Distributed Intelligent Systems for Network Security Control

Mohamed Shili

, Hamza Gharsellaoui

1,2,3

and Dalel Kanzari

LISI Laboratory, National Institute of Applied Sciences and Technology (INSAT), Carthage University, Tunis, Tunisia

National Engineering School of Carthage (ENIC), Carthage University, Tunis, Tunisia

Al Jouf College of Technology, TVTC, Al Jouf, K.S.A.

Institute of Applied Sciences and Technology of Sousse (ISSATso), Sousse University, Sousse, Tunisia

Keywords:

Network Security, Intelligent Agent, Misuse Systems, Attack Propagation, Intrusion Detection.

Abstract:

The great number of heterogeneous interconnected operating systems gives greater access to intruders and

makes it easier for malicious users to break systems security policy. Also, a single security control agent is

insufﬁcient to monitor multiple interconnected hosts and to protect distributed operating systems from hostile

uses. This paper shows the ability of distributed security controller’s agents to correlate data stream from

heterogeneous hosts and to trace abnormal behavior in order to protect network security. An experimental

study is done to improve our proposed approach.

1 INTRODUCTION

The point of network security is to oversee the normal

actives of its components and to prevent any attempt

to break in and disturb their functionality. In order

to do that, we need to compare different types of se-

curity systems as a base for our approach. When we

talk about security we need ﬁrst to identify the secu-

rity parameters, intrusion.com gave us the following

formula:

Security = visibility + control, but this formula is in-

complete, our approach is based on this idea: Secu-

rity = visibility + control + ”self awareness”, Speak-

ing of network security self awareness is more like

testing the limits of artiﬁcial intelligence and giving

the security a ”Soul”. In this sense, we need to iden-

tify the potential parameters in which way we give

the security system a developing character to enforce

high protection levels against external threats a num-

ber of intelligent tools which were based on machine

learning; like intrusion detection systems based on au-

tonomous agent are developed to survey the network

activityand to signal all abnormal deviation the aim of

these agents is to detect data signatures that threaten

the system’s behavior. In this paper, we propose two

kinds of intrusion detection agents to protect network

components the local agent controller that detects the

malicious data signature hidden in directly connected

systems based on a local base of known attacks and

a central agent controller that collects data from dis-

tributed local agent’s controller to detect the presence

of a propagated network threat.

Section 2 presents an overview on security sys-

tems. Section 3 presents our original proposed ap-

proach and Section 4 presents the experimentation

and comparison. Finally, Section 5 concluded this pa-

per.

2 SECURITY SYSTEMS REVIEW

Operating systems are compromised from the mali-

cious exploit of their services and the intent to vio-

late the security policy (Zimmermann., 2003), (Pri-

gent., 2003), (Ludovic., 2003) and (Michel., 2001).

Therefore, it is required to use mechanisms that pre-

vent the security administrator from improper use of

the system like the intrusion detection system (Spaf-

ford., 2000). The aim of intrusion detection system is

the ﬁnd malicious behaviors inside the network and to

automate the decision making process by keeping the

continuity of the normal network components tasks.

In this context, several methods are used to detect in-

trusion and to correlate alerts in order to ﬁnd propa-

gated network threat.

2.1 Mobile Autonomous Agents

Selker (Selker., 1994) and Morreale (Moreale, 1998)

348

Shili, M., Gharsellaoui, H. and Kanzari, D.

Distributed Intelligent Systems for Network Security Control.

DOI: 10.5220/0006009203480352

In Proceedings of the 11th International Joint Conference on Software Technologies (ICSOFT 2016) - Volume 1: ICSOFT-EA, pages 348-352

ISBN: 978-989-758-194-6

deﬁne an agent as a software component that performs

one or more communication tasks by acting in a pre-

set manner to reach predeﬁned ﬁxed goals. Besides,

Green (Green, 1997) deﬁnes mobile agent as a com-

putational entity which acts on behalf of other enti-

ties in an autonomous fashion, performs its activities

with some level of pro-activity and reactivity, exhibits

some degree of the key attributes of learning, co-

operation and mobility. Jaisankar et al., (Jaisankar.,

2009) showed that an autonomous agent has the ca-

pacity to detect unknown attacks without any pre-

requisite knowledge about speciﬁc attacks by survey-

ing the anomalous user activity. Mobile Agents re-

quire code source development and resource deploy-

ment for each agent. Moreover, the existence of noisy

and data disruption can inﬂuence the agent to transfer

wrong information.

