Toward Gamified Knowledge Contents Refinement
Case Study of a Conversation Partner Agent
Takayuki Iwamae
1
, Kazuhiro Kuwabara
2
and Hung-Hsuan Huang
2
1
Graduate School of Information Science and Engineering, Ritsumeikan University, Kusatsu, Shiga 525-8577, Japan
2
College of Information Science and Engineering, Ritsumeikan University, Kusatsu, Shiga 525-8577, Japan
Keywords:
Crowdsourcing, Gamification, Knowledge Refinement, Conversation Partner Agent.
Abstract:
Rich knowledge contents are necessary to develop an intelligent agent that interacts with people and supports
their communication or their activities. In this paper, we choose a conversation partner agent for people
with aphasia as an example and propose a method that interactively acquires and refines knowledge contents
for the agent. The proposed method is invoked when a problem is found in the knowledge contents and
utilizes the concept of gamified crowdsourcing. Gamified tasks verify the data input by a user. By utilizing a
crowdsourcing approach, we strive for more accurate knowledge contents. The paper presents its game design
and an example scenario.
1 INTRODUCTION
A large amount of knowledge contents is required to
develop an intelligent agent to support human com-
munication or activities. Knowledge contents may be
constructed from data available on the Internet using
machine learning technologies, for example. On the
other hand, the concept of crowdsourcing can also
be applied to construct various knowledge contents
by harnessing the power of hundreds or thousands of
people. In such crowdsourcing platforms as Amazon
Mechanical Turk (MTurk)
1
, many microtasks, often
called Human Intelligence Tasks (HITs), are shared
with many workers over networks. An example of
such a task is labeling an image.
In crowdsourcing, giving proper incentives to
workers is important for eliciting both qualitative and
quantitative better performances. A typical reward is
monetary, which can be considered an extrinsic mo-
tivation. The importance of intrinsic motivation has
also been pointed out (Ryan and Deci, 2000). Gami-
fication, which is defined as the use of game design
elements in non-gaming contexts (Deterding et al.,
2011), is a popular method to provide intrinsic mo-
tivation. In crowdsourcing, the idea of gamification is
widely utilized (Morschheuser et al., 2016).
In this paper, we propose a method that utilizes a
gamified crowdsourcing approach for knowledge con-
1
http://www.mturk.com/
tents refinement and focuses on a case of fixing prob-
lems in knowledge contents. The proposed method is
intended to be applied when a problem is found while
using the target system. Users provide the initial data
for revising the knowledge contents, and through a
gamified crowdsourcing process, many users can con-
tribute to its refinement.
As an example application, we use a conversa-
tion partner agent for people with aphasia (Kuwabara
et al., 2016). One of the conversation partner agent’s
functions is to assist the retrieval of a word that a per-
son with aphasia is having difficulty recalling. This
assisting process uses knowledge contents to present a
series of questions for the person with aphasia. From
his answers, the conversation partner agent suggests
the word he wants to express.
The rest of this paper is organized as follows. The
next section describes related work, followed by a
description of a conversation partner agent, which is
the target domain of this work. Section 4 explains
our proposed method that refines knowledge contents,
and Section 5 describes an application of the gamifi-
cation concept. We conclude this paper in Section 6.
2 RELATED WORK
Many applications of the gamification concept exist
in crowdsourcing tasks. One early application was
Games with a purpose (GWAPs), where a game ele-
302
Iwamae T., Kuwabara K. and Huang H.
Toward Gamified Knowledge Contents Refinement - Case Study of a Conversation Partner Agent.
DOI: 10.5220/0006243103020307
In Proceedings of the 9th International Conference on Agents and Artificial Intelligence (ICAART 2017), pages 302-307
ISBN: 978-989-758-219-6
Copyright
c
2017 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
ment was introduced in a task (von Ahn and Dabbish,
2008). Introducing a proper game rule makes it possi-
ble to produce meaningful results from game-playing.
GWAPs are applied in various fields including seman-
tic knowledge acquisition (Siorpaes and Hepp, 2008).
