Semantic Mutation Test to OWL Ontologies

Alex Mateus Porn and Leticia Mara Peres

Informatics Department, Federal University of Paraná, Av. Cel. Francisco H. dos Santos, Curitiba, Brazil

Keywords: Ontology, Semantic, Mutation.

Abstract: Ontologies are structures used to represent a specific knowledge domain. There is not a right way of defining

an ontology, because its definition depends on its purpose, domain, abstraction level and a number of ontology

engineer choices. Therefore, a domain can be represented by distinct ontologies in distinct structures and,

consequently, they can have distinct results when classifying and querying information. In light of this, faults

can be accidentally inserted during its development, causing unexpected results. In this context, we propose

semantic mutation operators and apply a semantic mutation test method to OWL ontologies. Our objective is

to reveal semantic fault caused by poor axiom definition automatically generating test data. Our method

showed semantic errors which occurred in OWL ontology constraints. Eight semantic mutation operators

were used and we observe that is necessary to generate new semantic mutation operators to address all OWL

language features.

1 INTRODUCTION

Ontologies are considered one of the semantic web

support. They describe and represent concepts of a

domain and relations between them. They have a

fundamental role to describe data semantics and act

like a backbone in knowledge based systems.

In information systems, an ontology is an

engineering artefact. They introduce a vocabulary to

define concepts, classify terms and relationships, and

define constraints (Gruber, 1995). They are used to

describe and represent a knowledge domain, and

provides an explicit specification of this vocabulary

(Horrocks, 2008). Ontologies can be very complex,

with several thousands of terms or very simple,

describing one or two concepts only.

The World Wide Web Consortium (W3C)

developed the Ontology Web Language (OWL)

standard (McGuinness and Harmelen, 2004). OWL is

a semantic web language designed to represent rich

and complex knowledge about things, groups of

things, and relations between things. It is a

computational logic-based language such that

knowledge expressed in OWL can be exploited by

computer programs, e.g., to verify the consistency of

that knowledge or to make implicit knowledge

explicit (OWL Working Group, 2012).

OWL formalism adopts an object-oriented model

in which the domain is described in terms of

individuals, classes and properties (Horrocks, 2008).

A key feature of OWL is it is based in a very

expressive Description Logics (DL), and in light of

this, an OWL ontology consists of a set of axioms

which are defined to represent a specific knowledge

domain (Horrocks, 2008).

However, a knowledge domain can be represented

by several distinct ontologies, which can result in

distinct structures, axioms and consequently, they can

have distinct results when classifying and querying

information. Therefore, ontology evaluation is an

important ontology engineer process to identify

whether an ontology meet its goals and whether it is

free of faults.

In light of this, we propose apply semantic

mutation test to OWL ontologies and generate

automatically test data, with objective to reveal

semantic faults in OWL ontology constraints defined

for any knowledge domain.

In the following, we describe related works in

section two, a briefly semantic mutation test

overview, semantic mutation operator definition and

semantic mutation test application in section three.

Next, we showing our experiment setup in section

four, and last, our conclusions.

434

Porn, A. and Peres, L.

Semantic Mutation Test to OWL Ontologies.

DOI: 10.5220/0006335204340441

In Proceedings of the 19th International Conference on Enterprise Information Systems (ICEIS 2017) - Volume 2, pages 434-441

ISBN: 978-989-758-248-6

2 RELATED WORKS

In (Grüninger and Fox, 1995) is provided a

mechanism to guide evaluation of design and

adequacy of ontologies. Firstly, informal competency

questions are defined. Then, using a first-order logic

terminology, they are converted in formal

competency questions. These formal competency

questions are used as axioms in ontology evaluation.

With objective to guarantee that an ontology is

well-verified, (Gómez-Pérez, 1996) presents a

framework which evaluates correctness of ontology

definitions. Using design criteria, Gómez-Pérez

analyses architecture, lexicon and syntax, and

content. The focus of this work is ontology

evaluation, which consists on verification, validation

and assessment.

