Combining Two Different DNN Architectures for Classifying

Speaker’s Age and Gender

Arafat Abu Mallouh

Zakariya Qawaqneh

and Buket D. Barkana

Computer Science and Engineering Department, University of Bridgeport, Bridgeport, CT, 06604, U.S.A.

Electrical Engineering Department, University of Bridgeport, Bridgeport, CT, 06604, U.S.A.

Keywords: Deep Neural Network, GMM-UBM, I-Vector, Speaker Age and Gender Classification, Fine-Tuning.

Abstract: Speakers’ age and gender classification is one of the most challenging problems in the field of speech

processing. Recently, remarkable developments have been achieved in the neural network field, nowadays,

deep neural network (DNN) is considered one of the state-of-art classifiers which have been successful in

many speech applications. Motivated by DNN success, we jointly fine-tune two different DNNs to classify

the speaker’s age and gender. The first DNN is trained to classify the speaker gender, while the second

DNN is trained to classify the age of the speaker. Then, the two pre-trained DNNs are reused to tune a third

DNN (AGender-Tuning) which can classify the age and gender of the speaker together. The results show an

improvement in term of accuracy for the proposed work compared with the I-Vector and the GMM-UBM as

baseline systems. Also, the performance of the proposed work is compared with other published works on a

publicly available database.

1 INTRODUCTION

Computerized systems such as language learning,

phone ads, crime detection, and health monitoring

are rapidly increasing, and this creates an urgent

need for better performance. These systems can be

improved by gathering correct information about

speaker’s age, gender, accent, and emotional state

(Nguyen et al., 2010). Age and gender recognition is

the ability to recognize the age and gender

information from speaker’s speech. A key stage in

identifying speakers’ age and gender is to select and

extract effective features that represent the speaker’s

characteristics uniquely. Then a classifier uses these

features to predict the speaker’s age and gender.

Many feature sets have been developed and

evaluated in the literature. In general, these sets can

be classified into three main categories: spectral,

prosodic, and glottal features. One of the spectral

feature sets is the Mel frequency cepstral

coefficients (MFCCs), which is widely used by

many researchers. The advantage of MFCCs is the

ability to model the vocal tract filter in a short time

power spectrum (Li et al., 2013, Metze et al., 2007).

DNNs have been used effectively for feature

extraction and classification in various fields, like

computer vision (Nguyen et al., 2015, Zeiler, 2013),

image processing and classification (Ciregan et al.,

2012, Simonyan and Zisserman, 2014), and natural

language recognition (Richardson et al., 2015, Yu et

al., 2010). One of the main advantages of DNN is

the deep architecture that transforms rich input

features to strong internal representation (Baker et

al., 2009). In the past, considerable research has

been carried out to improve speaker’s age and

gender classification, but the field still needs more

work for better results.

The main contributions of this work can be

summarized as the following; the usage of DNN is

investigated to classify the speaker’s age and gender

for the public age-annotated database of german

telephone speech database (aGender) using MFCCs.

A new method for training two DNNs is introduced,

where Age-DNN and Gender-DNN are combined

into a shared output layer to produce a tuned DNN,

which is able to classify a speaker age and gender

simultaneously. The reminder of the paper is

organized as follows: A brief literature review,

methodology, experimental results and discussion,

and finally, a conclusion of the proposed work.

112

Abu Mallouh A., Qawaqneh Z. and Barkana B.

Combining Two Different DNN Architectures for Classifying Speakerâ

Zs Age and Gender.

DOI: 10.5220/0006096501120117

In Proceedings of the 10th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2017), pages 112-117

ISBN: 978-989-758-212-7

2 LITERATURE REVIEW

Speakers’ age and gender characteristics were

studied early in the 1950’s in terms of pitch and

duration (Mysak, 1959). With the developments in

computer technology, studies are mainly focusing on

the classification of speakers’ age and gender.

Ming-Li et al. (Li et al., 2013) utilized various

acoustic and prosodic features to improve

classification accuracies by combining GMM base,

GMM-SVM mean super vector, GMM-SVM-MLLR

super vector, GMM-SVM-TPP super vector, and

SVM baseline system. The highest accuracy (52.7%)

is attained when all methods are fused together.

Metze et al. (Metze et al., 2007) studied different

techniques for age and gender recognition, based on

telephone applications. They compared the

performance of their system with humans. The first

technique they used was parallel phoneme

recognizer (PPR), which is one of the early systems.

