PaaS-BDP

A Multi-Cloud Architectural Pattern for Big Data Processing

on a Platform-as-a-Service Model

Thalita Vergilio and Muthu Ramachandran

School of Computing, Creative Technologies and Engineering, Leeds Beckett University, Leeds, U.K.

Keywords: Big Data, Containers, Resource Pooling, Docker Swarm, Orchestration, Multi-Cloud, PaaS.

Abstract: This paper presents a contribution to the fields of Big Data Analytics and Software Architecture, namely an

emerging and unifying architectural pattern for big data processing in the cloud from a cloud consumer’s

perspective. PaaS-BDP (Platform-as-a-Service for Big Data) is an architectural pattern based on resource

pooling and the use of a unified programming model for building big data processing pipelines capable of

processing both batch and stream data. It uses container cluster technology on a PaaS service model to

overcome common shortfalls of current big data solutions offered by major cloud providers such as low

portability, lack of interoperability and the risk of vendor lock-in.

1 INTRODUCTION

Big data is an area of technological research which

has been receiving increased attention in recent years.

As the Internet of Things (IoT) expands to different

spheres of human life, a large volume of structured,

semi-structured and unstructured data is generated at

very high velocity. To derive value from big data,

businesses and organisations need to detect patterns

and trends in historical data. They also need to

receive, process and analyse streaming data in real-

time, or close to real-time, a challenge which current

technologies and traditional system architectures find

difficult to meet.

Cloud computing has also been attracting growing

interest lately. With different service models

available such as infrastructure as-a-service (IaaS),

platform as-a-service (PaaS) and software as-a-

service (SaaS), it is no longer essential that companies

host their IT infrastructure on-premises.

Consequently, an increasing number of small and

medium-sized enterprises (SME) has ventured into

big data analytics utilising powerful computing

resources, previously unavailable to them, without

having to procure their own hardware or maintain an

in-house team of highly skilled IT professionals. The

popularisation of cloud computing is not without its

challenges, particularly when it comes to

guaranteeing the portability and interoperability of

components developed, thus preventing the risk of

vendor lock-in. The solution presented in this paper is

an answer to these challenges.

2 MOTIVATION

The plethora of technologies currently being used for

Big Data processing, and the lack of a systematic,

unified approach to processing big data in the cloud

is a motivation for this research. There is no single

accepted solution to cater for all types of big data, so

various technologies tend to be used in combination.

Consequently, the learning curve for a developer

working with big data is steep, and the processing

logic developed within one system is generally

incompatible with other systems, leading to code

duplication and low maintainability.

The aim of this research is to produce a

systematic and unified approach to developing

portable and interoperable Big Data processing

services on a multi-cloud PaaS service model. PaaS-

BDP is based on a programming model applicable to

both stream and batch data, thus eliminating the need

for the Lambda Architecture where multiple

technologies are used in combination.

Vergilio, T. and Ramachandran, M.

PaaS-BDP.

DOI: 10.5220/0006632400450052

In Proceedings of the 3rd International Conference on Complexity, Future Information Systems and Risk (COMPLEXIS 2018), pages 45-52

ISBN: 978-989-758-297-4

3 RELATED WORK

This research proposes a solution to the vendor lock-

in aspects of low portability and lack of

interoperability affecting existing big data processing

offerings in the cloud. Solutions to the vendor lock-in

issue encountered in the literature can be categorised

as follows:

3.1 Standardisation

Standardisation of cloud resource offerings is a way

of dealing with the vendor lock-in issue. However, no

universal set of standards has yet been identified

which would successfully solve the issues of

portability and interoperability between different

cloud providers (Martino, 2014), and the standards

that do exist have not been widely adopted by the

industry (Guillén et al., 2013).