Several authors propose methods to semantic

evaluation. (Poveda Villalón et al., 2012), proposes a

web based tool to improve ontology quality by

automatically detecting potential pitfalls which could

lead to modelling error.

(Batet and Sanchez, 2014) propose a score of the

accuracy evaluation which is dependent of the degree

of semantic dispersion of concepts in a given

ontology. This work is based on (Fernández et al.,

2009), which identified how taxonomic depth and

breadth variance can be used to reasonably predict

ontologies semantic accuracy.

In this same context, (Hlomani and Stacey, 2014)

propose apply a data-driven ontology evaluation,

using among others, clarity metric to measure the

number of word meanings, to evaluate quality and

correctness of the ontology.

According (Porn et al., 2016), ontology testing as

a specific ontology evaluation process is little

explored in the literature. In this sense, (Vrandečić

and Gangemi, 2009) propose apply unit testing in

ontologies like in software engineer.

In (García-Ramos et al., 2009) is proposed a

method to dynamically test ontologies. An automated

tool allows the user to define a set of tests to check

the functional requirements of ontology, to execute

them, and to inspect the results of execution.

In (Blomqvist et al., 2012), is proposed to find

errors verifying ontology inference through error

provocation and competency questions verification.

Some previous works concerning OWL mutation

testing can be saw in (Lee et al., 2008), (Porn and

Peres, 2014) and (Bartolini, 2016). Those three works

are similar to our proposal in this paper.

In (Lee et al., 2008) mutation operators are

applied in the mutation test to OWL-S, a standard

XML-based language for specifying workflows and

semantic integration among Web services (WS). In

this work, they analyse fault patterns of specific

OWL-S and their workflows, proposes an ontology-

based mutation analysis method, and applies

specification-based mutation techniques for WS

simulation and testing.

In (Porn and Peres, 2014) is proposed apply

mutation test exclusively to OWL ontologies, and 19

syntactic mutation operators on classes and relations

structures are defined with goal to find OWL

ontology pitfalls according to faults found in the

literature. However, in this work is not applied

mutation on OWL ontology DL axioms and is not

generate automatically test data. Although these 19

operators are defined to syntactic mutation, 5 of them

can be also used to semantic mutation.

Similar process is used in (Bartolini, 2016). In this

work are presented 22 mutation operators to semantic

mutation test, but 9 of them are similar to proposed in

(Porn and Peres, 2014). Others proposed syntactic

operators are applied in OWL annotations and OWL

structure, not being possible apply them in DL axioms

to evaluate OWL ontology semantic. Results do not

show the mutation score to analyse the test data

quality.

Small change in a semantic definition can

produce, in knowledge-based systems like

ontologies, a semantic meaning which is completely

distinct from the original axiom. In this sense, just

syntactic analysis is not enough to test an ontology.

Therefore, in this paper, we propose semantic

mutation operators and apply semantic mutation test

method to OWL ontologies. These semantic operators

are defined to make syntactic changes in DL

constraints of OWL ontology. They are applied with

aim to reveal semantic fault caused by poor axiom

definition and automatically generate test data.

3 OWL SEMANTIC MUTATION

We define OWL semantic mutation test as an error-

based technique where syntactic changes are

introduced in a set C of DL constraints or DL axioms

of an OWL ontology O. These syntactic changes are

made through predefined mutation operators, and

each change generates a new set C’ called mutant of

Thus, semantic mutation test in OWL ontologies

consists in make changes in OWL ontology

constraints Q of a set C, replacing, removing or

adding logic operators, generating new constraints Q’

of a set C’ and which can give another meaning to

original constraint Q, according to predefined

Semantic Mutation Test to OWL Ontologies

435

mutation operators. In this sense, it is possible

consider as a test case set T, a set of competency

questions proposed in (Grüninger and Fox, 1995).

For this comparison is necessary to execute O and

C, and O and C’ with the same test case set T. After

these executions, the results are compared to analyse

if the results of distinct executions, with the same set

T, are distinct for the execution of C’ in O. A set T is

used to distinguish the results of C’ from C, where

each C’ is executed with the same set T applied to C

in O (Delamaro et al., 2007).

