A Multi-Layer System for Semantic Textual Similarity

Ngoc Phuoc An Vo

and Octavian Popescu

Xerox Research Centre Europe, Meylan, France

IBM T.J.Watson Research, YorkTown, U.S.A.

Keywords:

Machine Learning, Natural Language Processing (NLP), Semantic Textual Similarity (STS).

Abstract:

Building a system able to cope with various phenomena which falls under the umbrella of semantic similarity

is far from trivial. It is almost always the case that the performances of a system do not vary consistently or

predictably from corpora to corpora. We analyzed the source of this variance and found that it is related to

the word-pair similarity distribution among the topics in the various corpora. Then we used this insight to

construct a 4-module system that would take into consideration not only string and semantic word similarity,

but also word alignment and sentence structure. The system consistently achieves an accuracy which is very

close to the state of the art, or reaching a new state of the art. The system is based on a multi-layer architecture

and is able to deal with heterogeneous corpora which may not have been generated by the same distribution.

1 INTRODUCTION

Exhaustive language models are difﬁcult to build be-

cause overcoming the effect of data sparseness re-

quires an infeasible amount of training data. In the

task of Semantic Text Similarity (STS)

, the systems

must quantiﬁably identify the degree of similarity be-

tween pairs of short pieces of text, like sentences.

On the basis of relatively small training corpora, an-

notated with a semantic similarity score obtained by

averaging the opinions of several annotators, an au-

tomatic system may learn to identify classes of sen-

tences which could be treated in the same way, as

their meaning is basically the same. It has been shown

that good results from STS systems may help to im-

prove the accuracy on related tasks, such as Para-

phrasing (Glickman and Dagan, 2004), Textual En-

tailment (Berant et al., 2012), Question Answering

(Surdeanu et al., 2011), etc.

However, building a system able to cope with var-

ious phenomena which fall under the umbrella of se-

mantic similarity is far from trivial. Various types of

knowledge must be considered when dealing with se-

mantic similarity, and the methodology of linking to-

gether different pieces of information is a matter of

research. It is almost always the case that the perfor-

mances of a system do not vary consistently or pre-

dictably from corpora to corpora. The STS corpora

used in STS competitions, and the task description

http://ixa2.si.ehu.es/stswiki/index.php/Main_Page

papers (Agirre et al., 2012; Agirre et al., 2013; Agirre

et al., 2014; Agirre et al., 2015) testify that there is

no system that consistently scores the best across cor-

pora, and big variation of system performance may

occur.

The contribution of this paper consists of three-

fold: (1) we ﬁrst investigate the variation of system

performance to alleviate the variances, (2) we propose

a multi-layer system to comprehensively handle dif-

ferent linguistic features coming from heterogeneous

source of data to predict the semantic similarity scores

between texts, and (3) we evaluate the system on all

available datasets for the task. To our best knowl-

edge, this is the ﬁrst attempt to evaluate a system on

all datasets in STS task. The goal is to present a STS

system able to consistently achieve state of the art, or

near state-of-the-art result on all STS datasets from

2012 - 2015.

The heterogeneity of sources considered for these

corpora makes it difﬁcult to maintain the hypothesis

of the same probability distribution of terms for train-

ing and testing, therefore we have to adapt our system

to handle this situation, which is better described as

a mixture of more or less independent and unknown

Gaussians. The system is modular having four prin-

cipal layers: (i) string similarity, (ii) semantic word

similarity, (iii) word alignment, and (iv) structural in-

formation. These are combined in order to build a

classiﬁer which correspond satisfactorily to our goal.

To prove this, we present comparatively the results of

Vo, N. and Popescu, O.

A Multi-Layer System for Semantic Textual Similarity.

DOI: 10.5220/0006045800560067

In Proceedings of the 8th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2016) - Volume 1: KDIR, pages 56-67

ISBN: 978-989-758-203-5

our system against the top three results for each year

individually.

The paper continues as follows: in the next section

we present an extensive literature on semantic sim-

ilarity which proved instrumental in the building of

the actual system. In Section 3 we analyze the varia-

tion in system performance for STS. In Section 4 we

present the system based on four layers. Section 5 de-

scribes the experiment settings and Section 6 presents

the evaluation results. The paper ends with a section

dedicated to conclusions and further work.

2 RELATED WORK

The Semantic Text Similarity (STS) task has become

one of the most popular research topics in NLP. Two

main approaches have been widely used for tack-

ling this task, namely Distributional Semantic Models

(DSMs) and Knowledge-based similarity approaches.

Distributional Semantic Models (DSMs) is a fam-

ily of approaches based on the distributional hypoth-

esis (Harris, 1968), according to which the meaning

of a word is determined by the set of textual contexts

in which it appears. These models represent words

as vectors that encode the patterns of co-occurrences

of a word with other expressions extracted from a

large corpus of language (Sahlgren, 2006; Turney

et al., 2010). DSMs are very popular for tasks such

as semantic similarity. The different meanings of a

word are described in a space and words used in sim-

ilar contexts are represented by vectors (near) in this

space. On the basis of such methods, semantically

similar words will appear in points near the (seman-

tic) space. Textual contexts can be deﬁned in different

ways, thus giving rise to different semantic spaces.

Knowledge-based similarity approaches quantify

the degree to which two words are semantically re-

lated using information drawn from semantic net-

works (Budanitsky and Hirst, 2006). Most of the

widely used measures (e.g. Leacock and Chodorow,

Wu and Palmer, Lin, and Jiang and Conrath, among

others) of this kind have been found to work well on

the WordNet taxonomy. All these measures assume

as input a pair of concepts, and return a value indi-

cating their semantic similarity. Though these mea-

sures have been deﬁned between concepts, they can

be adapted into word-to-word similarity metrics by

selecting for any given pair of words those two mean-

ings that lead to the highest concept-to-concept simi-

larity.

