SEPL: An IoT Platform for Value-added Services in the Energy

Domain

Architectural Concept and Software Prototype

Theo Zschörnig

, Robert Wehlitz

, Ingo Rößner

and Bogdan Franczyk

2,3

Institute for Applied Informatics (InfAI), Leipzig University, Hainstr. 11, 04109 Leipzig, Germany

Information Systems Institute, Leipzig University, Grimmaische Str. 12, 04109 Leipzig, Germany

Business Informatics Institute, Wrocław University of Economics, ul. Komandorska 118-120, 53-345 Wrocław, Poland

Keywords: Internet of Things, Value-added Services, Platform Architecture.

Abstract: The Internet of Things (IoT) is based on ubiquitous smart devices equipped with sensors, actuators and tags

which are connected to the Internet. Combining their sensing and actuation capabilities yields large

possibilities for businesses to provide customers with value-added services in terms of energy management,

entertainment, security and convenience. Businesses may use IoT data to develop innovative business models

thus further increasing the value and usefulness of smart devices. Despite these potentials, providers of IoT

platforms struggle to tackle some challenges which come with the design and operation of the platforms. In

this paper, we propose an architectural concept which aims to bridge this gap and provides an integrated

environment for smart device integration, data and analytics as well as IoT-aware processes. We also present

the Smart Energy Platform (SEPL) as an instantiation of the proposed concept to evaluate it in terms of its

functional feasibility and show that it addresses the issues current IoT platforms face.

1 INTRODUCTION

The Internet of Things (IoT) comprises smart devices

equipped with sensors, actuators, and tags which are

or attached to real-world objects and connected to the

Internet (Han et al., 2016). The number of smart

devices is estimated to reach 24 billion by the year

2020 (Greenough, 2016). This increase is

accompanied by huge amounts of data which offer

new possibilities for businesses to provide

value-added services for their customers.

In the energy domain, current and future trends,

such as smart metering, smart home, e-mobility and

smart grid are summarized under the umbrella term

smart energy (Aichele et al., 2013). In this context,

smart devices, which provide sensing and actuation

capabilities, are already used to gather energy data

and respond to changing circumstances, e.g. in the

case of demand-side management of energy

consumption. IoT platforms are a means to

interconnect distributed smart devices, use their

exposed services to create more sophisticated

services with added value and to build applications

upon them. Against this background, previous

research has found that current IoT platforms are

lacking important features for device integration, data

and analytics, as well as IoT-aware processes

(Wehlitz et al., 2017).

In this light, the main contribution of this paper is

an architectural concept for an IoT platform, which

bridges this gap. We furthermore present a software

prototype of a Smart Energy Platform (SEPL) as an

instantiation of the proposed concept in order to

evaluate its functional feasibility.

In this paper, we describe the motivation for

conducting this research (Sect. 2). Following, we

highlight the major challenges and state of the art for

designing and operating IoT platforms (Sect. 3). In

Sect. 4, we introduce our architectural concept, which

is divided into the three technical layers: Integration,

data and analytics, and IoT-aware processes.

Afterwards, we present the SEPL software prototype

to show in which way the components of each layer

are implemented and how they address the identified

challenges (Sect. 5). Finally, the paper concludes with

a short summary and outlook (Sect. 6).

Zschörnig, T., Wehlitz, R., Rößner, I. and Franczyk, B.

SEPL: An IoT Platform for Value-added Services in the Energy Domain.

DOI: 10.5220/0006695205930600

In Proceedings of the 20th International Conference on Enterprise Information Systems (ICEIS 2018), pages 593-600

ISBN: 978-989-758-298-1

593

2 MOTIVATION

The growing number of smart devices offers many

benefits for people in different areas of their everyday

life, such as energy management, entertainment,

security, and convenience (Zion Market Research,

2017). However, smart devices, in comparison to

regular devices, do not offer a notable advantage in

possibilities if the provided data and actuation

capabilities are not utilized. Therefore, services

which use the aforementioned capabilities are

required in order to create customer value around

products like smart meters, smart thermostats, smart

lights, etc.

Especially in the energy domain, utilities have to

develop new service offers and business models due

to low energy prices and high dues. In this context,

expert interviews revealed that utilities’ margin for

electricity supply in Germany is between 10 and 20

euros per household per year. Hence, with the

comprehensive rollout of smart meters and the

increasing adoption of smart devices, such businesses

have the chance to provide services which, in addition

to the pure energy supply, add value to their

customers and enable new sources of income.

