Adding Privacy Protection to Distributed Software Systems

George O. M. Yee

Computer Research Lab, Aptusinnova Inc., Ottawa, Canada

Department of Systems and Computer Engineering, Carleton University, Ottawa, Canada

Keywords: Distributed, Software, Development, System, Privacy, Risks, Mitigation.

Abstract: Distributed software systems are increasingly found in many aspects of our lives, as can be seen in social

media, international online banking, and international commerce (e.g. Internet shopping). This widespread

involvement of software in our lives has led to the need to protect privacy, as the use of the software often

requires us to input our personal or private information. A first step to protecting privacy is to identify the

risks to privacy found in the software system. Once the risks are known, measures can be put in place to

mitigate the risks. This is best done at the early stages of software development due to the heavy costs of

making changes after the software is deployed. This paper proposes a two-pronged approach, consisting of

privacy risk identification followed by risk mitigation, for adding privacy protection to distributed software.

The paper illustrates the approach with examples.

1 INTRODUCTION

Many distributed software systems targeting

consumers have appeared in recent years,

accompanying the rapid growth of the Internet. Such

systems are available for banking, shopping, travel

reservations, learning, healthcare, and even

government online (e.g. the European Union). Most

of these systems require a consumer’s personal

information in one form or another, leading to

concerns over privacy.

Various approaches have been used to protect

personal information, including data anonymization

(Iyengar, 2002) and pseudonym technology (Song et

al., 2006). Other approaches for privacy protection

include treating privacy protection as an access

problem and then bringing the tools of access

control to bear for privacy control (Adams and

Barbieri, 2006). However, these approaches presume

to know where and what protection is needed. They

presume that some sort of analysis has been done

that answers the question of “where” and “what”

with respect to privacy risks. Without such answers,

the effectiveness of the protection comes into

question. For example, protection against house

break-ins is ineffective if the owner only secures the

front door without securing other vulnerable spots

such as windows (where and what). In the same

way, privacy risk identification considering “where”

and “what” is essential to effective privacy

protection. The author’s earlier work (Yee, 2016)

proposed a visualization method for identifying

privacy risks, based on this notion of “where” and

“what”. This paper extends that work by adding risk

prioritization and mitigation.

This paper is organized as follows. Section 2

defines privacy, privacy preferences, and privacy

risks. Section 3 presents a summary of privacy risk

identification from (Yee, 2016). Section 4 describes

the application of measures to mitigate the privacy

risks. Section 5 presents an application example.

Section 6 discusses related work. Finally, Section 7

presents conclusions.

2 PRIVACY

As defined by (Goldberg et al., 1997), privacy refers

to the ability of individuals to control the collection,

retention, and distribution of information about

themselves. We add “purpose” to this definition. To

see that “purpose” is needed, consider, for example,

that one may agree to give out one’s email address

for the purpose of friends to send email but not for

the purpose of spammers to send spam. This

definition also suggests that “personal information”,

“private information” or “private data” is any

information that can be linked to a person;

Yee, G.

Adding Privacy Protection to Distributed Software Systems.

DOI: 10.5220/0006434903510358

In Proceedings of the 14th International Joint Conference on e-Business and Telecommunications (ICETE 2017) - Volume 4: SECRYPT, pages 351-358

ISBN: 978-989-758-259-2

351

otherwise, the information would not be “about” the

person. Thus, another term for private information is

“personally identifiable information (PII)”. These

terms are used interchangeably in this paper. In

addition, controlling the “collection” of information

implies controlling who collects what information.

Controlling the “retention” of information is really

about controlling the retention time of information,

i.e. how long the information can be retained before

being destroyed. Controlling the “distribution” of

information is controlling to which other parties the

information can be disclosed-to.

