Reﬁning a Reference Architecture for Model-Driven Business Apps

Jan Ernsting

, Christoph Rieger

, Fabian Wrede

and Tim A. Majchrzak

University of M

unster, M

unster, Germany

University of Agder, Kristiansand, Norway

Keywords:

Reference Architecture, MDSD, App, Mobile, Mobile App, Business App, Architecture.

Abstract:

Despite much progress, cross-platform app development frameworks remain a topic of active research. While

frameworks that yield native apps are particularly attractive, their spread is very limited. It is apparent that

(theoretical) technological superiority needs to be accompanied with profound support for developers and

adequate capabilities for maintaining the framework itself. We deem so called reference architectures to be

a major step for building better cross-platform app development frameworks, particularly if they are based

on techniques of model-driven software development (MDSD). In this paper, we describe a reﬁnement of a

reference architecture for business apps. We employ the model-driven cross-platform development framework

for this purpose. Its general design has been described extensively in the literature. The framework

has a sound foundation in MDSD, yet lacks a generator support that fulﬁls the above sketched goals. After

describing the required background, we argue in detail for a suitable reference architecture. While it will

be a valuable addition to the MD

framework, the discussion of our ﬁndings also makes a contribution for

generative app development in general.

1 MOTIVATION

Cross-platform development frameworks for apps

have gained much popularity (Ohrt and Turau, 2012;

Holzinger et al., 2012). However, most of them

employ Web technology and yield inferior results

when striving for a native look and feel (Joorabchi

et al., 2013; Heitk

otter et al., 2013a). Creating

cross-platform frameworks is a profound technolog-

ical challenge (cf. (Heitk

otter et al., 2013b)). At the

same time, a framework needs to be comprehensible

for developers. Moreover, it should provide adequate

development support. The latter is particularly true

when a framework seeks to improve the app develop-

ment process in general (cf. (Heitk

otter et al., 2015)).

In this paper, we build on previous work on MD

a cross-platform development framework that pro-

vides fully native apps for the supported target plat-

forms. It employs techniques from model-driven soft-

ware development (MDSD). Apps are rather mod-

elled than programmed; for this purpose, a domain-

speciﬁc language (DSL) is used, which has been tai-

lored to business app development (Heitk

otter et al.,

2013c).

Despite its undoubted technological soundness,

has not yet found widespread adoption. This

without question can be attributed to a missing com-

munity and user base (i.e. economies of scale). We

believe that part of the reason lies in the complexity of

generation (Evers et al., 2016), though. Code gener-

ation might seem negligible from an app developer’s

point of view since capabilities are taken for granted

when developing a speciﬁc app. However, improve-

ments in the generation step are also reﬂected in de-

velopment in form of extended capabilities and the

possibility to beneﬁt from improvements to the DSL.

We have, therefore, argued to overcome the existing

challenges with profound work on the app generation

step (Evers et al., 2016).

With a more detailed look at the problem, addi-

tional questions need to be asked:

• Can a design pattern such as Model-View-

Controller (MVC) or Model-View-ViewModel

(MVVM) (Smith, 2009) be implemented through-

out the development process?

• How can the fragmentation of devices and the het-

erogeneity of software be overcome?

• How can frequent releases of platforms (such

as Android and iOS), changes to the underlying

programming languages (such as Apple’s transi-

tioning from Objective-C to Swift (Swift Blog,

2015)), and modiﬁcations to the ecosystems be ef-

fectively reﬂected in the generators?

Ernsting, J., Rieger, C., Wrede, F. and Majchrzak, T.

Reﬁning a Reference Architecture for Model-Driven Business Apps.

In Proceedings of the 12th International Conference on Web Information Systems and Technologies (WEBIST 2016) - Volume 2, pages 307-316

ISBN: 978-989-758-186-1

307

• How can redundancy in a typical MVC descrip-

tion of apps be avoided?

Even though generators are seldom implemented

from scratch and only updated occasionally, their de-

velopment demands great skill. Code generators fa-

cilitate the embedding and have to account for two

driving forces: a model instance on the one side and

the target platform on the other. With this paper, we

reﬁne our previous work (Evers et al., 2016). This

reﬁnement builds on two shortcomings that we per-

ceived:

• Currently, MD

focuses on object structure and

behaviour, and not on interaction.

• The employed top-down approach (from model

to reference architecture to platform-speciﬁcity)

does not take into consideration platform-speciﬁc

features in an effective fashion.

Therefore, this paper presents a more effective ref-

erence architecture that advanced from the feedback

to realising a previously proposed reference architec-

ture with two distinct platforms. Thereby, it greatly

helped to ﬁx the ecosystem under test except for the

code generation stage. We were thus enabled in as-

sessing and revising the reference architecture accord-

ingly.

The main contributions of this paper are twofold.

