Everything-as-a-Thing for Abstracting the Internet-of-Things

Zakaria Maamar

, Noura Faci

, Mohamed Sellami

, Emir Ugljanin

and Ejub Kajan

Zayed University, Dubai, U.A.E.

Universit

e Lyon 1, Lyon, France

ISEP Paris, Paris, France

State University of Novi Pazar, Novi Pazar, Serbia

Keywords:

Capability, Internet of Things, Role, Service, Storytelling.

Abstract:

This paper discusses Everything-as-a-Thing (*aaT) as a novel way for abstracting the Internet-of-Things (IoT)

applications. Compared to other forms of abstraction like Everything-as-a-Service (*aaS) and Everything-

as-a-Resource (*aaR), *aaT puts emphasis on living things, on top of non-living things, that populate these

applications. On the one hand, living things take over roles that are deﬁned in terms of rights and duties. On

the other hand, non-living things offer capabilities that are deﬁned in terms of functional and non-functional

properties. Interactions that occur between living and non-living things are speciﬁed as stories that deﬁne who

does what, when, and where. For illustration purposes, *aaT is put into action using a healthcare case study.

1 INTRODUCTION

A plethora of buzzwords (e.g., cloud, fog, ubiqui-

tous, pervasive, and big data) describe the continuous

development of the ICT ﬁeld that is seeing, among

other things, a convergence of system development

approaches towards the paradigm of service compu-

ting. This paradigm is about exposing Everything-as-

a-Service (*aaS). Thing could be software, platform,

infrastructure, data communication, to cite just some,

with the ﬁrst 3 constituting the essence of cloud com-

puting. *aaS offers ICT practitioners multiple advan-

tages over other forms of computing (like component-

based), such as, abstracting the complexity of the

digital and physical worlds and their potential con-

nection, complying with the separation-of-concerns

principle (Parnas, 1972), and shifting the burden of

running certain internal operations to external bodies

in-return of a fee.

In conjunction with the expansion of service com-

puting, the ICT ﬁeld is, also, witnessing a pheno-

menal increase in the volume of data that is gene-

rated and, thus, needs to be “harnessed” in terms of

processing and storage. Indeed, according to Vice

President of Intel’s Architecture Group, Kirk Skau-

gen, there was more data transmitted over the In-

ternet in 2010 than the entire history of the Internet

through 2009

. One source of these data are millions

of sensors and actuators that perfectly exemplify the

mashable.com/2011/10/20/kirk-skaugen-web-2.

era of Internet-of-Things (IoT). IoT is about anything

and everything (e.g., smartphone, kitchen appliance,

and TV) that connects with peers and exchanges data

with them. According to Gartner

, 6.4 billion con-

nected things (not to confuse with everything as a ser-

vice) were in use in 2016, up 3% from 2015, and will

reach 20.8 billion by 2020. In addition, it is predicted

that the total economic impact of IoT will reach be-

tween $3.9 trillion and $11.1 trillion per year by the

year 2025 (DZone, 2017).

In this paper, we discuss IoT from a service per-

spective by raising 2 speciﬁc questions: what is a

thing when it acts as a consumer of services and

what is a thing when it acts as a provider of servi-

ces? Answering these 2 questions would raise anot-

her question, which is: is there room for Everything-

as-a-Thing (*aaT) in the current ICT landscape? Con-

trarily to *aaS where everything is about non-living

digital things, only, *aaT would include all forms

of things, living and non-living. *aaT would, ﬁrst,

back Snyder and Byrd’s vision about the Internet-

of-Everything

that is the next evolution stage of

IoT (Snyder and Byrd, 2017), and, second, respond

to Moldovan et al.’s statements that “Boundaries bet-

ween computing systems, people, and things are gra-

dually disappearing” and that “New approaches are

required to manage today’s and tomorrow’s increa-

www.gartner.com/newsroom/id/3165317.

Internet-of-Everything versus Internet-of-Things is dis-

cussed in (Simmons, 2015).

Maamar, Z., Faci, N., Sellami, M., Ugljanin, E. and Kajan, E.

Everything-as-a-Thing for Abstracting the Internet-of-Things.

