Power to the People!

Meta-Algorithmic Modelling in Applied Data Science

Marco Spruit and Raj Jagesar

Information and Computing Sciences, Utrecht University, Princetonplein 5, Utrecht, The Netherlands

Keywords: Applied Data Science, Meta-algorithmic Modelling, Machine Learning, Big Data.

Abstract: This position paper first defines the research field of applied data science at the intersection of domain

expertise, data mining, and engineering capabilities, with particular attention to analytical applications. We

then propose a meta-algorithmic approach for applied data science with societal impact based on activity

recipes. Our people-centred motto from an applied data science perspective translates to design science

research which focuses on empowering domain experts to sensibly apply data mining techniques through

prototypical software implementations supported by meta-algorithmic recipes.

1 APPLIED DATA SCIENCE

Pritzker and May (2015:7) define Data Science as

“the extraction of actionable knowledge directly

from data through a process of discovery, or

hypothesis formulation and hypothesis testing”. In

addition, they also relate the skills needed in Data

Science. Based on their observations we propose to

define Applied Data Science as follows:

Applied Data Science (ADS) is the knowledge

discovery process in which analytical

applications are designed and evaluated to

improve the daily practices of domain experts.

Note that this is in contrast to fundamental data

science which aims to develop novel statistical and

machine learning techniques for performing Data

Science. In Applied Data Science the objective is to

develop novel analytical applications to improve the

real world around us. From the perspective of the

Data Science Venn diagramme (Pritzker and May,

2015:9), Applied Data Science focuses on the

Analytical applications intersection between the

Domain expertise and Engineering capabilities.

Finally, we observe an analogy with the ubiquitous

people-process-technology model where technology

aligns with machine learning algorithms,

organisational processes are operationalised through

analytical software implementations, and domain

expertise is captured from, and enriched for, skilled

professionals. Hence the motto: power to the people!

Figure 1 contextualises the research field of and

needed skills in Applied Data Science.

It is from this novel Applied Data Science research

perspective that we investigate the core data science

topic of machine learning in the remainder of this

paper, from a meta-algorithmic modelling approach.

Figure 1: Applied Data Science in context.

2 MACHINE LEARNING

With the steadily growing availability of data

storage space and computing power, advanced data

400

Spruit, M. and Jagesar, R.

Power to the People! - Meta-Algorithmic Modelling in Applied Data Science.

DOI: 10.5220/0006081604000406

In Proceedings of the 8th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2016) - Volume 1: KDIR, pages 400-406

ISBN: 978-989-758-203-5

mining efforts are coming within reach of

increasingly more people. One common approach to

perform a data mining project, and central to this

ADS type of research, is to apply Machine Learning

(ML) techniques. The application of ML techniques

spans various disciplines like mathematics, statistics

and computer science. These disciplines combined

support the act of learning and result in models that

are fitted to data. The challenge is to derive models

that are accurate in the sense that they reflect the

underlying patterns in the data whilst ignoring

peculiarities that do not represent reality. A popular

and well known purpose of these models is to make

predictions on new and unseen examples of data.

However, ML techniques are also well suited to

explore the underlying patterns of a dataset. More

often than not, machine learning techniques are

employed to learn about the structure of a data set

(Hall et al., 2011). ML as a research field can be

considered to be positioned at the heart of

fundamental data science, as it requires both data

mining and engineering expertise. This is also

reflected in Figure 1 (Algorithms, in green colour).

3 PROBLEM STATEMENT

However, despite the growing usage and popularity

of machine learning techniques in data mining

projects, correctly applying these techniques remains

quite a challenge. We list the three main challenges

below:

1. Depth versus breadth: The ML field knows

many different use cases, each of which has a

sizeable body of literature surrounding the

specific cases. The literature is usually found

to be heavy on mathematical terminology and

aimed at the computer science community.

This prevents researchers from other fields in

learning and correctly applying machine

learning techniques in their own research

(Domingos, 2012).

