Towards Cooperative Self-adapting Activity Recognition

Andreas Jahn

, Sven Tomforde

, Michel Morold

, Klaus David

and Bernhard Sick

Communication Technology Group, University of Kassel, Kassel, Germany

Intelligent Embedded Systems Group, University of Kassel, Kassel, Germany

Keywords:

Activity Recognition, Self-adapting, Organic Computing, Cooperation, Active Learning.

Abstract:

Activity Recognition (AR) aims at deriving high-level knowledge about human activities and the situation

in the human’s environment. Although being a well-established research ﬁeld, several basic issues are still

insufﬁciently solved, including extensibility of an AR system at runtime, adaption of classiﬁcation models

to a very speciﬁc behaviour of a user, or utilising of all information available, including other AR systems

within range. To overcome these limitations, the cooperation of AR systems including sporadic interaction

with humans and consideration of other information sources is proposed in this article as a basic new way to

lead to a new generation of “smart” AR systems. Cooperation of AR systems will take place at several stages

of an AR chain: at the level of recognised motion primitives (e.g. arm movement), at the level of detected

low-level activities (e.g. writing), and/or at the level of identiﬁed high-level activities (e.g. participating

in a meeting). This article outlines a possible architectural concept, describes the resulting challenges, and

proposes a research roadmap towards cooperative AR systems.

1 MOTIVATION

The well-established research ﬁeld of activity and

context recognition (AR) aims at deriving high-level

knowledge about human activities and the situation

in the human’s environment from simple sensors

such as acceleration sensors, microphones, or gy-

roscopes (Lara and Labrador, 2013; Shoaib et al.,

2014). Often, mobile devices such as smartphones

or smart watches are used for this purpose (Shoaib

et al., 2015). Examples for application ﬁelds range

from monitoring maintenance tasks (Roy et al., 2013)

through trafﬁc applications (Liao et al., 2006) or mon-

itoring sports activities (Ermes et al., 2008) to medical

applications (Maurer et al., 2006).

Today’s AR systems have a number of limitations,

including the following: a) they typically rely on a

ﬁxed conﬁguration of sensors that are available in a

given device, b) their pre-trained classiﬁcation models

are often not customised to the speciﬁc user, and c)

the set of activities that have to be recognised in an

AR system is ﬁxed at the design-time of this system.

Based on the observation that we face an ever-

increasing number of (smart) sensors and devices in

our daily environment (already able to host AR sys-

tems), we suggest to overcome these limitations by

means of a fundamentally different way of develop-

ing and deploying AR systems. We claim that a coop-

eration of AR systems including sporadic interaction

with humans and consideration of other information

sources whenever possible will lead to a new gener-

ation of ”smart” AR systems with: i) the capability

to self-adapt to the activities and contexts of a spe-

ciﬁc user at runtime (including semi-autonomous ex-

tension to new kinds of activities or contexts), and

ii) an increased recognition accuracy and reduced en-

ergy consumption.

In this article, we outline our vision of a cooper-

ative self-adapting AR System. Cooperation of AR

systems will take place at several levels of an AR

chain: at the level of recognised motion primitives

(e.g. arm movement), over the level of detected low-

level activities (e.g. writing), to the level of identiﬁed

high-level activities (e.g. participating in a meeting or

activities of daily living).

To illustrate, consider a managerial meeting as

use-case to highlight the possible beneﬁts of such a

collaborative approach: An AR system running on a

smartphone recognises that its user is sitting. In its

vicinity are several other smartphones (also running

AR systems), a smart pen is activated and used, and

room-based sensors signal the utilisation of the room

(e.g. movement detectors are activated or a projector

is used). The recognition can be supported by consid-

ering even other information sources such as sitting

detectors in the chairs. Once a multitude of AR sys-

Jahn, A., Tomforde, S., Morold, M., David, K. and Sick, B.

Towards Cooperative Self-adapting Activity Recognition.

DOI: 10.5220/0006856100770084

In Proceedings of the 8th International Joint Conference on Pervasive and Embedded Computing and Communication Systems (PECCS 2018), pages 77-84

ISBN: 978-989-758-322-3

tems recognise the sit down activity, they might share

this information and conclude cooperatively that the

meeting is going to start. Important energy savings

might be achieved, if the whole recognition cycle is

not required for all participants, but only for a few.

