Specification of Personal Data Protection Requirements

Analysis of Legal Requirements from the GDPR Regulation

Mário Fernandes

, Alberto Rodrigues

da Silva

and António Gonçalves

1,2

INESC-ID, Instituto Superior Técnico, Universidade de Lisboa, Portugal

Escola Superior de Tecnologia de Setúbal, Instituto Politécnico de Setúbal, Portugal

Keywords: Personal Data Protection, Requirements Specification, Rslingo, Regulation (EU) 2016/679, GDPR.

Abstract: The European Union establishes in the Regulation 2016/679, or GDPR (General Data Protection

Regulation), a set of legal dispositions to achieve the protection of natural persons in what personal data

processing and the free movement of such data is concerned. When those dispositions are considered in the

development of information systems, the later become attainable for legal approval within that scope. This

paper presents the methodology we are following to elaborate a reusable catalogue of personal data

protection requirements aligned with the GDPR. Following a separation-of-concerns approach, the

catalogue shall serve the purpose of constructing information systems able to communicate with those that

process individuals’ personal data, to materialize the regulatory data protection capabilities disposed in the

GDPR. In that context, the elicitation of system requirements demands for the interpretation of a legal

document by business analysts, which consists of a scientifically relevant challenge. This research is

contextualized by the RSLingo initiative, a model-driven requirements engineering approach for the

rigorous specification of system requirements. In particular this paper discusses the GDPR’s requirements

defined as a catalogue of both business goals and system goals.

1 INTRODUCTION

The need to protect valuable information,

particularly of individuals, is a societal challenge

imposed by many governments to organizations.

Within the European scope, the General Data

Protection Regulation (GDPR or Regulation

2016/679) was defined by the European Union,

consisting of a set of legal dispositions to achieve

the protection of natural persons in what personal

data processing and the free movement of such data

is concerned (EU, 2016). The guarantee of

compliance with the GDPR, at the level of

information systems, demands for an effort from

business analysts when interpreting such legal

document.

The goal of this paper is to propose a rigorous

specification of requirements included in the GDPR,

and consequently to promote a better and systematic

interpretation of those legal requirements.

From the analysis of the GDPR document, the

aim is to elaborate a reusable catalogue of personal

data protection requirements to be used in the

design and implementation of information systems

able to communicate with those that process

individuals’ personal data, to turn them attainable

for legal approval within the scope of personal data

protection, specifically within the provisions of the

GDPR.

This research is contextualized within the

RSLingo initiative, a model-driven requirements

engineering approach for the rigorous specification

of system requirements (Ferreira & Silva, 2012;

Silva, 2015). The analysis of the GDPR involved

several tasks, namely reading, manual knowledge

extraction, and caracterization of many concepts and

sentences expressed in that legal document. The

analysis was supported by the RSLingo RSL

language (Silva, 2017, 2018), in which requirements

are defined at different abstraction levels, yet they

always represent an expression of stakeholders’

needs. Stakeholder, glossary of terms, business

process and business goal constructs allow to

express a high-abstraction-level overview of

stakeholders’ needs and concerns. From those,

system goal, functional requirement, quality

requirement, constraint, use case or user story

constructs can be used to specify their concerns at

system level. From the later, test cases can be

derived and defined in order to drive a verification

398

Fernandes, M., Rodrigues Silva, A. and Gonçalves, A.

Speciﬁcation of Personal Data Protection Requirements.

DOI: 10.5220/0006810603980405

In Proceedings of the 20th International Conference on Enterprise Information Systems (ICEIS 2018), pages 398-405

ISBN: 978-989-758-298-1

process (Silva, Paiva, & Silva, 2018). At a particular

point in time, especially if the software development

project is in its earlier stages, it may be just enough

to specify these requirements using only business

and/or system goal constructs.

The paper is structured as follows. Section 2

introduces the RSLingo RSL language, which

supports this research. Section 3 explains our

methodology of systematically analysing the GDPR

based on the background research. Section 4

presents some results obtained from applying this

methodology, namely through the presentation of

some produced work products. Section 5 discusses

some challenges addressed by our research, together

with its main contribution, and critically elaborates

on related work. Finally, Section 6 provides for

some concluding remarks and future direction for

our research.