Firstly, we propose a detailed, sophisticated reference

architecture for the model-driven creation of business

apps. While it has been tailored to use in MD

, it

is applicable to MDSD for apps (as well as in Web

technology-based frameworks) in general. Secondly,

we discuss our ﬁndings. This further increases the

generalizability of our work.

This paper is structured as follows. Section 2

draws the background of related work on MDSD for

business app development and the corresponding use

of reference architectures. Section 3 then presents

an evaluation of the existing reference architecture to

provide the foundation for the new proposal. This is

presented as a detailed reﬁnement in Section 4. Our

ﬁndings are then discussion in Section 5. Finally, we

draw a conclusion in Section 6.

2 RELATED WORK

Apart from business apps and related work in the area

of cross-platform development approaches, this sec-

tion speciﬁcally highlights a concrete approach for

business apps, namely MD

. In addition, the general

area of reference architectures is considered to base

the reﬁnements on.

2.1 Business Apps and App

Development

Besides common apps for purposes such as social net-

working or entertainment, business apps encompass

those that are directed at interacting with businesses’

backend information systems. In addition, they can be

categorised by their form-based and data-driven na-

ture (Majchrzak et al., 2015).

For apps, in general, to overcome the heterogene-

ity of mobile platforms, various approaches exist.

Their spectrum ranges from Web apps to native apps

(Majchrzak et al., 2015). While the former rely on

Web technologies such as HTML5, Cascading Style

Sheets (CSS), and JavaScript, the latter requires suf-

ﬁcient proﬁciency of the respective platforms, the ap-

plicable programming languages, and the respective

software development kits (SDKs). Generative ap-

proaches aim at providing a native look and feel as

well as native performance while striving to be as con-

venient to use as Web-based frameworks (Heitk

otter

et al., 2013a). There are two kinds of generative

cross-platform frameworks: transpilers and MDSD-

based approaches.

Transpilers allow compiling source, intermediate,

or binary code for one platform to another. However,

current transpilers such as J2ObjC (J2ObjC, 2015)

deliberately focus on non-UI code. Therefore, they

do not support a complete transformation and require

at least some ﬁnishing touches to let apps run on

targeted platforms. Consequently, they are neither

widely used nor can be considered to be particularly

mature.

Model-driven generative approaches employ the

techniques of MDSD (Stahl and V

olter, 2006). Typi-

cal examples for approaches encompass commercial

products such as WebRatio (WebRatio, 2015). It

utilises graphical models that are expressed in the In-

teraction Flow Modeling Language (IFML), which

the backing company pushed to standardisation by

the Object Management Group (OMG). Though re-

stricted to displaying data, applause (applause, 2015)

features a textual domain-speciﬁc language (DSL) to

express models in. While applause’s development

was discontinued for more than a year and Xmob

(Le Goaer and Waltham, 2013) has yet to present con-

crete modelling facilities, development on MD

pro-

gressed.

2.2 Creating Business Apps with MD

is based on a textual DSL that is structured

along the model-view-controller (MVC) design pat-

tern (Gamma et al., 1995; Buschmann et al., 1996).

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

308

MD² Archetype (in MD²-DSL)

Preprocessor

map.apps

Generator

Backend

Generator

Sources for

map.apps

Platform

Java EE

Server

Java sources

Sources for

Platform X

Figure 1: MD

Modelling Process.

To overcome platform heterogeneity, its syntax fo-

cuses on describing business apps. Thus, consolidated

abstractions are used to express archetypes in MD

DSL (Heitk

otter et al., 2013b). This has obvious lim-

itations, as featured elements correspond to the low-

est common denominator of platform features. This

is particularly true for view related aspects (cf. Sec-

tion 4). On the other hand, users beneﬁt from business

apps automatically derived from archetypes without

needing in-depth knowledge of target platforms. In

consequence, users have to weigh the pros and cons

of using a model-driven approach.

To mince matters, approaches can boost their use-

fulness by increasing the number of supported plat-

forms. This is achieved by adding code generation

facilities for desired platforms. An archetype passes

through a preprocessor as shown in Figure 1. That

stage augments the input archetype with concrete el-

ements to reduce generation effort (Majchrzak and

Ernsting, 2015). Next, the augmented archetype is

handed over to code generators. Currently, these out-

put sources for the commercial map.apps platform

(map.apps product description, 2015) and a Java EE

based backend. Nevertheless, the modelling process

incorporates provisions for adding generators such

that these dispense applications for arbitrary plat-

forms such as Windows Phone or Symbian.

Developing a code generator requires its engi-

neers to comprehend the archetype’s structure (i.e. the

metamodel and its instances) as well as the targeted

platform ecosystem (i.e. the programming environ-

ment, common libraries, etc.). Thus, engineers have

to account for these two forces that drive generator

development. In the following, assistive means that

reduce the overall development effort are illustrated.