Possible fields of application could be, but should not

be limited to, the increase of energy consumption

transparency, energy savings, and energy efficiency

in households.

Against this background, we found that IoT

platforms are an important building block to provide

the infrastructure and software tools necessary to

develop and run value-added services in the energy

domain. They can be used to integrate smart devices

of customers, e.g. smart meters, process and analyse

sensing data, e.g. energy consumption values, and

create more sophisticated services by service

composition and individualisation, for instance, to

control household appliances in an energy efficient

manner.

3 STATE OF THE ART

Recent studies analyzing IoT platforms have

identified multiple challenges for their design and

operation. These are usually separated into a

functional and non-functional dimension (Wehlitz et

al., 2017).

On the side of the functional challenges, data

management, service abstraction, marketplace

functionality, and device and service discovery are

most significant.

The area of non-functional challenges for IoT

platforms contains interoperability, privacy and

security, scalability, quality of service and context

awareness.

With regard to these challenges, there are many

existing approaches from businesses, the open source

community as well as researchers which have

different degrees of coverage (Wehlitz et al., 2017).

Concerning the functional challenges, most platforms

use service abstraction for providing a unified access

to smart devices. Data management and device and

service discovery are implemented only partly by

some platforms. More importantly, a marketplace is

missing in almost all of them.

On the side of the non-functional challenges,

context awareness is implemented by almost all

platforms. Yet, the integration of smart devices of

different vendors with distinct service interfaces, i.e.

interoperability, is supported only in part. Also, the

bulk of the regarded platforms do not fully support

scalability which seems to be a major issue with rising

smart device numbers. Quality of service and privacy

and security are also challenges which are only partly

solved (Wehlitz et al., 2017).

It is noteworthy, that two platforms we have

studied, FIWARE and ThingWorx, address most of

the found challenges. However, both are extensive

systems, exhibiting high complexity, a steep learning

curve or they are proprietary. Hence, it seems

plausible that they are not suitable to be used directly

by customers.

4 PLATFORM ARCHITECTURE

Looking at the challenges and the state of the art as

described in Sect. 3, we found the basic design of an

IoT platform should comprise three layers:

• An integration layer providing bidirectional

platform-to-device communication as well as

tools to unify device and service access.

• A data and analytics layer providing smart

device data management, but also means to

analyze and filter data.

• An IoT-aware process layer to enable the

composition and orchestration of IoT and

analytics services into more useful services and

applications.

Additionally, a marketplace should be offered to

platform users allowing them to share created content

in order to bring the platform to life. Another

important design goal for us is to make the entire

platform loosely coupled and easily extensible. This

requires

a unified, resilient way of communication

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

594

Figure 1: Components of the integration layer and their interactions.

between the different system components. The

proposed concept employs a streaming platform to

achieve this.

4.1 Integration Layer

The integration layer is the foundation of the

proposed platform concept. It acts as the main point

of integration for different kinds of smart devices.

Therefore, the layer must provide interfaces for them

to send and receive data.

In the context of smart home and smart building

environments, smart devices are often connected to a

local gateway (Risteska Stojkoska and Trivodaliev,

2017). In this regard, the platform operator needs to

provide either best practices for end users on how to

configure their gateway device or, more commonly,

find ways to enable inbound network traffic

automatically. In this regard, they have to provide

software for different gateway types in order to

platforms.

As shown in

Figure 1, we use platform connectors

in conjunction with client connectors to achieve this.

Client connectors are deployed either on gateways (1)

or on stand-alone smart devices (2). Supporting

various message protocols (e.g. HTTP, WebSocket,

CoAP), they send data to their counterparts, i.e.

platform connectors. These receive the data and push

it to the central streaming platform (3) for further

processing by other IoT platform services.

Publish-subscribe communication (e.g. based on

MQTT) (4) via an intermediary broker (5) is also

possible. Besides the actual communication with

smart devices, platform connectors gather historical

data about connection states of client connectors, e.g.

time of disconnect. They also handle the outgoing

data, meaning service requests, to the client

connectors. These requests are pushed to the

streaming platform by IoT platform services and

applications. The platform connectors interface the

streaming platform, fetch new service requests (6),

and proceed in sending the data to the destined client

connector. In addition, platform connectors register,

unregister and update device and service instance data

in the device and service repository (7). It contains

device and service type descriptions as well as device

instances with their service instantiations.

