Requirements Engineering and Variability Management in DSPLs

Domain Engineering: A Systematic Literature Review

euson M. P. da Silva

, Carla I. M. Bezerra

1,2,3

, Rossana M. C. Andrade

2,3

and Jos

e Maria S. Monteiro

Federal University of Cear

a (UFC), Quixad

a Campus, ZIP: 63902-580, Quixad

a, CE, Brazil

Federal University of Cear

a (UFC), Pici Campus, ZIP: 60455-760, Fortaleza, CE, Brazil

Group of Computer Networks, Software Engineering and Systems (GREat), Pici Campus,

Bloco 942-A, ZIP: 60455-760, Fortaleza, CE, Brazil

Keywords:

Dynamic Software Product Line, Requirements Engineering, Variability Management.

Abstract:

Recently, Software Product Lines (SPLs) have been used successfully for building products families. How-

ever, the currently and complex software products demand more adaptive features. Today, many application

domains demand capabilities for ﬂexible adaptation and post-deployment reconﬁguration. In this context,

Dynamic Software Product Lines (DSPLs) represent a way to produce software products able to change their

own behavior at runtime due to the changes in the product use environment. DSPLs present some interesting

properties such dynamic variability and reconﬁguration at runtime. The dynamic variability is represented by

the deﬁnition of variants and context information. The reconﬁguration at runtime is the process that enables

the features activation and deactivation in a conﬁguration product. Both properties are closely related to the re-

quirements engineering and variability management, in the domain engineering life-cycle. In this research, we

provide a systematic literature review that aims to identify the activities, assets, tools and approaches that are

used in requirements engineering and variability management in DSPLs domain engineering. We performed a

manual and automatic search, resulting in 581 papers of which 37 were selected. We also provide a discussion

about the challenges and solutions of runtime variability mechanisms in the context of DSPLs.

1 INTRODUCTION

Software Product Lines (SPLs) can be deﬁned as a

set of software-intensive systems sharing a common

and managed set of features that satisﬁes the spe-

ciﬁc needs of a particular market segment or mis-

sion (Northrop et al., 2007). However, SPLs just

support the development of static products (Hinchey

et al., 2012), i.e., SPLs products are not able to adapt

their own behavior to the changes in the users needs

at runtime (Bencomo et al., 2012). On the other hand,

the currently complex systems need to deal with dy-

namic aspects, such as successive reconﬁgurations at

runtime, after their ﬁrst deployment (Bosch et al.,

2015). In this context, emerged Dynamic Software

Product Lines (DSPL) (Hallsteinsen et al., 2008).

DSPLs extend existing product line engineer-

ing approaches by moving their capabilities to run-

time (Hinchey et al., 2012). In DSPLs, products

can be reconﬁgured dynamically at runtime after their

initial derivation (Bencomo et al., 2012). Although

DSPLs have some differences compared with SPLs,

DSPLs still share the same development life-cycle as

presented by Capilla et al. (Capilla et al., 2014a).

DSPLs, as well SPLs, are composed of two main

development life-cycle: domain and application engi-

neering (Hallsteinsen et al., 2008). The domain engi-

neering is responsible for (i) specifying, documenting

and developing the assets that will be used to compose

the future products of the line. Besides it is responsi-

ble for (ii) producing the necessary SPLs infrastruc-

ture, composed of: a common architecture and its

variation points, a set of reusable parts and a model

to represent the variability (Bencomo et al., 2012).

Once DSPLs adapt their own behavior at runtime,

besides to identify the requirements, it is necessary to

recognize the contexts that the line will need to sup-

port. These tasks are performed in the domain en-

gineering life-cycle, through two different activities:

domain and context analysis (Capilla et al., 2014a).

The domain analysis speciﬁes the domain that the line

will support, identifying and documenting the vari-

544

Silva, L., Bezerra, C., Andrade, R. and Monteiro, J.

Requirements Engineering and Variability Management in DSPLs Domain Engineering: A Systematic Literature Review.

In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 1, pages 544-551

ISBN: 978-989-758-187-8

able features of the domain (Capilla et al., 2014b).

The context analysis captures the contexts to be sup-

ported by the DSPL (Capilla et al., 2014b). An im-

portant activity from context analysis is to identify the

information used by the products reconﬁguration pro-

cess that happens due to the changes in use environ-

ment. When a new context is identiﬁed, the product

needs to check which features must be activated and

which should not (Capilla et al., 2014a).

