Yet Another Automated OLAP Workload Analyzer:

Principles, and Experiences

Alfredo Cuzzocrea

1,2

, Rim Moussa

and Enzo Mumolo

DIA Department, University of Trieste, Italy

ICAR-CNR, Italy

LaTICE and University of Carthage, Tunisia

Keywords:

Data Warehouse Tuning, OLAP Intelligence, Data Warehouse Workloads, OLAP Workloads.

Abstract:

In order to tune a data warehouse workload, we need automated recommenders on when and how (i) to

partition data and (ii) to deploy summary structures such as derived attributes, aggregate tables, and (iii) to

build OLAP indexes. In this paper, we share our experience of implementation of an OLAP workload analyzer,

which exhaustively enumerates all materialized views, indexes and fragmentation schemas candidates. As a

case of study, we consider TPC-DS benchmark -the de-facto industry standard benchmark for measuring the

performance of decision support solutions including.

1 INTRODUCTION

Decision Support Systems (DSS) are designed to em-

power the user with the ability to make effective de-

cisions regarding both the current and future activi-

ties of an organization. One of the most prominent

technologies for knowledge discovery in DSS envi-

ronments are On-line Analytical Processing (OLAP)

technologies. OLAP relies heavily upon a data model

known as the multidimensional database and the Data

cube. The latter has been playing an essential role

in the implementation of OLAP (Gray et al., 1997;

Vassiliadis, 1998a). However, challenges related to

Performance Tuning are to be addressed. OLAP wor-

kload Performance Tuning is usually based on (i) in-

dexes, (ii) summary data, i.e. derived attributes and

aggregate tables, and (iii) data fragmentation.

The paper outline is the following, in Section II,

we overview Performance Tuning Strategies, from de-

velopper perspective. In Section III, we present our

workload analyzer and our ﬁrst experience with TPC-

DS Benchmark. Finally we conclude the paper.

2 OLAP WORKLOAD

PERFORMANCE TUNING

The term On-line Analytical Processing (OLAP) is

introduced in 1993 by E. Codd (Codd et al., 1993).

This model constitutes a decision support system fra-

mework which affords the ability to calculate, conso-

lidate, view, and analyze data according to multiple

dimensions. OLAP relies heavily upon a data mo-

del known as the multidimensional databases (MDB)

(Kimball and Ross, 2013; Kimball et al., 1998; Mo-

lina, 2013; Imhoff et al., 2003; Inmon, 2005; DeWitt

et al., 2005; Surajit and Umeshwar, 1997; Codd et al.,

1993; Agarwal et al., 1996; Gyssens and Lakshma-

nan, 1997; Agrawal et al., 1997; Gray et al., 1997;

Vassiliadis, 1998a). An MDB schema contains a lo-

gical model consisting of OLAP cubes. Each OLAP

Cube is described by a fact table (facts), a set of di-

mensions and a set of measures. Multiple MDB de-

sign methods were proposed in the litterature and are

described in (Vassiliadis, 1998b; Cabibbo and Tor-

lone, 1998; Niemi et al., 2001; Hung et al., 2004;

Nair et al., 2007; Malinowski and Zim

anyi, 2008;

Romero and Abell

o, 2009; Thanisch et al., 2011).

In (Cuzzocrea and Moussa, 2013; Cuzzocrea et al.,

2013a), we detail a framework for MDB schemas de-

sign, successfully applied to turn TPC-H benchmark

into a multi-dimensional benchmark TPC-H*d. In or-

der to tune a data warehouse workload, we need auto-

mated recommenders on when and on how (i) to par-

tition data and (ii) to deploy summary structures (e.g.

derived attributes, aggregate tables, sketches synop-

sis, histograms synopsis), and (iii) to build OLAP in-

dexes.

Cuzzocrea, A., Moussa, R. and Mumolo, E.

Yet Another Automated OLAP Workload Analyzer: Principles, and Experiences.