DOI: 10.5220/0006869907330740

In Proceedings of the 13th International Conference on Software Technologies (ICSOFT 2018), pages 733-740

ISBN: 978-989-758-320-9

733

singly connected and heterogenous ecosystems of pe-

ople, computing processes, and things” (Moldovan

et al., 2018).

Considering things as providers and/or consumers

of services would require “revisiting” how today’s

things operate. Several reports indicate that things

are still passive and mainly conﬁned into a data-

provider role (Green, 2015; Mzahm et al., 2013; Wu

et al., 2014). In addition, and according to Gart-

ner’s hype cycle of emerging technologies (Snyder

and Byrd, 2017), IoT has entered the trough of dis-

illusionment, “a period of uninspiring results com-

pared to high expectation”. To ﬁx this disillusion-

ment and promote things from a data-provider role

to service-provider/consumer role, we deem neces-

sary examining how to support things “decide” on

the best course of action to take in response to a

particular surrounding. In this paper, we deﬁne

course of action using storytelling concepts namely

character and script (Ware et al., 2014). On the one

hand, things are characters who either play roles of

living things or offer capabilities of non-living things.

On the other hand, things comply with scripts’ what-

to-do, when, and where.

Our contributions include (i) deﬁnition of IoT-

related thing from a service perspective, (ii) empo-

werment of IoT-related thing so, that, a thing ta-

kes over/fulﬁlls roles/capabilities, (iii) speciﬁcation

of IoT-related thing’s roles/capabilities using storytel-

ling, (iv) proposition of *aaT to abstract IoT applicati-

ons development, and (v) illustration of *aaT through

a healthcare case study. The rest of this paper is orga-

nized as follows. Section 2 consists of some deﬁniti-

ons and then some related works. Section 3 presents

*aaT in terms of foundations and how things bind to

roles and capabilities. Section 4 concludes the paper.

2 SOME DEFINITIONS AND

RELATED WORK

Storytelling. It has been used in different domains

such as computer games and educational virtual

environments. Storytelling has one main ele-

ment, story, that features the following compo-

nents (Young et al., 2013): (i) script that outli-

nes a sequence and/or branching of actions and

events related to the story, (ii) characters that set

personalities along with their mental attitudes and

relationships, and (iii) settings (aka scenes) that

include spatio-temporal locations along with ob-

jects that characters manipulate when they join

the settings. Details about using storytelling in

game development are given in (Crawford, 2004),

for example.

Internet-of-Things. The abundant literature on

IoT (e.g., (Abdmeziem et al., 2016; Barnaghi and

Sheth, 2016; DZone, 2017; Zorzi et al., 2010))

does not help propose a unique deﬁnition of what

IoT is or should be. On the one hand, Barnaghi

and Sheth provide a good overview of IoT re-

quirements and challenges (Barnaghi and Sheth,

2016). Requirements include quality, latency,

trust, availability, reliability, and continuity that

should impact efﬁcient access and use of IoT data

and services. And, challenges result from today’s

IoT ecosystems that feature billions of dynamic

things that make existing search, discovery, and

access techniques and solutions inappropriate

for IoT data and services. On the other hand,

Abdmeziem et al. discuss IoT characteristics and

enabling technologies (Abdmeziem et al., 2016).

Characteristics include distribution, interopera-

bility, scalability, resource scarcity, and security.

And, enabling technologies include sensing, com-

munication, and actuating. These technologies

are mapped onto a three-layer IoT architecture

that are referred to as perception, network, and

application, respectively. Qin et al. (Qin et al.,

2014) deﬁne IoT from a data perspective as

“In the context of the Internet, addressable and

interconnected things, instead of humans, act as

the main data producers, as well as the main data

consumers. Computers will be able to learn and

gain information and knowledge to solve real

world problems directly with the data fed from

things. As an ultimate goal, computers enabled

by the Internet of Things technologies will be able

to sense and react to the real world for humans”.