Guedes et al. (Guedes et al., 2015) present a sys-

tematic mapping focused on DSPLs aspects to iden-

tify methodologies that are used to execute the vari-

ability management. However, the results do not

present what activities are used to project and how

these activities need to be executed to ensure the

DSPLs variability was well understood. In the work

of Da Silva et al. (da Silva et al., 2013) is presented a

SLR that aims at understanding how dynamic deriva-

tion is made in DSPL. The work identiﬁes how the

models, approaches and methods are used to address

the dynamic derivation problem in DSPLs, but it is

not presented how these assets are made, what in-

formation, roles and activities are involved to deﬁne

them.

In this context, we performed a Systematic Liter-

ature Review (SLR) to investigate how the require-

ments engineering and variability management are

performed in DSPLs domain engineering. We aimed

to identify the activities, assets, tools and approaches

that are used. As result, we analyzed 37 studies dated

from 2008 to 2015. The main contribution of this

work is a catalogue of activities to support the require-

ments process in DSPLs domain engineering.

The remainder of this work is organized as fol-

lows. Section 2 reports the SLR. Section 3 de-

scribes the studies classiﬁcation. The results of each

research questions are presented in section 4. Section

5 presents a discussion about the results. Section 6

discusses the threats of validity. Section 7 concludes

this work and presents suggestions for future work.

2 SYSTEMATIC REVIEW

PROCESS

The review process of this work followed the guide-

lines of (Keele, 2007) and (Kitchenham et al., 2009).

The process included the deﬁnition of three activities:

planning, conducting and results reporting. In the

planning was deﬁned the review protocol and in the

conducting, the focus was on the selection and analy-

ses process of the work. Finally, the results reporting

comprised the results presentation.

To support the SLRs execution we use a tool to

automatize some steps. The adopted tool was StArt

(State of the Art through Systematic Reviews) that

supports the review process since the deﬁnition of

the review protocol until the results report. Due to

StArt be a desktop tool, some steps were supported

by templates allowing the parallel work among the

researchers. The next subsections present how the re-

view process was done.

2.1 Research Questions

This work followed a main research question and six

(6) secondary questions. The ﬁrst four secondary

questions are related to list the activities, assets, tools

and the approaches used to represent the variability

and requirements in DSPLs domain engineering. Ad-

ditionally, the last two research questions deal with

the DSPLs variability and aim to specify what infor-

mation are used, still in the requirements engineering,

to do or just to support, the variability management at

runtime.

• RQ1. How are the requirements engineering (RE)

and variability management (VM) executed in

DSPLs domain engineering?

– RQ1.1. What activities of RE and VM are used

in DSPLs?

– RQ1.2. What approaches are used to document

the requirements in DSPLs?

– RQ1.3. What assets are built of RE and VM in

DSPLs?

– RQ1.4. What approaches are used to represent

the DSPLs variability?

– RQ1.5. What approaches are used to support

the reconﬁguration process in DSPLs?

– RQ1.6. What approaches are used to eliminate

possible inconsistencies in DSPLs variability

model?

2.2 Search Process

The search process started with a manual and auto-

mated search, in digital libraries (DL). The adopted

DLs were: Scopus

, Compendex

and Web of Sci-

ence

. The manual search was necessary due to the

veriﬁcation that the automated search did not return

papers from important conferences dated from 2015

(SPLC, VaMoS). After the two searches, all identiﬁed

papers were joined at the same work set.

http://lapes.dc.ufscar.br/tools/

http://www.scopus.com/

http://www.engineeringvillage.com/

https://apps.webofknowledge.com/

Requirements Engineering and Variability Management in DSPLs Domain Engineering: A Systematic Literature Review

545

To perform the automated search, we used a

search string. This string was deﬁned through key-

words, extracted from each research question. At the

end, the selected words were joined with search oper-

ators (AND, OR). To ensure the string was appropri-

ated to return valid papers, we tested it many times.

The adopted search string is presented bellow:

(“Software product line engineering” OR “Do-

main Engineering” OR “Domain Analysis” OR

“Context Analysis”) AND (Requirements OR “Re-

quirements Engineering” OR Elicitation OR Analysis

OR Speciﬁcation OR Veriﬁcation OR Management)

AND (“feature model” OR “variability model” OR

“decision model” OR “domain model”) AND (“Soft-

ware Product Line” OR “product family”) AND (au-

tonomic OR pervasive OR ecosystems OR dynamic

OR “context-aware*” OR adaptive)

2.3 Inclusion/Exclusion and Quality

Criteria

The papers of the automated and manual search were

analyzed according to some criteria. To justify the

reason that a paper would be selected or not, we de-

termine inclusion and exclusion criteria. Addition-

ally, the papers content should be evaluated. It was

done following the guidelines of Kitchenham et al.