Since the IoT domain has not yet undergone

successful standardization efforts (Díaz et al., 2016),

it is characterized by a large heterogeneity in terms of

data types, semantics and protocols, which

complicates access to their services (Perumal et al.,

2015; Díaz et al., 2016). Therefore, it seems

appropriate to transform different data types and

structures as well as semantics to a unified basis. In

our proposed concept, this is done by the platform

connectors. They map data structures of smart

devices to a generic data model, thus enabling

platform wide understandability and reusability

across different services and applications.

In this model, a device type is a collection of

comparable devices (e.g. Temperature Sensor),

which contains services (e.g. getTemperature).

Transforming data structures of smart devices into the

generic data model ensures that all data, which is

queued in the streaming platform, is already unified.

This approach also leads to reusability of value types,

since they are used frequently to create services in the

platform environment. Also, data structures using this

data model are independent from specific

serialization

formats. Hence, the layers on top of the

integration layer are able to create processes and

applications with high reusability across smart

devices.

IntegrationLayerIntegrationLayer

Platform

Connector

Platform

Connector

Deviceand

ServiceRepository

Deviceand

ServiceRepository

Streami ng

Platform

Streami ng

Platform

EdgeDe vi ceEdgeDe vi ce

BrokerBroker

Edge/MobileDe vi ceEdge/MobileDe vice

Cli entConnectorCli entConnector

EdgeDe vi ceEdgeDe vice

GatewayGateway

Cli entConnectorClientConnector

SEPL: An IoT Platform for Value-added Services in the Energy Domain

595

Figure 2: Components of the data & analytics layer and their interactions.

4.2 Data & Analytics Layer

The data and analytics layer is on top of the

integration layer and provides sophisticated data

manipulation, analytics, persistence and event

processing functionalities. Smart device data usually

arrives in data streams and is characterized as time

series data, thus creating the need for real-time

processing (Pawar and Attar, 2016). While the batch

processing of historical data combined with the

application of prediction models on this data is

already established, real-time processing of smart

device data enables the detection of causable

relationships between the devices themselves and

their environments. This may lead to the autonomous

adaption to new situations (Stolpe et al., 2016). As a

result, the analytics layer should be a lightweight

stream processing system which is able to easily

access the central streaming platform with the smart

device data, as shown in

Figure 2. Also, it is necessary

to provide capabilities to design analytics flows for

large amounts of different analytics problems.

In order to process data, we utilize analytics

operators which perform analytics actions on data

streams (e.g. Temperature Unit Conversion). These

operators are lightweight and perform a single task.

They may be composed into complex analytics flows,

thus providing the needed flexibility in analytics

design. Analytics operator metadata is stored in the

analytics operator repository and comprises inputs

(e.g. Temperature #1: float, Unit: string), outputs (e.g.

ConvertedTemperature: float), and configuration

parameters (e.g. ConversionUnit: string).

A flow designer is used to graphically design and

orchestrate input streams and analytics operators into

analytics flows, using operator metadata (1). Finished

analytics flows (e.g. Temperature Unit Conversion

and Mean Value) are saved into the flow repository

(2) and may contain multiple analytics operators and

data streams as input. A flow exposes inputs (e.g.

Temperature #1: float, Unit #1: string, Temperature

#2: float, Unit #2: string), outputs (e.g.

MeanTemperature: float) and configuration items

(e.g. ConversionUnit: string) for all analytics

operators used. Analytics flows are started (3) and

monitored (4) using a flow executor. In addition, the

flows are linked to smart device services data (5) as

input streams.

The analytics operators pull the data from the

streaming platform (input topic #1), process it and

push it back (output topic #1) (6). Analytics operators

linked to them in an analytics flow, pull their input

data from the data pushed back (output topic #1) and

continue in the same manner as the previous analytics

operators. In order to achieve data persistence, all

data streams need to be pulled from the streaming

platform into a Data Lake (7). Following the Data

Lake paradigm, they are saved as they are without

further processing. Once the saved data is needed by

platform services, it is pushed back into the streaming

platform.

Another key aspect of the data and analytics layer is

event processing. An event processing engine is

consuming data streams and triggers events if defined

event rules are met (8). We describe events at type

(e.g. value > 22) and instance level (e.g. temperature

value

from Temperature Sensor #1 > 22 °C). Events

are defined using an event rule designer and event

rules are stored in the event rule repository (9). The

event processing engine listens for all event rules

(10). These may be applied to all data streams present

in the streaming platform (e.g. smart device data,

analytics data, process data, etc.). In this regard, the

event rule designer may also access the analytics flow

repository to expose analytics flows to the user which

may be used to listen on for event detection (11).