If we focus on sentence to sentence similarity,

three prominent approaches are usually employed.

The ﬁrst approach uses the vector space model

(Meadow, 1992) in which each text is represented as

a vector (bag-of-words). The similarity between two

given texts is computed by different distance/angel

measures, like cosine similarity, Euclidean, Jaccard,

etc. The second approach assumes that if two sen-

tences are semantically equivalent, we should be able

to align their words or expressions. The alignment

quality can serve as a similarity measure. This ap-

proach typically pairs words from two sentences by

maximizing the summation of the word similarity

of the resulting pairs (Mihalcea et al., 2006). The

last approach employs different measures (like lexi-

cal, semantic and syntactic) from several resources as

features to build machine learning models for train-

ing and testing (Bär et al., 2012; Šari

c et al., 2012;

Shareghi and Bergler, 2013; Marsi et al., 2013; Vo

et al., 2014).

As for the speciﬁc case of measuring semantic

similarity between two given sentences, the Semantic

Textual Similarity (STS) tasks

2 3

have been ofﬁcially

organized and have received an increasing amount

of attention (Agirre et al., 2012; Agirre et al., 2013;

Agirre et al., 2014; Agirre et al., 2015).

The UKP (Bär et al., 2012) was the ﬁrst-ranked

system at STS 2012. This system used a log-linear

regression model to combine multiple text similarity

measures which range from simple measures (word

n-grams or common subsequences) to complex ones

(Explicit Semantic Analysis (ESA) vector compar-

isons (Gabrilovich and Markovitch, 2007), or word

similarity using lexical-semantic resources). Beside

this, it also used a lexical substitution system and sta-

tistical machine translation system to add additional

lexemes for alleviating lexical gaps. The ﬁnal models

after the feature selection, consisted of 20 features,

out of the possible 300+ features implemented.

By contrast, the best system at STS 2013, UMBC

EBIQUITY-CORE (Han et al., 2013), adopted and

expanded the alignment approach into "align-and-

penalize" by giving penalties to both the words that

are poorly aligned and to the alignments causing se-

mantic or syntactic contradictions. At the word level,

it used a common Semantic Word Similarity model

which is a combination of LSA word similarity and

WordNet knowledge.

The DLS@CU (Sultan et al., 2014b) achieved

best result at STS 2014. It used the word align-

ment approach described in the literature (Sultan

et al., 2014a), which considered several semantic fea-

tures, e.g. word similarity, contextual similarity, and

alignment sequence. It (Sultan et al., 2015) again

achieved the best result as shown at STS 2015 us-

http://www.cs.york.ac.uk/semeval-2012/task6/

http://ixa2.si.ehu.es/sts/

A Multi-Layer System for Semantic Textual Similarity

Figure 1: Variance of System Performance in STS 2012.

ing word alignment and similarities between compo-

sitional sentence vectors as its features. It adopted the

400-dimensional vectors developed in (Baroni et al.,

2014) using the word2vec toolkit (Mikolov et al.,

2013) to extract these vectors from a large corpus

(about 2.8 billion tokens). Word vectors between the

two input sentences were not compared, but a vector

representation of each input sentence was constructed

using a simple vector composition scheme, then the

cosine similarity between the two sentence vectors is

computed as the second feature. The vector repre-

senting a sentence is the centroid (i.e., the componen-

twise average) of its content lemma vectors. Finally,

these two features are combined using a ridge regres-

sion model implemented in scikit-learn (Pedregosa

et al., 2011). Besides DLS@CU, it is very interest-

ing that aligning words between sentences has been

the most popular approach for other top participants

ExBThemis (Hänig et al., 2015), and Samsung (Han

et al., 2015).

Besides these approaches, a new semantic repre-

sentation for lexical was proposed as semantic sig-

nature which is the multinomial distribution gener-

ated from the random walks over WordNet taxonomy

where the set of seed nodes is the set of senses present

in the item, (Pilehvar et al., 2013). This representa-

tion encompassed both when the item is itself a single

sense and when the item is a sense-tagged sentence.

This approach was evaluated on three different tasks

Textual Similarity, Word Similarity and Sense Simi-

larity; and it also achieved the state of the art on STS

2012 datasets.

3 VARIANCE OF SYSTEM

PERFORMANCE IN THE STS

TASK

After observing the results from the state-of-the-art

systems at the STS 2012 and 2013, we considered one

of the biggest problems to address is that results var-

ied from the different corpora, or in other words, the

Figure 2: Variance of System Performance in STS 2013.

results depend heavily on the given corpora. There

are two variances that can be addressed:

• First, the result of the state-of-the-art system is not

the best result on each corpus (variance between

systems, e.g. state of the art vs best-score system

on each corpus).

• Second, the variance of results from the same sys-

tem on different corpora in Figures 1 and 2 (re-

sults varied from 49% to 87% of the state-of-the-

art system in STS 2012, and 38% to 76% in STS

2013).

Therefore, we would like to investigate these vari-

ances to improve the state of the art and develop a

system which can obtain predictable results indepen-

dently on given corpora.

In this chapter, we analyze the source of variances

of accuracy on systems participating in the STS task

in 2012 and 2013 by two types of analysis: (1) anal-

ysis on the performance of participating systems, and

(2) corpora analysis on the various domains of data

which affect to the general performance of participat-

ing systems.

3.1 Performance Analysis of the STS

2012 - 2013

Firstly we analyze the difference between systems’

predictions and gold-standard on each dataset of the

STS 2012 and 2013.

Figure 1 shows that there is moderate gap between

the performance the of state-of-the-art system and the

best-score from other different systems over each cor-

pus. The difference on corpus SMT-news, OnWN

and MSRpar are quite large, which are approximately

11%, 6% and 5%, respectively.

