Web User Interface Implementation Technologies: An Underview

Antero Taivalsaari

, Tommi Mikkonen

, Kari Syst

and Cesare Pautasso

Nokia Technologies, Tampere, Finland

Department of Computer Science, University of Helsinki, Helsinki, Finland

Tampere University of Technology, Tampere, Finland

Software Institute, Faculty of Informatics, USI, Lugano, Switzerland

Keywords:

Web User Interfaces, Web Programming, Web Rendering, Single Page Web Applications, Web Application

Architectures.

Abstract:

Over the years, the World Wide Web has evolved from a document distribution environment into a rich de-

velopment platform that can run compelling, full-ﬂedged software applications. However, the programming

capabilities of the web browser – designed originally for relatively simple scripting tasks – have evolved or-

ganically in a rather haphazard fashion. Consequently, there are many ways to build applications on the Web

today. Depending on one’s viewpoint, current standards-compatible web browsers support three, four or even

ﬁve built-in application rendering and programming models. In this paper, we provide an ”underview” of the

built-in client-side web application UI implementation technologies, i.e., a summary of those rendering mod-

els that are built into the standards-compatible web browser out-of-the-box. While the dominance of the base

HTML/CSS/JS technologies cannot be ignored, we foresee Web Components and WebGL gaining popularity

as the world moves towards more complex and even richer web applications, including systems supporting

virtual and augmented reality.

1 INTRODUCTION

The World Wide Web has become such an integral

part of the human society that it is often forgotten that

the Web did not even exist thirty years ago. The orig-

inal design sketches related to the World Wide Web

date back to the late 1980s. The ﬁrst web browser

prototype for the NeXT computer was completed by

Tim Berners-Lee in December 1990. The ﬁrst version

of the Mosaic web browser was released in Febru-

ary 1993, followed by the ﬁrst commercially suc-

cessful browser – Netscape Navigator – in late 1994.

Widespread commercial use of the Web took off in the

late 1990s (Berners-Lee and Fischetti, 2000) when the

web browser became the most commonly used com-

puter program, sparking a revolution that has trans-

formed not only commerce but communication, social

life and politics as well.

In desktop computers, today nearly all the impor-

tant tasks are performed using the web browser. Even

mobile applications can be viewed merely as ”mirrors

into the cloud” (Charland and Leroux, 2011). While

native mobile apps still offer UI frameworks and wid-

gets that are better suited to the limited screen size and

input modalities of the devices, valuable content has

moved gradually from mobile devices to the cloud,

thus reducing the original role of the mobile apps con-

siderably.

Interestingly, the programming capabilities of the

Web have largely been an afterthought – designed

originally for relatively simple scripting tasks. Due

to different needs and motivations, there are many

ways to make software run on the Web – many more

than people generally realize. Furthermore, over the

years these programming capabilities have evolved in

a rather haphazard fashion. Consequently, there are

various ways to build applications on the Web. With-

out considering any extensions, frameworks and add-

on libraries, depending on one’s viewpoint, the Web

browser natively supports three, four or ﬁve different

built-in application rendering and development mod-

els. Thousands of libraries and frameworks have then

been implemented on top of these built-in models.

Furthermore, in addition to architectures that par-

tition applications more coarsely between server and

client side components (Gallidabino and Pautasso,

2017), it is increasingly possible to ﬁne-tune the ap-

plication logic by moving code ﬂexibly between the

Taivalsaari, A., Mikkonen, T., Systä, K. and Pautasso, C.

Web User Interface Implementation Technologies: An Underview.

DOI: 10.5220/0006885401270136

In Proceedings of the 14th International Conference on Web Information Systems and Technologies (WEBIST 2018), pages 127-136

ISBN: 978-989-758-324-7

127

client and the server (Meijer, 2007). In this context,

the rendering capabilities of the web browser are cru-

cial in creating the presentation layer of the applica-

tions.