Streaming

Platform

Streaming

Platform

StreamProcessingSystemStreamProcessingSystem

Analytics

Operator

Analytics

Operator

FlowExecutorFlowExecutor

Analytics

Operator

Reposit ory

Analytics

Operator

Reposit ory

FlowDe si gne rFlowDe si gne r

FlowRepositoryFlowRepository

Even t

ProcessingEngine

Even t

ProcessingEngine

Even tRule

Designer

Even tRule

Designer

EventRule

Reposit ory

EventRule

Reposit ory

Deviceand

ServiceRe pository

Deviceand

ServiceRe pository

Event

ProcessingEngine

Event

ProcessingEngine

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

596

Figure 3: Components of the IoT-aware process layer and their interactions.

4.3 IoT-Aware Process Layer

The IoT-aware process layer bundles the

functionalities of the integration as well as the data

and analytics layer. It serves the orchestration of IoT

services, analytics and event data along businesses,

smart devices and customers. The layer is based on a

centralized orchestration model and allows for the

modelling, implementation and execution of

IoT-aware processes.

As illustrated in Figure 3, processes are designed

using a process designer, which includes a graphical

user interface and stores created process models in the

process repository (1). It has access to device and

service types from the device and service repository

(2) together with event rule types from the event rule

repository (3). Hence, processes are designed using

abstract device, service and event definitions. This

allows for processes which are instance-independent

and therefore easily reusable. In addition, the same

model can be deployed for different smart devices

multiple times. Executable process models are

deployed by the process deployment component. It

pulls model definitions from the process repository

(4) and scans it for references to device/service and

event types. If any are present, it retrieves compatible

instances from the device and service repository (5).

User input is required to select which concrete

devices and services shall be used for a process

deployment. Event types are handled in the same

manner. After this, the process model is deployed to

the process engine, which ensures proper execution

(6). External task workers execute service tasks. Once

the process engine encounters a service task (e.g.

smart device actuation), it creates a new job for the

external task workers to be pulled and executed.

When they completed their jobs, they notify the

process engine which proceeds to the next step (7). In

case of an actuation service, an external task worker

fetches the required service description from the

device and service repository and sends a service

request to the streaming platform (8), which in turn is

accessed by platform connectors. A platform

connector forwards the service request to the client

connector which executes it or relays it to the actual

smart device.

Sensing requests get relayed back from the device

to the client connector to the platform connector

which pushes the sensing data to the streaming

platform. From there, events are, if applicable,

applied by the event processing engine on the data

stream. The process engine is able to process fired

events and act according to the executed process

model (e.g. to start a new or to affect the control flow

of a running process instance). The process engine is

supervised by the process monitoring component,

which provides insights to historical and operational

data of process instances (9). Finally, the execution of

processes may be integrated in external applications

using a REST API (e.g. a mobile application to trigger

new process instances) (10).

