of doc-

uments that both the string and its original query re-

trieved (Kim and Lee, 2015), and the distinctness en-

tropy of subtopic candidate strings measures the dis-

tinctness among the document sets that the strings re-

trieved (Zeng et al., 2004; Kim and Lee, 2015).

The SEM group at NTCIR-10 used the co-

occurrence of subtopic candidate strings in query logs

and the edit distance between the strings and their

original queries (Ullah et al., 2013).

Query-independent features like readability of

subtopic candidate strings are also useful (Ullah et al.,

2013; Wang et al., 2013d).

3.3 Subtopic Ranking

Subtopic ranking is indispensable for ﬁltering out

noises and for ranking subtopic strings by the prob-

ability that they are the query intent. The simplest

way is to sort them in order of linear combination of

features. However, as in document ranking, more so-

phisticated functions, e.g., TFIDF (TF over DF) and

BM25 (Robertson and Walker, 1994), are also used

(Kim and Lee, 2015; Wang et al., 2013d; Wang et al.,

2013b; Ullah et al., 2013).

Many methods assign different weights for differ-

ent sources of subtopic candidate strings (Luo et al.,

2014; Xue et al., 2013). For example, the THUIR

group at NTCIR-11 assigned the weights of 0.75 for

Google keywords generator, 0.15 for Google insights,

and 0.05 for query completion/suggestion by com-

mercial search engines (Xue et al., 2013).

Ullah and Aono proposed a method that represents

each subtopic candidate string by its feature vector

then score them by their cosine similarity with the

mean vector (Ullah and Aono, 2014).

It is notable that the THUSAM group at NTCIR-

12 adopted a variant of learning-to-rank methods that

Subtopic Ranking based on Hierarchical Headings

123

are state-of-the-arts methods for document ranking

(Luo et al., 2014).

3.4 Subtopic Diversiﬁcation

One important application of subtopic mining meth-

ods is search result diversiﬁcation. Therefore, diver-

sity of subtopic rankings is also important.

One promising way to diversify subtopic rankings

is subtopic clustering and extraction of the median

subtopics of each cluster (Yamamoto et al., 2014; Yu

and Ren, 2014; Xue et al., 2013; Wang et al., 2013b;

Wang et al., 2013a; Xia et al., 2013). The K-means

(Yamamoto et al., 2014), afﬁnity propagation (Yu and

Ren, 2014; Xia et al., 2013), a variant of K-medoids

(Xue et al., 2013) algorithms are used.

The THCIB group at NTCIR-10 clustered implicit

topics by the afﬁnity propagation algorithm, then as-

signed explicit topics to each cluster by Latent Dirich-

let Allocation (Wang et al., 2013c).

The Hierarchical InfoSimba-based Global K-

means (HISGK-means) algorithm clusters search re-

sult snippets then labels each cluster (Moreno and

Dias, 2013; Dias et al., 2011). The InfoSimba is a

similarity measure between snippets based on term

co-occurrence, and HISGK-means recursively clus-

ters snippets based on the measure and Global K-

means. Each label is obtained as the centroid of a

cluster.

Recently, some methods adopted word embedding

models (Luo et al., 2014; Moreno and Dias, 2014).

In word embedding models, we can subtract subtopic

candidate strings from their original query. Based on

this idea, the HULTECH group at NTCIR-11 recur-

sively subtracted subtopic candidate strings from their

original query then compared the difference and the

remaining subtopic candidate strings every time they

adopt the subtopic candidate string with the best score

(Moreno and Dias, 2014).

The maximal marginal relevance (MMR) frame-

work also concatenate items into rankings one-by-one

(Carbonell and Goldstein, 1998). In each iteration,

the MMR framework selects the item with the best

balance of the score and dissimilarity to the already

ranked items. Of course, it is useful for subtopic di-

versiﬁcation (Ullah and Aono, 2014).

As explained above, no existing method scores

or diversiﬁes subtopic candidate strings based on de-

tailed logical hierarchical structure in documents, e.g.

hierarchical heading structure, as in our method.