Figure 2 shows that there are still some gaps in

performance between state of the art and best-score

systems on each corpus, except the corpus FNWN,

which state of the art system scored highest. Signif-

icantly, in the corpus OnWN, the difference is huge,

almost 10%.

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

Figure 3: STS 2013 - Corpus FNWN - The word-pair similarity distribution using WordNet, Wikipedia and LCS mapped

to the semantic similarity classes [0-5]. Where the classes are gold-standard similarity scores [0-5] classiﬁed into different

brackets: Class_0 is [0-1), Class_1 is [1-2), Class_2 is [2-3), Class_3 is [3-4), Class_4 is [4-5), and Class_5 is [5].

Figure 4: STS 2013 - Corpus ONWN - The word-pair similarity distribution using WordNet, Wikipedia and LCS mapped

to the semantic similarity classes [0-5]. Where the classes are gold-standard similarity scores [0-5] classiﬁed into different

brackets: Class_0 is [0-1), Class_1 is [1-2), Class_2 is [2-3), Class_3 is [3-4), Class_4 is [4-5), and Class_5 is [5].

A Multi-Layer System for Semantic Textual Similarity

The heterogeneity of sources makes it difﬁcult for

a STS system to score consistently across different

corpora. However, the variation observed in the STS

tasks is rather signiﬁcantly big, up to the point that

few reliable statements regarding choosing one sys-

tem over another can be made. In Figures 1 and 2,

we plotted the performance of the state-of-the-art sys-

tem on different datasets at the STS 2012 and 2013.

We can see that the accuracy of this system may vary

within a window of 38%. This variance is problem-

atic, but another variance is probably more serious

than that on a speciﬁc corpus, the variance between

the best performance of the state-of-the-art system

and the performance of best-score system (the best

result on different corpora may come from different

systems) can be up to 9% - 12%. For the STS task,

the margin 9-12% is signiﬁcant, and many systems

achieving results within this distance to the state of

the art. The practical question is which system to

choose? How can one predict whether one system is

really the best system for a new, unknown corpus fed

as input?

3.2 Corpora Analysis of the STS 2013

Unless one is able to build systems that cope posi-

tively with these variances and the system predictably

obtains results within a non signiﬁcant window to the

state of art, the whole approach seems jeopardized.

Therefore, it is important to understand the source

of this variation and to be able to restrain it within

an acceptable margin. In Figures 3 and 4, we plot

the distribution of similar word-pairs according to the

similarity score. It shows that on the corpora with

good results for a simple classiﬁer, there is a good

co-variance between word similarity and the similar-

ity scores (Figure 4). Thus, a simple classiﬁer which

relies on word and string similarity is more likely to

go wrong on the corpus where the similarity score is

not necessarily correlated with the number of similar

words-pairs.

The second variance shown in Figures 1 and 2

is that the results of the state-of-the-art system are

not balanced among the test corpora, and vary from

0.4937 to 0.8739 in STS 2012 and 0.3804 to 0.7642

in STS 2013). In fact, the result of SMT corpus is

much lower than others in STS 2013. Most of the sys-

tems obtained good results on headlines and OnWN,

but very low on FNWN and SMT. It means that most

of the systems may learn good features in headlines

and OnWN, but not in FNWN and SMT which re-

sulted low scores. In other words, there may be other

features remaining in FNWN and SMT that most of

systems at the STS 2013 missed. However, it could

also be a function of the difﬁculty of the data.

In order to ﬁnd a way to alleviate this problem,

we investigated the types of similarity existing in the

STS 2013 corpora. We used the following common

techniques for computing text similarity for our in-

vestigation:

• A similarity based on Lin measure (Lin, 1998)

using WordNet hierarchy [WN] (computed by

the WordNet::Similarity package (Pedersen et al.,

2004)).

• A similarity based on Wikipedia concepts [Wiki]

(computed by the Wikipedia Miner package

(Milne and Witten, 2013)).

• A similarity based on the length of the Longest

Common Substring [LCS].

Using these three parameters, we picked ONWN

and FNWN datasets

for analyzing the number of

similar word-pairs between sentence pairs, in accor-

dance to its gold-standard (human annotation) simi-

larity scores in the scale [0-5] split in six classes.

By comparing the plots in Figure 3 (corpus

FNWN) vs Figure 4 (corpus OnWN), we can see that

the shape of the bars tends to be uniform in Figure 4

while in the Figure 3 the distribution is rather hectic.

A threshold separation is likely to work better for cor-

pus ONWN than FNWN. This analysis conﬁrms that

the high variance of the system’s accuracy is not only

related to the word-pair similarity distribution among

the gold-standard classes but also other features. In

order to improve the accuracy of STS systems, we

need to ﬁnd solutions that add more information on

top of the word-pair similarity to improve the separa-

tion between classes when the prediction of the word-

pair similarity is high.

4 FOUR SEMANTIC LAYERS

In this section we describe our system, which is built

from different linguistic features. We construct a

pipeline system, in which each component produces

different features independently and at the end, all

features are consolidated by the machine learning tool

WEKA, which learns a regression model for predict-

ing the similarity scores from given sentence-pairs.

We adopt few typical STS features in UKP (also

known as DKPro) (Bär et al., 2012), such as string

similarity, character/word n-grams, and pairwise sim-

ilarity; however, beyond these typical features, we

http://ixa2.si.ehu.es/sts/index.php%3Foption=com

_content&view=article&id=47&Itemid=54.html

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

Figure 5: System Overview.

also add other distinguished features, such as syntac-

tic structure information, word alignment and seman-

tic word similarity. The System Overview in Figure 5

shows the logic and design processes in which differ-

ent components connect and work together.

