Using Tag based Semantic Annotation to Empower Client and REST

Service Interaction

Cong Peng and Guohua Bai

Department of Creative Technologies, Blekinge Institute of Technology, Karlskrona, Sweden

Keywords:

Web Service Description, Semantic Annotation, REST, OpenAPI, Service Discovery, Semantic Web Services.

Abstract:

The utilization of Web services is becoming a human labor consuming work as the rapid growth of Web. The

semantic annotated service description can support more automatic ways on tasks such as service discovery,

invocation and composition. But the adoption of existed Semantic Web Services solutions is hindering by their

overly complexity and high expertise demand. In this paper we propose a highly lightweight and non-intrusive

method to enrich the REST Web service resources with semantic annotations to support a more autonomous

Web service utilization and generic client service interaction. It is achieved by turning the service description

into a semantic resource graph represented in RDF, with the added tag based semantic annotation and a small

vocabulary. The method is implemented with the popular OpenAPI service description format, and illustrated

by a simple use case example.

1 INTRODUCTION

The Web is growing exceedingly, either for human or

for machines (Web APIs). It is, on the one hand, brin-

ging an imaginative utilization of the services on the

Web. On the other hand, it also brings about a pro-

blem that the utilization of Web services is becoming

a tediously repetitive work, such as search for servi-

ces required, read documents to know how to invoke,

and program similar clients to utilize services. Those

works currently are more of human labor-centered

works other than intelligence-centered works, which

they are supposed to be.

For enabling a more autonomous usage of Web

services, it requires the client to have a certain level

of capabilities for interpreting the resources, such as

the understanding of what the resources are and the

possible actions to the resources. And it should also

reduce coupling between client and service. There-

fore, a machine understandable service description is

important to facilitate a more autonomous Web ser-

vice utilization from discovery, invocation to compo-

sition.

However, there are very few semantic service des-

criptions available for the current Web services. The

reasons are multi-fold. The existed semantic service

description standards are lacking links to the actual

Web service development technology stack. It requi-

res extensive manual work to annotate or even recre-

ate the descriptions of existed Web services. Besides,

the attempt to achieve fully semantic understandable

at once made those solutions (Kopecký et al., 2007;

Vitvar et al., 2008) complicated and highly expertise

requisite, which caused the reluctant of application.

In this paper, we propose a method called Sem-

REST (Semantic RESource Tagging) to add semantic

annotations to REST service description in a simple

manner to make the client service interaction more

generic and autonomous. To mitigate the semapho-

bia (Lanthaler and Gütl, 2011), our approach aims to

avoid much knowledge requirement on Semantic Web

by adding tag based semantic annotations to the ser-

vice description, which will be presented with the wi-

dely used OpenAPI speciﬁcation

in a non-intrusive

way. An example case is presented to demonstrate

how this approach could work.

2 RELATED WORK AND

PROBLEM ANALYSIS

There have been extensive works done on both syn-

tactic description and semantic description to Web

services. Here we only discuss those works that have

strong inﬂuence and are considered most relevant to

the work in this paper.

https://swagger.io/speciﬁcation/

Peng, C. and Bai, G.

Using Tag based Semantic Annotation to Empower Client and REST Service Interaction.

DOI: 10.5220/0006682500640071

In Proceedings of the 3rd International Conference on Complexity, Future Information Systems and Risk (COMPLEXIS 2018), pages 64-71

ISBN: 978-989-758-297-4

The Semantic Annotations for WSDL and XML

Schema (SAWSDL) aims to add semantic annotati-

ons to a WSDL (Web Services Description Language)

document’s input/output message, interfaces and ope-

rations (Kopecký et al., 2007). An annotation me-

chanism is also deﬁned in SAWSDL to specify the

data mappting between XML Schema types and an

ontology. SAWSDL is regarded as a lightweight ap-

proach to annotate Web services described in WSDL,

and recommended by the World Wide Web Consor-

tium (W3C) in 2007.