4 SUBTOPIC RANKING BASED

ON HIERARCHICAL HEADING

STRUCTURE

In this section, we propose scoring and ranking meth-

ods for subtopic strings. Our proposed methods are

based on matching between the subtopic strings and

hierarchical heading structure of documents in a cor-

pus. We regard that a subtopic string matches a block

iff all the words in the subtopic string appear either in

the heading of the block or in the headings of its an-

cestor blocks. For example, a subtopic string “com-

puter programming degrees” matches the “degrees”

block in Figure 1. If a subtopic string matches a

block, the block must refer to the subtopic accord-

ing to the deﬁnition of hierarchical heading structure.

Because of this deﬁnition of matching, if a subtopic

string matches a block, the string must also match

the hierarchical descendant blocks of the block. How-

ever, we do not consider such matching of hierarchi-

cal descendants of already matched blocks. Instead,

we score each block considering its hierarchical de-

scendants. Formally, the score of a pair of a subtopic

string s and a document d is:

docScore(s,d) =

∑

b in d

match(s,b)blockScore(b)

where b is each block in d, match(s,b) is 1 iff s

matches b and does not match any ancestor block of

b and is 0 otherwise. blockScore(b) is the score of b.

Hereafter in this section, we ﬁrst discuss the def-

inition of blockScore(b), then discuss integration of

subtopic scores on multiple documents, and ﬁnally

discuss ranking of multiple subtopics into a diversi-

ﬁed ranking.

4.1 Subtopic Scoring on a Single Page

First, we propose four scoring methods for blocks.

4.1.1 Scoring by Content Length

Basically, the more description about a subtopic a

document contains, the more important the subtopic

is for the author of the document. Furthermore, be-

cause the author writes the document for readers, the

importance of the subtopic for readers (and search en-

gine users) is also reﬂected by the length of the con-

tent. Based on this idea, we can score blocks by the

lengths of their contents. The score of a block b is:

blockScore(b) = length(b)

where length(b) is the length of b. We call this length

scoring. For example, if we score the blocks in Fig-

ure 1 by this, we obtain the result shown in Figure 2a.

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

124

Computer programming.

(60 + 2500 + 440 = 3000)

Schools (500 + 1600 + 400 = 2500)

Courses (1600)

Degrees (400)

Jobs (440)

(a) Length scoring.

Computer programming.

(log3000 ∼ 3.477)

Schools (log2500 ∼ 3.398)

Courses (log1600 ∼ 3.204)

Degrees (log400 ∼ 2.602)

Jobs (log440 ∼ 2.643)

(b) Log-scale scoring.

Computer programming.

(1 + 3 + 1 = 5)

Schools (1 + 1 + 1 = 3)

Courses (1)

Degrees (1)

Jobs (1)

Computer programming. (1)

Schools (1/3)

Courses (1/9)

Degrees (1/9)

Jobs (1/3)

(d) Top-down scoring.

Figure 2: Comparison of scoring results of page in Figure 1

by four scoring methods. Scores of blocks are in parenthe-

ses. Non-heading components of blocks are omitted.

In Figure 2, the scores of the blocks are in parentheses

and non-heading components of the blocks are omit-

ted.

4.1.2 Scoring by Log-Scaled Content Length

As the relevance of a document to a query is assumed

not to be direct proportional to the number of query

keyword occurrences in the document (Robertson and

Walker, 1994), the importance of a topic may also

be not direct proportional to the content length of

the block referring to the topic. Based on this idea,

we propose another scoring function with logarithmic

scaling:

blockScore(b) = log(length(b) + 1) .

We call this log-scale scoring. An example result of

log-scale scoring is shown in Figure 2b.

4.1.3 Bottom-up Scoring

In practice, the importance of some topics are not re-

ﬂected by the content length of their matching blocks.

For example, telephone number may be an impor-

tant subtopic of a place, but blocks under the head-

ing “telephone number” should contain relatively less

contents, i.e., only the exact telephone number of the

place, than blocks under other headings. Logarithmic

scaling in the previous section reduces the effect of

content length, but we also consider a scoring func-

tion that completely ignores content lengths. If we

assume even importance for all blocks excluding their

child blocks, the score of a block b is formulated as

below:

blockScore(b) = 1 +

∑

c∈b

blockScore(c)

where c is each child block of b. We call this bottom-

up scoring. An example result of bottom-up scoring

is shown in Figure 2c.