4.1 Data Preprocessing

The input data undergoes the data preprocessing in

which we use Tree Tagger (Schmid, 1994) to per-

form tokenization, lemmatization, and Part-of-Speech

(POS) tagging. On the other hand, we use the Stan-

ford Parser (Klein and Manning, 2003) to obtain the

dependency parsing from given sentences.

4.2 Layer One: String Similarity

We use Longest Common Substring (Gusﬁeld, 1997),

Longest Common Subsequence (Allison and Dix,

1986) and Greedy String Tiling (Wise, 1996) mea-

sures.

Longest Common Substring is the longest string

in common between two or more strings. Two

given texts are considered similar if they are overlap-

ping/covering each other (e.g sentence 1 covers a part

of sentence 2, or otherwise).

Longest Common Subsequence is the problem

of ﬁnding the longest subsequence common to all

sequences in a set of sequences (often just two se-

quences). It differs from problems of ﬁnding com-

mon substrings: unlike substrings, subsequences are

not required to occupy consecutive positions within

the original sequences.

Greedy String Tiling algorithm identiﬁes the

longest exact sequence of substrings from the text

of the source document and returns the sequence as

tiles (i.e., the sequence of substrings) from the source

document and the suspicious document. This algo-

rithm was implemented based on running Karp-Rabin

matching (Wise, 1993).

4.3 Layer Two: Semantic Word

Similarity

Semantic word similarity is the most basic semantic

unit which is used for inferring the semantic textual

similarity. There are several well-known approaches

for computing the pairwise similarity, such as seman-

tic measures using the semantic taxonomy WordNet

(Fellbaum, 1998) described by (Leacock et al., 1998;

Jiang and Conrath, 1997; Resnik, 1995; Lin, 1998;

Hirst and St-Onge, 1998; Wu and Palmer, 1994); or

other corpus-based approaches like Latent Semantic

Analysis (LSA) (Landauer et al., 1998), Explicit Se-

mantic Analysis (ESA) (Gabrilovich and Markovitch,

2007), etc.

Among the approaches described above, we de-

ploy three different approaches to compute the se-

mantic word similarity: the pairwise similarity algo-

rithm by Resnik (Resnik, 1995) on WordNet (Fell-

baum, 1998), the vector space model Explicit Se-

mantic Analysis (ESA) (Gabrilovich and Markovitch,

2007), and the Weighted Matrix Factorization (WMF)

(Guo and Diab, 2012).

Resnik Algorithm returns a score denoting how

similar two word senses are, based on the Information

Content (IC) of the Least Common Subsumer (most

speciﬁc ancestor node). As this similarity measure

uses information content, the result is dependent on

the corpus used to generate the information content

and the speciﬁcs of how the information content was

created.

Explicit Semantic Analysis (ESA) is a vecto-

rial representation of text (individual words or en-

tire documents) that uses a document corpus as a

knowledge base. Speciﬁcally, in ESA, a word is

represented as a column vector in the TF-IDF ma-

trix (Salton and McGill, 1983) of the text corpus and

a document (string of words) is represented as the

centroid of the vectors representing its words. The

ESA model is constructed by two lexical semantic re-

sources Wikipedia and Wiktionary.

5,6

Weighted Matrix Factorization (WMF) (Guo

and Diab, 2012) is a dimension reduction model to

extract nuanced and robust latent vectors for short

texts/sentences. To overcome the sparsity problem

in short texts/sentences (e.g. 10 words on average),

the missing words, a feature that LSA/LDA typically

overlooks, is explicitly modeled. We use the pipeline

to compute the similarity score between texts.

http://en.wikipedia.org/wiki/Main_Page

http://en.wiktionary.org

http://www.cs.columbia.edu/ weiwei/code.html

A Multi-Layer System for Semantic Textual Similarity

Besides these pairwise similarity methods, we

also use the n-gram technique at character and word

levels. We compare character n-grams (Barrón-

Cedeno et al., 2010) with the variance n=2, 3, ...,

15. By contrast, we compare the word n-grams us-

ing the Jaccard coefﬁcient done by Lyon (Lyon et al.,

2001) and containment measure (Broder, 1997) with

the variance of n=1, 2, 3, and 4.

4.4 Layer Three: Word Alignment

At the shallow level of comparing texts and com-

puting their similarity score, we deploy two machine

translation evaluation metrics: the METEOR (Baner-

jee and Lavie, 2005) and TERp (Snover et al., 2006).

However, our analysis shows that the TERp result

does not really contribute to the overall performance,

yet sometimes it may affect our system negatively.

Hence, we remove this metric from the system.

Metric for Evaluation of Translation with Ex-

plicit ORdering (METEOR) (Banerjee and Lavie,

2005) is an automatic metric for machine transla-

tion evaluation, which consists of two major com-

ponents: a ﬂexible monolingual word aligner and a

scorer. For machine translation evaluation, hypothesis

sentences are aligned to reference sentences. Align-

ments are then scored to produce sentence and corpus

level scores. We use this word alignment feature to

learn the similarity between words and phrases in two

given texts in case of different orders.

4.5 Layer Four: Syntactic Structure

Intuitively, the syntactic structure plays an important

role for the human being to understand the meaning of

a given text. Thus, it also may help to identify the se-

mantic equivalence between two given texts. We ex-

ploit the syntactic structure information by the mean

of three different approaches: Syntactic Tree Kernel,

Distributed Tree Kernel and Syntactic Generalization.

We describe how each approach learns and extracts

the syntactic structure information from texts to be

used in our STS system.

Syntactic Tree Kernel. Given two trees T

and

, the functionality of tree kernels is to compare two

tree structures by computing the number of common

substructures between T1 and T2 without explicitly

considering the whole fragment space. According

to (Moschitti, 2006), there are three types of frag-

ments described as the subtrees (STs), the subset trees

(SSTs) and the partial trees (PTs). A subtree (ST) is

a node and all its children, but terminals are not STs.