As SAWSDL only provides a way to attach se-

mantic annotation in WSDL documents but without

the speciﬁcation and standardization of the concrete

service semantics, WSMO-Lite was then proposed to

model service semantics within the SAWSDL frame-

work (Roman et al., 2015). WSMO-Lite is a service

ontology inspired by the WSMO (Web Service Mo-

deling Ontology) ontology that uses SAWSDL as an-

notation mechanism. It deﬁnes a a lightweight set

of semantic service descriptions in RDFS (Resource

Description Framework Schema) to annotate WSDL

elements (Vitvar et al., 2008). WSMO is a top-down

conceptual model for semantic Web services, whereas

the WSMO-Lite is a bottom-up model to provide a

lightweight ontology (Dieter Fensel et al., 2010).

In addition, in order to combine the common RE-

STful Web services and WSDL-based services into

one semantic Web service framework, Roman et al.

added hRESTS (HTML format for describing REST-

ful Services) and MicroWSMO, the two HTML mi-

croformats mirror WSDL and SAWSDL, to work to-

gether with WSMO-Lite (Roman et al., 2015). In

which the WSDL and hRESTS work as the service

description layer, SAWSDL and MicroWSMO work

as the semantic annotation layer points to concepts

deﬁned in WSMO-Lite.

RESTdesc is RESTful Web services semantic des-

cription method with an emphasis on hypermedia

APIs. It describes service’s request preconditions,

postconditions and quantiﬁers in RDF/Notation3 to

enable a more automatic service composition (Ver-

borgh et al., 2011).

The Hydra framework is a set of technologies tries

to make semantic enriched Hypermedia API for Web

services to enable generic clients to consume services

. It is based on the Hydra Core Vocabulary, which is

a lightweight vocabulary that deﬁnes some fundamen-

tal concepts commonly used by Web APIs (Lanthaler

and Guetl, 2013).

These solutions enabled the semantic annotations

to service descriptions, but they suffer a problem that

denoted by Lanthaler et al. as Semaphobia (Lanthaler

http://www.hydra-cg.com

and Gütl, 2011). It requires too much knowledge on

Semantic Web to annotate with these solutions, which

causes the reluctant of application.

Another problem with these solutions is user un-

friendly. Though the semantic service description is

meant to be understood by machines, it requires hu-

man to create, with handy support tools and human

readable formats. This is why the description stan-

dards like OpenAPI Speciﬁcation, API Blueprint and

RESTful API Modeling Language (RAML) are be-

coming popular these years. OpenAPI Speciﬁcation

(widely known as Swagger) is a deﬁnition standard

proposed by Open API Initiative to describe RESTful

Web APIs

. OpenAPI is the mostly used syntactic

description format currently, thanks to its easy to use

editor and multiple languages supported code genera-

tion tools.

However, due to lack of machine understandable

semantics, these syntactic API descriptions are still

inefﬁcient for service consumers to discover the spe-

ciﬁc resources within the service in a more autono-

mous manner with a generic client. The work done

by Lucky et al. presented an approach to add seman-

tic annotation to the response data schema in an Ope-

nAPI description (Lucky et al., 2016). However, it

did not mention how can the service client be impro-

ved by the semantic annotation to a more automatic

way. And it is more an approach to empower static

service composition.

In this paper we try to use a tag based approach

to add semantic annotation to the popular and easy to

use OpenAPI Speciﬁcation, to achieve a more generic

and autonomous client service interaction in a extre-

mely simple manner, at the same time take advantage

of human readable description format and supporting

tools, and keep its simple to start, well-integrated to

the existing web service work/development ﬂow, ea-

sily achievable with minimal intrusion, to overcome

the Semaphobia.

3 SEMANTIC RESOURCE

TAGGING WITH OpenAPI

3.1 Semantic Tag Annotated OpenAPI

As the mostly used API description standard with a

tooling ecosystem for both API developing and con-

suming, we ﬁrstly implement the SemREST with the

OpenAPI Speciﬁcation. Here in Listing 1 is an ex-

ample OpenAPI description fraction of the activities

resource in YAML format (which is a path object in

https://swagger.io

Using Tag based Semantic Annotation to Empower Client and REST Service Interaction

paths:

# Resource1-2

/1/user/-/activities/calories/date/{base-date}/

{end-date}.json:,→

get:

summary: Get Activity Time Series

description: Returns time series data for activities

calories resource.,→

parameters:

- name: base-date

in: path

description: The range start date.

