Ensuring Action: Identifying Unclear Actor Speciﬁcations in Textual

Business Process Descriptions

Ulf Sanne

, Hans Friedrich Witschel

, Alessio Ferrari

and Stefania Gnesi

Fachhochschule Nordwestschweiz, Riggenbachstr. 16, 4600 Olten, Switzerland

ISTI, CNR, Via G. Moruzzi 1, 56124 Pisa, Italy

Keywords:

Business Process Management, Quality Assessment, Natural Language Processing.

Abstract:

In many organisations, business process (BP) descriptions are available in the form of written procedures, or

operational manuals. These documents are expressed in informal natural language, which is inherently open

to different interpretations. Hence, the content of these documents might be incorrectly interpreted by those

who have to put the process into practice. It is therefore important to identify language defects in written

BP descriptions, to ensure that BPs are properly carried out. Among the potential defects, one of the most

relevant for BPs is the absence of clear actors in action-related sentences. Indeed, an unclear actor might lead

to a missing responsibility, and, in turn, to activities that are never performed. This paper aims at identifying

unclear actors in BP descriptions expressed in natural language. To this end, we deﬁne an algorithm named

ABIDE, which leverages rule-based natural language processing (NLP) techniques. We evaluate the algorithm

on a manually annotated data-set of 20 real-world BP descriptions (1,029 sentences). ABIDE achieves a recall

of 87%, and a precision of 56%. We consider these results promising. Improvements of the algorithm are also

discussed in the paper.

1 INTRODUCTION

In several contexts, which range from private compa-

nies to public administrations, business process (BP)

descriptions are available in natural language. In-

deed, although more formal graphical notations have

emerged to model BPs, such as BPMN (Business

Process Modelling and Notation) or YAWL (Yet An-

other Workﬂow Language), most of the legacy pro-

cess knowledge – when not tacit – is still conveyed in

paper-like documents, which have the form of proce-

dures or operational manuals. In addition, even when

graphical models are available, these are often com-

plemented by textual descriptions (Schumann et al.,

2014). Indeed, as noted by Ottensooser et al. (Otten-

sooser et al., 2012) and by Navrocki et al. (Nawrocki

et al., 2006), the understandability of a BP model is

higher when complemented with text. On the other

hand, given the informal nature of natural language,

textual descriptions might be unclear. In particular,

Sommerville highlights that, if a process description

does not assign a clear responsibility for tasks that are

part of the process – i.e., if the actor is unclear – this

might result in several organizational vulnerabilities

(Sommerville, 2007), namely: (a) unassigned respon-

sibility – i.e., the task is not performed, since nobody

is in charge; (b) duplicated responsibility – i.e., the

task is performed by more than one actor, with du-

plicated effort; (c) uncommunicated responsibility –

i.e., the task remains undone, since the actor in charge

of the task is not aware of his/her responsibility. Al-

though this problem might be addressed with the in-

troduction of, e.g., BPMN models, in which activity

icons and swim lanes support the speciﬁcation of ac-

tors, the problem might remain in the text that com-

plements such models.

Several studies were performed in the literature to

improve the quality of BP descriptions expressed as

models, to ensure their correctness (Morimoto, 2008),

and to improve their understandability (Reijers and

Mendling, 2011). Furthermore, studies were also per-

formed to identify defects in the textual labels of BP

models (Leopold et al., 2013), and to generate textual

descriptions from BP models (Leopold et al., 2014).

However, none of the studies addresses the problem

of the quality of the description of BP written by hu-

man editors.

This paper aims at ﬁlling this research gap. In par-

ticular, we focus on the detection of unclear actors

in BP speciﬁcations written in natural language. To

140

Sanne, U., Witschel, H., Ferrari, A. and Gnesi, S.

Ensuring Action: Identifying Unclear Actor Speciﬁcations in Textual Business Process Descriptions.

