Identification and Correction of Misspelled Drugs’ Names in

Electronic Medical Records (EMR)

Faiza Hussain and Usman Qamar

Department of Computer Engineering, College of E&ME, National University of Sciences and Technology (NUST),

H-12 Islamabad, Pakistan

Keywords: Spelling Correction, Electronic Medical Record, EMR, Natural Language Processing, Text Mining,

Information Retrieval, POST, Parts-of-Speech Tagging, Regular Expressions and Medical Text Processing.

Abstract: Medications are an important element of medical records but they usually contain significant data errors.

This situation may result from haphazardness or possibly careless storage of valuable information. In either

case, this misspelled data can cause serious health problems for the patients and can put their life at a major

risk. Thus, the correctness of medication data is an important aspect so that potential harms can be identified

and steps can be taken to prevent or mitigate them. In this paper, a novel and practical method is proposed

for automated detection and correction of spelling errors in electronic medical record (EMR). To realize this

technique, major relevant aspects is taken into consideration with the help of Parts-of-Speech tagging and

Regular Expressions. The paper concludes with recommendations and future work for giving a new

direction to the emendation of drug nomenclature.

1 INTRODUCTION

Processing medical texts is an emerging topic in

natural language processing, especially in English.

As it holds an immense amount of biomedical data

which every person accumulates over a lifetime. A

medical record can be divided into five major

portions i.e. medical history, laboratory, diagnostic

test results, patient’s condition and therapeutic

response, potential side effects, and drugs dosage

and treatment notes (Wagner, et al., 1996).

Prescribers may use this format as a procedure for

their documentation but may use another format

according to their own ease (Spooner, Linda, and

Kimberly, 2013). Clinicians can also write

additional information sometimes such as progress

notes, or correspondence etc.

Nowadays, to ease the work of pharmacists, a

variety of electronic systems are used to record

health information of patients. A primary goal of

these systems is to get simple yet important and

complete data enough for a doctor’s needs. There are

numerous benefits of the systematic data collection

such as it allows to regularly organize information of

patients in a decent manner and also allows to

transfer history and records of a patient to another

pharmacist (Spooner, Linda, and Kimberly, 2013).

Electronic medical record system (EMR) is one of

the methods to automatically record health-related

information of an individual that can be generated,

collected, managed, and used by clinicians,

researchers, managers, process- improvement teams,

and decision-support systems (Wagner, et al., 1996).

Despite many benefits, general implementation

of EMRs in the United States is very low; the latest

study showed that only 4% of doctors use a fully

functional EMR while 13%have a simple electronic

system (DesRoches CM, et al., 2008).The typical

cause is these clinical records are created in a rush

without any prooﬁ ng. Consequently, a large number

of spelling errors are resulted especially a wide

variety of data entry errors occur. These errors not

only originate because of the complexity of the

English language but also due to characteristics of

the medical domain. (Siklósi et al., 2016)

investigated the most frequent types of errors are the

unintentional mistyping, grammatical errors,

sentence fragments, and non-standardized

abbreviations.

It is self-evident that the correctness of such

information is important (Richard Pless, 2004).

Also, many researchers concluded that accurate

medication data is the need of the hour such as

(Price, D., et al., 1986) found 70 percent omissions

Hussain, F. and Qamar, U.

Identiﬁcation and Correction of Misspelled Drugs’ Names in Electronic Medical Records (EMR).

In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 2, pages 333-338

ISBN: 978-989-758-187-8

333

in dosages of patients and 46 percent were taking

medicines that were not recommended by their

doctor. (Monson and Bond, 1978) assessed 355

patients and also attained the same percentage of

errors in dose i.e. 70%.

Thus, these errors support us for the

improvement of EMR (medication) data as its

accuracy is an important factor for patient’s health.

In this research, we proposed a methodology for the

identification of errors in medication data and used

them to increase the accuracy of medication data

through correction of misspelled terms in Electronic

Medical Records. The data accuracy describes data

along two dimensions i.e. correctness and

completeness (Wagner, et al., 1996). Correctness is

the main concern according to the guidelines

provided by Wiederholt and Perrault (Shortliffe, et

al., 1990).