The main core of this system is to create a PPR for

each class in the age and gender database. They

reported that the PPR system performs almost like

human listeners, with the disadvantage of losing

quality and accuracy on short utterances.

Kim et al. (Kim et al., 2007) built a home robot

that classifies speakers' age and gender from speech

utterances using MFCCs, Harmonic to Noise ratio,

and Jitter and Shimmer feature sets. Three different

classifiers were used in their work: multi-layer

perceptron (MLP), GMM, and ANN, they achieved

an overall accuracy of 96.57%, 90%, and 94.6% for

age using the three classifiers respectively. Bahari et

al. (Bahari, 2011) tried to estimates the speakers’

age. In their work, they use weighted supervised

non-negative matrix factorization (WSNMF) to

reduce the dimension of the speaker HMM weight

supervector model. They achieved an accuracy of

96% for gender recognition on a Dutch speech

database. The achieved mean absolute error was

7.48 years for age recognition. Bahari et al. (Bahari,

2014) regress the speakers age by modeling each

utterance using the I-Vector and then employing the

SVR classifier.

The proposed system differs from other works in

many aspects; in our system, we utilize the

combination of different DNN architectures to

extract the features and to classify the groups.

Moreover, we introduce the idea of training two

DNNs one for age and another for gender, then

combining the two DNNs into one DNN that can

classify speaker’s age and gender.

3 METHODOLGY

The supervised training in DNNs aims to learn the

optimal weights that will make the DNN

classification process accurate with minimal

overfitting. In this work, the supervised learning is

divided into three parts; a DNN that learns the

speakers age, a DNN that learns the speakers gender,

and AGender-Tuning DNN that learns speakers age

and gender together.

3.1 Gender-DNN

This network is dedicated to capturing the gender of

each speaker. As shown in figure 1 the input for this

network is the MFCCs set, and the output labels are

male and female. The number of hidden layers is 5,

where the number of nodes in each layer are 1024

nodes. Extracting speaker gender is easier than

extracting the age or age and gender of the speaker.

The achieved accuracy of Gender-DNN is expected

to reach high scores, and this will make the Gender-

DNN participation in other DNN networks effective.

3.2 Age-DNN

This network will learn the speaker’s age, where the

input is the MFCCs feature set, and the output labels

are children, young, mature, and senior. As shown in

figure 2, the number of hidden layers is five each

consists of 1024 nodes. Decreasing the number of

labels helps the classifier to achieve better results,

we separated the gender labels from age labels to

enable the classifier to focus on age prediction. In

speech processing, it is known that age classification

is harder than gender classification, we will train

Age-DNN to focus and learn as much as possible

about speakers age, then Age-DNN will be involved

in a third DNN that utilize it.

3.3 AGender-Tuning System

In classification problems, two or more methods can

be combined and utilized by fusing their results on

the score level, but in these cases, the fusion may not

utilize the full ability of each network. In this paper,

we propose an alternative way to combine two or

more networks by fine-tuning their last hidden

layers’ outputs.

Combining Two Different DNN Architectures for Classifying Speakerâ

Zs Age and Gender

113

Figure 1: Gender-DNN architecture.

Figure 2: Age-DNN architecture.

Before combining, each network will be trained

separately to utilize the network maximum ability.

First, to generate the new proposed AGender-

Tuning network, the two trained age and gender

networks are reused as shown in figure 3. Next, a

new output layer with a softmax activation function

(softmax3) is added above the last hidden layers of

both networks to jointly fine tune them together. The

input for the newly added output layer is the

element-wise summation of the last hidden layer

outputs of age network (O

) and gender network

) as in (1).

X = O

(1)

Where is the element-wise summation between

each element in the two output vectors.

Figure 3: AGender-Tuning Network.

The output labels are 7, where each label

represents a class for a group of speakers who share

the same range of the age and gender. To combine

the two networks, the weight values of the pre-

trained age and gender networks are not changed

(frozen). Then, we train and tune the weight values of

the last hidden layers of the Age, Gender, and the

newly added output layer as follows:

1) The newly added output layer is trained using

softmax3. Consequently, the back propagation

process will take effect on the last hidden layers for

the Age-DNN and Gender-DNN.

2) Whenever Age-DNN receives updates from the

newly added output layer, it starts updating its last

hidden layer weights one more time using softmax1.

3) The same will be done for Gender-DNN,

whenever Gender-DNN receives updates from the

newly added output layer it; starts updating its last

hidden layer weights one more time using softmax2.

4) Steps 1 to 3 are repeated until there is no learning

gain.