4.1.4 Top-down Scoring

On the other hand, we can assume even importance

for all child blocks of a block. This assumption means

that child blocks of a block are used to segment its

topic into multiple subtopics of even importance. Be-

cause the original block may have meaningful con-

tents besides its child blocks, we also assign the same

importance to the contents. The score of a block b is:

blockScore(b) =











blockScore(p)

1+|p|

if b has a parent

block p

1 otherwise

where |p| is the number of the child blocks of p. We

call this top-down scoring. An example result of top-

down scoring is shown in Figure 2d.

4.2 Score Integration for Multiple Pages

Next, we explain four ways to integrate the scores of

a subtopic string on multiple documents.

4.2.1 Simple Summation

The simplest way to integrate the scores for multiple

pages is to sum them up. Such simple summation

Subtopic Ranking based on Hierarchical Headings

125

means that the importance of a subtopic string is re-

ﬂected by the length of contents (if we adopt length

scoring), the number of blocks (if we adopt bottom-

up scoring), and so on that refer to the subtopic in the

corpus. Formally, the score of a subtopic string s on a

corpus D is:

score(s,D) =

∑

d∈D

docScore(s,d) .

We call this method summation integration.

4.2.2 Page-based Integration

In summation integration, documents of more length

or including more blocks have more chance to con-

tribute to score(s,D). However, if we assume

each document is equally important, the scaling of

docScore(s,d) deﬁned below may be useful:

score(s,D) =

∑

d∈D

docScore(s,d)

blockScore(root(d))

where root(d) is the root block in d, i.e., the

block representing entire d. Because we score each

block considering its hierarchical descendant blocks,

blockScore(b) takes its maximum value in a doc-

ument when b is the root block of the document,

and docScore(s,d) takes its maximum value when s

matches the root block of d. Therefore, this division

by blockScore(root(d)) scales the docScore(s, d) to

[0,1]. We call this method page-based integration.

Note that there is no difference between summa-

tion and page-based integration when we use top-

down scoring because blockScore(b) in top-down

scoring is already scaled to [0,1].

4.2.3 Domain-based Integration

Some authors may split a topic into multiple docu-

ments in a domain, e.g., a set of web pages whose

URL have the same domain, instead of multiple

blocks. Considering such cases, domain-based scal-

ing may be more effective than page-based scaling.

To formulate such scaling, we introduce ∆, a set of

domains that appear in the corpus. Each domain δ ∈ ∆

is a subset of the corpus D, and

δ∈∆

δ = D. The new

integration function is:

score(s,D) =

∑

δ∈∆

∑

d∈δ

docScore(s,d)

∑

d∈δ

blockScore(root(d))

We call this method domain-based integration.

4.2.4 Combination Integration

If we apply both page-based and domain-based scal-

ing, the new integration function is:

score(s,D) =

∑

δ∈∆

|δ|

∑

d∈δ

docScore(s,d)

blockScore(root(d))

Computer programming.

(log500 ∼ 2.699)

Jobs (log440 ∼ 2.643)

Figure 3: Example re-scoring result of page in Figure 1 by

log-scale scoring after we rank ﬁrst subtopic string “com-

puter programming schools”.

We call this combination integration.

4.3 Diversifying Subtopic Ranking

To rank multiple subtopic strings into a ranking, we

can score each of them once, then simply sort the

strings by descending order of their scores. We call

this uniform ranking method.

However, because search result diversiﬁcation is

one of the most important applications of subtopic

ranking, diversity of subtopic ranking is also impor-

tant. Therefore, we also propose a diversiﬁcation

method of subtopic ranking. Our idea for diversiﬁ-

cation is that if a block matches a subtopic string that

is already ranked in the ranking, the topic of the block

is already referred to by the subtopic string, and there-

fore, even if the block matches some other remaining

subtopic strings, the block should not contribute to the

score of the subtopic strings.

Based on this idea, we propose a diversiﬁed rank-

ing method for subtopic strings based on hierarchical

heading structure. In this method, ﬁrst we score each

subtopic string on a document set then put only the

string with the best score into the resulting ranking.