2.3 Reference Architectures

To understand the relevance of developing and fur-

ther improving a reference architecture for MD

apps,

knowledge of the potential beneﬁts of reference archi-

tectures is advisable. This question was already sub-

ject of academic research; however, it was discussed

in a broader context and not speciﬁcally tailored to

model-driven software development and mobile apps

in particular (cf. (Cloutier et al., 2010; Angelov et al.,

2009)). Nonetheless, the ﬁndings can be transferred

to this area.

First of all, as any other form of architectures,

a reference architecture helps to control complexity

(Cloutier et al., 2010). The design of software is ex-

pressed in a standardized form such that it is easily un-

derstandable for developers. However, in the context

of MD

, a reference architecture main beneﬁt consists

in the preserved knowledge and guarantees a com-

mon understanding. The reference architecture is sup-

posed to build a common ground on which the devel-

opment of generators for new platforms takes place.

Consequently, it has to embrace the knowledge and

insights which were gained during the implementa-

tion of other generators and applications in order to

provide these to its consuming developers.

A common understanding of MD

application

components is necessary to keep the effort for devel-

opment and maintenance of existing generators man-

ageable. The architecture of the generators and ap-

plications should be similar to a certain degree. This

facilitates a quick understanding of the concrete archi-

tecture on different platforms. Thus, developers who

implemented a generator for a certain platform could

perform maintenance tasks on other platform genera-

tors, as the underlying concepts are the same.

3 EVALUATION OF A

REFERENCE ARCHITECTURE

FOR MODEL-DRIVEN

BUSINESS APPS

Various best practices and established patterns for

mobile platforms exist. Unsurprisingly, these typi-

cally neglect code generation as they do not distin-

guish between model-speciﬁc elements and compo-

nents concerned with the general application execu-

tion.

However, in the context of model-driven ap-

proaches, the aforementioned code generation stage

creates a tie between the model and its targeted plat-

forms. Thus, the generation stage forms a crucial

component of these approaches.

When considering MD

’s use of the MVC pat-

tern in its DSL model, sufﬁcient guidance with re-

gard to engineering apt code generators could be ex-

Reﬁning a Reference Architecture for Model-Driven Business Apps

309

pected. Yet, previous efforts showed that redundant

or recurring ideas could not be removed by the MVC

pattern itself nor did the tool’s underlying metamodel

offer substantial guidance in developing code genera-

tors. MD

’s constitutional development had focused

on Android and iOS as target platforms. At that stage,

its engineers noticed to some degree that numerous

architectural choices arose for both platforms (Evers

et al., 2016).

Prior to targeting a third, previously unconsidered

commercial platform, (Evers et al., 2016) compiled

a reference architecture for model-driven business

apps. Establishing support for map.apps (map.apps

product description, 2015) not only illustrated the ref-

erence architecture’s applicability, but also showed

that MD

’s scope could surpass the limits of mobile

platforms.

The reference architecture explicates dependen-

cies between and usages of MD

-DSL’s metamodel

elements. On a coarse level, the MVC pattern alone

did not facilitate development of code generators in an

intuitive fashion. Nevertheless, architectural elements

can easily be partitioned to accentuate MD

’s MVC

provenance as shown in Figure 2. To provide guid-

ance for generator development, (Evers et al., 2016)

described architectural key elements with regard to

their instantiation and runtime behaviour.

For example, concrete EventHandler account for

different event types that exist in MD

. These ar-

chitectural elements assist in orchestrating an app’s

runtime behaviour. They determine which associated

Action has to be executed in response to triggered

events. Here, the architecture’s explication guides

code generators to provide facilities to handle global

(e.g. context related) events such as connection lost,

view related (i.e. widget) events, and data persistence

(i.e. content provider) events in their respective gen-

erates (i.e. apps).

Of course, (Evers et al., 2016) elaborated on the

other elements in Figure 2. For now, we highlight

their discussion in which they point out that little

backing empiricism exists and that their architecture

may require minor changes to be universally appli-

cable to other platforms. Put straight, we strove to

evaluate the architecture’s suitability by targeting the

two platforms currently dominating the mobile mar-

ket: iOS and Android (Gartner, 2015).

The implementation was conducted as a greenﬁeld

approach, respecting the development process pro-

posed by (Stahl and V

olter, 2006, p. 27). Two inde-

pendent developers, who were not involved in the de-

velopment of the original reference architecture, im-

plemented the reference apps and generators for the

corresponding platforms, leveraging the original ref-

erence architecture as a guideline for the respective

concrete architectures.

