Face Anti-spoofing based on Deep Stack Generalization Networks
Xin Ning
1,2
, Weijun Li
1,2
, Meili Wei
2
, Linjun Sun
1,2
and Xiaoli Dong
1,2
1
Institute of Semiconductors, Chinese Academy of Sciences, 100083, Beijing, China
2
Cognitive Computing Technology Wave Joint Lab, 100083, Beijing, China
Keywords: Face Anti-spoofing, Convolutional Neural Networks, Stacked Generalized Approach, Intra-class Variations.
Abstract: Thanks for the recent development of Convolutional Neural Networks (CNNs), the performance of face
anti-spoofing methods has been improved by extracting more distinguishing features between genuine and
fake faces than the hand-crafted texture features. As known, the way of fraud is diverse, thus the fake class
has large intra-class variations, so training as a binary classification problem is hard to learn the
distinguishing features. In this work, our contribution is a novel model fusion approach for face anti-
spoofing, which can reduce the intra-class variations. According to the type of fraud, we firstly train
different models for face anti-spoofing problem by CNN, thus the intra-class variations of fake class has
reduced during training each model. Distinguishing features can be learned more easily. Then the stacked
generalized method is used for combining the lower models to achieve better predictive accuracy. For
perfecting the generalized accuracy, the stacked generalized approach changes the weight of each model's
prediction, so that the model after fusion can predict precisely whether the face image is fake or genuine.
Meanwhile, the experimental results indicate our method can obtain excellent results compared to the state-
of-the-art methods.
1 INTRODUCTION
Face recognition has achieved great success during
the past decades, and has been widely applied in
access control system, login system and so on.
However, a high security requirement for face
authentication is urgent, because only a photo, video
replay, or 3D-mask of valid user can easily spoof a
face recognition system to access secure information
illegally. With the popularity of electronic devices,
people can easily get photos and videos belonging to
others through the network, which caused a lot of
face recognition system for security risks. Therefore,
anti-spoofing problem for face biometric system has
gained great attention to the scholars and companies.
The fragility of face recognition systems to face
spoof attacks has motivated a number of studies on
face anti-spoofing, such as LBP (Maatta et al.,
2011), HOG (Komulainen et al., 2013), LBP-TOP
(Pereira, 2012), Image quality assessment (Wen et
al., 2015), CNN (Yang et al., 2014), etc.
However, published studies are limited in their
scope, because these methods are more to train a
common model to prevent attack from photo, video
or 3D-mask. Because of the diversity of fraud, a
general model cannot be learned in such
complexities, may not work when facing specific
fraud. Besides, these methods regard face anti-
spoofing as a binary classification problem, that is to
say the all kinds of fake face is one class, and the
real face is another class. As we all know, the fake
face can be a photo, a video replay, or a 3D-mask.
Due to different ways of fraud, the fake class has
large intra-class variations. These existing classifiers
in identifying sample work individually, as is well
known, when making critical decisions, wise people
often take into account the opinions from several
experts rather than only one. In this paper, we do not
address 3D-mask attacks, which are more costly to
launch, we focus on photo and replayed video
attacks. We learn a CNN model for each type of
fraud, then the stacked generalization method will be
use to integrate the two models, which will decide
whether the input face image is real or not. Stacked
generalization is a general method of using a high-
level model to combine lower-level models to
achieve greater predictive accuracy.
The remainder of the paper is organized as
follows: Section 2 briefly reviews the relevant work
on face anti-spoofing. Section 3 presents our
Ning, X., Li, W., Wei, M., Sun, L. and Dong, X.
Face Anti-spoofing based on Deep Stack Generalization Networks.
DOI: 10.5220/0006568103170323
In Proceedings of the 7th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2018), pages 317-323
ISBN: 978-989-758-276-9
Copyright © 2018 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
317
approach. The experimental setup and results are
discussed in Section 4. Finally, in Section 5 we
summarize this work highlighting its main
contributions.
