Test-Data Quality as a Success Factor for End-to-End Testing

An Approach to Formalisation and Evaluation

Yury Chernov

SIX Group Services AG, Selnaustrasse 30, Zurich, Switzerland

Keywords: Data Quality, Test-Data, End-to-End Testing, Data Quality Factors, Test-Data Quality Modelling.

Abstract: Test-data quality can be decisive in the success of end-to-end testing of complicated multi-component and

distributed systems. The proper metrics allows to compare different data sets and to evaluate their quality.

The typical data quality factors should be, on the one hand, enriched with the dimensions specific for the

testing, and, on the other hand many requirements to the production system data quality become not

relevant. The proposed formal model is based to great extent on the common sense and practical experience,

and not over-formalised. The implementation requires quite an effort, but once established can be very

useful.

1 INTRODUCTION

The aim of end-to-end testing is to verify the

complete business functionality of a system starting

from entry points and including the outgoing

information to end-users. The functionality is

defined by the requirements and corresponding use-

cases. The end-to-end testing takes place on special

test systems. Besides technical implementation of a

test system one of the major points is the test-data.

The quality of the test-data must ensure the

testability and the business-relevant test coverage.

The definition and evaluation of the test-data

quality is the topic of the current paper. In order to

define the quality of the test-data we summarise the

parameters of the data quality in general and then

include specific points of the testing.

The idealistic aim would be to fully formalise the

evaluation of the data-quality in order to enable a

proper metrics and a quantitate comparison of one

data-set to another. However, this aim is practically

not reachable, or can be only partly reached.

Therefore, our intention is to find a reasonable

approach, suitable to the evaluation and helpful in

finding the ways to improve the test-data. And the

major question remains: how we can formally define

the test-data quality.

The present paper is based on the testing

experience by SIX Swiss Exchange (SSE)

(http://www.six-swiss-exchange.com), where the

requirements to the reliability and stability are very

high. That is why the question of the test-data

quality is extremely important.

2 DATA QUALITY DIMENSIONS

Although the presented discussion is rather generic:

the rational and models are applicable to a wide

range of data-intensive systems, the influence of the

specific system under test, that is SSE, cannot be

ignored. We will first discuss the system under the

test especially in the context of the end-to-end

testing and the standard data quality dimensions, and

then introduce the test-data specifics reflected in the

model.

2.1 System Under Test

SSE is highly complicated multi-component system.

It includes a dozen of components running on

different platforms, with different data bases

(Oracle, SQL Server, MySql, etc.) and

communication principles, protocols and technical

means. The static or reference data that is defined in

the dimension tables (Kimball, 2013) and dynamic

or trading data (fact tables) arrives into the system

through different interfaces starting from web- and

application-based manual input and uploads, and

including fast algorithmic-trading interfaces, where

the time is differentiated in nanoseconds. The end-

to-end test system should reproduce this landscape

Chernov, Y.

Test-Data Quality as a Success Factor for End-to-End Testing - An Approach to Formalisation and Evaluation.

DOI: 10.5220/0005971700950101

In Proceedings of the 5th International Conference on Data Management Technologies and Applications (DATA 2016), pages 95-101

ISBN: 978-989-758-193-9

practically one to one.

The major specific of the system from the data

point of view is that the data consumers (banks and

other trading organisations) are to great extend data

creators, since they issue the products that are traded

on SSE. They are as well, as system customers, the

major source of functional requirements. That is a

very important point: we can refer to (Redman,

2013) who emphasised: “I’ve noted repeatedly the

importance of connecting data customers and data

creators. One difficulty is that customers often speak

in vague, confused, task-specific terms, while data

creators need hard, tangible specifications on which

to define and improve their processes.” However,

we should not forget that this was stated for the real

production data and we are investigating the data

aspects in the end-to-end test system.

The data can be analysed from different points of

view, which they use to call dimensions. The data

quality approach is not homogeneous. It changes

from dimension to dimension, since different aspects

come in the foreground of the analysis. Therefore, it

is important to discuss them, at least to point them

out.

The information circulated in SSE includes the

static data (issued products, participant information,

technical connection data, billing parameters etc.)

and dynamic data (trading information, calculated

indices, statistical evaluations etc.). Both types of

data come from the up-stream components and are

integrated in the downstream components (data

warehouse, monitoring and supervision tools, and

information distribution utilities). The third data type

is the information generated by the components

themselves (information products), which is based

on the incoming static and dynamic data. Of course

that relates more to the downstream components, for

instance, the spreads of the order books, or some

daily statistic reports.