A user’s privacy preference expresses the user’s

desired control over a) PII - what the item of

personal information is, b) collector - who can

collect it, c) purpose - the purpose for collecting it,

d) retention time - the amount of time the

information is kept, and e) disclosed-to - which other

parties the information can be disclosed-to. A

privacy risk is the potential occurrence of any action

or circumstance that will result in a violation of any

of the components PII, collector, purpose, retention

time, and disclosed-to in a user’s privacy preference.

3 PRIVACY RISK

IDENTIFICATION

As mentioned above, the method for privacy risk

identification was previously presented as (Yee,

2016) and we summarize it here. The method may

be applied to distributed software systems having

the following common characteristics:

a) The software system requires the user’s personal

information in order to carry out its function.

b) The software system is distributed, i.e. modules

of the system operate in different locations.

c) The software system may transmit the

information (e.g., move it from one place to

another within the system), store the information

(e.g., store the information in a data base), and

use the information to carry out its function.

The method is based on the notion that the location

of personal information gives rise to privacy risks

and consists of the following steps: i) determining

all the possible locations in the software system

where the user’s personal information could reside,

and ii) evaluating at each of these locations the

possible ways in which the user’s privacy

preferences could be violated.

Step i) is accomplished by modeling the software

system in terms of a Personal Information Map

(PIM), using the notational elements in Table 1.

Table 1: Elements of a PIM.

Element Description

Use Circle Identifies where PII is used.

Labeled with a letter together with

a description of the use in a legend.

Data Store

Identifies where PII is stored.

Labeled with a letter together with

a description of the data store in a

legend.

Same

Physical

Platform

Identifies use circles and data

stores that execute on the same

computing platform.

PII Data Flo w

Identifies the movement of PII

from one location to another.

Labeled with a number together

with a description of the data in a

legend.

Non-PII Data Flow

Identifies the movement of SD

from one location to another.

Labeled with a number together

with a description of the data in a

legend.

Legend

Descriptions corresponding to the

letters or numbers with which the

above elements were labeled.

Physically separate units, as delineated by

dashed rectangles, allow the identification of risks

for any data flow between them. Circles or squares

not enclosed by a dashed rectangle are understood to

be already physically separate units. Figure 1 shows

the PIM for the software system of an online seller

of merchandise (e.g. Amazon.com) that has modules

developed and running in both the United States and

Canada. The system requires the user’s name,

address, merchandise selection, and credit card

number. These are considered as three personal

information items where name and address together

are considered as one item. Figure 1 also shows

three non-personal information flows (4, 5, 6). The

dashed rectangle enclosing A, B, and C indicates

that A, B, and C all run on the same physical

computing platform.

Step ii) is accomplished by inspecting the PIM

resulting from step i). For each location (flow arrow,

storage square, and use circle) and each personal

information item, enumerate the possible ways in

which a privacy preference component may be

violated. This may be achieved by asking risk

questions for each component (see Table 2), and

drawing conclusions based on security and systems

knowledge, as well as experience. Record the results

in a Privacy Risks Table containing two columns:

the left column for records of the form “(PII

, PII

…/ locations)” and the right column containing the

corresponding privacy risks. Table 3 illustrates this

step for the online seller of Figure 1.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

352

Figure 1: PIM for an online seller of merchandise.

Table 2: Risk questions.

Component Risk Questions

PII

How can the user be asked for other PII,

either intentionally or inadvertently?

collector

How can the PII be received by an unintended

collector either in addition to or in place of

the intended collector?

purpose How can the PII be used for other purposes?

retention

time

How can the PII retention time be violated?

disclose-to

How can the PII be disclosed either

intentionally or inadvertently to an unintended

recipient?

Table 3: Partial privacy risks table corresponding to Fig. 1.