The evaluation of the reference architecture re-

vealed that it was already quite well suited to provide

guidance regarding the structural composition of re-

quired components. However, overall it was difﬁcult

to instantiate the reference architecture because of

two main shortcomings: ﬁrst, the reference architec-

ture lacks to provide an overview of the runtime be-

haviour and the interaction between components and

second, it chooses a misleading level of abstraction

at some points, thus slackening the platform-speciﬁc

development progression. Therefore, the reference ar-

chitecture was revised and applied as presented in the

following.

4 REVISING THE REFERENCE

ARCHITECTURE

Because of the aforementioned shortcomings, struc-

tural aspects of the original reference architecture

were improved and developers relieved with in-

creased ﬂexibility regarding the implementation in

programming code as well as increased clarity to-

wards interaction patterns.

4.1 Reference Architecture Structure

The revised reference architecture improves the struc-

ture three-fold: ﬁrst, the progression of the MD

lan-

guage introduced a process layer extension that is re-

ﬂected in the current architecture version. Further-

more, the previously unspeciﬁed view layer of the

application is substantiated and a mobile-centric task

queue component is added.

4.1.1 Workﬂow Layer

Since the initial development of the reference archi-

tecture, the MD

language further evolved. Most

prominently, an additional layer of so-called work-

ﬂow elements was added to its speciﬁcation, enabling

development of cross-app workﬂows and app prod-

uct lines (Dagef

orde et al., 2016). This process-

oriented layer is now also considered in the revised

reference architecture. For a seamless integration,

the current building blocks of events and actions

were reused. To trigger a workﬂow event, an action

called SetWorkflowElementAction extends the ex-

isting architecture. Newly added WorkflowElement

objects represent self-contained process steps. Every

workﬂow element is supplied with a workﬂow event

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

310

Controller

Model View

ContentProvider

DataStore

Factory

DataStore

Type

DataType Enum Entity

ContentProvider

Registry

EventHandler

GlobalEvent

Handler

ContentProvider

EventHandler

WidgetEvent

Handler

ViewManager

Validator

WidgetRegistry

Mapping

Widget

Layout

Action

CustomAction

SimpleAction

Widget

Wrapper

DataMapper

<<create>>

SingleWidget

Figure 2: Original Reference Architecture (Evers et al., 2016).

to identify transition points within the overall pro-

cess. Also, a workﬂow action indicates whether to

start or end the speciﬁed workﬂow. Together, condi-

tional workﬂow paths can be modelled.

The actual processing of the workﬂow elements is

performed by the WorkflowManager component. For

local workﬂow elements, this includes ﬁnalizing the

currently active workﬂow element, deciding upon the

further workﬂow path, and starting the next element.

In case the workﬂow element has to be continued in

another app, the intermediate state of the workﬂow

and its associated entities is additionally sent to the

backend server. The WorkflowManager component

of the subsequent app is then notiﬁed about a newly

available workﬂow instance and app users can even-

tually continue its execution.

4.1.2 View Speciﬁcation

The original version of the reference architecture did

not consider the implementation of the view as a part

of the architecture itself. It was claimed that the im-

plementation of the view was too platform-speciﬁc

and, therefore, could not be included. However, our

evaluation of the reference architecture on iOS and

Android showed that there are similarities regarding

the structure of views. That is on both platforms, the

view is deﬁned as a hierarchy of layouts and widgets

that can be arbitrarily nested. This pattern is also com-

mon on other platforms. Therefore, objects represent-

ing the structure of the view were included in the ref-

erence architecture. In case that a platform handles

the view differently, this part could easily be adapted

when transforming the reference architecture into a

platform-speciﬁc one.

The WidgetWrapper object was removed in the

revised reference architecture. At this point, the

original reference architecture stated that a widget

should provide a certain set of methods. However,

this was already done by applying a speciﬁc design

pattern, which is not necessarily the best choice for

the concrete implementation. On Android, for exam-

ple, it turned out to be more convenient to use Cus-

tom Views instead of wrapper objects. Therefore, we

claim that the application of concrete design patterns

should be avoided in order not to push developers in

a direction that might not be the best choice. Rather,

the reference architecture should be more general and

show options on how to develop the concrete imple-

mentation.

4.1.3 Tasks

In MD

, custom actions consist of atomic tasks.

These tasks perform operations such as binding the

value of a widget to an entity. Tasks were not a part

of the original reference architecture as they were sup-

posed to be directly transformed into plain code by

app generators. However, the evaluation showed that

tasks can still be further generalized. Consequently,

it is beneﬁcial to add classes for the different tasks

in the platform-speciﬁc libraries and to instantiate

them with required parameters in the generated code.

Tasks differ from actions in a way such that actions

perform high-level, control ﬂow-oriented operations,

such as switching to another view, whereas tasks per-

form low-level, view-oriented operations, such as en-

abling data binding to a widget.