For all other participants, the activity can be con-

cluded purely by e.g. proximity. Another important

improvement, other than increasing the recognition

accuracy, will be the ability to include new, unfore-

seen activities such as sitting on a table instead of

a chair, and still having this meeting. As a conse-

quence of “meeting ongoing”, incoming calls may be

muted and the calendar shows “not available”. In the

course of the meeting, it can be cooperatively con-

cluded that the (high-level activity) meeting is still

ongoing – even though a participant might have left

already – based on (basic) arm movements, i.e., the

(low-level) activity of writing of several participants.

The remainder of this article is organised as fol-

lows: Section 2 presents the research statement, Sec-

tion 3 brieﬂy summarises relevant work from the state

of the art, Section 4 presents an architecture concept

for collaborative AR systems, and Section 5 describes

the resulting research roadmap. Finally, Section 6

concludes the article.

2 RESEARCH STATEMENT

To address the vision above, we have to develop

and investigate the foundations for a new genera-

tion of cooperating, self-improving AR systems based

on the conﬂuence of ideas from two well estab-

lished research areas: 1) Human activity and context

recognition in pervasive/ubiquitous systems. 2) Or-

ganic Computing (OC) techniques for runtime self-

organisation and self-adaptation in technical systems.

From a scientiﬁc point of view, the above vision im-

plies several research directions including commu-

nication in ad-hoc networks, sensor self-description,

service discovery, robustness, security, and leveraging

new sources of information. In this article, we focus

on the latter as the other aspects are well covered by

current research.

The vision is brieﬂy sketched in the motivation es-

sentially amounts to a cooperating and self-improving

AR system. In this context, “cooperating” refers to an

AR system that is able to perform purpose-oriented

interaction with other AR systems. As cooperation

partners for the AR system, we not only consider

other AR systems being available in its communi-

cation range, but also its human user who may pro-

vide answers - assuring that the user is only asked

very sporadically. Thus, we aim at transforming an

AR system from a (traditionally) static system into an

evolving system that adapts to the time-dependent and

changing behaviour of its user. In particular, cooper-

ation has to be established with the following objec-

tives:

Objective 1. Cooperation based recognition accu-

racy improvement of ongoing human activities

at several levels of abstraction (i.e., from motion

primitives such as arm movements to high-level

activities such as participating in a meeting).

Objective 2. Reduction of energy consumption in

mobile devices hosting an AR system without de-

terioration of the AR system’s accuracy by coop-

eration.

Objective 3. Customisation of pre-trained AR sys-

tems (i.e., the AR system will adapt to the unique

activities of a speciﬁc user) supported by cooper-

ation.

Objective 4. Detection of hitherto unknown kinds of

activities (i.e., “novel” activities a speciﬁc AR

system was not pre-trained for) and self-extension

of the activity repertoire by cooperation.

The objectives above are not only relevant for the

ﬁeld of AR, but also for the area of OC (Tomforde

et al., 2017; M

uller-Schloer and Tomforde, 2017). In

particular, OC focuses on enabling autonomous tech-

nical devices with capabilities to self-organise, con-

tinuously self-assess the success of their behaviour,

and consequently self-adapt and self-improve at run-

time. As a result, traditional design-time decisions

are transferred to runtime and into the responsibility

of the systems themselves. This transfer of design-

time decisions to runtime is necessary, since not all

required features of a system can be anticipated of-

ﬂine, i.e., at design-time.

Consequently, we can summarise that the main

objectives under the common theme is to develop and

investigate novel techniques based on the principles

of OC to develop a new generation of “smart” AR

systems. In our approach, we focus on the speciﬁc

questions from the ﬁeld of AR systems, but we as-

sume that the main insights will also be transferable

to many other application domains.

Within this article, we refer to the object that per-

forms the AR as “entity”. An entity might be a smart-

phone or another smart device. For AR the entity

accesses internal and external information sources.

Internal sources might be sensors that are available

within the entity, for instance, the built-in accelerom-

eter or gyroscope of the smartphone. External sources

are not part of the entity such as infrastructure sensors

or other entities. Further, the term “activity” sum-

marises activities at all level of abstraction, i.e. mo-

PEC 2018 - International Conference on Pervasive and Embedded Computing

tion primitives as well as low- and high-level activi-

ties.

3 STATE OF THE ART

The following paragraphs summarise contributions

from the state of the art that are closely related to this

article in several domains.

AR aims at deriving knowledge about human ac-

tivities and the situation in the human’s environment.

In the recognition process, commonly, sensor data

are processed and matched to activities. That means,

the continuously incoming data stream is segmented,

for instance by applying a Sliding Window or Slid-

ing Window And Bottom-up (SWAB) method (Keogh

et al., 2001). For each segment application-speciﬁc

characteristics, i.e. features, are extracted. Common

features are time domain based features such as mean

or variance. These features are often used as they

are easy to calculate and simultaneously provide com-

paratively well insights into the data characteristics.