In this paper, we provide a comparison of the

built-in client-side web application architectures, i.e.,

the programming capabilities that the web browsers

provide out-of-the-box before any additional libraries

are loaded. This is a topic that has received surpris-

ingly little attention in the literature. While there are

countless papers on speciﬁc web development tech-

nologies, and hundreds of libraries have been devel-

oped on top of the browser, there are few if any

papers comparing the built-in user interface devel-

opment models offered by the browser itself. The

choice between these alternative development mod-

els has a signiﬁcant impact on the overall architecture

and structure of the resulting web applications. The

choices are made more difﬁcult by the fact that the

web browser offers a number of overlapping features

to accomplish even basic tasks, reﬂecting the histori-

cal, organic evolution of the web browser as an appli-

cation platform.

This paper is motivated by the recent trend to-

ward simpler, more basic approaches in web devel-

opment. According to recent studies, the vast major-

ity (up to 86%) of web developers feel that the Web

and JavaScript ecosystems have become far too com-

plex (http://stateofjs.com/). There is a movement to

go back to the roots of web application development

by building directly upon what the web browser can

provide without the added layers introduced by vari-

ous libraries and frameworks. The recent ”zero frame-

work manifesto” crystallizes this desire for simplicity

(Bitworking.org, 2014). However, even the ”vanilla”

browser offers a cornucopia of choices when it comes

to application development.

This paper is an extended version of an earlier

conference paper (Taivalsaari et al., 2017). The ex-

tensions over the earlier work include extended back-

ground and motivation, more detailed description of

the different technologies, together with sample code,

and a more elaborated discussion on the broader ar-

chitectural implications.

The structure of this paper is as follows. In Sec-

tion 2, we provide an overview on the evolution of

the web browser as an application platform. In Sec-

tion 3, we dive into the built-in user interface de-

velopment and rendering models offered by modern

web browsers: (1) DOM, (2) Canvas, (3) WebGL, (4)

SVG, and (5) Web Components. In Section 4, we

provide a comparison, followed by a broader archi-

tectural discussion in Section 5. Finally, Section 6

concludes the paper.

2 EVOLUTION OF THE WEB

BROWSER AS AN

APPLICATION PLATFORM

Over the past twenty-ﬁve years, the World Wide Web

has evolved from its humble origins as a document

sharing system to a massively popular hypermedia ap-

plication and content distribution environment – in

short, the most powerful information dissemination

environment in the history of humankind. This evo-

lution has not taken place in a fortnight; it has not

followed a carefully designed master plan either. Al-

though the World Wide Web Consortium (W3C) has

seemingly been in charge of the evolution of the Web,

in practice the evolution has been driven largely by

dominant web browser vendors: Mozilla, Microsoft,

Apple, Google and (to a lesser degree) Opera. Over

the years, these companies have had divergent, often

misaligned business interests. While browser compat-

ibility has improved signiﬁcantly in recent years, the

browser landscape is still truly a mosaic or cornucopia

of features, reﬂecting organic evolution – or a tug of

war – between different vendors over time.

Before delving into more technical topics, let us

brieﬂy revisit the evolution of the web browser as a

software platform (Taivalsaari et al., 2008; Taivalsaari

and Mikkonen, 2011; Anttonen et al., 2011).

Classic Web. In the early life of the Web, web

pages were truly pages, i.e., page-structured docu-

ments that contained primarily text with interspersed

images, without animation or any interactive con-

tent. Navigation between pages was based on sim-

ple hyperlinks, and a new web page was loaded from

the web server each time the user clicked on a link.

There was no need for asynchronous network com-

munication between the browser and the web server.

For reading user input some pages were presented as

forms, with simple textual ﬁelds and the possibility to

use basic widgets such as buttons and radio buttons.

These types of ”classic web” pages were characteris-

tic of the early life of the Web in the early 1990s.

Hybrid Web. With the introduction of DHTML

– the combination of HTML, Cascading Style Sheets

(CSS), the JavaScript language (Flanagan, 2011), and

the Document Object Model (DOM) – it became pos-

sible to create interactive web pages with built-in sup-

port for more advanced graphics and animation. The

JavaScript language, introduced in Netscape Naviga-

tor version 2.0B almost as an afterthought in Decem-

ber 1995, made it possible to build animated interac-

tive content by scripting directly the web browser.