The gamification idea is also used with paid
crowdsourced microtasks. An incentive model for
such a case was proposed (Feyisetan et al., 2015).
Quizz is another gamified crowdsourcing system for
knowledge curation (Ipeirotis and Gabrilovich, 2014).
To maintain the quality of the knowledge, it uses a
calibration quiz whose answers are known before-
hand to estimate a worker’s competence.
In addition, a web-based game called Common
Consensus (Lieberman et al., 2007) collects and val-
idates commonsense knowledge for understanding
goals in everyday human life. Similarly, in Robot
Trainer (Rodosthenous and Michael, 2016), not only
factual knowledge is collected but also knowledge in
rule form.
In this paper, we target the knowledge contents
that are used in the domain of word retrieval assis-
tance for people with aphasia and focus on the refine-
ment of the pieces of collected knowledge contents.
In the refinement process, we handle not only con-
ventional answers but also obscure ones and let work-
ers input their own level of confidence to maintain the
quality of the final results.
3 CONVERSATION PARTNER
AGENT
Conversation partner agents are intended to be used as
a kind of interpreter for people with aphasia. One of
their main functions is to support the word retrieval
process for such sufferers. That is, a person with
aphasia often has a problem recalling the proper word
even though he knows what he wants to say. In such
a situation, a human supporter (conversation partner)
acts as an interpreter to elicit the word. For example,
when a person with aphasia wants a particular type of
food, the human conversation partner might ask, Is it a
fruit? or Is it a snack?. Depending on the answer, the
human conversation partner narrows down to identify
the word the person with aphasia is thinking about.
The conversation partner agent is designed to
present an appropriate question for the person with
aphasia, and based on the answer, candidates are nar-
rowed down (Fig. 1). When a word with a certain pos-
sibility is identified, the agent presents it. The knowl-
edge contents are utilized that contain possible words
to be guessed and questions to ask. Note that the con-
versation partner agent is not meant to completely re-
Person with
aphasia
Select the next
question to ask
Update word
probabilities
Question
Answer
Conversation
Partner Agent
Word
suggestion
Determine the word
to suggest
Knowledge
Contents
Figure 1: Conversation partner agent overview.
place human conversation partners; it can also give
assistance by providing proper questions to ask and
reduce his burden.
This word retrieval assistance process resembles
a popular game called Akinator
2
, which guesses the
identity of a character being thought of through a se-
ries of questions and answers. It also allows a player
to input the correct answer when the system fails to
find an answer. This game, however, focuses on char-
acters that are either fictional or real, whereas con-
versation partner agents must handle a variety of top-
ics. In addition, in the Akinator game, some questions
such as Does the name begin with ’A’? assume that the
player already knows the word (name) of the answer
(character). This kind of question is not appropriate
for word retrieval assistance.
3.1 Knowledge Contents
The knowledge contents for the word retrieval assis-
tant consists of words, questions, and the answers to
the given question for the word the person with apha-
sia is thinking of. Let w ( D) denote a target word of
the word retrieval assistant, where D denotes a set of
possible words. Let q
i
(1 i n) denote a question to
ask to identify the word. We assume n multiple choice
type questions. Let N
i
denote the number of answer
choices for question q
i
, and let c
ik
(1 k N
j
) denote
an answer choice for question q
i
.
We also assume that multiple answers are possible
for word w. As we will explain below, we exploit the
concept of information gain to select the next ques-
tion. The knowledge contents contain the probability
that answer choice c
ik
is selected when question q
i
is
asked and w is the correct answer. This probability is
denoted by p(c
ik
|w). If there is no possibility that c
ik
will be chosen, p(c
ik
|w) = 0.
2
http://en.akinator.com
Toward Gamified Knowledge Contents Refinement - Case Study of a Conversation Partner Agent
303
3.2 Interaction with Users
The word retrieval assistant’s goal is to guess the word
the user is thinking about. In this regard, we calcu-
late the probability that word w is the correct answer,
which is denoted by p(w). Based on the answers to
the questions, the values of p(w) are updated. When
the probability of the word exceeds a certain thresh-
old, it is selected as the one the user has in mind.