2. Selection versus configuration: In line with

the aforementioned, applying machine

learning techniques confronts users with

many degrees of freedom in how to assemble

and configure a learning system. One

example of this is the fact that algorithm

performance is largely determined by

parameter settings, these settings are specific

for each class of algorithm. However, in

practice end users usually do not have

enough knowledge on how to find optimal

parameter settings (Yoo et al., 2012). Many

users leave the parameters to their default

settings and base algorithm selection on

reputation and / or intuitive appeal (Thornton

et al., 2013). This may lead to researchers

using underperforming algorithms and

gaining suboptimal results.

3. Accuracy versus transparency: Concerning

the creation of models: ML shows that

currently there is a trade-off to be had

between accuracy and transparency (Kamwa

et al., 2012). In practice this means that

algorithms which yield a high amount of

insight into the data do not perform as well as

their non-transparent (black box) counterparts

and the other way around.

In order to get a better grip on these challenges, we

propose a meta-algorithmic modelling approach,

which we define as follows:

Meta-Algorithmic Modelling (MAM) is an

engineering discipline where sequences of

algorithm selection and configuration activities

are specified deterministically for performing

analytical tasks based on problem-specific data

input characteristics and process preferences.

MAM as a discipline is inspired by Method

Engineering, “the engineering discipline to design,

construct and adapt methods, techniques and tools

for the development of information systems”

(Brinkkemper, 1996). In related work, Simke (2013)

describes a reusable, broadly-applicable set of

design patterns to empower intelligent system

architects. Finally, MAM also conceptually

resembles the Theory of Inventive Problem Solving

(TRIZ), a method for creative design thinking and

real problem solving, partly due to its “Meta-

Algorithm of Invention” (Orloff, 2016).

The strategic goal of MAM is to provide highly

understandable and deterministic method fragments

—i.e. activity recipes—to guide application domain

experts without in-depth ML expertise step-by-step

through an optimized ML process following Vleugel

et al. (2010) and Pachidi and Spruit (2015), among

others, based on the Design Science Research

approach (Hevner et al., 2004). We thereby promote

reuse of state-of-the-art ML knowledge and best

practices in the appropriate application of ML

techniques, whilst at the same time provide

information on how to cope with challenges like

parameter optimization and model transparency

(Pachidi et al., 2014).

We argue that this MAM approach aligns especially

Power to the People! - Meta-Algorithmic Modelling in Applied Data Science

401

well with the Applied Data Science perspective

which we pursue in this research.

4 RESEARCH APPROACH

By taking into account our problem statement

context above the overarching research question is

formulated as follows:

How can meta-algorithmic modelling as a

domain independent approach in an applied data

science context be operationalised to guide the

process of constructing transparent machine

learning models for possible use by application

domain experts?

We will initially proceed with a limited scope: the

creation of method fragments focused on supervised

machine learning for binary classification tasks on

structured data. This type of machine learning is

concerned with deriving models from (training) data

that are already available. Coincidentally this is one

of the most applied and mature areas within the

machine learning practice (Kotsiantis et al., 2007).

First a theoretical foundation is established on

the subjects of data mining, machine learning and

model transparency. The concepts derived from this

foundation are then grouped using the structure of a

data mining process model. For our purposes we

apply the base structure of the CRISP-DM process

model and group the concepts into the following

phases: data understanding, data preparation, and

modelling & evaluation. Our method fragments will

be composed using the same structure.

In this work we employ method engineering

fragments notation to specify the meta-algorithmic

models. More specifically, we apply the meta-

modelling approach which yields a process-

deliverable diagram (PDD; Weerd et al., 2008). A

PDD consists of two diagrams: the left-hand side

shows an UML activity diagram (processes) and the

right-hand side shows an UML class diagram

(concepts or deliverables). Both diagrams are

integrated and display how the activities are tied to

each deliverable. Lastly, the activities and the

concepts are each explained in separate tables.

However, due to page restrictions these explanatory

tables are excluded from this paper.

5 MODEL TRANSPARENCY

The concept of model transparency occasionally

surfaces in the body of literature. In particular, when

it concerns decision support systems where it must

be clear how a system came to a certain

(classification) decision (Johansson et al., 2004;

Olson et al., 2012; Kamwa et al., 2012b; Allahyari

et al., 2011).