A subset tree (SST) is a more general structure since

its leaves need not be terminals. The SSTs satisfy

the constraint that grammatical rules cannot be bro-

ken. When this constraint is relaxed, a more general

form of substructures is obtained and deﬁned as par-

tial trees (PTs).

The Syntactic Tree Kernel is a tree kernels ap-

proach to learn the syntactic structure from syntac-

tic parsing information, particularly, the Partial Tree

(PT) kernel is proposed as a new convolution kernel

to fully exploit dependency trees. The evaluation of

the common PTs rooted in nodes n

and n

requires

the selection of the shared child subsets of the two

nodes, e.g. [S [DT JJ N]] and [S [DT N N]] have [S

[N]] (2 times) and [S [DT N]] in common. We use the

tool svm-light-tk 1.5 to learn the similarity of syntac-

tic structure.

Syntactic Generalization (SG). Given a pair of

parse trees, the Syntactic Generalization (SG) (Galit-

sky, 2013) ﬁnds a set of maximal common subtrees.

Though generalization operation is a formal operation

on abstract trees, it yields semantics information from

commonalities between sentences. Instead of only ex-

tracting common keywords from two sentences, the

generalization operation produces a syntactic expres-

sion. This expression maybe semantically interpreted

as a common meaning held by both sentences. This

syntactic parse tree generalization learns the seman-

tic information differently from the kernel methods

which compute a kernel function between data in-

stances, whereas a kernel function is considered as a

similarity measure.

SG uses least general generalization (also called

anti-uniﬁcation) (Plotkin, 1970) to anti-unify texts.

Given two terms E

and E

, it produces a more gen-

eral one E that covers both rather than a more spe-

ciﬁc one as in uniﬁcation. Term E is a generalization

of E

and E

if there exist two substitutions σ

and

such that σ

(E) = E

and σ

(E) = E

. The most

speciﬁc generalization of E

and E

is called anti-

uniﬁer. Technically, two words of the same Part-of-

Speech (POS) may have their generalization which is

the same word with POS. If lemmas are different but

POS is the same, POS stays in the result. If lemmas

are the same but POS is different, lemma stays in the

result. The software is available here.

Distributed Tree Kernel (DTK). (Zanzotto and

Dell’Arciprete, 2012) This is a tree kernels method

using a linear complexity algorithm to compute vec-

tors for trees by embedding feature spaces of tree

fragments in low-dimensional spaces. Then a recur-

sive algorithm is proposed with linear complexity to

compute reduced vectors for trees. The dot product

among reduced vectors is used to approximate the

http://disi.unitn.it/moschitti/SIGIR-tutorial.htm

https://code.google.com/p/relevance-based-on-parse-trees

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

Table 1: Summary of STS datasets in years 2012 - 2015.

year dataset #pairs source

2012 MSRpar 1500 newswire

2012 MSRvid 1500 video descriptions

2012 OnWN 750 OntoNotes, WordNet glosses

2012 SMTnews 750 Machine Translation evaluation

2012 SMTeuroparl 750 Machine Translation evaluation

2013 headlines 750 newswire headlines

2013 FNWN 189 FrameNet, WordNet glosses

2013 OnWN 561 OntoNotes, WordNet glosses

2013 SMT 750 Machine Translation evaluation

2014 headlines 750 newswire headlines

2014 OnWN 750 OntoNotes, WordNet glosses

2014 Deft-forum 450 forum posts

2014 Deft-news 300 news summary

2014 Images 750 image descriptions

2014 Tweet-news 750 tweet-news pairs

2015 Images 750 image descriptions

2015 headlines 750 newswire headlines

2015 answers-students 750 student answers

2015 answers-forum 375 forum answers

2015 belief 375 forum

original tree kernel when a vector composition func-

tion with speciﬁc ideal properties is used. The soft-

ware is available here.

5 DATASETS AND EXPERIMENT

SETTINGS

The STS datasets (Agirre et al., 2012; Agirre et al.,

2013; Agirre et al., 2014; Agirre et al., 2015) are

constructed from various sources associated with dif-

ferent domains, e.g newswire headlines, paraphrases,

video description, image captions, machine transla-

tion evaluation, Twitter news and messages, forum

data, glosses combination of OntoNotes, FrameNet

and WordNet, etc. Only in STS 2012, the train and

test datasets are provided, since STS 2013 onward,

no new training dataset is given, but only the new

test dataset, whereas datasets in previous years can

Figure 6: Component Analysis.

https://code.google.com/p/distributed-tree-kernels

be used for training. Except the setup in STS 2012

where several of test sets have designated training

data, the STS 2013, 2014 setups are similar to STS

2015 with no domain-dependent training data. This

domain-independent character of STS data is a great

challenge for any system to achieve consistent perfor-

mance. The detail of datasets described in Table 1.

6 EVALUATIONS AND

DISCUSSION

The results are obtained with Pearson correlation,

which is the ofﬁcial measure used in both tasks.

The

overall result is computed by the Weighted Mean of

the Pearson correlations on individual datasets which

is weighted according to the number of sentence pairs

in that dataset. We compare our system’s performance

with the baseline and the top three systems in each

STS competition in years 2012, 2013, 2014 and 2015.

Performance Comparison on all STS Datasets.

Tables 2,3,4, and 5 show our system performance in

each year. In overall, Table 6 shows the side-by-side

comparison between our system and the baseline, the

DKPro and the state-of-the-art (SOTA) systems on all

STS datasets. This conﬁrms our stable and consis-

tent performance which always overcomes the base-

line (large margin 20-27%) and DKPro (4-13%) , and

achieves better or competitive results to SOTA sys-

tems.

