Mobile Data Store Platforms: Test Case based Performance Evaluation

Karim Kussainov and Bolatzhan Kumalakov

School of Science and Technology, Nazarbayev University, Kabanbay batyr 53, Astana, Republic of Kazakhstan

Keywords:

Mobile Database, SQLite, Realm, SnappyDB, Performance Evaluation.

Abstract:

Mobile applications are an important tool in knowledge management, as they collect and process massive

amount of user data. Day-to-day usage of mobile services has rocketed by factors over the last decade. Average

mobile device user installs multiple social network, messaging, professional and leisure applications. Saving

and retrieving associated data becomes a challenging task in the light of the growing number of applications on

a single device. While industry offers several well established platforms, such as BerkeleyDB and UnQLite,

we examine comparatively poorly examined Realm and SnappyDB against industry standard - SQLite. In

particular we are interested in performance and code maintainability, and use a test case in order to asses

them. Results revile that SQLite shows the poorest performance, while Realm provides the most intuitive way

of matching data to the application logic due to its object-oriented nature.

1 INTRODUCTION

The number of mobile services has rocketed by fac-

tors over the last decade. Average handheld device

user installs multiple social network and messaging

applications, apart from work related and, possibly,

gaming software. Storing state variables, user prefer-

ences and other data segments puts pressure on mo-

bile database engines, which have to cope with the

workload in order to support desired user experience.

Industry offers a range of solutions. SQLite is

a widely adopted mobile database management sys-

tem (Kreibich, 2010). It implements relational data

model, and natively supports industry standard - SQL

language speciﬁcation. All major mobile operat-

ing systems in the market support it, while Android

comes with the pre-installed version by default.

Major players in the market offer at least a dozen

alternative solutions, such as BerkeleyDB and Un-

QLite. Most of them are well tested and positioned

against each other. NoSQL movement, however, also

offers emerging, but promising SnappyDB (Hachicha,

2016) and Realm (Realm, 2016) database engines.

SnappyDB is an open source “key-value” database

management system for Android OS. It is based on

Googles LevelDB storage library, which was initially

designed to overcome relational data model perfor-

mance boundaries by eliminating notions of relation

and referential integrity. It also makes advanced use

of compression algorithms, thus, attempts to optimize

disc space usage as well.

Realm, on the other hand, is a cross-platform,

object-oriented database engine that can be deployed

on Android and iOS devices. It requires storable ob-

jects to extend RealmObject class and deﬁne its ac-

cess methods. The data is stored encapsulated, and

access operations are performed in an object-oriented

manner.

This paper presents comparative performance

evaluation of SQLite, SnappyDB and Realm database

engines. Results revile that SQLite shows the poorest

performance, while Realm provides the most intuitive

way of matching data to the application logic due to

its object-oriented nature.

Remainder of the paper is structured as follows:

Section 2 deﬁnes research design, including test

cases, evaluation criteria and tools. Section 3 presents

experimental results and corresponding discussion,

while Section 4 concludes the paper.

2 RESEARCH DESIGN

Mobile databases are local storages, which operate on

machines with limited computing and storage capa-

bilities. In order to ensure realistic evaluation results,

test runs are performed on the same mobile device,

one after another. They do not overlap, but run on top

of a realistic set of common user applications, such as

WhatApp, Instagram and Telegram.

Kussainov, K. and Kumalakov, B.

Mobile Data Store Platforms: Test Case based Performance Evaluation.

DOI: 10.5220/0006032300950099

In Proceedings of the 8th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2016) - Volume 3: KMIS, pages 95-99

ISBN: 978-989-758-203-5

2.1 Experiment Design

2.1.1 Read and Write Performance Evaluation

Design

Since mobile database systems follow centralized

DBMS architecture pattern, concurrent queries are

organized into a queue. The database engine then

processes it using threads. This in the worst case

is a sequential process, if majority of processes

try to process the same data segment. Thus, in-

stead of modelling concurrent processes that perform

read/write operations, we utilize single test applica-

tion that performs them with data segments of differ-

ent size. Database object/table structure stores two

ﬁelds/columns: planet and radius.

In order to test write performance we: ﬁrst, ini-

tiate single entry of “mars” and “3000” values; sec-

ond, perform multiple entries of 10000 random char-

acter long strings. Corresponding processing times

are logged by the client application.

Read performance, on the other hand, is tested

using two experiments. First queried number of en-

tries in the database and returned their total num-

ber. Prior to execution, SQLite and Realm got 30000

randomly generated entries per entity/RealmObject.