The data arrives into the system (incoming

information), is stored and processed and distributed

further to customers. The quality of these portions

can be different. The problems and defects in

incoming data can be partly corrected by the

software that these data reads, verifies and stores.

The same process takes place for the outgoing

data. When a certain data field is not populated for

certain tuples, it may be set to an agreed value by the

export routines.

But when the software itself has bugs (the testing

actually is done to detect them), it can reduce the

quality of the stored data by introducing the data

problems.

From the point of view of the source the data can

be external, that is comes from external sources

outside of the systems (ex. issued financial

instruments, indices form foreign stock exchanges,

currency rates etc.), or internal. Internal data is

produced either by the software that processes,

consolidates and converts the data, or by internal

users that have the role to enrich and maintain the

data.

The character of the data can be business-

relevant or pure technical one. The technical data

can include, for instance, network configuration and

user access paths. The quality of this data should be

extremely high; otherwise, the system will simply

not work properly.

Besides, the data relates to different objects in

the system. The quality might be interesting for

separate objects and even sub-objects. For instance,

one of the objects is securities

(products/instruments) listed on the stock exchange.

As sub-objects we can consider different types, like

shares, bonds, derivatives etc.

The summary of the data characteristics in SSE

is presented in Tab. 1. Of course the data can be

viewed from some additional aspects as well.

However, we define those ones that are more

relevant for the data quality modelling.

Table 1: Data Characteristics.

Data Dimension Dimension Refinement

Type

Static

Dynamic

Generated

Information

Incoming

Stored

Outgoing

Source

External

Internal

Character

Business

Technical

Store

Temporal

Long-term

Object

Products/Instruments

Participants

On-book trading data

Off-book trading data

………………………

The existing production SSE is reflected in end-

to-end test environment. The major test environment

includes 14 components: reference data repositories,

trading engine, off-book trading component,

monitoring system, data warehouse, data distribution

system etc. It covers a big portion of real production

functionality. It is never 100%, but it can be close to

that.

DATA 2016 - 5th International Conference on Data Management Technologies and Applications

2.2 Different Test Levels

In the current paper we focus our attention on the

functional end-to-end testing. In the SSE landscape

different test phases are implemented. Major of them

are component and integration testing, which take

place before the software is shipped to the end-to-

end testing. The requirements on the test-data are

different for different test phases.

The business relevance has lower priority for the

component testing, but rather the combinatorics of

possible data configurations is important. The aim of

the component testing is to check all technically

possible scenarios. That is done with synthetic data.

This data is not coming from the up-streams

components, but is stored in the specially prepared

files. The testing is mostly automated. Especially the

regression testing is appropriate, when the same

input files feed the test components with different

software versions and the results are compared.

For the integration testing the interface variants

and protocol configurations are in focus. Here not

only one separate component, but typically pares of

components are serving as testees. However, the

principle approach to the test-data is like in the

component testing. The data can be just synthetic

one. The closeness to the real production data is not

very important. Important is to cover all possible

protocol branches and all possible file

configurations, when the communication between

components is implemented through files. The last is

typical for the reference data.

For the end-to-end testing the data must support

all business functions and not necessary all

technically possible variations. To fulfil that the data

should be close to the real production one and also

cover future needs, which are technically possible,

but not activated yet. Therefore, the data is often a

combination of production and synthetic portions.

2.3 Data Quality Factors

The traditional data quality factors or dimensions are

defined in many publications (Redman, 2013;

Batini, 2006; Rainardi, 2008). They are mainly

oriented on the data warehouse concept, which is

quite appropriate for us as well.

When we are speaking about the data quality we

should not forget two aspects or objects, namely data

model and data set. Usually they mean the last, when

discussing the data quality. In the current work we

are doing that as well, because from the testing point

of view in general and the end-to-end testing in

particular the data set is the major point of interest.

The data model belongs primarily to the design.

However, often only during the testing you detect

the model problems and the feedback can be still

very useful.

Below in Tab. 2 we list the principle quality

factors. The list is rather generic and covers both

data models and data sets. That is why these factors

serve as a good basis for more precise and practical

definition when implementing them to the test

quality evaluation.

Table 2: Data Quality Factors.

Data Quality Factor Explanation

Correctness

Accuracy: data are correct

(data formats, defaults, initial

load, NULLs etc.).

Precision: data are adequately

specific.

Granularity: data are

sufficiently detailed.

Completeness

Completeness: all data are

available.

No Gaps: all needed values are

present.

State: data are in usable state.

Consistency No conflicting data.

Conformity Conformity with critical rules.

Integrity

Identity: unique keys are

defined.