2.2 Genetic Algorithms

Hoque et al. (Sazzadul., 2012) discuss the capacity

of genetic algorithms to detect various types of net-

work intrusions. In this context, genetic algorithms

are used to ﬁnd optimal solutions for network secu-

rity. Potential solutions detected are encoded as se-

quences of bits, characters or numbers. The unit of

encoding called a gene, and the encoded sequence is

called a chromosome. The genetic algorithm begins

with a set (population) of these chromosomes and an

evaluation function that measures the ﬁtness of each

chromosome, the goodness of the problem solution

represented by the chromosome. It uses reproduction

and mutation to create new solutions, which are then

evaluated. The selection of chromosomes for sur-

vival and recombination/evaluation sequence is iter-

ated many times and if the problem is constructed, the

strong solution gradually emerges. The issue in using

genetic algorithms is that they require a ﬁne deﬁnition

of the problem with predeﬁned complete variables.

2.3 Data Mining

Nguyen and Choi, (Nguyen., 2008) proved the util-

ity of data mining to detect real-time network attacks

by identifying suspicious patterns in row data. In this

context, a set of classiﬁed algorithms using knowl-

edge dataset allow to extract knowledge from volumi-

nous quantity of heterogeneous data. This technique

permits to treat a several system audit-ﬁles issued

from distant systems, to extract information about

current trafﬁcs and to check the presence of known

correlated attack signatures. Data mining requires an

enormous updated signature base to detect developed

attacks.

2.4 Expert System

Anderson et al. (Anderson, 1995) use expert rules to

characterize a known intrusive activity represented in

activity logs. The expert system is based on a set of

rules that encode the knowledge of a human expert.

These rules reﬂect the partially ordered sequence of

actions that comprise the intrusion scenario. Some

rules may be applicable to more than one intrusion

scenario. Expert system permits the incorporation of

an extensive amount of human experience into a com-

puter application to identify activities that match the

deﬁned characteristics of attacks. Unfortunately, ex-

pert systems require frequent updates to remain reli-

able.

2.5 Neural Networks

Ning (Ning., 2002) and Ghosh et al. (Ghosh., 2000),

show the ability of a neural network that detects il-

legitimate network used through monitoring unusual

user activity. The neural network is used to learn the

user normal activity and to alert the abnormal user be-

havior. Despite the expert systems, which can provide

the user with a deﬁnitive answer, if the characteristics

which are reviewed exactly match those which have

been coded in the rule base, the neural network will

conduct an analysis of the information and provides

a probability estimate that the data matches the char-

acteristics which has been trained to recognize. The

application of neural networks for intrusion detec-

tion has been investigated by a number of researchers

to perform anomaly and misuse detection (Cuppens.,

2002), (Ning., 2002) and (Ning., 2001). Most of these

techniques require an accurate deﬁnition of attack sig-

natures to establish a correlation between alerts. Also

with a noisy environment and data disruption they

cant give correct results. This inconvenient can be

solved by unsupervised learning machine tools like

neural network which has a great ability to treat noisy

and incomplete unknown data and to produce accu-

rate results by means of learning experiences. In our

approach, we will use distributed intelligent agents

based on neural network technique that collaborate to

detect propagated attacks in network.

3 DISTRIBUTED INTELLIGENT

AGENT FOR NETWORK

SECURITY CONTROL

We propose a set of distributed controllers agents that

survey the tasks of interconnected systems in order to

Distributed Intelligent Systems for Network Security Control

349

detect the presence of network threats. The system is

presented by a set of connected nodes. Each node is

surveyed by a local agent controller. Once an attack

is detected in a node, an alert describing the attack

is diffused from the local agent controller to the cen-

tralized agent monitor. The latter receives alerts and

shows the network components ”states”. The super-

vising process is dividedin two parts; the local control

at each sub network and the central control that col-

lects important alert from the local controllers. The

system control process can be described as follow:

• Capture of data process: this process has the role

of a sniffer which collects data packets from the

network interface. For the security reasons, this

interface would be invisible to the users of net-

work, to protect it from misuse.

• Storage of data process: it converts and records

the collected data packets into speciﬁc data struc-

tures.

• Analysis of data process: this process has a del-

icate task to support the responders engines to

make decision. It studies the incoming data to the

network to detect the occurrence of distributed at-

tack.

• It monitors activity in the network and compares

them against knownpatterns of intrusive or hostile

activities. If the result of the analysis is positives,

then data packets are classiﬁed as suspect and can

be added to the attacks base.

• Graph generation process: it draws a scheme to

show the different states of network nodes. Al-

tered nodes are ﬁlled with common color to in-

dicate the propagation of a speciﬁc attack in the

network.

