Relevant Acoustic Group Features for Automatic Sleepiness Recognition

Dara Pir

and Jarek Krajewski

2,3

Information Technology Program, Guttman Community College, City University of New York, New York, U.S.A.

Institute for Safety Technology, University of Wuppertal, Wuppertal, Germany

Engineering Psychology, Rhenish University of Applied Science Cologne, Cologne, Germany

Keywords:

Automatic Sleepiness Recognition, Acoustic Group Features, Computational Paralinguistics, Human-

Computer Interaction.

Abstract:

This paper compares the discriminating powers of various acoustic group features for the task of automatic

sleepiness recognition using three different classiﬁers: Voted Perceptron, Simple Logistic, and Random Forest.

Interspeech 2011 Sleepiness Sub-Challenge’s “Sleepy Language Corpus” (SLC) is used to generate the 4368

acoustic features of the ofﬁcial baseline feature set. The feature space is divided into Low-Level Descriptor

(LLD) partitions. We consider the resulting feature space in groups rather than individually. A group feature

corresponds to a set of one or more LLD partitions. The relevance of various group features to sleepiness state

is then evaluated using the mentioned classiﬁers. Employing larger feature sets has been shown to increase

the classiﬁcation accuracy in sleepiness classiﬁcation. Our results, however, demonstrate that a much smaller

subset of the baseline feature set outperforms the ofﬁcial Sub-Challenge baseline on the SLC test data.

1 INTRODUCTION

Sleep is a widespread phenomenon and there is great

interest in detecting it. An important area of inter-

est is the prevalent sleep related road accidents (Pack

et al., 1995; McCartt et al., 1996; Vanlaar et al.,

2008) where sleep detection systems may play a crit-

ical role in preventing them. Another area of great in-

terest is in the emerging ﬁelds of Ubiquitous Comput-

ing, Intelligent Companion, and Robots for Eldercare,

where both the naturalness and efﬁciency of Human-

Computer Interaction can be enhanced by knowing

the speaker’s various states such as fatigue and sleepi-

ness. The system may provide feedback about the

user’s state to appear more emphatic and may adapt

its output to the user’s state to render the communica-

tion more intelligible (Krajewski et al., 2008).

Employing the speech mode in recognition appli-

cations offers advantages: 1) over modes that use in-

trusive or inconvenient sensors which require being

attached to the subject or 2) under conditions that

degrade performance of alternative modes, e.g., low-

light environment for the visual mode (Krajewski and

oger, 2007; Krajewski et al., 2008; H

onig et al.,

2014a; H

onig et al., 2014b; Pir et al., 2017).

The binary task of sleepiness classiﬁcation, a

computational paralinguistics (CP) task, was pre-

sented at Interspeech 2011 Sleepiness Sub-Challenge

(Schuller et al., 2011). Whereas Automatic Speech

Recognition (ASR) tries to determine which words

are spoken, CP attempts to discover how those words

are spoken and thereby gain knowledge about the var-

ious aspects and conditions of the speakers, e.g., age,

gender, sleepiness, friendliness, etc. (Schuller and

Batliner, 2014; Hantke et al., 2016).

The Sleepiness Sub-Challenge employs the

openSMILE toolkit (Eyben et al., 2010) to generate

the 4368 baseline acoustic features from the “Sleepy

Language Corpus” (SLC) (Schuller et al., 2011). A

score of 70.3% Unweighted Average Recall (UAR)

is obtained by the Sub-Challenge baseline feature set

which is considered to be a collection of relevant

features for the task of sleepiness (Schuller et al.,

2011; Dhupati et al., 2010). The UAR measure takes

the imbalance between class instances into account

(Schuller et al., 2011)

We divide the feature space into Low-Level De-

scriptor (LLD) partitions and consider the resulting

feature space in groups rather than individually (Pir

and Brown, 2015). A group feature corresponds

to a set of one or more LLD partitions. The Sub-

Challenge ﬁndings demonstrate that using larger fea-

Pir, D. and Krajewski, J.

Relevant Acoustic Group Features for Automatic Sleepiness Recognition.

