Ontology Matching based on Multi-Aspect Consensus Clustering of
Communities
André Ippolito and Jorge Rady de Almeida Júnior
Computer and Digital Systems Department, Polytechnic School of University of São Paulo,
Avenida Professor Luciano Gualberto, n.º 158, São Paulo, Brazil
Keywords: Ontology Matching, Aspect, Consensus Clustering, Bayesian Cluster Ensembles, Community Detection.
Abstract: With the increase in the number of existing ontologies, ontology integration becomes a challenging task. A
fundamental step in ontology integration is ontology matching, which is the process of finding
correspondences between elements of different ontologies. For large-scale ontology matching, some authors
developed a divide-and-conquer strategy, which partitions ontologies, clusters similar partitions and restricts
the matching process to ontology elements of similar partitions. Works related to this strategy considered only
a single ontology aspect for clustering. In this paper, we proposed a solution for ontology matching based on
Bayesian Cluster Ensembles (BCE) of multiple aspects of ontology partitions. We partition ontologies
applying Community Detection techniques. We believe that BCE of multiple aspects of ontology partitions
can provide an ontology clustering that is more precise than the clustering of a single aspect. This can result
in a more precise matching.
1 INTRODUCTION
In the World Wide Web (WWW), developers create
web pages with information that humans can
interpret. Nevertheless, the underlying meaning of the
information is not sufficiently explicit to be machine-
interpretable. In order to overcome this difficulty, the
World Wide Web Consortium (W3C) is developing
technologies related to the Semantic Web, an
extension of the WWW, in which information
semantics of a domain becomes explicit with the use
of ontologies. Ontologies are formal specifications
about a knowledge domain, with logical descriptions
about real-world entities, which enable the inference
of rules. The Linked Open Data (LOD) Project
specifies the best practices in the publication of
ontologies. Recent statistics (Schmachtenberg, Bizer
and Paulheim, 2014) indicate an increase in the
number of published ontologies in the LOD Cloud,
related to a wide range of domains, e.g. Government,
Life Sciences, User-generated Content, Media and
Social Web.
With the progressive number of existing
ontologies, developed with different patterns, thus
increasing heterogeneity, ontology integration
becomes challenging. Ontology integration is
necessary when enterprises need to do a merge or an
acquisition, for example, because they have to
integrate their heterogeneous ontologies into a single
one. Ontology matching is the first step before
merging the ontologies and is the process of finding
correspondent elements in different ontologies. The
set of correspondences is the ontology alignment.
Euzenat and Shvaiko (2013) highlight a divide-and-
conquer strategy for large-scale ontology matching.
Given two ontologies, this strategy fragments both
ontologies in partitions and clusters similar partitions
of the two ontologies. The final step is the matching
process, which compares only the elements of the two
ontologies that belong to the same cluster. According
to Euzenat and Shvaiko (2013), the goal of this
strategy is to improve the matching efficiency,
avoiding the comparison of all ontology elements.
Algergawy, Massmann and Rahm (2011) and
Moawed et al. (2015) developed clustering-based
solutions for ontology matching. To cluster ontology
partitions, these authors considered the
terminological content (terms of labels and
annotations) of ontology elements of the partitions
and applied document clustering techniques.
However, these works did not explore other ontology
aspects, e.g. instance-based aspect, in the clustering
phase, which can help to increase the number of
correct clusters and correct matching
correspondences.
Ippolito, A. and Júnior, J.
Ontology Matching based on Multi-Aspect Consensus Clustering of Communities.
In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 2, pages 321-326
ISBN: 978-989-758-187-8
Copyright
c
2016 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
321
In this work, we propose a solution for ontology
matching that initially partitions two ontologies using
Community Detection techniques (Fortunato, 2010).
In the sequence, we consider three different aspects
of the ontology partitions: terminological content,
topological features and instance-based aspect, also
known as extensional aspect. For each aspect, we
apply Independent Component Analysis (ICA)
(Honkela, Hyvärinen and Väyrynen, 2010) for
dimensionality reduction. ICA is a technique inspired
in the problem of blind signal separation that applies
linear transformations on data to obtain statistically
independent components, reducing data to its most
relevant features. After applying ICA, we cluster
ontology partitions according to each aspect,
considered separately, and find a consensus clustering
applying Bayesian Cluster Ensembles (BCE) (Wang,
Shan and Banerjee, 2011). Finally, we match classes
and properties of ontology partitions that belong to
the same consensual cluster.