The next question is determined based on infor-
mation gain (Arima et al., 2015; Kuwabara et al.,
2016). To calculate the expected information gain
of asking question q
i
, first we set the probabilities of
words, p(w). The average information entropy, H,
can be defined as follows:
H =
wD
p(w)log p(w) .
The probability of w when answer choice c
ik
is
selected for question q
i
is represented using the
Bayesian theorem:
p(w|c
ik
) =
p(c
ik
|w)
p(c
ik
)
p(w) .
The probability that c
ik
is selected for question q
i
is
calculated as follows:
p(c
ik
) =
wD
p(c
ik
|w)p(w) .
The values of p(c
ik
|w) are taken from the knowledge
contents. The expected entropy after c
ik
is selected
when question q
i
is asked, H
ik
, is given as:
H
ik
=
wD
p(w|c
ik
)log p(w|c
ik
) ,
and the expected entropy after question q
i
is asked is
calculated as:
H
i
=
N
i
k=1
p(c
ik
)H
ik
.
Thus, the information gain of question q
i
, IG
i
, is
given as:
IG
i
= H H
i
.
To determine the next question, we calculate the
priority of question q
i
, PR
i
. The priority value takes
into consideration the number of answer choices for
question q
i
in addition to its information gain. Gener-
ally the information gain becomes higher when there
are many answer choices, but it is inadvisable to ask a
question with too many answer choices from the start,
especially for people with aphasia who might have
difficulty understanding too many answer choices.
PR
i
is defined as follows:
PR
i
=
1
N
i
β
IG
i
,
Table 1: Example knowledge contents.
q
1
: Is it a
fruit?
q
2
: What
color is it?
q
3
: What
does it taste
like?
strawberry Yes red sweet
banana Yes yellow sweet
orange Yes orange sweet,sour
lettuce No green
carrot No orange sweet,bitter
tomato No red
where β denotes the parameter that represents the ef-
fect of the number of answer choices of the question
and is set to 1.5 in the prototype.
The question with the highest priority value is se-
lected and asked. When c
ik
is selected as its answer,
p(w) is updated with p(w|c
ik
). This process contin-
ues until the probability of a certain word exceeds a
predefined threshold. If all the probabilities of words
become 0, the system reports that no answer is found.
If the questions are exhausted before it narrows down
the options to a single word, a list of possible answers
is returned.
3.3 Example Scenario
As an example, consider the simple data shown in Ta-
ble 1. In this example, there are three questions and
six words. Each cell in the table defines an answer
for the word when a question is asked. When there is
only one answer in the cell, 1 is the probability that
that answer will be selected. For example, an answer
to question q
2
(What color is it?) for strawberry is red,
and p(red|strawberry ) = 1 for q
2
. If the cell contains
two possibilities, such as the answer to q
3
(What does
it taste like?) for orange, they are treated as if the
possibility of each answer is 0.5. If there is no defi-
nite answer or an answer is unknown, “” is inserted
in the table.
Assume that the user (person with aphasia) is
thinking about strawberry. The system first calcu-
lates the priorities of the three questions and selects
q
1
: Is it a fruit?. In reply, answer Yes is given, and
then q
2
is asked next: What color is it?. If answer red
is given, strawberry will be chosen as the word the
user is thinking of since only strawberry remains as a
possibility in the example knowledge contents.
4 KNOWLEDGE CONTENTS
REFINEMENT
An overview of our proposed method of knowledge
contents refinement is shown in Fig. 2. When a word
ICAART 2017 - 9th International Conference on Agents and Artificial Intelligence
304
Game
Materials
Game
Play Log
Game
Scores
Game Generation
Game Execution Manager
Score
Calculation
Conversation Partner Agent
Word Retrieval
Assistance
Knowledge
Contents
Game Players
(Workers)
[start] Correct answer
cannot be obtained
Data for
Refinement
Data
Collection
New word/question
Revised data
Knowledge Contents Extraction
Person with
aphasia
(Human) Conversation Partner / Caregiver
Figure 2: Knowledge contents refinement overview.
retrieval assistant system fails to produce a correct an-
swer, it asks for data with which to revise the knowl-
edge contents. We assume that a human caregiver
such as a conversation partner who uses the system
with a person with aphasia will input the correct an-
swer. Using the input data, gamified tasks are gen-
erated and executed by other users. Based on their
results, the knowledge contents are updated.