2 BACKGROUND

RSLingo is a long-term research initiative in the

Requirements Engineering area (Ferreira & Silva,

2012). It is a linguistic approach to improve the

quality of requirements specifications. Although

being the most common and preferred form of

representing requirements, natural language is prone

to producing ambiguous and inconsistent

documents, hard to automatically validate or

transform into other kinds of artefacts (Silva, 2017).

Figure 1: RSL metamodel (simplified). The constructs in dark grey background are applied in the scope of this paper.

Businesslevel

Systemrelationsview

Systemlevel

Systemrequireme nt sview

Sta tema ch i nesview

Systemsvie w

Entities vie w

Actors view

Businessgoals viewGlossaryview

Businessprocessesview Stakeholdersvie w

BusinessProcess

GlossaryTerm BusinessGoal

Actor

UseCase

DataEntity

Stakeholder

FunctionalRequirement

DataEntityVie w

QualityRequire m ent

Constraint

StateMac hine

+

+Action

+State

SystemGoal

SystemRelation

System

UserStory

Glossary

BusinessEvent

BusinessFlow

Entity

Requirement

refere nc e

maste r

source

deta i l

initiates

pa rt ici pates

participant

externalparticipant

ta rget

Speciﬁcation of Personal Data Protection Requirements

399

RSLingo RSL. (Requirements Specification

Language) (Silva, 2017, 2018) is a comprehensive

domain-specific language designed to address

general-purpose RE activities such as the rigorous

specification, automatic validation, persistence and

management of system requirements. RSL is based

on other languages such RSL-IL (Ferreira & Silva,

2013), RSL-IL4Privacy (Caramujo & Silva, 2015;

Silva, Caramujo, Monfared, Calado, & Breaux,

2016), Pohl’s (Pohl, 2010), XIS* (Ribeiro & Silva,

2014a, 2014b; Silva, Saraiva, Silva, & Martins,

2007) and SilabREQ (Savić et al., 2015). In a more

detailed way, RSL is a controlled natural language to

support the elaboration of SRSs (Systems

Requirements Specifications) in a systematic,

rigorous, consistent and less ambiguous way,

namely by using the RSL Excel Template, which is

based in RSL itself. Representing domain

knowledge with such SRSs has in itself a way of

providing business stakeholders with a better

understanding of natural language statements that

represent requirements. RSL is a language that

includes a rich set of fundamental RE-specific

constructs logically arranged into views, according

to two dimensions: abstraction levels and RE

concerns, which means the architecture of RSL is

bidimensional and multiview (Silva, 2017).

Figure 1 depicts a simplified version of the RSL

metamodel. The two abstraction levels are illustrated

in the diagram: the business level and the system

level. The business level groups the views closer to

the business perspective, whereas the system level

groups the views closer to the system perspective.

Each view gathers one or more constructs. System

constructs may depend on some business constructs

(e.g. Entities may depend on Glossary terms and

Actors may depend on Stakeholders). These

constructs are defined as linguistic patterns and

represented textually by mandatory or optional

fragments (text snippets) (Silva, 2017). The RSL is

structured according a large set of constructs, such

as: glossary term, stakeholder, business goal,

business process, business event, business flow,

system, actor, data entity and data entity view,

system goal, functional requirement, quality

requirement, constraint, use case, user story, state

machine (Silva, 2017).

The personal data protection requirements

(extracted from the GDPR) are under specification

with a set of RSL constructs selected according to

the chosen linguistic style, appropriate for the early

stages of the requirements specification. That set is

composed of some business level views together

with the system goals view. (However, we could

have specified these requirements at the system level

following other styles by using constructs such as

functional requirements, quality requirements and

constraints; use cases or user stories).

3 GDPR ANALYSIS

The GDPR is targeted at the protection of natural

persons regarding the processing of their personal

data by automated or manual means, only in the case

that those data are contained or intended to be

contained in filing systems. According to the GDPR,

a filing system is set of structured personal data

accessible via specific criteria, whether centralized

or not. However, the GDPR mentions not only filing

systems, but also (secure) systems to which

controllers may grant remote and direct access of

data subjects to their own personal data.