Comparison to DKPro. Table 6 shows that

though we adopt some string and word similarity fea-

tures from DKPro, our system always outperforms

DKPro. The main difference between our system

and DKPro is that by adding two important modules

of processing word alignment and syntactic structure,

we consider more linguistic aspects in semantic infer-

ence leading to more robust and comprehensive capa-

bility to compute the semantic similarity. This proves

that this approach of multi-layer infrastructure opti-

mizes the system performance by delegating and cap-

turing various linguistic phenomena by proper seman-

tic layers, leading to higher precision and correlation.

Component Analysis. Figure 6 presents the anal-

ysis for each individual component in our STS sys-

tem. It shows the signiﬁcance of each layer into the

overall performance on STS 2012, 2013, 2014 and

2015 datasets. Despite the fact that string and word

similarity layer occupies a larger portion in the overall

performance, the signiﬁcance of other semantic lay-

ers is undenied. The design of multi-layer system im-

http://en.wikipedia.org/wiki/Pearson_product-

moment_correlation_coefﬁcient

A Multi-Layer System for Semantic Textual Similarity

Table 2: Evaluation Results on STS 2012 datasets.

System MSRpar MSRvid SMTeur OnWN SMTnews Mean

Baseline 0.433 0.30 0.454 0.586 0.391 0.436

DKPro 0.62 0.808 0.376 0.657 0.462 0.584

UKP (1

) 0.683 0.874 0.528 0.664 0.494 0.677

Takelab (2

) 0.734 0.880 0.477 0.680 0.399 0.675

SOFT-CARDINALITY (3

) 0.641 0.856 0.515 0.711 0.483 0.671

ADW (Pilehvar et al., 2013) 0.694 0.887 0.555 0.706 0.604 0.711

OurSystem (OS) 0.748 0.894 0.458 0.755 0.505 0.711

Table 3: Evaluation Results on STS 2013 datasets.

System FNWN headlines OnWN SMT Mean

Baseline 0.215 0.540 0.283 0.286 0.364

DKPro 0.385 0.706 0.784 0.317 0.569

UMBC_EBIQUITY_PairingWords (1

) 0.582 0.764 0.753 0.380 0.618

UMBC_EBIQUITY_galactus (2

) 0.743 0.705 0.544 0.371 0.593

deft-baseline (3

) 0.653 0.843 0.508 0.327 0.580

OurSystem (OS) 0.450 0.732 0.843 0.356 0.611

Table 4: Evaluation Results on STS 2014 datasets.

Systems deft-forum deft-news headlines images OnWN tweet-news Mean

Baseline 0.353 0.596 0.510 0.513 0.406 0.654 0.507

DKPro 0.452 0.713 0.697 0.777 0.819 0.722 0.714

DLS@CU (1

) 0.483 0.766 0.765 0.821 0.859 0.764 0.761

MeerkatMaﬁa (2

) 0.471 0.763 0.760 0.801 0.875 0.779 0.761

NTNU (3

) 0.531 0.781 0.784 0.834 0.850 0.676 0.755

OurSystem (OS) 0.508 0.762 0.765 0.818 0.896 0.749 0.768

Table 5: Evaluation Results on STS 2015 datasets.

System ans-forums ans-students belief headlines images Mean

Baseline 0.445 0.665 0.652 0.531 0.604 0.587

DKPro 0.696 0.712 0.699 0.766 0.808 0.746

DLS@CU-S1 (1

) 0.739 0.773 0.749 0.825 0.864 0.802

ExBThemis-themisexp (2

) 0.695 0.778 0.748 0.825 0.853 0.794

DLS@CU-S2 (3

) 0.724 0.757 0.722 0.825 0.863 0.792

OurSystem (OS) 0.713 0.744 0.733 0.808 0.858 0.783

Table 6: Comparison on all STS datasets.

Settings 2012 2013 2014 2015

Gain/Baseline 0.275 0.247 0.261 0.196

Gain/DKPro 0.127 0.042 0.054 0.037

Dist2SOTA 0.034 -0.007 0.007 -0.019

proves the overall performance from 3.7-12.7% more

by better robustness and comprehension to handle

more complicated semantic information via deeper

semantic layers.

Accordingly, we can claim that our system con-

sistently and stably performs at the state of the art or

top-tier level on all STS datasets from 2012 to 2015.

The framework of four different semantic layers helps

our system handle heterogeneous data from STS suc-

cessfully. By delegating and assigning different se-

mantic layers which deal with different types of in-

formation, the system can cope with and adapt to any

unknown domain data. This hypothesis is proven by

the constant performance on various datasets derived

from different domains in STS.

7 CONCLUSION AND FUTURE

WORKS

In this paper, we investigated the variance of system

performance in the STS task, then we presented a

novel framework to solve the greatest challenge of

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

domain-independent data for Semantic Textual Sim-

ilarity task. We unify the task into four main layers

of processing to exploit the semantic similarity in-

formation from different presentation levels (lexical,

string, syntactic, alignment) to overcome the variance

of system’s performance on data derived from various

sources. Our framework is implemented and eval-

uated on all STS datasets and consistently achieves

either state of the art or near state-of-the-art perfor-

mance in regard to the top three best systems in every

STS competition from 2012 to 2015.

REFERENCES

Agirre, E., Banea, C., Cardie, C., Cer, D., Diab, M.,

Gonzalez-Agirre, A., Guo, W., Lopez-Gazpio, I.,

Maritxalar, M., Mihalcea, R., Rigau, G., Uria, L., and

Wiebe, J. (2015). SemEval-2015 Task 2: Semantic

Textual Similarity, English, Spanish and Pilot on In-

terpretability. In Proceedings of the 9th International

Workshop on Semantic Evaluation (SemEval 2015),

Denver, CO. Association for Computational Linguis-

tics.

