Managing Personalized Cross-cloud Storage Systems with Meta-code

Magnus Stenhaug, Håvard D. Johansen and Dag Johansen

UIT The Arctic University of Norway, Norway

Keywords:

Privacy, Cloud Computing, Federated Cloud, Autonomic Data Management, Hybrid Cloud, Multi-cloud,

Data Policies, Security, Edge Computing.

Abstract:

Providing ﬁne-level and customized storage solutions for novice cloud users is challenging. At best, a limited

set of customization options are provided, often related to volume of data to be stored. We are proposing

a radical different customization approach for cloud users, one where personalization of services provided

is transparently managed and supported. Our approach to building personalized cloud storage services is to

allow the user to specify data management policies that execute in a user space container transparently to

the user. In this paper we describe Balva, a cloud management system that allows users to conﬁgure ﬂexible

management policies on their data. To support legacy applications, Balva is implemented at the ﬁle system

level, intercepting system calls to effectuate dynamic and personalized management policies attached to ﬁles.

1 INTRODUCTION

The convergence and application of IoT sensors, wi-

reless, mobile, and cloud computing enables new and

disruptive ways to quantify information on indivi-

duals and our environment. Small, wearable, non-

invasive, and sensing edge devices are becoming hou-

sehold items, with small manufacturing cost and a

vast array of different uses. When coupled with ad-

vanced machine learning techniques and an abun-

dance of cheap computational infrastructures in the

cloud, the data streams generated by these edge de-

vices have the potential to generate technological in-

novation at a scale never witnessed before (Schwab

2016).

However building storage systems that reliably

and over time can capture, store, and curate data

from a heterogeneous and dynamic pool of cloud-

connected edge devices is not trivial. Examples in-

clude solipsistic lifelogging (Gurrin, Smeaton, and

Doherty 2014), athlete quantiﬁcation systems (Johan-

sen et al. 2013), or medical research databases (Sten-

haug, Johansen, and Johansen 2016). Requirements

for management policies, security policies, and access

interfaces are likely to change over time and cannot be

all predicted at system design time. Systems currently

available for such applications provide little opportu-

nity to customize or individualize governing manage-

ment and security policies, or data interfaces.

This paper describes Balva, a cross-cloud data ser-

vice that federates input from edge devices into a lo-

gical cross-cloud abstraction. Data hosted by Balva

is governed by expressive management and security

policies, set by the end users themselves. The set of

policies can be adapted over time, in concert with the

changing needs and requirements of individual users

and their applications. The ﬂexibility in Balva stems

from small code snippets attached to individual data

objects. Each such code snippet provides security and

management functionality that can extend or change

various meta properties of the data objects it is atta-

ched to, including how the data is replicated or how it

can be transformed. We therefore refer to such code

snippets as meta-code (Johansen and Hurley 2011; Jo-

hansen et al. 2015). Balva interpositions meta-code

execution in the data access path of hybrid multi-

cloud ﬁle systems (Dobre, Viotti, and Vukoli

c 2014;

Ardagna 2015). Execution is transparent to the ap-

plications and does not require alteration of existing

data APIs. This enables Balva to adapt policies for le-

gacy applications, an important requirement for long

term data storage and curation. The Balva multi-cloud

architecture automates resource management across

multiple clouds, which may include autonomic so-

lutions for ﬁne-grained security and privacy policy

enforcement, data lock-in avoidance, fault-tolerance,

scalability, and performance optimization. We design

Balva to capture these rapid changes while still being

able to preserve and curate this data for the long term.

694

Stenhaug, M., Johansen, H. and Johansen, D.

Managing Personalized Cross-cloud Storage Systems with Meta-code.

DOI: 10.5220/0006377607220728

In Proceedings of the 7th International Conference on Cloud Computing and Services Science (CLOSER 2017), pages 694-700

ISBN: 978-989-758-243-1

Application

Balva Kernel

Module

Local

Storage

Cloud

Storage

Device

Cloud

Storage

Data

Vendor

…

Data

Vendor

Data

Vendor

Application

Balva Kernel

Module

Local

Storage

Device

Figure 1: Multi-cloud deployment with Balva.