There are some issues that are considered while

proposing a novel technique. Firstly, all the fields of

an individual’s record are not important, some fields

are optional, and some are not useful in correcting of

medication data. So, it is a prerequisite for choosing

an appropriate subset of fields. Another issue is to

understand the meaning of a medication record. In

simple words, there are two kinds of useful data are

recorded i.e. doctors instruct the patient what to do

and what the patient is feeling and taking (Wagner,

et al., 1996). Thirdly, the modern concepts of

biomedical are different from the classical one.

Thus, medical concepts are constantly changing

(Nordenfelt and Lennart, 2013). Furthermore, it is

difficult to identify and classify different

medications as their names resemble each other

(Wagner, et al., 1996) e.g. Pentobarbital and

Phenobarbital.

The organization of the paper is as follows: In

Section 2, Methodology and details of fundamental

techniques are explained. Results are shown in

Section 3 where dataset of the research is stated.

Along with, discussion and analysis of the results are

made in Section 4. In Section 5, Literature Review is

presented. And finally, the paper is concluded in

Section 6.

2 METHODOLOGY

The most effectual solution would be to expand the

scope of medical records by not only considering

drugs names but also the potentially related concepts

i.e. disease, symptoms etc. in all dimensions to

potentially identify correct medications.

2.1 Selection Criteria

Inclusion and exclusion criteria are illustrated below

that made certain that only relevant work is

considered.

2.1.1 Inclusion Criteria

Records those are considered to examine:

 Any patient consulted an authorized medical

nurse, practitioner or a doctor.

 Any patient with a drug prescription with

dosage and schedule.

2.1.2 Exclusion Criteria

Cleaning of entries is done through:

 Any patient having empty medication lists.

 Any patient who had been checked previously

and no new amendment in prescription was

made.

 Any medication with a brand name with the

help of non-drug terms.

 Redundant prescriptions of the same patient

found in the database.

2.2 Steps towards Solution

The complete flow of the proposed work is

presented in Figure 1.

The main tasks are broken down into the

following steps:

2.2.1 Data Preparation

For the preparation of data, first of all, records are

extracted about different allergies and then it is

analyzed. For this, NULL value and duplicate entries

are removed through the use of array_unique and

array_filter functions of PHP are used for the

identification of particular required data.

Fields include date, time, reason, result,

medication and instructions for multiple diverse

patients. Each record is fetched without biasness.

Then all records fulfilling inclusion and

exclusion criteria are saved in the database.

2.2.2 Pre-processing

Brown corpus’s Parts Of Speech Tagging (POST) is

a well-known method of relating a word with a

particular part of speech in a given sentence. But

tagging a word is not a straightforward process as

multiple words can communicate in multiple ways.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

334

Figure 1: Flow Chart of the Methodology.

Hence, there are multiple parts of speech against a

single term due to ambiguity and complexity of

English language. Actually, “what” the word is less

significant than “how” it is applied (Manning,

Christopher D., 2011).

Therefore, our first step is tagging of words

according to brown corpus methodology. Presently,

we have eight parts of speech in English: adjective,

adverb, conjunction, interjection,

noun, preposition, pronoun and verb along with

many categories and their sub-categories. But our

focus is on the nouns (NN) and the adjectives (JJ).

In working with clinical data, information is

written in a certain format such as “medication dose

unit-of-measure time-period” for example. “Aspirin

60 mg 1 tablet q.d.” This information share some

common features, that are patterns in the text but

they are fairly complex (Richard Pless, 2004). To

address them, regular expressions are used to

systematically collect data. As regular expression is

a simple way of describing a search pattern and

extract information. The advantage of regular

expressions is the incredible flexibility that they

offer. But the challenge of regular expressions is to

understand the patterns that you want to find but it

gives assurance to collect all valuable information

with ease.

2.2.3 Term Frequency (TF) Calculation

Term Frequency used in text mining to evaluate the

importance of a word in a document or corpus. The

significance of terms enhances proportionally to the

number of times a word occurs in a document. As

each document has different length, so, it may be

possible that a word would come more times in long

documents than in shorter ones. Therefore, the term

frequency is frequently divided by the document size

for normalization.