2 RELATED WORK
Because of the diversity of spoofing attacks, existing
traditional face anti-spoofing approaches can be
mainly categorized into four categories: (i) motion
based methods, (ii) texture based methods, (iii)
method based on image quality analysis, and (iv)
methods based on other cues. The motion based
methods was designed primarily to counter printed
photo attacks. Eye blinking (Pan et al., 2007) or lip
movement (Kollreider et al., 2007) are used for face
anti-spoofing. Given that motion is a relative feature
across video frames, these methods are expected to
have better generalization ability than the texture
based methods. However, motion based methods
need a relatively long time to accumulate stable
vitality features for face spoof detection. The texture
based methods include LBP (Maatta et al., 2011),
HOG (Komulainen et al., 2013), etc. Pereira et al.
(2012) used LBP-TOP to extract spatial and time
domain features from three orthogonal planes.
Unlike motion based methods, texture based
methods need only a single image to detect a spoof.
However, the generalization ability of many texture
based methods has been found to be poor. A recent
work (Galbally et al., 2014) proposed a biometric
liveness detection method for iris, fingerprint and
face images using 25 image quality measures,
including 21 full-reference measures and 4 non-
reference measures.
Different from traditional methods, CNNs can
extract distinguishing end-to-end features directly
from raw data, and has been proved efficient in
many other vision fields. Yang et al., (2014) extract
features by CNN, then feeding them to a SVM
classifier. Xu et al., (2016) proposed LSTM-CNN
architecture to learn the temporal structure from
videos.
Those works consider the face anti-spoofing as a
binary classification problem, all real face is one
class, and the other is all kinds of fake face. Because
of the variety of fake face, photo attacks and video
attacks will be different on the texture, reflect
illumination, resolution, etc., thus the large intra-
variance will increase the difficulty of classification.
Each model is heterogeneous and has strong
classification ability, therefore, the integration model
with stacked generalization method will make full
use of the advantages of different models,
complement each other, thus will achieve better
predictive accuracy.
3 PROPOSED METHOD
For reducing the intra-class variations, we train
different models according to the type of fraud face.
Each model can learn the deep and distinguishing
feature for classifying fake or real. The stacked
generalization method takes full advantage of each
model's prediction and change the weights of each
prediction. Then a wiser decision would be made for
maximizing generalize accuracy. With the stacked
generalized method, the training difficulty of anti-
spoofing problem is decreased than training a
general model. Besides, the model can converge
more easily.
3.1 Stacked Generalization
Stacked generalization (Wolpert, 1992; Ting and
Witten, 1997) is a general method of using a high-
level model to combine lower-level models to
achieve greater predictive accuracy. It's a scheme for
minimizing the generalization error rate of one or
more classifiers, and works by reducing the biases of
the classifiers with respect to a provided learning set.
When fusing the multiple classifiers, stacked
generalization exploited a strategy more
sophisticated for combining the individual
classifiers. Stacked generalization tries to learn
which classifiers are reliable ones, and use a higher-
level learning algorithm, the so-called "meta-
classifier", to discover the best way of how to
combine the outputs of the base classifiers. As
shown in Figure 1, there are two kinds of classifiers:
several base classifiers (leavel-0 classifiers) and one
meta-classifier (level-1 classifier). The output class
probabilities generated by level-0 models are used to
form level-1 data. Then a multivariable linear
regression model (MLR) is adapted for classification
tasks for level-1 classifier.
3.1.1 Level-0 Generalizers
As shown before (Krizhevsky et al., 2012; Simonyan
and Zisserman, 2014; He et al., 2016), deeper and
better pre-training networks lead to better
performance. ResNet (He et al., 2016) won the 1st
place on the ILSVRC 2015 classification task. The
depth of representations is of central importance for
many visual recognition tasks, especially in face
ICPRAM 2018 - 7th International Conference on Pattern Recognition Applications and Methods
318
anti-spoofing. In the task of face anti-spoofing, the
intra-class variations are large, and are mainly
caused by the appearance of different people, the
different ways of fraud, and the different resolutions
of faces images captured by different camera, such
as the photo attacks can be printed on different types
of paper, the video attacks can be played on different
electronic equipment and so on. Therefore, the
deeper networks can extract more useful and
distinguishing features. In this paper, we use a
ResNet50 (He et al., 2016) model as the level-0
generalizers.