This paper has the following structure: in section
2, we explain BCE; in section 3, we review the related
works; in section 4, we explain our methods; in
section 5, we outline the expected results. Since this
work is an ongoing project, we plan to present its
results and conclusions in future publications.
2 BAYESIAN CLUSTER
ENSEMBLES
Cluster Ensembles techniques combine clustering
solutions (base clusterings), obtained by different
algorithms, into a consensual clustering, which
captures different assumptions of the algorithms,
making the solution more accurate and more robust
(Wang, Shan and Banerjee, 2011).
In BCE, given n data points to be clustered, Wang,
Shan and Banerjee (2011) assume that each data point
participates in all consensual clusters, in different
proportions, given by probabilities. BCE is based on
a probabilistic generative process, which considers
that the consensual clusters generate the base
clusterings. Figure 1 illustrates the generative process
of BCE. Matrix B represents the base clusterings and
matrix C refers to the consensual clusters. In matrix
B, the lines represent seven data points, given by x
i
(i
= 1,…,7). There are three base clusterings, given by
λ
i
, which are the columns of B. The entries of B are
the base clusterings’ labels. In the generative process,
these labels are drawn from probabilistic distributions
related to the consensual clusters (matrix C). The
labels of the base clusterings follow discrete
distributions.
In the example of figure 1, let us consider that λ
1
for x
1
was generated by the consensual cluster 2.
Then, according to column 1 and line 2 of C, we have
a probability of 0.1 that x
1
is in cluster 1. Following
the same discrete distribution, the probability that x
1
is in cluster 2 is 0.1 and the probability of x
1
being in
cluster 3 is 0.8. Given that 0.8 is the highest
probability for λ
1
(column 1 of C), considering the
two consensual clusters, we conclude that the
consensual cluster 2 generated x
1
and that x
1
has label
3.
The goal of BCE is to infer the consensus
clustering with Bayesian Inference, such that the base
clusterings are the observed data. As figure 1 shows,
the inference process of BCE follows the inverse
direction of the generative process. BCE infers the
degree of membership Ɵ of each data point to the
consensual clusters and infers the consensual label z
assigned to the data points, considering α and β as
probabilistic parameters of the model. Wang, Shan
and Banerjee (2011) made an experiment with
scientific datasets to compare BCE to other Cluster
Ensembles techniques and clustering algorithms, e.g.
Hypergraph Partitioning Algorithm and K-means.
Wang, Shan and Banerjee (2011) measured the
clustering accuracy, considering the number of data
points correctly assigned to a cluster, based on a gold
standard. BCE outperformed the other techniques and
algorithms in most of the cases.
3 RELATED WORKS
Algergawy, Massmann and Rahm (2011) and
Moawed et al. (2015) used the Vector Space Model
(VSM) (Manning, Raghavan and Schütze, 2009) and
clustered ontology partitions solely based on their
terminological content, not considering different
aspects that partitions have. Considering multiple
aspects for clustering can help finding additional
correct clusters, which can increase the number of
similar ontology elements grouped in the same
cluster, helping to improve the precision of the
matching results.
Ferrara et al. (2015) found a consensus clustering
based on the co-occurrence of ontology elements in
the same cluster in different clustering solutions.
Ferrara et al. (2015) did not apply BCE, which can
provide more accurate clustering results than other
Cluster Ensembles techniques (Wang, Shan and
Banerjee, 2011). This accuracy can improve the
ontology clustering result, influencing on the
ontology alignment by increasing its precision.
ICEIS 2016 - 18th International Conference on Enterprise Information Systems
322
Figure 1: Bayesian Cluster Ensembles.
Moawed et al. (2015) applied Latent Semantic
Analysis (LSA) (Landauer, Foltz and Laham, 1998)
for dimensionality reduction. However, according to
Honkela, Hyvärinen and Väyrynen (2010), ICA was
able to reveal more relevant features in document
collections than LSA. We intend to extend the results
of ICA to ontologies, by finding more relevant terms
also in ontology partitions.