5) Finally, after training is done, the final result (S)

of speaker's age and gender classification are

considered by taking the max of the newly added

output layer (softmax3) as in (2).

S = argmax O

softmax3

(2)

Where O

softmax3

is the output posteriors of the newly

added output layer (softmax3).

BIOSIGNALS 2017 - 10th International Conference on Bio-inspired Systems and Signal Processing

114

4 EXPERIMENTAL RESULTS

AND DISCUSSION

4.1 Data Corpus

The aGender is used to test the proposed system.

The database consists of 47 hours of prompted and

free text (Schuller et al., 2010). It includes seven

categories: Children (C, 7-14 years old), young-

female (YF, 15-24 years old), young-male (YM, 15-

24 years old), mature-female (MF, 25-54 years old),

mature-male (MM, 25-54 years old), senior-female

(SF, 55-80 years old), and senior-male (SM, 55-80

years old). A 25% of the database of random

speakers are chosen for testing, and the remaining

75% are used for training.

4.2 Baseline Systems

4.2.1 I-Vector

I-Vector is considered as one of the state-of-art

systems that showed remarkable results in many

fields such as speaker recognition and language

identification (Richardson et al., 2015). The I-Vector

process consists of, eigenvoices extraction, noise

removal, and scoring. I-Vector classifier estimates

different classes by using eigenvoice adaptation

(Kenny et al., 2007). The process of extracting the I-

Vector of any utterance starts by finding the total

variability subspace. The total variability subspace is

used to estimate a low-dimensional set from the

adapted mean supervectors; the result is called the

Identity Vector (I-Vector). For each utterance,

GMM mean vectors are calculated as in (3). The

UBM super vector, M is adapted by stacking the

mean vectors of the GMM.

M = m+ Tw (3)

T represents a low-rank matrix, and w represents the

required low-dimensional I-Vector. After that, the

linear discriminant analysis is applied to reduce the

dimension of the extracted I-Vectors by using Fisher

criterion (Dehak et al., 2011). After the extraction of

the I-Vectors, noise in each I-Vector is removed by

Gaussian probabilistic linear discriminant analysis

(Kenny, 2010). Finally, given a test utterance, the

score between a target class and the test utterance is

calculated using the log-likelihood ratio. In this

work a 25ms MFCCs plus its delta and delta-delta

are used as the input features. An age and gender

independent UBM with 1024 mixtures is trained and

built with a 600 dimensional I-Vector extractor, and

a class subspace I-Vector of 400 dimensions for G-

PLDA.

4.2.2 GMM-UBM

Seven age and gender classes were classified using a

GMM classifier, with 1024 Gaussian mixtures per

class. The input is 13-dimensional MFCCs with their

first and second derivatives. The MFCCs are

normalized to zero mean and one-unit standard

deviation by using the cepstral mean subtraction and

variance normalization algorithm. The UBM model

is trained to inspect the general speaker’s

characteristics. It is used in conjunction with the

map adaptation (MAP) model by using a relevance

factor of 10. In the test evaluation process, the GMM

is computed for each test utterance. The log-

likelihood ratio function is then used to calculate the

score between each class model and the given test

GMM model.

4.3 DNN Training Process

A speech utterance is divided into frames of 25 ms.

In total, 39 features, one energy and 12- MFCCs

with its first and second derivatives, are extracted for

each frame. The number of nodes in the input layer

is equal to 39×n features, where n represents the

target frame concatenated with the preceding and

following (n-1)/2 frames in the utterance. In the

literature n is selected to be the odd numbers in {5,

21}. In our work n is chosen to be 11. The training

data is divided into mini-batches, each mini-batch

consists of 1024 random utterances. We used 20

epochs for training initial learning rate set to 0.1 for

the first six epochs, and then decreased to one-half

its original value for the remaining epochs.

4.4 Classification Accuracies

Several experiments were conducted to evaluate the

performance of the proposed work and to compare it

with the baseline systems. The classification

accuracies are presented in Table 1. The proposed

AGender-Tuning DNN outperformed the GMM-

UBM system by approximately 12% and

outperformed the I-Vector system by almost 7%.

The proposed work extracted the speaker’s age

separately from the gender before merging the last

hidden posteriors of Age and Gender DNNs into one

layer that is to be trained further. This separate pre-

training helped to maintain the unique identity of

each speaker even after age and gender posteriors

became one layer.