Further, frequency domain based features have been

investigated, which can extract unseen patterns and

trends in the data (Chaovalit et al., 2011). For exam-

ple, a Fourier transform can be used to uncover data

characteristics that support the recognition of a user’s

fall (Delahoz and Labrador, 2014). The extracted fea-

ture values are passed to a machine learning algo-

rithm which generates an AR model. A variety of ma-

chine learning algorithms are available such as clus-

tering algorithms, Support Vector Machines (SVMs),

or Bayesian classiﬁers. The generated model iden-

tiﬁes a user’s activity based on the incoming feature

values. To improve the AR performance, a well in-

vestigated approach is the integration of additional

information sources, often referred to as sensor fu-

sion. Commonly, a combination of sensor sources

is done in terms of raw sensor data. The data are

provided by additional (internal and external) sen-

sors. A multitude of sensors have been combined

such as accelerometer and gyroscope (Shoaib et al.,

2014), accelerometer and pressure sensor and micro-

phone (Khan et al., 2014), as well as accelerome-

ter and various combinations of infrastructure sensors

such as radio-frequency readers, object tags, or video

cameras (Roy et al., 2013).

Along integrating additional sensors, a (pas-

sive) collaborative approach was investigated. The

project ”Collaborative Context Recognition” (Co-

CoRec) considers other entities and information at

different abstraction levels, i.e. raw data, low-level

contexts, and high-level contexts, were data are ex-

clusive at these levels. The researchers investigate the

activity monitoring (Kampis and Lukowicz, 2014), or

the efﬁcient information distribution (Kampis et al.,

2015). Though, the project results are mainly in in-

formation monitoring and distribution. In this arti-

cle, we assume the monitoring and distribution of data

as being solved and focus on cooperative knowledge

gathering and processing in AR. We investigate co-

operative entities that dynamically send and receive

data needed for AR at multiple levels of abstraction,

and consider these in the corresponding stages of the

AR process. In comparison to our vision, active and

purpose-oriented cooperation with other sensors and

human users is not considered in AR systems today.

Organic Computing (OC) is a recent paradigm

of designing and developing self-adapting and self-

organising technical systems acting in the real world.

OC systems are designed to process so-called self-

x properties that allow them to be self-adaptive and

self-organising at runtime. In this article, we aim

at cooperative and self-adaptive AR systems, which

require a system design allowing for internal adap-

tation. OC and related initiatives (such as Auto-

nomic Computing (Kephart and Chess, 2003)) have

proposed a variety of architectural blueprints. Ex-

amples include the generalised observer/controller

(O/C) framework (Tomforde et al., 2011) and

the Monitor-Analyse-Plan-Execute(-Knowledge) cy-

cle, called MAPE(-k) (Kephart and Chess, 2003). For

both concepts (i.e., O/C and MAPE-k), multi-layered

extensions have been proposed as well as system-of-

systems concepts.

The utilisation of machine learning techniques is

a key factor for self-organised and self-adaptive tech-

nical systems. These systems have to adapt them-

selves in response to the ever-changing environmen-

tal conditions and at the same time have to guaran-

tee the compliance to restrictions preventing faulty

behaviour (Prothmann et al., 2009). Especially Au-

tonomous Learning is considered to be a key feature

in OC systems: At design-time, only incomplete in-

formation is available as basis for learning processes

(e.g., for training purposes).

Collaborative Learning (CL) is a topic related to

this article as we aim to enable individual AR sys-

tems to interact with each other to further improve

their recognition process. Distributed intelligent sys-

tems that work in a collaborative manner recently

became an active research issue (Panait and Luke,

2005). In the majority of these approaches, informa-

tion is locally acquired and pre-processed by the in-

telligent systems and then sent to special processing

units (which can be either centralised or distributed).

Less common, but closer related to our approach,

is work dealing with collaborating agents that learn

Towards Cooperative Self-adapting Activity Recognition

from each other by exchanging locally inferred rules

such as in (Jakob et al., 2008). In (Tan, 1993), the

authors investigate the exchange of different kinds

of knowledge (i.e., observations, observation-action-

reward vectors, and learned state transitions) between

agents that are equipped with reinforcement learning

techniques. Furthermore, agents equipped with SVM

exchange newly learned support vectors in (J

andel,

2009). Correctly classiﬁed samples yield a reward

which is used by the agents to adapt their SVM to

changes in the environment. A periodic exchange

of knowledge between agents with different learn-

ing paradigms (i.e., table based Q-learning and neural

networks trained with backpropagation) is presented

in (Gifford and Agah, 2009). This approach, how-

ever, is based on an application- and learner-speciﬁc

intermediate knowledge representation that must be

deﬁned in advance. Additionally, the choice of rep-

resentation greatly inﬂuences the performance of the

overall agent system.

