Internet of Things Middleware: How Suitable are Service-oriented

Architecture and Resource-oriented Architecture

Janick Kubela, Matthias Pohl, Sascha Bosse and Klaus Turowski

Magdeburg Research and Competence Cluster, Faculty of Computer Science,

University of Magdeburg, Magdeburg, Germany

Keywords:

Resource-oriented Architecture (RoA), Service-oriented Architecture (SoA), Internet of Things, Middleware,

Web of Things.

Abstract:

Over the last years, the Internet of Things was researched widely. Thus, various IoT applications are devel-

oped based upon different use-cases. Numerous middleware solutions for the IoT are based on the Service

oriented Architecture and Resource oriented Architecture. Both approaches do support the connection of dis-

tributed objects but no research is done to check the suitability of SoA and RoA in the context of common

IoT requirements in an adequate scope. In the context of this paper the fundamental mechanisms of SoA and

RoA are compared regarding to connectivity, compatibility, scalability, robustness and security. Resulting out

of this comparison, both approaches are suitable as the base of an IoT middleware. Nevertheless, RoA has

a lack of supporting bi-directional communication and real-time analysis while SoA rapidly become a heavy

middleware solution. Therefore, the use of a mixed-up middleware is recommended.

1 INTRODUCTION

Over the last decades, the internet developed into an

essential part of the everyday life. Its focus shifted

from an information network to a bidirectional com-

munication network (Fielding and Taylor, 2000). In

the era of mobile devices this development induces

the omnipresence of communication channels. For in-

stance, people communicate via smartphones, smart-

watches, tablets and other web compatible devices

with each other (Gubbi et al., 2013). Besides, the

interaction of humans with smart devices gets easier

by the advancement of voice, gesture and emotional

recognition (Fielding and Taylor, 2000). The next

logical step will be on one hand to enable the com-

munication between humans and non-smart, physi-

cal things and on the other hand the communication

among the things. This conception is summarized un-

der the umbrella term Internet of Things (IoT). Ac-

cording to (Haller et al., 2009), the IoT builds a bridge

between the physical and the digital world by inte-

grating physical objects seamlessly into the current

internet. Therefore, a reference architecture shows

on which one or more IoT applications are based

(Bandyopadhyay and Sen, 2011). The ﬁrst challenge

of the IoT is to extend those objects in a way that

allows them to connect to a network. Thus, each

physical object needs a digital representation of it-

self which can be realised by a barcode or an RFID

chip (Gazis et al., 2015). More complex physical

things can consist out of sensors to collect data from

its environment. At this point, the IoT consists out

of distributed and heterogenous things which use dif-

ferent communication channels and various types of

data representation. Therefore, a middleware layer

is needed to create an interoperability across the het-

erogenous things. Other requirements that needs to be

managed by the middleware are connectivity, compat-

ibility, scalability, robustness and security. In order to

bundle, evaluate and use the data generated by various

things, an application layer is needed. This layer indi-

cates a user interface to establish the communication

with the enduser (Bandyopadhyay and Sen, 2011). In

this context, the enduser is a human being which ac-

cesses the information generated by the IoT. Since the

middleware builds the core of the IoT architecture,

the choice of its architecture is a signiﬁcant decision.

In common, the Service oriented Architecture (SoA)

or the Resource oriented Architecture (RoA) is used

(Gazis et al., 2015; Guinard et al., 2012). However,

both approaches are originally designed to construct

(web) services at distributed networks like the inter-

net (MacKenzie et al., 2006; Richardson and Ruby,

2008). Therefore, it needs to be considered whether

Kubela, J., Pohl, M., Bosse, S. and Turowski, K.

Internet of Things Middleware: How Suitable are Service-oriented Architecture and Resource-oriented Architecture.

DOI: 10.5220/0006702202290236

In Proceedings of the 3rd International Conference on Internet of Things, Big Data and Security (IoTBDS 2018), pages 229-236

ISBN: 978-989-758-296-7

229

these approaches are suitable for the IoT. Currently

there are no researches dealing with this problem in an

acceptable scope. Thus, this paper shall show if SoA,

RoA or both approaches are adoptable to the IoT. In

the following chapter the concept of SoA and RoA

is shortly explained. Section 3 of this paper gives a

review about related literature by analysing various

papers and pointing out named reasons for using SoA

or RoA as a middleware solution. The forth chapter

names essential IoT requirements and which charac-

teristics of SoA and RoA fulﬁls them. Chapter 5 com-

pares the main differences of both approaches regard-

ing the named IoT requirements. In the end a short

outlook for future work is given.

2 DEFINITION OF SoA AND RoA

SoA as well as RoA were not actually created to be

used in the ﬁeld of IoT (Gazis et al., 2015; Guinard

et al., 2012). However, both architectures share the

goal to increase the interoperability of heterogeneous,

distributed objects (Guinard et al., 2011). Although

SoA and RoA share the same goal, both architectural

schemas are based on a different root concept. In

the following, the principle of both architectural ap-

proaches is explained.