DOI: 10.5220/0006812202930298

In Proceedings of the 20th International Conference on Enterprise Information Systems (ICEIS 2018), pages 293-298

ISBN: 978-989-758-298-1

293

Many research work investigated distributed rela-

tional data warehouses and an adjunct mid-tier for pa-

rallel cube calculus, namely OLAP* (Cuzzocrea et al.,

2013b). Other are investigating new systems SQL-on-

Hadoop Systems (e.g. Apache Hive, Apache Spark

SQL, Apache Drill, Cloudera Impala, IBM BigInsig-

hts). Partitioning schemes are very important, good

data fragmentation schemes allows parallel IO and

parallel processing. Automated distributed database

design was investigated in many research papers and

by DBMS vendor leaders AutoPart (Papadomanolakis

and Ailamaki, 2004),DB2 Design Advisor(Zilio et al.,

2004), Database Tuning Advisor for MS SQL Server

(Agrawal et al., 2004a; Agrawal et al., 2004b), and

DDB-Expert (Moussa, 2011).

Indexes and Materialized Views are physical

structures which aim at accelerating performance,

like similarly OLAP query approximation approaches

(e.g., (Cuzzocrea et al., 2009; Cuzzocrea and Ma-

trangolo, 2004)). Many research papers cover auto-

mated selection of materialized views and indexes for

OLAP workloads AutoAdmin (Agrawal et al., 2006),

Alerter Approach (Hose et al., 2008), Semi-Automatic

Index Tuning (Schnaitter and Polyzotis, 2012), Au-

toMDB (Cuzzocrea and Moussa, 2013; Cuzzocrea

et al., 2013a). Related work report experiences with

TPC-H benchmark (Transaction Processing Council,

2013b). The latter is obsolete now. Its successor TPC-

DS (Transaction Processing Council, 2013a) is the de-

facto industry standard benchmark for measuring the

performance of decision support solutions. In this pa-

per, we turn TPC-DS into a multidimensional bench-

mark and we analyze TPC-DS benchmark.

3 A MULTI-DIMENSIONAL

DATABASE TPC-DS

There are few decision-support benchmarks out of the

TPC benchmarks. Next, we overview most known

DSS benchmarks, APB-1 (OLAP Council, ) has been

released in 1998 by the OLAP council. APB-1 wa-

rehouse dimensional schema is structured around ﬁve

ﬁxed size dimensions and its workload is composed

of 10 queries. APB-1 is proved limited (Erik, 1998)

to evaluate the speciﬁcities of various activities. It

proposes a single performance metric termed AQM

(Analytical Queries per Minute). The metric AQM

denotes the number of analytical queries processed

per minute including data loading and computation

time.

The most prominent benchmarks for evaluating

decision support systems are the various benchmarks

issued by the Transaction Processing Council (TPC).

Since two decades, TPC-H benchmark is the most

used benchmark in the research community. The

TPC-H benchmark (Transaction Processing Coun-

cil, 2013b) exploits a classical product-order-supplier

model. It consists of a suite of business oriented ad-

hoc queries and concurrent data modiﬁcations. The

workload is composed of twenty-two parameterized

decision-support SQL queries with a high degree of

complexity and two refresh functions: RF-1 new sa-

les (new inserts) and RF-2 old sales (deletes). The

TPC-DS benchmark is launched for next generation

of decision support system benchmarking to replace

the TPC-H benchmark. It is described in next Section.

3.1 TPC-DS Benchmark

TPC-DS (Transaction Processing Council, 2013a)

was designed to examine large volumes of data, exe-

cute complex queries of various operational require-

ments and complexities (e.g., ad-hoc, reporting, itera-

tive OLAP, data mining) within large number of user

sessions. The benchmark stresses hardware system

performance in the areas of CPU utilization, memory

utilization, I/O subsystem utilization, and the ability

of the operating system and database software to per-

form TPC-DS workload. The TPC-DS schema mo-

dels seven data marts the sales and sales returns pro-

cess for an organization that employs three primary

sales channels: store, catalogs, and the Internet, as

well as the Inventory. All data is periodically syn-

chronized with source OLTP databases through data-

base maintenance functions. The schema includes 7

fact tables and 17 dimension tables.