Active Learning (AL) provides powerful ap-

proaches to create ﬂexible systems which are able

to adapt themselves to a changing environment (Set-

tles, 2009). These methods interact with their target

system to investigate which information might opti-

mise their model, and they actively acquire this in-

formation. In classiﬁcation (also in regression) prob-

lems, AL algorithms actively request the target value

of an instance (feature vector) (Aggarwal et al., 2014).

Three basic AL approaches exist: 1) query synthesis

(the query instance is generated), 2) pool-based AL

(the query is an instance from a pool of unlabelled in-

stances), and 3) stream-based AL (instances succes-

sively appear and the AL algorithm decides if the la-

bel should be acquired) (Aggarwal et al., 2014). One

of the main challenges is to balance the exploration

of new regions in the feature space and the exploita-

tion of the existing knowledge to reﬁne the trained

model (Settles, 2009). The most popular method is

uncertainty sampling, although it solely exploits the

model by acquiring labels from instances near the

classiﬁer’s decision boundary (Settles, 2009). More

sophisticated methods extend this approach by adding

exploratory components, density information, or class

priors (Reitmaier and Sick, 2013).

As a conclusion from this discussion of the state

of the art, we can state that traditional research in AR

does not consider cooperation sufﬁciently. Thus, pos-

sibly available knowledge to improve the efﬁciency

and quality of solutions is not taken into account. To

address this issue, especially techniques and insights

from the domains of OC, CL, and AL are promising

and have to be extended accordingly.

In this article, we claim that the state of the art

needs to be improved by a new approach for AR

which is taking advantage of cooperation by enabling

AR systems to be ﬂexible to environmental changes

by means of cooperation. This speciﬁcally includes:

• the ﬂexibility to consider the knowledge of other

AR systems about recognised activities at various

stages of a recognition chain,

• the capability to adapt to the behavioural patterns

and activities of a speciﬁc user at runtime (includ-

ing semi-autonomous extension to new kinds of

activities), and

• improving activity recognition in terms of its key

performance indicators such as accuracy and re-

duced energy consumption.

4 AN ARCHITECTURAL

CONCEPT FOR COOPERATIVE

SELF-ADAPTING AR SYSTEMS

We present an architectural blueprint for cooperat-

ing AR systems that is based on design concepts

from OC (Tomforde et al., 2011). For the de-

sign of self-organising and self-adapting systems, the

OC community has proposed a generalised design

concept that distinguishes between a ”System un-

der Observation and Control” (SuOC) and an ”Ob-

server/Controller” (O/C) tandem that is responsible

for adapting the behaviour of the SuOC to changing

conditions (Tomforde et al., 2011). The O/C tandem

may be realised in hierarchies of layers with increas-

ing abstraction (Tomforde and M

uller-Schloer, 2014).

Fig. 1 shows a customised variant of the generic

O/C architecture for cooperating, self-adaptive AR

systems. Here, the concept of the SuOC is instan-

tiated by the human user (or several humans) in a

sensor enhanced environment. The architecture con-

sists of two layers: The Reaction Layer is responsi-

ble for reactions to observed behaviour, i.e., it realises

the tasks of augmenting a traditional AR system with

mechanisms for cooperative reaction according to the

Objectives 1 and 2. The Adaptation Layer is respon-

sible for long-term improvements by adapting the Re-

action Layer at runtime, i.e., the upper layer monitors

and modiﬁes the behaviour of the bottom layer ac-

cording to Objectives 3 and 4.

The Reaction Layer is organised in three main

components: an observer component containing a

four-stage recognition chain, a controller component

triggering actuators, and a component for cooperative

reaction.

The four stages of the recognition chain in the ob-

server component are:

PEC 2018 - International Conference on Pervasive and Embedded Computing

Reaction

Layer

Adaptation

Layer

Pre-Processing

high level

Controller

low level

primitives

Cooperative

adaptation

Single Entity

Collective

SensorsActuators

Rule base

Condition Action

Context 𝑐

Do 𝐴

…. ….