(Kitchenham et al., 2006). For that, we deﬁne 6 ques-

tions and a valuation function. The evaluation score

could vary from 0, for papers that do not satisfy a cri-

terion, to 6, for papers that satisfy totally a criterion.

The inclusion/exclusion criteria are listed in Table 1.

Table 1: Inclusion/Exclusion criteria.

Inc/Exc Criterion

Inc. Activities about RE and VM for

DSPLs domain engineering

Inc. Approaches for the RE and VM activ-

ities

Inc. Approaches to support the require-

ments and variability

Inc. Approaches to support the inconsis-

tencies treatment in DSPLs variability

model

Exc. Do not focus on RE and VM of DSPLs

Exc. Not written in English

Exc. Out of the valid formats (papers from

conferences and journals)

Exc. Could not be accessed from UFC’s

network or by contacting authors

2.4 Data Extraction

The adopted approach for data extraction was based

on the work of Montagud et al. (Montagud et al.,

2012). For each research question was deﬁned some

values that could be the answers presented by the pa-

pers. It was done to make easy the extraction process.

The information to be extracted were: activities from

domain and context analysis, extracted from Capilla

et al. (Capilla et al., 2014b), involved roles, built

assets, variability representation, inconsistency treat-

ment, validation type and related adopted method, and

context use.

3 STUDIES CLASSIFICATION

The studies classiﬁcation process corresponds to the

conducting and review reporting phases of the SLR.

This process was done supported by four researchers

and made in 5 steps:

• Step 1: Perform string search on DLs and the

manual search;

• Step 2: Elimination of duplicated papers using the

StArt tool;

• Step 3: Title, Abstract and Keyword analysis of all

papers according to the inclusion/exclusion crite-

ria;

• Step 4: Full reading and analysis of the papers ac-

cording to the inclusion/exclusion criteria by the

researchers through pairs read;

• Step 5: Last check for duplicated papers iden-

tiﬁcation, and information extraction and quality

evaluation execution.

If during the classiﬁcation process of a paper a

nonconformity among the researchers happens, the

researchers are responsible for solving the conﬂict

and decide together if the paper would be eliminated

or not. An overview of this process is presented in

Figure 1. It is possible to see the number of returned

papers of each source and the number of selected pa-

pers after each step, respectively. Finally, after the

step ﬁve, the set of papers decreased to 37 papers that

were analysed again to extract the principal informa-

tion.

4 RESULTS

This section presents the SLR results from the 37 se-

lected work. The papers of our work were selected in

August/2015. Due to it some papers from important

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

546

Figure 1: Study selection process.

sources dated after august are not presented here. The

next subsections present each adopted research ques-

tion and their related results.

4.1 Papers Overview

Before the analysis of each research question is im-

portant to present an overview about the selected pa-

pers. Figure 2 presents the number of selected papers

along the years according to the three selection pro-

cess. According to Figure 2 is possible to see that the

oldest selected work in the 3rd selection dates from

2008. This means that the researches in DSPLs is

still a new research area. From 2011 the number of

selected papers per year is more regular varying be-

tween 4 and 7 papers.

Figure 2: Selected papers along the years.

About the papers use context, the majority (29)

was developed to academic ends, while 8 papers were

focused on the industrial area. It reinforces the idea

of DSPL is a new research area, but there are some

work that promote its use in industry. About the qual-

ity evaluation of the papers only one has the maximal

score 6 (S07), while the majority has a score between

3 and 5. Table 6 presents the the quality evaluation

of each paper.

4.2 Requirements Engineering and

Variability Management in DSPLs

Domain Engineering (RQ1)

The main research question aims to know how the re-

quirements engineering and variability management

are executed in DSPLs domain engineering. The re-

sults of each secondary question are presented as fol-

lows.

4.2.1 RQ1.1 What Activities of RE and VM are

used in DSPLs?

Table 2 shows the identiﬁed activities. As can

be seen, the activities are separated in three groups

(phases). The ﬁrst group brings the activities com-

monly used in the traditional software development,

domain analysis. The second group presents the activ-

ities of the context analysis. Some papers present the

activity Deﬁne operational rules of the domain analy-

sis phase that is related to the architecture modelling.

This kind of activity is commonly executed on the

project domain phase, like some papers execute. This

activity is attributed to the the second group, when it is

executed on the domain analysis phase, and attributed

to the third group, when a paper performs this activity

on the project domain phase. A ﬁnding is that the ac-

tivity Deﬁne multiple connection is executed only in

the project domain phase.