• Fact tables: store sales, store returns, ca-

talog sales, catalog returns, web sales,

web returns, inventory.

• Dimension tables: store, call center, cata-

log

page, web site, web page, warehouse, custo-

mer, customer address, customer demographics,

date dim, household demographics, item, in-

come band, promotion, reason, ship mode,

time dim.

TPC-DS workload contains 99 SQL queries, cove-

ring SQL99, SQL-2003 (Eisenberg et al., 2004) (i.e.,

window functions) and OLAP capabilities. TPC-DS

benchmark reports two main metrics (i) the Query-

per-Hour Performance Metric (Qph@Size and (ii)

The Price-Performance Metric ($/Qph) which reﬂects

the ratio of costs to performance.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

294

Figure 1: Data View of TPC-DS Cube 91 -a sub-view of Catalog Returns Datamart.

3.2 Turning TPC-DS Benchmark into a

Multi-dimensional Benchmark

In order to turn the TPC-DS benchmark into a mulm-

tidimensional benchmark, an initial schema is for-

med. The initial schema consists of all the cubes

required to efﬁciently answer the TPC-DS queries.

Each query is mapped to a minimal number of OLAP

cubes. We design each OLAP cube with the relevant

fact table, dimensions and measures. This leads to

the deﬁnition of multiple cubes. Hereafter, we detail

the process leading to the deﬁnition of each cube. We

used the framework for automating multidimensional

database schema design detailed in (Cuzzocrea and

Moussa, 2013; Cuzzocrea et al., 2013a).

OLAP hypercube Cube 91 shown in Figure 1 is

deﬁned as a transform of Q91 (illustrated in Figure

2) into an OLAP hypercube. In the example, Cube

91 is an OLAP cube for Q91 of TPC-DS Benchmark

(Transaction Processing Council, 2013a). Cube 91

has six dimensions (i) ’Call Center’, (ii) ’Returned

Date’, (iii) ’Returning Customer Marital Status’, (iv)

’Returning Customer Education Status’, (v) ’Retur-

ning Customer GMT Offset’ and (vi) ’Buy Potential’

and one numeric measure ’Sum of all Returns’ Net

Losses’, and performs over ’Catalog Returns facts’.

4 OLAP WORKLOAD ANALYZER

Tuning a database is a process that includes selection

of indexes, materialized views, derived attributes, and

fragmentation schemas.There are a number of tools

that have been designed to take the responsibility

from the database designer to advise the designer on

good choices: SAP, Oracle, Vertica, PoWA of post-

gres, Teradata.

4.1 TPC-DS Numbers

We parse cubes (XML ﬁles), detect common dimensi-

ons and measures as well as different dimensions and

measures for each pair of cubes.

4.2 Candidates Enumeration

The tuning advisor generates candidate indexes, ma-

terialized views, derived attributes, fragmentation

schemas and assesses the weight of each recommen-

dation based one or combination of these recom-

mendations. We implemented a greedy approach to

choosing indexes, materialized views, derived attri-

butes and fragmentation schemas. Indeed, we enume-

rate automatically all candidate indexes, materialized

views, derived attributes and fragmentation schemas.

• Candidate Indexes: For each cube, we consider

indexes on foreign keys for the fact table, or join

Yet Another Automated OLAP Workload Analyzer: Principles, and Experiences

295

Define YEAR = random(1998,2002, uniform);

Define MONTH = random(11,12,uniform);

Define BUY_POTENTIAL = text({"1001-5000",1},

{">10000",1},{"501-1000",1},{"0-500",1},

{"Unknown",1},{"5001-10000",1});

Define GMT = text({"-6",1},{"-7",1});