(PIIs / locations) Privacy Risks

(1, 2, 3 / path into

A); (2 / path into D);

(3 / path into E); (7 /

path into D)

Man-in-the-middle attack violates

collector, purpose, and disclose-to

(1, 2, 3 / path into

User could be asked for personal

information that violates PII

(1, 2, 3 / A); (1 / C);

(2, 7 / D); (3 / E)

Trojan horse or hacker attack on A, C,

D, and E violates collector, purpose,

and disclose-to

(1, 2, 3 / B)

SQL attack on B violates collector,

purpose, and disclose-to

(1, 2, 3 / B)

Information in B could be kept past

the retention time

4 PRIVACY RISKS MITIGATION

Privacy risks mitigation involves the application of

security safeguards (e.g. encryption) to mitigate the

risks. Due to the shortage of company resources, e.g.

time and money, not all risks will be mitigated. In

this case, it is necessary to choose a subset of risks

for mitigation.

4.1 Selecting Privacy Risks for

Mitigation

Intuitively, one would want to mitigate risks that are

highly probable to be realized, and that once

realized, would result in very costly damages. In

other words, due to budget constraints, we feel that

we can ignore the risks that tend not to be realized

and even if realized would cause very little damage.

Determining which risks to mitigate may be assisted

though weighting the risks according to criteria.

(Salter et al., 1998) proposed a method for

applying weights to various forms of attacks in order

to determine if a particular attack would be probable.

They focused on three aspects of an attack, namely

“risk”, “access”, and “cost”, where “risk” is risk to

the safety of the attacker, “access” is the ease with

which the attacker can access the system under

attack, and “cost” is the monetary cost to the

attacker to mount the attack. To avoid confusion

between “risk” to the safety of the attacker and

“risk” to privacy, we use “safety” for “risk” to the

safety of the attacker. The weight values are simply

“L”, “M”, and “H” for Low, Medium, and High,

respectively. These attack aspects can be represented

using a 3-tuple, as [safety, access, cost] and so [H,

M, L] would be an instance of the weights. For

example, consider a physical attack such as a

mugging incident in a park. In this case, the risk to

the safety of the attacker would be high (the person

being mugged could be an undercover police

officer), the attacker’s ease of access would be high

(people stroll through the park all the time), and the

attacker’s cost would be low (not much needed to

mount the attack). Thus, this attack has the weights

[H, H, L].

In this work, we add a fourth aspect of an attack,

namely the resulting damages from the attack. Thus,

we use the 4-tuple [safety, access, cost, damages]

with the same weight values L, M, and H. Hence we

would definitely want to defend against privacy risks

leading to attacks with weights [L, H, L, H]. We feel

that we can ignore privacy risks having attacks with

weights [H, L, H, L]. In reality, there is a spectrum

of weights between these two boundaries, where a

decision to defend or ignore may not be clear, and

ultimately a judgment, perhaps based on other

factors, may be needed. For example, it is not clear

whether or not a privacy risk with associated

weights [L, L, H, H] should be ignored, and one

would decide to defend if one believes that no matter

Adding Privacy Protection to Distributed Software Systems

353

how improbable the attack, the resulting damages

must never be allowed to occur.

The uncertainty of deciding which risks to

mitigate using the weights may be remedied through

the use of a Mitigation Policy. This policy would

identify the 4-tuples of weights whose associated

risks are to be mitigated. For example, the policy

might state that risks with associated 4-tuples [L, *,

*, H] and [L, *, *, M] are to be mitigated, where “*”

indicates possibilities L, M, and H. This policy may

stipulate the mitigation of more risks or fewer risks,

depending on the perceived level of attacker activity

over a past period of time (e.g., 6 months). The

perceived level of attacker activity could be based

on news of attacks from a security newsletter source

such as SANS Newsletters

(https://www.sans.org/newsletters/). As an example,

suppose it is perceived that the level of attacker

activity over the previous 6 months is high. Then the

above policy might be changed from “mitigate risks

with associated 4-tuples [L, *, *, H] and [L, *, *,

M]” to “mitigate risks with associated 4-tuples [L,

*, *, *] and [L, *, *, *], thus permitting an increase

in the number of risks mitigated, as a reflection of

the high level of attacker activity. Of course, it is

assumed here that management could be persuaded

to increase the financial budget for mitigation.