2.1 Service-oriented Architecture (SoA)

SoA is based on the root idea of splitting com-

plex systems into small components called services

(Bandyopadhyay and Sen, 2011). Those SoA ser-

vices are deﬁned as a logical, self-contained, indepen-

dent and reusable unit of tasks (Bean, 2009; Laskey

and Laskey, 2009; Schmidt et al., 2005; Spiess et al.,

2009) and are commonly abstracted from business

processes (Laskey and Laskey, 2009). From the user

point of view, a service is a black box that receives in-

put parameters and returns a speciﬁc output (Laskey

and Laskey, 2009; Spiess et al., 2009). Applications

can access the service interface and execute one or

more services to accomplish their task. Moreover,

new services can be created by chaining or enhanc-

ing existing services. Considering that, two services

communicate by exchanging messages (Bean, 2009).

But before two services are able to communicate they

have to ﬁnd each other using the Service Registry.

The Service Registry handles the metadata of all pub-

lished services. Those can be deposited as UDDI,

WSDL or other formats (Wan et al., 2006). The ser-

vices registered at the Service Registry does not have

to be owned or hosted by the same person or company.

Moreover, it allows the distribution of the SoA net-

work (Bean, 2009). Thus, a service can ﬁnd other ser-

vices automatically by searching at the Service Reg-

istry. SoA is based on a high degree of freedom by

choosing transport (like HTTP and FTP) and com-

munication protocols (like SOAP and XML) which

builds the interface of a service (Laskey and Laskey,

2009; Schmidt et al., 2005; Wan et al., 2006). In

the ﬁeld of SoA web services a commonly used tech-

nology is the WS-*-speciﬁcation (Gazis et al., 2015).

The result of this freedom is that the uniform inter-

face of services is harmed if different protocols are

used. To admit this problem, an Enterprise Service

Bus (ESB) can be established. The ESB uniﬁes all

mechanisms of the SoA in one component (Schmidt

et al., 2005). A SoA using an ESB as the central com-

ponent which handles all messages of the service net-

work is shown in (Bean, 2009).

2.2 Resource-oriented Architecture

(RoA)

The term RoA was established in the year 2007

(Richardson and Ruby, 2008). It describes a software

architectural style which is based on the Represen-

tational State Transfer (REST) paradigm stated out

in (Fielding and Taylor, 2000) and the transfer pro-

tocol HTTP. Using these technologies, the root idea

of RoA is to split complex systems into resources

which are encapsulated in a unique interface (REST-

ful resources). Following the deﬁnition (Richardson

and Ruby, 2008), everything can be deﬁned as a re-

source if it has a digital representation that is address-

able over a Unique Resource Identiﬁer (URI). The in-

terface of each resource is restricted to the methods

PUT, GET, POST and DELETE. The POST method

assigns a resource to the used URI (Guinard et al.,

2011). If the URI is already assigned to a resource,

the old resource is replaced. Afterwards, the GET

method is used to read the data provided by the re-

source. As a result, the data represented in a prede-

ﬁned format is returned. The most common represen-

tations are XML, JSON and HTML (Guinard et al.,

2011; Richardson and Ruby, 2008). Also, it is pos-

sible that a resource consists out of various represen-

tations. In this case, the calling instance can choose

which representation ﬁts best for the handled use case

(content negation) (Guinard et al., 2011). Another

method provided by HTTP is the PUT statement. It

is used to update the data represented by the resource

(Guinard et al., 2011). The last by standard HTTP

supported method is DELETE and is necessary to free

an URI by deleting the assigned resource. Based on

the forced use of HTTP and REST, all resource of

the RoA can communicate with each other without

IoTBDS 2018 - 3rd International Conference on Internet of Things, Big Data and Security

230

the need of an intermediary. Moreover, the connec-

tion between resources is following the client-server

principal. As a result, a resource (client) can only

pull data from another resource (server). In (Field-

ing and Taylor, 2000), the authors amplify this con-

cept by claiming that each request has to contain all

information necessary to process it. This character-

istic is named as statelessness (Fielding and Taylor,

2000; Richardson and Ruby, 2008). Another assumed

characteristic is the possibility of resources to cache

data that is already received and marked as cacheable.

The resources communicate which each other and are

linked to enable a navigation through them (Fielding

and Taylor, 2000; Richardson and Ruby, 2008).