There is consensus in the literature about the

types of algorithms that are known to yield

transparent and non-transparent (black box) models.

Both tree and rule models are considered as

transparent and highly interpretable. On the other

hand, artificial neural networks, support vector

machines and ensembles like random forests are

considered as black boxes (Johansson et al., 2004;

Olson et al., 2012; Kamwa et al., 2012b).

Currently there is no common ground on the

subject of tree and rule model complexity. Although

considered as transparent, critics note that the

interpretative value of complex tree and rule models

should be questioned (Johansson et al., 2004). On

the other hand, a study on model understandability

found indications that the assumption where simpler

models are considered as more understandable does

not always hold as true either (Allahyari et al.,

2011).

The choice between a transparent and non-

transparent modelling technique is not immediately

obvious since there is a tradeoff to be made between

accuracy and transparency. Black box modelling

techniques generally have better classification and

prediction performance, but the tradeoff with better

interpretable solutions is unavoidable. We found two

solutions in the body of literature that aim to bridge

this gap.

The first solution is aimed towards extracting

comprehensible information in the form of rules and

trees from black box modelling techniques like

artificial neural networks and support vector

machines (Johansson et al., 2004; Martens et al.,

2007; Setiono, 2003). The practice delivers

comprehensible information but is criticized for

being unrepresentative of the original model due to

oversimplification (Cortez et al., 2013).

The second solution approaches the problem

from the opposite direction by improving the

performance of a transparent modelling technique to

a level where it competes with its black box

counterparts. A variant of linear modelling is applied

known as generalized additive modelling (GAM)

enriched with information on pairwise interactions

between features (Lou et al., 2013). This allows to

retain the explanatory value of linear models and at

the same time achieve high performance in terms of

classification accuracy. The technique exposes the

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

402

contribution of each feature in relation to the

outcome values.

6 METHOD FRAGMENTS

In this section we present the method fragments as

derived from our literature study on the domains of

data mining and machine learning. All analytical

recipes are accompanied with a brief description.

6.1 Data Understanding

Before starting with any data mining project it is

important to become familiar with the data that will

be analyzed. The goal is to improve one’s

understanding of the data by using (statistical) tools

to summarize, plot and review datapoints in the data

set. This practice is called exploratory data analysis

(EDA) (Tukey 1977).

Figure 2: Data understanding method fragment.

The data understanding phase as depicted in

Figure 2 revolves around the application of

exploratory data analysis (EDA) techniques to

generate visualizations and tables to gain a first

insight into the relationships between the features of

a data set. A high number of features can make these

deliverables difficult to interpret. Therefore, the

activity flow shows that in cases of high dimensional

data sets it is recommended to pre-select a subset of

features using a feature selection technique.

We recommend the creation of histogram

graphs, pairwise scatterplots and correlation matri-

ces to start exploring relationships between the

features of a dataset. Histogram graphs and pairwise

scatterplots serve the purpose of visualizing overlap

and separability between the various classes of a

data set. Feature correlation matrices are used to

determine which features are redundant; these

should be removed when applying the naive bayes

(probabilistic) model. Menger et al. (2016) notably

provide a more detailed recipe for performing

interactive visualisation-driven EDA.

6.2 Data Preparation

The data preparation phase (Figure 3) consists of

three main activities: dataset construction, feature

extraction, and modelling technique preparation.

Figure 3: Data preparation method fragment.

Dataset construction: The dataset construction

activity entails loading the raw data and engineering

new features based on the raw data. Feature

engineering can be a substantial task but is difficult

to capture in a method since it is highly situational.

The last task within this activity is feature selection.

Not all features in a given data set have the same

informative importance or any importance at all.

This can be problematic as some classification

algorithms are designed to make the most of the data

that is presented to them. In these cases even

irrelevant features will eventually be included in the

model. In other words the model will be overfitted to

the data which means that the classification

algorithm has included the noise as an integral part

of the model (Tang, Alelyani, and Liu, 2014). The

solution is to select a subset of only the most

Power to the People! - Meta-Algorithmic Modelling in Applied Data Science

403

informative features reducing the dimensionality

(number of features) of the data set in the process.