- name: end-date

in: path

description: The end date of the range.

responses:

200:

description: A successful request.

schema:

$ref: '#/definitions/CaloriesTS'

Listing 1: Service Description Fraction of a Fitbit Resource.

the OpenAPI description) from Fitbit service API

when the time this paper is writing, we modiﬁed a

little for brevity. Fitbit is a health and ﬁtness service

that offers wearable devices to track activity data and

hosts Web service to provide access to data

. And this

Fitbit service description will be used as an example

through out this paper.

As analyzed in the previous section, the current

OpenAPI service description lacks machine under-

standable semantics that can provide the meaning of

what the resource represents. So we propose to add

tag based annotation to the resource. For the sake of

not violating the standard OpenAPI speciﬁcation, the

semantic tag annotation will be added through speci-

ﬁcation’s built-in optional ﬁeld, tags. A list of tags to

each operation object in OpenAPI is one kind of ad-

ditional metadata, it is for the similar purpose as our

semantic tag.

A semantic tag comprises 2 parts, which are a pre-

ﬁx and a sufﬁx joint by a colon. The preﬁx is an

abbreviation of the used open vocabulary’s Interna-

tionalized Resource Identiﬁer (IRI) (M. Duerst and

M. Suignard. IETF, 2005), the sufﬁx is the term in

the used vocabulary to indicate the semantic meaning,

which is case sensitive aligned to those vocabularies.

The two parts as a whole is equivalent to the IRI of

the term. This way of expressing semantic tag follows

the abbreviation mechanism of OWL (Web Ontology

Language) (W3C, 2012).

The Listing 2 shows the semantic tag annotated

version of the resource shown in Listing 1. The only

difference, which is highlighted, is the additional tags

https://www.ﬁtbit.com

paths:

# Resource1-2

/1/user/-/activities/calories/date/{base-date}/

{end-date}.json:,→

get:

summary: Get Activity Time Series

description: Returns time series data in the

specified range for a given resource.,→

tags:

- schema:calories

- schema:activities

- schema:ConsumeAction

parameters:

...

responses:

...

Listing 2: Annotated Service Description Fraction of a Fit-

bit Resource.

tags:

- name: schema

description: the schema.org vocab

externalDocs:

url: http://schema.org

description: uri of the schema.org vocab

Listing 3: Used Vocabulary Stated as OpenAPI Tags Object.

list for a resource’s description. As in the OpenAPI

speciﬁcation, all the used tags could be declared in

a tags object under the OpenAPI root object, so as

these semantic tags. The second additional informa-

tion will be added to the plain OpenAPI description is

the IRI of each tag. The IRIs will be indicated by the

url ﬁeld of each tag object’s externalDocs object

under the root tags object. But for the simplicity, we

can just state the vocabularies used in the root tags

object (as shown in Listing 3), which is compatible.

For serving the annotated service description to

the client, an OPTIONS method under the service’s

root path / will be added to each service to respond

the service description (as shown in Listing 4). As

a method for describing the communication options

for a target resource in HTTP/1.1 speciﬁcation (R.

Fielding, J. Gettys, J. Mogul et al., 1999), it makes

OPTIONS method a good way for discovering related

resources for the target resource (Steiner and Alger-

missen, 2011). Since a service description contains

all the resources, which can be regarded as all the re-

lated resources to the root resource, it is natural to use

the OPTIONS method to retrieve the service descrip-

tion, as the same in (Lucky et al., 2016).

When the annotations are added, now we can ge-

nerate the semantic description of the resources to

RDF based on it and together with the OpenAPI

COMPLEXIS 2018 - 3rd International Conference on Complexity, Future Information Systems and Risk

paths:

# Resource1-1

options:

summary: Returns service description

produces:

- application/json

- application/ld+json

responses:

...

Listing 4: OPTIONS Method of Root Resource for Serving

Annotated Service Description.

model and a small SemREST mapping vocabulary,

which simply contains some mapping entities to be

expressed in RDF. Table 1 only lists the entities those

are necessary to generate the resource graph, a more

complete vocabulary can refer to the work done by

Musyaffa et al. (Musyaffa et al., 2016).