2 THE BALVA ARCHITECTURE

Recent trends in cloud computing include federating

and orchestrating cloud services spanning multiple

cloud services and providers. By not committing to

a single cloud provider, but rather a collection of ser-

vice providers, application developers can potentially

avoid data lock-in and stay available if the cloud ser-

vice becomes unavailable. The trade-off is (often) an

increase in cost. This cost can be used to the beneﬁt

of the programmer as the service spanning multiple

providers can greedily choose the cheapest solution.

SpanStore (Wu et al. 2013) builds a storage service

spanning multiple cloud providers and optimizes for

low latency at a modest increase in cost. Similarly,

Supercloud (Jia et al. 2016) uses the Virtual Machine

spot market to choose the cheapest available compu-

ting resource at any time, migrating virtual machines

when cheaper resources become available.

Another beneﬁt of federating cloud services is that

companies can utilize in-house computing resources

while expanding into the cloud when in-house capa-

city is reached. While dynamically moving the exe-

cution and storage of an in-house resource is compel-

ling, it increases the complexity of managing and de-

veloping such services. Typically, a federation layer

implementing an IaaS cloud platform is added to the

software stack to alleviate some of the programming

effort. This comes at the cost of having to rely on a

set of middleware services and APIs deﬁned by the

provider of the federation software, with the potential

risk of relying on a software provider that may stop

supporting the software.

2.1 Object Model

Balva operates on objects consisting of a data layer

and a meta layer. We have designed Balva to impose

few restriction on what objects it can handle, their

granularity, and how they are stored and processed.

An object may be stored as a ﬁle, database record,

or any sequence of bytes that can be interpreted by

applications accessing that object. Balva does, howe-

ver, require that each object o has a unique identiﬁer

o.id, for example when stored as a ﬁle: an UUID or a

host and path name combination. The identiﬁer does

not have to be static, and may change over time. We

also require that all Balva storage backends support a

meta-layer that can store textual or binary key-value

metadata with each object. The object storage bac-

kend must always keep meta-data together with the

data, even if the object is renamed or transformed by

applications. Each object can potentially exist in in-

ﬁnitely many discrete states between its creation and

its deletion.

In Balva, the meta-layer of each data object o in-

cludes a lists a of named and well-deﬁned meta-code

modules o.metacode = [m

, m

, . . . , m

] that applica-

tions and Balva can invoke. Invocation of a meta-code

module may include parameters and may return some

value to the caller. Meta-code modules are execu-

ted by the Balva runtime in the isolated context of

the object they are attached to, and may manipulate

contained data and metadata. As such, the meta-code

functions in o.metacode constitute o’s public and pri-

vate interfaces. Balva supports objects with different

and dynamic o.metacode members, adapted to how

each object will be used. Each meta-code module

m ∈ o.metacode is set by some principal m.u, iden-

tiﬁed by the hash of u’s public key. Whenever the

meta-code m is executed, it will run with the privile-

ges of its governing principal m.u and isolated within

the execution context of o.

We take a minimalist approach to federating cloud

storage resources. Balva requires only a few meta-

code modules on objects for its own operations, de-

pending on what particular backend objects are sto-

red in or its indented usage. For instance, in our ﬁle

system implementation of the Balva architecture, as

will be described below, the meta-code array includes

modules for read, write, and delete operations. In ad-

dition, Balva provides meta-code modules for mani-

pulating an object’s meta layer, including adding and

removing elements of the o.metacode array. We adapt

a programming model where users and their appli-

cations can extend, replace, or remove elements of

o.metacode over time, avoiding the need to deﬁne

in advance a static set of data-access operations for

all cloud backend systems that are to be supported.

The ability to extend objects with operations imple-

menting various management policies enables users

to build a powerful and personalized storage system

tailored for their individual needs.

Managing Personalized Cross-cloud Storage Systems with Meta-code

695

2.2 Access Tokens

Balva is designed to be deployed across multiple

cloud computers or even hybrid and multi-clouds

spanning different vendors, as illustrated in Figure 1.