3.2 Cloud Federations

Another alternative solution to the vendor lock-in

issue is the establishment of cloud federations

(Kogias et al., 2016). In a cloud federation, providers

voluntarily agree to participate and are bound by rules

and regulations. This however places the focus on the

cloud provider, rather than on the consumer of cloud

services. As this research approaches the vendor lock-

in issue from the cloud consumer’s perspective, cloud

federations are excluded from its scope.

3.3 Middleware

The introduction of a layer of abstraction to enable

distribution and interoperability between different

cloud providers has also been proposed as a possible

solution to the cloud lock-in problem (Guillén et al.,

2013), (Silva et al., 2013). One such model, called

Neo-Metropolis, was proposed by H. Chen et al.

(Chen et al., 2016). This model is based on a kernel,

which provides the platform’s basic functionality, a

periphery, composed of various service providers

hosted on different clouds, and an edge, representing

customers who utilise services and provide

requirements (Chen et al., 2016). Whilst the kernel

would be fairly stable and backwards compatible,

with stable releases, the periphery would be in

constant development, or perpetual beta, and would

be based on open-source code (Chen et al., 2016).

One criticism to this type of approach, however,

is that the lock-in problem is not resolved, it is simply

shifted to the enabling middleware layer (Guillén et

al., 2013).

3.4 Unified Models

A model-driven approach to development, combined

with a unifying framework for modelling cloud

artefacts, has been suggested as a possible solution to

the vendor lock-in problem. In fact, the “model once,

generate everywhere” precept of MDA (Model

Driven Architecture) suggests that software can be

cloud platform-agnostic, provided that the necessary

code generating engines are in place (Martino, 2014).

In reality, however, it is difficult to find concrete

examples of perfectly accurate code generation

engines capable of producing all of the source code

exclusively from the models (Guillén et al., 2013).

MULTICLAPP is an architectural framework that

separates the application design from cloud provider-

specific deployment configuration. Application

modelling is done using an extended UML profile.

The models are then processed by a Model

Transformation Engine, responsible for inserting

cloud provider-specific configuration and generating

class skeletons (Guillén et al., 2013). Although this

approach ensures the perpetuation of the models in

case of cloud provider migration, application

implementation code would still need to be re-

written.

3.5 Virtualisation

The use of containers or hypervisor technology

(virtual machine managers) to deploy software in the

cloud is a pattern which minimises the effects of

vendor lock-in, as the environment configuration and

requirements are packaged together with the

deployed application.

3.5.1 Virtual Machines

The use of VMs to deploy applications is generally

associated with the IaaS cloud service model.

Together with the code for the developed application,

a VM also contains an entire operating system

configured to run that code. Since containers are

lighter and easier to deploy and maintain than VMs,

this research advocates the use of container

technology in its proposed architecture.

3.5.2 Containers

Containers are a lighter alternative to VMs

(Bernstein, 2014). They have gained increased

popularity recently, following the open-sourcing of

the most widely-accepted technology, Docker, in

March 2013 (Miell & Sayers, 2015).

COMPLEXIS 2018 - 3rd International Conference on Complexity, Future Information Systems and Risk

The benefits of using containers become more

apparent when it comes to implementing distributed

architectures (Bernstein, 2014), as their small size and

relative ease of deployment allow for better elasticity

across different clouds. Docker is based on the Linux

operating system, which is a good fit for the cloud as

it is reliable, has a wide user base, and allows

containers to scale up without incurring additional

licensing costs (Celesti et al., 2016).

This research embraces the emerging trend

towards containerisation as it recognises the benefits

of using a multi-cloud environment for the

deployment of distributed big data processing

frameworks.

4 PROPOSED SOLUTION

The proposed solution is an architectural pattern for

big data processing using frameworks and containers

on a PaaS service model.

4.1 Conceptual Elements

4.1.1 Framework

The framework takes care of parallelising the data

processing, scheduling work between the processing

units and ensuring fault tolerance. In traditional, on-

premises implementations, the framework code is

generally downloaded and unpacked in each

participating machine. A number of setup steps are

then completed to integrate each machine into the

cluster as a worker. As this process is executed within

each participating machine, usually by entering

commands on a terminal, it is prone to failure due to

differences between environments or human error.