The generated RDF depicts the resource in the ser-

vice is presented Figure 1 as a graph. To be noted

that in Figure 1, the resource IRI is manually repla-

ced by a human readable name for readability. The

resource IRI in actual fact is identiﬁed by calculating

MD5 hash of the resource’s OpenAPI description path

string. With the semantic tags indicating what the re-

source represents, now we can use the semantic tags

to enable service client for the discovery of required

resources in the service by semantic inference. For

example in the case of different vocabularies are used

among different services and client but indicating the

same or similar entity, the client can infer all the re-

sources annotated in different different vocabularies

with the help of a simple ontology.

Figure 1: Resource Graph of a Fitbit Resource.

3.2 SemREST Framework

Since the server cannot predict what the client will

require for the next step, so many computations of

resource discovery will be done on the client side (re-

source URL query and inferring). Although it can be

processed also on the service or third party service re-

gistry for different purposes, we only demonstrate the

client side resource discovery in this paper.

The architecture of framework is shown in Figure

2, include the extended components to the ofﬁcial

OpenAPI framework, the server side of service, and

the client side with a semantic module. As we propose

to add tag based semantic annotations to the OpenAPI

service description, here we explain how the process

is for generating the semantic annotated service des-

cription.

Figure 2: Architecture of SemREST.

When the service developer completed the nor-

mal OpenAPI description, the semantic tag annota-

tions could be added. The annotated OpenAPI ser-

vice description could be registered to third party ser-

vice registries for enhanced semantic service disco-

very. Then the annotated OpenAPI description will

be served at the service’s root path via OPTIONS met-

hod in certain data exchange format, either JSON or

YAML.

The client contains an additional semantic mo-

dule, which is responsible for parsing service des-

cription into resource graph, and inferring for requi-

red resources. Firstly the the client need to register

what services it connects to by setting the service root

URL. The registration of services is a one time job,

and in the work of this stage, we leave aside the secu-

rity and authorization, but it is achievable with certain

OpenAPI objects. The client can retrieve the annota-

ted service description under the services’ root path

via OPTIONS method after registration meanwhile set-

Using Tag based Semantic Annotation to Empower Client and REST Service Interaction

Table 1: Named Entities Used in SemREST.

Name/Abbreviation Type Description

semrest:tag Class A semantic tag that annotates a resource

semrest:method Class A HTTP method that a resource supports

semrest:options Class A HTTP OPTIONS method, a subclass of semrest:method

semrest:get Class A HTTP GET method, a subclass of semrest:method

semrest:paths Class The paths of all resources in a OpenAPI description ﬁle

semrest:template Class An URL of a path, string value of a path object

semrest:hasResource Property To state a description of service contains which resources

semrest:hasTag Property To state the annotated semantic tags of a resource

semrest:hasMethod Property To state the supported HTTP method of a resource

ting required resources by semantic tags.

For generating a semantic resource graph, the re-

source graph generator component in the semantic

module will parse the annotated description together

with the small SemREST vocabulary into a RDF do-

cument, which could be in any RDF compatible for-

mat such as RDF/XML, JSON-LD or Turtle. The

generated resource graph, it can be used multiple ti-

mes and can be renewed when the service description

changed by retrieving a new version. When the se-

mantic resource graph is generated, the semantic in-

ferrer component can then query in the graph which

resources to request by the set semantic tags. The se-

mantic module of client can suggest which tags to use

under the same vocabulary as the services used, which

can reduce some inference work. When the required

resources are found, the metadata (URLs, parameters,

etc.) will be passed to the request module to send the

requests to the services.

4 FEASIBILITY OF SemREST

4.1 Tooling and Implementation

Our current proof-of-concept prototype is a very sim-

ple implementation supported by openly available

tools. The creation of the normal OpenAPI service

description is completed by the ofﬁcial Swagger on-

line editor

in YAML format. For the semantic tag

annotation, the vocabularies are searched via the Lin-

ked Open Vocabularies

, and the adding of semantic

tags is completed by Swagger editor as well. As the

process of creation and editing of service description

is only a text editing work, it could be achieved by

any text editor.