Similar to program mutation test, if after

executing all test cases T, there are still Q’ in C’ of O

that generate the same output of Q in C of the same

O, and it is not possible generate new test cases that

differentiate Q from Q’, the mutant constraint Q’ is

considered similar to Q, it means that, or Q is correct,

or it has errors unlikely to occur (DeMillo, 1978).

In the same way, as in software engineer, test case

set T is suitable to C concerning C’, whether for each

constraint Q belonging to C’, or Q’ is similar to Q or

Q’ is distinct from Q in at least one test data

(Delamaro et al., 2007).

Deciding whether a mutant is equivalent to an

original constraint, is made by the engineer, because

determine whether two programs compute the same

function is an undecidable question (Budd, 1981).

Although mutation operators apply syntactic

changes, they are considered semantic operators

because they allow semantic analysis of results.

With the objective of to analyse adequacy of T

executed in C and C’, the mutation score

is calculated.

This score ranges from 0 to 1 and provides an

objective measure of how much T is considered

appropriate (DeMillo, 1978 and Delamaro et al.,

2007). For an ontology O, a set of constraints C' and

a set of test cases T, the mutation score S is obtained

as follows (DeMillo, 1978):









′

′



−′

(1)

The mutation score is obtained through the total

of dead mutant constraints (C’m) of OWL ontology

O, over the generated mutant constraints (C’g) of

OWL ontology O, minus equivalent mutant

constraints (C’e) of OWL ontology O.

3.1 OWL Semantic Mutation

Operators

In (Porn and Peres, 2014), 19 mutation operators were

defined to introduce syntactic changes in OWL

ontologies. Those operators generate variations like

change hierarchical structure of a class, add or

remove a disjunction definition between classes, add

or remove a class equivalence definition, remove

“AND” and “OR” operators in an equivalence

definition, among others.

Some of those operators can be used to produce

semantic mutation in OWL ontologies, but they are

not sufficient to test all OWL possibilities.

According (Horrocks et al., 2000), a description

logic knowledge base is made up of a terminological

part (Tbox) and an assertional part (Abox), each part

consisting of a set of DL axioms. Tbox asserts facts

about concepts and roles (binary relations), usually in

the form of inclusion axioms, while Abox asserts

facts about individuals (single objects), usually in the

form of instantiation axioms.

OWL comprises Tbox and Abox, and it is based

on a very expressive DL called SHOIN, a sort of

acronym derived from several language features. The

symbol S is an abbreviation to ALC, a DL Alternative

Language whit add-ons. It depicts a basic set of

features, like data types, constraints as intersection,

union and complement, as well as, existential and

universal quantifiers. The symbol H corresponds to

properties hierarchies, symbol O to enumerated

classes and axioms, like disjunction and equivalence,

symbol I stands inverse properties and symbol N

cardinality restrictions.

How description logic is composed by several

formal knowledge representation languages, and

OWL ontologies implementation is based on DLs,

each semantic mutation operator should consider

Tbox or Abox axioms defined in DL ALCON, in other

words, axioms defined in Attributive Language (AL),

which allow atomic negation, concept intersection,

universal restrictions and limited existential

quantification. They should support complex concept

negation (C), enumerated classes of objects value

restrictions (O) or cardinality restrictions (N).

Therefore, to apply this semantic mutation test

method to OWL ontologies, we select 5 mutation

operators (CEUA, CEUO, ACOTA, ACATO and

ACSTA) proposed in earlier works (Porn and Peres,

2014), and we defined 3 new operators to generate

semantic mutants and generate automatically test

data. These 8 operators accomplish at least one of the

DL ALCON feature.

In this context, we propose the following semantic

mutation operators applied over DL constraints

defined in OWL classes, OWL object properties and

OWL data properties. The semantic mutation

operators are presented as follow:

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

436

• CEUA removes each AND operator in a given

OWL DL constraint, generating two mutants,

one with the left side of the AND operator and

another with the right side.

• CEUO removes each OR operator in a given

OWL DL constraint, generating two mutants,

one with the left side of the OR operator and

another with the right side.

