Privacy-aware Data Storage in Cloud Computing

emy Pottier and Jean-Marc Menaud

IMT Atlantique, 4 rue Alfred Kastler, 44307 Nantes, France

Keywords:

Cloud Computing, Storage, Privacy, Security.

Abstract:

The increasing number of cloud storage services like Dropbox or Google Drive allows users to store more

and more data on the Internet. However, these services do not give users enough guarantees in protecting the

privacy of their data. In order to limit the risk that the storage service scans user documents, for example, for

commercial purposes, we propose a storage service that stores data on several cloud providers while prohibing

these providers to read user documents. Indeed, the proposed sky storage service (i.e., a service composed

of several cloud services) named SkyStore, protects the user privacy by breaking user documents into blocks

and spreading these blocks over many cloud storage providers. The architecture of this service ensures that

SkyStore can not read user documents. It connects directly users to cloud providers in order to avoid trusting

a third-party. This paper consists of two parts. First, the sky service architecture is described to detail the

different protections provided to secure user documents. Second, the consequences of this architecture on the

performance are discussed.

1 INTRODUCTION

Nowadays, the cloud computing offers a very wide

variety of services like cinema programs, weather

forecast or television series streaming. Moreover,

these services are readily available for free download

from application stores like the Apple App Store or

Google Play. These applications, for desktop comput-

ers or mobile phones, change the way we interact with

online services. In promising to access our documents

(pictures, movies, text ﬁles) from anywhere, the num-

ber of users of cloud storage services like Dropbox

grows rapidly. However, storing personal data in the

cloud needs trusted storage services that ensure the

protection and the privacy of our data. For exam-

ple, some mail services scan the content of emails

for tailored advertising, so it does not appear impossi-

ble to consider that some storage services could scan

the content of our ﬁles in our own best interest, as

they say. With storage services like Dropbox, users

must have full trust in the cloud provider manag-

ing their data because providers can read user docu-

ments and retrieve information about users. So, some

users subscribe to storage services that use encryp-

tion at the user side like SpiderOak. As data is en-

crypted before outsourcing it to a cloud provider, the

user privacy is strengthened because the provider can

not read user documents. However, the recent FBI-

Apple encryption dispute

or successful side-channel

attacks (Genkin et al., 2014) have shown us that de-

crypting data is possible. Moreover, in countries like

France, the size of the encryption key is limited to

128 bits with all the consequences that involves for

the data privacy.

In order to help users to ensure the privacy of data

stored on different cloud providers, we proposed a

storage service based on many cloud providers run-

ning exclusively on the user side. To ensure the data

privacy without using encryption, users break their

documents into blocks and these blocks are stored on

cloud providers. By ensuring that each cloud provider

owns only one part of blocks, cloud providers can not

read or deliver user documents. To avoid the use of

a trusted third-party that could threaten the data pri-

vacy, the storage service is not hosted on the cloud

but it runs on user devices and it connects directly to

cloud providers. So, user data and the organization

of the data on cloud providers, i.e., the metadata, are

only managed by users, and so, only users can read

their documents. Consequently, the trust is placed in

the application on the user device rather than in the

storage service on the cloud.

In the remainder of this paper, we describe mech-

anisms for ensuring the user data privacy in the pro-

http://www.cnbc.com/2016/03/29/apple-vs-fbi-all-

you-need-to-know.html

Pottier, R. and Menaud, J-M.

Privacy-aware Data Storage in Cloud Computing.

DOI: 10.5220/0006294204050412

In Proceedings of the 7th International Conference on Cloud Computing and Services Science (CLOSER 2017), pages 377-384

ISBN: 978-989-758-243-1

377

posed cloud storage service. Section 2 gives an

overview of existing works about privacy-aware sys-

tems and cloud storage. Section 3 shows the architec-

ture of the storage service and it describes the man-

agement of both the data and the metadata associated

with user documents. Section 4 analyzes the per-

formance of a prototype of the storage service and

it compares this prototype to existing cloud storage

services. Section 5 provides a conclusion and future

works.