Thus, we propose a solution that applies BCE and
ICA with the goal of bridging the gaps of the related
works.
4 METHODS
Our proposed solution (figure 2) has four steps:
community detection to partition the ontologies into
communities; community clustering based on
multiple aspects; consensus clustering of multiple
aspects with BCE; matching ontology elements of
consensual clusters.
4.1 Community Detection to Partition
the Ontologies into Communities
In the first step, we take two different ontologies O
and O’ for matching and consider each ontology
structure as a graph, using one of the approaches of
Coskun et al. (2011): subjects and objects of each
ontology correspond to nodes and predicates
correspond to edges. We partition each of the
ontology graphs into communities applying the
Community Detection algorithms that had the most
accurate clustering results in the study of Coskun et
al. (2011): Random Walks, Fast Greedy Algorithm
and Potts Model (Fortunato, 2010).
We evaluate the community structure obtained by
each of the algorithms using the modularity function
(Fortunato, 2010). Modularity measures the
difference between a community structure and the
structure of a random graph, i.e. a graph with edges
placed at random. The higher the modularity, the
better the community structure is. For each ontology
graph, we choose the set of communities given by the
algorithm that provides the highest modularity. Let e
ii
be the fraction of ends of edges that belong to the
same community i. Let b
i
be the fraction of edges
whose ends belong to different communities. The
modularity Q is:
Q =
(e
iii
- b
i
2
)
(1)
4.2 Community Clustering based on
Multiple Aspects
In the second step, we consider each ontology
community according to three different aspects:
terminological, topological and extensional. For each
aspect, we first model the ontology communities
according to their features, calculate distances
between communities and then cluster the
communities based on their distances.
4.2.1 Model and Distances for the
Terminological Aspect
For the terminological aspect, we extract terms of
labels and annotations of ontology elements of each
community, considering a community as a document.
Then we apply removal of stop words, stemming,
tokenization and use the VSM for modelling the
Ontology Matching based on Multi-Aspect Consensus Clustering of Communities
323
Figure 2: Overview of the proposed solution.
communities. We apply ICA for dimensionality
reduction and obtain the distances that are the input
for the clustering algorithms using the cosine distance
(Manning, Raghavan and Schütze, 2009). Let c1 and
c2 be two ontology communities and v
c1
and
v
c2
be its vectors representations in the VSM. The
cosine distance CD between c1 and c2 is:
CD
c1,c2
=1-
v
c1
.v
c2
|v
c1
|
|
v
c2
|
(2)
4.2.2 Model and Distances for the
Topological Aspect
For the topological aspect, we represent the topology
of each community based on three features (Albert
and Barabási, 2002): global clustering coefficient,
average path length and the exponent of the power
law. We calculate the distances based on these
features, applying the Euclidean distance (Manning,
Raghavan and Schütze, 2009).
Let k
i
be the number of edges connecting a given
node i to its neighbours and let E
i
be the number of
edges between the neighbours of i. The local
clustering coefficient of i, denoted by LCC
i
, is given
by (3). The global clustering coefficient GCC of a
community is the average of the LCC
i
of the nodes of
the community.
LCC
i
=
2E
i
i
(
i
-1)
(3)
Given a community with N nodes and K edges,
the average path length L is:
L =
ln (N)
ln
(
K
)
(4)
Given a random node i of a graph, the probability
P(k) of i having k edges is given by the power law as
in (5), where γ is the exponent of the power law:
P(k) = k
-
γ
(5)
Let c1 and c2 be two communities with d features,
whose values are given by c1
z
and c2
z
respectively,
with z = 1,…,d. The Euclidean Distance ED is:
ED(c1,c2) = (
|c1
z
- c2
z
|
z
2
)
1/2
(6)
4.2.3 Model and Distances for the
Extensional Aspect
For the extensional aspect, we model each
community considering each of its distinct concepts
as a different dimension whose value is the number of
its instances. We use ICA for dimensionality
reduction and apply an extension of the distance
developed by Hu et al. (2006) to calculate distances
between ontology communities.