The architectural pattern proposed in this section

presents a solution to this problem.

4.1.2 Image

An image specifies how to build/get an application,

its runtime environment and dependencies and

execute it in a container. It is abstract, whereas a

container is concrete. Many identical containers can

be created from a single image, which makes them a

good choice of technology for exploring the elasticity

of the cloud when building distributed systems. In a

similar way in which a class is used to instantiate an

object in object-oriented programming, an image is

used to instantiate containers in container-based

implementations.

Images are stored in a registry, which can be

private or public, and downloaded when needed.

Registries enable version control and promote code

sharing and reuse.

4.1.3 Container

Containers are lightweight runtime environments

deployed to virtual or physical machines. Each

machine can have several containers running in it.

They share the same operating system, but are

otherwise separate deployment environments.

4.1.4 Machine

A bare-metal or virtual machine can have a number

of containers running on it. They can be based on-

premises or in the cloud, with the latter generally

exhibiting greater elasticity. AWS, for example,

allows vertical scaling of their virtual machines

through re-sizing, which involves selecting a more

powerful configuration from the offers available

(Resizing Your Instance - Amazon Elastic Compute

Cloud, 2017).

4.2 Resource Sharing

The new architectural pattern proposed in this

research decouples the physical deployment

environment, i.e. machines, from the artifacts that are

deployed to them and ultimately the frameworks that

own the artifacts. Instead of having dedicated

machines for Hadoop, Spark, etc, these frameworks

share a pool of resources and take or drop them as

needed. Increased utilisation and improved access to

data sharing have been highlighted in the literature as

advantages associated with pooling resources

between big data frameworks (Hindman et al., 2011).

In fact, these factors are particularly relevant in the

context of cloud-based architectures, where costs are

transparent and changes are immediately visible. If

we take, for example, a multi-cloud setup where

resources are fluid and vendor lock-in is negligible, it

is possible to scale up using whichever provider is

most suitable at the time, or even replace providers

without detrimentally affecting the system.

The existence of mixed big data packages, such as

the Hadoop Ecosystem, suggests that there is no de-

facto big data technology to cater for all different

needs and scenarios. Instead, organisations tend to

utilise more than one framework concurrently. This is

another strong argument for choosing an architecture

which allows resources to be pooled and shared

between frameworks.

PaaS-BDP

Fig.1 illustrates how the proposed architectural

pattern decouples frameworks from machines by

introducing a new abstraction: containers. From a

machine’s perspective, it runs containers. A machine

is unaware of which frameworks, if any, are

associated with the containers running on it. Specific

environment configuration is defined at container

level, leaving the machine itself generic and agnostic.

The framework, on the other hand, knows nothing

about the specific machines on which their workers

and managers run. It does know which containerised

workers and managers are part of the cluster at a given

time, and their corresponding states, but it has no

knowledge of machines and their configurations.

Figure 1: Container-Based Big Data Processing

Deployment.

Fig.2 illustrates how the proposed architecture

scales up. Different big data frameworks are

maintained concurrently, as are different sets of

machines hosted in different locations. More

machines can be added to the cluster to scale the

system vertically. Likewise, more containers can be

created from a worker image and deployed to the

cluster if a particular job executed by a framework

needs to be scaled horizontally.

Figure 2: Container-Based Big Data Processing

Deployment on a PaaS Service Model.

4.3 Programming the Big Data

Processing Pipeline

This section decouples the big data processing

pipeline code from the framework under which it

ultimately runs. When the concept of a processing

pipeline is abstracted as a series of operations, defined

by business needs, performed on units of data, we find

no reason to believe it could not be written in a

framework-agnostic way. This avoids duplication

when different frameworks are used and enables the

portability of the developed artifact between

frameworks.