DOI: 10.5220/0006779802090214

In Proceedings of the 4th Inter national Conference on Information and Communication Technologies for Ageing Well and e-Health (ICT4AWE 2018), pages 209-214

ISBN: 978-989-758-299-8

209

Table 1: Type: Type of features included in LLD set. LLD-Set: Names of LLDs contained in the set. nLLD: Number of

LLDs in the LLD set.

Type LLD-Set nLLD

Energy

Sum of auditory spectrum 1

Sum of RASTA-style ﬁltered auditory spectrum 1

RMS Energy 1

Zero-Crossing Rate 1

Spectral

RASTA-style ﬁlt. auditory spectrum 26

Spectral energy 2

Spectral Roll Off 4

Spctral Flux, Entropy, Variance, Skewness, Kurtosis, Slope 6

MFCC 12

Voice

F0 1

Probability of voicing 1

Jitter (local) 1

Jitter (delta) 1

Shimmer 1

ture sets improves the classiﬁcation performance. By

evaluating the various constituent group features of

the baseline feature set we attempt to discover those

that are more relevant for the task. This information,

in turn, may be helpful in designing feature sets with

superior performance.

The novel aspect of this paper in the context of

sleepiness recognition, to the best of our knowledge,

is the use of multiple classiﬁers in evaluating the dis-

criminating power of the various group features that

comprise the openSMILE generated baseline feature

set without employing any feature selection opera-

tion.

This paper is organized as follows. Section 2 de-

scribes group features, LLDs, and the Mel-Frequency

Cepstral Coefﬁcients (MFCCs). Section 3 describes

the corpus. Section 4 covers the group features con-

sidered in experimental evaluation, the over-sampling

step, and the classiﬁers employed. Section 5 presents

the experimental results and the paper’s conclusions

and suggested future work are discussed in Section 6.

2 FEATURES

Acoustic features are generated, on the chunk level,

by application of functionals like statistical moments

or quartiles to LLD contours such as Fundamental

Frequency or Zero-Crossing Rate (Schuller et al.,

2009; Weninger et al., 2013; Schuller et al., 2011).

2.1 Group Features

Acoustic group features are comprised of LLD par-

titions. LLD-based portioning is acoustically moti-

vated since the features within an LLD are supra-

segmental information on the same single LLD and

therefore related (Schuller et al., 2011; Pir and Brown,

2015; Pir et al., 2016; Pir et al., 2017)

2.2 LLDs

The list of basic LLDs used by the openSMILE toolkit

to generate the baseline acoustic features are shown in

Table 1. The LLDs are divided by type into: energy-

related, spectral, and voice-related sets. Details about

the full set of functionals applied to these LLDs can be

found in (Schuller et al., 2011). For each basic LLD

shown, there is a corresponding delta LLD. Delta is

deﬁned as the ﬁrst order difference function of the re-

lated LLD (Eyben, 2016). The total number of LLDs,

i.e., basic and delta combined, are therefore twice the

numbers shown in Table 1.

2.3 MFCCs

The MFCCs (Davis and Mermelstein, 1980) are

among the most popular features for ASR and have

also been successful in many other audio process-

ing tasks such as speaker identiﬁcation, music sig-

nal processing, and CP (Eyben, 2016; Lerch, 2012).

We therefore chose to investigate the performance of

four of their smaller subsets in addition to the full set

which is included in the openSMILE feature set.

3 CORPUS

The 21 hours of SLC speech recordings were made

from 99 subjects. The recordings have a sampling rate

ICT4AWE 2018 - 4th International Conference on Information and Communication Technologies for Ageing Well and e-Health

210

Table 2: Classiﬁcation results in % UAR on test data using three classiﬁers: VP, SL, and RF. Type: Type of features included

in the group feature. Group: Abbreviation for the group feature. Basic: Results for basic group features. Delta: Results for

delta group features. Comb: Results for the combined basic and delta group features. The best performance for each row is

depicted in bold.