3 RELATED WORKS

Some researches already try to show the suitability

of RoA and SoA as an IoT middleware. Neverthe-

less, either the focus of their research is on a spe-

ciﬁc IoT use case or the justiﬁcation of their deci-

sions is limited. As a result, none of the found pa-

pers analyses the ﬁtting of fundamental characteris-

tics of SoA and RoA to common IoT requirements

in an adequate scope. A Web of Things (WoT) ar-

chitecture using the concept of RoA as middleware

is presented in (Guinard et al., 2011). As a reason

for using RoA instead of SoA Guinard et al. mention

that SoA is often to heavy and complex for the ﬁeld

of IoT. Moreover, the strict use of HTTP and REST

simpliﬁes the integration of things into the current

internet. In contrast, a SoA based middleware only

uses the Internet as a transport infrastructure to ex-

change data inside of the SoA network. On one hand,

the authors conclude that WoT applications stand out

due to high scalability, high ﬂexibility and simplic-

ity without justifying their conclusion. On the other

hand, they state out that working with real-time data

streams, avoiding a request overhead, low latency and

searching for things are challenges of an RoA based

middleware. A comparison between the use of RoA

and SoA as an IoT middleware regarding the devel-

opers’ perspective is provided. The result of the study

is that the concept of RoA ”is easier to learn, more

intuitive and more suitable for programming IoT ap-

plications” than SoA (Guinard et al., 2012). Other-

wise, the authors mention that the ﬁxation of RoA

to HTTP does not allow the use of various security

mechanisms. Instead, SoA can make use of a wide

range of security tools. Nevertheless, they raise the

question if voluminous security mechanisms like they

are provided by WS-* are necessary. Another result

of their study is that the participations would rather

choose SoA for business applications based on the su-

perior security mechanisms and the possibility to use

a Service Registry. In (Spiess et al., 2009), a similar

result is concluded. The authors create a SoA middle-

ware to adapt business processes to the IoT. As rea-

sons for their choice the authors name the discovery

functionality provides by the Service Registry and the

scenario-speciﬁc way of creating new services based

on processes. Another aspect is the need for event-

handling and real-time processing in the ﬁeld of man-

ufacturing. Therefore, the created SOCRADES ar-

chitecture uses amongst others a Service Catalogue

and a Service Monitor. Furthermore, they suggested

the various security aspects provides by SoA. Never-

theless, they decided to use a SoA based middleware

without considering the possibility to use RoA instead

(Spiess et al., 2009). Moreover, it seems that the deci-

sion of using SoA is made because of its origin to dig-

italise business processes. A comparison of different

IoT middleware solutions is provided in (Chaqfeh and

Mohamed, 2012). At the beginning, the authors name

common IoT requirements as well as known IoT mid-

dleware solutions like SoA and RoA. Afterwards, a

table is presented that shows which middleware solu-

tion fulﬁls the given requirements. According to the

authors, SoA fulﬁls all stated requirements. In con-

trast, RoA has a lack in security and providing ad-

equate interfaces. Unfortunately, the authors neither

justify their conclusion nor name mechanisms of SoA

and RoA that cover the name requirements.

4 IoT REQUIREMENTS

COMPARED TO SoA AND RoA

In the following, the fundamental aspects of SoA and

RoA are compared to common IoT requirements. At

ﬁrst, each IoT requirement and its sub-requirements

is deﬁned. Afterwards, mechanisms of SoA and RoA

that suits the requirement are named and rated. Ta-

ble 1 shows the results of the performed compari-

son. The ﬁrst column names common IoT require-

ments that should be fulﬁlled by an IoT middle-

ware. Those are identiﬁed from various academic

papers like (Bandyopadhyay and Sen, 2011; Bonomi

et al., 2014; Guinard et al., 2011; Haller et al., 2009;

Kolozali et al., 2014; Pang et al., 2015). The reviewed

requirements are connectivity, compatibility, scalabil-

ity, robustness and security. At the next two columns

of the table rate the ability of SoA and RoA to han-

dle these requirements. For this, the symbol ”-” sig-

nalises that the current requirement cannot be fulﬁlled

by the architectural approach in a suitable way. Addi-

tionally, a ”o” shows that the chosen architecture can

Internet of Things Middleware: How Suitable are Service-oriented Architecture and Resource-oriented Architecture

231

handle this requirement partly. The symbol ”+” sig-

nalizes that the characteristics RoA or SoA are suit-

able to fulﬁl this requirement.

Table 1: IoT Requirements and their Accomplishment by

SoA and RoA.

Requirement SoA RoA

Connectivity

Interoperability o +

Addressability + +

Loose Coupling o +

Self-Connection o -

Searchable Things + +

Bi-Directional Communication + o

Compatibility

Middleware Connectivity o o

Back-/Forward Compatibility o o

Scalability

Various Number of Things + +

Latency o o

Real-Time Processing + -

Robustness

Drop out of Things + -

Validity of Data + -

Security

Authentication + +

Privacy + +

4.1 Connectivity

The term connectivity uniﬁes all characteristics of an

IoT middleware to form a homogenous network out of

a heterogenous mass of things (Bandyopadhyay and

Sen, 2011; Bonomi et al., 2014). It is a fundamental

characteristic of the IoT that all things have the abil-

ity to communicate with each other without the need

of human interaction (Bandyopadhyay and Sen, 2011;

Haller et al., 2009). This sub-requirement is referred

to as interoperability. To enable a communication,

things have to be addressable (Haller et al., 2009).