4.3.1 Different Programming Models

Many big data frameworks claim that any

programming language can be used to define their

processing pipelines, e.g. (Apache Storm - Project

Information, n.d.), (MapReduce Tutorial, 2013). This

section shall demonstrate that the main issue affecting

the portability and interoperability of artifacts

produced for a given framework is not to do with the

programming language, but with the abstractions and

programming model to which a developer must

adhere. These tend to be specific to each framework

and not easily translatable between them. A simple

visual example of a classifier and counter

implementation is used to illustrate this point.

Imagine a scenario where there are various green

and yellow circles, and a business need to count how

many circles there are of each colour. This section

compares two different approaches to implementing

a solution: one using MapReduce, a popular

algorithm for distributed parallel processing of batch

files, and another using a topology of spouts and

bolts, abstractions provided by the Storm framework.

Fig.3 presents a MapReduce-based solution. A

mapping function is first applied to each element of

each data set. It accepts coloured circles and outputs

numbered coloured circles which, in code, would be

represented as key/value pairs where the key is the

colour and the value is the number. The reduce

function then takes a set of values (all the circles

where the colour is yellow, or all the circles where the

Figure 3: The Map-Reduce Algorithm.

COMPLEXIS 2018 - 3rd International Conference on Complexity, Future Information Systems and Risk

colour is green) and performs a reduction operation,

i.e. transforms them into a smaller set of values. In

this case, it outputs one element, a circle where the

number is the sum of all the other numbers in the set.

The result could also be represented as a key/value

pair where the key is the colour or the circle and the

value is the number it displays.

Storm, a framework mainly designed for stream

processing, uses a different type of abstraction from

those used by MapReduce, namely spouts and bolts.

Spouts represent sources of streaming data, whilst

bolts represent transformations applied to them.

Because streaming data is infinite, a similar exercise

of counting circles by colour only makes sense if time

is taken into consideration, not only in the visual

representation, but also in the code implementation of

a possible solution. Fig. 4 represents a stream-based

approach to the circle count exercise. Using spouts

and bolts, it processes each element it sees in real-

time and updates a counter. Because the source of

data is infinite, the processing of the data is also

infinite, and the results are never final.

Figure 4: Spouts and Bolts Representing Stream Data

Processing.

Having examined two very simple examples

where the same problem is solved using different

frameworks and different approaches to big data

processing, it becomes apparent that the lack of

portability or interoperability between artifacts

produced for different frameworks is a complex issue

that goes beyond the simple translation of one library

into another. The abstractions upon which these

frameworks are built are fundamentally diverse, one

of the reasons why they generally provide their own

libraries.

In this section, a simple example of a counter for

different coloured circles was used to obtain an

insight into how big data frameworks use different

abstractions and a different programming model to

implement solutions to the same problem. In

particular, batch and stream architectures appear to

differ fundamentally due to the limited or unlimited

nature of the data source. The Lambda Architecture,

developed as an answer to this predicament, never did

circumvent the inconvenience of developers having

to maintain different pieces of code, containing the

same business logic, in different places, only because

the incoming data is, in some cases, limited and, in

others, unlimited. Section 4.3.3 looks at how this

dichotomy has been broken and explores the benefits

associated with using a unified programming model

with different big data frameworks. Before that,

however, the following section takes a closer look at

the traditional scenario of software development

using different frameworks and different

programming models.

4.3.2 Framework-Specific Programming

Framework-specific programming is hereby defined

as writing software code which is intended to be

executed from within a given framework. In a

scenario where multiple frameworks are used,

artifacts produced for each framework exist

independently and are maintained independently

throughout their existences. If a business case arises

to duplicate the functionality developed within one

framework onto a different framework, it is usually

the case that new code will need to be written, as the

conceptual model and abstractions used in the

implementation will be incompatible. Fig. 5

illustrates the process of programming for specific

frameworks.

Figure 5: Framework-Specific Programming.