So, Term Frequency is used to obtain all

available matching drugs’ names from the internet:

TF= (Number of times appears in a medical

record) / (Total number of terms in the

medical record)

(1)

2.2.4 Information Retrieval (IR)

Since many online medication dictionaries are

available, such corpus will be used to extract all

possible spellings of the anticipated misspelled drug

through information retrieval. In IR, what more we

need is to:

 Process information quickly from the web

documents as there is a bulk amount of data

available on the web. The indexed web

contains 4.39 billion web pages at the time of

writing this. And to retrieve useful

information from it is not an easy task.

 Flexibility in matching patterns is required.

 Ranking in retrieved results. As hundreds and

thousands are results are retrieved what we

need is to have best results for our query so

for this ranked retrieval is very important

Identiﬁcation and Correction of Misspelled Drugs’ Names in Electronic Medical Records (EMR)

335

(Manning, Raghavan, and Schütze, 2008).

Further comprehension will be done with the

help of Lemmatization and Stemming of words by

considering the fact that ‘particular nouns’ can’t be

altered in any case.

2.2.5 Cosine Similarity

This metric is frequently applied to determine the

similarity between two documents due to the

presence of multiple similar words. Here, words are

treated as vectors to calculate the normalized dot

product. The result 0 depicts that two documents do

not share any common term while other scores show

some similarity. In our case, comparison of most

relevant drug name extracted through IR will be

performed through Cosine Similarity.

3 RESULT

Dataset: In order to evaluate, an incorrect test set of

clinical documents is necessary. For this purpose, we

randomly selected 250 electronic medical records.

All the data is available in tabular form.

Precision = True Positives/Total

Prescriptions

(2)

The formula (2) was applied to calculate the

overall accuracy of the system that how well it

performed on correcting erroneous terms in the test

set. ‘Actual’ spellings were compared with the

‘Corrected’ ones in each prescription and ‘Total’

were all possible records having no NULL entry in

them while duplicate entries were considered as their

quantity and dosage method vary person to person.

Analysis of every single prescription was done

manually by comparing ‘Corrected’ results with

multiple medical dictionaries.

Below graph shows the accuracy of the novel

approach by applying the formula of precision.

Figure 2: Comparison of Results.

Figure 2 demonstrates how precision rate varies.

X-axis represents a total number of records while Y-

axis represents the precision of retrieved results

while horizontal line represents the threshold.

4 DISCUSSION

The essence of this approach is detailed comparison

instead of simply replacing drug name with the ﬁrst

ranked suggestion. The evaluation is done on the

basis of:

 Whether the technique provided all possible

spellings of the word.

 Whether a word can be presented in multiple

senses.

 Whether results are close enough to the actual

spellings.

The approximate average precision is 0.742.

From results described in Figure 3, we observe that

overall results are better than previous non-context

based approaches. However, in some situations,

accuracy of results is reduced as the data is chosen

randomly, therefore, it is imbalanced in nature that

becomes a major cause of result’s graph decline. A

potential limitation of this approach is that complete

disease and symptoms information is required.

Although, a new technique is proposed in this paper

with the combination of Information Retrieval (IR),

Regular Expressions and POST, but sometimes, the

nature of English language leads us towards the

uncertainty of applying it in few circumstances.

Ambiguous and unclear terms may cause drifting

from the actual intent when replacement of the word

is made. However, it can be said that, through

detailed analysis of grammatical issues, we will able

to overcome issues and improve this technique.

5 RELATED WORK

The problem of misspelling in the medical domain

has been addressed in various publications.

(Ruch et al., 2003) classified spelling error

detection and correction into two types. The first

type is word-based or context-free spelling

correction which consists of errors that cannot be

found in the dictionary, for example, handel instead

of handle. The other type is context-based or context

sensitive which deals with the correct word but

invalid within the situation, for instance, worm body

instead of warm body. Also (Kukich, Karen., 1992)

divided the problem into three subgroups as (a) non-

0,2

0,4

0,6

0,8

1,2

103

120

137

154

171

188

205

222

239

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

336

word error detection; (b) isolated-word error

correction; and (c) context-dependent word

correction. However, many proposed techniques rely

on a lexicon-based approach.