Moreover, the coupling between the things has to be

loosely which means that things are modular and in-

dependent of each other and the communication chan-

nel of other things (Bandyopadhyay and Sen, 2011).

Another part of connectivity is the self-connection of

things which is bond to the discovery mechanism of

the network (Gubbi et al., 2013; Sundmaeker et al.,

2010). The possibility of the autonomously connec-

tion of new things is necessary because of the fact that

the IoT is a dynamic network which allows things

to move and connect to another middleware (Sund-

maeker et al., 2010). The last sub-requirement of con-

nectivity is the bi-direction communication (Bandy-

opadhyay and Sen, 2011; Haller et al., 2009; Spiess

et al., 2009). Thus, in some IoT use cases things

have to push data to an application or other things.

In this case, the pull method of the client-server prin-

cipal is not sufﬁciently. Creating a SoA based IoT

middleware means that things, parts of things or as-

sociations of things are interpreted as services. As

a result, a number of heterogenous things is turned

into a homogenous network of services. The services

collaborate irrespective their underlying technologies

by using their service interface (Bean, 2009; Haller

et al., 2009; Spiess et al., 2009). Resulting, the inter-

operability and loosely coupling of things is received.

Nevertheless, the architectural design of SoA does not

specify how the interface has to be build. So, the

designer of the IoT middleware has to deﬁne stan-

dard protocols that build the interface. Alternatively, a

translator has to be established as intermediary (Bean,

2009). Besides the effort of an initial implementation

and continuous maintenance (Bean, 2009), the inter-

mediary harms the requirement of loosely coupling by

establishing a dependence on the translator (Schmidt

et al., 2005). Another violation of the loose coupling

at a SoA occurs if a session state can be created dur-

ing the communication of two services. A possible

situation of this circumstance is the use of various se-

curity mechanisms (Hafner et al., 2009). Neverthe-

less, it is mentioned that the registration of services

can be too complex for IoT objects because of their

limited amount of computing power and data mem-

ory (Guinard et al., 2012). If a new thing needs to get

part of the network it just has to be published at the

Service Registry. The last mentioned sub-requirement

of connectivity is the bi-directional communication.

Because of the high degree of freedom, each service

can handle an arbitrary number of methods at its in-

terface. Moreover, SoA is not bound to the client-

server principal whereby the pushing of data is possi-

ble like it is needed for event handling (Spiess et al.,

2009). Like SoA the RoA approach can be adopted

as an IoT middleware. Thus, all things, part of things

or associations of things are interpreted as resources.

Those encapsulate the things by giving them a unique

interface and hiding their fundamental implementa-

tion. As a result, a homogenous network of indepen-

dent resources arises which only allows a collabora-

tion using the standard HTTP methods. The handling

of various message protocols like JSON and XML is

handled at a RoA by the use of content negotiation

or the use of different resources for each content rep-

resentation style (Richardson and Ruby, 2008). As a

result, the interoperability inside of a RoA network

is given. Additionally, the characteristic of stateless

connections supports the requirement of loosely cou-

IoTBDS 2018 - 3rd International Conference on Internet of Things, Big Data and Security

232

pled things. In contrast to SoA, RoA do not need a

structure like a Service Registry to make resources

discoverable. Thus, all RESTful things can be found

easy if they are described via microformats or simi-

lar (Gubbi et al., 2013; Guinard et al., 2011). On one

hand, the use of HTTP ensures that also new things

are immediately integrated to the RoA network. On

the other hand, non-RESTful things need to get a

RESTful interface or proxy to become part of the

RoA network (Guinard et al., 2011; Richardson and

Ruby, 2008). The requirement of bi-directional com-

munication is contrary to the characteristic of RoA

that data can only be pulled (client-server principal).

Thus, the realisation of a bi-direction communication

is only possible if a high network trafﬁc and latency

is accepted. One possible solution is the use of web

hooks which needs a speciﬁc and public URI that is

called by another resource if a speciﬁc event occurs

(Guinard et al., 2011).

4.2 Compatibility

The vision of a ubiquitous IoT intends the existence

of various IoT applications and also loose things.

Nevertheless, the IoT is a network where all compo-

nents should be able to communicate with each other.