Thanks to a reliable and efﬁcient Internet, the

Web has become the platform of choice for thou-

sands of online transactions (related to e-commerce,

e-government, e-learning, etc.) involving thousands

of things exposed as services (*aaS). However, *aaS

seems overlooking a major stakeholder in the equa-

tion of achieving these transactions, namely people

who are now labeled as prosumers standing for consu-

mers of services and providers of services (Pedrinaci

and Domingue, 2010). *aaS does not capture the pe-

ople dimension when exposing everything, including

humans, as a service. Our *aaT addresses this limi-

tation by expanding the list of things to people, who,

on top of authorizing the use of their personal resour-

ces (e.g., desktops and networks), will have a say on

how online transactions should be shaped due to con-

cerns like privacy, limited availability, and social atti-

tude. Thus, we consider *aaT as a normal evolution of

*aaS and all its derivatives like *aaR (Resource) (Ba-

ICSOFT 2018 - 13th International Conference on Software Technologies

734

ker et al., 2018).

In (Christophe et al., 2011), the authors discuss

the vision of a Web of things in which things are ex-

posed as services and interactions with these servi-

ces are deﬁned as patterns. Though Christophe et al’s

work is a bit outdated, published in 2011, their vision

has, nowadays, become a reality with the multitude of

everyday objects connected to the Internet. To include

humans in the list of everyday’s “objects”, *aaT offers

the necessary means namely roles and capabilities to

deﬁne living and non-living things, respectively.

In (Perera et al., 2014), sensing-as-a-service mo-

del is presented using 5 actors: sensors, owners of

sensors, publishers of sensors, providers of sensed

data, and consumers of sensed data. Beneﬁts of using

this model include embracement of cloud computing

principles, participatory sensing, sharing and reusing

sensor data, and fostering innovation. The model

is evaluated through the win-win situation based on

several objects that share common sensing data: a

person with a new refrigerator with built-in sensors

(temperature, door, etc.), a sensor publisher, an ice

cream manufacturing company, and a cheese manu-

facturer. All of these objects expose themselves as

sensors whose data are mutually shared in favor of all

with respect to their roles, preferences, and capabili-

ties.

In (Broring et al., 2017), the authors introduce

an architectural model for IoT ecosystems and high-

light 5 common interoperability patterns that would

enable cross-platform interoperability among highly

heterogeneous entities like providers and consumers

from different application domains, among providers

hosted on different IoT platforms, etc., and thus, es-

tablishing successful IoT ecosystems. A particular

cross-platform pattern enables applications to access

resources (information or functionality) from multi-

ple platforms through the same interface speciﬁca-

tion. Despite the focus on interoperability across IoT

applications, services and platforms, the idea of using

patterns to allow multi-purpose of things may be ex-

tended to anything on the Web.

In (Chen et al., 2014), the authors propose

Wisdom-as-a-Service (WaaS) model using 4 types of

services: data, information, knowledge, and wisdom.

WaaS provides intelligent IT applications based on

a variety of intelligent technologies (e.g., personali-

zation and context-awareness) for making judgments

and taking actions so, that, the right services are pro-

vided to humans. After humans consuming service

the process is return to things to start new loop. The

cycle from raw data to the right services is called Wis-

dom Web of Things (W2T) processing cycle that ac-

cording to Chen et al. “... realizes the harmonious

symbiosis of humans, computers, and things in the

hyper-world”. Our *aaT describes this symbiosis in

an uniﬁed manner.

In (Raggett, 2015), the author stresses out the role

of avatars in virtualizing the Web-of-Things (WoT).

On top of connected devices that illustrate things,

Raggett considers living things, which is in line with

our *aaT, as well as other objects. Another use of

avatar-based WoT architecture is discussed in (Mrissa

et al., 2015). Despite the novel concept of using ava-

tars, the human dimension is missing from the colla-

boration space that arises between things.

3 *aaT APPROACH

3.1 Foundations

In compliance with the storytelling principles

(Section 2), we deﬁne *aaT using 2 main con-

cepts (Fig. 1): character that would abstract IoT ap-

plications’ future stakeholders and script that would

abstract IoT applications’ future operations (or course

of action) that the stakeholders will execute. Depen-

ding on a script’s deﬁnition (e.g., narrative descrip-

tion), a character either takes over a Role (R) that we

deﬁne using duties and rights (Section 3.2) or fulﬁlls

a Capability (C) that we, also, deﬁne using functional

and non-functional (aka QoS) attributes (Section 3.3).