Although the papers present speciﬁc activities to

attend to the domain speciﬁcation, some details about

these activities execution were clearer in the section

of studies cases. However, the identiﬁed activities are

more related to requirements and variability model-

ing, and how the variability management is done at

design time and runtime. Activities about require-

ments elicitation are executed with fewer importance.

This question identiﬁed too the roles involved in

the activities, shown in Table 2. Just 9 papers present

the roles involved in their activities. Although the

roles are more involved in the project speciﬁcation

and modelling, there is not a clear deﬁnition about

the responsibilities of each one. For example, the de-

signers and the architects are responsible for model-

ing the DSPLs architecture, S05 and S09. The ana-

lysts are involved in the activities of modeling such as

identifying of features, S06 e S07. On the other hand,

the deﬁnition of the developer role just combines the

responsibilities of the other roles. It difﬁculties the

understanding about which roles are necessary to ex-

Requirements Engineering and Variability Management in DSPLs Domain Engineering: A Systematic Literature Review

547

Table 2: Result from the ﬁrst research question.

Domain Engineering

Domain Analysis Domain Project

Domain Analysis Context Analysis Domain Project

Activities Conception, Elicita-

tion, Speciﬁcation,

Validation

Identify physical properties, Identify context

features, Model context features, Deﬁne oper-

ational rules

Deﬁne operational rules,

Deﬁne multiple connection

Roles Analyst (S06, S07), Designer (S05, S06, S15, S16, S26, S35), Architect (S09), Developer (S31)

ecute each activity.

The identiﬁed activities are supported by some

tools. Most papers (64%) did not use tools to sup-

port their process or they did not mention it. The rest

of the papers use tools to project modelling as also to

verify the consistency and correctness of the models.

Table 3 presents the tools related to each purpose.

Table 3: Tools support.

Purpose Tools and Papers

Workﬂow rep-

resentation

BPMN (S10)

Variability

modelling

Fama (S02), MOSkitt4SPL

(S07), Atlas Model (S07),

BPMN (S10), Familiar (S26),

FeatureIDE (S26), eMoﬂon

(S8), Odyssey (S28), DOPLER

(S33), VariaMos (S36, S37)

Veriﬁcation

models

GNU Prolog (S07), Clafer

(S10), Familiar (S26), Vari-

aMos (S36, S37).

4.2.2 RQ1.2 What Approaches are used to

Document the Requirements in DSPLs?

Only 6 papers present approaches that are used to

document the requirements. The adopted approaches

vary of the use UML diagrams, class diagram and use

case (S13), sequence diagram (S15), approach that

does not support the concept of variability, until the

use of new approaches like Schemas (S25) and Goals

(S35). S01 and S05 organize the domain requirements

in feature model, but they do not present what ap-

proaches are used to transform the requirements, tex-

tual speciﬁcation, in features of the variability model.

4.2.3 RQ1.3 What Assets are Built of RE and

VM in DSPLs?

Table 4 presents all identiﬁed assets. The feature

model as also the context feature model represent the

assets with the higher frequency, 37% each one. The

feature model is used to represent the DSPLs variabil-

ity, as is used by traditional SPLs. The deference in

DSPLs is about the context feature model that joins

the context features, necessary to the reconﬁguration

process. The next more used model is the extended

feature model (6 papers), this model extends the fea-

ture model to support speciﬁc needs.

Table 4: Built Assets.

Assets Papers

Aspect model S23, S31

Base composi-

tion model and

Composition

model

S07

Base Model S10

Context feature

model

S01, S06, S07, S10, S11, S12,

S20, S22, S28, S29, S30, S32,

S34, S37

Extended

feature model

S05, S08, S10, S16, S18, S34

Feature model S01, S02, S03, S04, S07, S12,

S13, S20, S21, S26, S27, S28,

S32, S37

Feature model

adaptation

S01

Requirements

speciﬁcation

S13, S15, S25, S35

Rules adaptions S24

States machine S08

Weaving model S07, S10

4.2.4 RQ1.4 What Approaches are used to

Represent the DSPLs Variability?

The models used to represent the variability were: As-

pect model (S31), Actor model (S17), MVRP (S16),

OWL (S12), OCL (S04) and Feature Model (S01,

S02, S03, S07, S10, S11, S13, S14, S15, S19, S21,

S23, S26, S27, S28, S29, S34, S37).

The feature model represents the most used ap-

proach to represent the variability due to its use ﬂex-

ibility. This approach allows to change its own prop-

erties in order to attend the new use needs. Other con-

sideration about the feature model is that there is not a

pattern to represent the variability. For example, some

papers identify context features but the way to orga-

nize these information vary. Some put the context fea-

tures at the same feature model used to represent the

variability while others put it in a independent model.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

548

4.2.5 RQ1.5 What Approaches are used to

Support the Reconﬁguration Process in

DSPLs?