Therefore, the compatibility between various middle-

ware implementations is necessary to enable a cross-

application collaboration. Thus, an IoT middleware

has to handle backward and forward compatibility to

avoid communication errors based on different proto-

col versions. The implementation of a SoA designed

middleware is based on a high degree of freedom, as

mentioned before. Therefore, the use of an intermedi-

ary to translate different transport and messaging pro-

tocols is necessary to ensure the communication in-

side a network and between various networks (Bandy-

opadhyay and Sen, 2011). The use of an ESB for this

translation task is suggested in (Schmidt et al., 2005).

As a result, the requirement of compatibility is ful-

ﬁlled. Besides translation messages the ESB can also

queue message and provides a synchronous as well as

asynchronous messaging. Nevertheless, the effort of

implementing an ESB respectively the extension of an

ESB needs to be considered. On one hand, the initial

effort is demanded on the number of various proto-

cols used by the connected things and networks. On

the other hand, a recurring effort appears by the con-

tinuous addition of new protocols and protocol ver-

sions. This dependence on the ESB results in possi-

ble single point of failure. RoA beneﬁts from its tight

relation to REST and HTTP. Thus, the connection to

other RoA based network is automatically established

without any extra effort. In contrast, the things of

a non-RoA based network has to be covered by an

RESTful interface which can result in a high effort.

A smart gateway which is realised by a tiny server

that acts as a proxy for the things is recommended in

(Guinard et al., 2011). Nevertheless, the advantage of

this approach is that no central intermediary is needed

and thus no single point of failure is created. How-

ever, the case of incompatibility of protocols because

of the use of different versions is rare for a RoA mid-

dleware. The reason for this is that the HTTP protocol

is backwards compatible by default (Richardson and

Ruby, 2008). Moreover, all versions of HTTP support

the methods PUT, GET, POST and DELETE. Never-

theless, the forward compatibility is not guaranteed.

Thus, a solution to handle forward incompatibility is

to catch and handle HTTP error codes (Richardson

and Ruby, 2008) or to use the HTTP header to make

clear that the called resource ﬁts the requirements.

4.3 Scalibility

The IoT paradigm assumes a dynamic and evolving

environment. Thus, the number of things connected

to a middleware can vary as well as the number of ap-

plications based on this middleware (Bandyopadhyay

and Sen, 2011; Kruger and Hancke, 2014). There-

fore, an IoT middleware has to perform well irrespec-

tive of the number of handled things (Chaqfeh and

Mohamed, 2012). This characteristic is referred to as

scalability. Moreover, scalability means that the num-

ber of accesses to things triggered by various appli-

cations should not affect the performance of the IoT

network spanned by the middleware. An indicator for

this circumstance is the latency which describes the

time needed to answer a request. Consequently, the

middleware has to handle and transfer the data gen-

erated by the things in-time. The number of things

connected to the network inﬂuences a SoA middle-

ware in different ways. On one hand the size of the

Service Registry grows or shrinks with the number of

services. On the other hand, the number of things in-

ﬂuences the status monitor which has to handle more

heartbeats. Both circumstances can be handled by

providing ﬂexible processing and storage power by

using cloud computing (Bonomi et al., 2014). Addi-

tionally, the number of calls of one as well as all ser-

vices inﬂuences the SoA middleware. The transmit-

ter can be scaled by using cloud computing (Schmidt

et al., 2005). Thus, the limiting factor delays on the

things which mostly have a small processing power.

Therefore, SoA supports different mechanisms to re-

lieve the load on the things. One aspect is the Ser-

vice Broker which can distribute messages to sim-

ilar services if one service is busy (Schmidt et al.,

Internet of Things Middleware: How Suitable are Service-oriented Architecture and Resource-oriented Architecture

233

2005; Spiess et al., 2009). Another aspect is the pos-

sibility to queue requests so that they can be handled

one after another without overloading the thing (Du

et al., 2011; Garces-Erice, 2009). Consequently, a

high number of requests can result in a high latency.

Another aspect that has inﬂuence on the latency is

the translation of each request by the ESB (Du et al.,

2011). Thus, also the handling of real time data is

inﬂuenced. To solve this problem, the use of a real-

time assurance mechanism at the ESB is proposed in

(Du et al., 2011). This mechanism is responsible to

prioritise all messages and giving them a deadline. A

similar approach is an Event Scheduler (Garces-Erice,

2009). The main focus of RoA is to handle a vari-

ous number of resources respectively things by han-

dling them loosely coupled and independent. More-

over, RoA has no central intermediary which han-

dles the connection between the resources. Thus, a

point-to-point communication is established between

the resources which avoids a performance inﬂuence

by a ﬂuctuating number of things. Similar to SoA,

the communication bottleneck of RoA is the low pro-

cessing power of the things. As a result, several calls

of one resource at once has to be handled by the re-

source itself (Richardson and Ruby, 2008). The state-

lessness of a resource ensures that one access to the

resource is not inﬂuences by other, simultaneous ac-

cesses (Richardson and Ruby, 2008). The result is

that no connection state needs to be loaded and that

parallel processing is supported. Moreover, RoA pro-

vides a client side cache which allows the buffering of

cacheable data (Guinard et al., 2011). Another aspect

to handle multiple requests is the concept of a lay-

ered system which allows the redirection of requests

to sub-resources. The layered system concept results

in a higher latency because of the intermediary that is

embodied by the resource (Guinard et al., 2011). On

the contrary, the possibility to cache data and redi-

rect requests to sub resources can lower the latency

by handling the request faster (Guinard et al., 2011;