Figure 2: Systems and stakeholders defined in the scope of GDPR.

«System»

Processing System

(A)

«System»

Regulatory System

data subject (A)

controller

data protection

officer

processor

superv isory authority

«System»

Processing

System (B)

data subject (B)

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

400

Nevertheless and based on an interpretation of

the GDPR, other systems may also be considered,

namely systems where controllers or processors

could register violations of data, where data subjects

could request for the rectification of data, where

controllers or processors could record processing

activities and where data protection officers could

monitor that registration.

For the purpose of this paper, the GDPR is an

elicitation source of not only business but also

system requirements to consider when developing

information systems able to communicate with those

that process individuals’ personal data, in order to

materialize the regulatory data protection

capabilities disposed in the GDPR. This may imply

the existence of two types of systems: regulatory

systems and processing systems, whose operation

includes, yet it is not restricted to processing

individuals’ personal data. Figure 2 shows the two

types of systems mentioned based on the GDPR‘s

Introductory items 15 and 16, and Article 2(1). This

paper presents not only business and system

requirements of regulatory systems, but also a RSL-

based methodology to extract these requirements

from legal documents. In the context of personal

data protection, system requirements state the way in

which the business requirements shall be met in the

application domain i.e. how the data shall be

protected regardless of the technology used by those

systems to implement that protection.

Figure 3: Methodology for analysing the GDPR.

contextualize

2. define

stakeholders

4.1. define

systems

4.2. define

system

relations

5.1. define

business

processes

5.2. define

business

goals

6. define

system goals

Glossary

Stakeholders

Domain

model w ith

domain terms

System

Relations

SystemGoals

BusinessGoals

BusinessProcessesSystems

3. represent

domain terms

(and

stakeholders)

Speciﬁcation of Personal Data Protection Requirements

401

The analysis of the GDPR involved a set of tasks

as depicted in Figure 3. The objects shown in this

figure represent work products as partially include in

a RSL specification.

Task 1: Contextualization. This task consisted of

the familiarization of the business analyst with the

domain of personal data protection. The work

product of this task is a list containing the definition

of the business domain terms to better support the

understanding of regulatory systems, from a

business perspective.

Task 2: Definition of Stakeholders. This task

consisted of identifying and characterizing the

parties interested in the development and operation

of regulatory systems.

Task 3: Representation of Structure Composed of

Domain Terms (and stakeholders). This task

consisted of modelling the relation between the main

domain terms identified in the GDPR, along with

their attributes. A UML class diagram can be

elaborated to complement that understanding.

Task 4: Definition of Systems and System

Relations. This task consisted of (subtask 4.1)

identifying each system involved in the business

domain of personal data protection, regardless of

being an in-scope or an out-of-scope system, and

characterizing its type e.g. whether system or

subsystem; and (subtask 4.2) characterizing the

interactions between source and target systems

involved in the business domain of personal data

protection, whether those systems being internal

systems (in-scope) or external systems (out-of-

scope).

Task 5: Definition of Business Processes and

Business Goals. This task consisted of (subtask 5.1)

identifying and characterizing the business

processes, based on an ordering of tasks concerned

with regulating the processing of personal data; and

(subtask 5.2) identifying and characterizing the

businessgoals to be achieved with the application of

the provisions in the GDPR to regulatory systems.

Although not represented in the diagram, this task

also included the identification and characterization

of business flows to express control flows between

business processes or between business processes

and business events – business flows can be of type

sequential, conditional (equivalent to the BPMN

exclusive gateway) or parallel (equivalent to the

BPMN parallel gateway).

Task 6: Definition of System Goals. This task

consisted of identifying and characterizing the

systemgoals to be achieved with the application of

the provisions in the GDPR to regulatory and

processing in-scope systems.

The execution of these tasks is guided by a

control flow that suggests the adopted GDPR

analysis methodology. Figure 3 is complemented by

the illustration of dependencies between the tasks

and the RSL constructs that are progressively

specified throughout that flow.

4 SPECIFICATION OF DATA

PROTECTION

REQUIREMENTS WITH THE

RSL

This section demonstrates part of the work products

originated from each task of the GDPR analysis

methodology described in Section 3. Some columns

from the tables in the RSL Excel Template were

omitted due to space restrictions (e.g. the

Description or Priority BusinessGoals’ attributes

were omitted in the corresponding table).