Referential Integrity.

Cardinality: relationship

constrains are present.

Dependency: functional

constrains are present.

Uniqueness: no duplicate data.

Validity

Values are within required

range.

No Null values in Non-NULL

fields.

Timeliness

Currency: data are up to date.

Repetition: data include enough

history.

Continuity: no historical gaps.

Sequentially: data are logically

sequenced.

Data Comprehension

Data match business; data are

understandable; data are easy

to view; data are structured in

logical sequence; data are fit-

to-tool (easily

imported/exported).

We are discussing these factors below. But first

of all describe specifics of requirements to the test-

data that define its quality.

Test-Data Quality as a Success Factor for End-to-End Testing - An Approach to Formalisation and Evaluation

2.3.1 Test-Data Quality

The data quality factors reflect the general data

quality aspects. The test-data and especially the test-

data for the end-to-end testing have its specifics:

 it should cover all real production cases and

configurations

 it should properly reflect the real production data

relations and stochastic distributions

 it should support possible future functionality

that is not used currently in the production

system, but is possible technically

 it should quantitatively reflect the requirements

for non-functional testing, that is over the current

production volumes.

These specifics do not influence the general

approach, however, they definitely important for the

evaluation in the model presented below.

The test-data quality has one additional

characteristic. Namely, how good the data covers all

needs of the planned test activity, that is how good it

for the execution of all planned test cases. Finally

that is the crucial thing about the test-data.

The test coverage is usually derived from

business and technical use cases and requirements.

Each use case is typically transferred into several

test requirements. When you manage to build a pure

hierarchal test planning system then each test

requirement is covered by several test cases. In

practise you may have more complicated relations –

many-to-many, when one test case supports several

test requirements. Besides, every test case may have

several configurations.

The quality factor reflects how good this

complicated structure is supported by the test-data,

so, that every test case could be executed with all its

configurations. This criterion complements the set of

quality factors.

2.3.2 Correctness

The data accuracy is easily formalised both for the

interfaces and in the data store. They check formats,

default values, initial load values against system

specifications, empty fields. We are speaking about

pure technical checks. More business-oriented

verification is done along the data comprehension

dimension.

Precision for a data entity should be the same all

over the system. It makes no sense to store a field

with, say, six decimal places, when the data source

delivers it with only four positions after decimal

point. The check of the precision aspect is

complicated, since the same variables might have

different names in different components (see the

consistency dimension) and the proper analysis

requires a big analytical rather than formal effort.

The granularity is business-defined and is

covered in the data model level.

For SSE the major focus lays on default values,

initial load for new versions and migrations, and

NULLs. The NULL-values are traditionally the

source of many problems. They often play an

important role in the integration between

components when one component designed by an

outsourcing company, say in India, allows NULLs

for specific field, and the next component that has

been purchased from a provider in Australia expects

no NULLs on the interface. Often such problems

happen. Generally NULL can note either non

existing value, or existing but unknown (not

provided by the data source), or when you do not

know, whether the value exists.

2.3.3 Completeness

The data completeness is as well easily checked on

the database level. It is better when you have the

statistical reference from the real production. The

source of the data in the test system is mainly test

automation scripts. They should be configured in

such a way that at least the data relations (not always

volumes) remain production-like.

On the table level we should verify that there are

no empty tables. For instance, in the current SSE

data warehouse test system there are 36 empty tables

out of totally 187. However, some of them relate to

the functions, which are not tested in the end-to-end

system, others are not populated any more, but still

kept in production for historic reporting. There are

some tables that have been introduced, however, not

used in production, since the corresponding business

functionality is not yet activated.

On the record level – check for empty, not-

populated fields. Here we should verify not simply

NULLs, but those fields that are filled in some

components, but empty in other.

From the dynamic point of view it should be

controlled that there is data for all days (in SSE

context) or other relevant time entities. For instance,

in the current test data warehouse there is data from

01.06.2015 till 01.05.2016, that is, 335 calendar days

(2016 is a leap-year). That corresponds to 231

business days (minus weekends and bank holidays).

In the data warehouse there are 220 loaded days, i.e.

11 days are missing for some reasons.

From the object point of view – all objects (like

legal entities, participants or trading users by SSE)

should include required data.

DATA 2016 - 5th International Conference on Data Management Technologies and Applications

For the end-to-end test purposes it is necessary

that the data is complete and has no gaps during the

test cycles. Between the test cycles some data gaps

are acceptable. However, we are trying to avoid that

by scheduling the execution of automatic scripts

every day. Besides, the data gaps can be added on

purpose - to test, how the system copes with them.