4.2 Method for Privacy Risk Mitigation

1. Apply weights to the privacy risks using the

procedure described in Section 4.1 above.

Develop a Mitigation Policy that can be used as a

basis for selecting the 4-tuples of weights whose

associated risks are to be mitigated. Select the

risks for mitigation based on this policy.

2. Apply security measures (e.g. encryption) to

mitigate the privacy risks.

Applying this method for mitigation to the example

of Section 3 gives Table 4, containing the weights

(Step 1) and mitigations (Step 2) corresponding to

the risks identified in Table 3.

The weights in Table 4 were assigned as follows.

For the man-in-the-middle attack, the risks to the

attacker’s safety is low since he or she is attacking at

a distance; the access is high since it’s the Internet;

the cost is low as not much equipment is needed; the

damages would be high since the attacker could post

the private information leading to heavy damages to

the company’s reputation. Similar considerations

apply to the weight assigned to the Trojan horse or

hacker attack. For the SQL attack on B, accessibility

was assigned as low and cost as high because

improvements to the database user interface were

Table 4: Weights and mitigations for risks in Table 3.

(PIIs /

locations)

Privacy

Risks

Weights

(Step 1)

Mitigations

(Step 2)

(1, 2, 3 /

path into A);

(2 / path

into D); (3 /

path into E);

(7 / path

into D)

Man-in-the-

middle attack

violates

collector,

purpose, and

disclose-to

[L, H, L, H]

Use SSL for

(1, 2, 3 / path

into A); use

encryption

with

electronic

signatures for

the rest.

(1, 2, 3 /

path into A)

User could be

asked for

personal

information

that violates

PII

[L, H, L,

Not

considered

for

mitigation

(1, 2, 3 / A);

(1 / C); (2, 7

/ D); (3 / E)

Trojan horse

or hacker

attack on A,

C, D, and E

violates

collector,

purpose, and

disclose-to

[L, H, L, H]

Use a

combination

firewall and

intrusion

protection

system in

front of A.

(1, 2, 3 / B)

SQL attack

on B violates

collector,

purpose, and

disclose-to

[L, L, H, H]

Not

considered

for

mitigation

(1, 2, 3 / B)

Information

in B could be

kept past the

retention time

[L, H, L,

Not

considered

for

mitigation

recently carried out to guard against SQL attacks.

The risk of the user being asked for information

violating PII and the risk of information kept past

the retention time were considered as potential

accidents caused by the company itself. Therefore,

the risk to safety, the accessibility, and the costs

were deemed to be low, high, and low respectively.

The resulting damages were considered to be

medium because the accidents would likely be

quickly discovered through auditing and remedied.

The privacy risks in Table 4 that are labeled as “not

considered for mitigation” were so labeled as a

result of a Mitigation Policy that states “only

mitigate risks with weights [*, *, L, H]”.

5 APPLICATION EXAMPLE

Consider an airline reservation system called

AccuReserve offered by a Canadian airline with

headquarters in Toronto, Canada. AccuReserve

(fictitious) is composed of the globally developed

and distributed modules shown in Table 5, along

with their private information requirements.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

354

The country-specific modules (modules other

than Main) were developed and runs in their

respective countries to fulfill a requirement by the

respective governments to have databases of their

citizens’ personal information reside within their

respective countries. Given this requirement, it was

decided to develop the user interface within each

country, to take advantage of local expertise in

customizing the interface to client behavior, in order

to improve user friendliness and efficiency.

Table 5: AccuReserve modules and private data required.