4.1 Invocation of a Refinement Process
When the word retrieval assistant system fails to find a
word with high probability or to narrow a list of words
to one, it is treated as a failure. The followings are the
possible causes of failures: 1) The target word is not
in the knowledge contents; 2) The target word is in
the knowledge contents, but its data are not correct; 3)
There are not enough questions to narrow the possible
words to one.
In our proposed method, the data for correction
are input by the user. When a word cannot be found
or a word comes out that is different from what the
user had in mind, the correct answer (word) is asked
to be entered. When the word cannot be narrowed to
one, another question must be entered.
The data input for revision can be represented as
a triple hw, q
i
, c
ik
i. The system contains the history
of the user’s responses, which can be used as part of
the data when a new word is input. However, with
this information, we cannot determine the value of
the probability of p(c
ik
|w) required by the knowledge
contents. The gamified tasks are generated from these
triples to determine p(c
ik
|w) values.
4.2 Example Scenario (cont’d)
Continuing the example scenario explained above, as-
sume that apple is the word being thought of by the
user. As before, based on a question’s priority value,
q
1
is asked first: Is it a fruit?. The user answers with
Yes. Then the next question (What color is it?) is an-
New word is entered
Answers for each question are shown
Figure 3: Entering a new word.
Table 2: Data added for a new word.
Word Question Answer
apple q
1
: Is it a fruit? Yes
apple q
2
: What color is it? red
swered with red, and strawberry is suggested by the
system, which is not correct in this case. This invokes
the revising mode. The correct answer apple is en-
tered as shown in Fig. 3. By utilizing the history of
a user’s responses, additional data for apple are also
obtained, as shown in Table 2.
Assume that these additional data are added to the
knowledge contents. In this case, after the responses
are obtained for q
1
and q
2
, the possible words that re-
main are strawberry and apple. Question q
3
is asked
next: What does it taste like?. However, apple re-
mains one possibility since it has no answer data for
question q
3
, and consequently, it cannot be eliminated
from the possible word list.
In such a case, a new question is needed to distin-
guish between apple and strawberry. Suppose that a
new question is input with the answers for these two
words: How big is it?. Then the data shown in Table 3
are obtained.
Further, assume that the word the user has in mind
is a specific kind of apple, for example, a green apple.
In this case, for the first question q
1
(Is it a fruit?), Yes
is the answer, and the next question q
2
(What color is
it?) is presented with the following possible answer
choices: red, orange, and yellow. Since the answer
choices do not contain the correct response, the user
must choose none of the above. In this case, the cor-
rect answer, apple, is entered in the revising mode,
Toward Gamified Knowledge Contents Refinement - Case Study of a Conversation Partner Agent
305
Table 3: Data of new question.
Word Question Answer
strawberry q
4
: How big is it? small
apple q
4
: How big is it? medium
and the answer to question q
2
(What color is it?) is
entered as green.
At this state, question q
2
(What color is it?) will
have two possible answers for apple: red and green.
The possibilities of these answers are determined with
the gamified tasks explained in the next section.
5 GAMIFIED REFINEMENT
PROCESS
5.1 Task Description
We designed a task to determine the possibilities of
an answer for a given question. The task presents
a statement that can be answered by either Yes or
No. A worker inputs his degree of agreement with
the presented statement and also her confidence value.
The statement of the task, denoted by s
w,ik
, is gener-
ated from the data to revise the knowledge contents:
hw, q
i
, c
ik
i. Worker u enters the degree of agreement
to statement s
w,ik
, denoted by A
u
(s
w,ik
) and the confi-
dence value, denoted by B
u
(s
w,ik
). Both values range
between 0 and 1.