Reﬁning a Reference Architecture for Model-Driven Business Apps

311

4.1.4 TaskQueue

In general, mobile applications should be designed in

a resource efﬁcient way as mobile devices typically

provide limited resources compared to personal com-

puters. The Android platform, for example, provides

a built-in memory management that is enabled to free

up memory allocated to paused activities so that it

can be used by activities with a higher priority, e.g.

active ones. Consequently, it is not guaranteed that

widget objects exists all the time an app is running.

However, for certain tasks, such as data binding, it

is necessary to have access to a widget, e.g. to regis-

ter event listeners. The ﬁrst version of the reference

architecture suggested overcoming that issue by cre-

ating WidgetWrappers on start-up of the application.

As these WidgetWrappers keep a reference to the ac-

tual widget, the Android memory management does

not destroy the objects so that they can be accessed

if required during the execution of the app. However,

this approach leads to memory leaks, i.e. objects that

blocked memory and could not be deleted, because

they were referenced by a running app. To avoid these

leaks and to facilitate a more dynamic handling of ap-

plication resources, the concept of the TaskQueue is

introduced in the revised version of the reference ar-

chitecture.

The TaskQueue provides functionality to store

tasks that cannot be executed because of required ob-

jects missing. As soon as the required objects are cre-

ated, the execution is triggered again. An example

from the Android platform is the transition between

activities. When a new activity is started, all wid-

get objects that belong to the activity’s view are cre-

ated. Therefore, it might be possible to execute tasks

that could not be executed before. Thus, the transi-

tion between activities is one point in the ﬂow of an

Android app where the execution of formerly stored

tasks should be triggered again.

4.2 Platform-speciﬁc Implementation

Variability

Possible alternatives for the implementation of the ar-

chitecture in object-oriented programming languages

include the approaches that are discussed in the fol-

lowing.

4.2.1 Status Quo

The original reference architecture was developed

with a top-down approach starting from the MD

lan-

guage deﬁnition. As a consequence, platform-speciﬁc

characteristics were mainly treated as limitations that

needed to be bypassed by additional generalised com-

ponents. For example, the event handling mechanism

is designed as explicit component because platforms

not necessarily provide the possibility to extend their

native event system.

As further contribution, the revised architec-

ture incorporates the implementation learning in a

bottom-up manner. Particularly, the main pain

point of over-generalisation, resulting in tedious re-

implementations of existing platform features, should

be avoided. Mapping the reference architecture to ap-

propriate platform implementations is a problem to

be solved by generator developers with knowledge

of the target platform’s characteristics and advanced

language constructs. This choice of implementation

allows for the necessary variability to avoid imple-

mentation overhead and beneﬁt from available lan-

guage features. (Fazal-e-Amin et al., 2011) discuss

several techniques for object-oriented programming

languages that are applicable for the MD

reference

architecture.

4.2.2 Delegation

Glue interfaces bridge potentially incompatible code

parts by specifying an interface towards the rest of the

application (France and Rumpe, 2007). As a basis,

all components of the revised reference architecture

can be regarded as such interfaces instead of explicit

class requirements. Components that cannot easily

be speciﬁed as one object on the target platform can

use available aggregation or delegation mechanisms

to perform the desired action as long as the interface

towards the remaining objects is fulﬁlled. Developers

can therefore beneﬁt from unique platform features

to reduce development time, increase runtime perfor-

mance, or improve maintainability and readability of

the resulting code.

For example, the implementation of data map-

pings depends on available platform features. Where

possible, an efﬁcient bidirectional map of model en-

tity and view element is a good solution. Other im-

plementations are likely suitable as long as the data

mapper can be queried to look up the respective wid-

get to an entity attribute, and vice versa.

4.2.3 Inheritance

Extending classes of the platform is a viable solution

to reuse existing functionality contained in the plat-

form libraries. Using class inheritance mechanisms,

provided classes only need to be enriched with miss-

ing operations in order to comply with the reference

architecture speciﬁcation, again reducing implemen-

tation efforts.

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

312

Controller

Model View

ContentProvider

DataStore

Factory

DataStore

Type

DataType Enum Entity

ContentProvider

Registry

EventHandler

GlobalEvent

Handler

ContentProvider

EventHandler

WidgetEvent

Handler

ViewManager

Validator

WidgetRegistry

Mapping

Widget

Layout

Action

CustomAction

SimpleAction

DataMapper

<<create>>

Workflow

WorkflowEvent

Handler

Workflow

Manager

WorkflowEvent

Workflow

Element

WorkflowAction

Task

TaskQueue

SingleWidget

Figure 3: Revised Reference Architecture.