Module Function

Private Information

Required

Main –

developed

and runs

in Canada

Maintains

central database

of aircraft

routes and seat

availability;

also acts as the

client interface

and client

database for

Canada

Identification details (name,

address, phone, citizenship,

passport number), flight

details requested

(originating city, destination

city, date of departure, one-

way ticket or return ticket,

date of return (if return

ticket)), payment details

(name, credit card number,

credit card expiry date)

Mod-US –

developed

and runs

in the US

Client interface

and database

for the US

Same as for Main

Mod-EU –

developed

and runs

in the EU

(Germany)

Client interface

and database

for the EU

Same as for Main

5.1 Identification of Privacy Risks

Draw the PIM for AccuReserve. The resulting

PIM is shown in Figure 2, and was achieved by

drawing the PIM for each module (Main, Mod-US,

and Mod-EU) and then linking the modules together

with communication links. Main is made up of the

master database of available flights together with the

user interface for Canada. The user interfaces all

have the same PIM structure, which is not surprising

since they all serve the same purpose. However, the

components that are responsible for communicating

with the user (represented by A, L, and I in the PIM)

are specialized within each country to maximize user

friendliness and efficiency. These components are

not necessarily distinguishable at the PIM level.

Recall that the PIM is not a software design or

architecture diagram and does not necessarily show

all the software components in the system. An

interesting aspect of this PIM is that it reflects the

fact that the software design is already privacy

friendly in the sense that private information does

not flow outside the country of origin. Thus, “flight

details requested” and “flight details assigned” (data

items 2 and 5) are non-private, being associated with

the user by way of an identification hash (considered

part of each data item), except for 2 when it is

associated with the identification details of 1 (on the

path leading into and out of A, I, and L).

Legend:

A, I, L: receive and store data

B, H, M: communicate w. Main

C, K, O: charge credit card

D, E, J, N: databases

F: flight availability manager

G: communicate with countries

1: identification details

2: flight details requested

3: payment details

4: flight availability updates

5: flight details assigned

6: travel itinerary

Figure 2: PIM for AccuReserve; Main consists of E, F, G,

A, B, D, and C; Mod-US consists of L, M, N, and O;

Mod-EU consists of H, I, J, and K.

Enumerate Privacy Risks at Private Information

Locations. Table 6 gives a partial Privacy Risk

Table for locations in Figure 2 that have interesting

or serious privacy risks. The theft of personal

information means that the information is under the

control of an unintended party. Clearly, this can

violate the corresponding privacy preference or

preferences in terms of violating collector, purpose,

retention time, and disclose-to. The risk of personal

1, 2, 3

1, 2,

1, 2, 3

1, 2,

1, 2, 3

1, 2,

Adding Privacy Protection to Distributed Software Systems

355

information theft arises so often that it is convenient

to call it CPRD-risk, from the first letters of

collector, purpose, retention time, and disclose-to.

The risks in Table 6 were obtained as follows. For

the first and second rows, it was noticed that the

personal information flows through transmission

paths connecting physically distinct units. The risk

questions of Table 2 were then considered, leading

to possible man-in-the-middle attacks that give rise

to CPRD-risk. Notice that “(1, 2, 3 / path between A

and D)” is excluded because A and D both run on

the same platform (so the path is not very accessible

to attack). For the third row, violations of PII are

always possible unless strict controls are in place

against it. For the fourth row, it was observed that

private data are input to information use processes

A, I, L, C, K, O. The risk questions of Table 2 were

again considered, leading to possible Trojan horse or

hacker attacks that again give rise to CPRD-risk. For

the fifth row, it was noticed that private data are

stored in databases. Once again the risk questions

were considered, leading to possible SQL attacks

against the databases, giving rise to CPRD-risk. For

the second to last row, it was noticed that private

information stored in databases could be subject to

insider attacks. Finally, for the last row, it was

observed that the private data stored in the databases

could be kept past their retention times. In each of

these rows, knowledge of the system (private data

locations) and knowledge of information security

(possible attacks) were needed to identify the risks.

It should be noted that the links between G and B, G

and M, and G and H are also vulnerable to man-in-

the-middle attacks, but these attacks would not be

privacy attacks, since these links are not used for

private information. Non-privacy attacks are outside

the scope of this paper.

Table 6: Privacy risks table corresponding to Fig. 2.