DOI: 10.5220/0006040301400147

In Proceedings of the 8th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2016) - Volume 3: KMIS, pages 140-147

ISBN: 978-989-758-203-5

this end, we designed and implemented an algorithm

named ABIDE (unclear Actor detection in BusIness

process DEscription). The algorithm leverages a set

of heuristics, and makes use of rule-based natural lan-

guage processing (NLP) techniques to identify state-

ments with unclear actors, including cases of miss-

ing actor – i.e., when the actor is not speciﬁed and

thus a case of unassigned or uncommunicated respon-

sibility might result –, meaningless actor – i.e., the

term that identiﬁes the actor does not have sense in

the context of the document (again, unassigned re-

sponsibility may be the result) –, and ambiguous ac-

tor – i.e., the term that identiﬁes the actor can be in-

terpreted in different ways, which might lead to du-

plicated responsibility. To evaluate ABIDE, we em-

ployed a set of 20 real-world BP descriptions (1,029

sentences), which were previously annotated for clar-

ity defects by human operators. Then, we deﬁned

two classical baseline algorithms – never warn and

warn randomly – against which we compared the per-

formance of ABIDE in predicting the manual anno-

tations. ABIDE outperforms the two baselines, and

achieves a recall of 87% and a precision of 56% on

the data. To our knowledge, this is the ﬁrst work that

addresses the problem of unclear actors in BP descrip-

tions, and we consider these results a promising start-

ing point.

2 RELATED WORK

Our research is related to research in the area of de-

scription of business processes – in particular regard-

ing the assignment of roles and responsibilities – and

to research on clarity of natural language descriptions

in general.

2.1 Principles for Describing

Responsibilities in Business

Processes

Formal notations for the description of business pro-

cesses include means to express responsibility for ex-

ecuting an action – for instance, BPMN (OMG, 2011)

foresees swimlanes to represent roles or actors re-

sponsible for any activity. In military orders, the 5-W

principle is used to describe an action (Lind and Lu-

bera, 2009), including, besides the what, where, when

and why also the who, i.e. who is responsible for an

action.

Concerning the assignment of responsibilities,

previous research has distinguished different types of

responsibilities. The so-called RACI charts (Smith

and Erwin, 2005) summarize the common ways how

people can be involved in a particular activity. The ab-

breviation RACI stands for responsible, accountable,

consulted and informed. In our work, we concentrate

on responsibility. Indeed, from the business process

perspective, consulted persons are not actors, but re-

sources used in activities (Ciabuschi et al., 2012). In-

formed actors do not actively contribute, which turns

them into stakeholders rather than actors (Voinov and

Bousquet, 2010). Finally, accountability is rather a

legal than a functional term.

Within RACI, the deﬁnition of “responsible” is as

follows: “The actor technically responsible. It means

that he or she is in charge of carrying out the activ-

ity under given circumstances and with given means

and resources. Responsibility can be shared.” In our

research, we investigate to what extent responsibility

for an activity – as given by this deﬁnition – is clearly

deﬁned by a textual BP description.

2.2 Text Clarity

There is extensive literature that promotes principles

ensuring clarity, conciseness and the absence of tech-

nical jargon in written communication. Examples

of such literature include The Plain English Guide

(Cutts, 1996) or the reference book Style: Toward

Clarity and Grace (Williams and Colomb, 1995) –

containing practical examples and guidelines of how

to write clearly.

In terms of clarity defects, ambiguity has been

studied extensively in scientiﬁc work. Ambigu-

ity of terms is an open problem in the computa-

tional linguistic community, and is traditionally as-

sociated to the so-called word-sense disambiguation

(WSD) task (Navigli, 2009; Ide and V

eronis, 1998).

Several approaches exist that address this problem,

which use unsupervised (Agirre and Edmonds, 2007;

eronis, 2004), supervised (Lee and Ng, 2002) and

knowledge-based approaches (Banerjee and Peder-

sen, 2003; Navigli and Velardi, 2005).

Ambiguity as a quality defect has been largely

studied in the ﬁeld of requirements engineering. In

software engineering, requirements need to be under-

stood by different stakeholders and should be as lit-

tle ambiguous as possible to avoid misunderstanding

among the stakeholders. Therefore, several studies

have been performed to categorise and detect ambi-

guities in NL requirements.

Part of the works are focused on the identiﬁcation

of typical ambiguous terms and constructions (Berry

and Kamsties, 2005; Berry et al., 2003; Gnesi et al.,

2005; Wilson et al., 1997; Gleich et al., 2010). One of

the seminal works on ambiguity in requirements is the

Ensuring Action: Identifying Unclear Actor Speciﬁcations in Textual Business Process Descriptions

141

one of Berry et al. (Berry et al., 2003), which has been

implemented in tools such as QuARS (Gnesi et al.,

2005) and ARM (Wilson et al., 1997) – which detect

lexical ambiguities, based on vague, weak or subjec-

tive expressions (e.g., “as soon as possible”, “reason-

ably”). Another research direction tries to translate

text into some kind of formal representation in order

to automatically detect problems with its interpreta-

tion (Ambriola and Gervasi, 2006; Kof, 2010). Work

on syntactic ambiguity in requirements has focused

on anaphoric (e.g., (Yang et al., 2011)) – i.e., associ-

ated to the interpretation of pronouns – and coordina-

tion ambiguities (e.g., (Chantree et al., 2006)) – i.e.,

associated with coordinating conjunctions.