The typical spelling correction system by

(Levenshtein, Vladimir I., 1966) is based on

minimum edit distance which ranks suggestion by

the least number of inclusion, removal, replacement

and reversal required to convert one string into the

other.

(Turchin, Alexander, et al, 2007) identiﬁed

incorrect words by comparing them to some

predeﬁned list of words, but this baseline method is

extended by doing prevalence analysis, i.e.

determining the frequency ratio of a word and its

one edit distance alternatives in the corpus.

(Patrick, Jon, and Dung. 2011) used numerous

knowledge bases of English clinical terms in

addition to utilizing statistical methods.

Mass noun errors in English are solved by

(Brockett et al., 2006), who focused on grammatical

errors rather than on orthographical. Their work is

related to the (Ehsan, Nava, and Faili, 2013) where

the traditional SMT algorithm is used for spelling

error preciseness. Though, in the approach, errors

were initiated artiﬁcially.

(Siklósi et al., 2016) presented a new method for

automatic correction in Hungarian clinical records

by means of a SMT decoder. Due to the lack of a

corpus normalized, a realistic aim was not fully

achieved.

Some spelling suggestion tools such as Aspell

and Gspell also exist in the English language for use

and exploration. Aspell is a mixture of the Meta-

phone algorithm and near-miss strategy. While

NGrams, metaphone, common misspellings, and

homophone retrieval tools are present in Gspell.

Candidates are evaluated by the Levenshtein edit

distance, and similar ranked candidates are re-

ordered by (Divita, G., 2003).

A frequency-based approach joining a medical

dictionary configuration was built to improve

recommendations of Aspell and Gspell by (Crowell

et al., 2004). Turchin et al. used prevalence analysis

for correction. (Senger, Christian, et al., 2010) made

use of Aspell and user activities to analyze

medication misspellings in a drug query system.

6 CONCLUSIONS AND FUTURE

WORK

As we know that medical records play a significant

role in everyone’s life. So, the focus of this study is

to illustrate the problems of Electronic Medical

Records. Based on the causes of data errors, an

effective improvement to the EMR would be to

expand its scope to classify possible medications. In

our paper, we presented a method to correct single

spelling errors by concentrating more on ‘how’ and

‘why’ part of the searching instead of ‘what’,

making a ﬁrm base for extending it to the correction

of multiple errors as well. POST, Regular

Expressions, and Information Retrieval played an

important role in substitution. The overall accuracy

of the system is a technically better than traditional

techniques.

Even with EMR extensions, 100% accuracy

can’t be guaranteed, some minor error chances will

remain (Wagner, et al., 1996). As the domain of

searching is very gigantic; still more work is

required to gather more accurate and close results.

So, we have some future plans for including text

parsing in it and will do the implementation of this

technique for free-text clinical records to provide

more ease to practitioners.

REFERENCES

Brockett, C., Dolan, W.B. and Gamon, M., 2006, July.

Correcting ESL errors using phrasal SMT techniques.

In Proceedings of the 21st International Conference

on Computational Linguistics and the 44th annual

meeting of the Association for Computational

Linguistics (pp. 249-256). Association for

Computational Linguistics.

Crowell, J., Zeng, Q., Ngo, L., and Lacroix, E.M., 2004. A

frequency-based technique to improve the spelling

suggestion rank in medical queries. Journal of the

American Medical Informatics Association, 11(3),

pp.179-185.

DesRoches, C.M., Campbell, E.G., Rao, S.R., Donelan,

K., Ferris, T.G., Jha, A., Kaushal, R., Levy, D.E.,

Rosenbaum, S., Shields, A.E. and Blumenthal, D.,

2008. Electronic health records in ambulatory care—a

national survey of physicians. New England Journal of

Medicine, 359(1), pp.50-60.