Balva therefore may run in multiple administrative

domains: from trusted cloud vendors to individual

user devices and community owned IoT devices. A

program executing locally on a client device must still

be able to transparently access protected data through

the local ﬁle system or a shared library. With traditi-

onal Access-Control Lists (ACLs), users would need

to maintain accounts with each individual federated

service, and have little opportunity to delegate their

rights beyond sharing their passwords. Bearer tokens

are seemingly better suited for federated cloud opera-

tions, as individual services do not need to keep lo-

cal state on access rights. In particular, Balva grants

access to invoke meta-code operations based on a me-

chanism similar to the Codecaps as described by Re-

nesse et al. (2013).

Balva access tokens are signed sequences meta-

code predicates, or heritages, h

= [p

, p

, . . . , p

] that

are evaluated in the context of an object o whene-

ver m ∈ o.metacode is invoked. Given a heritage h,

a meta-code operation m ∈ o.metacode, Balva only

admits an invocation if

∀p ∈ h | eval(p, m, o) = true

Thus, having some heritage h

, a principal can create

a derived heritage h

n+1

by appending new predicates:

n+1

= h

n+1

Doing so attenuates the rights granted by h

with ad-

ditional restrictions imposed by p

n+1

. Because herita-

ges are cryptographically sealed so that h

cannot be

retrieved from h

n+1

, principals can safely share subset

of their rights with others. Each heritage have a root

predicate p

that only returns true for some objects.

By convention, a principal holding a heritage h such

that eval(h[0], m, o) = true is said to be the owner of

o, and is typically granted full access.

3 IMPLEMENTATION DETAILS

Balva is a cloud storage service designed to allow

conﬁguration of advanced management and security

meta-code policies on stored objects. Balva targets

supporting the wide-range of existing data-driven ap-

plication stacks available today, and hence meta-code

based policy conﬁguration and enforcement must be

transparent to existing legacy applications accessing

write()

C library

write()

policy

SysFs

Balva

Predicate

write() system call

Call

policy

KERNEL

USER-SPACE

true

false

Policy

return

Figure 2: Control ﬂow of write operations.

data. Balva is therefore placed at the Operating Sy-

stem (OS) and ﬁle system level within existing Linux-

based software stacks. As such, ﬁles and blocks are

our unit of storage and data access; open, read, and

write are our main operations. We assume the under-

lying ﬁle system has the traditional semantic of uni-

quely identiﬁable and hierarchical organized ﬁle na-

mes and the ability to attach metadata to ﬁles, a com-

mon function in most Linux ﬁles systems (e.g., ext-4,

the journaling ﬁle system for Linux).

Balva meta-code policies are executed based on

up-calls from the kernel into a user space daemon,

in response to ﬁle system calls. As such, the core

components of our runtime is a Linux kernel module

and a collection of processes that implements ﬁle sy-

stem policies. This enables Balva to take advantage

of hooks inserted into the ﬁle system, and execute

code in the critical path of regular ﬁle system opera-

tions such as open, read, and write. The Balva kernel

module communicates with a user process, which in

turn invokes the appropriate callback function. We

have implemented hooks for several system calls as

required to interposition meta-code in the ﬁle system

access path. These includes the sys_open, sys_read,

and sys_write calls.

The Balva kernel module makes scheduling and

conﬁguration decisions on how to execute the meta-

code policies associated with the data according to a

conﬁguration set by the user. In addition to the ker-

nel module, Balva manages a set of processes running

inside containers in user space (Felter et al. 2015; Sol-

tesz et al. 2007). The runtime launches a kernel mo-

dule that listens for speciﬁc system calls, contacting

the user space processes if there is a policy set to exe-

cute given the system call parameters and the current

conﬁguration. From this, we can construct and com-

bine modular mechanisms and policies to implement

a personalised data store that can capture speciﬁc user

needs.