To the best of our knowledge, no research has

been conducted to address quality defects related to

the (lack of) clarity of actor speciﬁcations in textual

business process descriptions. For the reasons out-

lined above, we consider this a relevant gap that our

research tries to close.

3 DATA-DRIVEN PROBLEM

AWARENESS

In order to better understand “actor unclear” defects

in textual business process descriptions, we ﬁrst com-

piled a corpus consisting of documents that describe

procedures in public administrations.

In order to select the documents, we ﬁrst identi-

ﬁed websites that include pointers to publicly acces-

sible BP descriptions (e.g., the US Nuclear Commis-

sion Website

, the UK Health and Safety Website

the US Court Website

) and then selected a set of 20

documents from those Websites, containing a total of

1,029 sentences. In doing so, we excluded documents

requiring special expertise (e.g. that of a lawyer), as

well as high-level regulations.

We then recruited 17 annotators and made sure

that all documents from the data set were annotated by

at least two annotators. We instructed the annotators

by means of examples of defective sentences and told

them to tag in a sensitive way, i.e. be rather strict in

tagging sentences as defective. The tagging resulted

in 126 sentences being annotated as having an unclear

actor. This may only occur when the sentence de-

scribes a BP activity, i.e., something that would be

translated into an activity shape in BPMN, such as

http://www.nrc.gov/about-nrc/policy-making/

internal.html

http://www.hse.gov.uk/foi/internalops/

http://www.uscourts.gov/rules-policies/

current-rules-practice-procedure

a Task or a Process. Hence, our ﬁrst objective was

to identify which were these types of sentences, and

in which way they differed from other types of sen-

tences. By manually analysing the data-set, we iden-

tiﬁed 8 types of sentences in the textual BP descrip-

tions. Activity sentences describe an instruction to

be performed by some actor involved in the BP. Ex-

ample: The LEAP Academy employee will submit to

the Commissioner of Education an enrollment report

for the forthcoming year by June 1. Business rules

ban or enforce actions or results of actions. Exam-

ple: The EPBR application shall adhere to the tem-

plate in annex A. Motivational statements explain

the purpose or goal of a process. Example: The for-

mal second opinion (FSO) procedure is an important

part of ensuring that OSD maintains high standards

of assessment decision-making. Introductory sum-

maries summarize brieﬂy a set of activities and other

process features in advance, without claiming to com-

prise all necessary information. Example: After sub-

mission, each application will be subject to a two-step

selection procedure. Repeating summaries provide

a brief repetition of what has been explained before,

to reinforce the reader’s memory or highlight impor-

tant aspects. Example: After completion of all steps

described above, the project manager has now es-

tablished a full list of relevant stakeholders end their

concerns in the project. Activity meta-information

constitutes additional information about an activity,

which does not belong to the activity description it-

self. Example: The required realtime coordination of

the distributed deployment team is possible, since the

team is equipped with mobile communication devices.

Background information describes background or

context. Example: The City of Austin has established

a major event initiative that is supported by the Police

Department, EMS and Fire Department. Deﬁnitions

explain a term for later use. Example: The Service

Conference is a meeting in which the applicant and

the other parties involved discuss about the applica-

tion.

For our task, we considered only the sentences of

the ﬁrst type, since they were those that could po-

tentially include an unclear actor defect. Hence, we

manually identiﬁed activity sentences in the data-set.

The analysis resulted in 255 sentences, including the

previously annotated unclear actor defects (126 sen-

tences). From now on, this annotated set of sentences

will be referred to as the gold standard.

We then analysed the defects that had been anno-

tated in order to understand which categories of prob-

lems exist and what solutions might help to resolve

them. The result of this analysis was the identiﬁca-

tion of three main problem classes, namely:

KMIS 2016 - 8th International Conference on Knowledge Management and Information Sharing

142

• Missing Actor: the sentence does not include any

explicit actor;

• Meaningless Actor: the sentence includes an ex-

plicit actor, but a human reader may not under-

stand what is meant by the term used to identify

the actor;

• Ambiguous Actor: the sentence includes an ex-

plicit actor, but there is more then one way to un-

derstand the meaning of the term used to describe

the actor.