Richardson and Ruby, 2008). As mentioned before,

real-time processing is hard to handle using RoA. The

reason for that is that straight HTTP and REST only

support the pulling of data. Thus, the use of web

hooks to implement event handling and AtomPub for

implementing data streaming at a RoA middleware is

suggested (Guinard et al., 2011).

4.4 Robustness

The robustness of a network describes its ability to

handle the availability of things (Haller et al., 2009;

Kolozali et al., 2014). Another aspect of robustness is

the validity of measured and supported data (Kolozali

et al., 2014). A SoA based middleware can handle

the drop out of service by using a status monitor (Du

et al., 2011). Each service frequently sends a mes-

sage (heartbeat) to this monitor to show that it is still

working. In combination with an ESB the failure of a

service can be regulated by searching for an alterna-

tive service with equal functions (Haller et al., 2009).

Moreover, the ESB can support a validity check of

data by reading and checking all passing messages. A

disadvantage of this process is that the latency will in-

crease as well as the workload of the ESB. Based on

the lack of bi-direction communication and event han-

dling, the detection of dropped out resources at a RoA

networks is difﬁcult. One solution can be to deﬁne

one or more resources which checks if other resources

are still available. The disadvantage of this solution is

that an information and trafﬁc overhead will result out

of the frequently send GET requests to all resources to

get their status (Guinard et al., 2011). As a result, the

application designer has to handle a possible drop out

of a resource and implement an alternative behaviour

like the searching for similar resources. The advan-

tage of this approach is that the failure of one resource

is handled by each application itself which results in

an individual and therefore suitable solution. Never-

theless, the rising effort of the application design has

to be mentioned. This circumstance can be avoided

by extending a mashup software by an autonomous

error handling (Guinard et al., 2011). This solution

can also be used to check the validity of data at the

application layer. Moreover, the data validity check

can also be moved to the things layer.

4.5 Security

The creation of networks by linking-up real-world

things and connect them to the internet is not free

of dangers. The security of IoT, IoT application and

IoT architectures is an important aspect that should

be mentioned. The number of connected things and

the amount produced data offers a huge contact sur-

face for cyber criminals. Therefore, various security

aspects and typical attacks that have to be mentioned

while create an IoT middleware are analysed (Farooq

et al., 2015; Riahi et al., 2013; Gou et al., 2013). It

should be mentioned that an effective security level

can only be accomplished if all layers of the IoT struc-

ture are secured. Based on the fact that SoA is not

bound to speciﬁc technologies, a wide range of secu-

rity tools can be used. Standardised WS-Security in

combination with SOAP is suggested and by the use

of security tokens an authentication process is estab-

lished (Tiburski et al., 2015). Additionally, XML En-

cryption ensures the privacy of data and wards man-

IoTBDS 2018 - 3rd International Conference on Internet of Things, Big Data and Security

234

in-the-middle attacks off (Tiburski et al., 2015; Fa-

rooq et al., 2015). Nevertheless, the implementation

of these security standards can result in a high effort

especially regarding the ESB which can be a secu-

rity vulnerability, too. Thus, Hafner et al. (Hafner

et al., 2009) created a blueprint for Security as a Ser-

vice (SeAAS). As already mentioned, RoA is based

on HTTP and REST. Therefore, HTTP Basic, HTTP

Digest or WS-Security Extension are suggested to

use for authentication (Richardson and Ruby, 2008).

However, both methods are not save (Lee et al., 2015).

HTTP Basic can be a victim of replay and injection at-

tacks while HTTP Digest is not save regarding man-

in-the-middle attacks. Therefore, the authors devel-

oped a method called ID-based Authentication which

performs authentication using private and public keys

in combination with the resource URIs. Furthermore,

the existing APIs of social networks can be used as a

proxy to authenticate users and manage their access

to resources (Guinard et al., 2011). The aspect of pri-

vacy can be fulﬁlled by the use of HTTPS instead of

HTTP which encrypts the transferred data (Richard-

son and Ruby, 2008; Clark and van Oorschot, 2013).

5 DISCUSSION AND

CONCLUSION

The performed analysis of SoA and RoA shows that

both approaches do not fulﬁl all requirements raised

by the IoT perfectly. Table 1 shows that SoA sup-

ports all requirements at least in an elementary way.