2 RELATED WORKS

In the early 2000s, many works contribute to possible

solutions for anonymous storage accessible by the In-

ternet based on peer-to-peer architectures (Dingledine

et al., 2000)(Waldman and Mazieres, 2001). These

systems permit to store and access documents while

protecting the anonymity of users. The cooperation

of the high number of nodes in the architecture al-

lows to hide where the data is really stored and the

user that stores or reads the document. Tangler and

The Free Haven Project break documents into smaller

blocks by using redundant distribution schemes, such

as erasure code algorithms (Luo et al., 2009) or infor-

mation dispersal algorithms (Rabin, 1989), in order to

efﬁciently replicate documents. In these peer-to-peer

systems, the high number of nodes is critical to en-

sure a large storage space and the anonymity of both

users and documents. Additionally, the system can

not guarantee optimum performance because it can

not control node capabilities.

For the purpose of providing a reliable storage

space on the Internet with a competitive price, storage

providers use the possibilities offered by the cloud. To

avoid being dependent on one single cloud provider,

RACS (Abu-Libdeh et al., 2010) and SCMCS (Singh

et al., 2011) propose cloud storage services using sev-

eral cloud providers to improve the data availability

by maintaining redundancy in data distribution and to

preserve the data privacy. In these systems, the pri-

vacy is achieved by dividing documents into blocks

and distributing these blocks among several clouds or

providers. In this way, cloud providers only host a

part of user documents, and so, it can not read them.

To reconstruct the whole document, cloud providers

must collude with each other to exchange the parts

of the document. In fact, the use of redundant distri-

bution schemes could be used to cut user documents

into blocks and shufﬂe the block content in order to

make the document hard to reconstruct (Cincilla et al.,

2015). So, even with all data blocks, reading doc-

uments is not an easy task. However, the architec-

ture proposed by RACS and SCMCS involves a third-

party that knows the block organization. So, users

must trust the third-party instead of cloud providers.

Although this third-party does not own the user data,

it could read user documents before storing them in

cloud providers, ask the blocks to cloud providers or

give the block organization to cloud providers. In

some way, the issue of the data privacy is moved to

cloud providers to the third-party on the cloud. In

our approach, the third-party does not exist. Users

connect directly to several cloud providers with their

cloud accounts from the SkyStore application. In this

architecture, users do not share critical data like the

block organization with anyone but they must trust the

application not to release personal data.

In this paper, we explore the possibility of pro-

tecting the user privacy from a storage service us-

ing several cloud storage providers in the same way

as RACS and SCMCS. So, the system breaks user

documents into smaller blocks and stores blocks to

different providers. The privacy is protected by two

main ideas. First, the storage service does not store

all the data in the same cloud provider. In this way,

the ﬁrst step in reading documents is to retrieve every

block. The second step is to assemble the blocks to

reconstruct documents. The storage service shufﬂes

the data before building blocks and cloud providers

do not know the shufﬂe algorithm. So, putting the

blocks together is not a straightforward task. To in-

crease the complexity of these two steps, the storage

service stores blocks of every user with no organiza-

tion on cloud providers. So, at the provider level, a

large amount of blocks belonging to users is stored

with no information. As in peer-to-peer systems, the

more blocks there are, the more complicated is to

reconstruct documents. Unlike RACS and SCMCS,

the information to reconstruct documents, namely the

metadata, is not owned by a third-party that does not

exist in our architecture. Consequently, users are the

only ones who can read the data, i.e., their documents.