In the second phase, web pages became increas-

ingly interactive. Web pages started containing ani-

mated graphics and plug-in components that allowed

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

128

richer, more interactive content to be displayed. This

phase coincided with the commercial takeoff of the

Web during the dot-com boom of the late 1990s when

companies realized that they could create commer-

cially valuable web sites by displaying advertisements

or by selling merchandise and services over the Web.

Plug-in components such as Adobe Flash, RealPlayer,

Quicktime and Shockwave were introduced to make

it possible to construct web pages with visually en-

ticing, interactive multimedia, allowing advanced an-

imations, movie clips and audio tracks to be inserted

in web pages.

In this phase, the Web started moving in direc-

tions that were unforeseen by its original designer,

with web sites behaving more like multimedia presen-

tations rather than static pages. Content mashups and

web site cross-linking became popular and communi-

cation protocols between the browser and the server

became increasingly advanced (Daniel and Matera,

2014). Navigation was no longer based solely on hy-

perlinks. For instance, Flash apps supported drag-

and-drop and direct clicking/events on various types

of objects, whereas originally no support for such fea-

tures existed in browsers.

The Web as an Application Platform. In the

early 2000s, the concept of Software as a Service

(SaaS) emerged. Salesforce.com pioneered the use

of the Web as a Customer Relationship Manage-

ment (CRM) application platform in the early 2000s,

demonstrating and validating the use of the Web and

the web browser as a viable target platform for busi-

ness applications. At that point, people realized that

the ability to offer software applications seamlessly

over the Web and then perform instant worldwide

software updates could offer unsurpassed business

beneﬁts.

As a result of these observed beneﬁts, people

started to build web sites that behave much like desk-

top applications, for example, by allowing web pages

to be updated partially, rather than requiring the entire

page to be refreshed. Such systems often eschewed

link-based navigation and utilized direct manipulation

techniques (e.g., drag and drop features) borrowed

from desktop-style applications instead. Interest in

the use of the browser as an application platform was

reinforced by the introduction of Ajax (Asynchronous

JavaScript and XML) (Holdener, 2008). The key idea

in Ajax was to use asynchronous network communi-

cation between the client and the server to decouple

user interface updates from network requests. This

made it possible to build web sites that do not neces-

sarily block when interacting with the server and thus

behave much like desktop applications, for example,

by allowing web pages to be updated asynchronously

one user interface element at a time, rather than re-

quiring the entire page to be updated each and every

time something changed. Although Ajax was primar-

ily a speciﬁc technique rather than a complete devel-

opment model or platform, it fueled further interest

in building ”Web 2.0” applications that could run in

a standard web browser. This also increased the de-

mand for a full-ﬂedged programming language that

could be used directly from inside the web browser in-

stead of relying on any external plug-in components.

After the introduction of Ajax and the concept of

Single Page Applications (SPAs) (Jadhav et al., 2015),

the number of web development frameworks on top

of the web browser has exploded. Today, there are

over 1,300 ofﬁcially listed JavaScript libraries (see

http://www.javascripting.com/).

Server-Side JavaScript. The use of client-side

web development technologies has spread also to

other domains. For instance, after the introduction of

Google V8 high-performance JavaScript engine, the

use of the JavaScript language has quickly spread into

server-side development as well. As a result, Node.js

(https://nodejs.org/) has become a vast ecosystem of

its own. In fact, the NPM (Node Package Manager)

ecosystem has been growing even faster in recent

years than the client-side JavaScript ecosystem. Ac-

cording to npmjs.com, there are more than 700,000

NPM packages at the time of this writing.

As already mentioned earlier, in this paper we

shall focus only on client-side technologies and only

on those technologies that have been included na-

tively in standards-compatible web browsers. We feel

that this is an area that is surprisingly poorly covered

by existing research.