• ACOTA replaces each OR operator in a given

OWL DL constraint by one AND operator,

generating one mutant for each OR operator

replaced.

• ACATO replaces each AND operator in a given

OWL DL constraint by one OR operator,

generating one mutant for each AND operator

replaced.

• ACSTA replaces each ∃ (Existential) operator

in a given OWL DL constraint by one ∀

(Universal) operator, generating one mutant for

each Existential operator replaced.

• ACATS replaces each ∀ (Universal) operator

in a given OWL DL constraint by one ∃

(Existential) operator, generating one mutant

for each Universal operator replaced.

• AEDN adds one negation operator for each

AND, OR, ∃ or ∀ operator in a given OWL DL

constraint, generating one mutant to each

operator.

• AEUN removes one negation operator in a

given OWL DL constraint, generating one

mutant for each not operator removed.

Some considerations about these operators are

which they are applied only in logical axioms,

because we considered in this analysis to apply

semantic mutation test on OWL constraints defined

according to at least on DL ALCON feature.

These types of axioms do not include annotations

or labels, they include axioms like disjunction

between class, cardinalities constraints, domain and

range definitions of classes, object properties and data

type properties, as well as, axioms which are not

addressed by the proposed mutation operators, like an

equivalence axiom defined by only one class, similar

to say which disease class is equivalent to the

pathology class, or remove a disjunction definition

between these two classes.

Table 1 shows an example of the semantic

mutation test applied in the people OWL ontology

(Bechhofer et al., 2003), where an equivalence axiom

defined on the class “haulage truck driver” is mutated

with ACATO semantic mutation operator, generating

three new mutant OWL ontology constraint. Each one

of these constraints is also used as a test data.

Table 1: Example of semantic mutation operator ACATO

applied in an original OWL ontology constraint.

Class Constraint Mutant constraint

haulage

truck

driver

Person

and

(drives

some

truck)

and

(works

for some

(part of

some

'haulage

company')

)

person or

(drives some truck)

and

(works_for some

(part_of some

'haulage company'))

person and

(drives some truck)

(works_for some

(part_of some

'haulage company'))

person or

(drives some truck)

(works_for some

(part_of some

'haulage company'))

3.2 Semantic Mutation Application

We propose to execute semantic mutation test in

OWL ontologies in a similar process as (Porn and

Peres, 2014):

1. Mutation operator selection: the first step is

select or define appropriate semantic mutation

operators which address at least one DL ALCON

feature, and realize semantic mutations on DL

constraints of OWL ontologies.

2. Mutants DL constraints generation: each

selected semantic mutation operator is applied

on original DL constraints Q in C of original

OWL ontology O based on its specification.

They generate an arbitrary number of mutant

constraints Q’ with the same error type applied

in distinct constraints.

3. Test data generation: each original DL

constraint Q and each new mutant DL

constraint Q’ in C’ are selected as new test data,

generating a set of test case T to be executed in

the original ontology DL constraints C and each

C’.

4. Original ontology constraint execution: after

define T, C must be executed with T. Each test

data in T is interpreted by a reasoner, which

analyse test data according to C defined in the

ontology, giving back a result based on super

classes, subclasses and individual instantiation.

5. Mutants ontology constraint execution: each

test data T executed in C should be executed in

each mutant constraint Q’, and result of C’

Semantic Mutation Test to OWL Ontologies

437

should be compared with result of original

ontology O.

6. Result analysis: whether a mutant Q’ presents

a distinct result of Q after a test data T

execution, Q’ is considered killed. Otherwise,

whether Q’ presents the same result of Q and is

not possible generate new test data to be used,

Q’ can be considered equivalent to Q, or a fault

was revealed in C. This analysis is determined

by the engineer. The mutation score can be

calculated after execute all mutants, to set

suitability degree of used test data.

The main differences between these steps in

relation to process proposed by (Porn and Peres,

2014), are the test data set automatically generated

and the application of mutation operators in

constraints, which satisfy at least one DL ALCON

feature. In light of generate automatically test data,

each mutated constraint is considered a new test data

to be executed over DL mutant constraint generated

of the OWL ontology.