On the one hand, role targets living things (hu-

mans). On the other hand, capability targets non-

living things and permits to cater to the needs and

requirements of *aaS. By differentiating living/role

from non-living/capability, *aaT complies with the

separation-of-concerns principle since each has dif-

ferent objectives to achieve, different needs to satisfy,

and different requirements to meet.

In Fig. 1, we note that (i) scripts regulate the ope-

rations (what-to-do) of characters ((n, m) cardinality),

(ii) a role may request other capabilities in accordance

with its rights ((0, n) cardinality), (ii) a role may su-

pervise other roles in accordance with its duties, as

well ((0, n) cardinality), and (iii) a capability may be

composed of other capabilities in accordance with its

functional attributes ((0, n) cardinality). More details

about the interactions between characters are provi-

ded in Section 3.4.

3.2 Binding Characters to Roles

Characters, who refer to living things, take over Ro-

les (R) deﬁned in terms of rights (r) to request and du-

ties (d) to achieve. Rights and duties vary depending

Everything-as-a-Thing for Abstracting the Internet-of-Things

735

Character Thing

as a

Everything

instantiates

takes over

xor

fulfills

requests(0,n)

Script

regulates(n,m)

Role

supervises

(0,n)

Capability

composes

(0,n)

Figure 1: *aaT’s core concepts for abstracting IoT applications’ stakeholders/operations.

on-leave

idle

resumption

(un)planned

leave

on-hold

(consumer)

completion

(un)planned

leave

busy

(provider)

request assignment

request completion

request transfer

response delivery

resumptionresumption

(un)planned

leave

Figure 2: Lifecycle of a character taking over a role.

prevention/

correction

request assignment

activated

(provider)

serviced

request completion

completion

not-

activated

completion

suspended

(consumer)

request transfer

response delivery

Figure 3: Lifecycle of a character fulﬁlling a capability.

busy:R 

j

idle:R 

j

idle:R 

i

busy: R 

i

on-hold:R 

i

on-hold:R 

i

busy:R 

i

Intra-transition Inter-transition

Legend

Figure 4: Supervision cycle representing R2R interaction.

suspended:C 

i

Intra-transition Inter-transition

Legend

not-

activated:C 

i

not-

activated:C 

j

activated:C 

i

activated:C 

j

suspended:C 

i

activated:C 

i

Figure 5: Composition cycle representing C2C interaction.

not-

activated:C 

j

activated:C 

j

idle:R 

i

busy: R 

i

on-hold:R 

i

Intra-transition Inter-transition

Legend

on-hold:R 

i

busy:R 

i

Figure 6: Request cycle representing R2C interaction.

ICSOFT 2018 - 13th International Conference on Software Technologies

736

on whether a character consumes services or provides

services.

1. Character’s rights/duties as a service consumer (c)

are, but not limited to, listed below:

• R.c(r

): search for other services provided by

other characters.

• R.c(r

): receive services from other characters

according to what is agreed upon.

• R.c(r

): raise concerns about other characters’

behaviors.

• R.c(d

): use valid credentials during identiﬁca-

tion.

• R.c(d

): provide feedback, whenever neces-

sary, on the consumed services of other charac-

ters.

• R.c(d

): compensate the consumed services of

other characters as agreed upon.

2. Character’s rights/duties as a service provider (p)

are, but not limited to, listed below:

• R. p(r

): reject service requests (e.g., off-duty)

of other characters.

• R. p(r

): ask for the necessary capabilities

when providing services to other characters.

• R. p(r

): self-protect from malicious requestors

of services.

• R. p(r

): request fair treatment when competi-

tion arises.

• R. p(r

): be compensated in return of the provi-

ded services to other characters.

• R. p(d

): offer fair treatment to all requestors of

services.

• R. p(d

): allow any external request to audit

(check) the provided services to other charac-

ters.

Building upon the aforementioned rights and du-

ties, we illustrate in Fig. 2 a lifecycle for a character

that takes over a role.

• As a service consumer, states include idle, on-

hold, and on-leave. And, transitions include re-

quest transfer, response delivery, completion, re-

sumption (× 2), and (un)planned leave (× 2).