3 USER DATA PRIVACY

In our cloud storage service SkyStore, the role of

users is far more important than just selecting doc-

uments to upload on the cloud. Indeed, users are

responsible to break their documents into blocks be-

fore sending them to the cloud storage service. This

operation, called the encoding process, allows users

to choose the algorithm to build blocks and select

providers. So, users install the storage service to

communicate with cloud providers on their device,

e.g., a desktop computer. Then, users choose cloud

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

378

providers from the list of available ones. At least

two providers are required to distribute data blocks

but a higher number of providers increases the pri-

vacy by decreasing the amount of data stored on each

provider. Users also choose the algorithm used to

break their documents. By selecting their algorithm,

users may choose to use cut-and-shufﬂe (Cincilla

et al., 2015) or erasure code algorithms depending on

the characteristics choosen. The cut-and-shufﬂe algo-

rithm ensures the respect of the user privacy by mix-

ing the data and breaking it into blocks. The erasure

code algorithm (Luo et al., 2009) allows the loss of

blocks to prevent cloud provider outage but the size

of documents is increased. For instance, when users

store 100 MB of data on three providers by using the

erasure code algorithm, 150 MB of data are stored on

cloud providers but only two providers are required to

reconstruct the data. So, in case of a single provider

failure, user documents can be downloaded.

During the encoding process, metadata is gener-

ated at the user side as shown in Figure 1. The meta-

data is the information to retrieve all blocks of doc-

uments and assemble these blocks. The metadata of

one document consists of the encoding algorithm, the

number of blocks, the block names and the location

of blocks, i.e., the cloud providers used to store the

blocks of the document. Metadata can not be stored

to user devices because of device failures and theft of

devices. The loss of metadata means the loss of user

documents. So, metadata is stored on cloud providers

with the same encoding process than user documents

and the required information for retrieving it is com-

puted from functions as detailed in Section 3.2.

Figure 1: Metadata generation during the encoding process.

3.1 Data Storage

In our previous work, we proposed a cloud stor-

age service, named TrustyDrive (Pottier and Menaud,

2016), based on a traditional architecture. This archi-

tecture, also used in above-mentioned works (Abu-

Libdeh et al., 2010)(Singh et al., 2011), connects

users and cloud providers by means of a third-party.

Although the main concern of TrustyDrive is the

anonymity, the use of a third-party forces users to trust

another component. This component is responsible

for managing and storing the metadata, and so, it can

exploit or disclose it without user consent that could

reduce the privacy of users. In the proposed architec-

ture, users and cloud providers are directly connected

and users have access to the storage space of cloud

providers.

The ﬁrst advantage to store blocks of one docu-

ment on several providers is that each provider has

only one part of the data. Moreover, the data is mixed

by the encoding algorithm, and so, even one block of

a plain text is illegible. As a result, one provider, or

someone with an access to the provider, who wants

to exploit the data of the user could not do it without

retrieving the blocks hosted in other providers. An

attacker, or a malicious organization, that wants to re-

trieve blocks from every provider, has to hack or pres-

sure several providers. Actually, it is easier to operate

on a single provider instead of several ones because

there are more weakness to ﬁnd and exploit.

In the improbable case of the attacker succeeds

in retrieving every block from providers used by the

storage service, he has to reconstruct documents. As

the attacker has collected lots of blocks, he could try

to limit the number of blocks to decrypt by analyz-

ing only the blocks associated with a speciﬁc user or

a speciﬁc document. However, the cloud providers do

not have any information about the block organiza-

tion, and so, the attacker can not group blocks by user

or by document from the hack of the storage service.

In fact, the attacker may have some information

about blocks coming from every provider like the

creation date and the block size. These information

are available from common cloud providers and they

could compromise the user privacy.

From the creation date, the attacker could group

blocks by date and assume that every block with

nearly equal dates belong to the same document. This

information threatens the privacy because the attacker

can now try to decrypt the document from a small

amount of blocks. In common ﬁle systems, the cre-

ation date of a ﬁle could be customized with basic

commands (e.g., on Linux, the bash command touch

could modify date attributes of a ﬁle

). Unfortunately,

such customizations (e.g., modiﬁcation of the cre-

ation date) are not available from cloud provider API

like the Dropbox API, and so, the application can not

hide this information from attackers.

http://tinyurl.com/nnopzzj

Privacy-aware Data Storage in Cloud Computing

379

Assuming that the encoding algorithm breaks one

document into blocks with a same size, the attacker

can also group blocks by their size in order to easily

detect blocks belonging to the same document. The

privacy is, once again, threatened. To solve this is-

sue, encoding algorithms could make blocks with ran-

dom sizes but it is easier to design algorithms that

create blocks of equal sizes for all documents. As

the design of encoding algorithms is already compli-

cated, this option is rejected. Another option is to use

blocks with a ﬁxed size, either using padding or mak-

ing small blocks. In order to have blocks with equal

sizes, the system ﬁlls blocks with useless data, called

padding, until the required size. The main disadvan-

tage of padding is to increase the size of the data to

upload for one document. An alternative of padding is

to build small blocks with a ﬁxed size to increase the

number of blocks with equal sizes on each provider.