Native widget extensions are a possible applica-

tion of this approach: Platforms such as Android sup-

port the creation of custom widgets by sub-classing a

generic widget class. Consequently, only additional

functionalities for validation and value access need to

be implemented manually. Alternatively, wrapper ob-

jects can be used that refer to native widget elements

as fallbacks. As a second option, the native platform

event system can be extended with custom events on

some platforms; thus limiting implementation over-

head. Where this is not possible, for instance on iOS,

all event-related components of the reference archi-

tecture need to be implemented.

4.2.4 Overloading

Overloading methods or using generic classes is a

further technique to ﬂexibly implement the required

methods of the reference architecture’s component

speciﬁcations. By choosing appropriate parameters,

the desired functionality can be provided while lever-

aging the potential of the respective programming

language concepts.

For instance, dynamically typed languages such

as JavaScript might look up view element references

using String objects. However, statically typed lan-

guages may beneﬁt from enumeration types by pro-

viding additional compile-time security with regard

to the existence of such references.

4.2.5 Decentralized Processing

Several components of the reference architecture

manage other components. However, it is deliberately

unspeciﬁed whether a single object should perform

all management activities or whether responsibilities

can be shared by a distributed set of instances. For

example, event handlers can be implemented as sin-

gleton objects that handle speciﬁc events on a global

application level. On the other hand, the Android im-

plementation initializes individual event handlers that

use the observer pattern to directly capture changes

of the widgets and content providers (Gamma et al.,

1995, p. 293).

As a result, the revised reference architecture

combines the previous model-driven top-down ap-

proach with a platform-driven bottom-up perspective

while at the same time encouraging implementation

choices by generator developers.

4.3 Reference Architecture Interactions

To assist developers with respect to their implemen-

tation choices and expatiate on desired component in-

teractions in the respective implementations, further

behavioural aspects require clariﬁcation complement-

ing the revised structure of the reference architec-

ture. Particularly, three main interactions are essen-

tial for the application execution: basic widget con-

trol ﬂows, process-oriented workﬂow control ﬂows,

and data ﬂows.

Reﬁning a Reference Architecture for Model-Driven Business Apps

313

WidgetEvent

Handler

Widget

Action

CustomAction

SimpleAction

Task

TaskQueue

4b) Perfom tasks

when widgets are

(re-)created

1) Trigger update,

e.g. tap button

2) Event

handler

executes

registered

action

On startup:

Initialize

actions

On startup:

interactions

Initializer

3a) Perform

view updates

on active

widgets

3b) Queue tasks for

inactive widgets

Figure 4: Interaction diagram for widget control ﬂows.

4.3.1 Widget Control Flow

In MD

, apps’ business logic is modelled using MD

actions which, amongst others, can trigger view up-

dates. Events and actions are created and mutually

registered by the Initializer component which sets

up all interacting objects on application launch and

triggers the ﬁrst event. From this point onwards, the

event-action loop is the backbone of the application

runtime. As depicted in Figure 4, widget changes are

observed through respective gesture or value change

events. Event handlers then execute the respective ac-

tions registered on start-up of the application. De-

pending on the state of the targeted view element,

updates such as widget state changes or view transi-

tions can directly be applied on visible elements. Up-

date tasks on currently inactive elements, for instance

data binding changes, are temporarily queued in the

TaskQueue as described in Subsubsection 4.1.4.

4.3.2 Workﬂow Control Flow

In addition to this app-internal view update mecha-

nism, the overall business process modelled as multi-

ple workﬂow elements (Dagef

orde et al., 2016) also

leverages the event-action loop concept. Instead of

updating a view element, the widget event handler

executes a FireEventAction that further triggers a

workﬂow event (cf. Figure 5). The respective event

is handled by the WorkflowEventHandler that no-

tiﬁes the WorkflowManager component to process

the event as described in Subsubsection 4.1.1. When

starting the next workﬂow element, its start-up action

is executed which may contain model-speciﬁc initial-

ization tasks. It also switches to the respective view

and updates widget contents according to the regular

widget control ﬂow description.

4.3.3 Data Flow

As MD

apps are data-driven, data ﬂows within the

application are a major element of interest. Start-

WidgetEvent

Handler

Widget

FireEventAction

WorkflowEvent

Handler

Workflow

Manager

CustomAction

1) Trigger update,

e.g. tap button

2) Event handler fires

registered workflow event

On startup:

workflow

elements

On startup:

interactions

Initializer

3) Action triggers event for a

specific workflow element

4) Event handler passes

workflow update to

workflow manager

Server

5) Workflow state

sent to server for

cross-app workflows

6) Execute startup

action of next

workflow element

7) Change

view and

update

content

Figure 5: Interaction diagram for workﬂow control ﬂows.