• As a service provider, states include idle, busy,

and on-leave. And, transitions include request

assignment, request completion, completion, re-

sumption (× 2), and (un)planned leave (× 2).

Since rights and duties are deﬁned as abstract con-

cepts, they need to be instantiated according to a case

study, which is discussed in Section 3.5.

3.3 Binding Characters to Capabilities

Characters, that refer to non-living things, fulﬁll

Capabilities (C) deﬁned in terms of functional ( f )

attributes associated with what-is-offered and non-

functional (n f ) attributes associated with what-is-

guaranteed. Functional and non-functional attributes

vary depending on whether the character consumes

services or provides services.

1. Character’s functional/non-functional attributes

as a service consumer (c) are, but not limited to,

listed below:

• C.c( f

): compose services provided by other

characters according to what is agreed upon.

• C.c(n f

): use valid credentials during authenti-

cation.

2. Character’s functional/non-functional attributes

as a service provider (p) are, but not limited to,

listed below:

• C. p( f

): announce services.

• C. p( f

): monitor provided services.

• C. p(n f

): ensure the quality-of-service of the

provided services to other characters.

• C. p(n f

): allow any external request to audit

(check) the provided services to other charac-

ters.

Building upon the aforementioned functional and

non-functional attributes, we illustrate in Fig. 3 a life-

cycle for a character that fulﬁlls a capability.

• As a service consumer, states include not-

activated and suspended. And, transitions include

request transfer, response delivery, and comple-

tion.

• As a service provider, states include not-activated,

activated, and serviced. And, transitions include

request assignment, request completion, comple-

tion (× 3), and prevention/correction.

Since functional and non-functional attributes are

deﬁned as abstract concepts, they need to be instan-

tiated according to a case study, which is discussed

in Section 3.5.

3.4 Interactions between Characters

Fig. 1 illustrates 3 types of interactions that involve

characters together.

• Role-2-Role (R2R) interaction happens through

supervise(0,n) relation. Acting as a provider of

services, a character’s role may

consist of look-

ing after other characters (also acting as providers

Because of 0 min in the cardinality.

Everything-as-a-Thing for Abstracting the Internet-of-Things

737

of services) whose (certain) duties are required for

achieving this role’s duties.

For modeling needs of R2R interaction, we map

supervise relation onto a supervision cycle that in-

volves 2 roles, R

:supervisor and R

:supervisee,

and is represented as a set of connected states

that originate from these roles’ respective lifecy-

cles whether a role is a consumer (supervisor) or

provider (supervisee). On top of these states, the

supervision cycle features 2 types of transitions:

intra-transitions connecting states that belong to

the same lifecycle (already shown in Fig. 2) and

inter-transitions connecting states that belong to

separate lifecycles. Fig. 4 is the supervision cycle

representing R2R interaction. Assumption made

in this cycle is that the supervisee is waiting for

requests from the supervisor. This cycle also high-

lights one intra-transition from busy to on-hold to

allow the same supervisor to switch roles from

provider to consumer and another intra-transition

from on-hold to busy to allow the supervisor to

switch roles from consumer to provider. These

2 intra-transitions need to be added to a charac-

ter’s lifecycle shown in Fig. 2.

• Capability-Capability (C2C) interaction happens

through compose(0,n) relation. Acting as a provi-

der of services, a character’s capability may con-

sist of initiating other characters (also acting as

providers of services) whose (certain) capabilities

are required for achieving this capability’s functi-

onal attributes.

For modeling needs of C2C interaction, we

map compose relation onto a composition cy-

cle that involves 2 capabilities, C

:composer and

:component, and is represented as a set of con-

nected states that originate from these capabi-

lities’ respective lifecycles whether a capability

is a consumer (composer) or provider (compo-

nent). On top of these states, the composition cy-

cle features 2 types of transitions: intra-transitions

connecting states that belong to the same lifecy-

cle (already shown in Fig. 3) and inter-transitions

connecting states that belong to separate lifecy-

cles. Fig. 5 is the composition cycle represen-

ting C2C interaction. Assumption made in this

cycle is that the component is waiting for requests

from the composer. This cycle also highlights one

intra-transition from activated to suspended to al-

low the composer to switch roles from provider to

consumer and another intra-transition from sus-

pended to activated to allow the same composer

to switch roles from consumer to provider. These

2 intra-transitions need to be added to a charac-

ter’s lifecycle shown in Fig. 3.