2.3.4 Consistency

Formally conflicts may occur when the same data in

different tables is imported from different sources. If

their values are not the same, we can speak about

conflicting data.

Another aspect of this problem is different names

for the actually same data entities. Often that

happens when the data entities are in different

components. The optimal way is to build the data

name maps. The formalisation of these maps enables

the automation of the data consistency checks.

In SSE there are rather many disagreements in

data field names due to historically development of

components by different software suppliers.

2.3.5 Conformity

Data rules are implemented either in the database or

on the application level - in GUIs or interfaces. The

important point here is to check the historical data.

A new implemented rule will not allow new non-

conform data. However, the old one that had been

entered into the system before can include non-

conform values. Often the conformity errors are

detected when a user tries to change these old data

entities.

In SSE only for reference data components the

conformity aspect of the quality is relevant, because

trading components often receive just the current

data (for the current business day). So even when

they do have some conformity problem, the root

cause is in the reference data components. The

verification can be technically easily done on the

databases. The difficulty is to consistently formalise

all business rules, which are often implemented on

the interface level, in terms of the database entities.

2.3.6 Integrity

That relates mainly to the data-model. Of course if

the referential integrity, cardinality and dependency

are not defined on the database level then they are

the point for the formal verification on the data-set

level. But the most interesting here could be the

historical development of data-sets, when they grew

incrementally from version to version with the data

model changes. In this case the referential integrity

and cardinality of the historic data could be broken.

The verification is analogous to the consistency

dimension. The integrity rules are technical ones and

formulated on the database level.

2.3.7 Validity

Validity in out context is about the data ranges.

There are two types of required range. The first is

the technical one, which is defined on the database

level. These ranges should be checked, like in the

case of integrity, only for historical data. The second

type is business-relevant ranges. This means that

technically the values outside the range are possible,

but they are not meaningful from the business point

of view. These ranges could be very interesting for

the evaluation of the data quality of the end-to-end

testing. For the component testing, especially non-

functional one, the extreme values are needed.

The evaluation becomes complicated, since some

rules have been changed. So the validation should be

estimated based on the rules valid for the specific

period.

2.3.8 Timeliness

The authors of (Batini, 2006) defined the currency

formally as the age of the data unit plus difference

between the delivery time (the time the information

product is delivered to the customer) and the input

time (the time the data unit is obtained).

Volatility is the length of time data remains

valid.

Timeliness, which is measured from 0 (bad) to 1

(good), equals 1 minus relation of the currency to

the volatility. However, this formal approach is not

always relevant.

In the SSE end-to-end test system the new data is

generated daily by means of automated scripts. The

quality check includes the verification the daily

process that is that all tables are populated in all

components. By this we guaranty no historical gaps.

From time to time (two-three times a year) the

test environment is set-up from scratch as a copy of

production system. This copy includes just the

reference data, so the system starts its live from zero.

However, some applications like billing or statistical

evaluations require much historical data. Therefore,

the test environment must “live” for some time,

before all tests can be executed.

2.3.9 Data Comprehension

The data comprehension dimension is least

Test-Data Quality as a Success Factor for End-to-End Testing - An Approach to Formalisation and Evaluation

formalised. Actually it can be evaluated only on the

bases of end-user opinions. For the testing this

dimension is probably not very interesting, unless

the data comprehension requirements are more

formally formulated.

3 DATA QUALITY MODEL

Above we presented just some explanations to the

data quality factors. Let us abstract from the formal

definition of them and assume that they can be

evaluated somehow by experts or with special

procedures. For instance, one of the aspects of

completeness could be the number of not populated

fields and the number of empty tables in a database.

For us is important to compare different data sets to

each other and not the formal quantitative definition

of the quality level. This comparison might involve

two variants of data sets for the same system under

the testing or two states of the same data set at

different points of time, the last can reflect, for

instance, two different projects.

There are three known approaches to the

definition of data quality dimensions: theoretical

(Wand, 1996), empirical (Wang, 1996) and intuitive

(Redman, 1996). We are trying to combine them in a

simple model.

We define the quality model as a primitive

weighted sum of the factor levels:





∙







(1)

Where

is the level of factor i,

is the weight of the factor i,

n – total number of factors

In our case n = 8 (Tab. 2), and x

reflects the level of

correctness, x

– the level of completeness, etc. The

model (1) is very generic, the exact definition the

levels and the weights is application specific.

In order to provide compatibility, the test-data

quality models must be mapped on the same scale.

The most appropriate seems the normalised scale.