Feature selection is either performed manually using

EDA techniques, or selection is performed using a

feature selection algorithm.

Feature extraction: The feature extraction

activity entails the application of projection me-

thods. Projection methods like principal component

analysis are automated feature engineering

techniques that aim to best describe the main differ-

rentiators of a data set creating a select (low) number

of features in the process (dimensionality reduction).

Transparency between the outcome variable and the

original features may be lost while using a

projection technique.

Modelling technique preparation: Lastly, the

modelling technique preparation activity consists of

three paths that define preparation steps depending

on the model type chosen by the data scientist.

When tree and rule models are required due to

model transparency concerns, no additional prepara-

tion steps are necessary since modern algorithm

implementations take care of preparation steps

internally. Linear models and the probabilistic naive

Bayes model can be chosen due to performance

concerns. Both types require their own conversion

steps in order to be able to process the data in the

next phase of the DM process. The naive Bayes

model type e.g. requires redundant features to be

removed since they will negatively influence classi-

fier results. Linear model types require input data to

be represented in numerical form so transformation

steps should be performed as needed e.g. the

binarization of categorical data. Note however that

some concrete algorithm implementations of linear

models may perform these steps as part of their

internal workings.

6.3 Modelling and Evaluation

The modelling and evaluation method fragment

(Figure 4) consists of three activities aimed at

deriving classification models from data sets: search

space definition, find optimal parameters, and

predict & classify.

Search space definition: The search space

definition activity has a route to explore fully

automated model (and parameter) selection in

analyzing the data set. Currently one experimental

implementation exists in the form of Auto-WEKA

(Thornton et al. 2013). Auto-WEKA is an

experimental machine learning toolkit that almost

completely relies on Bayesian optimization

techniques to generate models. The toolkit is unique

Figure 4: Modelling & evaluation method fragment.

in the sense that it considers the choice for the

modelling technique as part of the problem space as

well. This relieves potential users from having to

manually select and test algorithms, instead Auto-

WEKA uses all the algorithms that are part of the

WEKA toolkit and determines which algorithm

generates the best results for a given data set.

Currently, due to the novelty of this technique, the

approach should be used to gain initial insight into

model types that may perform best on the provided

data set.

Find optimal parameters: Next, the application

of automated search strategies is central to the

following activity named “Find optimal parameters”.

Recall from our problem statement that the

performance of algorithms is highly dependent on

how they are configured, a problem known as

(hyper) parameter optimization. Getting optimal

performance from a modelling technique means

finding the right (combination of) parameter

settings. The best settings will be different for each

data set which necessitates an automated means of

determining these values. Search strategies like grid

search, random search and Bayesian optimization

support the task to (intelligently) iterate over

combinations of parameters evaluating the perfor-

mance at each attempt.

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

404

This task requires the data scientist to decide on

various factors that determine how the search for the

best configuration will be executed. We recommend

to consider at least the following “Top 5” factors:

1. Model type: The model type itself. The data

scientist can choose to iterate over different

modelling techniques (tree, rule, ensemble,

linear and probabilistic) to find out which type

works best given a specific data set. This

approach is similar to Auto-WEKA since it

includes the model type as part of the problem

(search) space.

2. Parameter types: This key factor comprises the

parameters that belong to a specific model type.

Parameter types can range from procedural

configuration settings to the specific number of

times a procedure is performed.

3. Resampling method: The resampling method

used to support the evaluation process.

Resampling methods apply various procedures

to train and test models on the data provided to

them. For example, the holdout method splits

the data set in a training and test set, usually in a

70%-30% ratio. The model is first trained using

the training set, afterwards it is tested on the

unseen instances of the test set. Other

resampling methods include: (stratified) k-fold

cross validation, leave-one-out and

bootstrapping.

4. Search strategy: The search strategy itself. Grid

search is exhaustive by nature, meaning that all

possible parameter combinations will be tried.