In that case, the number of blocks generated for one

document increases in order to drown blocks associ-

ated to one document in a sea of blocks. This solu-

tion allows to protect the privacy without uploading

more data than necessary but increase dramatically

the number of blocks to upload. We choose the last

option by counting on simultaneous downloads and

uploads of blocks to reduce the loss of performance.

3.2 Metadata Storage

Once users have encoded their documents, the meta-

data of these documents contains the entire informa-

tion required to reconstruct them. So, the protec-

tion of metadata is a determining factor to preserve

the user privacy. Moreover, metadata must be saved

in a safe storage because the loss of metadata pre-

vents users to reconstruct their documents. As a com-

puter and a mobile phone can be stolen, the backup

of metadata must be stored in a remote storage. In

our approach, this remote storage is the sky storage

service itself. To minimize the potential damage of a

theft, metadata is never written to the local drive of

the user device but it remains in the device memory.

So, when users close the application, their metadata

is destroyed.

The permanent storage of metadata is performed

by breaking it into blocks from the encoding algo-

rithm before sending the generated blocks to the cloud

storage service. Two pieces of information are re-

quired to store the metadata blocks: a list of cloud

providers and a list of block names. To store the

metadata, all registered providers are used. Conse-

quently, users must obtain access to every provider

to retrieve their metadata from other devices. So,

users must manually connect to the right providers

before retrieving their metadata, and so, their docu-

ments. This seems to be restrictive but it is necessary

for the security of the application in order to avoid to

give cloud provider credentials, mostly passwords, to

a third-party. However, credentials are stored on user

devices, and so, users have to authenticate just once

on cloud providers. An additional password is asked

at the storage service startup to protect user docu-

ments in case the computer or the phone is stolen.

To compute the list of metadata block names, cryp-

tographic functions calculate the block names from

the password, the name of the provider and the email

of the provider account. For example, the function

SHA-1 could be used for calculating names of blocks

required to save the metadata of the user from its pass-

word as follows: SHA1(password + providerName +

email).

In conclusion, the retrieval of metadata is based

on (i) the correct list of cloud providers, (ii) the cre-

dentials of these cloud accounts, (iii) the block names

deﬁned from passwords, emails and provider names

of cloud provider accounts.

3.3 Architecture Comparison

In the storage service proposed in this paper, users

control their data by choosing the encoding algorithm

and by avoiding that cloud providers can read their

metadata. In TrustyDrive (Pottier and Menaud, 2016),

the anonymity provides a stronger data privacy by

hiding the owner of the data but it is achieved by us-

ing a third-party but users must trust the cloud storage

service for not saving metadata. In the remainder of

this section, we discuss the beneﬁts and the disadvan-

tages of connecting users directly to cloud providers

or by the means of a third-party.

A direct connection between users and cloud

providers means that users create one account on each

cloud provider. For an architecture with three cloud

providers, the creation and the connection do not take

a long time but, for seven or more cloud providers,

this operation can quickly become cumbersome and

tricky. Moreover, inexperience people may ﬁnd difﬁ-

cult to know exactly the features of the cloud provider,

for example, the transfer rates, the location of the

data, etc. This features could be analyzed and pro-

posed by expert third-parties. The last, but not the

least, disadvantage is the number of blocks stored on

cloud providers. In the architecture without any third-

party, cloud providers are used by one single user. So,

the number of blocks could not be sufﬁcient to ensure

the data privacy and credentials to connect to cloud

providers can lead to the user identity.