The deciding factors of SoA are the ESB and the free-

dom to choose the used protocols free. On one hand,

the ESB allows the management and monitoring of

all services and its communication which is useful

to provide real-time processing, robustness and secu-

rity. On the other hand, the ESB causes a high effort

by its initial implementation and continuous mainte-

nance. Moreover, the use of an intermediary results

in a single point of failure and harms the loose cou-

pling of things. Nevertheless, SoA cannot be used

as an IoT middleware without providing an ESB or

a similar intermediary. The high degree of freedom

to choose the service interface harms the interoper-

ability of services but allows to use use-case speciﬁc

protocols. Regarding Table 1, RoA does not support

all requirements of the IoT. The reason for not fulﬁll-

ing the requirements self-connection, real-time pro-

cessing and robustness is that the REST concept does

not allow the pushing of data. Thus, a bi-directional

communication can only be implemented with a huge

effort and by causing unnecessary trafﬁc for exam-

ple by using web hooks. Omitting the lack of bi-

directional communication, RoA is well suited for

IoT applications because of its strict deﬁnition of a

unique interface which avoids the use of an interme-

diary. As a result, a lightweight and simple network

can be build. Moreover, RoA beneﬁts from the de-

pendence on HTTP by embedding the IoT into the

existing internet. In contrast, SoA uses the internet as

an infrastructure to exchange its data instead of merg-

ing both approaches. All in all, SoA as well as RoA

can be suitable to build a IoT middleware. The de-

cision to one of the two approaches depends on the

speciﬁc use-case and the future use of the created net-

work. The analysis of SoA and RoA regarding var-

ious IoT requirements can be the basis for this de-

cision. Thus, RoA is recommended if no real-time

analysis or event-handling is necessary because of its

lightweight and connectedness to the existing inter-

net. In contrast, SoA should be used if complex pro-

cesses should be designed or real-time analysis are

needed. Moreover, the lack of security mechanisms

of RoA mentioned in (Guinard et al., 2012; Chaqfeh

and Mohamed, 2012) can be proven. Nevertheless,

the security mechanisms of RoA is suitable for com-

mon IoT applications. It is also possible to match

both approaches to provide from the lightweight of

RoA and the ﬂexibility of SoA. Future researches can

build a mix-up architecture of SoA and RoA based

on the reviewed IoT requirements and mechanisms.

Moreover, the security mechanisms of both middle-

ware solutions need to be reviewed in more detail. For

this, the things layer and the application layers needs

to be included because of the high dependency in the

ﬁeld of security. Another research topic is to evalu-

ate how strong the named IoT requirements depend

on each other and which architectural characteristics

are necessary to fulﬁl all requirements.

REFERENCES

Bandyopadhyay, D. and Sen, J. (2011). Internet of

things: Applications and challenges in technology and

standardization. Wireless Personal Communications,

58(1):49–69.

Bean, J. (2009). SOA and web services interface design:

principles, techniques, and standards. Morgan Kauf-

mann.

Bonomi, F., Milito, R., Natarajan, P., and Zhu, J. (2014).

Fog Computing: A Platform for Internet of Things and

Analytics, pages 169–186. Springer International Pub-

lishing, Cham.

Chaqfeh, M. A. and Mohamed, N. (2012). Challenges

in middleware solutions for the internet of things.

In 2012 International Conference on Collaboration

Technologies and Systems (CTS), pages 21–26.

Internet of Things Middleware: How Suitable are Service-oriented Architecture and Resource-oriented Architecture

235

Clark, J. and van Oorschot, P. C. (2013). SoK: SSL and

HTTPS: Revisiting past challenges and evaluating cer-

tiﬁcate trust model enhancements. In 2013 IEEE Sym-

posium on Security and Privacy, pages 511–525.

Du, L., Duan, C., Liu, S., and He, W. (2011). Research

on service bus for distributed real-time control sys-

tems. In 2011 6th IEEE Joint International Infor-

mation Technology and Artiﬁcial Intelligence Confer-

ence, volume 1, pages 401–405.

Farooq, M. U., Waseem, M., Khairi, A., and Mazhar, S.

(2015). A critical analysis on the security concerns

of internet of things (IoT). International Journal of

Computer Applications, 111(7).

Fielding, R. T. and Taylor, R. N. (2000). Architectural

styles and the design of network-based software ar-

chitectures. University of California, Irvine Doctoral

dissertation.

Garces-Erice, L. (2009). Building an enterprise service bus

for real-time SOA: A messaging middleware stack. In

2009 33rd Annual IEEE International Computer Soft-

ware and Applications Conference, volume 2, pages

79–84.

Gazis, V., Grtz, M., Huber, M., Leonardi, A., Mathioudakis,

K., Wiesmaier, A., Zeiger, F., and Vasilomanolakis, E.

(2015). A survey of technologies for the internet of

things. In 2015 International Wireless Communica-

tions and Mobile Computing Conference (IWCMC),

pages 1090–1095. IEEE.