Given two training data sets
1
Q y , , 1,...,
nn
x n N
and
2
, , 1,...,
nn
P y x n N
where
n
y
is the class
value and
n
x
represents the attribute values of the ss
instance,
Q
defines the set of real face and video
attack face, and
P
defines the set of real face and
photo attack face. The specific type of fraud is
included in each dataset, causing the small intra-
class variations and large inter-class variations. So
the training difficulty can be decreased. Then
randomly split the data sets into two parts
11
,QP
and
22
,QP
. Define
11
, , 1,...,
nn
Q y x n N M
,
12
, , 1,...,
nn
P y x n N M
and
,
22
, , 1,...,
nn
P y x n N M
to be the training
and validation sets. The
1
Q
and
1
P
datasets are used
for training level-0 data, and the
2
Q
and
2
P
datasets
are used for forming the level-1 data. Given
ResNet50 called level-0 generalizers, training on the
data in the training set
1
Q
and
1
P
to induce a model,
for
1,...,kK
, which are called level-0 models. The
level-1 data assembled from the outputs of the
K
models is
'
2 11 1 1 1
, ,..., ,..., ,..., ,..., ,..., , 1,...,
n n In k n kIn K n KIn
Q y z z z z z z n M
,
'
2 11 1 1 1
, ,..., ,..., ,..., ,..., ,..., , 1,...,
n n In k n kIn K n KIn
P y z z z z z z n M

,
where
kin ki n
z P x
is the prediction from the level-
0 models, and
ki n
Px
denote the probability of the
thi
output class, and in the ResNet50,
ki n
Px
is the
class probability of the Softmax layer's output, and
1
1
I
ki n
i
Px
.
Figure 1: The illustration of stacked generalization.
3.1.2 Level-1 Generalizers
After obtaining the level-1 data, we use MLR
(Breiman, 1996) to derive from this data a model
in this work. MLR which Breiman (Breiman, 1996)
used in regression settings, is an adaptation of a
least-square linear regression algorithm. If the
classification problem is with real-valued attributes,
it can be transformed into a multi-response
regression problem. In the face anti-spoofing task,
they are two classes, they can be converted into two
separate regression problems, where the problem for
class has instances with responses equal to 1 when
they have class 1 and 0 otherwise.
The linear regression for class 1 is simply:
KI
ki ki
ki
LR z P z

(1)
We solve this problem to choose the linear
regression coefficients
ki
to minimize:
'
2
2
,
nn
n ki ki n
j k i
y z Q
y P z



(2)
where
y
is equal to 1 when the instance's label is
corresponding with the class 1,s and 0 otherwise.
These regression coefficients can be the weight of
each level-0 model's prediction probability. In the
test phase, after the fusion, the probability of each
sample predicting fake or real is readjusted, so that
according to the probability, the sample is
classifying correctly. In the experimental stage, we
compare the accuracy with the AND rule. As shown
in Table 2, our method is better than the AND rule
with a large margin. According the AND rule, if
both the two model's prediction is real, then the final
prediction is real, otherwise is fake. We believe the
Face Anti-spoofing based on Deep Stack Generalization Networks
319
reason is that our method learns which model is
more reliable and which not. Because each level-0
model is heterogeneous, for each specific sample,
the classification accuracy rates of these models are
quite different. Therefore, the weights can adjust the
predictions so that the more wisdom decision can be
given.
When classifying a new instance
x
, compute
LR x
for the two classes, and assign the instance
to class real which has the greatest value. That is to
say, if
real fake
LR x LR x
, then we believe the
sample is a real face, otherwise fake face.