About the application of mutation operators just

in semantic context, it is an excellent alternative to

produce mutants containing significant faults, and

reduce the large number of inconsistent mutants and

with obvious faults, like circulatory faults or partition

faults (Gómez-Pérez, 2004) or unlikely to occur.

4 EVALUATION

4.1 Objectives

Executing semantic mutation test in OWL ontologies,

and analyse in detail the application adequacy of

proposed mutation operators, as well as, validate

them and analyse the test data quality automatically

generated.

4.2 Hypothesis

Mutation test is the most effective to reveal faults, but

also the most expensive (Wong et al., 1995).

According to this, for our evaluation we infer two

hypotheses, identified as H1 and H2:

H1: Semantic mutation operators to OWL

ontologies reduce application cost of mutation test

and allows to reveal faults which are not identified

with syntactic operators.

H2: After applying each semantic mutation

operator in OWL ontology constraints, these mutated

OWL constraints are effective test data to find faults

in original OWL ontology.

4.3 Activities and Instruments

In order to execute and validate the steps of semantic

mutation test presented in section 3.2, we used 8

semantic mutation operators presented in section 3.1.

Steps 2 and 3 were made using Protégé tool

(Musen, 2015). Each semantic mutation operator was

applied over all DL constraints, each operator at a

time, generating mutants according to the number of

existing operators. According to (Delamaro et al.,

2007), it is possible generate mutants applying more

than one mutation operator at once. However, this

situation has a high cost of mutant generation and

implementation, and it does not contribute to generate

better test cases (Budd, T. A. et al., 1980).

For steps 4 and 5, each generated test data during

step 3 is firstly executed on the original OWL

ontology constraint C and next on each mutant OWL

ontology constraint C’, using in these steps the

Protégé DL query.

For step 6, the last one, the results of C and each

C’ are compared. This analysis is to verify results

which are composed by instantiation of super classes,

subclasses and individuals. If results of C and C’ are

distinct with the same test data, C’ is considered

killed and a fault revealed. However, if results are

similar, C’ can be considered equivalent to C, and in

other words, or C is correct, or C has errors unlikely

to occur.

Table 2 presents results example from an original

OWL ontology constraint after executing a test data.

Table 2: Example of results from an original OWL ontology

constraint.

Class

Original

Constraint

Test data T Results

driver

person

and

(drives

some

vehicle)

person

and

(drives

some

vehicle)

Superclasses

- adult

- animal

- grownup

- person

Subclasses

- bus driver

- haulage truck

driver

- lorry driver

- mad cow

- van driver

- white van man

Instances

- Mick

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

438

After execute a test data it was obtained 4 super

classes, 6 subclasses and 1 individual according to

Table 2. On the other hand, according to Table 3,

when executing the same test data in the OWL

ontology mutant constraint, it was obtained 5 super

classes, 7 subclasses and 1 individual. In this

example, the test data revealed the inserted fault and

the mutant was considered killed and discarded.

Table 3: Example of results from a mutant OWL ontology

constraint.

Class Mutant C’ Test data T Results

driver

person

(drives

some

vehicle)

person and

(drives

some

vehicle)

Superclasses

- adult

- animal

- driver

- grownup

- person

Subclasses

- bus driver

- haulage

truck driver

- lorry driver

- mad cow

- van driver

- white van

man

- kid

Instances

- Mick

Defining if C’ is equivalent to C is an undecidable

question. Decide whether the test keep going while C’

presents the same result from C is an engineer

decision. The mutation score is used to evaluate

generated test data and as a metric to decide whether

it is necessary generates new test data or close the test.

4.4 Data Set

We selected as data set of our evaluation the OWL

ontology called people, from (Bechhofer et al., 2003).

This is a simple ontology which describes people,

links between them, pets and things they do. This

ontology has DL expressivity ALCHOIN. It contains

372 axioms and 108 logical axioms. We consider to

this setup only logical axioms, because they do not

include annotations, which do not represent logical

concepts.