By using a third-party as a proxy to connect to

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

380

cloud providers, users only connect to one service.

They only have to create one account on the third-

party. Moreover, as one third-party is used by many

users, the number of blocks stored on cloud providers

dramatically increases that improves the data privacy.

Indeed, as the third-party of the TrustyDrive architec-

ture can not link users to documents, retrieving all the

documents of a speciﬁc users is technically unfeasi-

ble unless the third-party is corrupted or malicious.

However, as users do not own the credentials of cloud

providers, they can not have access to the physical

storage space to check the content of the blocks, for

instance, to check that blocks are illegible. In the ar-

chitecture described in this paper, users have full ac-

cess to the storage space, and so, they can check the

data stored on every cloud provider.

4 THE COST OF THE PRIVACY

The storage service presented here proposes to store

documents on the cloud while ensuring the user pri-

vacy. In this section, we analyze the cost associated

with uploading and downloading documents from a

prototype designed as a privacy-aware storage ser-

vice.

One part of the extra cost is related to prevent

the theft of documents. Unlike other cloud stor-

age services like Dropbox, Google Drive, Microsoft

OneDrive, etc., the system does not keep a local copy

of documents. So, the theft of the user device (laptop,

mobile phone) does not involve the theft of documents

but users have to frequently download documents to

read or edit them.

Another additional cost comes from both the gen-

eration and the transfert of blocks. As data encryp-

tion involves a performance overhead, encoding al-

gorithms consume both processor and memory re-

sources. So, the time to build blocks slows down doc-

ument transfers. Moreover, documents are divided

into several blocks that increases the number of up-

load and download requests to handle documents, and

so, times to upload and download documents raise.

Metadata describes the organization of user doc-

uments and every modiﬁcation of this organization,

like uploading new documents, renaming or moving

documents, modiﬁes the metadata. In common cloud

storage services like Dropbox, when a document is

uploaded, the only piece of metadata to upload is the

document name. The organization of the document

data only concerns the cloud storage service. Users

does not know how their data is stored (e.g., is the

document stored on one single ﬁle or on many ﬁles

?). As the proposed storage service manages the user

metadata on the user side, users must upload it. In

addition, the local metadata on the user side is differ-

ent from the metadata stored on the cloud after every

modiﬁcation of user documents. To maintain the syn-

chronization between the local metadata and the re-

mote one, the application uploads it after every mod-

iﬁcation. So, metadata is frequently uploaded which

has a direct negative impact on the performance of the

system.

One parameter that inﬂuences the performance of

the system is the block size because it deﬁnes the

number of blocks necessary to encode one document.

As mentionned in Section 3.1, this feature of the sys-

tem is used to generate a sufﬁcient number of blocks

in order to ensure the privacy. However, an excessive

number of blocks reduces the performance of the sys-

tem. A balance must be struck between the privacy

and the performance of the system.

The next section describes the prototype of a stor-

age service guided by above mentionned principles.

In the Section 4.2, the evaluation of the prototype clar-

iﬁes the impact of the block size on the performance

of the system. A comparison between our prototype

of the storage service and existing cloud storage ser-

vice is given in the Section 4.3.

4.1 Prototype Description

Unlike TrustyDrive (Pottier and Menaud, 2016),

which chooses an architecture with a third-party as

described in the Section 3.3, the proposed cloud stor-

age service connects directly users to cloud providers.

The proposed prototype allows users to store their

documents while respecting the user privacy from an

application that installs on the client device running

a Windows 10 operating system. For a more real-

istic evaluation, this application does not use an in-

frastructure designed for this speciﬁc experiment but

three of the main cloud storage providers available

on the market, i.e., Dropbox, Google Drive and Mi-

crosoft OneDrive. So, users must ﬁrst create at least

two accounts on these cloud providers before using

the application.

The application saves the documents of users on

every registered cloud provider by breaking them into

blocks. The number of blocks created for one doc-

ument represents a multiple of the number of cloud

providers to ensure an equal distribution of the data.