Second, we remove all the blocks matching with the

string from the corpus. Third, we re-score the remain-

ing subtopic strings on the remaining blocks then put

the string with the best score into the resulting rank-

ing. The second and third steps are repeated until all

subtopic strings are ranked.

For example, suppose we have three subtopic

strings, “computer programming school”, “computer

programming course”, and “computer programming

jobs”. If we rank the strings by uniform ranking

method and the log-scale scores of the blocks in

Figure 2b, the ranks of the strings are in the order

above because the strings match the “Schools” (score:

3.398), “Courses” (score: 3.204), and “Jobs” (score:

2.643) blocks, respectively. On the other hand, if

we rank the strings by diversiﬁed ranking method,

“computer programming jobs” achieves the second

rank because after “computer programming school”

is ranked ﬁrst, its matching block “School” includ-

ing its descendant blocks is removed from the re-

calculation of the scores. Then the score of “computer

programming course” in this page becomes 0 because

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

126

the block referring to the subtopic in this page has al-

ready matched the higher ranked subtopic “computer

programming school”.

5 EVALUATION

In this section, we evaluate and compare the baselines

and our proposed methods.

We proposed four block scoring methods, four

score integration methods, and two subtopic ranking

methods. We can arbitrary combine these methods.

However, there is no difference between summation

and page-based integration and also between domain-

based and combination integration when we use top-

down scoring as discussed in Section 4.2.2. There-

fore, we compare 28 proposed methods in total.

5.1 Evaluation Methodology

Because we do not discuss extraction methods of

subtopic candidate strings, we evaluate our ranking

methods by re-ranking the baseline subtopic rankings.

We use the ofﬁcial data set (including baselines)

and evaluation measures of the NTCIR-10 INTENT-2

task subtopic mining subtask (Sakai et al., 2013). This

is because the dataset of the latest NTCIR-12 IMine-

2 task is not available yet, and because ﬁrst-level

and second-level subtopics are distinguished in the

second-latest NTCIR-11 IMine task while our pro-

posed methods do not distinguish them. All compo-

nents of the NTCIR-10 data set is publicly available

and most of them are on the web site of NII

In the subtopic mining subtask, participants are re-

quired to return ranked list of top-10 subtopic strings

for each query. Subtopic strings are expected to be

sorted in descending order of their intent probability,

i.e. the probability that search engine users submitting

the given query need information on the subtopics (or

intent). Multiple subtopic strings may refer to the

same intent, but a string refers to one intent at most.

Ofﬁcial evaluation measures of the subtask are in-

tent recall (I-rec), D-nDCG, and D]-nDCG.

The deﬁnition of the I-rec measure is:

iRec@10 = |I

|/|I|

where I is a set of known subtopics of the original

query, and I

is a set of subtopics represented by any

of the maximum 10 strings in a ranking to be evalu-

ated. This measure reﬂects the recall and diversity of

subtopics in rankings. The deﬁnition of the D-nDCG

http://www.nii.ac.jp/dsc/idr/en/ntcir/ntcir.html

measure for a ranking of maximum 10 strings is:

DnDCG@10 =

DDCG@10

ideal DDCG@10

where DDCG@10 =

∑

r=1

∑

Pr(i|q)g

(r)

log(r + 1)

where r is a rank, Pr(i|q) is the intent probability of

a subtopic i behind the original query q, and g

(r) is

1 iff the string at the rank r refers to the subtopic i,

and 0 otherwise. The D-nDCG measure reﬂects the

precision and accuracy of rankings.

The integrated measure D]-nDCG is the weighted

summation of I-rec and D-nDCG.

D]nDCG@10 = γiRec@10 + (1 − γ)DnDCG@10

where γ is the weight of I-rec which is ﬁxed to 0.5 in

this paper and the subtask. In other words, D]-nDCG

is arithmetic mean of I-rec and D-nDCG.

An ofﬁcial evaluation tool is available online

5.2 Data Set

The details of the data set is as follows.

Queries: We used 50 keyword queries in the NTCIR

data set that are also used in the Text Retrieval Con-

ference (TREC) 2012 Web track (Clarke et al., 2012).