Combining Two Different DNN Architectures for Classifying Speakerâ

Zs Age and Gender

115

The proposed system achieved a significant

improvement especially in mature female and male

classes (45.52%, 48.62%) and senior female and

male classes

(57.5%, 60.63%). As well as, the I-

Vector classifier achieved better results than the

GMM-UBM system in all classes except for the MM

class. We can see that in children and SF classes, the

proposed and the I-Vector systems achieved almost

same results with a slight advantage for the

AGender-Tuning system. The confusion matrix for

the proposed system is presented in Table 2.

It can be seen from table 2 that the proposed

system achieved a significant improvement for all

classes especially for (MF, MM, SF, and SM). Our

system was able to discriminate between these

classes better than the baseline systems. Agender-

Tuning system has been trained in two ways, first

with separated age (Age-DNN) and gender (Gender-

DNN) networks, second, with a shared output layer

resulted from the Age-DNN and Gender-DNN

output layers, and this shared output layer has seven

age and gender labels.

Table 1: The classification accuracies of GMM-UBM, I-

Vector, and AGender-Tuning DNN (%).

GMM-

UBM

I-Vector AGender-

Tuning

C 55.6 64.9 65.7

YF 48 57.1 58.3

YM 41.9 49 49.9

MF 29.6 32.5 45.5

MM 41.2 36 48.6

SF 36.4 49.9 57.5

SM 53.9 45.8 60.6

Table 2: Confusion matrix for the aGender-Tuning DNN.

Act.

Pred.

C YF YM MF MM SF SM

65.7

14.9 5.7 3.2 2.1 6.2 2.3

YF 11.8

58.3

0.5 19.9 0.7 8.3 0.5

YM 2.1 0.9

49.9

2.6 26.9 2.9 14.7

MF 8.6 18.2 1.2

45.5

1.2 24.8 0.5

MM 1.2 0.1 22.3 0.3

48.6

1.2 26.2

SF 8.1 9.1 1.2 21.1 1.5

57.5

1.5

SM 1.5 0 8.7 1.2 22.2 5.8

60.6

To evaluate the performance of the baseline

systems and the proposed work when the time

duration of the speech utterance is different; we

examined the overall accuracy of each system over

five slots of time durations (1-5 seconds). Figure 4

shows the performance of the three systems.

Figure 4: Comparison between the AGender-Tuning and

the baseline systems for different time duration utterances.

Table 3: Comparison of proposed and previous works (%).

System Accuracy

GMM Base-1 43.1

Mean Super Vector-2 42.6

MLLR Super Vector-3 36.2

TPP Super Vector-4 37.8

SVM Base-5 44.6

MFuse 1+2+3+4+5 52.7

AGender-Tuning 55.16

In general, the performance of all systems has

been enhanced by increasing the duration of the

utterance time; AGender-Tuning system performed

better than the baseline systems for all time slots. A

possible explanation refers to the fact that I-Vector

and GMM-UBM systems could not build a good

representation of eigenvector and GMM-UBM

supervector for the corresponding utterance if it is

short in time, and it is known that the aGender

database utterances are short in time. When the

duration of the utterance increases, for example from

3 to 4 seconds, the accuracy is not increasing for the

GMM-UBM and AGender-Tuning system, this is

due to the sparse data of these utterances duration,

where most of the YF, MF, and MM utterances

exists in this time duration. Also, we noticed from

table 2 that the higher misclassification occurs

between these

classes and these classes have the

least accuracy results among other classes.

Table 3 shows a comparison between the

proposed work and six different methods presented

in (Li et al., 2013). The best result in (Li et al., 2013)

occurred when all systems are combined manually

(MFuse 1+2+3+4+5), as shown in the table. We can

BIOSIGNALS 2017 - 10th International Conference on Bio-inspired Systems and Signal Processing

116

see that AGender-Tuning system outperforms all the

baseline systems of the manually fused system.

Using our method, the accuracy of the speaker’s age

and gender is improved by approximately 3%

compared with the fused system.

5 CONCLUSION

In this work, we proposed AGender-Tuning DNN

system to classify the speakers’ age and gender by

combining two DNN architectures; Age-DNN to

classify four groups of age, and Gender-DNN to

classify the gender. A third output layer is proposed

to combine the output layers of Age and Gender

DNNs using element-wise summation. The results of

the proposed work are compared with two baseline

systems; the I-Vector and GMM-UBM on the public

database aGender. The proposed work achieved

better results in terms of overall accuracy and even

for individual classes. Also, the proposed system was

doing very well compared with the baseline systems

regardless of the time duration of the speaker

utterance. The overall accuracy of the proposed

system, I-Vector, and GMM-UBM systems are

55.16%, 47.89%, and 43.8% respectively.