4.4 Marketplace

The marketplace allows customers to share their data,

modeled IoT-aware processes, analytics flows and

operators with other platform users (businesses and

customers). All content created by customers and

businesses as well as data streams originating from

smart devices may be accessed as defined in the

Proc essEngineProcessEngine

Process

Repository

Process

Repository

Proces s

Designer

Proces s

Designer

External

Tas kWorker

External

Tas kWorker

Proces s

Monitoring

Proces s

Monitoring

Event

Processing

Engine

Event

Processing

Engine

Device

andService

Repository

Device

andService

Repository

Streaming

Plat form

Streaming

Plat form

Proces s

Deployment

Proces s

Deployment

Ret rieveDeviceand

ServiceTy pes

Ret rieveDeviceand

ServiceTy pes

Ret rieveDevice

andService

Instances

Ret rieveDevice

andService

Instances

Fetch/CompleteTa sksFetch/CompleteTa sks

Ret rieve

Process

InstanceData

Ret rieve

Process

InstanceData

Apply

Even tRules

Apply

Even tRules

Deploy

ProcessModel s

Deploy

ProcessModel s

Save/Load

ProcessModels

Save/Load

ProcessModels

Ret rieve

ProcessModels

Ret rieve

ProcessModels

Inv ok eServicesInv ok eServices

TriggerEventsTriggerEvents

Third‐

pa rty

IoTApplication

Third‐

pa rty

IoTApplication

External

Interface

Event

Rule

Repository

Event

Rule

Repository

StartEventRule

Instances

StartEventRule

Instances

Ret rieveEv entRu leTypesRet rieveEv entRu leTypes

Ret rieveEv ent

RuleInstances

Ret rieveEv ent

RuleInstances

Send

Req uests

Send

Req uests

Event

RuleDesigner

Event

RuleDesigner

Save/Load

EventRuleTy pes

Save/Load

EventRuleTy pes

SEPL: An IoT Platform for Value-added Services in the Energy Domain

597

permission system. This system links user instances

to processes, flows, operators, and device instances

from the respective repositories. Customers and

businesses are able to share their content and device

data and publish them at the marketplace. The access

to the shared entities may be limited to individual

customers or businesses or groups of them. Also, a

fee for using the entities may be applied. If other

customers or businesses decide to subscribe to

content or device instances, the required permissions

are set in the permission system.

Granting permission to content allows the

subscriber to use the flow, operator or process with

their own smart devices. In case of a shared smart

device, the subscriber may access emitted data from

the device as set by the owner. In this context, using

the actuation capabilities of a shared device is

generally forbidden because of security concerns.

5 PROTOTYPE

In order to provide a proof of concept of our

architecture presented in Sect. 4, we implemented all

system components as an integrated cloud-based

software prototype, the SEPL. Its purpose is to

provide platform tools to customers, to integrate their

smart devices, analyze their data and develop and use

IoT-aware processes for energy management

scenarios. Also, customers may share their data with

businesses, which in turn are provided with tools to

develop value-added services around this data,

creating surplus value.

The platform architecture is based on the concept

of Microservices, meaning that functionalities are

encapsulated as single services by software

containers, in our case using Docker

(https://www.docker.com/). This provides easy

scalability of services which undergo heavy usage

and enables easy change or substitution of services

with changed requirements. Because of this, we

employed Apache Kafka as a central streaming

platform (https://kafka.apache.org/). To ensure

usability, we also developed a front-end application

using AngularJS which provides access to important

platform tools. User authentication and authorization

is ensured using the API gateway Kong

(https://getkong.org/) in conjunction with a user

repository and permission system. In order to further

strengthen privacy and security we followed the

“Privacy by Design” and security principles as

pointed out in scientific literature (Schaar, 2010;

Dougherty et al., 2009).

Because of the complex structure and the

Microservice approach of the platform architecture, it

is necessary to employ a powerful container

orchestration and scheduling service. We use Rancher

(http://rancher.com/) as it is easy to use and offers

many out-of-the box features for platform operation.

5.1 Integration Layer

The main focus when implementing the integration

layer, was to provide interfaces to enable

communication between smart devices and the SEPL,

but also to unify device and service descriptions from

different vendors. Although the layer components are

designed to be easily extendable in terms of protocol

and device integration, a lot of the smart devices we

use in our laboratory environment for testing our

approach support the wireless communication

standards ZigBee and Z-Wave. Both are very

common and well suited for home energy

management scenarios (Zhao et al., 2016).

The client connectors in smart home and smart

building environments are provided in two ways: As

plugins for already existing IoT gateways and as

software libraries to be used for single smart devices

by more advanced users. When deployed at IoT

gateways, it is possible to use existing resources of

them to search for locally connected smart devices

and send this information to the SEPL, as the

foundation for their integration.

The platform connector is scalable in order to

being able to communicate with huge numbers of

smart devices. It uses the device and service

descriptions from the device and service repository to

transform data from client connectors to the generic

data model as explained in Section 4.1.

The device and service repository is based on

Virtuoso (https://virtuoso.openlinksw.com/) and

utilizes RDF for schema description. Other services

can access the data from the device and service

repository using a REST interface. Since it also stores

all registered device instances, it enables platform

services and users to discover smart devices and their

services. Internally, it queries the RDF database using

SPARQL, therefore enabling powerful queries.

5.2 Data & Analytics Layer

The analytics concept we employ is based on the

Kappa architecture, meaning all data is handled as a

stream. Therefore, analytics operators use the Kafka

Streams (https://kafka.apache.org/) library to

integrate with the streaming platform and are written

as individual Microservices, which are encapsulated

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

598

using Docker. Using JAVA or Python, it is possible

to create powerful data analytics as well as machine

learning algorithms for processing. This allows for

flexible analytics operators which offer the same

capabilities as stream processing engines like Apache

Spark Streaming or Apache Storm. In addition, this

approach helps in reducing the programming

overhead caused by changing data models and

analytics requirements, compared to a Lambda

architecture (Zschörnig et al., 2017).