Non-Standard Development Models and Ar-

chitectures. For the sake of completeness, it should

be mentioned that over the years web browsers have

supported various additional client-side rendering and

development models. For instance, Java applets were

an early attempt to include Java language and Java

virtual machine (JVM) support directly in a web

browser. However, because of the immaturity of

the technology (e.g., inadequate performance of early

JVMs) and resistance by some vendors, applets never

became an ofﬁcially supported browser feature.

In the late 2000s, so called Rich Internet Applica-

tion (RIA) platforms such as Adobe AIR or Microsoft

Silverlight were very much in vogue. RIA systems

were an attempt to reintroduce alternative program-

ming languages and libraries in the context of the Web

in the form of browser plug-in components that each

provided a complete platform runtime. For a compre-

hensive overview of RIA systems, refer to Castelyn’s

survey (Casteleyn et al., 2014). However, just as it

Web User Interface Implementation Technologies: An Underview

129

was predicted in (Taivalsaari and Mikkonen, 2011),

the RIA phenomenon turned out to be rather short-

lived. The same seems to be true also of various at-

tempts to support native code execution directly from

within the web browser. For instance, Google’s Na-

tive Client offers a sandbox for running compiled C

and C++ code in the browser, but it has not become

very popular. Mozilla’s classic NPAPI (Netscape Plu-

gin Application Programming Interface) – introduced

originally in 1995 by Netscape – has recently been

removed from all the major browsers; for instance,

Google Chrome stopped supporting it in 2015. Al-

though there are some interesting ongoing efforts in

this area – such as the W3C WebAssembly effort

(http://webassembly.org/), it is now increasingly dif-

ﬁcult to extend the programming capabilities of the

web browser without modifying the source code of

the browser itself.

3 CLIENT-SIDE WEB USER

INTERFACE RENDERING

TECHNOLOGIES

As summarized above, the history of the Web has un-

dergone a number of evolutionary phases, reﬂecting

the document-oriented – as opposed to application-

oriented – origins of the Web. Nearly all the appli-

cation development capabilities of the Web have been

an afterthought, and have emerged as a result of di-

vergent technical needs and business interests instead

of careful planning and coordination.

As a result of the browser evolution that has oc-

curred in the past two decades, today’s web browsers

support a mishmash of complementary, partially over-

lapping rendering and development models. These

include the dominant ”holy trinity” of HTML, CSS

and JavaScript, and its underlying Document Object

Model (DOM) rendering architecture. They also in-

clude the Canvas 2D Context API as well as WebGL.

Additionally, there are important technologies such

as Scalable Vector Graphics (SVG) and Web Compo-

nents that complement the basic DOM architecture.

The choice between the rendering architectures

can have signiﬁcant implications on the structure of

client-side web applications. Effectively, all of the

technologies mentioned above introduce their own

distinct programming models and approaches that the

developers (and development frameworks built on top

of these base technologies) are expected to use. Fur-

thermore, all of them have varying levels of frame-

work, library and tool support available to simplify

the actual application development work on top of the

underlying development model. The DOM-based ap-

proach is by far the most popular and most deeply

ingrained, but the other technologies deserve a fair

glimpse as well.

Below we will dive more deeply into each technol-

ogy. We will start with the DOM, Canvas and WebGL

models, because these three technologies can be re-

garded more distinctly as three separate technologies.

We will then examine SVG and Web Components,

which introduce their own programming models but

which are closely coupled with the underlying DOM

architecture at the implementation level.

3.1 DOM / DHTML

In web parlance, the Document Object Model (DOM)

is a platform-neutral API that allows programs and

scripts to dynamically access and update the content,

structure and style of web documents. Document Ob-

ject Model is the foundation for Dynamic HTML –

the combination of HTML, CSS, and JavaScript –

that allows web documents to be created and manip-

ulated using a combination of declarative and imper-

ative development styles. Logically, the DOM can be

viewed as an attribute tree that represents the con-

tents of the web page that is currently displayed by

the web browser. Programmatic interfaces are pro-

vided for manipulating the contents of the DOM tree

from HTML, CSS and JavaScript.