Figure 2: Examples of real access and spoofing attempts in
the CASIA-FASD database. The first row is low-quality,
the second row is middle-quality and the last row is high-
quality. The first column is genuine, and the others form
left to right are warp-photo, cut-photo and video fraud.
Figure 3: Examples of real access and spoofing attempts in
the REPLAY-ATTACK database. The four rows from top
to down are real video, print fraud video, mobile fraud
video and high-definition fraud video. And the first
column is adverse environment and the second column is
controlled.
Figure 4: Examples of real access and spoofing attempts in
our database. The five rows are captured by different
cameras, from top to down are Phone Low Resolution
front camera, Pad front camera, Phone Normal Resolution
front camera, USB Low Resolution and USB High
Resolution. The four columns are different type of fraud,
from left to right are warp A4 photo fraud, cut eye A4
photo, warp copper photo and video replay fraud.
4 EXPERIMENTS
Our proposed method is successful on the face anti-
spoofing data sets. We evaluated it in this section on
two different datasets, including CASIA (Zhang et
al., 2012), and Replay-attack (Chingovska et al.,
2012).
4.1 Implementation Details
In this work, during the training, we first separate
the video attacks and photo attacks into different
sets. For each video, we selected one frame every
three frames, thus forming the training, validation
and test sample sets. For each frame, the face can be
detected by using Viola-Jones algorithm. To provide
precise face locations, we implement the face
alignment algorithm proposed in Sun et al., (2014)
ICPRAM 2018 - 7th International Conference on Pattern Recognition Applications and Methods
320
after a common Viola-Jones face detection. After
obtaining the landmarks, their bounding box is
regarded as the final face location. According to
Yang et al. (2014), beyond the conventional face
region, the backgrounds are helpful for the
classification as well. Therefore, we enlarge the
original ones with re-scaling ratio 1.8. Finally, all
input images are resized to 224*224. For the CNN,
we use Caffe toolbox and adopt a commonly used
structure ResNet50, which was ever used in He et al.
(2016). In the training of the ResNet50 for video
attack face and photo attack face, the learning rate is
0.0001; decay rate is 0.001; and the momentum is
0.9. Before fed into the ResNet50, the data are first
centralized by the mean of training data.
4.2 Datasets
4.2.1 CASIA-FASD Database
The database collects 600 short videos from 50
clients (Zhang et al., 2012). For each subject, there
different quality videos are captured by different
resolution camera. For each camera, one real video
and corresponding three different kinds of attacks
were recorded. The three kinds of attacks are warped
photo attack, cut photo attack and electronic screen
attack. Therefore, each subject has 12 sequences (3
genuine and 9 fake ones). Three different imaging
quality conditions were recorded using an imaging
device of (1) High-quality, (2) Middle-quality, and
(3) Low-quality. Example frames from genuine and
fake videos are shown in Figure 2. For evaluation,
the total set of videos is divided into two non-
overlapping subsets for training and testing.
4.2.2 REPLAY-ATTACK Database
This database contains 1200 short videos from 50
subjects (Chingovska et al., 2012), including both
real accesses and face spoofing attacks. Each person
in the database was recorded the videos in two
illumination conditions: controlled and adverse. A
high resolution pictures and videos were taken for
each subject under the same condition. There are
three attacks: print attacks, mobile attacks and high-
definition attacks. And the videos were divided into
hand based attacks and fixed based attacks. Example
frames from genuine and fake videos are shown in
Figure 3.For evaluation, the total set of videos is
divided into three non-overlapping subsets for
training, development and testing.
4.2.3 Our Database
The database contains 1500 short videos from 100
subjects, including both real accesses and face
spoofing attacks. For each subject, there different
quality videos are captured by different resolution
camera. For each camera, one real video and
corresponding three different kinds of attacks were
recorded. The three kinds of attacks are warped
photo attack, cut photo attack and electronic screen
attack. Example frames from genuine and fake
videos are shown in Figure 4. Therefore, each
subject has 15 sequences (1 genuine and 14 fake
ones). For evaluation, the total set of videos is
divided into two non-overlapping subsets for
training.