New analytics flows are created with the help of

the analytics designer, which interfaces the analytics

operator repository. In our prototype, the designer

utilizes a flow chart visualization to enable users to

design new analytics flows, which are saved in the

flow repository.

The request to start an analytics flow is send to the

flow executor, which checks it for errors. If the flow

is valid, it starts the analytics operator Docker

containers in the required order with the necessary

input, output and configuration values. The analytics

operator containers are deployed on the underlying

orchestration and scheduling environment. Data

persistence is achieved by pulling all data streams

from Apache Kafka into the Data Lake which uses a

HDFS environment. Platform services may request

data from the Data Lake, which pushes it back into

Apache Kafka.

Event rules are stored in the event rule repository

and are created using a JSON document which

contains information on the data stream to be

monitored and the actual rule. A rule is written by

combining service fields from the device and service

repository and logical expressions using the event

rule designer.

5.3 IoT-Aware Process Layer

The process designer component of our software

prototype is based on bpmn.io, a BPMN 2.0 rendering

toolkit and web modeler (https://bpmn.io), which was

extended to integrate with the device and service

repository. We selected BPMN 2.0 because it seems

to be the best suited modeling language for mapping

IoT concepts in processes (Meyer et al., 2011).

Following Meyer et al., 2013, our solution intends

that IoT-aware processes are modeled within BPMN

pools. The lanes of a pool represent device types.

Each service task that is placed on a lane is assigned

to and handled by the respective device type.

In case of a new deployment, the process

deployment component analyses the process

definition and prompts the user to select concrete

instances for every found event and/or device type. It

then deploys the process model to the process engine,

which is based on the open-source platform Camunda

(https://camunda.org). This supports the external task

pattern and, hence, provides more flexibility and

scalability for executing service tasks. The

implementation of external task workers is

independent from a specific programing language and

additional source code for service task execution has

not to be deployed to and executed by the process

engine. Additionally, in conjunction with the event

processing engine and the stream processing system,

the process engine enables context awareness. In this

regard, the stream processing system provides new

insights into smart device data and the event

processing engine is able to define actions based on

changing parameters. IoT-aware processes may

include this information, thus allowing smart devices

to be “aware” of their surroundings and adapt to

changing environments.

5.4 Marketplace

The main objective of the marketplace is to allow

users (customers and businesses) of the SEPL to

easily share and subscribe to processes, analytics

operators and flows. In this regard, users of the SEPL

may define if a process, analytics flow or operator

may be published at the marketplace or only be shared

with a single user or a group of users. If it is published

at the marketplace, a request is sent to its repository,

which then lists it in the appropriate category. This

categorization is based on the type of the shared entity

(e.g. process vs. operator) and its characteristics (e.g.

inputs, outputs, purpose, etc.).

In conclusion, the marketplace offers various

capabilities to share key entities of the SEPL, thus

enabling device integration through sharing, but most

important it is the key component to enable

businesses to apply new business models around

smart devices in the energy domain.

6 CONCLUSION & OUTLOOK

In this paper, we presented an architectural concept

for the design and operation of IoT platforms.

Customers may use its tools to integrate and

orchestrate their smart devices and gain insights into

their data, whereas businesses use them to create new

applications and value-added services on top of the

customer-specific data.

The proposed concept takes into account

functional and non-functional challenges which were

identified by current research and are not met entirely

SEPL: An IoT Platform for Value-added Services in the Energy Domain

599

by existing solutions. Looking at these challenges, we

found that an IoT platform should comprise technical

layers for device and service integration and

abstraction as well as their discovery, but also

capabilities for data management and analytics and

IoT-aware process modeling, implementation and

execution. Furthermore, customers and businesses

need to be able to share device data access and

processes with other users of the platform through a

marketplace. The composition of all these platform

components leads to quality of service regarding the

communication with smart devices and context

awareness in terms of their environment.

Future research in this field needs to focus on the

advanced use of semantic technologies for device

integration as well as device and service discovery.