4.1 Stakeholders View

Stakeholders are people and organizations that

influence the development of an information system

or will be affected by its operation, in this case, the

operation of regulatory systems.

Table 1: Stakeholders identified by GDPR.

Name Description Type

Data

Subject

An identifiable natural person who can

be identified, directly or indirectly, in

particular by reference to an identifier

such as a name, an identification

number, location data, an online

identifier or to one or more factors

specific to the physical, physiological,

genetic, mental, economic, cultural or

social identity.

Person

Controller

A natural or legal person, public

authority, agency or other body which,

alone or jointly with others, determines

the purposes and means of the

processing of personal data

Team

Processor

A natural or legal person, public

authority, agency or other body which

processes personal data on behalf of the

controlle

Team

Supervisory

Authority

An independent public authority which

is established by a EU Member State.

Organi-

zation

Data

Protection

Officer

(DPO)

An enterprise security leadership role

responsible for overseeing data

protection strategy and implementation

to ensure compliance with GDPR

requirements.

Person

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

402

Stakeholders are original sources of requirements,

despite that, in the case of this paper, requirements

were elicited from the GDPR itself. Table 1 contains

some stakeholders interested in the development of

regulatory systems. Some stakeholders will be users

of those systems, hence will be constituted Actors in

the Actors view. A Stakeholder is characterized, at

least, by its name and type, as stated in the table.

4.2 Business Goals View

Business goals can be faced as the value that the

system represents for the business, in this case that

regulatory system represent to the protection of

personal data and the free movement of such data.

Table 2 lists the definition of some business goals

that, once achieved with the development and

operation of regulatory systems, allow warranting

the regulatory data protection capabilities

provisioned by the GDPR. The identification and

characterization of business goals constitutes a

starting point for the identification and

characterization of system goals. The values in the

column Part of indicate the aggregation relations

that may exist between BusinessGoals, which means

that they can be decomposed into sub-

BusinessGoals. (The tags preceding the

BusinessGoals are their id(entifiers) and express no

particular order in what the items or articles of the

GDPR are concerned.)

Table 2: Some business goals extracted from the GDPR.

Name Part of

bg_1: Facilitate the exercise of the data

subject’s rights

bg_1.1: Right to obtain from the controller

confirmation as to whether or not personal

data concerning him/her are being

rocesse

bg_1

bg_1.2: Right to transmit personal data to

another controller without hindrance from

the controller to whom they have been

rovide

bg_1

bg_6: Lawfulness, fairness and

transparency of personal data processing

(

art. 6

)

bg_7: Conditions for consent (art. 7)

bg_7.1: Where processing is based on

consent, the controller shall be able to

demonstrate that the data subject has

consented to processing of his or her

ersonal data.

bg_7

bg_7.2: The data subject shall have the

right to withdraw his or her consent at any

time.

bg_7

4.3 System Goals View

System goals can be derived from business goals,

since the first operationalize the later in a particular

system context (in the case of this paper, the context

of the regulatory system). This means that if system

goals are met, business goals are equally met, hence

the provisions in the GDPR are respected by the

regulatory system. Table 3 depicts the definition of

some system goals extracted from the GDPR for

regulatory systems. Additionally, to allow a

comparative insight over both types of system, Table

4 presents some system goals also extracted from the

GDPR for processing systems. The semantics

associated with each column in both tables is the

same as the one associated with the column of same

name in Table 2.

Table 3: System goals extracted from the GDPR for

regulatory systems.

Name Part of

sg_1: Record personal data processing

activities

sg_1.1: Maintain a record of the personal

data processing activities under the

responsibility of each controlle

sg_1

sg_1.2: Maintain a record of all categories

of personal data processing activities

carried out by each processor on behalf of

a controlle

sg_1

sg_2: Personal data breaches shall be

notified to the competent supervisory

authority and, eventually, the data subject

Table 4: System goals extracted from the GDPR for

processing systems.