Gou, Q., Yan, L., Liu, Y., and Li, Y. (2013). Construc-

tion and strategies in IoT security system. In 2013

IEEE International Conference on Green Computing

and Communications and IEEE Internet of Things and

IEEE Cyber, Physical and Social Computing, pages

1129–1132.

Gubbi, J., Buyya, R., Marusic, S., and Palaniswami, M.

(2013). Internet of things (IoT): A vision, architec-

tural elements, and future directions. Future Gen-

eration Computer Systems, 29(7):1645 – 1660. In-

cluding Special sections: Cyber-enabled Distributed

Computing for Ubiquitous Cloud and Network Ser-

vices & Cloud Computing and Scientiﬁc Applications

Big Data, Scalable Analytics, and Beyond.

Guinard, D., Ion, I., and Mayer, S. (2012). In Search of

an Internet of Things Service Architecture: REST or

WS-*? A Developers’ Perspective, pages 326–337.

Springer Berlin Heidelberg, Berlin, Heidelberg.

Guinard, D., Trifa, V., Mattern, F., and Wilde, E. (2011).

From the internet of things to the web of things:

Resource-oriented architecture and best practices. Ar-

chitecting the Internet of things, pages 97–129.

Hafner, M., Memon, M., and Breu, R. (2009). SeAAS-a ref-

erence architecture for security services in SOA. Jour-

nal of Universal Computer Science, 15(15):2916–

2936.

Haller, S., Karnouskos, S., and Schroth, C. (2009). The

Internet of Things in an Enterprise Context, pages 14–

28. Springer Berlin Heidelberg, Berlin, Heidelberg.

Kolozali, S., Bermudez-Edo, M., Puschmann, D., Ganz,

F., and Barnaghi, P. (2014). A knowledge-based ap-

proach for real-time IoT data stream annotation and

processing. In 2014 IEEE International Conference

on Internet of Things (iThings), and IEEE Green Com-

puting and Communications (GreenCom) and IEEE

Cyber, Physical and Social Computing (CPSCom),

pages 215–222.

Kruger, C. P. and Hancke, G. P. (2014). Implementing the

internet of things vision in industrial wireless sensor

networks. In 2014 12th IEEE International Confer-

ence on Industrial Informatics (INDIN), pages 627–

632.

Laskey, K. B. and Laskey, K. (2009). Service oriented ar-

chitecture. Wiley Interdisciplinary Reviews: Compu-

tational Statistics, 1(1):101–105.

Lee, S., Jo, J. Y., and Kim, Y. (2015). Method for secure

RESTful web service. In 2015 IEEE/ACIS 14th In-

ternational Conference on Computer and Information

Science (ICIS), pages 77–81.

MacKenzie, C. M., Laskey, K., McCabe, F., Brown, P. F.,

Metz, R., and Hamilton, B. A. (2006). Reference

model for service oriented architecture 1.0. OASIS

standard, 12:18.

Pang, Z., Zheng, L., Tian, J., Kao-Walter, S., Dubrova, E.,

and Chen, Q. (2015). Design of a terminal solution

for integration of in-home health care devices and ser-

vices towards the internet-of-things. Enterprise Infor-

mation Systems, 9(1):86–116.

Riahi, A., Challal, Y., Natalizio, E., Chtourou, Z., and

Bouabdallah, A. (2013). A systemic approach for IoT

security. In 2013 IEEE International Conference on

Distributed Computing in Sensor Systems, pages 351–

355.

Richardson, L. and Ruby, S. (2008). RESTful web services.

O’Reilly Media, Inc.

Schmidt, M. T., Hutchison, B., Lambros, P., and Phip-

pen, R. (2005). The enterprise service bus: Making

service-oriented architecture real. IBM Systems Jour-

nal, 44(4):781–797.

Spiess, P., Karnouskos, S., Guinard, D., Savio, D., Baecker,

O., d. Souza, L. M. S., and Trifa, V. (2009). SOA-

based integration of the internet of things in enterprise

services. In 2009 IEEE International Conference on

Web Services, pages 968–975.

Sundmaeker, H., Guillemin, P., Friess, P., and Woelfﬂ

e, S.

(2010). Vision and challenges for realising the internet

of things. Cluster of European Research Projects on

the Internet of Things, European Commision, 3(3):34–

36.

Tiburski, R. T., Amaral, L. A., Matos, E. D., and Hessel, F.

(2015). The importance of a standard security archit

ecture for SOA-based iot middleware. IEEE Commu-

nications Magazine, 53(12):20–26.

Wan, K.-M., Lei, P., Chatwin, C., and Young, R. (2006).

Service-oriented architecture. pages 998–1002.

IoTBDS 2018 - 3rd International Conference on Internet of Things, Big Data and Security

236