Analytics architectures have to be developed to cater

to a non-technical audience, allowing self-service

analytics. In terms of IoT-aware processes, tools for

adaptive case management should be investigated to

improve context awareness and flexibility. Also,

business models on how to operate this kind of

platform need to be created and evaluated. Finally,

the research concerning hybrid approaches on IoT

platforms, e.g. in conjunction with Fog Computing,

needs to be deepened.

ACKNOWLEDGEMENTS

The work presented in this paper is partly funded by

the European Regional Development Fund (ERDF)

and the Free State of Saxony (Sächsische Aufbaubank

— SAB)

REFERENCES

Aichele, C., & Doleski, O. D. (Eds.). (2013). Smart Meter

Rollout - Praxisleitfaden zur Ausbringung intelligenter

Zähler. Wiesbaden: Springer Vieweg.

Díaz, M., Martín, C., & Rubio, B. (2016). State-of-the-art,

challenges, and open issues in the integration of Internet

of things and cloud computing. Journal of Network and

Computer Applications, 67, (pp. 99–117).

Dougherty, C., Sayre, K., Seacord, R. C., Svoboda, D., &

Togashi, K. (2009). Secure Design Patterns. Retrieved

from http://www.dtic.mil/get-tr-doc/pdf?AD=ADA636

498

Greenough, J. (2016). How the 'Internet of Things' will

impact consumers, businesses, and governments in

2016 and beyond. Retrieved from

http://www.businessinsider.com/how-the-internet-of-

things-market-will-grow-2014-10?IR=

Han, S. N., Khan, I., Lee, G. M., Crespi, N., & Glitho, R.

H. (2016). Service composition for IP smart object

using realtime Web protocols: Concept and research

challenges. Computer Standards & Interfaces, 43, (pp.

79–90).

Meyer, S., Ruppen, A., & Magerkurth, C. (2013). Internet

of Things-Aware Process Modeling: Integrating IoT

Devices as Business Process Resources. In D.

Hutchison, T. Kanade, Ó. Pastor (Eds.), Lecture Notes

in Computer Science. Advanced Information Systems

Engineering (Vol. 7908, pp. 84–98).

Meyer, S., Sperner, K., Magerkurth, C., & Pasquier, J.

(2011). Towards modeling real-world aware business

processes. In D. Guinard, V. Trifa, & E. Wilde (Eds.),

In: The Second International Workshop on Web of

Things (p. 1).

Pawar, K., & Attar, V. (2016). A survey on Data Analytic

Platforms for Internet of Things. In CAST-2016. 19-21

December 2016 (pp. 605–610). Piscataway, NJ: IEEE.

Perumal, T., Datta, S. K., & Bonnet, C. (2015). IoT device

management framework for smart home scenarios. In

2015 IEEE 4th Global Conference on Consumer

Electronics (GCCE) (pp. 54–55).

Risteska Stojkoska, B. L., & Trivodaliev, K. V. (2017). A

review of Internet of Things for smart home:

Challenges and solutions. Journal of Cleaner

Production, 140, Part 3, (pp. 1454–1464).

Schaar, P. (2010). Privacy by Design. Identity in the

Information Society, 3(2), (pp. 267–274).

Stolpe, M. (2016). The Internet of Things: Opportunities

and Challenges for Distributed Data Analysis. ACM

SIGKDD Explorations Newsletter, 18(1), (pp. 15–34).

Wehlitz, R., Häberlein, D., Zschörnig, T., & Franczyk, B.

(2017). A Smart Energy Platform for the Internet of

Things-Motivation, Challenges, and Solution Proposal.

In Business Information Systems: 20th International

Conference, BIS 2017, Poznan, Poland, June 28-30,

2017, Proceedings (Vol. 288, p. 271).

Zhao, Z., Agbossou, K., & Cardenas, A. (2016).

Connectivity for Home Energy Management

applications. In APPEEC 2016. 2016 IEEE PES Asia

Pacific Power and Energy Engineering Conference:

October 25-28, 2016, Xi'an, China (pp. 2175–2180).

Zion Market Research. (2017). Global Smart Home Market

is Set for a Rapid Growth and is Expected to Reach

around USD 53.45 Billion by 2022. Retrieved from

https://www.zionmarketresearch.com/news/smart-

home-market

Zschörnig, T., Wehlitz, R., & Franczyk, B. (2017). A

Personal Analytics Platform for the Internet of Things:

Implementing Kappa Architecture with Microservice-

based Stream Processing. In Proceedings of the 19th

International Conference on Enterprise Information

Systems (pp. 733–738).

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

600