When Balva initializes, the kernel module loca-

tes the system call table and replaces speciﬁc system

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

696

read()

C library

read()

policy

SysFs

Balva

Predicate

read() system call

Policy

return

KERNEL

USER-SPACE

true

false

Call policy

Figure 3: Control ﬂow of read operations.

calls with Balva prototype functions. These prototype

functions perform additional logic in addition to nor-

mal system call execution. To execute the read system

call, the runtime will identify any meta-code attached

to the ﬁle access operation, and invoke the associ-

ated code before executing the original system call.

Access token predicates are handed to Balva through

the metadata layer of the ﬁles, which ensures API

compatibility. To protect the Linux kernel, we have

decoupled the predicate and meta-code execution by

handling the former within the kernel and the latter

in user space. Since predicate functions are designed

to be simple regular expression evaluations, the pen-

alty of executing a predicate function for every ﬁle is

minimal.

Figure 2 depicts how writes are executed within

the kernel space and the user space. Balva intercepts

the initial write and passes the intermediate buffer to

our meta-code interface or the system call depending

on the output of the predicate evaluation. If the pre-

dicate returns true, the kernel thread handling the sy-

stem call will block while waiting for the user level

meta-code callbacks to be completed. The user level

meta-code will read the intermediate buffer and pass

it back to the kernel with any potential changes. Once

the user-level execution has completed, the Balva ker-

nel module will invoke the original system call with

the modiﬁed buffer. Once the routing completes, the

kernel module will return to the original calling ap-

plication. Similarly, Figure 3 shows the control ﬂow

of a read operation. The difference between handling

read and write operations is that we call the original

system call prior to the user space policy for reads,

while write operations call the policy prior to the sy-

stem call.

Figure 4 shows how an open system call is execu-

ted. The user space policy is called if the predicate

function returns true, and if the return value of the

policy is to deny access the kernel module will im-

mediately return an appropriate error value to the cal-

ling program. If the meta-code policy returns success-

open()

C library

open()

policy

SysFs

Balva

Predicate

open() system call

Call

policy

KERNEL

USER-SPACE

true

false

Policy

return

Deny7access

Allow7access

Figure 4: Control ﬂow of open operations.

fully, the kernel module will call the ﬁle system im-

plementation of sys_open, and return the ﬁle handle

returned by the system call. The sys_open call crea-

tes a new ﬁle descriptor handle for the calling process.

Access control is implemented by associating speciﬁc

ﬁles with access control mechanisms. If a mechanism

denies access to a ﬁle, the mechanism can simply re-

turn the appropriate error message without invoking

the original system call.

3.1 Policy Examples

Adding policies to be executed on data accesses is

done by incrementally adding meta-code modules in

Balva.

Data Transformation We implement data transfor-

mation policies by adding a transformation step to re-

ads and writes. For a write operation, we relay the

data d from the system call to the callback function

implementing the transform. The callback function

will then transform the input data and the runtime will

return the transformed data d

to the kernel module

which then completes the system call. The data d

viewed by the ﬁle system and mirrored to the local

hard drive. Conversely, we can retrieve the original

data by calling the read callback for a reverse trans-

form policy with the transformed data d

Using this technique, we can implement an en-

cryption policy. The callback routine for write can

encrypt the data d and write the encrypted data d

disk. An application reading the data will invoke the

callback routine for the read operation, and transform

the encrypted data d

into the decrypted data d viewed

by the application. With an encryption policy, we can

retroﬁt encryption to existing systems without having

to modify the application or ﬁle system.

Implementing ﬁltering functionality in Balva can

be done during both reads and writes. Filtering data

during a write operation persists the data in the ﬁltered

state. Filtering can also be implemented by transfor-

Managing Personalized Cross-cloud Storage Systems with Meta-code

697

ming the output data according to the policy for each

read, with the unﬁltered data residing on disk. Balva

supports writing ﬁltering and declassiﬁcation policies

that can adapt according to speciﬁc parameters, such

as user and device privileges.