This can be costly both in time and computing

resources. Random search and Bayesian

optimization aim to find the optimal set of

parameters intelligently requiring significantly

less tries to do so.

5. Performance metrics: The performance

measure(s) used to evaluate each attempt.

Common measures are classification accuracy,

true positive rate (TPR), false positive rate

(FPR) and the area under the curve (AUC).

Using a combination of measures is necessary

since classification accuracy by itself is known

to misrepresent the performance of a model in

the case of class imbalances in the data set.

The factors discussed above are common to the

search strategies outlined in this section, and

combined they form the template that makes up the

complete problem space through where the search

will be executed. The structure and accessibility of

this approach is in line with the design goal of this

research where we aim to construct a method that

enables a user to create optimal models.

Predict & classify: Lastly, the activity “predict &

classify” is followed to conclude a DM project. The

model derived from the parameter search activity

can now be used to classify new and unseen data.

7 FUTURE RESEARCH

We are currently extending and refining the method

fragments as outlined in Figures 2-4 with the goal to

ultimately evaluate the method on a broad array of

data sets, ranging from small/large to low/high

dimensional data sets. We are interested to see how

classification performance holds up over different

variants in data sets. We are also especially

interested, by using qualitative research methods, in

studying to what extent the methods support non-

data scientists in their efforts to perform DM

projects.

Next, the problem space of our research could be

broadened to cover cases outside of the domain of

supervised binary classification, e.g. multiclass,

regression and image analysis problems. Method

fragments could be created to deal with (sub)cases in

the aforementioned domains.

Furthermore, the structures defined in these

methods could be used for the development and

enhancement of data mining tools. Auto-WEKA is

an example of such a tool but follows a rigid

method. For example, the tool uses a pre-set path of

actions and tasks and does not support embedding

domain knowledge during the DM process. From

our own experiences we identify a great need for

sophisticated tools that offer simplified access to

advanced ML techniques while retaining the ability

to embed domain knowledge in the data mining

process.

Finally, we aim to further refine and integrate

existing meta-algorithmic models, as well as to

incrementally yet continuously broaden our

modelling scope in creating ML method fragments

to also include unsupervised learning, non-binary

classification tasks, and unstructured data (e.g.

Spruit and Vlug, 2015), among others.

As our strategic objective we envision Meta-

Algorithmic Modelling (MAM) as a well-defined,

transparant, and methodological infrastructure for

Applied Data Science (ADS) research which has the

potential to uniformly interconnect the vast body of

knowledge as recipes for machine learning by

enabling application domain experts to reliably

perform data science tasks themselves in their daily

practices.

Power to the People! - Meta-Algorithmic Modelling in Applied Data Science

405

REFERENCES

Allahyari, H., and N. Lavesson. 2011. “User-Oriented

Assessment of Classification Model Understandabili-

ty,” in 11

Scandinavian Conference on Artifical

Intelligence, pp. 11-19.

Brinkkemper, S. 1996. “Method Engineering: Engineering

of Information Systems Development Methods and

Tools,” Information and Software Technology (38:4),

pp. 275-280.

Cortez, P., and M. J. Embrechts. 2013. “Using Sensitivity

Analysis and Visualization Techniques to Open Black

Box Data Mining Models,” Information Sciences

(225), pp. 1-17.

Domingos, P. 2012. “A Few Useful Things to Know about

Machine Learning,” Communications of the ACM

(55:10), pp. 78-87.

Hall, M., E. Frank, G. Holmes, B. Pfahringer, P.

Reutemann, and I. H. Witten. 2009. “The WEKA Data

Mining Software: An Update,” ACM SIGKDD

Explorations Newsletter (11:1), pp. 10-18.

Hevner, A., S. March, P. Jinsoo, and S. Ram. 2004.

“Design Science in Information Systems Research,”

MIS Quarterly (28:1), pp. 75-105.

Johansson, U., L. Niklasson, and R. König. 2004. “Accu-

racy Vs. Comprehensibility in Data Mining Models,”

in Proceedings of the Seventh International Conferen-

ce on Information Fusion Vol. 1, pp. 295-300.