Observer

Adaptation

Learning

Observer

Evaluation

Knowledge

Discovery

Entities knowledge

assessment

Cooperative reaction

Knowledge about

other entities

Ground truth feedback

via human users

Other AR systems

Entities similarity

assessment

Human user

Figure 1: Architectural blueprint of a cooperative and self-

adapting AR system based on the Observer/Controller ap-

proach (Tomforde et al., 2011) from the OC domain.

Stage 1. Pre-processing and feature extraction: Raw

data directly obtained from sensors (e.g., acceler-

ation values gathered from an accelerometer) are

pre-processed (e.g., ﬁltered and segmented). Fea-

tures are extracted that characterise certain activi-

ties.

Stage 2. Recognition of motion primitives: Features

are used to identify (classify) motion primitives

such as lifting the arm. At this stage, we rely on

SVM, but may use k-Nearest-Neighbour (kNN)

classiﬁers as alternative. Recognised motion

primitives can be either used as an independent

factum or are passed to the low-level AR stage.

Stage 3. Recognition of low-level activities: This

stage focuses on the identiﬁcation of low-level

activities as a set of temporally and coher-

ently related arm movements, i.e. motion prim-

itives. Low-level activities are modelled as

(probabilistic) sequences of motion primitives.

Thus, models such as left-right Hidden-Markov-

Models (HMM) are used.

Stage 4. Recognition of high-level activities: Based

on results of the lower stages, the goal is to recog-

nise related high-level activities, e.g. to identify

activities such as meeting, dish washing, dinner,

or tram ride. High-level AR uses knowledge about

motion primitives, low-level activities, and, pos-

sibly, other external information sources. High-

level activities are seen as temporal sequences and

modelled with HMM, too.

While the O/C tandem at the Reaction Layer

is given, the component for cooperative reaction –

which addresses Objectives 1 and 2 – has to be devel-

oped and investigated. It collects activity information

from other AR systems and/or information sources

which is then fed into the recognition chain or fused

with results of stages of the recognition chain. The

component for cooperative reaction is in charge of ac-

tively collecting beneﬁcial information.

The Adaptation Layer – which addresses Objec-

tives 3 and 4 – has to be developed and investigated

but contains the O/C tandem as well. The observer

component is responsible for evaluating the behaviour

of the Reaction Layer. In particular, this means to as-

sess the classiﬁcation success of the AR system and

the appropriateness of consecutive actions. As a re-

sult, the AR system becomes self-aware concerning

its own performance. The controller component im-

proves the behaviour of the Reaction Layer over time

by combining the two modules learning and adap-

tation. Conceptually, this establishes a control loop

on-top of the control loop of the Reaction Layer that

increases the ability of the system to positively re-

act to new situations arising at runtime and to adapt

the AR system to a speciﬁc user or a new kind of

activity. Similar to the Reaction Layer, the Adapta-

tion Layer contains a module for cooperative adapta-

tion that (passively or actively) collects activity infor-

mation from other AR systems or additional sources

(e.g., external sensors) and humans who can occa-

sionally be asked to provide information about a cur-

rent situation or an event that occurred shortly before.

In order to ﬁnally establish a cooperative AR sys-

tem based on the presented blueprint, we have to ad-

dress several research challenges in the ﬁrst place.

These are brieﬂy outlined in the following section.

5 RESEARCH ROADMAP

The vision of cooperative, self-adaptive AR systems

leads to the following research roadmap.

Challenge 1 – Assessment and Selection of Infor-

mation Available Via Cooperation at the Reaction

Layer.

The ﬁrst step towards cooperation at the Reaction

Layer is to assess the knowledge of other entities in

order to identify the most beneﬁcial information for

AR. Therefore, all information arriving via broadcast-

ing needs to be managed, organised, and structured.

To identify information that are beneﬁcial for AR a

promising approach is to estimate the ”recognisabil-

ity”. As the information are possibly available at dif-

ferent abstraction levels, the ”recognisability” estima-

tion algorithm needs to be able to respect the different

informational content of the received data. Further,

information are provided from dynamically changing

information sources. Techniques are necessary that

ﬂexibly manage the (un-/)available sources of infor-

mation.

Towards Cooperative Self-adapting Activity Recognition

Challenge 2 – Improving the Classiﬁcation Accu-

racy Through Cooperation.

To improve the AR classiﬁcation accuracy, the infor-

mation beneﬁcial for AR needs to be integrated into

the AR process. As it is possible that previously un-

known information sources appear, these sources are

analysed and introduced into the AR system. Depen-

dent on the level of abstraction the information are

considered at the corresponding recognition stages of

the recognition chain, i.e. pre-processing, motion-

primitives, low-level, or high-level activities (see Sec-

tion 4). The motion-primitives might be recognised

by applying feature extraction and machine learn-

ing algorithms such as kNN and SVM. At the fur-

ther stages, an HMM might be applied to process

the higher-level information. The applied classiﬁers

need to be extended to be able to handle dynamically

changing information sources.