Examples for each class are reported in Table 1.

The different heuristics that compose ABIDE are de-

signed to address these classes of defects.

4 A RULE-BASED ALGORITHM

FOR DEFECT DETECTION

4.1 NLP Technologies Adopted

Before describing the heuristics that we deﬁned to

identify the defects, it is useful to discuss shortly

the natural language processing (NLP) technologies

that we adopted to extract information from the doc-

uments, and that will be referred in the following

sections: The preprocessing starts with a sentence

segmentation of the text, followed by tokenization,

i.e. partitioning of the text into separate tokens, such

as words, numbers and punctuation. Next, Part-

of-Speech (POS) Tagging is performed which as-

sociates to each token a Part-of-Speech, e.g., noun

(NN), verb (VB), adjective (JJ), etc. The POS tag-

ging forms the basis for a shallow parsing that iden-

tiﬁes noun phrases (NP, “noun chunking”) and verb

phrases (VP, “verb chunking”) in sentences. This will

allow later to identify e.g. chunks that refer to actors.

Finally, we apply a Gazetteer which searches for oc-

currences of terms deﬁned in a list of terms. It can be

used to check for e.g. the presence of vague terms in

the documents.

Based on these preprocessing steps, out heuris-

tics were implemented within the tool GATE (Gen-

eral Architecture for Text Engineering (Cunningham,

2002)) in the form of so-called JAPE Rules. Such

rules allow deﬁning high-level regular expressions

over tokens and other elements in a text. They iden-

tify patterns of elements that match the rule. Since

JAPE rules can be rather long to report, we will use a

more concise and intuitive pseudo-code to present the

heuristics which is inspired by the JAPE grammar.

In JAPE, and in our rules, we use the usual sym-

bols from the syntax of regular expressions to express

e.g. logical conjunction or disjunction.

4.2 Heuristics for Missing Actor

The ﬁrst heuristics that we describe allows to identify

sentences in which the actor is missing. For sentences

in active form, an actor is missing only when a verb

in imperative form is used, e.g., in Delete the applica-

tion if the two-months period has expired. However,

in these cases, the actor is expected to be the reader

of the sentence. Hence, we do not consider these sit-

uations as cases in which the actor is missing. For

sentences in passive form, the actor is missing when

the sentence does not include a “by” clause to express

a subject, e.g., The procedure shall be carried out be-

fore the end of March 2015.

The former type of sentences are all those sen-

tences that include the following pattern:

MIS

= (Token ∈ Aux)

(Token.POS == V BN|V BD)(Token)∗

(¬“by”)

(1)

The pattern matches any case in which we have a

term that indicates the presence of at least an auxiliary

verb (Token ∈ Aux, i.e.,“am”, “are”, “were”, “being”,

“is”, “been”, “was”, “be”) followed by a past partici-

ple (VBN) or past tense (VBD). Moreover, the rule

checks the absence of the Token “by” in the same sen-

tence which is an indicator of the potential speciﬁca-

tion of an actor. The notation (Token)∗ indicates that

the verb might be followed by zero or more Tokens,

before the Token “by” is found. All the sentences in-

cluding the previous pattern are marked as Defective

by ABIDE.

4.3 Heuristics for Meaningless Actor

Even when a sentence includes an actor, the term used

to name the actor might not be understandable by

the reader, i.e., the actor is meaningless. To iden-

tify sentences with meaningless actors, ABIDE uses

the following heuristics. First ABIDE searches for

potential actors in the sentence. To this end, the

algorithm extracts subject-verb-object (SVO) triples

from the sentence, and names as potential actors all

the nouns playing the role of subject in the sentence.

Then, ABIDE checks whether all the potential actors

expressed in the sentence can be understood by the

reader. This is done by examining whether each of the

actors candidates in the sentence belongs to a dictio-

nary of terms and whether it is not an acronym. In par-

ticular, in our implementation, the algorithm checks

a) whether the term can be found in Wikipedia and

b) whether it is an acronym, i.e. consists of all up-

per case characters. The rationale of this approach is

the following: in the case of a), although the reader

Ensuring Action: Identifying Unclear Actor Speciﬁcations in Textual Business Process Descriptions

143

Table 1: Sub-classes of the actor unclear problem.