4.3 Experimental Results
The performance of the proposed stack generalized
based face anti-spoofing approach was evaluated on
the three databases. All these results are given in
Table 1. For a performance comparison, the results
of the state-of-the-art countermeasures and the
baseline algorithms in databases to face spoofing
attacks are listed in Table 1. On the CASIA-FASD
database, best performance in previous work was
achieved by the LBPs form three orthogonal planes
(LBP-TOP) method, exploring the spatial and
temporal LBP distributions simultaneously. Our
method achieved an EER of 3.42%, which is better
than the LBP-TOP method. On the REPLAY-
ATTACK, our method achieved an EER of 0.13%
and HTER of 0.63% respectively, both of which are
superior to the others.
Besides, the performance of our method was
compared with the AND rule method on the
REPLAY-ATTACK, CASIA-FASD and our
database. The results are listed in Table 2.From the
results, the proposed stacked generalized method
achieved a huge performance improvement in
liveness detection compared with the AND rule
method.
On the REPLAY-ATTACK, CASIA-FASD and
our database, our method achieved a huge
performance improvement in face anti-spoofing
problem. These results illustrate the effectiveness of
the proposed stacked generalized face liveness
detection approach.
Face Anti-spoofing based on Deep Stack Generalization Networks
321
Table 1: Comparison between the proposed
countermeasure and state-of-the-art methods based on the
REPLAY-ATTACK, CASIA-FASD database.
Approach
Replay-
attack-
dev(EER)%
Replay-
attack-
test(HTER)%
CASIA-
FASD-test-
EER (%)
IQA based
(Galbally and
Marcel, 2014)
---
---
32.40
Motion (Pereira et
al., 2013 )
11.60
11.70
26.60
LBP + SVM
(Yang et al., 2013)
8.55
11.75
18.50
LBP-TOP + SVM
(Pereira et al.,
2012)
7.88
7.60
10.00
SBIQF+NN
(Feng et al., 2016 )
3.83
6.13
15.5
YCbCr + HSV +
LBP (Boulkenafet
et al., 2015)
0.4
2.9
6.2
LSTM
(Xu et al., 2016)
---
---
5.17
Our Method
0.13
0.63
3.42
Table 2: Comparison between the proposed
countermeasure and the AND rule method based on the
REPLAY-ATTACK, CASIA-FASD database.
Approach
Replay-attack-
dev(EER)%
Replay-attack-
test(HTER)%
CASIA-FASD-
test(EER)%
AND Rule
0.38
2.63
5.83
Our Method
0.13
0.63
3.42
5 CONCLUSIONS
With the rapid development of face anti-spoofing
techniques, the threats of spoofing attacks will also
increase in the diversity. It's hard to learn a model to
detect all types of fraud. Hence, the integration of
several countermeasures is a promising approach.
The proposed method is a way of combination. And
our method can be easily combined with other
algorithms, as long as these algorithms are helpful
for liveness detection. In future work, other advance
neural networks will be investigated to improve face
anti-spoofing performance, such as the long short-
term memory (LSTM) network, which may be more
effective in learning face liveness features.
ACKNOWLEDGEMENTS
This work was supported by the National Nature
Science Foundation of China (No. 61572458), and
the China Scholarship Council (Grant
No.201404910237).
REFERENCES
Maatta J, Hadid A, Pietikainen M., 2011. Face spoofing
detection from single images using micro-texture
analysis[C]// International Joint Conference on
Biometrics. IEEE.
Komulainen J, Hadid A, Pietikainen M., 2013. Context
based face anti-spoofing[C]// IEEE Sixth International
Conference on Biometrics: Theory, Applications and
Systems. IEEE.
Pereira T D F, Anjos A, Martino J M D, et al., 2012.
LBP − TOP Based Countermeasure against Face
Spoofing Attacks [J].