Challenge 3 – Energy Efﬁciency.

As an important advantage of cooperation, single de-

vices may (partly) switch off their AR systems to

save energy. This is possible whenever information

obtained from other, ”similar” entities can be trans-

ferred to maintain their own functionality without lo-

cal AR. Thus, ”similar” entities have to be identiﬁed.

To quantify the similarity between entities, the align-

ment algorithm might be applied (Sigg et al., 2010).

As the alignment algorithm calculates the similarity

for one information abstraction level, techniques are

needed that are able to handle all levels. Based on

these results, ”footprints” of each entity might be used

to identify ”similar” entities. Once a similarity is

agreed, only one entity processes the AR. The AR is

conducted as discussed in Challenge 2 and, hence, in-

cludes all stages. The results are provided to all other

entities.

Challenge 4 – Short-term Adaptation of the Reac-

tion Layer.

As shown in various publications, the classiﬁcation

success largely depends on the selected window size

(when using the sliding window method). Thus, the

AR accuracy might be improved when the window

sizes are dynamically adapted to the current situation

at runtime. To ”spot” activity changes in the contin-

uous sensor data, a promising approach is analysing

the low- and high-frequency components of the ac-

celeration data. The components can be derived by

applying a Butterworth low-pass ﬁlter (Suarez et al.,

2015). Secondly, activity changes might be seen

by monitoring the activity frequency characteristics

within the sensor data. Applying Dual-Tree Com-

plex Wavelet Transformation to emphasise areas of

frequency changes in sensor data as suggested in (We-

ickert et al., 2009) might give insights into the activity

frequency characteristics to adjust the window size.

Challenge 5 – Runtime Customisation of the AR

System at the Reaction Layer.

An AR system continuously analyses sensor data to

estimate the current user activities. Once deployed,

the detection mechanism runs continuously and pro-

vides a classiﬁcation. However, the correctness of

this classiﬁcation depends highly on the pre-training

at design-time by means of example data. Assum-

ing that all detectable activities have been part of

the training data, we still face the problem that pre-

training is not necessarily done with the particular

user, and classiﬁcations based on sensor data will oc-

casionally be wrong (depending on variances in the

user’s behaviour). A framework of measures based

on (Fisch et al., 2016) and techniques, e.g., for trans-

ductive learning will allow for an adaptation of the

classiﬁcation system to changing conditions and a

customisation to the speciﬁc user.

Challenge 6 – Runtime Self-extension at the Reac-

tion Layer for Detection of Novel Kinds of Activi-

ties.

The knowledge of the Reaction Layer comprises all

activities that have been part of the training process.

However, this seldom covers all distinct activities the

respective user will experience when using the AR

system: Novel activities may appear and others may

become obsolete due to changes of the user’s be-

haviour. Consequently, techniques are needed that

foster the set of known activities that are considered

by the Reaction Layer at all stages of the recognition

system. A promising approach may be found in the

combination of two aspects: (i) determine if the con-

sidered classes of known activities are sufﬁcient, e.g.,

by means of developing techniques for anomaly de-

tection, and (ii) introduce appropriate novel classes

of behaviour and update the recognition system ac-

cordingly (e.g., based on exchanging class informa-

tion among systems).

Challenge 7 – Cooperation with Human Users for

Long-term Improvement.

The human user is the instance in the entire system

with the best knowledge about activities that supports

long-term improvement of the AR system. The chal-

lenge is to actively collaborate with the user by con-

sidering efﬁciency, acceptability, and comfort issues.

Therefore, the status and the preferences of a user

PEC 2018 - International Conference on Pervasive and Embedded Computing

have to be analysed and assessed continuously. As an

approach to solve this challenge, techniques for up-

dating the user model that are based on the ideas of

“Active Learning” (Settles, 2009) have to be devel-

oped. Active Learning allows for covering the task

of efﬁciently acquiring knowledge from the user and

improving the underlying knowledge models accord-

ingly.

Challenge 8 – Cooperation with Other AR Systems

for Long-term Improvement.