In the web browser, the DOM serves as the foun-

dation for a retained (automatically managed) graph-

ics architecture. In such a system, the application de-

veloper has no direct, immediate control over render-

ing. Rather, all the drawing is performed indirectly

by manipulating the DOM tree by adding, removing

and modifying its nodes; the browser will then decide

how to optimally lay out and render the display after

each change.

Over the years, the capabilities of the DOM have

evolved signiﬁcantly. The evolution of the DOM

has been described in a number of sources, includ-

ing Flanagan’s JavaScript ”bible” (Flanagan, 2011).

In this paper we will not go into details, but it is use-

ful to provide a summary since this evolution partially

explains why the browser offers such a cornucopia of

overlapping functionality.

• DOM Level 1 speciﬁcation – published in 1998

– deﬁnes the core HTML (and XML) document

models. It speciﬁes the basic functionality for

document navigation.

• DOM Level 2 speciﬁcation – published in 2000

– deﬁnes the stylesheet object model, and pro-

vides methods for manipulating the style infor-

mation attached to a document. It also enables

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

130

traversals on the document and provides support

for XML namespaces. Furthermore, it deﬁnes

the event model for web documents, including the

event listener and event ﬂow, capturing, bubbling,

and cancellation functionality.

• DOM Level 3 speciﬁcation – released as a num-

ber of separate documents in 2001-2004 – deﬁnes

document loading and saving capabilities, as well

as provides document validation support. In ad-

dition, it also addresses document views and for-

matting, and speciﬁes the keyboard events and

event groups, and how to handle them.

• DOM Level 4 speciﬁcation refers to a ”living doc-

ument” that is kept up to date with the latest de-

cisions of the WHATWG/DOM working group

(https://dom.spec.whatwg.org/).

DOM attributes can be manipulated from HTML,

CSS, JavaScript, and to some extent also XML code.

As a result, a number of entirely different develop-

ment styles are possible, ranging from purely impera-

tive usage to a combination of declarative styles using

HTML and CSS. For instance, it is possible to create

impressive 2D/3D animations using the CSS anima-

tion capabilities without writing a single line of im-

perative JavaScript code.

Below is a ”classic” DHTML example that de-

ﬁnes a text paragraph and an input button in HTML.

The input button deﬁnition includes an onclick event

handler function that – when clicked – hides the text

paragraph by changing its visibility style attribute to

’hidden’.

<!DOCTYPE html>

T h i s i s a p i e c e o f t e x t .

<i n pu t ty p e = ” b u t t o n ” v a l ue =” H i d e t e x t ”

o n c l i c k = ” d o c u m e n t . g et E l e me nt B y I d ( ’ t e x t ’ ) . s t y l e . v i s i b i l i t y

= ’ h i dd en ’ ”>

</ body></ html>

In practice, very few developers nowadays use

the raw, low-level DOM interfaces directly. The

DOM and DHTML serve as the foundation for an

extremely rich library and tool ecosystem that has

emerged on top of the base technologies. The manip-

ulation of DOM attributes is usually performed using

higher-level convenience functions provided by pop-

ular JavaScript / CSS libraries and frameworks.

3.2 Canvas

The Canvas (ofﬁcially known as the Canvas

2D Context API) is an HTML5 feature that

enables dynamic, scriptable rendering of two-

dimensional (2D) shapes and bitmap images

(https://www.w3.org/TR/2dcontext/). It is a low-

level, imperative API that does not provide any

built-in scene graph or advanced event handling

capabilities. It that regard, Canvas offers much

lower level graphics support than the DOM or SVG

APIs that will automatically manage and (re)render

complex graphics elements.

Canvas objects are drawn in immediate mode.

This means that once a shape such as a rectangle is

drawn using Canvas API calls, the data structure rep-

resenting the rectangle is immediately forgotten by

the system. If the position of the rectangle needs to

be changed, the entire scene needs to be repainted, in-

cluding any objects that might have been invalidated

(covered) by the rectangle. In the equivalent DOM or

SVG case, one could simply change the position at-

tributes of the rectangle, and the browser would then

automatically determine how to optimally re-render

all the affected objects.