Name Part of

sg_1: Ensure a level of security

appropriate for the data subject’s rights

and freedoms

sg_1.1: Pseudonymize and encrypt

ersonal data

sg_1

sg_1.2: Keep the confidentiality, integrity,

availability and resilience of processing

systems and services

sg_1

sg_1.3: Restore the availability and access

to personal data, in a timely manner, in the

event of a physical or technical incident

sg_1

sg_1.4: Execute a process to regularly test,

assess and evaluate the effectiveness of

technical measures concerned with the

security of personal data processing

sg_1

Speciﬁcation of Personal Data Protection Requirements

403

5 DISCUSSION

Analysing a legal document like the GDPR

encompasses a challenge for business analysts

working in the development of information systems

capable of processing personal data according to the

legal dispositions in that document, as well as for

business analysts working in the development of

information systems responsible for providing the

electronic means to regulate the processing of

personal data.

The analysis effort required by the parties that

must comply with the dispositions in the GDPR is

reduced with the reuse of the work products from the

analysis methodology reported in this paper. On one

hand, reporting to the business level work products

(e.g. Glossary, Stakeholders and BusinessGoals),

they support a better understanding of the GDPR,

from which regulatory systems can be further

designed and implemented. They also augment the

comprehensibility of the personal data protection

business domain. On the other hand, reporting to the

system level work products (e.g. Systems and

SystemGoals), they provide for a rigorous

interpretation of the GDPR, from which, specifically

in the scope of our research, regulatory systems can

be further designed and implemented.

Prior efforts of other authors have been

undertaken to systematize past research concerned

with the handling of legal texts for software systems

development (Otto & Antón, 2007). The same

authors who surveyed those efforts, together with

Massey (Massey, Otto, & Antón, 2009), later

reviewed specifications of legally compatible

systems and produced requirements to foster legal

compatibility. However, those authors focused on

goals to specify requirements for the development of

legally compatible systems. Our approach to the

specification of such systems is broader in terms of

the views over legal texts it considers (the RSL

views).

Hoffmann, et al. (Hoffmann et al., 2012)

presented in 2012 some research on the

commonality within legal software requirements and

proposed legal software requirements patterns

(extracted from recurring legal requirements) to

produce catalogues of that kind of requirements. The

research reported in this paper involved dealing with

linguistic patterns and linguistic styles, not for legal

software requirements in the broad sense, but for the

specification of personal data protection

requirements, also extracted from legal documents to

produce a personal data protection requirements

catalogue.

6 CONCLUSION

The analysis of the GDPR is a starting point for the

further analysis, design and implementation of

information systems capable of ensuring the

confidentiality, integrity, availability and resilience

of the personal data they process. Due to

technological evolution, several services currently

share data and part of it relies on personal data

related to banking, healthcare and other data

domains. Those data require strict measures to

protect them from diversion for improper purposes

with irreversible consequences, yet maintaining the

free movement of such data. The application of

penalties for improper diversion purposes comes

from the detection of infringements, so the

extraction of business and system requirements from

the GDPR is of extreme importance, in order to

specify and further develop regulatory systems able

to communicate with processing systems and

operationalize the regulatory capabilities disposed in

the GDPR. This paper presented a systematic

approach to the analysis of the GDPR from both

business and system perspectives, useful for the

development and operation of regulatory systems.

The paper illustrated the approach with a sample of

some work products originated from executing the

analysis methodology.

Future work includes further analysis of the

GDPR from the system perspective, namely

involving the specification of Actors, DataEntities

and StateMachines views, as well as developing

automatic transformations of requirements into

formats other than the RSL Excel Template, along

with complementary diagrams. These model

transformations will require the use of RSL in its

programmatic shape, therefore transforming the

RSL-based SRS document in Excel format into an

even more rigorous representation. The RSL-based

specification of the GDPR will act as a catalogue of

personal data protection requirements and the

ultimate goal is for it to be reused in any project of

personal data regulatory systems development. In

future research efforts, the methodology to analyse

legal documents presented in this paper may be

applied to other regulatory documents that impose

requirements to information systems specification

and further development e.g. ISO 27000.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

404

ACKNOWLEDGEMENTS

This work was partially supported by national funds

under FCT projects UID/CEC/50021/2013 and

CMUP-EPB/TIC/0053/2013.