VP SL RF

Type Group Basic Delta Comb Basic Delta Comb Basic Delta Comb

Energy ENER 61.3 60.8 62.4 64.0 64.5 65.7 58.4 65.3 62.9

Spectral

RFilt 66.0 61.6 64.9 68.3 65.5 67.7 64.9 63.6 65.5

SpEn 42.7 45.8 46.1 54.2 57.7 58.7 51.0 53.0 51.0

SpRo 62.0 56.4 58.2 61.9 62.2 62.0 63.7 62.6 64.9

Mom+ 63.3 62.4 64.4 63.2 64.1 63.8 60.7 61.1 61.2

MFCC12 63.7 59.4 62.1 64.2 59.0 63.3 67.9 61.7 66.0

Voice VOICE 66.7 63.3 65.3 66.6 65.8 66.7 67.8 62.6 67.6

All ALL 67.1 65.3 67.9 70.4 66.5 68.9 68.7 69.0 69.8

MFCC

MFCC1 66.4 55.9 63.5 66.6 54.0 67.3 66.2 61.5 67.8

MFCC2 66.4 60.8 65.8 67.4 59.4 67.1 70.1 62.5 70.4

MFCC3 65.3 59.1 65.5 64.9 56.9 65.2 70.1 62.3 70.7

MFCC4 64.4 60.0 64.5 64.8 59.0 64.4 70.2 62.4 70.2

of 16 kHz and are quantized at 16 bits (Schuller et al.,

2011).

SLC uses the Karolinska Sleepiness Scale (Shahid

et al., 2012), which deﬁnes levels of sleepiness 1

though 10. A level greater than 7.5 represents the

sleepy state and one equal to or less than 7.5 indicates

a non-sleepy state.

4 METHOD

4.1 Group Features Considered

For each LLD, three different feature sets are consid-

ered for evaluation. The ﬁrst set consists of the basic

features. The second set is comprised of the delta fea-

tures of the corresponding basic features of the ﬁrst

set. The third set is the basic and delta sets combined.

The number of energy-related LLD sets is small

and hence they are combined into a single group fea-

ture for performance evaluation. The voice-related

LLD sets are also combined for the same reason. Each

of the ﬁve spectral LLD sets is considered as a group

feature and evaluated separately. In addition, four

MFCC group features are considered where the ﬁrst

group includes the ﬁrst coefﬁcients, the second group

includes the ﬁrst and second coefﬁcients, and so forth.

4.2 Synthetic Minority Over-sampling

Technique

WEKA’s Synthetic Minority Over-sampling Tech-

nique (SMOTE) implementation (Chawla et al., 2002)

is used to balance the number of class instances in the

development set.

4.3 Classiﬁers

Our three classiﬁers use WEKA’s (Hall et al., 2009)

implementations: VotedPerceptron (VP) (Freund and

Schapire, 1999), SimpleLogistic (SL) (Sumner et al.,

2005), and RandomForest (RF) (Breiman, 2001). The

training is done on training and development data

combined and the evaluation is performed on test data

using the Sub-Challenge deﬁned data partitions.

5 EXPERIMENTAL RESULTS

5.1 Relevance

The classiﬁcation results on test data are shown in Ta-

ble 2 for the basic, delta, and combined group features

using three classiﬁers: VP, SL, and RF. The bold en-

tries in each row of the table depict the best perfor-

mance for the associated group feature. The results

demonstrate that relevance depends on the classiﬁer

used, e.g., Mom+ is most relevant for VP, RFilt for

SL, and SpRo for RF. Alternatively, average relevance

could be deﬁned as the classiﬁcation accuracies’ av-

erage for all classiﬁers.

5.2 Comparison Among Basic, Delta,

and Combined Groups Features

Table 3 shows the classiﬁcation accuracy averages for

the basic, delta, and combined group features using

Relevant Acoustic Group Features for Automatic Sleepiness Recognition

211

each classiﬁer. The basic groups’ averages outper-

form those of the delta for every classiﬁer and the

combined groups’ averages outperform those of the

basic for the RF and SL classiﬁers.

Table 3: Classiﬁcation accuracy averages in % UAR for the

basic, delta, and combined group features using each classi-

ﬁer. Classiﬁer: Classiﬁer used. The rest of the columns are

described as in Table 2.