Problem class Description Example(s)

Actor missing An activity is described without

referring to an actor

The request for purchase form will be forwarded to

Purchasing (passive)

Actor meaningless The term referring to an actor can-

not be interpreted by the expected

target audience

The DCM and SCC shall supply copies of relevant

information [...]

Actor ambiguous The way an actor is referred to can

be interpreted in more than one

way

Finally, they must be dated, and signed by the rel-

evant person within the institution [...]

does not necessarily know the meaning of the term

expressing the actor, he/she can access Wikipedia and

associate a meaning to the actor. For b), we assume

that readers may not be familiar with acronyms if they

are not previously introduced in the text (or even then

might quickly forget their meaning) – our algorithm

does not check previous introduction of the full form

of acronyms, an extension that may be added as future

work.

To extract SVO triples, the algorithm leverages

shallow parsing, and checks each sentence for the fol-

lowing pattern:

SVO

= (NP)(V P)(NP) (2)

The pattern matches any triple in which we have a

noun chunk followed by a verb chunk and by a noun

chunk. The ﬁrst noun chunk is expected to include the

subject of the sentence. However, it might be com-

posed of more than one Token, as e.g., The principal

HDEC. For all the nouns in the ﬁrst NP in P

SVO

–

referred as Subject in the following – the algorithm

checks whether the noun can be found in Wikipedia.

To this end, the following pattern is applied:

UNK

= (Token.POS =∼ NN∗,

Token ∈ Sub ject,

Token /∈ Wikipedia|Acronym(Token))

(3)

The pattern matches any Token representing a

noun (i.e., all Tokens which have a POS starting with

), which is included in Subject, and that either

does not belong to the Wikipedia dictionary or is

recognised as an acronym – where Acronym(·) is a

predicate that is true if a token consists only of up-

per case characters (possibly separated by periods).

All the sentences including the previous pattern are

marked as Defective by ABIDE.

4.4 Heuristics for Ambiguous Actor

If the actor has a meaning that can be found in

Wikipedia, this does not imply that the actor is not

The notation =∼ matches regular expressions

ambiguous. Hence, we deﬁne three additional heuris-

tics to check for ambiguous actors. Three main cases

of ambiguous actor are identiﬁed by ABIDE:

1. Ambiguous Noun: an actor might be ambiguous

if the term that identiﬁes the actor can have differ-

ent meanings in different linguistic contexts. For

example, the term Assessor can be the assistant to

a judge or magistrate, in a legal context, and or an

an expert who calculates the value of property, in

the real-estate appraisal domain.

2. Ambiguous Pronoun: an actor might be ambigu-

ous if a pronoun – e.g., he, it, him, her – is used

to refer to more than one noun, as in the sentence:

The delegate assesses the presence of the candi-

date, and he provides his signature. Here, the pro-

noun he can be referred to the delegate or to the

candidate. These phenomena are normally called

anaphoric ambiguities (Yang et al., 2011).

3. Vague Modiﬁer: the name of an actor might be

associated with a vague modiﬁer as in The rele-

vant authority, or The proper ofﬁce.

To detect the cases described above, ABIDE lever-

ages the Sub ject element extracted from the P

SVO

pattern described in Sect. 4.3. In particular, to de-

tect cases of ambiguous nouns (case 1), it looks up

the Sub ject element in a list of ambiguous terms.

For our experiments, we have compiled a list of

such terms by analysing the previously annotated

gold standard (see Section 3). We identiﬁed sen-

tences describing an activity that had been tagged

as defects and checked whether they contained un-

clear terms in their subjects. We included such terms

in the list if we reckoned that they might occur in

BP description across several domains. The current

list is as follows: AmbiguousTermList = {“person”,

“responsible”, “ofﬁce”, “staff”, “employee”, “com-

pany”, “unit”, “those”, “all”, “somebody”, “team”}.

Of course such a list – being derived from a fairly

small corpus – cannot be claimed to be comprehen-

sive. We believe that it can be extended and tuned

for a domain when our approach is used in practice.