Access Control We can implement ﬁne-grained

access control policies by encrypting the data during

writes and relying on a decryption key that is fet-

ched remotely and stored temporarily. This enables us

to write policies that reason with high-level concepts

such as user roles within a corporation in relation with

the contents of the ﬁles. To revoke access to the data,

the key owner can revoke the access to the remote en-

cryption key. By leveraging trusted computing plat-

forms such as Intel SGX (McKeen et al. 2013), these

policies can be enforced by executing within a secure

environment.

Data Management Replication policies can be

constructed by monitoring ﬁles for changes, and per-

form replication to an ofﬂine location according to the

consistency and durability needs of the policy. We

have implemented mechanisms for replicating data

to the major cloud vendors: Amazon S3, Windows

Azure Storage and Google Storage. With these me-

chanisms, we can construct replication speciﬁc po-

licies where data is replicated to one or more cloud

storage services in different geographical regions. For

example, a user may be restricted to storing offsite

backups within EU or US for certain types of ﬁles.

We can also construct auditing policies to track the

provenance and changes in ﬁles by logging ﬁle acces-

ses to a remote location.

4 EVALUATION

We perform a series of benchmarks to identify ad-

ditional latency incurred when interpositioning meta-

code policies in the access path of data. When a ﬁle is

associated with a speciﬁc policy, the runtime will exe-

cute user space code during a system call execution in

the kernel, and the resulting additional context switch

can be an expensive procedure. This context switch

overhead is measured with a series of benchmarks to

evaluate the validity of the meta-code execution mo-

del.

We deployed Balva on a Linux server equipped

with an Intel Xeon E5-1620 processor running at

3.70 GHz, 64 GB of memory and a 500 GB Samsung

840 EVO SSD. We are running Ubuntu server 16.04,

and we use a standard deployment of Linux Server.

100

200

300

400

500

600

0 B 20kB 40kB 60kB 80kB 100kB

microseconds

size

Baseline

Balva

FUSE

Figure 5: Read latency.

100

200

300

400

500

600

700

800

0 B 20kB 40kB 60kB 80kB 100kB

microseconds

size

Baseline

Balva

FUSE

Figure 6: Write latency.

When the Balva kernel module is loaded into the run-

ning Linux kernel, all subsequent invocation of sy-

stem calls will trigger evaluation of policy predicates.

The overhead of such predicate evaluations are neg-

ligible as they do not trigger any context switch out

from the kernel space.

4.1 System Call Latency

We calculate the system call latency by measuring the

entry and exit difference in a user space program in-

voking the open, read and write system calls, avera-

ging the measurements over a million individual calls

to the kernel. We open three different ﬁles that will

behave differently. The ﬁrst will not invoke any meta-

code policies. This provides us with a baseline me-

asurement to compare the different implementations.

The second will invoke a Balva meta-code policy that

mirrors the input, and represents a minimal no-op po-

licy. Additionally, we compare our kernel module to

an implementation using FUSE to capture ﬁle system

calls.

Figure 5 shows the average latency of a read sy-

stem call. We observe that Balva incurs an additio-

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

698

100

120

140

160

180

Baseline Balva Fuse

microseconds

Figure 7: Open latency.

nal cost for our setup. With a buffer size of 1 byte,

Balva has a 13.7 times higher read latency compared

to the baseline. For 100 kB buffer sizes, Balva is 7.4

times slower. The write system call latency can be

seen in Figure 6. Compared to the FUSE implemen-

tation, Balva performed better for all sizes. Compared

with the baseline system call, Balva incurs an additi-

onal latency cost of approximately two to three times

the baseline latency. The results for the open system

call can be seen in Figure 7, and show comparable

results to the read and write latency.

Our experiments reveal that even with the incur-

red overhead of additional policy execution, Balva is

able to perform comparably to the base Linux ﬁle sy-

stem. Invoking a user deﬁned policy is not a costly

operation, but the overall additional cost of executing

these depends on the individual meta-code functiona-

lity. Note that we do not make any speciﬁc assump-

tions on the underlying ﬁle system mechanisms such

as caching and prefetching. We do not specify that

the ﬁle system should bypass the cache for our expe-

riments.

4.2 Replication Policy Latency

In this experiment, we measure the write latency of a

policy where each write is replicated to Amazon S3.