Document Sets: We used the baseline document

rankings generated by default scoring of Indri search

engine (including query expansion based on pseudo-

relevance feedback) and Waterloo spam ﬁlter for

TREC 2012 Web track. The baseline rankings are

available online

. Each ranking consists of 131–

837 web pages from ClueWeb09B for a query. The

ClueWeb09B collection is one of the most well-

known snapshots of the web, contains 50 million web

pages, and is crawled by the Lemur Project in 2009.

The collection is also available at distribution cost

Baseline Results: There are the snapshots of query

completion/suggestion results by commercial search

engines prepared for the NTCIR-10 INTENT-2 task.

We used the query completion results by Google and

Yahoo because they achieved the best I-rec and D-

nDCG scores respectively among the baselines (Sakai

et al., 2013). Because the both results contain only

10 strings at most for each query, re-ranking of them

do not affect the I-rec scores. Therefore, we also

used our merged baseline result which is generated by

merging four baseline query completion/suggestion

results and sorting them in “dictionary sort” (Sakai

et al., 2013). Because the meaning of dictionary sort

http://research.nii.ac.jp/ntcir/tools/ntcireval-en.html

https://github.com/trec-web/trec-web-2014

http://www.lemurproject.org/clueweb09/

Subtopic Ranking based on Hierarchical Headings

127

is ambiguous, we could not reproduce their evalua-

tion result. We merged the results, decapitalized the

strings, removed duplicated strings, and sort the re-

maining strings in byte order in UTF-8 to generate

our merged baseline result.

Known Intents and Intent Probabilities: The

known intents, subtopic strings referring to them, and

their intent probabilities are manually prepared for the

subtask (Sakai et al., 2013). All the true subtopic

strings in the baseline results must be in this data ac-

cording to their annotation process.

5.3 Implementation Details

In this section, we explain the details of our imple-

mentation required to evaluate our methods.

Heading Structure Extraction: To extract hierarchi-

cal heading structure in web pages, we use our pre-

viously proposed heading-based page segmentation

(HEPS) method (Manabe and Tajima, 2015). It ex-

tracts each heading and block in pages as an array

of adjoining sibling DOM nodes. For evaluation, we

used the reference implementation of HEPS 1.0.0

Text Contents of Headings and Blocks: We used the

URL and title as the heading of each web page. As the

text contents of the other headings, blocks, and entire

pages, we use their corresponding raw strings that we

previously deﬁned (Manabe and Tajima, 2015). Intu-

itively, the raw string of a component is the string of

the DOM text nodes in the component. Before gener-

ating raw strings, each DOM IMG (image) nodes are

replaced by its alternate text and URL, i.e., alt and src

HTML attribute values.

Content Length: For length and log-scaled scoring,

we used the number of characters in their raw strings

as their length.

Domain: For domain-based and combination integra-

tion, we distinguished the domains of web pages by

the fully qualiﬁed domain names in their URLs.

Matching between Subtopic Strings and Headings:

Before matching subtopic candidates and hierarchi-

cal headings, we performed basic preprocessing for

retrieval, e.g., tokenization, stop word ﬁltering, and

stemming, for both strings. All URLs were split by

any non-word characters, and the other strings are to-

kenized by Stanford CoreNLP toolkit (Manning et al.,

2014). All tokens were decapitalized, ﬁltered out

33 default stop words of the Lucene library

, then

stemmed by the Porter stemmer (Porter, 1997).

Subtopic Candidate Strings: After preprocessing,

duplicated subtopic candidate strings and subtopic

candidate strings same as queries were removed.

https://github.com/tmanabe/HEPS

http://lucene.apache.org/

Table 1: D-nDCG score comparison with query comple-

tion by Google. Top-5 proposed methods are listed. For all

methods and baseline, I-rec = 0.3841.

Scoring Integration Ranking Score

log-scale domain-based uniform .4502

log-scale combination uniform .4501

log-scale domain-based diversiﬁed .4487

log-scale combination diversiﬁed .4485

bottom-up page-based diversiﬁed .4479

Query completion result by Google .3735

Table 2: D-nDCG score comparison with query completion

by Yahoo. Top-5 proposed methods are listed. For all meth-

ods and baseline, I-rec = 0.3815.