4 DISTRIBUTED SECURITY

SYSTEMS MODEL

Our purpose is to correlate distributed events to show

the state of different network components in order to

take the right decision in case of threats. The Fig-

ure 1 models distributed controllers agent in network,

where each controller is presented by a node. Each

node is surveyed by intrusion detection agent. Once

an attack is detected in a node an alert describing the

attack is diffused from this agent to the centralized su-

pervising agent. The latter receives alerts and applies

correlation algorithms to recognize correlated intru-

sion attacks. The role of agent is to handle incoming

data and to infer signiﬁcant patterns to take the right

decision. Our system operates in two stages: ﬁrst, it

Figure 1: Distributed Control Agents.

applies a set of local agent controller, and then uses

a centralized coaching agent to combine the detectors

outputs. Each local detector examines part of the net-

work, extracts normal and attack signature from in-

put patterns detects, and then throws the results to the

monitor detector. The last merges then the incoming

results, eliminates overlappingdetections and extracts

the relationships between input patterns. The critical

role of the local intrusion detection agent is to extract

knowledge about fundamental information of attacks

from noisy and heterogeneous input data. The critical

role of the centralized intrusion detection agents is to

correlate between input distributed events to extract

the relationship between them, to detect the networks

components ”states”, and then to take the right deci-

sion.

5 EXPERIMENTATION RESULTS

The aim of the experimentation is to evaluate the role

of the local control agent and the central control agent

to protect network from malicious uses.

5.1 The Local Control Agent (LCA)

Function

As shown in Figure 2, the Local Control Agent

(LCA); based on machine learning technique, studies

in real-time the input patterns and then extracts intrin-

sic features that classify data into two categories:

• Normal data: regular data,

• Suspicious data: attack signature,

• The LCA while using a classiﬁcation algorithm

would:

– rely on different predeﬁned and permanently

updated scenarios stored in a database,

– ﬁlter newly incoming data and ultimately,

– Report any suspicious data to the Central Con-

trol Agent (CCA).

ICSOFT-EA 2016 - 11th International Conference on Software Engineering and Applications

350

Figure 2: Local Control Agent Model.

Figure 2 presents the following notations:

• e1, e2, e3, and e4: are input events about system

activities,

• C: data classiﬁcation in normal or suspicious

class.

5.2 The Central Control Agent (CCA)

Function

The Central Control Agent (CCA) is based on ma-

chine learning paradigm; it gives the ﬁnal decision

about the set of input data from local controllers. It

speciﬁes the state of the network, three observations

are then possible:

• The presence of a propagated attack,

• The presence of independents attacks,

• The absence of any attack,

The CCA uses an algorithm of data extraction that

allows identifying similar or varied suspicious data

from different LCA. So this central controller cor-

relates input data from different network nodes and

takes the decision about the presence of propagated

attacks in the network, and so to send directive re-

sponses to the local controllers nodes to either remove

an unnecessary local response (ﬁrewall ﬁltering rule),

or to add a response (ﬁrewall ﬁltering rule along an al-

ternate attack path). It is expected to collaborate with

the others network components; example the domains

network management facilities, to select the optimal

points in the network to block harmful connections in

the presence of serious attacks. The CCA generates

as output a graphical representation of the distributed

network nodes. The affected nodes are marked by a

distinguished color. These nodes are connected by a

set of edges. The nodes and edges are described by a

set of attributes. Nodes attribute is made up of pairs

(Clef: Designation) of values that represents the ad-

dress and the name of the network components. The

edges are numbered to mark the order of attack prop-

agation. When an attack is presented, the central con-

troller constructs an illustrative oriented schema rep-

resenting the spread of attacks among network from

source to target nodes. This schema is based on input

Figure 3: Local Controller Input Information.

information about distributed network nodes as illus-

trated by Figure 3. So the sequence off input events

e1, e2, e3,e4 ,.. Forwarded to the central controller is

translated into sequence .

• 111281781581000580184501190000,

• 1212817815810001023191505193010 ,

• 2212817815710007180185918191622,

• 3512817815610008053194501200050...

For example, we assume that the presented attack on

the network is Deny of Service (DoS) which is refer-

enced by the number 3. Then the input data to the cen-

tral controller that contains the sequence ”111” shows

that the resource component is attacked by the DoS.

The central controller activates nodes that represent

network affected hosts by this attack (see ﬁgure). An

example of the input data and the output data of the

central control agent is illustrated by the Figure 4 and

an example of the output central controllers graph that

represents the attack propagation in network is illus-

trated by the Figure 5.