SnappyBD, however, searches values by its key pre-

ﬁx. Thus, in order to generate 30000 values it re-

quired generating corresponding number of unique

keys, while in order to perform the operation it is not

necessary to apply count function to the number of

returned values. In SQLite query results had to be

processed using following method:

cursor.getCount();

For the second experiment we query all the plan-

ets, where radius is less than 4000. Data set contained

12000 objects/keys-value pairs that satisfy the con-

straint. Similarly to the previous experiment, SQLite

and Realm utilize build-in functionality:

select * from planets Where radius<4000;

for SQL and

realm.where(Planet.class).lessThan(radius, 4000)

.findAll();

for Realm respectively. SnappyDB, on the other hand,

adds the key to the list every time it comes across one

that starts with “Planet,” which also corresponds to a

value less than 12000.

Second, we measure RAM consumption during

10000 character long string value write operations ex-

ecution. In order to do so we use native android mem-

ory investigator and Cool Tool application. Both re-

port memory usage, and we were interested in average

and maximum consumption rate.

Finally, we alternate test application functional-

ity and measure how many lines of code had to be

modiﬁed in terms of database access. Which in-

cludes database query commands, response handling

and data matching.

2.1.2 Test Application Design

Test application implements three core functions:

adding entry, querying data and deleting them. The

use case diagram (Figure 1) illustrates the concept us-

ing UML 2.0 use case diagram.

Figure 1: Figure presents UML 2.0 Use case diagram,

which visualizes Test application functionality.

For the experiment proposes we developed three

Android applications, which implement the same

functionality. Most of the code was reused to guar-

antee that the only difference is in data store handling

part.

Figure 2 illustrates how write operation is per-

formed on its implementation level.

Figure 2: Figure presents UML 2.0 Sequence diagram for

”Add entry” procedure.

KMIS 2016 - 8th International Conference on Knowledge Management and Information Sharing

2.2 Implementation Details

Test applications were developed using Android Stu-

dio version 1.5.1, and installed on LG Nexus 5. The

device runs Android 6.0.1, and has quad-core Snap-

dragon 800 CPU (2.26 MHz) with 2 GB of RAM.

SQLite database engine came with the operating sys-

tem, while SnappyDB and Realm had to be installed

manually.

We performed following operations in order to

conﬁgure the environment:

• set “multiDexEnabled” to true in application level

“build.gradl” conﬁguration ﬁle to facilitate work

with the SQLite database.

• add SnappyDB (version 0.5.0) .jar ﬁle to the

“jniLibs”, and corresponding ﬁeld to the depen-

dencies ﬁeld in application level “build.gradl”.

• install Realm (version 0.88.3) plugin, and add

class path dependency to the project level

“build.gradl”.

Initial application design includes EditText ﬁelds,

TextViews and several buttons. EditText ﬁelds are

used to add an entry to the database. TextViews dis-

play results such as status logs and time consumed.

Every operation is written as a button handler. Figure

3 presents a screenshot of the testing client applica-

tion.

3 EXPERIMENTAL RESULTS

3.1 Test Results

3.1.1 Memory Consumption

The experiment is designed in such a way, that it

is impossible to completely separate RAM usage of

the database engine and common user applications.

Nonetheless, given that we avoided active use of these

applications (only the background services run con-

stantly) it is possible to assume equal conditions.

When in stand-by mode average memory use of the

mobile device ranged from 200 KB to 2 MB. Table 1

presents memory consumption data during the tests.

Table 1: Table presents memory consumption data.

Platform name Average Maximum

SQLite 81 MB 115 MB

SnappyDB 12 MB 66 MB

Realm 15 MB 69 MB

Figure 3: Figure presents a screenshot of the client appli-

cation, which performs test entries and logs the execution

time. When the data is collected it is loaded to the MS Ex-

cel software to derive statistical data.

RealmTest and SnappyTest applications used

maximum of 60-70 MB, while SQLite consumed up

to 115 MB.

SnappyDB showed the lowest memory consump-

tion of about 12 MB and Realm needed up to 15MB

on average. SQLite showed different results in a dif-

ferent tests, ranging from 24 to 130 MB. Refreshing

rate of the app is one second and both SnappyDB and

Realm usually use less than one second.

3.1.2 Read/Write Performance

Difference in performance when writing single entry

is very little. SnappyDB shows the slowest result,

there is no sharp decline in performance for writing

a string of 10000 characters and a number. However,

there is a considerable difference in performance dur-

ing high amount of writing operations. While Realm

and Snappy manage to push 10000 data pairs within

1 second, it takes about 80000 seconds for SQLite to

do the same. Please, note the logarithmic scale in the

Figure 4.

Realm is an undisputed leader in querying oper-

ations. It takes 8 ms to count 30000 items and 3-4

seconds to perform a simple query. SnappyDB needs

Mobile Data Store Platforms: Test Case based Performance Evaluation

Figure 4: Figure visualizes write performance data.