Due to mobility, the user’s smartphone running the

AR system is surrounded by other users that may also

carry AR systems or other “smart” devices – which

may have experienced different user behaviour and

varying sequences of activities. This existing knowl-

edge may be beneﬁcial for the AR system under con-

sideration: as basis for evaluating the success of its

Reaction Layer, for identifying novel classes of activi-

ties, or as additional source to improve the certainty of

a classiﬁcation decision. The challenge in this context

maps the previous human-related challenge to ﬁnd ef-

ﬁcient and beneﬁcial ways to query and incorporate

user knowledge to technical devices. An approach to

solve this challenge will be based on techniques for

modelling the knowledge, the expertness, and the mu-

tual experiences made with other technical devices.

Challenge 9 – Estimating the Success of Coopera-

tion.

The vision postulated in this article is that such a co-

operative AR system is more efﬁcient, more robust,

and more successful than traditional approaches. The

ﬁnal challenge is to proof these assumptions.

Therefore, scenarios are necessary that cover the

different aspects of the previous challenges. In or-

der to determine the success of the system two se-

tups need to be compared: 1) No cooperation al-

lowed: This represents the recognition performance

achievable already today and, thus, provides the initial

benchmark; 2) Assuming a perfect cooperation: This

evaluates whether applying cooperation improves the

recognition performance. It is guaranteed that all

knowledge is immediately accessible to all entities.

The (cooperatively) achieved recognition results are

quantiﬁed by appropriate evaluation metrics and the

calculation of statistically relevant results. To gain

deeper insights, the time span of adaptation (for long-

term success analysis) might be monitored.

6 CONCLUSION

In this article, we claimed that the next promising step

in activity recognition (AR) research is to focus on

cooperative solutions. Therefore, we outlined an ar-

chitectural concept and the resulting challenges, fol-

lowed by deriving a research roadmap towards coop-

erative and self-adapting AR systems. Cooperative

self-adapting AR is a basic new way to lead to a new

generation of ”smart” AR systems that address several

basic issues that are still insufﬁciently solved in the

research ﬁeld of AR, including extensibility of an AR

system at runtime, adaption of classiﬁcation models

to a very speciﬁc behaviour of a user, or utilisation of

all information available, including other AR systems

within communication range. Cooperation of AR sys-

tems will take place at all stages of the AR chain: at

the level of recognised motion primitives (e.g. arm

movement), the level of detected low-level activities

(e.g. writing), and/or at the level of identiﬁed high-

level activities (e.g. participating in a meeting).

REFERENCES

Aggarwal, C. C., Kong, X., Gu, Q., Han, J., and Yu, P. S.

(2014). Active learning: A survey. Data Classiﬁca-

tion: Algorithms and Applications, pages 571–605.

Chaovalit, P., Gangopadhyay, A., Karabatis, G., and Chen,

Z. (2011). Discrete wavelet transform-based time se-

ries analysis and mining. ACM Computing Surveys,

43(2):1–37.

Delahoz, Y. and Labrador, M. (2014). Survey on Fall Detec-

tion and Fall Prevention Using Wearable and External

Sensors. Sensors, 14(10):19806–19842.

Ermes, M., P

arkk

a, J., M

antyj

arvi, J., and Korhonen, I.

(2008). Detection of daily activities and sports with

wearable sensors in controlled and uncontrolled con-

ditions. IEEE Transactions on Information Technol-

ogy in Biomedicine, 12(1):20 – 26.

Fisch, D., Gruhl, C., Kalkowski, E., Sick, B., and Ovaska,

S. J. (2016). Towards automation of knowledge un-

derstanding: An approach for probabilistic generative

classiﬁers. Information Sciences, 370:476–496.

Gifford, C. M. and Agah, A. (2009). Sharing in teams of

heterogeneous, collaborative learning agents. Interna-

tional Journal of Intelligent Systems, 24(2):173–200.

Jakob, M., To

cka, J., and P

echou

cek, M. (2008). Collab-

orative Learning with Logic-Based Models. In Adap-

tive Agents and Multi-Agent Systems, pages 102–116.

Springer.

andel, M. (2009). Cooperating classiﬁers. In Nature In-

spired Cooperative Strategies for Optimisation, pages

213–225. Springer.

Kampis, G., Franke, T., Negele, S., and Lukowicz, P.

(2015). Efﬁcient Information Distribution Using Hu-

Towards Cooperative Self-adapting Activity Recognition

man Mobility. Procedia Computer Science, 66:382–

391.

Kampis, G. and Lukowicz, P. (2014). Collaborative local-

ization as a paradigm for incremental knowledge fu-

sion. In IEEE Conference on Cognitive Infocommuni-

cations (CogInfoCom), pages 327–331. IEEE.