Another way to extend it automatically would be to

KMIS 2016 - 8th International Conference on Knowledge Management and Information Sharing

144

use bootstrapping approaches when descriptions are

quality-checked and hence manually annnotated in a

real-life setting. The following pattern summarises

the approach to detect ambiguous nouns:

AMB

= (Token.POS =∼ NN∗,

Token ∈ Sub ject,

Token ∈ AmbiguousTermList)

(4)

To check for ambiguous pronouns (case 2),

ABIDE simply checks whether the Sub ject element

includes a pronoun. This might lead to false posi-

tive cases. However, more complex machine learn-

ing methods are required to handle anaphoric ambi-

guities (Yang et al., 2011), which can however leave

some ambiguity undiscovered. To detect ambiguous

pronouns, the following pattern is applied:

AMB

= ((Token.POS == PP|

Token.POS =∼ PR∗),

Token ∈ Sub ject)

(5)

The pattern matches any Token representing a per-

sonal pronoun (PP), or other types of pronouns (PR∗),

which is included in Sub ject.

Finally to check for vague modiﬁers (case 3),

ABIDE checks whether the Sub ject element includes

one of the terms included in a list of vague modi-

ﬁers. In our implementation, we used the list adopted

by QuARS (Gnesi et al., 2005), which includes 446

vague terms. We refer this set with the name Vague.

We ﬁrst implemented the following pattern:

AMB

= (Token ∈ Vague,Token ∈ Sub ject) (6)

After some ﬁrst experiments with our data set, we

realised that the relevance of the cases of vague mod-

iﬁers was rather high, and that the low accuracy of the

shallow parsers adopted was preventing ABIDE from

ﬁnding cases of ambiguous subjects. We therefore re-

laxed our rule by using the following pattern:

AMB

= (Token ∈ Vague) (7)

In the following, we only used the pattern P

AMB

ABIDE marks as Defective any sentence that matches

one of the following patterns: P

AMB

, P

AMB

, P

AMB

5 EVALUATION

To evaluate the ABIDE algorithm, we used the gold

standard data set introduced in Section 3. It consists

of 255 sentences that describe an activity within a

business process. Of these, 126 were manually tagged

as defective. We ﬁrst describe the evaluation mea-

sures and baselines, then report results and ﬁnally

analyse potential improvements.

5.1 Baselines and Evaluation Measures

Our goal was to run ABIDE on the gold standard

and compare its annotations of defective sentences

to the manual ones, using measures such as pre-

cision, recall and F-measure. In order to be able

to judge the quality of these results, we compared

them to two baseline taggers: Baseline NONE is

a simple tagger that predicts no defect for every

sentence. It corresponds to having no quality control

for BP descriptions (a common approach in many

organisations). Baseline RANDOM annotates a

given sentence as defective with a given a priori

probability p. In our case, since roughly 50% of

all gold standard sentences are defective according

to human judgement, we used p = .5. We also

considered a “Baseline ALL”, which would mark all

sentences as defects – however, we conjecture that

applying that baseline in practice will not lead to a

perfect recall (i.e., to all defects being spotted) since

the human who will do the quality assurance and

who then has to look at every sentence will surely

overlook defects. Since this effect is hard to quan-

tify, we have not used such baseline in the experiment.

Standard measures such as precision and recall

give equal weight to both types of mistakes that

ABIDE can make – i.e., false positives and false neg-

atives. In practice, the impact of a false positive can

be substantially different from the impact of a false

negative.

One way to take this difference into account is to

use a version of the F-measure that places greater em-

phasis on, e.g., recall. Another option is a cost-based

evaluation where one estimates the negative impact

(cost) caused by each ABIDE decision. Figure 1 de-

picts the costs that we estimate to arise for our sce-

nario.

Figure 1: A cost matrix for prediction of defects.

Whenever ABIDE predicts a defect, a warning is

raised and a responsible person has to inspect the cor-

responding sentence. We assume that this causes an

average loss of time (i.e., cost) of C minutes – the

responsible has to re-consider the formulation of the

sentence and sometimes possibly to clarify the situa-

tion.

When ABIDE fails to identify a defective sentence

Ensuring Action: Identifying Unclear Actor Speciﬁcations in Textual Business Process Descriptions

145

Table 3: Categories of false positive passive sentences.

Error pattern Example Frequency

Passive in a part of the sentence which does

not describe the activity

The FSO OM shall use the information to consider

if the acceptance criteria are met.

X ensures that Y is done The Senior Administrator [...] ensures that all re-

quired registration documentation is ﬁled [...].

X is required/recommended/requested to do

Suppliers are expected to note interest in the con-

tract and request the ITT documents.