This question is related to the approaches that are used

to support the adaptability at runtime. This activity is

more related to the domain design. Table 5 presents

the results of this question.

Table 5: Approaches to reconﬁguration process.

Approaches Studies

Adaptation rules S07, S24

ECA S01, S02, S22, S27, S31, S32

MAPE-K S15, S36

MAPE S01, S35

Transformation rules S26

Aspect models S23

Context mapping S10

PrtNets S30

Contraint-satisfaction S21

ECA (Event-Condition-Action) approach is the

most widely used approach. ECA is based on rules

that are created from constraints of different sources,

such as the activity responsible for identifying oper-

ational rules (see subsection 4.2.1). The process of

specifying the adaptation rules through MAPE (Mon-

itor, Analyze, Plan and Execute) and MAPE-K (Mon-

itor, Analyze, Plan, Execute and Knowledge) follows

almost the same methodology for both. It is neces-

sary to identify how the context information would be

accessible, specifying the constraints that would be

responsible to decide to what new context the product

would change and what parts would be necessary to

support this new context.

4.2.6 RQ1.6 What Approaches are used to

Eliminate Possible Inconsistencies in

DSPLs Variability Model?

In DSPLs it is necessary to ensure that not only the

variability model at design time is consistent as also

the consistency of the model when a reconﬁgura-

tion happens. Although this consistency checking be

an important step to ensure and validate the require-

ments, only 12 papers mentioned it. Eight papers

(S07, S08, S10, S20, S22, S26, S28, S37) executed

checks just to ensure the adopted variability model did

not have inconsistencies. It was used tools to execute

this checking (the list of identiﬁed tools is presented

in Table 3).

Related to the papers that did checking at runtime

(S02, S05, S06, S08, S15), only speciﬁc papers (e.g.,

S08, S15) present the approaches they adopted. The

checking process followed the use of adaptation rules

and the application of algorithms that are responsible

for evaluating if a new conﬁguration has any incon-

sistencies or not. The other papers just cite they did it

but they did not present details about.

5 DISCUSSION

The domain engineering is responsible for exploring

the domain that the DSPL will support. The results of

this work show that DSPLs research has produced a

set of assets, tools and approaches to support the ac-

tivities necessary for DSPL requirements engineering

and variability management.

About the activities of domain analysis, we con-

cluded that the activities responsible for the domain

speciﬁcation and modeling have more importance that

the others, like conception and elicitation. Because

of it most papers do not specify formally the require-

ments domain. It goes against the domain analysis

goal. The same problem happens with the activities

of context analysis. The activities focus on the con-

texts identiﬁcation and modeling, while the activities

that treats the rules deﬁnition, responsible for identi-

ﬁcation of changes in a context, receives less impor-

tance. Still about domain analysis, we identiﬁed that

the papers do not present activities to support the re-

quirements changes as also do not present how the

changes are treated, when they happen.

A challenge about the reconﬁguration process is

to change the variability model at runtime when a re-

conﬁguration happens. Tools are used to check the

model structure and its consistence but it was not

identiﬁed yet a tool that supports this veriﬁcation at

runtime. Another important ﬁnding is about how

the non-functional requirements (NFR) are identiﬁed

and treated in domain engineering. Only one paper

(S15) treated this issue with the same importance that

functional requirements (FR) receive. The NFRs are

more related to the domain project, that is when the

architecture is modeled. Although this relation be-

tween the architecture modeling and the NFRs, it is

important that the activity of architecture modeling

receives the necessary information about the NFRs

from domain analysis instead to identify the motiva-

tions around them. Other ﬁnding about NFRs is how

the reconﬁguration process is done. The NFRs are not

considered by the papers in this process.

S09 is interested in evaluating the DSPLs quality

attributes but they just focused on the features model.

Evaluating the quality attributes in all DSPLs domain

engineering using others assets represents a new re-

search opportunity.

Requirements Engineering and Variability Management in DSPLs Domain Engineering: A Systematic Literature Review

549

6 THREATS TO VALIDITY

This section discusses threats that could have affected

the SLR results. We veriﬁed the threats were about

the construct validity. Construct validity is concerned

whether the treatments reﬂect the cause and the out-

come reﬂects the effect (Wohlin et al., 2012).

The ﬁrst possible threat is about the search string.