(PIIs / locations) Privacy Risks

(1, 2, 3 / path into A);

(1, 2, 3 / path into I);

(1, 2, 3 / path into L)

Man-in-the-middle attacks lead to

CPRD-risk.

(1, 2, 3 / path between I

and J); (1, 2, 3 / path

between L and N); (1, 3 /

path between N and O)

Man-in-the-middle attacks lead to

CPRD-risk.

(1, 2, 3 / path into A); (1,

2, 3 / path into I);

(1, 2, 3 / path into L)

The user could be asked for personal

information that violates PII (i.e. asked

for PII other than 1, 2, 3).

(1, 2, 3 / A, I, L); (1, 3 /

C, K, O)

Trojan horse, or hacker attacks on the

personal information use circles lead to

CPRD-risk.

(1, 2, 3 / D, J, N)

Potential SQL attacks on D, J, and N

lead to CPRD-risk.

(1, 2, 3 / D, J, N)

Potential insider attack steals private

information from D, J, and N resulting

in CPRD-risk.

(1, 2, 3 / D, J, N)

Private information in D, J, and N

could be kept past the retention time.

5.2 Mitigation of Privacy Risks

Applying the method for privacy risk mitigation

described in Section 4.2 produces Table 7,

containing the weights (Step 1) and mitigations

(Step 2) corresponding to the risks identified in

Table 6.

The weights in Table 7 were assigned as follows.

A weight of [L, H, L, H] was assigned to the first

row after the same considerations as that described

in Section 4.2 for man-in-the-middle attacks. A

weight of [M, M, L, H] was assigned to the second

row since the paths in this row are relatively short

(connecting components in the same module),

leading to greater risk for the attacker (greater risk of

being seen) and lower accessibility (fewer places to

access the link). A weight of [L, H, L, M] was

assigned to the third and last rows out of the same

considerations as in Section 4.2, for the risk of the

user being asked for information that violates PII

and the risk of private information kept past the

retention time. A weight of [L, H, L, H] was

assigned to the Trojan horse or hacker attack in the

fourth row and the SQL attacks in the fifth row since

the attacker could operate from a distance with easy

access through the Internet and with relatively low

costs. A weight of [L, H, L, H] was assigned to the

risk of an insider attack in the sixth row since an

insider can hide in plain sight, has high access by

virtue of being an insider, and carry out the attack at

zero cost to herself.

The privacy risks in Table 7 were prioritized

using the Mitigation Policy “only mitigate risks with

weights [L, *, *, H]”.

6 RELATED WORK

This section primarily concerns related works

involving privacy risk prioritization and mitigation.

Please consult (Yee, 2016) for related works on

privacy risk identification.

In terms of risk prioritization, no references were

found that deals directly with the prioritization of

privacy risks. However, abundant work exists on the

assessment of security risks, which is closely related

to prioritizing privacy risks. (Alizadeh and Zannone,

2016) present a risk-based framework that facilitates

the analysis of business process executions. The

framework detects non-conforming process

behaviors and ranks them according to criticality,

which is determined by the execution’s impact on

organizational goals. The criticality ranking enables

a security analyst to prioritize the most severe

SECRYPT 2017 - 14th International Conference on Security and Cryptography

356

incidents. (Jorgensen et al., 2015) propose

decomposing risk associated with a mobile

application into several risk types that are more

easily understood by the application’s users and that

a mid-level risk summary be presented that is made

up of the dimensions of personal information

privacy, monetary risk, device availability/stability

risk, and data integrity risk.

Table 7: Weights and mitigations for risks in Table 6.

(PIIs /

locations)

Privacy Risks

Weights

(Step 1)

Mitigations

(Step 2)

(1, 2, 3 / path

into A); (1,

2, 3 / path

into I);

(1, 2, 3 / path

into L)

Man-in-the-

middle attacks

lead to CPRD-

risk.