UpdateContent

ProviderAction

ContentProvider

DataStore

ContentProvider

EventHandler

WidgetEvent

Handler

Widget

Server

3) Execute registered

action

4) Synchronize

content

provider

6) Observe

content provider

change

7) Execute

registered action

5) Save entity

Optional: Send data

to remote server

Validator

1) Observe

widget change

2) Validate input

UpdateWidget

Action

8) Synchronize widget state

Figure 6: Interaction diagram for data ﬂows.

ing from observed widget changes again, ﬁrst in-

put validation is applied to avoid unnecessary data

ﬂows. Next, event handlers execute the registered ac-

tion which notiﬁes the content provider of an update.

This content provider manages the underlying entity

and saves the ﬁeld to either local storage or a remote

location accessed by a data store. Finally, the con-

tent provider also emits an update event such that the

respective event handler executes update actions for

(potentially multiple) associated widgets. This loop,

depicted in Figure 6, can also be started when an ex-

ternal data source changes and the data store notiﬁes

the content provider of updated content.

These interaction loops additionally guide the be-

havioural implementation of the reference architec-

ture on new platforms without enforcing any technical

implementation approach with regard to the event and

synchronization techniques.

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

314

5 DISCUSSION AND OUTLOOK

The revised reference architecture incorporates in-

sights gained from the application of the original ar-

chitecture in three distinct generator implementations.

However, the focus on the MD

language still lim-

its the empirical validation of the approach. On the

one hand, the balance of component generalisation

and ﬂexibility of implementation derived from the

evaluated generator implementations needs to be val-

idated. On the other hand, the described interac-

tion illustrations are also based on the currently avail-

able generator implementations. In retrospect, this in-

formation would have provided important guidance

for the understanding of the reference architecture.

Still, for both aspects empirical validation can only

be achieved by applying the reﬁned reference archi-

tecture to another platform without prior knowledge

of the subject matter.

While the interaction patterns do not impose any

restrictions on the actual implementation, there might

also be platforms for which the basic event-action

loop is not well applicable. With additional commu-

nication emerging from cross-app workﬂow coordina-

tion, it should be considered to further specify the be-

haviour of the existing external interfaces as guidance

for generator developers. For instance, data exchange

formats on mobile platforms should be assessed to

provide further standardisation. Also, different com-

munication mechanisms such as asynchronous back-

end requests or servers pushing messages to apps may

be considered with regard to user experience improve-

ments. Incorporating such changes into the reference

architecture may result in changes to the interaction

mechanisms that were presented in this paper.

Finally, the derived best practices need to be reap-

plied to the generator implementations fostering a

maintainable code base following common architec-

tural design decisions. The revised reference architec-

ture already incorporates changes resulting from the

language evolution as for instance the workﬂow

layer extension integrates nicely into the existing ar-

chitecture. Yet, it has to be shown whether the current

reference architecture is ﬂexible enough to adapt to

future DSL language changes.

Despite some minor drawbacks, the evaluation

showed that reference architectures can serve as sup-

portive means for extending model-driven approaches

such as MD

. In addition, these limitations were

leveraged to assist in revisiting and applying these

newly gained insights as presented in Section 4.

6 CONCLUSION

In this paper, we have presented work on the re-

ﬁnement of a reference architecture for MD

. It

extends the model-driven cross-platform framework

with means to provide uniﬁed, maintainable, and scal-

able code generation. Thereby, it ultimately also con-

tributes to the framework’s ease-of-development.

Based on the study of related work and the ﬁrst

suggestion by (Evers et al., 2016), we proposed steps

for the reﬁnement. Despite some minor drawbacks,

the evaluation showed that reference architectures

can serve as supportive means for extending model-

driven approaches such as MD

. These limitations

were leveraged to assist in revisiting and applying the

newly gained insights. The actual work consists of de-

tailed suggestions for the structure of the reference ar-

chitecture, ways to address platform-speciﬁcity while

keeping an abstract interface, and suggested guide-

lines for component interactions.

There is a ﬁne line between being too speciﬁc and

too general (or, rather, abstract) with regard to ref-

erence architectures. We are conﬁdent that we have

found a balanced approach with the proposals made

in this paper. However, the feasibility of our ideas

will need to be proven empirically – ﬁrst qualitatively

and ultimately quantitatively. In the meantime, we

will keep up our work and also seek to contribute to

the core of the MD

framework including its domain-

speciﬁc language. Currently, an alternative, graphical

modelling front-end that utilises the revised reference

architecture and generators is being designed to assess

its accessibility to modellers; thus, making a case in

favour of reusable and maintainable generation facili-

ties. We hope that MD

will get more attention by in-

dustrial users in the future, probably even stimulating

work on complementary or competing approaches.

REFERENCES

Angelov, S., Grefen, P., and Greefhorst, D. (2009). A clas-

siﬁcation of software reference architectures: Analyz-

ing their success and effectiveness. In European Conf.

on Software Architecture (ECSA), pages 141–150. doi:

10.1109/WICSA.2009.5290800

applause (2015). https://github.com/applause/.