Hu et al. (2006) developed a distance for
ontologies based on the Kullback-Leibler distance.
Hu et al. (2006) defined a probability based on the
distance (C
k
), which is a distance between a concept
C
k
and an ideal concept C
o
that instantiates infinite
objects. Hu et al. (2006) calculate a concept
restriction as the inverse of the number of its instances
and use the difference between concept restrictions to
calculate distances between concepts. Given (C
k
)
and (C
j
), with jk, Hu et al. (2006) formulated an
ICEIS 2016 - 18th International Conference on Enterprise Information Systems
324
equation for the probability P(C
k
):
P(C
k
) =
1 - (C
k
)
(1 -
(C
j
))
j
(7)
Considering P(C
k
), Hu et al. (2006) defined the
distance ΔJ between two ontologies O and O’, with
concepts C
i
and C’
i
respectively:
ΔJ
=
P
C
i
log
P(C
i
)
P(C'
i
)
i
+
P
C'
i
log
P(C'
i
)
P(C
i
)
i
(8)
For the distances, we also ponder the common
instances of a pair of .ontology communities. Let cmi
be the number of common instances of two ontology
communities and let ti be the total number of
instances of the two communities. The distance ΔI
based on the common instances is given by (9) and
we apply the average of (8) and (9) to obtain the
distance between two given communities of different
ontologies.
ΔI =1-
cmi
ti
(9)
4.2.4 Community Clustering of each Aspect
For each aspect, we consider its respective distances
between pairs of ontology communities. Based on the
distances, we apply the following clustering
algorithms: Single-link, Complete-link, Unweighted
Pair Group Method with Arithmetic Mean, Ward’s
Method, Divisive Analysis, Partitioning Around
Medoids, Expectation Maximization and K-Means.
Thus, we have eight clustering results for each aspect
and we choose the best clustering result, such that we
have only one clustering result for each aspect.
4.2.5 Selection of the Clustering Result of
Each Aspect
For each aspect, we compare the eight clustering
results based on the silhouette width (Rousseeuw,
1987), which is a measure that considers the
separation between different clusters and the degree
of compactness of a cluster. Let a
i
be the average
distance between an element i and all the elements of
the same cluster of i and let b
i
be the average distance
between element i and the elements of the nearest
cluster. The silhouette width S is given by (10). For
each aspect, we select the clustering result with the
highest silhouette width. These selected clustering
results are the input for the next step.
S =
i
-a
i
max
(
i
,a
i
)
(10)
4.3 BCE of Multiple Aspects
In the third step, we take the selected clustering result
of each aspect and apply BCE to find a consensus
clustering. The selected clustering results are the
observed data, based on which we infer the consensus
clustering using BCE.
4.4 Matching between Ontology
Elements of Consensual Clusters
In the fourth step, we apply matching techniques to
the ontology classes and properties of ontology
communities of the same consensual cluster. We plan
to use syntactic, structural and semantic techniques,
comparing the matching results to a benchmark,
publicly available on the web or provided by experts.
Given an alignment A and a benchmark result B, we
evaluate the matching result with regard to recall (R),
precision (P) and F-measure (F) (Euzenat and
Shvaiko, 2013):
R(A,B) =
|BA|
|B|
(11)
P(A,B) =
|BA|
|A|
(12)
F(A,B) =
2PR
P + R
(13)
5 EXPECTED RESULTS
According to Wang, Shan and Banerjee (2011), BCE
provided a more accurate clustering than the
clustering obtained by other algorithms applied
separately. We believe that we can extend these
results to ontologies, with BCE of multiple ontology
aspects providing a more precise ontology clustering
than the clustering of each ontology aspect. In our
comparative evaluation, we plan to apply the
silhouette width to compare the ontology clustering
result of BCE with the clustering results of each
ontology aspect.
A more precise ontology clustering of BCE can
imply in more ontology elements grouped together
that are similar, which can result in a more precise
matching. We plan to compare the matching metrics
(recall, precision and F-measure) that result from the
use of BCE with the matching metrics that result from
the clustering of each aspect.