SELECT cc_call_center_id Call_Center,

cc_name Call_Center_Name,

cc_manager Manager,

SUM(cr_net_loss) Returns_Loss

FROM call_center,

catalog_returns,

date_dim,

customer,

customer_address,

customer_demographics,

household_demographics

WHERE cr_call_center_sk = cc_call_center_sk

AND cr_returned_date_sk = d_date_sk

AND cr_returning_customer_sk = c_customer_sk

AND cd_demo_sk = c_current_cdemo_sk

AND hd_demo_sk = c_current_hdemo_sk

AND ca_address_sk = c_current_addr_sk

AND d_year = [YEAR]

AND d_moy = [MONTH]

AND ( (cd_marital_status = ’M’ AND

cd_education_status = ’Unknown’)

OR (cd_marital_status = ’W’ AND

cd_education_status = ’Advanced Degree’))

AND hd_buy_potential like ’[BUY_POTENTIAL]%’

AND ca_gmt_offset = [GMT]

GROUP BY cc_call_center_id, cc_name, cc_manager,

cd_marital_status, cd_education_status

ORDER BY SUM(cr_net_loss) DESC;

Figure 2: SQL Statement of TPC-DS Query Q91.

indexes, simple and composite indexes attributes

of dimension tables. For each dimension table

with n attributes invoked for the calculus of cube,

the number of indexes is













+ ... +





. Indexes types depend on cardinality of the

dimension. Indeed, bitmaps are proposed for low

cardinality dimensions and B-Tree based indexes

are proposed for high cardinality dimensions. In

practice, this choice is one of the principal fac-

tors that inﬂuence whether a database design gi-

ves acceptable performance. Two important fac-

tors to consider are: (i) The existence of an index

on an attribute may speed up greatly the execution

of those queries in which a value, or range of va-

lues, is speciﬁed for that attribute, and may speed

up joins involving that attribute as well; (ii) On

the other hand, every index built for one or more

attributes of some relation makes insertions, dele-

tions, and updates to that relation more complex

and time-consuming.

• Candidate Materialized Views: For each a n di-

mensional cube, Based on the ALL values, the

data cube is divided into 2

cuboids. A materi-

alized view is proposed for each cuboid. For in-

stance, for Cube91, the ﬁrst cuboid -the core cu-

boid, is a six dimensional cube (hexeract). The





cuboids are ﬁve-dimensional cuboids.

The next





are four-dimensional cuboids. The

last cuboid has a single value and is a zero-

dimensional point.

• Candidate Derived Attributes: For each cube, we

check high cardinality snowﬂake dimensions (i.e.,

dimensions which cardinaly is scale factor), and

propose derived attributes within star dimensions

(i.e., connecting through hierarchical relations-

hips snowﬂake dimensions to the fact table). De-

rived attributes sketch all required measures.

• Candidate Fragmentation Schemas: We refer

to OLAP* framework for generating candidate

schema candidates.

5 CONCLUSIONS AND FUTURE

WORK

In this paper, we derived from TPC-DS benchmark a

multi-dimensional database and reported a thorough

analysis of TPC-DS benchmark, as well as the recom-

mendations derived from the workload analysis. Each

recommendation is characterized by a building cost

estimation, a maintenance cost, a storage cost, and a

weight in the workload. In Future work, we will in-

vestigate relationships among recommendations, i.e.,

namely consolidation and conﬂict relationships, in or-

der to prune candidates combinations, and assess ex-

perimentally cubes calculus performances.

REFERENCES

Agarwal, S., Agrawal, R., Deshpande, P., Gupta, A.,

Naughton, J. F., Ramakrishnan, R., and Sarawagi, S.

(1996). On the computation of multidimensional ag-

gregates. In Proceedings of the 22th International

Conference on Very Large Data Bases, VLDB ’96, pa-

ges 506–521. Morgan Kaufmann Publishers Inc.

Agrawal, R., Gupta, A., and Sarawagi, S. (1997). Mo-

deling multidimensional databases. In Proceedings of

the Thirteenth International Conference on Data En-

gineering, pages 232–243.

Agrawal, S., Bruno, N., Chaudhuri, S., and Narasayya,

V. R. (2006). Autoadmin: Self-tuning database sys-

temstechnology. IEEE Data Eng. Bull., 29(3):7–15.