Agirre, E., Baneab, C., Cardiec, C., Cerd, D., Diabe,

M., Gonzalez-Agirrea, A., Guof, W., Mihalceab, R.,

Rigaua, G., and Wiebeg, J. (2014). Semeval-2014 task

10: Multilingual semantic textual similarity. SemEval

2014, page 81.

Agirre, E., Cer, D., Diab, M., Gonzalez-Agirre, A., and

Guo, W. (2013). sem 2013 shared task: Semantic tex-

tual similarity, including a pilot on typed-similarity. In

In* SEM 2013: The Second Joint Conference on Lex-

ical and Computational Semantics. Association for

Computational Linguistics. Citeseer.

Agirre, E., Diab, M., Cer, D., and Gonzalez-Agirre, A.

(2012). Semeval-2012 task 6: A pilot on semantic

textual similarity. In Proceedings of the First Joint

Conference on Lexical and Computational Semantics-

Volume 1: Proceedings of the main conference and

the shared task, and Volume 2: Proceedings of the

Sixth International Workshop on Semantic Evalua-

tion, pages 385–393. Association for Computational

Linguistics.

Allison, L. and Dix, T. I. (1986). A bit-string longest-

common-subsequence algorithm. Information Pro-

cessing Letters, 23(5):305–310.

Banerjee, S. and Lavie, A. (2005). Meteor: An automatic

metric for mt evaluation with improved correlation

with human judgments. In Proceedings of the ACL

Workshop on Intrinsic and Extrinsic Evaluation Mea-

sures for Machine Translation and/or Summarization,

pages 65–72.

Bär, D., Biemann, C., Gurevych, I., and Zesch, T. (2012).

Ukp: Computing semantic textual similarity by com-

bining multiple content similarity measures. In Pro-

ceedings of the First Joint Conference on Lexical and

Computational Semantics-Volume 1: Proceedings of

the main conference and the shared task, and Volume

2: Proceedings of the Sixth International Workshop

on Semantic Evaluation, pages 435–440. Association

for Computational Linguistics.

Baroni, M., Dinu, G., and Kruszewski, G. (2014). Don’t

count, predict! a systematic comparison of context-

counting vs. context-predicting semantic vectors. In

ACL (1), pages 238–247.

Barrón-Cedeno, A., Rosso, P., Agirre, E., and Labaka, G.

(2010). Plagiarism detection across distant language

pairs. In Proceedings of the 23rd International Con-

ference on Computational Linguistics, pages 37–45.

Association for Computational Linguistics.

Berant, J., Dagan, I., and Goldberger, J. (2012). Learn-

ing entailment relations by global graph structure op-

timization. Computational Linguistics, 38(1):73–111.

Broder, A. Z. (1997). On the resemblance and containment

of documents. In Compression and Complexity of Se-

quences 1997. Proceedings, pages 21–29. IEEE.

Budanitsky, A. and Hirst, G. (2006). Evaluating wordnet-

based measures of lexical semantic relatedness. Com-

put. Linguist., 32(1):13–47.

Fellbaum, C. (1998). WordNet. Wiley Online Library.

Gabrilovich, E. and Markovitch, S. (2007). Computing se-

mantic relatedness using wikipedia-based explicit se-

mantic analysis. In IJCAI, volume 7, pages 1606–

1611.

Galitsky, B. (2013). Machine learning of syntactic parse

trees for search and classiﬁcation of text. Engineering

Applications of Artiﬁcial Intelligence, 26(3):1072–

1091.

Glickman, O. and Dagan, I. (2004). Acquiring lexical para-

phrases from a single corpus. Recent Advances in Nat-

ural Language Processing III. John Benjamins Pub-

lishing, Amsterdam, Netherlands, pages 81–90.

Guo, W. and Diab, M. (2012). Modeling sentences in the

latent space. In Proceedings of the 50th Annual Meet-

ing of the Association for Computational Linguistics:

Long Papers-Volume 1, pages 864–872. Association

for Computational Linguistics.

Gusﬁeld, D. (1997). Algorithms on strings, trees and se-

quences: computer science and computational biol-

ogy. Cambridge University Press.

Han, L., Kashyap, A., Finin, T., Mayﬁeld, J., and Weese, J.

(2013). Umbc ebiquity-core: Semantic textual simi-

larity systems. In In* SEM 2013: The Second Joint

Conference on Lexical and Computational Semantics.

Association for Computational Linguistics.

Han, L., Martineau, J., Cheng, D., and Thomas, C. (2015).

Samsung: Align-and-differentiate approach to seman-

tic textual similarity. SemEval-2015, page 172.

Hänig, C., Remus, R., and De La Puente, X. (2015). Exb

themis: Extensive feature extraction from word align-

ments for semantic textual similarity. SemEval-2015,

page 264.

Harris, Z. S. (1968). Mathematical structures of language.

Interscience Publishers.

Hirst, G. and St-Onge, D. (1998). Lexical chains as rep-

resentations of context for the detection and correc-

tion of malapropisms. WordNet: An electronic lexical

database, 305:305–332.

A Multi-Layer System for Semantic Textual Similarity

Jiang, J. J. and Conrath, D. W. (1997). Semantic similarity

based on corpus statistics and lexical taxonomy. arXiv

preprint cmp-lg/9709008.

Klein, D. and Manning, C. D. (2003). Accurate unlexical-

ized parsing. In Proceedings of the 41st Annual Meet-

ing on Association for Computational Linguistics-

Volume 1, pages 423–430. Association for Computa-

tional Linguistics.

Landauer, T. K., Foltz, P. W., and Laham, D. (1998). An in-

troduction to latent semantic analysis. Discourse pro-

cesses, 25(2-3):259–284.