Scoring Integration Ranking Score

log-scale page-based diversiﬁed .4617

bottom-up domain-based diversiﬁed .4609

log-scale page-based uniform .4608

log-scale summation diversiﬁed .4601

length domain-based diversiﬁed .4587

Query completion result by Yahoo .3829

Ties: If we have multiple subtopic candidates of the

same score in our uniﬁed ranking method or in any

iteration of our diversiﬁed ranking method, we sorted

them in the same order as the baseline ranking.

5.4 Evaluation Results

Table 1, 2, and 3 show evaluation results. Table 1

shows the D-nDCG scores achieved by each method

when they re-rank the query completion by Google,

and Table 2 shows the D-nDCG scores achieved by

each method when they re-rank the query comple-

tion by Yahoo. In Table 1 and 2, top-5 proposed

methods are listed in descending order of their D-

nDCG scores. Table 3 shows the scores achieved

by each method when they re-rank our merged base-

line result. In Table 3, top-5 proposed methods are

listed in descending order of their D]-nDCG scores.

In this comparison, the log-scale/summation/uniform

method achieved the best scores in all the measures

among all the proposed methods including ones omit-

ted from Table 3.

5.5 Discussion

In all comparisons, our proposed methods achieved

the better scores than the baseline results. This is not

because we proposed a number of methods and one

of them achieved a better score than each baseline re-

sult by chance. For example, let us focus on the log-

scale/page-based/diversiﬁed method which achieved

the best D]-nDCG score throughout this experiment

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

128

Table 3: Comparison with our merged baseline result. Top-5 methods are listed in descending order of their D]-nDCG scores.

Scoring Integration Ranking I-rec D-nDCG D]-nDCG

log-scale summation uniform .4009 .3997 .4003

log-scale page-based uniform .3986 .3981 .3984

length summation uniform .3974 .3945 .3959

log-scale combination uniform .3956 .3921 .3939

log-scale domain-based uniform .3956 .3913 .3934

Our merged baseline result .3310 .3066 .3188

by reranking the result by Yahoo. The method also

achieved a better D-nDCG score (0.4470) than the re-

sult by Google and better I-rec, D-nDCG, and D]-

nDCG scores (0.3840, 0.3695, and 0.3768, respec-

tively) than the merged result. Moreover, according

to Student’s paired t-test (where each pair consists of

the scores of the baseline and our proposed method

for a query), all the D-nDCG and D]-nDCG scores

were statistically signiﬁcantly different from the base-

line scores (p < 0.05). This fact supports the effec-

tiveness of our proposed subtopic ranking methods.

Only the I-rec score was not statistically signiﬁcant

(p = 0.0656). Hereafter in this paper, we discuss sta-

tistical signiﬁcance based on the same test procedure.

5.5.1 Comparison of Block Scoring Methods

Log-scale scoring achieved the best scores in all the

three comparisons. This fact may suggest that the

importance of a topic is reﬂected by the content

length of the block referring to the topic, but the

importance is not direct proportional to the length.

Moreover, 11 among the 15 best results shown in

Table 1, 2, 3 are using log-scale scoring. This

fact may suggest the robustness of log-scale scor-

ing. However, the advantage of log-scale scoring

over the others was small. For example, the D-

nDCG score of the Yahoo result reranked by the

log-scale/page-based/diversiﬁed method was not sta-

tistically signiﬁcantly different from the scores of

the bottom-up/page-based/diversiﬁed (p = 0.1481),

top-down/page-based/diversiﬁed (p = 0.1204), and

length/page-based/diversiﬁed (p = 0.0972) methods.

5.5.2 Comparison of Score Integration Methods

Score integration methods had only small impact. In

the comparison with the Google result (Table 1), the

log-scale/domain-based/uniform method achieved

the best D-nDCG score, but its difference from the

second-best score by log-scale/combination/uniform

method was small (0.0001). In the comparison

with the Yahoo result (Table 2), the log-scale/page-

based/diversiﬁed method achieved the best D-nDCG

score, but its difference from the score by the log-

scale/summation/diversiﬁed method was also small

(0.0016). In the comparison with our merged re-

sult (Table 3), the differences between the best log-

scale/summation/uniform method and the second-

best log-scale/page-based/uniform method were also

small.