REFERENCES

Bahari, M.H. and Van Hamme, H., 2011. Speaker age

estimation and gender detection based on supervised

non-negative matrix factorization. In Biometric

Measurements and Systems for Security and Medical

Applications (BIOMS), 2011 IEEE Workshop on (pp.

1-6). IEEE.

Bahari, M.H., McLaren, M. and van Leeuwen, D.A., 2014.

Speaker age estimation using i-vectors. Engineering

Applications of Artificial Intelligence, 34, pp.99-108.

Baker, J. M., Deng, L., Glass, J., Khudanpur, S., Lee, C.-

H., Morgan, N. & Shaughnessy, D. O., 2009.

Developments and directions in speech recognition

and understanding, Part 1 [DSP Education]. Signal

Processing Magazine, IEEE, 26, 75-80.

Ciregan, D., Meier, U. and Schmidhuber, J., 2012. Multi-

column deep neural networks for image classification.

In Computer Vision and Pattern Recognition (CVPR),

2012 IEEE Conference on (pp. 3642-3649). IEEE.

Dehak, N., Kenny, P., Dehak, R., Dumouchel, P. &

Ouellet, P., 2011. Front-end factor analysis for speaker

verification. Audio, Speech, and Language Processing,

IEEE Transactions on, 19, 788-798.

Kenny, P., 2010. Bayesian speaker verification with

heavy-tailed Priors. In proc. of Odyssey - The Speaker

and Language Recognition Workshop, Brno, CZ.

Kenny, P., Boulianne, G., Ouellet, P. & Dumouchel, P.,

2007. Joint factor analysis versus eigenchannels in

speaker recognition. Audio, Speech, and Language

Processing, IEEE Transactions on, 15, 1435-1447.

Kim, H.J., Bae, K. and Yoon, H.S., 2007. Age and gender

classification for a home-robot service. In RO-MAN

2007-The 16th IEEE International Symposium on

Robot and Human Interactive Communication(pp.

122-126). IEEE.

Li, M., Han, K. J. & Narayanan, S., 2013. Automatic

speaker age and gender recognition using acoustic and

prosodic level information fusion. Computer Speech &

Language, 27, 151-167.

Metze, F., Ajmera, J., Englert, R., Bub, U., Burkhardt, F.,

Stegmann, J., Muller, C., Huber, R., Andrassy, B.,

Bauer, J.G. and Littel, B., 2007. Comparison of four

approaches to age and gender recognition for

telephone applications. In 2007 IEEE International

Conference on Acoustics, Speech and Signal

Processing-ICASSP'07 (Vol. 4, pp. IV-1089). IEEE.

Mysak, E. D., 1959. Pitch and duration characteristics of

older males. Journal of Speech & Hearing Research.

Nguyen, A., Yosinski, J. and Clune, J., 2015. Deep neural

networks are easily fooled: High confidence

predictions for unrecognizable images. In 2015 IEEE

Conference on Computer Vision and Pattern

Recognition (CVPR)(pp. 427-436). IEEE.

Nguyen, P., Tran, D., Huang, X. & Sharma, D., 2010.

Automatic Speech-Based Classification of Gender,

Age and Accent. In: KANG, B.-H. & RICHARDS, D.

(eds.) Knowledge Management and Acquisition for

Smart Systems and Services. Springer Berlin

Heidelberg.

Richardson, F., Reynolds, D. & Dehak, N., 2015. Deep

neural network approaches to speaker and language

recognition. Signal Processing Letters, IEEE, 22,

1671-1675.

Schuller, B., Steidl, S., Batliner, A., Burkhardt, F.,

Devillers, L., Müller, C.A. and Narayanan, S.S., 2010.

The INTERSPEECH 2010 paralinguistic challenge.

In InterSpeech (Vol. 2010, pp. 2795-2798).

Simonyan, K. & Zisserman, A., 2014. Very deep

convolutional networks for large-scale image

recognition. arXiv preprint arXiv:1409.1556.

Yu, D., Wang, S., Karam, Z. and Deng, L., 2010.

Language recognition using deep-structured

conditional random fields. In 2010 IEEE International

Conference on Acoustics, Speech and Signal

Processing (pp. 5030-5033). IEEE.

Zeiler, M. D., 2013. Hierarchical convolutional deep

learning in computer vision. PhD thesis, ch. 6, New

York University.

Combining Two Different DNN Architectures for Classifying Speakerâ

Zs Age and Gender

117