[L, H, L, H]

Use SSL for

(1, 2, 3 / path

into A); 1, 2, 3

/ path into I);

(1, 2, 3 / path

into L)

(1, 2, 3 / path

between I

and J); (1, 2,

3 / path

between L

and N); (1, 3

/ path

between N

and O)

Man-in-the-

middle attacks

lead to CPRD-

risk.

[M, M, L, H]

Not considered

for mitigation

(1, 2, 3 / path

into A); (1,

2, 3 / path

into I);

(1, 2, 3 / path

into L)

The user could

be asked for

personal

information that

violates PII (i.e.

asked for PII

other than 1, 2,

3).

[L, H, L, M]

Not considered

for mitigation

(1, 2, 3 / A,

I, L); (1, 3 /

C, K, O)

Trojan horse, or

hacker attacks

on the personal

information use

circles lead to

CPRD-risk.

[L, H, L, H]

For each

module,

constrain all

incoming

traffic to a

firewall with

intrusion

protection

(1, 2, 3 / D,

J, N)

Potential SQL

attacks on D, J,

and N lead to

CPRD-risk.

[L, H, L, H]

Use strong

encryption on

the databases

D, J, and N.

(1, 2, 3 / D,

J, N)

Potential insider

attack steals

private

information

from D, J, and N

resulting in

CPRD-risk.

[L, H, L, H]

Strengthen

screening of

potential

employees;

deal with

employee

grievances

fairly

(1, 2, 3 / D,

J, N)

Private

information in

D, J, and N

could be kept

past the

retention time.

[L, H, L, M]

Not considered

for mitigation

Their work suggests that privacy risk

prioritization may be facilitated by decomposing the

risks into more easily understandable categories or

dimensions (as also done in this work). (Islam et al.,

2016) present a framework for threat analysis and

risk assessment of automotive embedded systems to

systematically tackle security risks and determine

security impact levels. The latter serve to prioritize

the severity of the risks. The framework aligns with

several industrial standards.

In terms of privacy risk mitigation, no other

work similar to this work was found. (Kandappu et

al., 2013) examine crowd-sourced survey platforms

and show how easily user privacy can be

compromised by collating information from multiple

surveys. They propose a new crowd-sourcing

platform that allows users to control their privacy

loss using at-source obfuscation. (Lucas and

Borisov, 2008) address the privacy risks of social

networking websites where the providers of such

websites can observe and collect the information that

users transmit through the network. They propose to

mitigate these risks through the implementation of a

new architecture for protecting the information

transmitted, using encryption. These authors have

implemented the architecture using a prototype

Facebook application and claim that their

implementation strikes a balance between protecting

privacy and maintaining Facebook’s usability.

(Oladimeji et al., 2011) look at healthcare delivery

through ubiquitous computing and suggest that new

techniques are needed to deal with the concerns for

security and privacy within such delivery. They

propose a goal-centric and policy-driven framework

for deriving security and privacy risk mitigation

strategies in ubiquitous health information

interchange. These authors employ scenario analysis

and goal-oriented techniques to model security and

privacy objectives, threats, and mitigation strategies

in the form of safeguards or countermeasures.

7 CONCLUSIONS AND FUTURE

WORK

This work has proposed a straightforward approach

for adding privacy protection to distributed software

systems, consisting of two parts. The first part

identifies the privacy risks, and the second part

mitigates the risks, both parts focusing attention on

locations that contain PII.

Some of the strengths of the method include: a)

provides a structured way to identify privacy risks,

and b) prioritizes the risks to be mitigated, to

account for budgetary constraints.

Some weaknesses of the method are: a) drawing

Adding Privacy Protection to Distributed Software Systems

357

the PIM is a manual task, prone to error, and b) the

assignment of weights for selecting the risks to be

mitigated is subjective and dependent on the

expertise and experience of the person or persons

doing the assignment. Weakness a) can be addressed

by building tools for automatically drawing the PIM.

Similar tools already exist for rendering a software

architecture diagram from the reverse engineering of

code, e.g., (Nanthaamornphong et al., 2013).