We implemented both the imitation services and

the client in Python. The imitation services, which

https://swagger.io/swagger-editor/

http://lov.okfn.org/dataset/lov/

implemented with Flask framework

, imitate how the

actual service receive requests and return responses

with fake data, and only include the resources that

appear in the example case in the next section. The

client is comprised by 2 modules, a REST service re-

quester and a semantic module. In our prototype, we

simply integratively use the Python client generated

by the Swagger CodeGen framework to handle the

service requests. The semantic module is built upon

the RDFLib

for a quicker implementation. Other-

wise, the Apache Jena

is a more powerful Semantic

Web framework that enables more functionalities like

inference API. Currently, we use the JSON format of

the annotated description ﬁle in the prototype, since

it is easier to transfer the description into a JSON-

LD document (Manu Sporny et al., 2014), which is

a concrete RDF syntax, by add the vocabularies as a

context object.

4.2 Example Case

Here we will use an example case to demonstrate how

the proposed SemREST can achieve a more autono-

mous and generic client service interaction in a sim-

ple and non-intrusive way. The example case involves

the forementioned Fitbit service and Human API ser-

vice. Human API is a health data platform that aggre-

gates clinical data from comprehensive sources such

as Electronic Health Record, health devices and wea-

rable devices, and makes data accessible as RESTful

API

The scenario is set as, a service consumer Alice

uses Fitbit service to record her activity data include

calories consumption, and uses a blood pressure mo-

nitor that the data of which can be consumed from

Human API. Alice wants her health agent client with

a semantic module can gather her data from the 2 ser-

http://ﬂask.pocoo.org/

http://rdﬂib.readthedocs.io

https://jena.apache.org/

https://www.humanapi.co/

COMPLEXIS 2018 - 3rd International Conference on Complexity, Future Information Systems and Risk

vices to have a comprehensive view of the health sta-

tus.

Although both Fitbit and Human API provide Web

APIs with documentations, the data are stored and

need to be retrieved separately, Alice still need to read

the two documents and develop two different client

programs in order to gather her data from the two

services. If both Fitbit and Human API can provide

their service description with semantic tag annotati-

ons as the approach proposed in this paper, then it

will reduce much repeated works. We will present

how the process will be for the two service providers

and Alice’s client.

Since it involves the service providers to serve

their services with description, and clients to inte-

ract with the services, so this example case consists

of 2 stage processes that are Semantic Service Des-

cription Generation and Serving, and Client Service

Interaction.

4.2.1 Description Generation and Serving

Firstly we will create the Fitbit SemREST service

description. Besides the activities’ calories consump-

tion resource shown in Section 3.1, the resource of

the foods’ calories intake data is also added to this

example. Since the original OpenAPI service descrip-

tion of Fitbit is already provided for API consumer (as

many other web service providers do), here we can di-

rectly add semantic tag annotations to the resources.

As we described in Section 3.1, the resource1-

2 is annotated from Listing 1 into Listing 2. The

only place we changed is the tags ﬁeld. We add tag

schema:calories

to resource1-2. Consider the ca-

lories data for activities can be regarded as consu-

ming, so we can add schema:ConsumeAction

resource 1-2. For the resource of the foods’ calories

intake data, which we call it resource1-3, the annota-

ted service description is shown in Listing 5. We add

tag schema:calories to it as well, and obviously tag

schema:FoodEvent

can be added to resource 1-3.

Combine these 2 annotated resources with Listing 3,

in which described the used schema vocabulary stated

in tags object, and Listing 4, in which described the

root resource path for serving service description, we

get the annotated SemREST description fraction to be

used in this example case.

Now we will create the Human API SemREST

service description. Since Human API has not provi-

ded API description in OpenAPI speciﬁcation yet, so

we need to compose its OpenAPI description imita-

http://schema.org/calories

http://schema.org/ConsumeAction

http://schema.org/FoodEvent

paths:

# Resource 1-3

/1/user/-/foods/log/caloriesIn/date/{baseDate}/{endDate}:

get:

tags:

- schema:calories

- schema:FoodEvent

responses:

...

Listing 5: Annotated Service Description Fraction of a Fit-

bit Resource.

tags:

- name: m3lite

description: The M3-lite Taxonomy

externalDocs:

url: http://purl.org/iot/vocab/m3-lite#

description: uri of the M3-lite Taxonomy

paths:

# Resource2-1

options:

summary: Returns service description

produces:

- application/json

- application/ld+json

responses:

...

# Resource 2-2

/v1/human/blood_pressure:

get:

summary: Returns the latest blood pressure reading

description: The latest blood pressure reading

tags:

- m3lite:BloodPressure

...