Next, we presenting a summary of features of

people OWL ontology: 372 axioms, 108 logical

axioms, 60 classes, 14 object properties, 22

individuals, 33 subclasses; and 21 equivalent classes.

We consider only axioms which can be mutated

and generated at the same time as a new test data, with

at least one DL ALCON feature. Due to this, in people

ontology we consider 68 logical DL ALCON axioms

which can be mutated with these 8 semantic mutation

operators.

4.5 Results

After execute semantic mutation test in people OWL

ontology, we obtained 434 mutants for 8 semantic

mutation operators and the mutation score 0,94. Table

4 presents the results, showing the total of generated,

killed, inconsistent and live mutants.

Table 4: Semantic mutation test results.

Mutation

operator

Generated

Mutants

Killed

Mutants

Inconsistent

Mutants

Live

Mutants

CEUA

77 73 0 4

CEUO

7 10 1

ACOTA

7 5 0

ACATO

43 2 0

ACSTA

57 0 9

ACATS

13 0 0

AEDN

200

152 38 10

AEUN

3 0 0

Total

434

355 55 24

Mutation score 0,94

Live mutants can be a fault or equivalent mutant.

In this analysis, we considered live mutants as

equivalent to original DL constraints.

Inconsistent mutant is a mutant that can not be

executed by a reasoner, because it has in its definition

inconsistent axioms. This fault type is immediately

revealed in which reasoner is executed. In this case,

no test data needs to be executed. However, this

mutant type is considered a mutant killed, but it does

not allow to evaluate the set of test case.

Therefore, to calculation of mutation score, we

considered the total of mutants minus the total of

inconsistent mutants as the total of generated mutants.

Table 5 shows the number of the test data used to

kill each mutant DL constraint of people OWL

ontology.

Table 5: Number of test data used to kill mutants.

Mutant

operator

Total of

mutants

Original

test data

Mutated

test data

Other test

data

CEUA

25 46 1

CEUO 18 --- --- 7

ACOTA 12 1 --- 6

ACATO 45 18 25 ---

ACSTA 66 34 5 18

ACATS 13 13 --- ---

AEDN 200 62 25 65

AEUN 3 3 --- ---

Semantic Mutation Test to OWL Ontologies

439

About Table 5, we considered on the “Original

test data” column the same constraints used by

mutation operator to generate mutant DL constraints.

The column “Mutated test data” refers to the number

of mutated constraints by the same mutation operator

which generated mutant DL constraints. The column

“Other test data” refers to the number of test data

generated by a given mutation operator and used to

kill a mutant DL constraint generated by other

mutation operator.

4.6 Discussion

With these results was possible observe that, to kill

some mutant DL constraints of people OWL

ontology, generated by five mutation operators

(CEUA, CEUO, ACOTA, ACSTA and AEDN) was

necessary carry out test data generated by another

mutation operators. This occurred because the

original test data and mutated test data produced the

same semantic result, but in contrast with another

distinct constraint, the fault was revealed.

In other cases, like ACATS and AEUN mutation

operators, original test data were sufficient to kill and

reveal all inserted faults.

Some mutant DL constraints could not be killed

in this experiment. We did not define them as

equivalents or fault, because we consider that is

necessary define new semantic mutation operators

which approach other OWL language features. Thus,

with new test data it will be possible that more

mutants will be killed.

This result presents operators effectiveness,

showing a large amount of errors which can be

inserted in OWL ontologies by developer, due to the

large number of generated mutants.

According (DeMillo, 1978), mutation score is

better the closer to 1. Our test case set proved to be

efficient to revealed fault, because the mutation score

is 0,94. This score was found during the first

execution of mutation test.

In a general context, according to hypothesis H1,

this method of semantic mutation test produced a

large number of mutants, but a smaller amount than

the syntactic mutation test, decreasing the cost of its

application and improving the quality of mutants,

because few equivalent mutants have been generated,

which provides a more accurate evaluation of the test

data used in accordance with hypothesis H2.