5.5.3 Effect of Diversiﬁed Ranking Method

Because I-rec measures the diversity of rankings,

we focus on the I-rec score comparison with our

merged result (Table 3). No method with di-

versiﬁed ranking achieved the top-5 scores. The

top-down/combination/diversiﬁed method achieved

the best I-rec score (0.3869) among the meth-

ods with diversiﬁed ranking. The I-rec score

difference between the method and the best log-

scale/summation/uniform method was not statisti-

cally signiﬁcant (p = 0.2759). The I-rec score

difference between the best method and the log-

scale/summation/diversiﬁed method was also not sta-

tistically signiﬁcant (p = 0.1028). They show that our

proposed ranking diversiﬁcation method did neither

improve nor worsen resulting rankings.

6 CONCLUSION

We proposed subtopic ranking methods based on the

ideas that hierarchical headings in a document re-

ﬂect the topic structure of the document and that the

length of contents referring to a topic reﬂects the

importance of the topic. Our methods rank candi-

date subtopics based on the blocks whose hierarchical

headings match the subtopic candidate strings. We

evaluated our methods by using the publicly avail-

able NTCIR data set. The results indicated (1) our

methods signiﬁcantly improved the baseline rankings

by commercial search engines, (2) log-scale scoring

seems effective and robust, (3) there is no substantial

difference among score integration methods, and (4)

our ranking diversiﬁcation method was not effective.

Subtopic Ranking based on Hierarchical Headings

129

ACKNOWLEDGMENT

This work was supported by JSPS KAKENHI Grant

Number 13J06384 and 26540163.

REFERENCES

Bah, A., Carterette, B., and Chandar, P. (2014). Udel @

NTCIR-11 IMine track. In NTCIR.

Bouchoucha, A., Nie, J., and Liu, X. (2014). Universit

e de

montr

eal at the NTCIR-11 IMine task. In NTCIR.

Carbonell, J. and Goldstein, J. (1998). The use of MMR,

diversity-based reranking for reordering documents

and producing summaries. In SIGIR, pages 335–336.

Clarke, C. L. A., Craswell, N., and Voorhees, E. M. (2012).

Overview of the TREC 2012 web track. In TREC.

Das, S., Mitra, P., and Giles, C. L. (2012). Phrase pair clas-

siﬁcation for identifying subtopics. In ECIR, pages

489–493.

Dias, G., Cleuziou, G., and Machado, D. (2011). Informa-

tive polythetic hierarchical ephemeral clustering. In

WI, pages 104–111.

Dou, Z., Hu, S., Luo, Y., Song, R., and Wen, J.-R. (2011).

Finding dimensions for queries. In CIKM, pages

1311–1320.

He, J., Hollink, V., and de Vries, A. (2012). Combining im-

plicit and explicit topic representations for result di-

versiﬁcation. In SIGIR, pages 851–860.

Hu, Y., Qian, Y., Li, H., Jiang, D., Pei, J., and Zheng, Q.

(2012). Mining query subtopics from search log data.

In SIGIR, pages 305–314.

Jiang, D. and Ng, W. (2013). Mining web search topics

with diverse spatiotemporal patterns. In SIGIR, pages

881–884.

Kim, S.-J. and Lee, J.-H. (2015). Subtopic mining using

simple patterns and hierarchical structure of subtopic

candidates from web documents. Inf. Process. Man-

age., 51(6):773–785.

Liu, Y., Song, R., Zhang, M., Dou, Z., Yamamoto, T., Kato,

M. P., Ohshima, H., and Zhou, K. (2014). Overview

of the NTCIR-11 IMine task. In NTCIR.

Luo, C., Li, X., Khodzhaev, A., Chen, F., Xu, K., Cao, Y.,

Liu, Y., Zhang, M., and Ma, S. (2014). THUSAM at

NTCIR-11 IMine task. In NTCIR.

Manabe, T. and Tajima, K. (2015). Extracting logical hierar-

chical structure of HTML documents based on head-

ings. PVLDB, 8(12):1606–1617.