Figure 5: Figure visualizes read performance data.

100-120 ms in order to perform the same operations.

SnappyDB exhibits no difference between 30000 and

12000 elements to count. It takes about half of a sec-

ond for SQLite to count 30000 rows in one entity and

about 112 ms to perform a simple query and write re-

sult to the StringBuffer.

Finally, the standard VM heap size for Nexus 5 is

ﬁxed at 192 MB. In order to have reliable result, it

was manually increased through android.manifest ﬁle

to 512 MB.

3.1.3 Code Maintanability

Realm uses separate java classes for each type of ob-

jects (+20 lines in this example). It uses 1 line query.

Snappy querying is more complex due to the database

initialization and try-catch methods. On the other

hand, there is a simplest adding procedure in Snap-

pyDB. In Realm there are several lines of code with

respect to class setters. In SQLite there is only one

line of code.

3.2 Discussion

From the presented results we can see that platforms

show close code maintainability and memory usage

Table 2: Code complexity (LoC).

Platform AppTotal Add entry Query

SQLite 165 1 1

SnappyTest 186 3 5

RealmTest 159+20 6 1

characteristics. The only exception is the SQLite en-

gine, which in extreme cases uses eight times as much

RAM as the other ones. Of course, it may be justiﬁ-

ably argued that we consider highly unlikely scenar-

ios, which do not normally accrue in the real world.

Nonetheless, we try to take into account the high rate

of mobile database load explained earlier.

From the performance perspective SQLite also

shown poorer performance. In particular, it takes al-

most twice the time for performing write operations,

and ﬁve times as much time for read operations. We

are also aware that there are SQLite modiﬁcations

that show better performance than the standard edi-

tion, such as (Bakibayev et al., 2012). However, in-

stalling and conﬁguring them is not a standard pro-

cedure when the cell phone loses its service level.

Hence, they are of limited access to a common user.

SnappyDB has limited functionality, but it seems

to be the fastest in terms of reading/writing myriad

of entries. While it is mostly due to its data model

simpliﬁcation (the simplest among considered), there

is additional work for the software engineer when

matching data segments to object ﬁelds of the pro-

gram. Realm has also proven to be an alternative to

SQLite database. It is also easier to match data seg-

ments, because it makes use of object encapsulation.

Nonetheless, within the described performance

map choosing one database engine the other depends

on the dataset. Some data do not ﬁt into two-

dimensional row-column structure, while extracting

JSON segments create unnecessary computational

load (Dash, 2013). Relational databases are suitable

for complex queries, but lack ﬂexibility, which results

in difﬁculties when database scheme changes signiﬁ-

cantly. Hence, SQLite is a viable option for small to

medium datasets and solutions with low concurrency.

It is also widely accepted among mobile developer

community.

4 CONCLUSION

Paper presents case based comparative evaluation of

SQLite, SnappyDB and Realm mobile data store en-

gines. Test results revile that all of the solutions dis-

tribute close complexity in terms of code maintain-

ability and memory consumption.

In terms of performance, in extreme cases - such

KMIS 2016 - 8th International Conference on Knowledge Management and Information Sharing

as writing and reading large entries - SQLite showed

the poorest results, while Realm and SnappyDB are

signiﬁcantly faster. Nonetheless, SQLite better suits

applications with medium datasets and low concur-

rency.

Mobile applications are an important tool in

knowledge management, as they collect and process

user side conﬁgurations, logs, etc. Information re-

viled in this studies may be used when engineering

such systems to facilitate better data retrieval and save

when needed.

ACKNOWLEDGEMENTS

This work is supported by Nazarbayev University

(Astana, Kazakhstan) under its internal Social Policy

Grant scheme.

REFERENCES

Bakibayev, N., Olteanu, D., and Zavodny, J. (2012).

Demonstration of the FDB query engine for factorised

databases. PVLDB, 5(12):1950–1953.

Dash, J. (2013). RDBMS vs. NoSQL: How do you

pick? http://zdnet.com/article/rdbms-vs-nosql-how-

do-you-pick/. [Online; accessed 11-August-2016].

Hachicha, N. (2016). A fast and lightweight

key/value database library for android. http://

www.snappydb.com/. [Online; accessed 20-April-

2016].

Kreibich, J. A. (2010). Using SQLite - Small. Fast. Reliable.

Choose any Three. O’Reilly.

Realm (2016). Realm is a replacement for sqlite and core

data. https://realm.io/. [Online; accessed 25-April-

2016].

Mobile Data Store Platforms: Test Case based Performance Evaluation