4.3.3 Framework-Agnostic Programming

As seen in the previous section, in framework-

specific programming, developers use specialised

libraries provided by each framework. The processing

code written is therefore only compatible with a

particular framework, as are the artifacts produced.

The necessary conditions to enable framework-

agnostic programming can be understood by once

again referring to the process in Fig. 6. If, instead of

using a framework-provided library, developers used

a common library compatible with the main big data

frameworks, they would be able to write processing

PaaS-BDP

code in a framework-agnostic way, and to produce

artifacts compatible with multiple frameworks. The

Apache Beam SDK (Apache Beam, 2017) comes

very close to being such a library. The issue of

fundamental differences between programming

models for batch and stream is resolved by treating all

data as if it were streaming. Streaming data, due to its

unbounded nature, is divided into bounded subsets

called windows, which are finite and can be processed

one at a time. The same approach is used for the

processing of batch data: even though the data is

finite, it could be so large that, for processing

purposes, it makes sense to treat it as infinite. Large

sources of batch data would therefore be divided into

windows and processed one subset at a time, as if they

were streaming. Fig. 6 and 7 illustrate the windowing

of batch data so the same programming model is

applied for both batch and stream data.

Figure 6: Batch Processing using a Stream-Based

Programming Model.

Figure 7: Stream Processing using a Stream-Based

Programming Model.

The benefits of decoupling the programming

model from specific big data frameworks include less

code duplication, increased reusability and

maintainability of artifacts produced, and a shallower

learning curve for developers wanting to work with

big data. Fig. 8 illustrates the framework-agnostic

programming model. Note how the developer only

produces one artifact, which is then uploaded to

different frameworks, to be processed using their

respective resources.

Figure 8: Framework-Agnostic Programming.

4.3.4 Framework-Agnostic Programming

with Pooled Resources

This section aims to amalgamate the framework

agnostic programming model described in the

previous section with the container-based

architectural pattern proposed earlier. It demonstrates

how decoupling artifacts from frameworks and from

the machines that run them leads to less duplication,

higher maintainability of code, as well as easier,

simpler and more effective management of machine

clusters.

Fig. 9 illustrates the framework-agnostic model

with pooled resources. Big data processing pipelines

are developed once per business case, instead of one

per framework. Once the artifact is ready to be

released into production, it can be uploaded to and

executed by any compatible big data framework.

Because the programming model used is stream-

based, the big data framework must be able to execute

stream pipelines. This is one of the limitations of the

model. However, should users of major batch

processing frameworks such as Hadoop wish to adopt

the proposed unified model, they could do so with

minimal impact and without the need for migration

by adopting a parallel transition strategy over a long

period of time (Okrent & Vokurka, 2004). Since

HDFS files can be used as data sources in the

proposed model, new processing pipelines can be

developed using the unified model and run by a

stream engine without affecting the existing code

developed to run in Hadoop.

Figure 9: Framework-Agnostic Programming with Pooled

Resources.

The second decoupling line in Fig. 10 shows how

resources can be pooled and shared by different

frameworks. Frameworks have a number of runners

or workers responsible for the parallel execution of

data processing pipelines. These workers are typically

deployed to clusters of machines on a one cluster per

framework basis, as shown in Fig. 8. This represents

COMPLEXIS 2018 - 3rd International Conference on Complexity, Future Information Systems and Risk

a potential waste of resources, magnified in a cloud

scenario where machines are charged on a per-minute

base. The chance of charges being incurred for

machines which are idle is higher, since a machine

commissioned for a given framework’s cluster cannot

be immediately utilised by a different framework.

The proposed model solves this issue by allowing

different frameworks to share the same cluster.

Runners belonging to different frameworks are

deployed to machines as containers. Because

machines only execute containers and know nothing

about which framework, if any, the containers belong

to, they become framework-independent and can be

shared between several of them.

This section presented the full proposed model for

big data processing in the cloud. It discussed the

advantages of utilising a unified programming model

and a container-based architecture with pooled

resources for cases where different big data

frameworks are used simultaneously.