Since BCE finds a consensus among different
clustering solutions, BCE tends to find fewer clusters
Ontology Matching based on Multi-Aspect Consensus Clustering of Communities
325
than the sum of clusters of all clustering solutions. In
the divide-and-conquer strategy, less clusters imply in
less comparisons during the matching process. We
plan to compare the number of matching comparisons
that results from the use of BCE with the number of
comparisons that results from the union of clusters of
all aspects.
To illustrate the potential contributions of our
approach, let us consider two ontologies, O and O’,
and two ontology communities, co and co’, taken
from O and O’ respectively. Let us also consider that
co has a concept C labelled “Creator” and that co’ has
a concept C’ with the label “Author”. C and C’ are
semantically correspondent concepts. Communities
co and co’ have common instances and approximate
exponents of the power law.
Clustering the terminological aspect tend not to
cluster co and co’, because labels’ strings of C and C’
are not similar. Nevertheless, the extensional and the
topological similarities of co and co’ contribute to
group co and co’ together. The reduced distances
between co and co’, due to their similarities, increase
the silhouette width. Grouping co with co’ implies in
grouping concepts C and C’, thus helping to increase
the matching metrics.
Let us also consider that the community clustering
based on the three aspects results in ten clusters and
that BCE finds five consensual clusters. Then, we
match the elements of five clusters instead of ten
clusters, contributing to reduce the number of
comparisons in the matching process.
REFERENCES
Albert, R., Barabási, A., 2002. Statistical Mechanics of
Complex Networks. In Reviews of Modern Physics 74,
47. arXiv:cond-mat/0106096.
Algergawy, A., Massmann, S., Rahm, E., 2011. A
Clustering-Based Approach for Large-Scale Ontology
Matching. In Advances in Databases and Information
Systems, vol. 6909, pp. 415-428.
Coskun, G., Rothe, M., Teymourian, K., Paschke, A., 2011.
Applying Community Detection Algorithms on
Ontologies for Identifying Concept Groups. In
WOMO’11, 5
th
International Workshop on Modular
Ontologies. IOS Press.
Euzenat, J., Shvaiko, P., 2013. Ontology Matching.
Springer, 2
nd
edition.
Ferrara, A., Genta, L., Montanelli, S., Castano, S., 2015.
Dimensional Clustering of Linked Data: Techniques
and Applications. In Transactions on Large-Scale Data
and Knowledge-Centered Systems XIX, pp. 55-86.
Fortunato, S., 2010. Community Detection in Graphs. In
Physics Reports 486 (3), pp. 75-174.
Honkela, T., Hyvärinen, A., Väyrynen, J. J., 2010.
WordICA - Emergence of Linguistic Representations
for Words by Independent Component Analysis. In
Natural Language Engineering (16), pp. 277–308.
Hu, B., Kalfoglou, Y., Alani, H., Dupplaw, D., Lewis, P.,
Shadbolt, N., 2006. Semantic Metrics. In: EKAW’06.
15
th
International Conference on Knowledge
Engineering and Knowledge Management. Springer.
Landauer, T. K., Foltz, P.W., Laham, D., 1998. Introduction
to Latent Semantic Analysis. In Discourse Processes
(25), pp. 259-284.
Manning, C. D., Raghavan, P., Schütze, H., 2009. An
Introduction to Information Retrieval. Cambridge
Press.
Moawed, S. Algergawy, A., Sarhan, A., Eldosouky, A.,
Saake, G., 2015. Improving Clustering-Based Schema
Matching Using Latent Semantic Indexing. In
Transactions on Large-Scale Data and Knowledge-
Centered Systems XV, pp. 102-123.
Rousseeuw, P. J., 1987. Silhouettes: a Graphical Aid to the
Interpretation and Validation of Cluster Analysis. In
Journal of Computational and Applied Mathematics,
vol. 20, pp.53-65.
Schmachtenberg, M., Bizer, C., Paulheim, H., 2014. State
of the LOD Cloud 2014. University of Mannheim.
Wang, H., Shan, H., Banerjee, A., 2011. Bayesian Cluster
Ensembles. In Statistical Analysis and Data Mining:
The ASA Data Science Journal, vol. 4, pp. 54-70. Wiley
Periodicals.
ICEIS 2016 - 18th International Conference on Enterprise Information Systems
326