Agrawal, S., Chaudhuri, S., Koll

ar, L., Marathe, A. P., Na-

rasayya, V. R., and Syamala, M. (2004a). Database

tuning advisor for microsoft SQL server 2005. In

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

296

(e)Proceedings of the Thirtieth International Confe-

rence on Very Large Data Bases, pages 1110–1121.

Agrawal, S., Narasayya, V. R., and Yang, B. (2004b). Inte-

grating vertical and horizontal partitioning into auto-

mated physical database design. In Proceedings of the

ACM SIGMOD International Conference on Manage-

ment of Data, Paris, France, June 13-18, 2004, pages

359–370.

Cabibbo, L. and Torlone, R. (1998). A logical approach to

multidimensional databases. In Advances in Database

Technology - EDBT’98, 6th International Conference

on Extending Database Technology Proceedings, pa-

ges 183–197.

Codd, E. F., Codd, S. B., and Salley, C. T. (1993). Providing

OLAP (on-line analytical processing) to user-analysts:

An IT mandate. Codd and Date, 32:3–5.

Cuzzocrea, A., Furfaro, F., and Sacc

a, D. (2009). Ena-

bling OLAP in mobile environments via intelligent

data cube compression techniques. J. Intell. Inf. Syst.,

33(2):95–143.

Cuzzocrea, A. and Matrangolo, U. (2004). Analytical syn-

opses for approximate query answering in OLAP en-

vironments. In Database and Expert Systems Appli-

cations, 15th International Conference, DEXA 2004

Zaragoza, Spain, August 30-September 3, 2004, Pro-

ceedings, pages 359–370.

Cuzzocrea, A. and Moussa, R. (2013). Multidimensional

database design via schema transformation: Turning

TPC-H into the TPC-H*d multidimensional bench-

mark. In 19th International Conference on Manage-

ment of Data, COMAD, pages 56–67.

Cuzzocrea, A., Moussa, R., and Akaichi, H. (2013a). Au-

toMDB: A framework for automated multidimensio-

nal database design via schema transformation. In

19th International Conference on Management of

Data, COMAD, pages 93–94.

Cuzzocrea, A., Moussa, R., and Xu, G. (2013b). Olap*:

Effectively and efﬁciently supporting parallel OLAP

over big data. In The 3rd International Conference on

Model and Data Engineering MEDI, pages 38–49.

DeWitt, D. J., Madden, S., and Stonebraker, M. (2005).

How to build a high-performance data warehouse.

http://db.lcs.mit.edu/madden/high perf.pdf.

Eisenberg, A., Melton, J., Kulkarni, K. G., Michels, J., and

Zemke, F. (2004). SQL: 2003 has been published.

SIGMOD Record, 33(1):119–126.

Erik, T. (1998). Comparing different approaches to OLAP

calculations as revealed in benchmarks. In Intelli-

gence Enterprises Database Programming & Design.

Gray, J., Chaudhuri, S., Bosworth, A., Layman, A., Rei-

chart, D., Venkatrao, M., Pellow, F., and Pirahesh, H.

(1997). Data cube: A relational aggregation operator

generalizing group-by, cross-tab, and sub-totals. Data

Min. Knowl. Discov., 1(1):29–53.

Gyssens, M. and Lakshmanan, L. V. S. (1997). A founda-

tion for multi-dimensional databases. In Proceedings

of 23rd International Conference on Very Large Data

Bases, VLDB, pages 106–115.

Hose, K., Klan, D., Marx, M., and Sattler, K. (2008). When

is it time to rethink the aggregate conﬁguration of your

OLAP server? PVLDB, 1(2):1492–1495.

Hung, E., Cheung, D. W.-L., and Kao, B. (2004). Optimiza-

tion in data cube system design. Journal of Intelligent

Information Systems, 23(1):17–45.

Imhoff, C., Galemmo, N., and Geiger, J. G. (2003). Maste-

ring Data Warehouse Design: Relational and Dimen-

sional Techniques. Wiley.