Manning, C. D., Surdeanu, M., Bauer, J., Finkel, J.,

Bethard, S. J., and McClosky, D. (2014). The Stan-

ford CoreNLP natural language processing toolkit. In

ACL, pages 55–60.

Moreno, J. G. and Dias, G. (2013). HULTECH at the

NTCIR-10 INTENT-2 task: Discovering user intents

through search results clustering. In NTCIR.

Moreno, J. G. and Dias, G. (2014). HULTECH at the

NTCIR-11 IMine task: Mining intents with continu-

ous vector space models. In NTCIR.

Oyama, S. and Tanaka, K. (2004). Query modiﬁcation by

discovering topics from web page structures. In AP-

Web, pages 553–564.

Porter, M. F. (1997). Readings in information retrieval.

chapter An Algorithm for Sufﬁx Stripping, pages

313–316. Morgan Kaufmann Publishers Inc., San

Francisco, CA, USA.

Robertson, S. E. and Walker, S. (1994). Some simple effec-

tive approximations to the 2-poisson model for proba-

bilistic weighted retrieval. In SIGIR, pages 232–241.

Sakai, T., Dou, Z., Yamamoto, T., Liu, Y., Zhang, M.,

and Song, R. (2013). Overview of the NTCIR-10

INTENT-2 task. In NTCIR.

Song, R., Zhang, M., Sakai, T., Kato, M. P., Liu, Y., Sug-

imoto, M., Wang, Q., and Orii, N. (2011). Overview

of the NTCIR-9 INTENT task. In NTCIR.

Ullah, M. Z. and Aono, M. (2014). Query subtopic mining

for search result diversiﬁcation. In ICAICTA, pages

309–314.

Ullah, M. Z., Aono, M., and Seddiqui, M. H. (2013).

SEM12 at the NTCIR-10 INTENT-2 english subtopic

mining subtask. In NTCIR.

Wang, C., Danilevsky, M., Desai, N., Zhang, Y., Nguyen,

P., Taula, T., and Han, J. (2013a). A phrase mining

framework for recursive construction of a topical hi-

erarchy. In KDD, pages 437–445.

Wang, C.-J., Lin, Y.-W., Tsai, M.-F., and Chen, H.-H.

(2013b). Mining subtopics from different aspects for

diversifying search results. Inf. Retr., 16(4):452–483.

Wang, J., Tang, G., Xia, Y., Zhou, Q., Zheng, T. F., Hu,

Q., Na, S., and Huang, Y. (2013c). Understanding the

query: THCIB and THUIS at NTCIR-10 intent task.

In NTCIR.

Wang, Q., Qian, Y., Song, R., Dou, Z., Zhang, F., Sakai, T.,

and Zheng, Q. (2013d). Mining subtopics from text

fragments for a web query. Inf. Retr., 16(4):484–503.

Xia, Y., Zhong, X., Tang, G., Wang, J., Zhou, Q., Zheng,

T. F., Hu, Q., Na, S., and Huang, Y. (2013). Ranking

search intents underlying a query. In NLDB, pages

266–271.

Xue, Y., Chen, F., Damien, A., Luo, C., Li, X., Huo, S.,

Zhang, M., Liu, Y., and Ma, S. (2013). THUIR at

NTCIR-10 INTENT-2 task. In NTCIR.

Yamamoto, T., Kato, M. P., Ohshima, H., and Tanaka, K.

(2014). KUIDL at the NTCIR-11 IMine task. In NT-

CIR.

Yu, H. and Ren, F. (2014). TUTA1 at the NTCIR-11 IMine

task. In NTCIR.

Zeng, H.-J., He, Q.-C., Chen, Z., Ma, W.-Y., and Ma, J.

(2004). Learning to cluster web search results. In

SIGIR, pages 210–217.

Zheng, W., Fang, H., Cheng, H., and Wang, X. (2012).

Diversifying search results through pattern-based

subtopic modeling. Int. J. Semant. Web Inf. Syst.,

8(4):37–56.

Zheng, W., Wang, X., Fang, H., and Cheng, H. (2011).

An exploration of pattern-based subtopic modeling for

search result diversiﬁcation. In JCDL, pages 387–388.

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

130