The number of created blocks on each provider to en-

code one document is caculated according to the fol-

lowing formula:

block

= dS

doc

provider

block

where N

block

is the number of blocks per provider,

Privacy-aware Data Storage in Cloud Computing

381

doc

is the size of the document,

provider

is the number of registered providers,

block

is the size of one block

From the number of providers N

provider

, the en-

coding algorithm opens N

provider

buffers and starts to

read the document content one byte at a time. Bytes

are alternately distributed in each buffer as described

in Figure 2. When buffer sizes reaches the block size,

buffers are uploaded and N

provider

new buffers are cre-

ated and ﬁlled. The process continue until the end of

the document content. From this encoding algorithm,

most of the blocks have an equal size and only the last

provider

blocks are smaller than the block size. Obvi-

ously, the block size S

block

has a huge impact on the

number of blocks.

Figure 2: Distribution of one user document into 3 blocks.

The information required to reconstruct docu-

ments, i.e., the metadata, consists of a list of block

names and a list of cloud providers on which blocks

are stored. From these two pieces of information,

the application manages blocks by uploading, down-

loading or deleting them by using the cloud provider

REST API. We assume that users do not share their

cloud accounts and the storage space provided by

cloud providers is only used by one person. Conse-

quently, the number of blocks generated by the user

will not be mixed with blocks of other users, and so,

it must be sufﬁciently high to protect the user privacy.

In the following experiments, three accounts of

cloud providers are registered in the application (one

Dropbox account, one Google Drive account and one

Microsoft OneDrive account). The prototype will be

compared with two cloud storage services: Dropbox

and BoxCryptor. Dropbox is one of the famous cloud

storage services. It allows users to easily save doc-

uments on the cloud. To upload documents, users

move their documents in the Dropbox folder. This

folder is automatically synchronized with the cloud

folder. A local copy remains at the user side to read

and edit the document. BoxCryptor allows users to

save documents on the cloud while protecting their

100

125

150

175

200

225

250

0 100 200 300 400 500 600 700 800 900 1000

Number of blocks (s)

Block Size (kB)

50 B file

5 MB file

12 MB file

(a) Number of blocks to encode documents with

different block sizes

0 100 200 300 400 500 600 700 800 900 1000

Upload time (s)

Block Size (kB)

50 B file

5 MB file

12 MB file

(b) Time to upload documents with different

block sizes

Figure 3: The impact of the block size on document up-

loads.

privacy by using encryption. BoxCryptor connects to

many cloud providers like Dropbox to save encrypted

documents but the entire document is saved on a sin-

gle provider. As BoxCryptor does not save user pass-

words, both cloud providers and BoxCryptor can not

read user documents. So, users must trust BoxCryptor

to not store their passwords. Moreover, the underly-

ing cloud providers has entire documents so it can try

to decrypt them.

As both Dropbox and BoxCryptor keep a local

copy of user documents, users do not have to down-

load their documents before reading or editing them.

In our prototype, this local copy is deleted to mini-

mize the consequences of theft of user devices. So,

user documents are most often downloaded. As doc-

uments are not downloaded with Dropbox and Box-

Cryptor, we choose to compare upload times in the

following experiments. The Section 4.2 shows the im-

portance of the block size on the performance of the

prototype. The Section 4.3 compares the prototype

with Dropbox and BoxCryptor.

4.2 Performance Assessment

The prototype developped in this study is available

from the Windows Store

for mobile phones and

desktop computers running a Windows 10 operating

https://www.microsoft.com/en-

us/store/p/trustydrive/9nblggh52pq6

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

382

system. Every experiment is performed on a desktop

computer with 4 GB of memory and a dual core pro-

cessor (T8100 2.10GHz). Three documents are up-

loaded on the three registered providers:

• a text document with a small size of 50 B. This

document could help users to save important pass-

words which are rarely used ;

• an audio ﬁle with a medium size of 5 MB. This

document could be an interview about a sensitive

topic ;

• a JPEG picture of 16 Mpixels with a size of

12 MB. The user does not want to disclose it.

The proposed storage service protects the user

privacy by breaking user documents into blocks,

and then, distributing these blocks to many cloud

providers. Additionally, there is no third-party be-

tween users and cloud providers and only users know

the metadata to prevent providers reading documents.