It needs to reﬂect the main objective of the study

otherwise would be returned work out of the study

area. We have tried to minimize it through successive

searches in DLs. As result, we veriﬁed that always

some important papers, that we knew before, were re-

turned (S06, S13). The second threat might have been

about the search process. We veriﬁed papers from im-

portant conferences dated from 2015 were not been

returned by the DLs. To solve this, we did a manual

search in the proceedings of these conferences

7 CONCLUSIONS AND FUTURE

WORK

This SLR aimed to determine how the requirements

engineering and variability management supports the

DSPLs domain engineering. To answer this question,

we identiﬁed relevant and current studies following a

formal approach. These studies were analyzed, eval-

uated and the information were extracted.

The results show the activities are concentrated on

DSPLs modeling and speciﬁcation. Traditional ap-

proaches (UML diagrams) can be used to document

the domain requirements as also the feature model,

that can be also used to represent the domain variabil-

ity. The assets built in the activities can be done using

tools responsible for modeling and consistence veriﬁ-

cation of them. We identiﬁed the following research

opportunities: modeling and treatment of NFRs still

in domain analysis; evaluating quality attributes using

assets different of variability models; a mechanism

to check the consistence and that be able to modify

the variability model at runtime; deﬁning a pattern to

represent the variability in DSPLs; and exploring ap-

proaches that can be used for eliciting the FRs.

As future work, we would like to determine ap-

proaches to support the found gaps and to deﬁne a

formal process for DSPLs RE and VM.

REFERENCES

Bencomo, N., Hallsteinsen, S., and Santana de Almeida, E.

(2012). A view of the dynamic software product line

landscape. Computer, 45(10):36–41.

Bosch, J., Capilla, R., and Hilliard, R. (2015). Trends

in systems and software variability. IEEE Software,

(3):44–51.

Capilla, R., Bosch, J., Trinidad, P., Ruiz-Cort

es, A., and

Hinchey, M. (2014a). An overview of dynamic soft-

ware product line architectures and techniques: Ob-

servations from research and industry. Journal of Sys-

tems and Software, 91:3–23.

Capilla, R., Ortiz, O., and Hinchey, M. (2014b). Con-

text variability for context-aware systems. Computer,

(2):85–87.

da Silva, J. R. F., Pereira da Silva, F. A., do Nascimento,

L. M., Martins, D. A., and Garcia, V. C. (2013). The

dynamic aspects of product derivation in dspl: A sys-

tematic literature review. In Information Reuse and

Integration (IRI), 2013 IEEE 14th International Con-

ference on, pages 466–473. IEEE.

Guedes, G., Silva, C., Soares, M., and Castro, J. (2015).

Variability management in dynamic software product

lines: A systematic mapping. In Components, Ar-

chitectures and Reuse Software (SBCARS), 2015 IX

Brazilian Symposium on, pages 90–99. IEEE.

Hallsteinsen, Svein andHinchey, M., Park, S., and Schmid,

K. (2008). Dynamic software product lines. Com-

puter, 41(4):93–95.

Hinchey, M., Park, S., and Schmid, K. (2012). Building

dynamic software product lines. Computer, (10):22–

26.

Keele, S. (2007). Guidelines for performing systematic lit-

erature reviews in software engineering. In Technical

report, Ver. 2.3 EBSE Technical Report. EBSE.

Kitchenham, B., Brereton, O. P., Budgen, D., Turner, M.,

Bailey, J., and Linkman, S. (2009). Systematic litera-

ture reviews in software engineering–a systematic lit-

erature review. Information and software technology,

51(1):7–15.

Kitchenham, B., Mendes, E., and Travassos, G. H. (2006).

A systematic review of cross-vs. within-company cost

estimation studies. In Proceedings of the 10th inter-

national conference on Evaluation and Assessment in

Software Engineering, pages 81–90. British Computer

Society.

Montagud, S., Abrah

ao, S., and Insfran, E. (2012). A

systematic review of quality attributes and measures

for software product lines. Software Quality Journal,

20(3-4):425–486.

Northrop, L., Clements, P., Bachmann, F., Bergey, J.,

Chastek, G., Cohen, S., Donohoe, P., Jones, L., Krut,

R., Little, R., et al. (2007). A framework for soft-

ware product line practice, version 5.0. SEI.–2007–

http://www. sei. cmu. edu/productlines/index. html.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

550

APPENDIX

Table 6: Quality evaluation of the studies.

ID Reference Quality

Score

S01 L. Shen, X. Peng, and W. Zhao. Software product line engineering for developing self-adaptive systems: Towards the domain requirements. In Computer

Software and Applications Conference (COMPSAC), 2012 IEEE 36th Annual.