Figure 4: Central Controller Input and Output Data.

Figure 5: Network Attack Propagation.

6 CONCLUSION

To reach a best level of distributed system security, we

have proposed in this article two types of controllers;

Distributed Intelligent Systems for Network Security Control

351

the Local Control Agent (LCA) that detects the pres-

ence of attacks on its operating system and the Cen-

tral Control Agent (CCA) that detects the presence of

propagated network attacks. Using LAC and CCA are

only the two of many resources that can be deployed

to increase visibility and control within a corporate

computing environment, the concept of defense in-

depth is the emphasis on using the best defensive tech-

nologies and mechanisms within your organization to

craft the appropriate security environment. This paper

suggests an architecture that employs both LAC and

CCA technologies used together to strongly inﬂuence

an organizational security posture, using both tech-

nologies in a harmony will ensure the needed tools

and the appropriate defensive techniques to combat

zero day and existing threats while also having the

visibility into internal networks and the ability to sup-

ply forensic data and trend analysis. On the future

works, we aim to develop the agents’ structures that

perform collaborated detection of composed attacks.

REFERENCES

Zimmermann., J., Ludovic., M., Christophe B. (2003). An

Improved Reference Flow Control Model for Policy-

Based Intrusion Detection. In proceedings of the 8th

European Symposium on Research in Computer Secu-

rity (ESORICS).

Prigent., N., Bidan., C., Heen. O., Durand. A., (2003). Scu-

rit des rseaux domestiques. SSTIC’03, 1er Symposium

sur la Scurit des Technologies de l’Information et de

la Communication. Rennes.

Ludovic., M., (2003). Dtection des intrusions dans les

systmes dinformation: la ncessaire prise en compte

des caractristiques du systme surveill. HDR, Univer-

sit de Rennes 1.

Michel., C., Ludovic., M., (2001). ADeLe: an Attack

Description Language for Knowledge-based Intrusion

Detection. In Proceedings of the 16th International

Conference on Information Security. KluIr.

Cuppens., F., Mige., A., (2002). Alert Correlation in a

Cooperative Intrusion Detection Framework. In IEEE

Symposium on Security and Privacy.

Ning., P., Reeves., D., (2002). Constructing Attack Scenar-

ios through Correlation of Intrusion Alerts. In CCS.

Ning., P., Reeves., D., Cui., Y., (2001). Correlating Alerts

Using Prerequisites of Intrusions. Technical Report,

TR-2001-13, North Carolina State University, Depart-

ment of Computer Science.

Ning., P., Cui., Y., Reeves., D., (2002). Analyzing Intensive

Intrusion Alerts via Correlation. In Recent Advances

in Intrusion Detection.

Nguyen., H., Choi., D., (2008). Application of Data Min-

ing to Network Intrusion Detection: Classiﬁer Selec-

tion Model. Springer-Verlag Berlin Heidelberg, pages

399–408.

Ghosh., A., Michael., C., and Michael., S., (2000). A Real-

Time Intrusion Detection System Based on Learning

Program Behavior. Reliable Technologies, USA.

Selker., T., (1994). Coach: A teaching agent that Learns.

Communications of the ACM, Volume 37, Issue 7.,

pages 547–570.

Moreale., P., (1998). Agents on the Move. IEEE Spectrum,

pages 34–41.

Green., S., Hurst., L., Nangle., B., Cunningham., P.,

Somers., F., and Evans., R., (1997). Software Agents:

A Review. Technical report. Trinity Collega, Dublin,

Ireland.

Spafford., H., Zamboni., D., (2000). Intrusion detection us-

ing autonomous agents. Computer Networks, Volume

34, Issue 4., pages 547–570.

Jaisankar., N., Saravanan, K., Durai S., (2009). Intelligent

intrusion detection system framework using mobile

agents. International Journal of Network Security and

Its Applications (IJNSA), Volume 1, Issue 2.,

Sazzadul., M., Abdul, M., Abu Naser B., (2012). An imple-

mentation of i ntrusion detection system using genetic

algorithm. International Journal of Network Security

and Its App lications (IJNSA), Volume 4, Issue 2.,

Anderson D., Frivold T., and Valdes A.,. (1995).

Next-generation intrusion detection expert system

(NIDES): A summary. Technical Report SRI-CSL-95-

07, Computer Science Laboratory, SRI International,

Menlo Park, California.

ICSOFT-EA 2016 - 11th International Conference on Software Engineering and Applications

352