5 EVALUATION

The current section presents preliminary results for an

initial experiment which consisted of setting up and

configuring a multi-cloud containerised environment

on a PaaS service model. A total of 12 virtual

machines were commissioned from Microsoft Azure,

Google Cloud and the Open Science Data Cloud

(OSDC), as illustrated in Table 1. Although every

attempt was made to commission identical machines

to operate as workers, lack of standardisation

amongst cloud providers led to our nodes being

slightly, although not significantly different.

Docker was used for containerisation, and Docker

Swarm for orchestration. The nodes were networked

across clouds using the Weave Net Docker plugin

(Weave Net, 2017). The Apache Beam SDK was used

to program the big data processing pipeline, since it

provides a unifying programming model for both

batch and stream data. Apache Flink was selected as

a runner since, at the time of writing, it provided the

widest range of capabilities from the open-source

technologies supported by Apache Beam (Apache

Beam Capability Matrix, n.d.).

At this initial stage, we successfully verified that

the proposed architecture is feasible and that the job

of processing incoming streaming data is seamlessly

parallelisable across different clouds. We also

verified that the proposed architecture is horizontally

and vertically scalable by increasing the number of

containers running data processing jobs, and by

adding nodes dynamically to the pool of resources.

Table 1: Multi-Cloud Virtual Machine Specification.

Cloud Resource

Commissioned

RAM CPU Disk Purpose

Azure Standard DS2 v2

Promo

7GB 2vCP

30G

Orchestratio

Azure Standard DS2 v2

Promo

7GB 2vCP

30G

Work

Parallelisati

Azure Standard DS2 v2

Promo

7GB 2vCP

30G

Worker

Azure Standard DS2 v2

Promo

7GB 2vCP

30G

Worker

Azure Standard DS2 v2

Promo

7GB 2vCP

30G

Worker

Googl

n1-standard-2 7.5G

2vCP

10G

Worker

Googl

n1-standard-2 7.5G

2vCP

10G

Worker

OSDC m3.medium 6GB 2vCP

10G

Worker

OSDC m3.medium 6GB 2vCP

10G

Worker

OSDC m3.medium 6GB 2vCP

10G

Worker

OSDC m3.medium 6GB 2vCP

10G

Worker

OSDC ram8.disk10.eph64.co

re4

8GB 4vCP

10G

Messaging

We are currently working on a Case Study which

involves developing a real-time Energy Efficiency

Analysis service using the multi-cloud big data

architecture proposed. This Case Study shall provide

us with a solid evaluation of our contribution in a real-

world scenario.

6 CONCLUSIONS AND FUTURE

WORK

This paper presented a contribution to the fields of

Big Data Analytics and Cloud Software Architecture

of an emerging and unifying architectural pattern for

big data processing in the cloud. This pattern is based

on the use of big data frameworks, containers and

container orchestration technology for the

deployment of big data processing pipelines capable

of processing both batch and stream data. We

discussed how the issues of low portability and lack

of interoperability, identified as common

shortcomings of current cloud-based solutions, are

overcome by our proposed solution. We expect to

complete our Case Study evaluation of the proposed

architecture in the coming months.

Furthermore, we envision additional development

of the initial proposal to collect metrics related to

processing time from a data flow perspective. The

PaaS-BDP

aim is to develop a monitoring service to inform cloud

consumers of delays in the processing of windows of

data, thus highlighting the need to increase processing

capacity by scaling the system vertically (i.e. adding

more virtual machines to the pool). Correspondingly,

the monitoring service would gather information on

whether data is waiting too long to be processed, thus

suggesting the need to scale the system horizontally

(i.e. increase the number of containers running the

framework’s workers). This monitoring service from

a unique data flow perspective is also a contribution

to the field, and will be used to gather performance

metrics to further evaluate the architectural pattern

proposed in this paper.