Classiﬁer Basic Delta Comb

RF 65.0 62.3 65.7

SL 64.7 61.2 65.1

VP 62.9 59.2 62.6

In addition, Table 4 shows the percentage of cases

where each of the basic, delta, and combined groups

achieves top performance for every classiﬁer. The

combined groups are associated with about 57% of

the cases followed by the basic groups representing

around 35% of the cases. The delta groups achieve

top results in only about 8% of the cases.

Table 4: The percentages of best performances for every

classiﬁer. Classiﬁer: Classiﬁer used. Basic, Delta, and

Comb: The percentage of times the corresponding category

of group features achieves top performance for a particular

classiﬁer and group feature.

Classiﬁer Basic Delta Comb

All 35% 8% 57%

5.3 Most Relevant Group Features

Overall

The three most relevant, i.e., top performing, group

features using any classiﬁer are shown in Table 5.

All the top three performances are achieved by the

RF classiﬁer on some MFCC group. The best re-

sult, 70.7% UAR, achieved by the combined MFCC3

group feature outperforms the ofﬁcial Sub-Challenge

baseline of 70.3% while being comprised of only 6

LLDs.

We have not included in the table the 70.4% UAR

result obtained by the SL classiﬁer on the entire base-

line feature set as our goal is to ﬁnd particular group

features that are relevant to the sleepiness state.

5.4 Most Relevant Group Features on

Average

The three most relevant group features on average are

shown in Table 6. The MFCC2 basic group feature,

comprised of only 2 LLDs, achieves the highest av-

erage performance of 68.0% UAR. We have not in-

cluded performance results on the entire baseline fea-

ture set for the reason described above.

Table 5: Three top performing group features using any

classiﬁer. Group: Abbreviation for the group feature. Cat:

Group feature category. Cls: Classiﬁer. nLLD: Number of

LLDs in the group feature. % UAR: Classiﬁcation result in

% UAR. Performance results that are superior to the Sub-

Challenge baseline are depicted in bold.

Group Cat Cls nLLD % UAR

MFCC3 Comb RF 6 70.7

MFCC2 Comb RF 4 70.4

MFCC4 Basic RF 4 70.2

Table 6: Columns are described as in Table 5.

Group Cat nLLD % UAR

MFCC2 Basic 2 68.0

MFCC2 Comb 4 67.8

MFCC3 Comb 6 67.1

5.5 Irrelevant Group Feature

Our analysis has allowed us to identify a group fea-

ture, the SpEn (Spectral Energy) group, that performs

worse than chance for all three categories as shown in

Table 7. We note that the group is not irrelevant when

using the SL classiﬁer and the performance of the RF

classiﬁer is near chance.

Table 7: Classiﬁcation results of the VP classiﬁer for SpEn

(spectral energy) group feature. Columns are described as

in Table 2.

Group Basic Delta Comb

SpEn 42.7 45.8 46.1

5.6 Comparison with Previous Results

Of the six accepted papers in the Interspeech 2011

Sleepiness Sub-Challenge only three surpassed the

highly competitive baseline (Schuller et al., 2014).

The best performing system achieved a UAR of

71.7% which is not a signiﬁcant improvement over

the baseline at an α = 0.05 level (Schuller et al.,

2014). The mentioned system employed two other

standard feature sets in addition that of the Sleepiness

Sub-Challenge. Classiﬁcation results were obtained

using the authors’ proposed Asymmetric Simple Par-

tial Least Squares method, SVM, and fusions (Huang

et al., 2011; Schuller et al., 2014). Our best perfor-

mance is achieved, however, using only about 5% of

the features (6 out of 118 LLDs) in the baseline fea-

ture set. This reduction is signiﬁcant in two important

ways. First, it renders the training phase of computa-

tionally intensive classiﬁers more tractable. Second,

it provides knowledge to domain experts by identify-

ing those features that are better suited to the task.

ICT4AWE 2018 - 4th International Conference on Information and Communication Technologies for Ageing Well and e-Health

212

Although (H

onig et al., 2014a) reports a state-

of-the-art result of 71.9% UAR, the dataset used is

smaller and a direct performance comparison cannot

be made.