The code snippet below provides a minimal ex-

ample of Canvas API usage. In this example, we

ﬁrst instantiate a 2D canvas graphics context of size

100x100 after declaring the corresponding HTML el-

ement. We then imperatively draw a full circle with a

40 pixel radius in the middle of the canvas using the

Canvas 2D Context JavaScript API.

<!DOCTYPE html>

v a r c = d o c u m e n t . g e t E l e me n t B yI d ( ”myCanvas ” ) ;

v a r c t x = c . g e t C o n t e x t ( ” 2 d ” ) ;

c t x . b e g i n P a t h ( ) ;

c t x . a r c ( 5 0 , 5 0 , 4 0 , 0 , 2 ∗ Math . PI ) ;

c t x . s t r o k e ( ) ;

</ s c r i p t>

</ body></ html>

Note that in these simple examples we are mix-

ing HTML and JavaScript code. In real-world ex-

amples, it would be a good practice to keep declara-

tive HTML (and CSS) code and imperative JavaScript

code in separate ﬁles. We will discuss programming

style implications later in Section 4.

The event handling capabilities of the Can-

vas API are minimal. A limited form of event

handling is supported by the Canvas API with

hit regions (https://developer.mozilla.org/en-

US/docs/Web/API/Canvas API/Tutorial/Hit regions

and accessibility).

Conceptually, Canvas is a low level API upon

which a higher-level rendering engine might be built.

Although canvas elements are created in the browser

as subelements in the DOM, it is entirely possible to

create just one large canvas element, and then per-

form all the application rendering and event handling

inside that element. There are JavaScript libraries

Web User Interface Implementation Technologies: An Underview

131

that add event handling and scene graph capabilities

to the canvas element. For instance, with Paper.js

(http://paperjs.org/) or Fabric.js (http://fabricjs.com/)

libraries, it is possible to paint a canvas in layers, and

then recreate speciﬁc layers, instead of having to re-

paint the entire scene manually each time. Thus, the

Canvas API can be used as a full-ﬂedged application

rendering model of its own.

The Canvas element was was initially introduced

by Apple in 2004 for use inside their own Mac OS

X WebKit component in order to support applications

such as Dashboard widgets in the Safari browser. In

2005, the Canvas element was adopted in version 1.8

of Gecko browsers and Opera in 2006. The Canvas

API was later standardized by the Web Hypertext Ap-

plication Technology Working Group (WHATWG).

The adoption of the Canvas API was hindered by

Apple’s intellectual property claims over this API.

From a technical viewpoint, adoption was also slowed

down by the fact that the Canvas API expressiveness

is signiﬁcantly more limited than the well-established,

mature immediate-mode graphics APIs that were

available in mainstream operating systems already a

decade or two earlier. Microsoft’s DirectX API –

originally introduced in Windows 95 – is a good ex-

ample of a substantially more comprehensive API.

3.3 WebGL

WebGL (http://www.khronos.org/webgl/) is a cross-

platform web standard for hardware accelerated 3D

graphics API developed by Khronos Group, Mozilla,

and a consortium of other companies including Ap-

ple, Google and Opera. The main feature that WebGL

brings to the Web is the ability to display 3D graph-

ics natively in the web browser without any plug-in

components. WebGL is based on OpenGL ES 2.0

(http://www.khronos.org/opengles), and it leverages

the OpenGL shading language GLSL. A comprehen-

sive JavaScript API is provided to open up OpenGL

programming capabilities to JavaScript programmers.

In a nutshell, WebGL provides a JavaScript API

for rendering interactive, immediate-mode 3D (and

2D) graphics within any compatible web browser

without the use of plug-in components. WebGL is in-

tegrated into major web browsers, enabling Graphics

Processing Unit (GPU) accelerated usage of physics

and image processing and effects in web applications.

WebGL applications consist of control code written in

JavaScript and shader code that is typically executed

on a GPU.