Leacock, C., Miller, G. A., and Chodorow, M. (1998). Us-

ing corpus statistics and wordnet relations for sense

identiﬁcation. Computational Linguistics, 24(1):147–

165.

Lin, D. (1998). An information-theoretic deﬁnition of sim-

ilarity. In ICML, volume 98, pages 296–304.

Lyon, C., Malcolm, J., and Dickerson, B. (2001). Detecting

short passages of similar text in large document col-

lections. In Proceedings of the 2001 Conference on

Empirical Methods in Natural Language Processing,

pages 118–125.

Marsi, E., Moen, H., Bungum, L., Sizov, G., Gambäck, B.,

and Lynum, A. (2013). Ntnu-core: Combining strong

features for semantic similarity. In In* SEM 2013:

The Second Joint Conference on Lexical and Com-

putational Semantics. Association for Computational

Linguistics.

Meadow, C. T. (1992). Text information retrieval systems.

Academic Press, Inc.

Mihalcea, R., Corley, C., and Strapparava, C. (2006).

Corpus-based and knowledge-based measures of text

semantic similarity. In AAAI, volume 6, pages 775–

780.

Mikolov, T., Chen, K., Corrado, G., and Dean, J. (2013).

Efﬁcient estimation of word representations in vector

space. arXiv preprint arXiv:1301.3781.

Milne, D. and Witten, I. H. (2013). An open-source

toolkit for mining wikipedia. Artiﬁcial Intelligence,

194:222–239.

Moschitti, A. (2006). Efﬁcient convolution kernels for de-

pendency and constituent syntactic trees. In Machine

Learning: ECML 2006, pages 318–329. Springer.

Pedersen, T., Patwardhan, S., and Michelizzi, J. (2004).

Wordnet:: Similarity: measuring the relatedness of

concepts. In Demonstration Papers at HLT-NAACL

2004, pages 38–41. Association for Computational

Linguistics.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer, P.,

Weiss, R., Dubourg, V., et al. (2011). Scikit-learn:

Machine learning in python. The Journal of Machine

Learning Research, 12:2825–2830.

Pilehvar, M. T., Jurgens, D., and Navigli, R. (2013). Align,

disambiguate and walk: A uniﬁed approach for mea-

suring semantic similarity. In ACL (1), pages 1341–

1351.

Plotkin, G. D. (1970). A note on inductive generalization.

Machine intelligence, 5(1):153–163.

Resnik, P. (1995). Using information content to evaluate se-

mantic similarity in a taxonomy. arXiv preprint cmp-

lg/9511007.

Sahlgren, M. (2006). The word-space model: Us-

ing distributional analysis to represent syntagmatic

and paradigmatic relations between words in high-

dimensional vector spaces.

Salton, G. and McGill, M. J. (1983). Introduction to modern

information retrieval.

Šari

c, F., Glavaš, G., Karan, M., Šnajder, J., and Baši

B. D. (2012). Takelab: Systems for measuring seman-

tic text similarity. In Proceedings of the First Joint

Conference on Lexical and Computational Semantics-

Volume 1: Proceedings of the main conference and

the shared task, and Volume 2: Proceedings of the

Sixth International Workshop on Semantic Evalua-

tion, pages 441–448. Association for Computational

Linguistics.

Schmid, H. (1994). Probabilistic part-of-speech tagging us-

ing decision trees. In Proceedings of international

conference on new methods in language processing,

volume 12, pages 44–49. Manchester, UK.

Shareghi, E. and Bergler, S. (2013). Clac-core: Exhaus-

tive feature combination for measuring textual simi-

larity. In In* SEM 2013: The Second Joint Conference

on Lexical and Computational Semantics. Association

for Computational Linguistics.

Snover, M., Dorr, B., Schwartz, R., Micciulla, L., and

Makhoul, J. (2006). A study of translation edit rate

with targeted human annotation. In Proceedings of

association for machine translation in the Americas,

pages 223–231.

Sultan, M. A., Bethard, S., and Sumner, T. (2014a). Back

to basics for monolingual alignment: Exploiting word

similarity and contextual evidence. Transactions of

the Association for Computational Linguistics, 2:219–

230.

Sultan, M. A., Bethard, S., and Sumner, T. (2014b). Dls@

cu: Sentence similarity from word alignment. Se-

mEval 2014, page 241.

Sultan, M. A., Bethard, S., and Sumner, T. (2015). Dls@ cu:

Sentence similarity from word alignment and seman-

tic vector composition. In Proceedings of the 9th In-

ternational Workshop on Semantic Evaluation, pages

148–153.

Surdeanu, M., Ciaramita, M., and Zaragoza, H. (2011).

Learning to rank answers to non-factoid questions

from web collections. Computational Linguistics,

37(2):351–383.

Turney, P. D., Pantel, P., et al. (2010). From frequency to

meaning: Vector space models of semantics. Journal

of artiﬁcial intelligence research, 37(1):141–188.

Vo, N. P. A., Caselli, T., and Popescu, O. (2014). Fbk-

tr: Applying svm with multiple linguistic features for

cross-level semantic similarity. SemEval 2014, page

284.

Wise, M. J. (1993). String similarity via greedy string tiling

and running karp-rabin matching. Online Preprint,

Dec, 119.

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

Wise, M. J. (1996). Yap3: Improved detection of similar-

ities in computer program and other texts. In ACM

SIGCSE Bulletin, volume 28, pages 130–134. ACM.

Wu, Z. and Palmer, M. (1994). Verbs semantics and lexical

selection. In Proceedings of the 32nd annual meeting

on Association for Computational Linguistics, pages

133–138. Association for Computational Linguistics.

Zanzotto, F. M. and Dell’Arciprete, L. (2012). Distributed

tree kernels. arXiv preprint arXiv:1206.4607.

A Multi-Layer System for Semantic Textual Similarity