(i.e. when a false negative occurs), the sentence re-

mains in the ﬁnal process description. We optimisti-

cally assume that process executors who read the sen-

tence will not work on false assumptions, but will al-

ways spot the unclarity and attempt to clarify. Such

clariﬁcation – that may involve speaking to colleagues

or consulting other sources – causes a loss of time

(cost) that we estimate to be at least as high as the

above-mentioned cost C for handling raised warnings.

Process descriptions usually have to be read – at least

once – by all persons that are regularly involved in

process execution. If the number of such persons is

N, then, based on the above arguments, the cost of a

false negative is at least NC. In our evaluation runs,

we used C = 1 and N = 5 or N = 10, i.e. we assumed

a situation with 5, respectively 10 process executors

working based on a common process description.

5.2 Results

Table 2 shows the results of ABIDE and the two base-

lines in terms of precision, recall, F-measure and cost.

Table 2: ABIDE results.

Measure ABIDE NONE RANDOM

Precision 0.56 1 0.5

Recall 0.87 0 0.5

0.69 0 0.5

Cost (N = 5) 285 630 448

Cost (N = 10) 355 1260 768

Although ABIDE is far from perfect in terms of

precision, it clearly outperforms the baselines in terms

of both F-measure and cost, indicating that a quality

control based on ABIDE can help to save cost.

5.3 Qualitative Analysis

In order to derive potential future improvements of

ABIDE’s precision, we made an analysis of false pos-

itives, attempting to categorise them in terms of lin-

guistic patterns. It turned out that interesting “false

positive patterns” can be observed primarily in the

area of passive sentences (see Section 4.2).

Table 3 shows the three categories of false posi-

tive passive sentences that we identiﬁed in the data,

each with its frequency in our gold standard and an

example.

In the ﬁrst category, one often ﬁnds sentences

where the activity to be performed is described in ac-

tive voice, but – in the same sentence – e.g. a condi-

tion of that action is described in passive voice (as in

the example given above in Table 3).

Since these error classes account for roughly one

third of all false positives in our experiment, it might

be worth extending ABIDE’s rules, e.g. by checking

whether passive is really used in the activity-related

part of a sentence (category 1, ﬁrst line in Table 3) or

whether one of the patterns of category 2 or 3 (last

two lines in Table 3) is present in a sentence.

6 CONCLUSIONS

In this paper, we have shown that it is feasible to

build an algorithm that will support the quality con-

trol for business process descriptions in terms of how

clearly they refer to responsible actors. We have im-

plemented the algorithm ABIDE – based on some

rather simple rule-based heuristics – that will detect

sentences describing an activity, but with unclear or

no reference to a responsible actor. We have shown

that this algorithm outperforms the baselines in terms

of its precision and recall and that it will help to save

cost when applied in quality control.

In future, as indicated in Section 5.3, there are still

several extensions and ﬁne-tunings of ABIDE that we

plan to address, in particular in the area of passive

sentences, in which false positives may be avoided by

considering some linguistic patterns that our qualita-

tive analysis has revealed. We further plan to evalu-

ate ABIDE in a real-life setting by discussing its re-

sults with persons responsible for writing and check-

ing business process descriptions.

KMIS 2016 - 8th International Conference on Knowledge Management and Information Sharing

146

ACKNOWLEDGEMENT

This work is supported by the European Union FP7

ICT objective, through the Learn PAd Project with

Contract No. 619583.

REFERENCES

Agirre, E. and Edmonds, P. G. (2007). Word sense disam-

biguation: Algorithms and applications, volume 33.

Springer Science & Business Media.

Ambriola, V. and Gervasi, V. (2006). On the systematic

analysis of natural language requirements with Circe.

ASE, 13.

Banerjee, S. and Pedersen, T. (2003). Extended gloss over-

laps as a measure of semantic relatedness. In IJCAI,

volume 3, pages 805–810.

Berry, D. M. and Kamsties, E. (2005). The syntactically

dangerous all and plural in speciﬁcations. IEEE Soft-

ware, 22(1):55–57.

Berry, D. M., Kamsties, E., and Krieger, M. M. (2003).

From contract drafting to software speciﬁcation: Lin-

guistic sources of ambiguity.

Chantree, F., Nuseibeh, B., Roeck, A. N. D., and Willis,

A. (2006). Identifying nocuous ambiguities in natural

language requirements. In Proc. of RE’06, pages 56–

65.

Ciabuschi, F., Perna, A., and Snehota, I. (2012). Assem-

bling resources when forming a new business. Journal

of Business Research, 65(2):220–229.