Let M denote a set of workers of the task. We
first calculate the weighted average of the degree of
agreement regarding statement s
w,ik
, where the weight
is determined based on the confidence value. Let v
w,ik
denote this weighted average. We determine the value
of p(c
ik
|w) by considering every possible c
ik
for ques-
tion q
i
. By denoting a set of possible values of c
ik
by
C
i
, we have the following:
v
w,ik
=
uM
A
u
(s
w,ik
)B
u
(s
w,ik
)
uM
B
u
(s
w,ik
)
p(c
ik
|w) =
v
w,ik
c
ik
C
i
v
w,ik
.
Continuing the above example, for the triple of
word apple, question What color is it?, and answer
red, the generated statement is The color of the ap-
ple is red. A worker enters his degree of agreement to
this statement and his confidence value (Fig. 4).
Assume that after the tasks are executed by differ-
ent workers, the results shown in the three most left
columns of Table 4 are obtained. Note that the num-
ber of entries is kept small for the example’s clarity.
From these inputs we get v
w,ik
= 0.816 for red and
v
w,ik
= 0.177 for green. From these values, we get
p(red|apple) = 0.821 and p(green|apple) = 0.178.
The color of the apple
is red.
Player’s input
Player’s input
(confidence)
Figure 4: Screenshot of playing the game.
5.2 Scoring Rules
Next we introduce the concept of gamification into
the above tasks. Gamification’s main objective is to
motive workers (or game players) to execute tasks.
We present a set of tasks to a worker under a time
limit. For example, one game round might consist of
12 tasks that must be executed in 60 seconds. By set-
ting a time limit, a worker is expected to make more
intuitive answers. Points are basically given based on
the number of executed tasks. However, if the points
given are only determined by the number of executed
tasks, workers are not motivated to input appropriate
answers.
To address this problem, we also give bonus points
to workers as an incentive to deliver more plausible
answers. Bonus points, which are calculated after the
value of p(c
ik
|w) is determined, increase when degree
of agreement A
u
(s
w,ik
) is closer to p(c
ik
|w). When
A
u
(s
w,ik
) and p(c
ik
|w) are the same, the bonus points
are the highest; a worker who submits the most dif-
ferent values from p(c
ik
|w) receives the fewest bonus
points. In addition, we consider confidence value
B
u
(s
w,ik
) input by a worker.
More specifically, we calculate the number of
bonus points given to a worker, denoted by R
u
, as fol-
lows. Let err
u
denote the absolute difference between
A
u
(s
w,ik
) and p(c
ik
|w). If err
u
is smaller than half of
max
uM
err
u
, the bonus points are increased. Other-
wise, they are decreased. The amount of increase or
decrease is determined by confidence value B
u
(s
w,ik
):
err
u
= |A
u
(s
w,ik
) p(c
ik
|w)|
R
u
= BP(1 K(err
u
max
uM
err
u
2
))B
u
(s
w,ik
) ,
where K denotes a parameter that represents the effect
of the confidence value to the bonus points and BP
denotes the ratio of the internal value to them.
Continuing the earlier example, a worker’s bonus
points are calculated as shown in the right most col-
umn of Table 4, where K is set to 10 and BP is set to
100. A worker who submitted a degree of agreement
value closer to p(c
ik
|w) is given more bonus points,
and a worker who submitted the value farthest from
p(c
ik
|w) receives fewer bonus points.
The worker with higher confidence values re-
ceives more bonus points even if he enters the same
ICAART 2017 - 9th International Conference on Agents and Artificial Intelligence
306
Table 4: Example of worker inputs and bonus points.
Worker input Bonus points
Worker Degree of
agreement
Confidence
value
Difference
with
p(c
ik
|w)
Bonus
points R
u
The color of the apple is red.
u
1
0.9 0.9 0.084 77
u
2
0.8 0.3 -0.016 113
u
3
0.8 0.8 -0.016 134
u
4
0.7 0.5 -0.116 71
The color of the apple is green.
u
1
0.2 0.4 0.022 116
u
2
0.3 0.3 0.122 82
u
3
0.1 0.6 -0.078 90
degree of agreement values (see u
2
and u
3
in Table 4).