6 CONCLUSIONS AND FUTURE

WORK

In this paper, we compared the accuracy perfor-

mances of LLD-based group features that comprise

the Sleepiness Sub-Challenge’s baseline feature set

using three different classiﬁers. Our analysis has re-

vealed the relative discriminating powers of various

group features for a speciﬁc classiﬁer as well as aver-

aged over all classiﬁers. Our top performance, which

achieved improvement over the ofﬁcial baseline, was

obtained using the Random Forest classiﬁer and the

MFCC group feature containing the ﬁrst three coefﬁ-

cients. The mentioned MFCC group feature includes

only 6 LLDs out of the 118 that comprise the baseline

feature set.

Future work includes extending the current frame-

work for evaluating relevance for group features in the

context of other paralinguistics tasks as well as devel-

oping feature selection methods that incorporate the

knowledge obtained about group feature relevance in

this paper.

REFERENCES

Breiman, L. (2001). Random forests. Machine Learning,

45(1):5–32.

Chawla, N. V., Bowyer, K. W., Hall, L. O., and Kegelmeyer,

W. P. (2002). Smote: synthetic minority over-

sampling technique. Journal of artiﬁcial intelligence

research, pages 321–357.

Davis, S. and Mermelstein, P. (1980). Comparison of para-

metric representations for monosyllabic word recog-

nition in continuously spoken sentences. IEEE trans-

actions on acoustics, speech, and signal processing,

28(4):357–366.

Dhupati, L. S., Kar, S., Rajaguru, A., and Routray, A.

(2010). A novel drowsiness detection scheme based

on speech analysis with validation using simultaneous

eeg recordings. In Automation Science and Engineer-

ing (CASE), 2010 IEEE Conference on, pages 917–

921. IEEE.

Eyben, F. (2016). Real-time speech and music classiﬁcation

by large audio feature space extraction. Springer.

Eyben, F., W

ollmer, M., and Schuller, B. (2010). opens-

mile: The munich versatile and fast open-source audio

feature extractor. In Proceedings of the international

conference on Multimedia, pages 1459–1462. ACM.

Freund, Y. and Schapire, R. E. (1999). Large Margin Clas-

siﬁcation Using the Perceptron Algorithm. Machine

Learning, 37(3):277–296.

Hall, M., Frank, E., Holmes, G., Pfahringer, B., Reutemann,

P., and Witten, I. H. (2009). The weka data min-

ing software: an update. ACM SIGKDD explorations

newsletter, 11(1):10–18.

Hantke, S., Weninger, F., Kurle, R., Ringeval, F., Bat-

liner, A., Mousa, A. E.-D., and Schuller, B. (2016).

I hear you eat and speak: Automatic recognition of

eating condition and food type, use-cases, and im-

pact on asr performance. PloS one, 11(5):e.0154486.

doi:10.1371/journal.pone.0154486.

onig, F., Batliner, A., Bocklet, T., Stemmer, G., N

oth, E.,

Schnieder, S., and Krajewski, J. (2014a). Are men

more sleepy than women or does it only look like–

automatic analysis of sleepy speech. In 2014 IEEE In-

ternational Conference on Acoustics, Speech and Sig-

nal Processing (ICASSP), pages 995–999. IEEE.

onig, F., Batliner, A., N

oth, E., Schnieder, S., and Kra-

jewski, J. (2014b). Acoustic-prosodic characteristics

of sleepy speech – between performance and interpre-

tation. In Proc. of Speech Prosody, pages 864–868.

Huang, D.-Y., Ge, S. S., and Zhang, Z. (2011). Speaker

State Classiﬁcation Based on Fusion of Asymmetric

SIMPLS and Support Vector Machines. In INTER-

SPEECH 2011 – 12

Annual Conference of the Inter-

national Speech Communication Association, 2011,

Florence, Italy, Proceedings, pages 3301–3304.

Krajewski, J. and Kr

oger, B. J. (2007). Using Prosodic

and Spectral Characteristics for Sleepiness Detection.

In INTERSPEECH 2007 – 8

Annual Conference of

the International Speech Communication Association,

August 27-31, Antwerp, Belgium, Proceedings, pages

1841–1844.

Krajewski, J., Wieland, R., and Batliner, A. (2008). An

Acoustic Framework for Detecting Fatigue in Speech

Based Human-Computer-Interaction, pages 54–61.