Cunningham, H. (2002). GATE, a general architecture

for text engineering. Computers and the Humanities,

36(2):223–254.

Cutts, M. (1996). The plain English guide. Oxford Univer-

sity Press.

Gleich, B., Creighton, O., and Kof, L. (2010). Ambi-

guity detection: Towards a tool explaining ambigu-

ity sources. In Proc. of REFSQ’10, volume 6182 of

LNCS, pages 218–232. Springer.

Gnesi, S., Lami, G., and Trentanni, G. (2005). An automatic

tool for the analysis of natural language requirements.

IJCSSE, 20(1).

Ide, N. and V

eronis, J. (1998). Introduction to the special

issue on word sense disambiguation: the state of the

art. Computational linguistics, 24(1):2–40.

Kof, L. (2010). From requirements documents to system

models: A tool for interactive semi-automatic transla-

tion. In Proc. of RE’10.

Lee, Y. K. and Ng, H. T. (2002). An empirical evaluation of

knowledge sources and learning algorithms for word

sense disambiguation. In Proceedings of the ACL-02

conference on Empirical methods in natural language

processing-Volume 10, pages 41–48. Association for

Computational Linguistics.

Leopold, H., Eid-Sabbagh, R.-H., Mendling, J., Azevedo,

L. G., and Bai

ao, F. A. (2013). Detection of naming

convention violations in process models for different

languages. Decision Support Systems, 56:310–325.

Leopold, H., Mendling, J., and Polyvyanyy, A. (2014). Sup-

porting process model validation through natural lan-

guage generation. Software Engineering, IEEE Trans-

actions on, 40(8):818–840.

Lind, H. and Lubera, M. (2009). Battle Management Lan-

guage - An Implementation for a Military Scenario

Editor.

Morimoto, S. (2008). A survey of formal veriﬁcation

for business process modeling. In Computational

Science–ICCS 2008, pages 514–522. Springer.

Navigli, R. (2009). Word sense disambiguation: A survey.

ACM Computing Surveys (CSUR), 41(2):10.

Navigli, R. and Velardi, P. (2005). Structural seman-

tic interconnections: a knowledge-based approach

to word sense disambiguation. Pattern Analysis

and Machine Intelligence, IEEE Transactions on,

27(7):1075–1086.

Nawrocki, J. R., Nedza, T., Ochodek, M., and Olek, L.

(2006). Describing business processes with use cases.

In 9th International Conference on Business Informa-

tion Systems, BIS, pages 13–27.

OMG (2011). Business Process Model and Notation

(BPMN V 2.0).

Ottensooser, A., Fekete, A., Reijers, H. A., Mendling, J.,

and Menictas, C. (2012). Making sense of business

process descriptions: An experimental comparison of

graphical and textual notations. Journal of Systems

and Software, 85(3):596 – 606.

Reijers, H. A. and Mendling, J. (2011). A study into the

factors that inﬂuence the understandability of busi-

ness process models. Systems, Man and Cybernetics,

Part A: Systems and Humans, IEEE Transactions on,

41(3):449–462.

Schumann, R., Delafontaine, S., Taramarcaz, C., and

equoz, F. (2014). Effective Business process doc-

umentation in federal structures. In 44. Jahrestagung

der Gesellschaft f

ur Informatik, pages 1043–1057.

Smith, B. and Erwin, J. (2005). Role & Responsibility

Charting (RACI).

Sommerville, I. (2007). Models for responsibility assign-

ment, pages 165 – 186. Springer.

eronis, J. (2004). Hyperlex: lexical cartography for in-

formation retrieval. Computer Speech & Language,

18(3):223–252.

Voinov, A. and Bousquet, F. (2010). Modelling with

stakeholders. Environmental Modelling & Software,

25(11):1268–1281.

Williams, J. and Colomb, G. (1995). Style: Toward Clarity

and Grace. Chicago guides to writing, editing, and

publishing. University of Chicago Press.

Wilson, W. M., Rosenberg, L. H., and Hyatt, L. E. (1997).

Automated analysis of requirement speciﬁcations. In

Proc. of ICSE’97, pages 161–171.

Yang, H., Roeck, A. N. D., Gervasi, V., Willis, A., and

Nuseibeh, B. (2011). Analysing anaphoric ambigu-

ity in natural language requirements. Requir. Eng.,

16(3):163–189.

Ensuring Action: Identifying Unclear Actor Speciﬁcations in Textual Business Process Descriptions

147