Furthermore, automated analysis of the PIM should

be feasible by using a rules engine to automate the

enumeration of privacy risks, based on machine

understanding of the graphical notation in the PIM.

Weakness b) may be overcome by replacing the

weights with probabilities of risk realization,

calculated objectively with an algorithm that takes

account of factors such as past attacks, existing

threats, the state of attack technology, and existing

defenses of the software system. Note that we have

already proposed to partially incorporate the impact

of past attacks, in terms of enlarging the number of

risks to be mitigated (see Section 4.1) based on a

high level of past attacker activity.

Future work includes resolving weaknesses a)

and b), and validating the effectiveness of the

approach in industrial settings.

REFERENCES

Adams, C. and Barbieri, K., 2006. Privacy Enforcement in

E-Services Environments. Chapter in Privacy

Protection for E-Services. Edited by G. Yee. Idea

Group, Inc.

Alizadeh, M. and Zannone, N., 2016. Risk-based Analysis

of Business Process Executions. Proceedings of the

6th ACM Conference on Data and Application

Security and Privacy (CODASPY’16), pp. 130-132.

Goldberg, I., Wagner, D., and Brewer, E., 1997. Privacy-

Enhancing Technologies for the Internet. Proceedings

of IEEE COMPCON’97, pp. 103-109.

Islam, M., Lautenbach, A., Sandberg, C., and Olovsson,

T., 2016. A Risk Assessment Framework for

Automotive Embedded Systems. Proceedings of the

ACM International Workshop on Cyber-Physical

System Security (CPSS’16), pp. 3-14.

Iyengar, V. S., 2002. Transforming Data to Satisfy Privacy

Constraints. Proceedings of the 8

ACM SIGKDD

International Conference on Knowledge Discovery

and Data Mining (KDD’02), Edmonton, Alberta, pp.

279-288.

Jorgensen, Z., Chen, J., Gates, C., Li, N., Proctor, R. and

Yu, T., 2015. Dimensions of Risk in Mobile

Applications: A User Study. Proceedings of the 5th

ACM Conference on Data and Application Security

and Privacy (CODASPY’15), pp. 49-60.

Kandappu, T., Sivaraman, V., Friedman, A., Boreli, R.,

2013. Exposing and Mitigating Privacy Loss in

Crowdsourced Survey Platforms. Proceedings of the

2013 Workshop on Student Workhop, pp. 13-16.

Lucas, M. and Borisov, N., 2008. flyByNight: Mitigating

the Privacy Risks of Social Networking. Proceedings

of the 7th ACM Workshop on Privacy in the Electronic

Society (WPES ’08), pp. 1-8.

Nanthaamornphong, A., Morris, K. and Filippone, S.,

2013. Extracting UML Class Diagrams from Object-

Oriented Fortran: ForUML. Proceedings of the 1

International Workshop on Software Engineering for

High Performance Computing in Computational

Science and Engineering (SE-HPCCSE’13), pp. 9-16.

Oladimeji, E. A., Chung, L., Jung, H. T. and Kim, J.,

2011. Managing Security and Privacy in Ubiquitous

eHealth Information Interchange. Proceedings of the

5th International Conference on Ubiquitous

Information Management and Communication

(ICUIMC ’11). Article No. 26.

Salter, C., Saydjari, O. S., Schneier, B. and Wallner, J.,

1998. Toward A Secure System Engineering

Methodology. Proceedings of the New Security

Paradigms Workshop, pp. 2-10.

Song, R., Korba, L., and Yee, G., 2006. Pseudonym

Technology for E-Services. Chapter in Privacy

Protection for E-Services. Edited by G. Yee. Idea

Group, Inc.

Yee, G., 2016. Visualization of Privacy Risks in Software

Systems. Proceedings of the Tenth International

Conference on Emerging Security Information,

Systems and Technologies (SECURWARE 2016), pp.

289-294.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

358