Listing 6: Annotated Service Description of Human API’s

Root and BloodPressure Resource.

ted from their API documentation ﬁrst. The imita-

ted OpenAPI description is shown in Listing 6, in

which the blood_pressure resource 2-2 is given the

semantic tag m3lite:BloodPressure

under The

M3-lite Taxonomy (Gyrard et al., 2016). As the same

in Fitbit description, the service description is served

under the path / via OPTIONS method.

4.2.2 Resources Look up and Request

Now we have the two services serving their re-

sources and service descriptions with semantic tag

annotation, Alice’s health agent client can start

to work. Alice will ﬁrstly tell her client where

the services are serving by setting the root URLs

of the 2 services, and then set what resour-

http://purl.org/iot/vocab/m3-lite#BloodPressure

Using Tag based Semantic Annotation to Empower Client and REST Service Interaction

Figure 3: Interaction Sequence of the Example Case.

ces she want to retrieve by setting semantic tags

schema:calories and schema:ConsumeAction to

the calories data she wants for her activities, and tag

m3lite:BloodPressure for her blood pressure data

she wants. Then the client starts to interact with the

services. It will ﬁrstly send OPTIONS request to the

two services’ root path to get their service descrip-

tions. Figure 3 depicts the client service interaction

process of the example case.

Once the client get the service descriptions, the se-

mantic module parses all the resources into a combi-

ned resource graph in RDF, which is shown in Figure

4 (the graph is simpliﬁed for brevity). The semantic

module can then reason about required resources by

the semantic tags set by Alice. So here the resource

templates of resource 1-2 and resource 2-2 are found

by schema:calories + schema:ConsumeAction

and m3lite:BloodPressure, respectively. Each re-

source’s path, parameters and other metadata in its

OpenAPI description will then be determined by re-

source templates and passed to the request module.

For the resource 1-1, the client requires baseDate and

endDate as parameters to retrieve the representation

form Fitbit service. With all the metadata and para-

meters of a service request being available, the ac-

tual HTTP request could be achieved in various ways.

In this example, we use the automatically generated

service client by the Swagger CodeGen framework to

send the requests.

After Alice’s health agent client get the calories

of activities data from Fitbit and blood pressure data

from Human API, it can then utilize them more com-

prehensively, simply like a graph to present the trend

and correlation between calories consumption and

blood pressure.

The interactions of client between Fitbit service

Figure 4: Combined Resource Graph of 2 Services.

and HumanAPI are achieved by the same client that

supported by the tag based semantic annotation in a

very simple way, without breaking the normal web

service interaction process.

5 CONCLUSION

In this paper, we proposed SemREST, an extremely

lightweight and non-intrusive method, to enable se-

mantics to resources of REST Web services. With

this initial work, we identify a simple and fully com-

patible way of adding tag based semantic annotations

to the widely used OpenAPI service description for-

mat. The small SemREST vocabulary we speciﬁed

COMPLEXIS 2018 - 3rd International Conference on Complexity, Future Information Systems and Risk

together with the tag annotation mechanism provide a

bridge from the syntactic OpenAPI description to the

semantic resource graph, which enables a more ge-

neric and automatic client service interaction that can

reduce many repeated human labor consuming work.

The method we proposed also provide the potential

for service discovery and composition, as the resour-

ces of the annotated services are semantically linked.

The semantic resource graph could be generated and

host on service side or third party service registry for

the clients to query required resources.

However, in this initial work, we only realized the

GET method for resources to make it as a data ag-

gregation agent for different sources. And we only

shown some naive cases to demonstrate this method,

it leaves the authorization and security issues out for

the sake of briefness.

For the future work, we plan to validate this met-

hod with more different services and realize other

HTTP methods like POST and PUT, and evaluate the

usability by performing survey with Web service pro-

viders and consumers. For the invoking and compo-

sition of services, it could be achieved in 2 difference

approaches, one is the code automatic generation like

OpenAPI framework provided, the other is the seman-

tic way like what Hydra (Lanthaler and Guetl, 2013)

is trying to do. We will try to explore how our method

can integrate with approach like Hydra.