5 CONCLUSIONS

OWL ontologies are knowledge representation model

of a specific domain. However, a domain can be

defined by several ways, because its definition

depends on features as desired abstraction level,

purpose and a number of developer choices, among

others.

In this sense, there is not a right way to develop

OWL ontologies. Methods to evaluate them are

useful to guide developers and testers to develop

ontologies which are correct or close to reality.

The semantic mutation test proposed in this paper

showed be an alternative to OWL ontology testing.

The generated mutants revealed faults with efficiency

based on mutation score of 0,94.

According to this, the results of this method

present a large amount of errors which can occur in

OWL ontologies, based on a large number of

generated mutants. In this context, the generated test

cases proved are very efficient to revealed these

errors, in accordance with few mutants remained

alive, as mentioned in Table 4 and Table 5.

Our semantic mutation operators have shown that

they do not cover all OWL language implementation

possibilities. So, it is necessary generate new

semantic mutation operators addressing other OWL

language features, like add, remove or replace

disjunction between class, cardinality restrictions,

object properties and data type properties domain and

range, as well as, semantic mutation operators to

individuals, property characteristics, among others.

Therefore, it is still necessary to develop an

automated tool to facilitate OWL semantic mutation

test application, because Protégé tool aids to generate

mutants and execute test data, but it does not provide

a mechanism to execute this process automatically.

ACKNOWLEDGEMENTS

We thank the support provided by the Federal

University of Paraná Graduate Program in Computer

Science (PPGInf / UFPR), CAPES and Federal

Institute of Paraná.

This work was conducted using Protégé resource,

which is supported by grant GM10331601 from the

National Institute of General Medical Sciences of the

United States National Institutes of Health.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

440

REFERENCES

Gruber, T. R., 1995. Toward principles for the design of

ontologies used for knowledge sharing. In Int. j. hum-

comput. st., Vol. 43, No. 5-6, pp. 907-928.

Grüninger, M., Fox, M. S., 1995. Methodology for the

Design and Evaluation of Ontologies. In Workshop on

Basic Ontological Issues in Knowledge Sharing in Int.

Joint Conf. on Artificial Intelligence. Toronto, Canada.

Gómez-Pérez, A., 1996. Towards a framework to verify

knowledge sharing technology, Expert Systems with

Applications, Vol 11, No. 4, pp. 519-529.

Poveda-Villalón, M., Suárez-Figueroa, M. C., Gómez-

Pérez, A., 2012. Validating ontologies with OOPS!, In

18th Int. Conf. in Knowledge Eng. and Knowledge

Management. Galway City, Ireland, pp. 267-281.

Batet, M., Sanchez, D., 2014. A Semantic Approach for

Ontology Evaluation. In 26th Int. Conf. on Tools with

Artificial Intelligence. Limassol, Cyprus, pp. 138-145.

Fernández, M., Overbeeke, C., Sabou, M., Motta, E., 2009.

What Makes a Good Ontology? A Case-Study in Fine-

Grained Knowledge Reuse. In 4th Asian Conference on

The Semantic Web, pp. 61-75.

Porzel, R., Malaka, R., 2004. A task-based approach for

ontology evaluation. In Proc. of the Workshop on

Ontology Learning and Population at the 16th

European Conf. on Artificial Intel. Valencia, Spain.

Brewster, C., Alani, H., Dasmahapatra, S., Wilks, Y., 2004.

Data driven ontology evaluation, In Int. Conf. on

Language Resources and Evaluation. Lisbon, Portugal.

Porn, A. M., Huve, C. G., Peres, L. M. Direne, A. I., 2016.

A Systematic Literature Review of OWL Ontology

Evaluation. In 15

International Conference on

WWW/Internet. Mannheim, Germany, pp. 67-74.

Vrandečić, D., Gangemi, A., 2006. Unit tests for ontologies.

In On the Move to Meaningful Internet Systems.

Montpellier, France, pp. 1012-1020.

García-Ramos, S, Otero, A., Fernández-López, M., 2009.