Divita, G. 2003. Spelling Suggestion Tools (Gspell),

National Library of Medicine. Available at

http://lexsrv3.nlm.nih.gov/LexSysGroup/Projects/gSpe

ll/current/GSpell.html.

Ehsan, N., and Faili, H., 2013. Grammatical and

contextsensitive error correction using a statistical

machine translation framework. Software: Practice

and Experience, 43(2), pp.187-206.

Kukich, K., 1992. Techniques for automatically correcting

words in text.ACM Computing Surveys (CSUR), 24(4),

pp.377-439.

Levenshtein, V.I., 1966, February. Binary codes capable

Identiﬁcation and Correction of Misspelled Drugs’ Names in Electronic Medical Records (EMR)

337

of correcting deletions, insertions, and reversals.

In Soviet physics doklady (Vol. 10, No. 8, pp. 707-

710).

Manning, C.D., Raghavan, P. and Schütze, H.,

2008. Introduction to information retrieval (Vol. 1,

No. 1, p. 496). Cambridge: Cambridge university

press.

Manning, C.D., 2011. Part-of-speech tagging from 97% to

100%: is it time for some linguistics?

In Computational Linguistics and Intelligent Text

Processing (pp. 171-189). Springer Berlin Heidelberg.

Monson, R.A., and Bond, C.A., 1978. The accuracy of the

medical record as an index of outpatient drug

therapy. JAMA, 240(20), pp.2182-2184.

Nordenfelt, L., 2013. Identification and classification of

diseases: Fundamental problems in medical ontology

and epistemology. Studia Philosophica Estonica, 6(2),

pp.6-21.

Patrick, J.D. and Nguyen, D., 2011. Automated Proof

Reading of Clinical Notes. In PACLIC (pp. 303-312).

Perreault, L.E. and Shortliffe, E.H., 1990. Medical

Informatics: Computer Applications in Health Care.

Addison-Wesley.

Price, D., Cooke, J., Singleton, S. and Feely, M., 1986.

Doctors' unawareness of the drugs their patients are

taking: a major cause of overprescribing?

BMJ, 292(6513), pp.99-100.

Richard Pless. 2004. "An Introduction to Regular

Expressions with Examples from Clinical Data",

IL, SUGI Proceedings. Available at http://www2.sas.

com/proceedings/sugi29/043-29.pdf.

Ruch, P., Baud, R. and Geissbühler, A., 2003. Using

lexical disambiguation and named-entity recognition

to improve spelling correction in the electronic patient

record. Artificial intelligence in medicine, 29(1),

pp.169-184.

Senger, C., Kaltschmidt, J., Schmitt, S.P., Pruszydlo,

M.G., and Haefeli, W.E., 2010. Misspellings in drug

information system queries: characteristics of drug

name spelling errors and strategies for their

prevention. International journal of medical

informatics, 79(12), pp.832-839.

Siklósi, B., Novák, A. and Prószéky, G., 2016. Context-

aware correction of spelling errors in Hungarian

medical documents. Computer Speech &

Language, 35, pp.219-233.

Spooner, L.M. and Pesaturo, K.A., 2013. The Medical

Record. Fundamental Skills for Patient Care in

Pharmacy Practice, p.37.

Turchin, A., Chu, J.T., Shubina, M. and Einbinder, J.S.,

2007. Identification of misspelled words without a

comprehensive dictionary using prevalence analysis.

In AMIA Annual Symposium Proceedings (Vol. 2007,

p. 751). American Medical Informatics Association.

Wagner, M.M. and Hogan, W.R., 1996. The accuracy of

medication data in an outpatient electronic medical

record. Journal of the American Medical Informatics

Association, 3(3), p.234.

https://github.com/darylc123/diabetes-prediction/blob/mas

ter/trainingSet/training_SyncAllergy.csv.

http://mines.humanoriented.com/classes/2010/fall/csci568/

portfolio_exports/sphilip/cos.html.

http://www.tfidf.com/

http://www.regexbuddy.com/regex.html.

http://www.worldwidewebsize.com/

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

338