Springer Berlin Heidelberg, Berlin, Heidelberg.

Lerch, A. (2012). An introduction to audio content analysis:

Applications in signal processing and music informat-

ics. John Wiley & Sons.

McCartt, A. T., Ribner, S. A., Pack, A. I., and Hammer,

M. C. (1996). The scope and nature of the drowsy

driving problem in new york state. Accident Analysis

& Prevention, 28(4):511–517.

Pack, A. I., Pack, A. M., Rodgman, E., Cucchiara, A.,

Dinges, D. F., and Schwab, C. W. (1995). Character-

istics of crashes attributed to the driver having fallen

asleep. Accident Analysis & Prevention, 27(6):769–

775.

Pir, D. and Brown, T. (2015). Acoustic Group Feature Se-

lection Using Wrapper Method for Automatic Eating

Condition Recognition. In INTERSPEECH 2015 –

Annual Conference of the International Speech

Communication Association, September 6-10, 2015,

Dresden, Germany, Proceedings, pages 894–898.

Pir, D., Brown, T., and Krajewski, J. (2016). Wrapper-

Based Acoustic Group Feature Selection for Noise-

Robust Automatic Sleepiness Classiﬁcation. In Pro-

ceedings of the 4

International Workshop on Speech

Relevant Acoustic Group Features for Automatic Sleepiness Recognition

213

Processing in Everyday Environments (CHiME 2016),

September 13, 2016, San Francisco, CA, USA, pages

78–81.

Pir, D., Brown, T., and Krajewski, J. (2017). Automatic

Driver Sleepiness Detection Using Wrapper-Based

Acoustic Between-Groups, Within-Groups, and In-

dividual Feature Selection. In Proceedings of the

International Conference on Vehicle Technology

and Intelligent Transport Systems, Edited by: Oleg

Gusikhin, Markus Helfert and Ant

onio Pascoal, ISBN:

978-989-758-242-4, April 22–24, Porto, Portugal,

pages 196–202.

Schuller, B. and Batliner, A. (2014). Computational par-

alinguistics: emotion, affect and personality in speech

and language processing. John Wiley & Sons.

Schuller, B., Steidl, S., and Batliner, A. (2009). The IN-

TERSPEECH 2009 Emotion Challenge. In INTER-

SPEECH 2009 – 10

Annual Conference of the Inter-

national Speech Communication Association, Septem-

ber 6–10, 2009, Brighton, UK, Proceedings, pages

312–315.

Schuller, B., Steidl, S., Batliner, A., Schiel, F., and Kra-

jewski, J. (2011). The INTERSPEECH 2011 Speaker

State Challenge. In INTERSPEECH 2011 – 12

An-

nual Conference of the International Speech Commu-

nication Association, 2011, Florence, Italy, Proceed-

ings, pages 3201–3204.

Schuller, B., Steidl, S., Batliner, A., Schiel, F., Krajewski,

J., Weninger, F., and Eyben, F. (2014). Medium-term

speaker statesa review on intoxication, sleepiness and

the ﬁrst challenge. Computer Speech & Language,

28(2):346–374.

Shahid, A., Wilkinson, K., Marcu, S., and Shapiro, C. M.

(2012). Karolinska sleepiness scale (kss). In STOP,

THAT and One Hundred Other Sleep Scales, pages

209–210. Springer.

Sumner, M., Frank, E., and Hall, M. (2005). Speeding

Up Logistic Model Tree Induction, pages 675–683.

Springer Berlin Heidelberg, Berlin, Heidelberg.

Vanlaar, W., Simpson, H., Mayhew, D., and Robertson, R.

(2008). Fatigued and drowsy driving: A survey of

attitudes, opinions and behaviors. Journal of Safety

Research, 39(3):303–309.

Weninger, F., Eyben, F., Schuller, B., Mortillaro, M., and

Scherer, K. (2013). On the acoustics of emotion in au-

dio: What speech, music, and sound have in common.

Frontiers in psychology, 4:227–239.

ICT4AWE 2018 - 4th International Conference on Information and Communication Technologies for Ageing Well and e-Health

214