OntologyTest: A Tool to Evaluate Ontologies through

Tests Defined by the User. In 10

Int. Work-Conf. on

Art. Neural Networks. Salamanca, Spain, pp. 91-98.

Blomqvist, E., Sepour, A. S., Presutti, V., 2012. Ontology

testing-methodology and tool, In 18

International

Conference in Knowledge Engineering and Knowledge

Management. Galway City, Ireland, pp. 216-226.

Lee S, Bai X, Chen Y., 2008. Automatic Mutation Testing

and Simulation on OWL-S Specified Web Services. In

Simulation Symposium, Annual, pp. 149-156.

Bartolini, C., 2016. Mutation OWLs: semantic mutation

testing for ontologies. In Proc. of the International

Workshop on domain specific Model-based approaches

to verification and validation. Rome, Italy, pp. 43-53.

Porn, A. M., Peres, L. M., 2014. Mutation Test to OWL

Ontologies. In 13

International Conference on

WWW/Internet. Porto, Portugal, pp. 123-130.

Delamaro, M. E., Maldonado, J. C., Jino, M., 2007.

Introdução ao Teste de Software, in Portuguese,

volume 394 of Campus. Elsevier, 2007.

DeMillo, R. A., Lipton, R. J., Sayward, F. G., 1978. Hints

on Test Data Selection: Help for the Practicing

Programmer. Computer. pp. 34-41.

Budd. T. A., 1981. Mutation Analysis: Ideas, Example,

Problems and Prospects. In Proceedings of the Summer

School on Computer Program Testing held at

SOGESTA, Urbino, Italy, pp. 129-148.

Horrocks, I., Sattler, U., Tobies, S., 2000. Reasoning with

Individuals for the Description Logic SHIQ. In

Proceedings of the 17

International Conference on

Automated Deduction. Pittsburgh, USA, pp. 482-496.

Musen, M. A., 2015. The Protégé project: A look back and

a look forward. AI Matters. Association of Computing

Machinery Specific Interest Group in Art. Intelligence.

Bechhofer, S., Horrocks, I., Patel-Schneider, P., 2003.

Tutorial on OWL. In 2

International Semantic Web

Conference. Sanibel Island, Florida, USA. Available in:

<http://owl.man.ac.uk/2006/07/sssw/people.owl>.

Accessed: November 10

, 2016.

Horrocks, I., 2008. Ontologies and the semantic web. In

Magazine Communications of the ACM – Surviving the

data deluge. Vol. 51, Issue 12, pp. 58-67.

McGuinness, D. L., Harmelen, F. van, 2004. OWL Web

Ontology Language Overview. Available in:

<http://www.w3.org/TR/owl-features/>. Accessed:

November 11

, 2016.

OWL Working Group, 2012. Web Ontology Language

(OWL). Available in:

<https://www.w3.org/2001/sw/wiki/OWL>. Accessed:

November 11

, 2016.

Budd, T. A., DeMillo, R. A., Lipton, R. J., Sayward, F. G.,

1980. Theoretical and Empirical Studies on Using

Programa Mutation to Test the Functional Correctness

of Programs. In Proc. of the 7

ACM Symposium of

Principles of Programming Languages. pp. 220-233,

New York, NY, USA.

Gómez-Pérez, A., 2004. Ontology Evaluation. Handbook

on Ontologies, Springer, pp. 251-273.

Burton-Jones, A., Storey, V. C., Sugumaran, V., Ahluwalia,

P., 2005. A semiotic metrics suite for assessing the

quality of ontologies, Data & Knowledge Engineering,

Vol. 55, No. 1, pp. 84-102.

Hlomani, H., Stacey, D., 2014. An extension to the data-

driven ontology evaluation. In 15th Int. Conf. on Info.

Reuse and Integration. Redwood, USA, pp. 845-849.

Wong, W. E., Mathur, A. P., Maldonado, J. C., 1995.

Mutation Versus All-uses: An Empirical Evaluation of

Cost, Strength and Effectiveness. In Software Quality

and Productivity: Theory, Practice and Training.

London, UK, pp. 258-265.

Semantic Mutation Test to OWL Ontologies

441