Speciﬁcally, the meta-code policy writes a copy of all

data updates to an Amazon S3 instance before allo-

wing the application to continue. The S3 instance is

located in Ireland (eu-west-1), and we measured an

average ping latency of 74.0 milliseconds between the

local machine and the Amazon S3 front ends. Since

S3 does not allow incremental updates, we need to re-

write the entire ﬁle each time. To avoid reading and

writing to a large ﬁle for each operation, we partition

the ﬁle with a ﬁxed block size of 4096 bytes. With a

partitioned ﬁle, we can perform incremental updates

by only updating the respective blocks. We average

Table 1: Average latency of write system calls when repli-

cating to Amazon S3.

Policy latency

None (Baseline) 6.8 µs

No-op policy 14.7 µs

Replicate to S3 (Ireland) 188.0 ms

the time it takes to complete a million random write

operations of 1 byte to a 1 GB ﬁle, and compare the

results with writing to the local hard drive. The results

can be seen in Table 1.

We observe as expected that the latency cost of the

additional remote cloud write is quite high compared

to only writing to the local disk. However, the incur-

red cost comes with the added beneﬁt of having the

data replicated to a remote location with a strong con-

sistency model. The meta-code policy is implemented

with approximately 300 lines of C. A more reﬁned

solution would be to relax consistency requirements,

and cache data locally before writing to the cloud

asynchronously. This solution would mask some of

the write latency at the cost of additional code com-

plexity and a weaker consistency model.

5 RELATED WORK

FUSE (Singh 2006) allows users to implement cus-

tom ﬁle systems without having to reason with the OS

kernel. However, a FUSE implementation of Balva li-

mits us to operate on ﬁles within a subdirectory (Hur-

ley and Johansen 2014). Additionally, we would need

to implement the ﬁle system itself or simply mirror

the local ﬁle system. By interpositioning policies be-

tween the application and the I/O system calls, we do

not have to reason with implementing a ﬁle system or

the details of the underlying ﬁle system.

Data capsules (Song et al. 2012) resemble our

model of adding functionality to data items. Howe-

ver their data protection as a service paradigm does

not appear to extend beyond the reach of a single

cloud; Balva is built for hybrid and multi-cloud en-

vironments where security policies are implemented

throughout. Associating code with individual data

items also has similarities to the active documents

work (Dourish et al. 2000) and Monitoring-Oriented

Programming (Chen and Ro¸su 2007). Our scope is a

bit broader than verifying code execution, but some

of the techniques employed are similar.

Guardat (Vahldiek-Oberwagner et al. 2015) ta-

kes a similar approach to enforcing policies at ﬁle

accesses. Their approach is to allow users to spe-

cify data access policies using the Guardat policy lan-

guage. Balva allows users to write policies in fami-

Managing Personalized Cross-cloud Storage Systems with Meta-code

699

liar programming languages, only relying on a mini-

mal library that communicates with the kernel mo-

dule. Executing the policies in user space isolates the

OS kernel from faulty policies while supporting a rich

set of policies.

6 CONCLUSION

This paper describes Balva: a cloud storage service

that transparently interpositions meta-code between

applications and ﬁle system calls. By implementing

security and management policies as meta-code at-

tached to objects, Balva enables users to extend the

storage system at runtime to enforce customized po-

licies for encryption, replication, auditing, and access

control. The experimental evaluations of the Balva

kernel module show that our ﬂexible security and ma-

nagement policies can be supported with little over-

head on the I/O performance.

ACKNOWLEDGMENTS

This work was supported in part by the Norwegian

Research Council project numbers 231687/F20. We

would like to thank the anonymous reviewers for their

useful insights and comments.

REFERENCES

Ardagna, Danilo (2015). “Cloud and Multi-cloud Com-

puting: Current Challenges and Future Applications”.

In: Proceedings of the Seventh International Works-

hop on Principles of Engineering Service-Oriented

and Cloud Systems. PESOS ’15. Florence, Italy: IEEE

Press, pp. 1–2.