In this section, we will examine the performance of

the prototype by uploading the 3 documents described

above with different block sizes. The ﬁrst part of

this evaluation shows the impact of the block size on

transfer times. In a second phase, the system is used

with a ﬁxed block size and the encoding process is

examined very carefully to differentiate computation

times and transfer times.

The number of blocks used to encode one docu-

ment is deﬁned by the block size as described in Sec-

tion 4.1. When the block size grows, the number of

generated blocks per document decreases quickly to-

ward the minimal number of 3 blocks per document,

i.e., one block per provider. As 3 providers are regis-

tered to the application, the encoding process builds at

least 3 blocks that it ﬁlls alternatively with document

data. When blocks reach the maximum block size,

3 additional blocks are created. So, a ﬁle with a size

smaller than 3 times the block size is always encoded

on 3 blocks. The 12 MB ﬁle is encoded on 246 blocks

with 50 kB blocks and 15 blocks with 1 MB blocks

as shown in Figure 3(a). Reducing the number of

blocks allows to decrease the number of upload re-

quests. When the number of upload requests drops,

the time to upload documents is improved as shown

in Figure 3(b). When blocks vary in size from 50 kB

to 500 kB, upload times of both the 5 MB ﬁle and the

12 MB are signiﬁcantly improved because the number

of connections to cloud providers decreases.

The upload of one document consists of ﬁlling

blocks by reading and mixing the document content,

uploading blocks and uploading the metadata. In the

next experiment, we measure the time consumed by

each of these steps to determine which one is the most

consuming task. The ﬁrst step is to read the docu-

Table 1: Calculation times and upload times during the en-

coding process.

5 MB File

Block Calculation Upload

size (B) time (s) time (s)

50 000 2.040 23.552

100 000 1.703 13.180

250 000 1.597 6.074

500 000 1.536 4.305

750 000 1.531 4.445

1 000 000 1.515 4.195

12 MB File

Block Calculation Upload

size (B) time (s) time (s)

50 000 4.854 49.678

100 000 3.809 25.837

250 000 3.463 11.496

500 000 3.328 8.438

750 000 3.344 6.055

1 000 000 3.219 5.758

ment content and ﬁll blocks while mixing their con-

tent. This step is a CPU-intensive task, and so, its

duration is highly dependent on the hardware. The

time to execute this step is called the calculation time.

The second measurement is the upload of every block

belonging to the document. This time is called the

upload time and it does not include the metadata up-

load time. Metadata consists of block names used

by the three documents and providers that store these

blocks. So, the metadata size depends on the num-

ber of blocks determined by the block size. As the set

of documents is small, the size of the metadata varies

from 3 kB to 30 kB depending on the block size but

the time to upload it is almost constant. Actually, this

time varies from 0.8 s to 1.2 s but this change is more

dependent on the network quality than the metadata

size. Calculation times and upload times with differ-

ent block sizes are summarized in the table 1.

For both the 5 MB ﬁle and the 12 MB ﬁle, a re-

duction in upload times is observed while the num-

ber of blocks abruptly decreases due to an increase of

the block size. These new results conﬁrm the previ-

ous ones. For small block sizes, calculation times are

negatively impacted. When the block size is greater

than 100 kB, calculation times are stable. Conse-

quently, reducing the number of blocks improves up-

load times but it may compromise the user privacy,

and so, a tradeoff between the performance and the

security must be found, for example, by using 500 kB

blocks.

Privacy-aware Data Storage in Cloud Computing

383

Table 2: Upload times (s) on different cloud storage ser-

vices.

File Size (MB) 20 50 100

Dropbox 14.0 26.8 65.2

BoxCryptor 18.1 30.3 65.5

Our Prototype 14.9 25.4 59.7

4.3 Storage Service Comparison

Many cloud storage services are available to store

gigabytes of data like Dropbox, Google Drive, Mi-

crosoft OneDrive. These services provide a free and

large storage space for users without ensuring the user

privacy. Few storage services care about privacy with

zero knowledge cloud solutions based on encryption

like SpiderOak or BoxCryptor. To compare the per-

formance of our prototype with other storage services,

we choose two cloud services: Dropbox and Box-

Cryptor. Dropbox is one of the leader in storage ser-

vices and BoxCryptor proposes free accounts with

AES-256 encryption.