• Role-Capability (R2C) interaction happens

through request(0,n) relation. Acting as a provi-

der of services, a character’s role may consist of

using other characters (also acting as providers of

services) whose (certain) capabilities’ functional

attributes are required for achieving this role’s

duties.

For modeling needs of R2C interaction, we map

request relation onto a request cycle that in-

volves 1 role, R

:requestor, and 1 capability,

:requestee, and is represented as a set of con-

nected states that originate from both this role’s

lifecycle acting as a consumer (requestor) and this

capability’s lifecycle acting as a provider (reque-

stee). On top of these states, the request cycle fea-

tures 2 types of transitions: intra-transitions con-

necting states that belong to the same lifecycle

(already shown in Fig. 2 and Fig. 3) and inter-

transitions connecting states that belong to sepa-

rate lifecycles. Fig. 6 is the request cycle repre-

senting R2C interaction. Assumption made in this

cycle is that the requestee is waiting for requests

from the requestor. This cycle also highlights one

intra-transition from busy to on-hold to allow the

requestor to switch roles from provider to consu-

mer and another intra-transition from on-hold to

busy to allow the requestor to switch roles from

consumer to provider. These 2 intra-transitions

need to be added to a character’s lifecycle shown

in Fig. 2.

3.5 *aaT APPLICATION TO A CASE

STUDY

To illustrate how we put *aaT into action (so that

*aaT’s concepts become concrete), a simple scena-

rio is used. The scenario concerns a hospital that is

on high-alert being close to a car accident. The hos-

pital has different state-of-the-art equipment and faci-

lities that showcase how IoT can smoothen operations

and improve efﬁciency. For instance, wards have am-

bient sensors for temperature automatic-control, life-

support machines have RFID tags for better tracking,

and smart wrists allow real-time transmission of pa-

tients’ vitals to appropriate recipients.

Let us consider an injured driver who requires a

surgery due to brain bleeding. In compliance with

Section 2’s storytelling principles, the relevant script

for surgery is activated as per the hospital’s prescri-

bed guidelines. A simple deﬁnition of this script

given in Listing 1 where G stands for main goal, TG

Script formalization does not fall into the scope of this

work.

ICSOFT 2018 - 13th International Conference on Software Technologies

738

stands for terminal goal, CH stands for character, R

stands for role, C stands for capability, T stands for

time, and L stands for location. At run time, the script

is activated, which means instantiating the necessary

arguments. For instance, CH:R:doctor becomes John,

CH:R:nurse becomes Melissa, CH:C:thermometer be-

comes thermometer

A12

, T becomes 2:50pm, and L be-

comes operatingTheater

opt3

Listing 1: Example of script deﬁnition.

1 Script = G:stop-brain-bleeding

2 G:prepare-patient

3 (TG:diagnose-patient;

4 CH:R:nurse.takeTemp.CH:R:patient OR CH:C:

thermometer.takeTemp.CH:R:patient,

5 CH:R:nurse.takePress.CH:R:patient OR CH:C

:smartWrist.takePress.CH:R:patient,

6 CH:R:doctor.diagnose.CH:R:patient; T:

currentTime; L:operatingTheater)

7 (TG:give-medication; ..... )

8 G:perform-surgery

9 (TG:prepare-operating-theater; .....)

10 (TG:.....)

11 .....

In Fig. 1, *aaT deﬁnes role with rights and du-

ties, capability with functional and non-functional at-

tributes, and, ﬁnally, relations between roles, between

capabilities, and between roles and capabilities. We

illustrate all these concepts with the brain bleeding

surgery.

Doctor Role: to identify the duties and rights of doc-

tor as role, we resort to job descriptions that cle-

arly deﬁne these duties and rights from different

perspectives like patient, line-manager, peer, com-

munity, etc. In the following, we consider the pa-

tient perspective.

Examples of Doctor’s rights/duties as a service

consumer (c) are:

• Doctor.c(r

): consult patient ﬁles prior and af-

ter surgeries.

• Doctor.c(r

): have access to surgery equip-

ment.