Buschmann, F., Meunier, R., Rohnert, H., Sommerlad, P.,

and Stal, M. (1996). Pattern-Oriented Software Ar-

chitecture. Wiley.

Cloutier, R., Muller, G., Verma, D., Nilchiani, R., Hole,

E., and Bone, M. (2010). The concept of reference

architectures. Systems Engineering, 13(1):14–27.

Dagef

orde, J. C., Reischmann, T., Majchrzak, T. A., and

Ernsting, J. (2016). Generating app product lines in

a model-driven cross-platform development approach.

Reﬁning a Reference Architecture for Model-Driven Business Apps

315

In 49th Hawaii International Conference on System

Sciences (HICSS).

Evers, S., Ernsting, J., and Majchrzak, T. A. (2016). To-

wards a reference architecture for model-driven busi-

ness apps. In 49th Hawaii International Conference

on System Sciences (HICSS).

Fazal-e-Amin, Mahmood, A. K., and Oxley, A. (2011). An

analysis of object oriented variability implementation

mechanisms. ACM SIGSOFT Software Engineering

Notes, 36(1):1.

France, R. and Rumpe, B. (2007). Model-driven develop-

ment of complex software: A research roadmap. In

Future of Software Engineering, pages 37–54. IEEE

Computer Society.

Gamma, E., Helm, R., Johnson, R., and Vlissides, J. (1995).

Design patterns: Elements of reusable object-oriented

software. Addison-Wesley professional computing se-

ries. Addison-Wesley.

Gartner Press Release (2015). http://www.gartner.com/

newsroom/id/3169417.

Heitk

otter, H., Hanschke, S., and Majchrzak, T. A. (2013a).

Evaluating Cross-Platform Development Approaches

for Mobile Applications. In Revised Selected Papers

WEBIST 2012, volume 140 of LNBIP, pages 120–138.

Springer.

Heitk

otter, H., Majchrzak, T. A., and Kuchen, H. (2013b).

Cross-Platform Model-Driven Development of Mo-

bile Applications with MD

. In Proc. of the 28th An-

nual ACM Symposium on Applied Computing (SAC),

pages 526–533. ACM.

Heitk

otter, H., Majchrzak, T. A., and Kuchen, H.

(2013c). MD

-DSL - eine dom

anenspeziﬁsche

Sprache zur Beschreibung und Generierung mobiler

Anwendungen. In 6. Arbeitstagung Programmier-

sprachen (ATPS), volume 215 of LNI, pages 91–106.

Gesellschaft f

ur Informatik e.V. (GI).

Heitk

otter, H., Kuchen, H., and Majchrzak, T. A. (2015).

Extending a Model-Driven Cross-Platform Develop-

ment Approach for Business Apps. Science of Com-

puter Programming (SCP), 97(1):31–36.

Holzinger, A., Treitler, P., and Slany, W. (2012). Making

apps useable on multiple different mobile platforms:

On interoperability for business application develop-

ment on smartphones. In Multidisciplinary Research

and Practice for Information Systems, volume 7465 of

Lecture Notes in Computer Science, pages 176–189.

Springer.

J2ObjC (2015). http://j2objc.org/.

Joorabchi, M. E., Mesbah, A., and Kruchten, P. (2013). Real

challenges in mobile app development. In 2013 ACM /

IEEE International Symposium on Empirical Software

Engineering and Measurement, pages 15–24.

Le Goaer, O. and Waltham, S. (2013). Yet another DSL

for cross-platforms mobile development. In Proc. of

the First Workshop on the Globalization of Domain

Speciﬁc Languages, pages 28–33. ACM.

Majchrzak, T. A. and Ernsting, J. (2015). Reengineering

an approach to model-driven development of business

apps. In 8th SIGSAND/PLAIS EuroSymposium, pages

15–31.

Majchrzak, T. A., Ernsting, J., and Kuchen, H. (2015).

Achieving business practicability of model-driven

cross-platform apps. Open Journal of Information

Systems (OJIS), 2(2):3–14.

map.apps product description (2015). http://conterra.de/

en/produkte/con-terra-solutionplatform/mapapps/

beschreibung.aspx.

Ohrt, J. and Turau, V. (2012). Cross-platform development

tools for smartphone applications. IEEE Computer,

45(9):72–79.

Smith, J. (2009). Patterns – WPF Apps With The Model-

View-ViewModel Design Pattern. https://msdn.

microsoft.com/en-us/magazine/dd419663.aspx.

Stahl, T. and V

olter, M. (2006). Model-Driven Software De-

velopment: Technology, Engineering, Management.

Wiley.

Swift Blog (2015). Swift blog - apple developer. https://

developer.apple.com/swift/blog/.

WebRatio (2015). http://www.webratio.com/.

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

316