4,25

S02 A. S. Nascimento, C. M. Rubira, and F. Castor. Arcmape: A software product line infrastructure to support fault-tolerant composite services. In High-

Assurance Systems Engineering (HASE), 2014 IEEE 15th International Symposium.

3,25

S03 D. Dermeval, T. Tenorio, I. I. Bittencourt, A. Silva, S. Isotani, and M. Ribeiro. Ontology-based feature modeling: An empirical study in changing scenarios.

Expert Systems with Applications, 42(11):4950–4964, 2015.

3,75

S04 C. Dubslaff, C. Baier, and S. Kluppelholz. Probabilistic model checking for feature-oriented systems. In Transactions on Aspect-Oriented Software

Development XII, pages 180–220. Springer, 2015.

3,5

S05 R. Mizouni, M. A. Matar, Z. Al Mahmoud, S. Alzahmi, and A. Salah. A framework for context-aware self-adaptive mobile applications spl. Expert

Systems with applications, 41(16):7549–7564, 2014.

5,25

S06 R. Capilla, J. Bosch, P. Trinidad, A. Ruiz-Cortes, and M. Hinchey. An overview of dynamic software product line architectures and techniques: Observa-

tions from research and industry. Journal of Systems and Software, 91:3–23, 2014.

4,5

S07 G. H. Alferez, V. Pelechano, R. Mazo, C. Salinesi, and D. Diaz. Dynamic adaptation of service compositions with variability models. Journal of Systems

and Software, 91:24–47, 2014.

S08 J. Burdek, S. Lity, M. Lochau, M. Berens, U. Goltz, and A. Schurr. Staged conﬁguration of dynamic software product lines with complex binding time

constraints. In Proceedings of the Eighth International Workshop on Variability Modelling of Software-Intensive Systems, page 16. ACM, 2014.

4,25

S09 L. E. S

anchez, J. A. Diaz-Pace, A. Zunino, S. Moisan, and J.-P. Rigault. An approach for managing quality attributes at runtime using feature models. In

Software Components, Architectures and Reuse (SBCARS), 2014 Eighth Brazilian Symposium on, pages 11–20.

3,75

S10 A. Murguzur, X. De Carlos, S. Trujillo, and G. Sagardui. Context-aware staged conﬁguration of process variants@ runtime. In Advanced Information

Systems Engineering, pages 241–255. Springer, 2014.

4,75

S11 K. Saller, M. Lochau, and I. Reimund. Context-aware dspls: model-based runtime adaptation for resource-constrained systems. In Proceedings of the 17th

International Software Product Line Conference co-located workshops, ACM, 2013.

3,75

S12 C. Cetina, P. Giner, J. Fons, and V. Pelechano. Prototyping dynamic software product lines to evaluate run-time reconﬁgurations. Science of Computer

Programming, 78(12):2399–2413, 2013.

4,25

S13 F. G. Marinho, R. M. Andrade, C. Werner, W. Viana, M. E. Maia, L. S. Rocha, E. Teixeira, J. B. Ferreira Filho, V. L. Dantas, F. Lima, et al. Mobiline: A

nested software product line for the domain of mobile and context-aware applications. Science of Computer Programming, 78(12):2381–2398, 2013.

4,25

S14 I. Kumara, J. Han, A. Colman, T. Nguyen, and M. Kapuruge. Sharing with a difference: realizing service-based saas applications with runtime sharing and

variation in dynamic software product lines. In Services Computing (SCC), 2013 IEEE International Conference on, pages 567–574.

3,25

S15 C. Ghezzi and A. M. Shariﬂoo. Dealing with non-functional requirements for adaptive systems via dynamic software product-lines. In Software Engineer-

ing for Self-Adaptive Systems II, pages 191–213. Springer, 2013.

5,25

S16 L. Jean-Baptiste, S. Maria-Teresa, G. Jean-Marie, and B. Antoine. Modeling dynamic adaptations using augmented feature models. In Proceedings of the

28th Annual ACM Symposium on Applied Computing, pages 1734–1741. ACM, 2013.

4,25

S17 H. Sabouri and R. Khosravi. Modeling and veriﬁcation of reconﬁgurable actor families. JUCS, 19(2):207–232, 2013. 3,25

S18 D. Kramer, C. Sauer, and T. Roth-Berghofer. Towards explanation generation using feature models in software product lines. Knowledge Engineering and

Software Engineering (KESE), page 13, 2013.

4,25

S19 V. T. Sarinho, A. L. Apolinario, and E. S. de Almeida. Oofm-a feature modeling approach to implement mpls and dspls. In 2012 IEEE 13th International

Conference on Information Reuse & Integration (IRI), 2012.