Chen, Feng and Grigore Ro¸su (2007). “Mop: an efﬁcient

and generic runtime veriﬁcation framework”. In: ACM

SIGPLAN Notices. Vol. 42. 10. ACM, pp. 569–588.

Dobre, Dan, Paolo Viotti, and Marko Vukoli

c (2014). “Hy-

bris: Robust Hybrid Cloud Storage”. In: Proceedings of

the ACM Symposium on Cloud Computing. SOCC ’14.

Seattle, WA, USA: ACM, 12:1–12:14.

Dourish, Paul et al. (2000). “A programming model for

active documents”. In: Proceedings of the 13th an-

nual ACM symposium on User interface software and

technology. ACM, pp. 41–50.

Felter, Wes et al. (2015). “An updated performance com-

parison of virtual machines and Linux containers”.

In: Performance Analysis of Systems and Software

(ISPASS), 2015 IEEE International Symposium on,

pp. 171–172.

Gurrin, Cathal, Alan F. Smeaton, and Aiden R. Doherty

(2014). “LifeLogging: Personal Big Data”. In: Founda-

tions and Trends in Information Retrieval 8.1, pp. 1–

125.

Hurley, J. and D. Johansen (2014). “Self-Managing Data in

the Clouds”. In: 2014 IEEE International Conference

on Cloud Engineering, pp. 417–423.

Jia, Qin et al. (2016). “Smart spot instances for the su-

percloud”. In: Proceedings of the 3rd Workshop on

CrossCloud Infrastructures & Platforms. ACM, p. 5.

Johansen, Dag and Joseph Hurley (2011). “Overlay cloud

networking through meta-code”. In: Computer Soft-

ware and Applications Conference Workshops (COMP-

SACW), 2011 IEEE 35th Annual. IEEE, pp. 273–278.

Johansen, Håvard D. et al. (2013). “Combining Video

and Player Telemetry for Evidence-Based Decisions in

Soccer”. In: Proc. of the Int. Congr. on Sports Science

Research and Technology Support.

Johansen, Håvard D et al. (2015). “Enforcing privacy poli-

cies with meta-code”. In: Proceedings of the 6th Asia-

Paciﬁc Workshop on Systems. ACM, p. 16.

McKeen, Frank et al. (2013). “Innovative instructions and

software model for isolated execution.” In: HASP@

ISCA, p. 10.

Renesse, Robbert van et al. (2013). “Secure Abstraction

with Code Capabilities”. In: Proc. of the 21st Euromi-

cro Int. Conf. on Parallel, Distributed, and Network-

Based Processing.

Schwab, Klaus (2016). “The fourth industrial revolution”.

In: World Economic Forum Geneva.

Singh, Sumit (2006). Develop your own ﬁ-

lesystem with FUSE. Developer Works.

https://www.ibm.com/developerworks/library/l-fuse/.

IBM.

Soltesz, Stephen et al. (2007). “Container-based Operating

System Virtualization: A Scalable, High-performance

Alternative to Hypervisors”. In: Proc. of the 2nd ACM

SIGOPS/EuroSys European Conference on Computer

Systems. EuroSys ’07, pp. 275–287.

Song, Dawn et al. (2012). “Cloud data protection for the

masses”. In: Computer 45.1, pp. 39–45.

Stenhaug, Magnus, Håvard Johansen, and Dag Johansen

(2016). “Transforming Healthcare through Life-long

Personal Digital Footprints”. In: Proc. IEEE Con-

ference on Connected Health: Applications, Systems

and Engineering Technologies: The 1st International

Workshop on Cloud Connected Health. CHASE ’16.

IEEE.

Vahldiek-Oberwagner, Anjo et al. (2015). “Guardat: Enfor-

cing data policies at the storage layer”. In: Proceedings

of the Tenth European Conference on Computer Sys-

tems. ACM, p. 13.

Wu, Zhe et al. (2013). “Spanstore: Cost-effective geo-

replicated storage spanning multiple cloud services”.

In: Proceedings of the Twenty-Fourth ACM Symposium

on Operating Systems Principles. ACM, pp. 292–308.

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

700