Inmon, W. H. (2005). Building the Data Warehouse. Wiley.

Kimball, R., Reeves, L., Thornthwaite, W., Ross, M., and

Thornwaite, W. (1998). The Data Warehouse Lifecy-

cle Toolkit: Expert Methods for Designing, Develo-

ping and Deploying Data Warehouses. John Wiley &

Sons, Inc., 1st edition.

Kimball, R. and Ross, M. (2013). The Data Warehouse

Toolkit: The Deﬁnitive Guide to Dimensional Mo-

deling. John Wiley.

Malinowski, E. and Zim

anyi, E. (2008). A conceptual mo-

del for temporal data warehouses and its transforma-

tion to the ER and the object-relational models. Jour-

nal of Data Knowledge Engineering, 64(1):101–133.

Molina, H. G. (2013). Data warehousing overview: Issues,

terminology, products. www.cs.uh.edu/∼ceick/6340/

dw-olap.ppt.

Moussa, R. (2011). DDB expert: A recommender for distri-

buted databases design. In 2011 Database and Expert

Systems Applications, DEXA, International Works-

hops, Toulouse, France, August 29 - Sept. 2, 2011,

pages 534–538.

Nair, R., Wilson, C., and Srinivasan, B. (2007). A con-

ceptual query-driven design framework for data wa-

rehouse. Intl. Journal of Computer and Information

Science and Engineering, 1(1).

Niemi, T., Nummenmaa, J., and Thanisch, P. (2001). Con-

structing OLAP cubes based on queries. In Proc. of

the 4th ACM intl. workshop on Data warehousing and

OLAP (DOLAP), pages 9–15.

OLAP Council. APB-1 benchmark. www.olapcouncil.org.

Papadomanolakis, S. and Ailamaki, A. (2004). Autopart:

Automating schema design for large scientiﬁc data-

bases using data partitioning. In Proc. of the 16th Intl

Conference on Scientiﬁc and Statistical Database Ma-

nagement (SSDBM, pages 383–392.

Romero, O. and Abell

o, A. (2009). A survey of multidi-

mensional modeling methodologies. Intl. Journal of

Data Warehousing and Mining (IJDWM), 5(2):1–23.

Schnaitter, K. and Polyzotis, N. (2012). Semi-automatic

index tuning: Keeping dbas in the loop. PVLDB,

5(5):478–489.

Surajit, C. and Umeshwar, D. (1997). An overview of

data warehousing and OLAP technology. In SIGMOD

Rec., volume 26, pages 65–74. ACM.

Thanisch, P., Niemi, T., Niinim

aki, M., and Nummenmaa,

J. (2011). Using the entity-attribute-value model for

OLAP cube construction. In Proc. of 10th Intl. Conf.

Perspectives in Business Informatics Research (BIR),

pages 59–72.

Transaction Processing Council (2013a). TPC-DS bench-

mark. http://www.tpc.org/tpcds.

Yet Another Automated OLAP Workload Analyzer: Principles, and Experiences

297

Transaction Processing Council (2013b). TPC-H bench-

mark. http://www.tpc.org/tpch.

Vassiliadis, P. (1998a). Modeling multidimensional data-

bases, cubes and cube operations. In Proceedings of

the 10th International Conference on Scientiﬁc and

Statistical Database Management, SSDBM’98, pages

53–62. IEEE Computer Society.

Vassiliadis, P. (1998b). Modeling multidimensional databa-

ses, cubes and cube operations. In 10th International

Conference on Scientiﬁc and Statistical Database Ma-

nagement, Proceedings, pages 53–62.

Zilio, D. C., Rao, J., Lightstone, S., Lohman, G. M., Storm,

A. J., Garcia-Arellano, C., and Fadden, S. (2004).

DB2 design advisor: Integrated automatic physical

database design. In (e)Proceedings of the Thirtieth

International Conference on Very Large Data Bases,

Toronto, Canada, August 31 - September 3 2004, pa-

ges 1087–1097.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

298