Wen D, Han H, Jain A K., 2015. Face Spoof Detection
with Image Distortion Analysis [J]. IEEE Transactions
on Information Forensics & Security.
Yang J, Lei Z, Li S Z., 2014. Learn Convolutional Neural
Network for Face Anti-Spoofing [J]. Computer
Science.
Pan G, Sun L, Wu Z, et al., 2007. Eyeblink-based Anti-
Spoofing in Face Recognition from a Generic
Webcamera[C]// IEEE, International Conference on
Computer Vision.
Kollreider K, Fronthaler H, Faraj M I, et al., 2007. Real-
Time Face Detection and Motion Analysis with
Application in “Liveness” Assessment [J]. Information
Forssssensics & Security IEEE Transactions on.
Galbally J, Marcel S, Fierrez J., 2014. Image Quality
Assessment for Fake Biometric Detection: Application
to Iris, Fingerprint, and Face Recognition [J]. IEEE
Transactions on Image Processing a Publication of
the IEEE Signal Processing Society.
Xu Z, Li S, Deng W., 2016 Learning temporal features
using LSTM-CNN architecture for face anti-
spoofing[C]// Pattern Recognition. IEEE.
Wolpert D H., 1992. Original Contribution: Stacked
generalization [J]. Neural Netw.
Ting K M, Witten I H., 1997. Stacked generalization:
when does it work? [C]// Fifteenth International Joint
Conference on Artificial Intelligence. Morgan
Kaufmann Publishers Inc.
Krizhevsky A, Sutskever I, Hinton G E., 2012. ImageNet
classification with deep convolutional neural
networks[C]// International Conference on Neural
Information Processing Systems. Curran Associates
Inc.
Simonyan K, Zisserman A., 2014 Very Deep
Convolutional Networks for Large-Scale Image
Recognition [J]. Computer Science.
He K, Zhang X, Ren S, et al., 2016. Deep Residual
Learning for Image Recognition[C]// Computer Vision
and Pattern Recognition. IEEE.
Breiman L., 1996. Stacked regressions [J]. Machine
Learning.
ICPRAM 2018 - 7th International Conference on Pattern Recognition Applications and Methods
322
Chingovska I, Anjos A, Marcel S., 2012. On the
effectiveness of local binary patterns in face anti-
spoofing[C]// Biometrics Special Interest Group.
IEEE.
Zhang Z, Yan J, Liu S, et al., 2012. A face ant spoofing
database with diverse attacks[C]// Iapr International
Conference on Biometrics.
Galbally J, Marcel S., 2014. Face Anti-spoofing Based on
General Image Quality Assessment[C]// International
Conference on Pattern Recognition. IEEE Computer
Society.
Pereira T D F, Anjos A, Martino J M D, et al., 2013. Can
face anti-spoofing countermeasures work in a real
world scenario? [C]// International Conference on
Biometrics. IEEE.
Yang J, Lei Z, Liao S, et al., 2013. Face liveness detection
with component dependent descriptor[C]//
International Conference on Biometrics. IEEE.
Pereira T D F, Anjos A, Martino J M D, et al., 2012. LBP
− TOP, Based Countermeasure against Face Spoofing
Attacks[C]// International Conference on Computer
Vision.
Feng L, Po L M, Li Y, et al., 2016. Integration of image
quality and motion cues for face anti-spoofing [J].
Journal of Visual Communication & Image
Representation.
Boulkenafet, Zinelabidine, Jukka Komulainen, and
Abdenour Hadid., 2015 "Face anti-spoofing based on
color texture analysis." Image Processing (ICIP), 2015
IEEE International Conference on. IEEE.
Xu Z, Li S, Deng W., 2016. Learning temporal features
using LSTM-CNN architecture for face anti-
spoofing[C]// Pattern Recognition. IEEE.
Sun J, Wen F, Wei Y, et al., 2014. Face alignment by
Explicit Shape Regression [J]. International Journal of
Computer Vision.
Face Anti-spoofing based on Deep Stack Generalization Networks
323