REFERENCES

Dieter Fensel, Florian Fischer, Jacek Kopecký, Reto

Krummenacher, Dave Lambert, and Tomas

Vitvar (2010). WSMO-Lite: Lightweight Se-

mantic Descriptions for Services on the Web.

https://www.w3.org/Submission/WSMO-Lite/.

Accessed: 2017-09-19.

Gyrard, A., Gomez, D., Bajaj, G., Lanza, J., San-

chez, L., Agarwal, R., and Elsaleh, T. (2016).

The M3-lite Taxonomy. http://ontology.ﬁesta-

iot.eu/ontologyDocs/ﬁesta-iot/doc. Accessed: 2017-

09-19.

Kopecký, J., Vitvar, T., Bournez, C., and Farrell, J. (2007).

SAWSDL: Semantic Annotations for WSDL and

XML Schema. IEEE Internet Computing, 11(6):60–

67.

Lanthaler, M. and Guetl, C. (2013). Hydra: A Vocabu-

lary for Hypermedia-driven Web APls. In Procee-

dings of the 6th Workshop on Linked Data on the Web

(LDOW2013) at the 22nd International World Wide

Web Conference. CEUR.

Lanthaler, M. and Gütl, C. (2011). A semantic descrip-

tion language for RESTful Data Services to combat

Semaphobia. In 5th IEEE International Conference

on Digital Ecosystems and Technologies (IEEE DEST

2011), pages 47–53.

Lucky, M. N., Cremaschi, M., Lodigiani, B., Menolas-

cina, A., and De Paoli, F. (2016). Enriching API

Descriptions by Adding API Proﬁles Through Se-

mantic Annotation. In International Conference on

Service-Oriented Computing, pages 780–794. Sprin-

ger, Cham.

M. Duerst and M. Suignard. IETF (2005). RFC

3987: Internationalized Resource Identiﬁers (IRIs).

http://www.ietf.org/rfc/rfc3987.txt. Accessed: 2017-

08-15.

Manu Sporny, Dave Longley, Gregg Kellogg, Markus Lant-

haler, and Niklas Lindström (2014). JSON-LD 1.0.

https://www.w3.org/TR/json-ld/. Accessed: 2017-08-

08.

Musyaffa, F. A., Halilaj, L., Siebes, R., Orlandi, F., and

Auer, S. (2016). Minimally Invasive Semantiﬁcation

of Light Weight Service Descriptions. In 2016 IEEE

International Conference on Web Services (ICWS),

pages 672–677. IEEE.

R. Fielding, J. Gettys, J. Mogul, H. F., L. Masinter, P. Leach,

and Berners-Lee, T. (1999). Hypertext Transfer Pro-

tocol – HTTP/1.1. http://tools.ietf.org/html/rfc2616.

Roman, D., Kopecký, J., Vitvar, T., Domingue, J., and

Fensel, D. (2015). WSMO-Lite and hRESTS: Lig-

htweight semantic annotations for Web services and

RESTful APIs. Web Semantics: Science, Services and

Agents on the World Wide Web, 31:39–58.

Steiner, T. and Algermissen, J. (2011). Fulﬁlling the hy-

permedia constraint via HTTP OPTIONS, the HTTP

vocabulary in RDF, and link headers. In Proceedings

of the Second International Workshop on RESTful De-

sign - WS-REST ’11, page 11, New York, New York,

USA. ACM Press.

Verborgh, R., Steiner, T., Van Deursen, D., De Roo, J.,

de Walle, R., and Gabarró Vallés, J. (2011). Des-

cription and Interaction of RESTful Services for Au-

tomatic Discovery and Execution. Proceedings of the

FTRA 2011 International Workshop on Advanced Fu-

ture Multimedia Services.

Vitvar, T., Kopecký, J., Viskova, J., and Fensel, D. (2008).

WSMO-lite annotations for web services. In ESWC

2008: The Semantic Web: Research and Applications,

pages 674–689, Berlin, Heidelberg. Springer Berlin

Heidelberg.

W3C (2012). OWL 2 Web Ontology Language Struc-

tural Speciﬁcation and Functional-Style Syntax (Se-

cond Edition). https://www.w3.org/TR/2012/REC-

owl2-syntax-20121211/#IRIs. Accessed: 2017-09-08.

Using Tag based Semantic Annotation to Empower Client and REST Service Interaction