REFERENCES

Caramujo, J., & Silva, A. R. d. (2015). Analyzing Privacy

Policies Based on a Privacy-Aware Profile: The

Facebook and LinkedIn Case Studies. 17th IEEE

Conference on Business Informatics (CBI), Lisboa,

Portugal.

Regulation 2016/679 of the European Parliament and of

the Council of 27 April 2016 on the protection of

natural persons with regard to the processing of

personal data and on the free movement of such data

(General Data Protection Regulation) (2016).

Ferreira, D. d. A., & Silva, A. R. d. (2012). RSLingo: An

Information Extraction Approach toward Formal

Requirements Specifications. 2nd IEEE Model-Driven

Requirements Engineering Workshop (MoDRE),

Chicago, Illinois, USA.

Ferreira, D. d. A., & Silva, A. R. d. (2013). RSL-IL: An

Interlingua for Formally Documenting Requirements.

3rd International Workshop on Model-Driven

Requirements Engineering (MoDRE), Rio de Janeiro,

Brazil.

Hoffmann, A., Schulz, T., Hoffmann, H., Jandt, S.,

Roßnagel, A., & Leimeister, J. M. (2012). Towards the

Use of Software Requirement Patterns for Legal

Requirements. 2nd International Requirements

Engineering Efficiency Workshop (REEW), Essen,

Germany.

Massey, A. K., Otto, P. N., & Antón, A. I. (2009).

Prioritizing Legal Requirements. 2nd International

Workshop on Requirements Engineering and Law

(RELAW), Atlanta, Georgia, USA.

Otto, P. N., & Antón, A. I. (2007). Addressing Legal

Requirements in Requirements Engineering. 15th

IEEE International Requirements Engineering

Conference (RE), New Delhi, India.

Pohl, K. (2010). Requirements Engineering:

Fundamentals, Principles, and Techniques. Berlin

Heidelberg: Springer-Verlag.

Ribeiro, A., & Silva, A. R. d. (2014a). Evaluation of XIS-

Mobile, a Domain Specific Language for Mobile

Application Development. Journal of Software

Engineering and Applications, 7(11), 906-919.

Ribeiro, A., & Silva, A. R. d. (2014b). XIS-Mobile: A DSL

for Mobile Applications. 29th Annual ACM

Symposium on Applied Computing (SAC), Gyeongju,

Korea.

Savić, D., Vlajić, S., Lazarević, S., Antović, I., Stanojević,

V., Milić, M., & Silva, A. R. d. (2015). Use Case

Specification Using the SilabReq Domain Specific

Language. Computing and Informatics, 34(4), 877-

910.

Silva, A. R. d. (2015). Model-driven engineering: A

survey supported by the unified conceptual model.

Computer Languages, Systems & Structures,

43(October 2015), 139-155.

Silva, A. R. d. (2017). Linguistic Patterns and Linguistic

Styles for Requirements Specification (I): An

Application Case with the Rigorous RSL/Business-

Level Language. 22nd European Conference on

Pattern Languages of Programs (EuroPLoP), Irsee,

Germany.

Silva, A. R. d. (2018). Rigorous Requirements

Specification: Specification of Use Cases with the

RSLingo RSL Language. Lisboa: INESC-ID.

Silva, A. R. d., Caramujo, J., Monfared, S., Calado, P., &

Breaux, T. (2016). Improving the Specification and

Analysis of Privacy Policies: The RSLingo4Privacy

Approach. 18th International Conference on Enterprise

Information Systems (ICEIS), Rome, Italy.

Silva, A. R. d., Paiva, A., & Silva, V. (2018). Towards a

Test Specification Language for Information Systems:

Focus on Data Entity and State Machine Tests. 6th

International Conference on Model-Driven

Engineering and Software Development

(MODELSWARD), Funchal, Madeira, Portugal.

Silva, A. R. d., Saraiva, J., Silva, R., & Martins, C. (2007).

XIS-UML Profile for eXtreme Modeling Interactive

Systems. 4th International Workshop on Model-Based

Methodologies for Pervasive and Embedded Software

(MOMPES), Braga, Portugal.

Speciﬁcation of Personal Data Protection Requirements

405