Keogh, E., Chu, S., Hart, D., and Pazzani, M. (2001). An

online algorithm for segmenting time series. IEEE

International Conference on Data Mining (ICDM),

pages 289–296.

Kephart, J. and Chess, D. (2003). The Vision of Autonomic

Computing. IEEE Computer, 36(1):41–50.

Khan, A. M., Tufail, A., Khattak, A. M., and Laine, T. H.

(2014). Activity Recognition on Smartphones via

Sensor-Fusion and KDA-Based SVMs. International

Journal of Distributed Sensor Networks, 2014:1–14.

Lara, O. D. and Labrador, M. A. (2013). A survey on human

activity recognition using wearable sensors. IEEE

Communications Surveys & Tutorials, 15(3):1192–

1209.

Liao, L., Fox, D., and Kautz, H. (2006). Location-based

activity recognition. Advances in Neural Information

Processing Systems, 18(1):787–794.

Maurer, U., Smailagic, A., Siewiorek, D. P., and Deisher,

M. (2006). Activity recognition and monitoring using

multiple sensors on different body positions. In IEEE

International Workshop on Wearable and Implantable

Body Sensor Networks (BSN), pages 113–116. IEEE.

uller-Schloer, C. and Tomforde, S. (2017). Organic Com-

puting – Technical Systems for Survival in the Real

World. Springer International Publishing, Cham.

Panait, L. and Luke, S. (2005). Cooperative Multi-Agent

Learning: The State of the Art. Autonomous Agents

and Multi-Agent Systems, 11:387–434.

Prothmann, H., Branke, J., Schmeck, H., Tomforde, S.,

Rochner, F., H

ahner, J., and M

uller-Schloer, C.

(2009). Organic Trafﬁc Light Control for Urban Road

Networks. International Journal of Autonomous and

Adaptive Communications Systems, 2(3):203 – 225.

Reitmaier, T. and Sick, B. (2013). Let us know your deci-

sion: Pool-based active training of a generative classi-

ﬁer with the selection strategy 4DS. Information Sci-

ences, 230:106–131.

Roy, N., Misra, A., and Cook, D. (2013). Infrastructure-

assisted smartphone-based adl recognition in multi-

inhabitant smart environments. In IEEE International

Conference on Pervasive Computing and Communi-

cations, pages 38–46. IEEE.

Settles, B. (2009). Active learning literature survey. Com-

puter Sciences Technical Report 1648, University of

Wisconsin–Madison.

Shoaib, M., Bosch, S., Incel, O., Scholten, H., and Havinga,

P. (2014). Fusion of Smartphone Motion Sensors for

Physical Activity Recognition. Sensors, 14(6):10146–

10176.

Shoaib, M., Bosch, S., Incel, O., Scholten, H., and Havinga,

P. (2015). A Survey of Online Activity Recognition

Using Mobile Phones. Sensors, 15(1):2059–2085.

Sigg, S., Haseloff, S., and David, K. (2010). An Alignment

Approach for Context Prediction Tasks in UbiComp

Environments. IEEE Pervasive Computing, 9(4):90–

97.

Suarez, I., Jahn, A., Anderson, C., and David, K. (2015).

Improved activity recognition by using enriched ac-

celeration data. In ACM International Joint Confer-

ence on Pervasive and Ubiquitous Computing, pages

1011–1015, Osaka, Japan. ACM.

Tan, M. (1993). Multi-agent reinforcement learning: Inde-

pendent vs. cooperative agents. In Proceedings of the

tenth International Conference on Machine Learning,

pages 330–337.

Tomforde, S. and M

uller-Schloer, C. (2014). Incremental

Design of Adaptive Systems. Journal of Ambient In-

telligence and Smart Environments, 6:179 – 198.

Tomforde, S., Prothmann, H., Branke, J., H

ahner, J., Mnif,

M., M

uller-Schloer, C., Richter, U., and Schmeck, H.

(2011). Observation and Control of Organic Systems.

In Organic Computing - A Paradigm Shift for Complex

Systems, pages 325 – 338. Birkh

auser.

Tomforde, S., Sick, B., and M

uller-Schloer, C.

(2017). Organic Computing in the Spotlight.

http://arxiv.org/abs/1701.08125.

Weickert, T., Benjaminsen, C., and Kiencke, U. (2009). An-

alytic Wavelet Packets - Combining the Dual-Tree Ap-

proach With Wavelet Packets for Signal Analysis and

Filtering. IEEE Transactions on Signal Processing,

57(2):493–502.

PEC 2018 - International Conference on Pervasive and Embedded Computing