• Doctor.c(d

): return patient ﬁles after surge-

ries..

• Doctor.c(d

): meet deadlines when submitting

surgery requests.

Examples of Doctor’s rights/duties as a service

provider (p) are:

• Doctor. p(r

): inform insurance providers about

patient conditions before and after surgeries.

• Doctor. p(r

): postpone patient surgeries.

• Doctor. p(d

): consult patients before and after

surgeries.

• Doctor. p(d

): prescribe medicines before and

after surgeries.

Thermometer Capability: to identify the functional

and non-functional attributes of thermometer as

capability, we resort to the descriptions that a ma-

ker of this thermometer provides.

Examples of Thermometer’s functional/non-

functional attributes as a service consumer (c)

are:

• Thermometer.c( f

): not-applicable.

• Thermometer.c(n f

): use 2mm diameter dispo-

sable lens-ﬁlters.

Examples of Thermometer’s functional/non-

functional attributes as a service provider (p)

are:

• Thermometer. p( f

): measure body tempera-

ture.

• Thermometer. p(n f

): measure body tempera-

ture with 99% accuracy.

Doctor-Nurse Relation: to illustrate the supervise

relation between doctor and nurse roles, we stress

out the duties of doctor that call for the duties

of nurse. Doctor’s duties will be listed from

a service-consumer perspective whereas nurse’s

duties will be listed from a service-provider per-

spective. Examples of duties are:

• Doctor.c(d

): request patient vitals from nurse.

• Nurse. p(d

): respond to doctor with patient vi-

tals.

smartWrist-Thermometer Relation: to illustrate

the compose relation between smartWrist and

thermometer capabilities, we stress out the capa-

bilities of smartWrist that call for the capabilities

of thermometer. smartWrist’s and thermometer’s

capabilities will be listed from a service-provider

perspective. Examples of capabilities are:

• Thermometer. p( f

): measure body tempera-

ture.

• smartWrist. p( f

): inform nurse based on the

body temperature returned by thermometer.

Nurse-Thermometer Relation: to illustrate the re-

quest relation between nurse as role and thermo-

meter as capability, we stress out the duties of

nurse that call for the capabilities of thermome-

ter. Nurse’s duties will be listed from a service-

consumer perspective whereas thermometer’s ca-

pabilities will be listed from a service-provider

perspective. Examples of duties and capabilities

are:

• Nurse.c(d

): request body temperature from

thermometer.

Everything-as-a-Thing for Abstracting the Internet-of-Things

739

• Thermometer. p( f

): measure body tempera-

ture.

4 CONCLUSION

This paper presented Everything-as-a-Thing (*aaT)

as a new paradigm for abstracting the Internet-

of-Things (IoT). Compared to Everything-as-a-

Service (*aaS) and Everything-as-a-Resource (*aaR),

*aaT differentiates living from non-living things. The

former take over roles that are deﬁned in terms of rig-

hts and duties, and, the latter offer capabilities that

are deﬁned in terms of functional and non-functional

properties. *aaT, also, relies on storytelling’s prin-

ciples, namely script to deﬁne what living and non-

living things are expected to perform and character to

bind living and non-living things to speciﬁc scripts.

Our ongoing work consists of applying *aaT to a real

scenario like the one discussed in this paper.

REFERENCES

Abdmeziem, M. R., Tandjaoui, D., and Romdhani, I.

(2016). Architecting the Internet of Things: State of

the Art, pages 55–75. Springer International Publis-

hing.

Baker, T., Ugljanin, E., Faci, N., Sellami, M., Maamar,

Z., and Kajan, E. (2018). Everything as a Re-

source: Foundations and Illustration through Internet-

of-Things. Computers in Industry, 94.

Barnaghi, P. M. and Sheth, A. P. (2016). On Searching

the Internet of Things: Requirements and Challenges.

IEEE Intelligent Systems, 31(6).

Broring, A., Schmid, S., Schindhelm, C., Khelil, A., Ka-

bisch, S., Kramer, D., Phuoc, D. L., Mitic, J., Ani-

cic, D., and Teniente, E. (2017). Enabling iot ecosys-

tems through platform interoperability. IEEE Soft-

ware, 34(1):54–61.