WebGL is widely supported in modern desktop

browsers. However, its availability, performance and

usability is dependent on various factors such as the

GPU supporting it.

Just like the Canvas API discussed above, the

WebGL API is a rather low-level API that does not

automatically manage rendering or support high-level

events. From the application developer’s viewpoint,

the WebGL API may in fact be too cumbersome to

use directly without utility libraries. For instance, set-

ting up typical view transformation shaders (e.g., for

view frustum), loading scene graphs and 3D objects

in the popular industry formats can be very tedious

and requires writing a lot of source code.

Given the verbosity of shader deﬁnitions, we

do not provide any code samples here. However,

there are excellent WebGL examples on the Web.

For instance, the following link contains a great

example of an animated, rotating, textured cube

with lighting effects: http://www.sw-engineering-

candies.com/snippets/webgl/hello-world/.

Because of the complexity and the low level na-

ture of the raw WebGL APIs, many JavaScript conve-

nience libraries have been built or ported onto WebGL

in order to facilitate development. Examples of such

libraries include A-Frame, BabylonJS, three.js, O3D,

OSG.JS, CopperLicht and GLGE.

3.4 SVG

Scalable Vector Graphics (SVG) is an XML-based

vector image format for two-dimensional graphics

with support for interactivity, afﬁne transformations

and animation. The SVG Speciﬁcation (W3C, 2011)

is an open standard published by the World Wide

Web Consortium (W3C) originally in 2001. Although

bitmap images were supported since the early days of

the Web (the <IMG> tag was introduced in the Mosaic

browser in 1992), vector graphics support came much

later via SVG.

The code snippet below provides a simple exam-

ple of an SVG object deﬁnition that renders an auto-

matically scaling, graphical W3C logo to the screen

(https://dev.w3.org/SVG/tools/svgweb/samples/svg-

ﬁles/w3c.svg).

<sv g xmlns = ’ h t t p : / / www . w3 . o rg / 2 0 0 0 / svg ’ vie wBox=” 0 0 131

76 ”>

<p a t h d= ”M36, 5 l 1 2 , 4 1 l1 2 −41h 3 3 v 4 l −13 ,21 c30 , 1 0 ,2 , 6 9 −2 1 , 2 8

l7 −2c15 ,27 ,33 , − 2 2 ,3 , − 1 9 v−4l1 2 −20h−15 l −17 ,59h−1l

−13−42 l −12 ,42h−1l −20−67 h 9 l1 2 , 4 1 l8 −28 l −4−13h9 ”

f i l l = ’#0 0 5A9C ’ />

<p a t h d= ”M94, 5 3 c15 , 3 2 , 3 0 , 1 4 , 3 5 , 7 l −1−7c −16 ,26 −32 ,3 −34 ,0

M122 , 1 6 c −10 −21 −34,0−21,30 c −5−30 16 , −38 23 , −21 l 5

−10 l −2−9” />

</ s v g>

</ d iv>

While SVG was originally just a vector image for-

mat, SVG support has been integrated closely with the

web browser to provide comprehensive means for cre-

ating interactive, resolution-independent content for

the Web. Just like with the HTML DOM, SVG images

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

132

can be manipulated using DOM APIs via HTML,

CSS and JavaScript code. This makes it possible to

create shapes such as lines, Bezier/elliptical curves,

polygons, paths and text and images that be resized,

rescaled and rotated programmatically using a set of

built-in afﬁne transformation and matrix functions.

The code sample below serves as an example of

interactive SVG that deﬁnes a circle object that is ca-

pable of changing its size in response to mouse input.