Therefore, we can state that both x

and q are defined

on the scale of 0 to 1. The weights a

should be

defined accordingly to ensure the proper value range

for q.

The definition of a

is rather complicated. The

only reasonable way seems to be an expert

evaluation. However more formal procedures could

be thinkable as well.

3.1 Structure-based Approach

As it was mentioned above, the SSE system includes

many non-homogeneous components. The first

approach to the data quality evaluation is to evaluate

the quality levels for every component and then to

aggregate them with a product function:

   







∙



(2)

Where q

is the quality level of j-th component,

estimated by (1); b

is the weight of the j-th

component.

We should use the product function rather than a

weighted sum, because the quality is hardly defined

by a bottleneck component. Therefore, when the

data quality of an up-stream component is poor, the

high quality of a down-stream one cannot improve

the total value.

3.2 Object-based Approach

Basic model (1) & (2) may be implemented not

exclusively to the whole data structure, but only for

selected objects as well. In our application we can

take for instance just traded securities or only billing

relevant data entities. This approach of course

requires a proper analysis of the data and very

precise business know-how. In other words it cannot

be realised just formally, as it is in principle possible

with the structure-based approach.

3.3 Use-case-based Approach

This approach we call “use-case-based”, but

practically it is based on the test cases and their

configurations. We assume that the above described

chain use case –> test case –> test case configuration

(test instance) covers all the needed requirements to

the end-to-end testing. Of course that is not always

the case and strongly depends on the quality of the

test specifications and plans. However, in SSE that

should be assumable. In general, if the coverage of

the system functionality by the testware is not good,

then the test-data quality cannot add a lot.

We can detect, whether the test-data set supports

a test instance, either by trying to execute it or just

ask an expert (tester). By the end we have binary

value: true or false. Let us call this variable “test

instance quality indicator” and denote it through t

for the j-th instance of the i-th test case. The test-

data quality may be modelled by the following

expression:

DATA 2016 - 5th International Conference on Data Management Technologies and Applications

100

 

∑





∙



,

,

∑





,

,

(3)

Where T is the number of test cases, k - number of

configurations, and c

is the corresponding weight of

the test case. Number of configurations is normally

individual for every test case; therefore, we should

actually speak about k

The evaluation with the model (3) is usually

effort and time consuming. However, once done, it

could be very useful. It presents a different view on

the test-data quality. For instance, as we already

mentioned above, the data warehouse in the end-to-

end test system of SSE has 36 empty tables out of

totally 187, although they are populated in the

production system. That has rather strong influence

on the data quality evaluation according to (1)-(2).

However, all of end-to-end test cases can be

executed, and the value of QU from (3) could be

high.

4 CONCLUSIONS

The dimensions that are typical for the data quality

analysis can be applied to the test-data for the end-

to-end testing as well. They provide useful

information. However, from the one hand, the

typical dimensions should be enriched with the

specific for the test-data factors. From the other

hand, not all requirements, which are important for

the real productive data, are relevant for the test-

data. Therefore, the corresponding model should be

based not only on the formal approach, but on the

common sense and empirics as well.

The practical results require a big effort.

However, once established and implemented in

terms of models (1) - (3), the procedure can be very

effective in evaluation of the test-data quality.

Very challenging task is the design of a more

formal model for the proper definition of the weights

in (1), (2), and (3). Till know they are defined

intuitive or partly by experts and are not very

differentiated. The proper approach seems to be the

combination of expert estimation with several

simulations of the test data.

REFERENCES

Batini, C., Scannapieco, M., 2006. Data Quality:

Concepts, Methodologies and Techniques, Springer.

Berlin.

Kimball, R., Ross, M. 2013. The Data Warehouse Toolkit:

The Definitive Guide to Dimensional Modeling.

Wiley, 3

Ed.

Rainardi, V., 2008. Building a Data Warehouse: With

Examples in SQL Server, Apress. New York.

Redman, T.C., 1996. Data Quality for the Information

Age. Artech House.

Redman, T.C., 2013. Data Quality Management Past,

Present, and Future: Towards a management System

for Data. In. Handbook of Data Quality: Research and

Practice (Ed. Sadig, S.), Springer.

Wand, Y., Wang, R.Y. 1996. Anchoring Data Quality

Dimensions in Onto-logical Foundation.

Communication of the ACM, 39, 11.

Wang, R.Y., Strong, D.M. 1996. Beyond Accuracy: What

Data Quality Means to Data Consumers. Journal of

Management Information Systems 12, 4.

Test-Data Quality as a Success Factor for End-to-End Testing - An Approach to Formalisation and Evaluation

101