For this experiment, three ﬁles are tranferred: one

20 MB ﬁle, one 50 MB ﬁle and one 100 MB ﬁle. The

prototype is conﬁgured to use 500 kB blocks. The

upload times of these ﬁles are shown in the Table 2.

The results show that our prototype initially ap-

pears a little more performant but BoxCryptor and

Dropbox begin by copying user documents on the lo-

cal storage before uploading them. Our prototype do

not use local copies. However, our prototype uploads

documents to multiple cloud providers by means of

concurrent block uploads that could speed up the ﬁle

transfer. According to network disturbances and the

accuracy of the measurement, the difference between

the upload times are not sufﬁcient to determine the

fastest cloud storage service.

5 CONCLUSION

In this paper, we propose a cloud storage service that

protects the privacy of users by breaking user docu-

ments into blocks in order to spread them on several

cloud providers. As cloud providers only own a part

of the blocks and they do not know the block organi-

zation, they can not read user documents. Moreover,

the storage service connects directly users and cloud

providers without using a third-party as is generally

the practice in cloud storage services. Consequently,

users do not give critical information (security keys,

passwords, etc.) to a third-party.

To improve the presented prototype, the ability of

sharing documents between users should be available.

As every cloud service has this feature, our prototype

does not have to copy blocks from cloud providers of

the ﬁrst user to providers of the second user. It just has

to share the metadata of the ﬁle, and then, download

the blocks from sharing links.

REFERENCES

Abu-Libdeh, H., Princehouse, L., and Weatherspoon, H.

(2010). Racs: A case for cloud storage diversity.

In Proceedings of the 1st ACM Symposium on Cloud

Computing, SoCC ’10, pages 229–240, New York,

NY, USA. ACM.

Cincilla, P., Boudguiga, A., Hadji, M., and Kaiser, A.

(2015). Light blind: Why encrypt if you can share?

In SECRYPT 2015 - Proceedings of the 12th Interna-

tional Conference on Security and Cryptography, Col-

mar, Alsace, France, 20-22 July, 2015., pages 361–

368.

Dingledine, R., Freedman, M. J., and Molnar, D. (2000).

The free haven project: Distributed anonymous stor-

age service. In In Proceedings of the Workshop on De-

sign Issues in Anonymity and Unobservability, pages

67–95.

Genkin, D., Shamir, A., and Tromer, E. (2014). RSA

Key Extraction via Low-Bandwidth Acoustic Crypt-

analysis, pages 444–461. Springer Berlin Heidelberg,

Berlin, Heidelberg.

Luo, J., Xu, L., and Plank, J. (2009). An efﬁcient

xor-scheduling algorithm for erasure codes encoding.

In Dependable Systems Networks, 2009. DSN ’09.

IEEE/IFIP International Conference on, pages 504–

513.

Pottier, R. and Menaud, J. M. (2016). Trustydrive: a multi-

cloud storage service that protects your privacy. In

2016 IEEE 9th International Conference on Cloud

Computing.

Rabin, M. O. (1989). Efﬁcient dispersal of information for

security, load balancing, and fault tolerance. J. ACM,

36(2):335–348.

Singh, Y., Kandah, F., and Zhang, W. (2011). A secured

cost-effective multi-cloud storage in cloud comput-

ing. In Computer Communications Workshops (IN-

FOCOM WKSHPS), 2011 IEEE Conference on, pages

619–624.

Waldman, M. and Mazieres, D. (2001). Tangler: A

censorship-resistant publishing system based on doc-

ument entanglements. In Proceedings of the 8th ACM

Conference on Computer and Communications Secu-

rity, CCS ’01, pages 126–135, New York, NY, USA.

ACM.

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

384