Since the confidence values are reflected in determin-
ing both p(c
ik
|w) and bonus points R
u
, if we assume
that a worker wants to gain more points, he will be
more motivated to input more plausible answers.
6 CONCLUSIONS AND FUTURE
WORK
This paper presented a method of refining knowledge
contents to be used with a conversation partner agent
for people with aphasia. Our proposed method deals
with such problems of knowledge contents as missing
words or questions. The information that revise the
knowledge contents is requested to be entered by a
user, and then the input data are refined by applying
the concept of gamified crowdsourcing.
Currently we are implementing a prototype as a
web application with conventional gamification ele-
ments such as a leader board or a badge system. We
plan to conduct evaluation experiments to show the
effectiveness of our proposed approach, especially
where a gamified approach can effectively provide
better incentives to workers.
In this paper, the conversation partner agent is
used as the target of our case study. The word retrieval
assistance process can be viewed as guessing an item
a user is consciously or unconsciously thinking of.
It can be viewed as recommending an item a user
wants through a series of questions and answers. The
proposed knowledge contents refining method can be
used for such kinds of applications. We also plan to
apply the proposed method to other application do-
mains.
ACKNOWLEDGEMENTS
This work was partially supported by JSPS KAK-
ENHI Grant Number 15K00324.
REFERENCES
Arima, S., Kuroiwa, S., Horiuchi, Y., and Furukawa, D.
(2015). Question-asking strategy for people with
aphasia to remember food names. Journal on Tech-
nology & Persons with Disabilities, 3:10–19.
Deterding, S., Dixon, D., Khaled, R., and Nacke, L. (2011).
From game design elements to gamefulness: Defining
”gamification”. In Proceedings of the 15th Interna-
tional Academic MindTrek Conference: Envisioning
Future Media Environments, pages 9–15. ACM.
Feyisetan, O., Simperl, E., Van Kleek, M., and Shadbolt, N.
(2015). Improving paid microtasks through gamifica-
tion and adaptive furtherance incentives. In Proceed-
ings of the 24th International Conference on World
Wide Web, WWW ’15, pages 333–343. International
World Wide Web Conferences Steering Committee.
Ipeirotis, P. G. and Gabrilovich, E. (2014). Quizz: Targeted
crowdsourcing with a billion (potential) users. In
Proceedings of the 23rd International Conference on
World Wide Web, WWW ’14, pages 143–154. ACM.
Kuwabara, K., Iwamae, T., Wada, Y., Huang, H.-H., and
Takenaka, K. (2016). Toward a conversation part-
ner agent for people with aphasia: Assisting word
retrieval. In Intelligent Decision Technologies 2016:
Proceedings of the 8th KES International Conference
on Intelligent Decision Technologies (KES-IDT 2016)
Part I, pages 203–213. Springer International Pub-
lishing.
Lieberman, H., Smith, D., and Teeters, A. (2007). Common
consensus: a web-based game for collecting common-
sense goals. In ACM Workshop on Common Sense for
Intelligent Interfaces.
Morschheuser, B., Hamari, J., and Koivisto, J. (2016).
Gamification in crowdsourcing: A review. In 49th
Hawaii International Conference on System Sciences
(HICSS), pages 4375–4384.
Rodosthenous, C. and Michael, L. (2016). A hybrid ap-
proach to commonsense knowledge acquisition. In
proceedings of the 8th European Starting AI Re-
searcher Symposium (STAIRS 2016), pages 111–122.
IOS Press.
Ryan, R. M. and Deci, E. L. (2000). Self-determination the-
ory and the facilitation of intrinsic motivation, social
development, and well-being. American psychologist,
55(1):68–78.
Siorpaes, K. and Hepp, M. (2008). OntoGame: Weaving the
semantic web by online games. In The Semantic Web:
Research and Applications, volume 5021 of Lecture
Notes in Computer Science, pages 751–766. Springer
Berlin Heidelberg.
von Ahn, L. and Dabbish, L. (2008). Designing games with
a purpose. Commun. ACM, 51(8):58–67.
Toward Gamified Knowledge Contents Refinement - Case Study of a Conversation Partner Agent
307