Kamwa, I., S. Samantaray, and G. Joós. 2012. “On the

Accuracy Versus Transparency Trade-Off of Data-

Mining Models for Fast-Response PMU-Based

Catastrophe Predictors,” IEEE Transactions on Smart

Grid (3:1), pp. 152-161.

Kotsiantis, S. B., I. Zaharakis, and P. Pintelas. 2007.

“Supervised Machine Learning: A Review of

Classification Techniques,” in Emerging Artifical

Intelligence Applications in Computer Engineering,

pp. 3-24.

Lou, Y., R. Caruana, J. Gehrke, and G. Hooker. 2013.

“Accurate Intelligible Models with Pairwise

Interactions,” in Proceedings of the 19

ACM

SIGKDD International Conference on Knowledge

Discovery and Data Mining, pp. 623-631.

Menger, V., M. Spruit, K. Hagoort, and F. Scheepers.

2016. “Transitioning to a Data Driven Mental Health

Practice: Collaborative Expert Sessions for Knowle-

dge and Hypothesis Finding,” Computational and

Mathematical Methods in Medicine, Article ID

9089321.

Olson, D. L., D. Delen, and Y. Meng. 2012. “Comparative

Analysis of Data Mining Methods for Bankruptcy

Prediction,” Decision Support Systems (52:2), pp. 464-

473.

Orloff, M. 2016. “ABC-TRIZ: Introduction to Creative

Design Thinking with Modern TRIZ Modelling,”

Springer.

Pachidi, S., M. Spruit, and I. van der Weerd. 2014.

“Understanding Users' Behavior with Software

Operation Data Mining,” Computers in Human

Behavior (30), pp. 583-594.

Pachidi, S., and M. Spruit. 2015. “The Performance

Mining method: Extracting performance knowledge

from software operation data”, International Journal

of Business Intelligence Research (6:1), pp. 11–29.

Pritzker, P., and W. May. 2015. NIST Big Data

interoperability Framework (NBDIF): Volume 1:

Definitions. NIST Special Publication 1500-1. Final

Version 1, September 2015.

Setiono, R. 2003. “Techniques for Extracting Classifica-

tion and Regression Rules from Artificial Neural

Networks,” Computational Intelligence: The Experts

Speak Piscataway, NJ, USA: IEEE, pp. 99-114.

Simke, S. 2013. “Meta-Algorithmics: Patterns for Robust,

Low Cost, High Quality Systems,” Wiley – IEEE.

Spruit, M., and B. Vlug. 2015. “Effective and Efficient

Classification of Topically-Enriched Domain-Specific

Text Snippets”, International Journal of Strategic

Decision Sciences (6:3), pp. 1–17.

Tang, J., S. Alelyani, and H. Liu. 2014. “Feature Selection

for Classification: A Review,” Data Classification:

Algorithms and Applications Vol. 37, pp. 2 – 29.

Thornton, C., F. Hutter, H. H. Hoos, and K. Leyton-

Brown. 2013. “Auto-WEKA: Combined Selection and

Hyperparameter Optimization of Classification

Algorithms,” in Proceedings of the 19

ACM

SIGKDD International Conference on Knowledge

Discovery and Data Mining, pp. 847-855.

Tukey, J. W. 1977. “Exploratory Data Analysis,”

Addison-Wesley.

van de Weerd, I., and S. Brinkkemper. 2008. “Meta-

Modelling for Situational Analysis and Design

Methods,” Handbook of Research on Modern Systems

Analysis and Design Technologies and Applications,

pp. 35-54.

Vleugel, A., M. Spruit, and A. van Daal. 2010. “Historical

data analysis through data mining from an outsourcing

perspective: the three-phases method,” International

Journal of Business Intelligence Research, (1:3), pp.

42-65.

Yoo, I., P. Alafaireet, M. Marinov, K. Pena-Hernandez, R.

Gopidi, J. Chang, and L. Hua. 2012. “Data Mining in

Healthcare and Biomedicine: A Survey of the

Literature,” Journal of Medical Systems (36:4), pp.

2431-2448.

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

406