Chen, J., Ma, J., Zhong, N., Yao, Y., Liu, J., Huang, R.,

Li, W., Huang, Z., Gao, Y., and Cao, J. (2014). WaaS:

Wisdom as a Service. IEEE Intelligent Systems, 29(6).

Christophe, B., Boussard, M., Lu, M., Pastor, A., and Tou-

biana, V. (2011). The web of things vision: Things as

a service and interaction patterns. Bell Labs Technical

Journal, 16(1):55–61.

Crawford, C. (2004). Chris Crawford on Interactive Story-

telling (New Riders Games). New Riders Games, CA,

USA.

DZone (https://dzone.com/guides/iot-applications-

protocols-and-best-practices, 2017 (visited in

May 2017)). The Internet of Things, Application,

Protocols, and Best Practices. Technical report,

DZone.

Green, H. (December 2015). The Internet of

Things in the Cognitive Era: Realizing the

Future and Full Potential of Connected De-

vices. www-01.ibm.com/common/ssi/cgi-

bin/ssialias?htmlﬁd=WWW12366USEN.

Moldovan, D., Copil, S., and Dustdar, S. (2018). Elastic

Systems: Towards Cyber-Physical Ecosystems of Pe-

ople, Processes, and Things. Computer Standards &

Interfaces, 57.

Mrissa, M., M

edini, L., Jamont, J., Le Sommer, N., and

Laplace, J. (2015). An Avatar Architecture for the

Web of Things. IEEE Internet Computing, 19(2).

Mzahm, A., Ahmad, M., and Tang, A. (2013). Agents

of Things (AoT): An intelligent operational concept

of the Internet of Things (IoT). In Proceedings of

the 13th International Conference on Intellient Sys-

tems Design and Applications (ISDA’2013), Bangi,

Malaysia.

Parnas, D. (1972). On the Criteria to be Used in Decom-

posing Systems into Modules. Communications of the

ACM, 15(12).

Pedrinaci, C. and Domingue, J. (2010). Toward the Next

Wave of Services: Linked Services for the Web Data.

Journal of Universal Computer Science, 16(13).

Perera, C., Zaslavsky, A., Christen, P., and Georgakopoulos,

D. (2014). Sensing as a Service Model for Smart Ci-

ties Supported by Internet of Things. Transactions on

Emerging Telecommunications Technologies, 25(1).

Qin, Y., Sheng, Q., Falkner, N., Dustdar, S., Wang, H.,

and Vasilakos, A. (2014). When Things Matter: A

Data-Centric View of the Internet of Things. CoRR,

abs/1407.2704.

Raggett, D. (2015). The Web of Things: Challenges and

Opportunities. Computer, 48(5).

Simmons, L. ((last checked out March 2018) Oc-

tober 2015). What is the Difference between

the Internet-of-Everything and the Internet-of-

Things? blog.cloudrail.com/internet-of-everything-

vs-internet-of-things.

Snyder, T. and Byrd, G. (June 2017). The Internet of Ever-

ything. Computer, 50(6).

Ware, S., Young, R., Harrison, B., and Roberts, D. (2014).

[a computational model of narrative conﬂict at the fa-

bula level. IEEE Transactions on Computational In-

telligence and Artiﬁcial Intelligence in Games, 6(3).

Wu, Q., Ding, G., Xu, Y., Feg, S., Du, Z., Wang, J., and

Long, K. (April 2014). Cognitive Internet of Things:

A New Paradigm Beyond Connection. IEEE Internet

of Things Journal, 1(2).

Young, R. M., Ware, S. G., Cassell, B. A., and Robertson, J.

(2013). Plans and Planning in Narrative Generation:

A Review of Plan-based Approaches to the Genera-

tion of Story, Discourse and Interactivity in Narrati-

ves. Sprache und Datenverarbeitung, Special Issue

on Formal and Computational Models of Narrative,

37(1-2).

Zorzi, M., Gluhak, A., Lange, S., and Bassi, A. (2010).

From Today’s INTRAnet of Things to a Future IN-

TERnet of Things: a Wireless- and Mobility-related

View. IEEE Wireless Commun., 17(6).

ICSOFT 2018 - 13th International Conference on Software Technologies

740