ACKNOWLEDGEMENTS

This work made use of the Open Science Data Cloud

(OSDC) which is an Open Commons Consortium

(OCC)-sponsored project.

Cloud computing resources were provided by a

Microsoft Azure for Research award.

REFERENCES

Apache Beam (2017) Apache Beam [Online]. Available

from: <https://beam.apache.org/> [Accessed 28

February 2017].

Apache Beam Capability Matrix (n.d.) Apache Beam

Capability Matrix [Online]. Available from:

<https://beam.apache.org/documentation/runners/capa

bility-matrix/> [Accessed 9 August 2017].

Apache Storm - Project Information (n.d.) Project

Information [Online]. Available from:

<http://storm.apache.org/about/multi-language.html>

[Accessed 7 August 2017].

Bernstein, D. (2014) Containers and Cloud: From LXC to

Docker to Kubernetes. IEEE Cloud Computing, 1 (3)

September, pp. 81–84.

Celesti, A., Mulfari, D., Fazio, M., Villari, M. & Puliafito,

A. (2016) Exploring Container Virtualization in IoT

Clouds. In: 2016 IEEE International Conference on

Smart Computing (SMARTCOMP), May 2016. pp. 1–6.

Chen, H. M., Kazman, R., Haziyev, S., Kropov, V. &

Chtchourov, D. (2016) Big Data as a Service: A Neo-

Metropolis Model Approach for Innovation. In: 2016

49th Hawaii International Conference on System

Sciences (HICSS), January 2016. pp. 5458–5467.

Guillén, J., Miranda, J., Murillo, J. M. & Canal, C. (2013)

A UML Profile for Modeling Multicloud Applications.

In: Lau, K.-K., Lamersdorf, W. & Pimentel, E. ed.,

Service-Oriented and Cloud Computing, September 11,

2013. Springer Berlin Heidelberg, pp. 180–187.

Hindman, B., Konwinski, A., Zaharia, M., Ghodsi, A.,

Joseph, A. D., Katz, R., Shenker, S. & Stoica, I. (2011)

Mesos: A Platform for Fine-Grained Resource Sharing

in the Data Center. In: Proceedings of the 8th USENIX

Conference on Networked Systems Design and

Implementation, 2011. Berkeley, CA, USA: USENIX

Association, pp. 295–308.

Kogias, D. G., Xevgenis, M. G. & Patrikakis, C. Z. (2016)

Cloud Federation and the Evolution of Cloud

Computing. Computer, 49 (11) November, pp. 96–99.

MapReduce Tutorial (2013) MapReduce Tutorial [Online].

MapReduce Tutorial. Available from:

<https://hadoop.apache.org/docs/r1.2.1/mapred_tutoria

l.html> [Accessed 7 August 2017].

Martino, B. D. (2014) Applications Portability and Services

Interoperability among Multiple Clouds. IEEE Cloud

Computing, 1 (1) May, pp. 74–77.

Miell, I. & Sayers, A. H. (2015) Docker in Practice. Shelter

Island, NY: Manning Publications.

Okrent, M. D. & Vokurka, R. J. (2004) Process Mapping in

Successful ERP Implementations. Industrial

Management & Data Systems, 104 (8) October, pp.

637–643.

Resizing Your Instance - Amazon Elastic Compute Cloud

(2017) [Online]. Available from:

<http://docs.aws.amazon.com/AWSEC2/latest/UserGu

ide/ec2-instance-resize.html> [Accessed 24 July 2017].

Silva, G. C., Rose, L. M. & Calinescu, R. (2013) A

Systematic Review of Cloud Lock-In Solutions. In:

2013 IEEE 5th International Conference on Cloud

Computing Technology and Science, December 2013.

vol. 2. pp. 363–368.

Weave Net (2017) [Online]. Available from:

<https://store.docker.com/plugins/weave-net-plugin>

[Accessed 20 December 2017].

COMPLEXIS 2018 - 3rd International Conference on Complexity, Future Information Systems and Risk