2,25

S20 F. G. Marinho, P. H. Maia, R. Andrade, V. M. Vidal, P. A. Costa, and C. Werner. Safe adaptation in context-aware feature models. In Proceedings of the

4th International Workshop on Feature-Oriented Software Development, ACM, 2012.

4,25

S21 C. Parra, D. Romero, S. Mosser, R. Rouvoy, L. Duchien, and L. Seinturier. Using constraint-based optimization and variability to support continuous

self-adaptation. Proceedings of the 27th ACM Symposium on Applied Computing, 2012.

S22 F. G. Marinho, R. Andrade, and C. Werner. A veriﬁcation mechanism of feature models for mobile and context-aware software product lines. In Software

Components, Architectures and Reuse (SBCARS), 2011 Fifth Brazilian Symposium on.

4,25

S23 C. Parra, X. Blanc, A. Cleve, and L. Duchien. Unifying design and runtime software adaptation using aspect models. Science of Computer Programming,

76(12):1247–1260, 2011.

3,75

S24 M. Rosenmuller, N. Siegmund, M. Pukall, and S. Apel. Tailoring dynamic software product lines. In ACM SIGPLAN Notices, volume 47, pages 3–12.

ACM, 2011.

3,25

S25 J. Dehlinger and R. R. Lutz. Gaia–pl: a product line engineering approach for efﬁciently designing multiagent systems. ACM Transactions on Software

Engineering and Methodology (TOSEM), 20(4):17, 2011.

S26 M. Acher, P. Collet, P. Lahire, S. Moisan, and J.-P. Rigault. Modeling variability from requirements to runtime. In Engineering of Complex Computer

Systems (ICECCS), 2011 16th IEEE International Conference on, pages 77–86.

4,5

S27 L. Shen, X. Peng, J. Liu, and W. Zhao. Towards feature-oriented variability reconﬁguration in dynamic software product lines. In Top Productivity through

Software Reuse, pages 52–68. Springer, 2011.

3,75

S28 P. Fernandes, C. Werner, and E. Teixeira. An approach for feature modeling of context-aware software product line. J. UCS, 17(5):807–829, 2011. 4

S29 Z. Jaroucheh, X. Liu, and S. Smith. Mapping features to context information: Supporting context variability for context–aware pervasive applications. In

Web Intelligence and Intelligent Agent Technology, 2010, International Conference on.

3,75

S30 Z. Jaroucheh, X. Liu, and S. Smith. Candel: product line based dynamic context management for pervasive applications. In Complex, Intelligent and

Software Intensive Systems (CISIS), 2010 International Conference on, pages 209–216.

S31 T. Dinkelaker, R. Mitschke, K. Fetzer, and M. Mezini. A dynamic software product line approach using aspect models at runtime. In 5th Domain-Speciﬁc

Aspect Languages Workshop, 2010.

4,5

S32 M. Acher, P. Collet, F. Fleurey, P. Lahire, S. Moisan, and J.-P. Rigault. Modeling context and dynamic adaptations with feature models. In 4th International

Workshop Models@ run. time at Models 2009 (MRT’09), page 10, 2009.

3,25

S33 R. Wolﬁnger, S. Reiter, D. Dhungana, P. Grunbacher, and H. Prahofer. Supporting runtime system adaptation through product line engineering and plug-in

techniques. In Composition-Based Software Systems, 2008, Seventh International.

S34 R. Capilla, M. Hinchey, and F. J. Daz. Collaborative context features for critical systems. In Proceedings of the Ninth International Workshop on Variability

Modelling of Software-intensive Systems, page 43. ACM, 2015.

3,5

S35 J. C. Mu

noz-Fern

andez, G. Tamura, I. Raicu, R. Mazo, and C. Salinesi. Refas: a ple approach for simulation of self-adaptive systems requirements.

Proceedings of the 19th International Conference on Software Product Line, ACM, 2015.

4,25

S36 N. Abbas and J. Andersson. Harnessing variability in product-lines of self-adaptive software systems. In Proceedings of the 19th International Conference

on Software Product Line, pages 191–200. ACM, 2015.

2,25

S37 R. Mazo, J. C. Mu

noz-Fern

andez, L. Rincon, C. Salinesi, and G. Tamura. Variamos: an extensible tool for engineering (dynamic) product lines. Proceedings

of the 19th International Conference on Software Product Line. ACM, 2015.

3,5

Requirements Engineering and Variability Management in DSPLs Domain Engineering: A Systematic Literature Review

551