<!DOCTYPE sv g PUBLIC ” −/ /W3C / / DTD SVG 1 . 1 / / EN”

” h t t p : / / www . w3 . o rg / G r a ph i c s / SVG / 1 . 1 / DTD/ sv g 1 1 . d t d ”>

<sv g wi d th =” 6cm” h e i g h t =” 5cm” viewBox=” 0 0 600 500 ” xm l ns

=” h t t p : / / www . w3 . o rg / 2 0 0 0 / s vg ” v e r s i o n =” 1 . 1 ”>

<!−− Change t h e r a d i u s w i t h ea c h c l i c k −−>

f u n c t i o n c i r c l e c l i c k ( e v t ) {

v a r c i r c l e = e v t . t a r g e t ;

v a r c u r r e n t R a d i u s = c i r c l e . g e t A t t r i b u t e ( ” r ” ) ;

i f ( c u r r e n t R a d i u s == 10 0 ) {

c i r c l e . s e t A t t r i b u t e ( ” r ” , c u r r e n t R a d i u s ∗ 2 ) ;

} e l s e {

c i r c l e . s e t A t t r i b u t e ( ” r ” , c u r r e n t R a d i u s ∗ 0 . 5 ) ;

}

</ s c r i p t>

<!−− D e f i n e c i r c l e w i t h o n c l i c k e v e n t h a n d l e r −−>

<c i r c l e o n c l i c k =” c i r c l e c l i c k ( e v t ) ” cx =” 300 ” c y = ” 225 ” r

=” 100 ” f i l l =” bl u e ” />

</ s v g>

As illustrated in the example, the SVG scene

graph enables event handlers to be associated with ob-

jects, so a circle object may respond to an onClick

event or other events. To get the same functionality

with canvas, one would have to implement the code

to manually match the coordinates of the mouse click

with the coordinates of the drawn circle in order to

determine whether it was clicked.

Just like with the HTML DOM, SVG support in

the web browser is based on a retained (managed)

graphics architecture. Inside the browser, each SVG

shape is represented as an object in a scene graph that

is rendered to the display automatically by the web

browser. When the attributes of an SVG object are

changed, the browser will calculate the most optimal

way to re-render the scene, including the other objects

that may have been impacted by the change.

In the earlier days of the Web, SVG was the only

means to implement a scalable, ”morphic” graphics

system, which is why the SVG DOM API was used

as the foundation for graphics implementation, e.g.,

in the original Lively Kernel web programming

system (Taivalsaari et al., 2008). The following

link provides a reference to a more comprehensive,

”Lively-like” example of an SVG-based application

that includes interactive capabilities (image rescal-

ing and rotation based on mouse events) as well:

https://dev.w3.org/SVG/tools/svgweb/samples/svg-

ﬁles/photos.svg/.

In general, it is important to summarize that in the

context of the Web, considering its tight integration

within the DOM and its ability to embed HTML snip-

pets as a foreign Object, SVG is much more than just

an image format. Together with event handling capa-

bilities, afﬁne transformations, gradient support, clip-

ping, masking and composition features, SVG can be

used as the basis for a full-ﬂedged, standalone graph-

ical application architecture or windowing system.

3.5 Web Components

Web Components (https://www.w3.org/TR/#tr Web

Components) are a set of features added to the HTML

and DOM speciﬁcations to enable the creation of

reusable widgets or components in web documents

and applications. The intention behind Web Compo-

nents is to bring component-based software engineer-

ing principles to the World Wide Web, including the

interoperability of higher-level HTML elements, en-

capsulation, information hiding and the general abil-

ity to create reusable, higher-level UI components that

can be added ﬂexibly to web applications.

An important motivation for Web Components is

the fundamentally brittle nature of the Document Ob-

ject Model. The brittleness comes from the global

nature of elements in the DOM created by HTML,

CSS and JavaScript code. For example, when you use

a new HTML id or class in your web application

or page, there is no easy way to ﬁnd out if it will

conﬂict with an existing name already used by the

page earlier. Subtle bugs creep up, style selectors can

suddenly go out of control, and performance can suf-

fer, especially when attempting to combine code writ-

ten by multiple authors (Mikkonen and Taivalsaari,

2008). Over the years various tools and libraries have

been invented to circumvent the issues, but the funda-

mental brittleness issues remain. The other important

motivation is the ﬁxed nature of the standard set of

HTML elements. Web Components make it possible

to extend the basic set of components and support dy-

namically downloadable components across different

web pages or applications.

Web Components are built on top of a concept

known as the Shadow DOM. In technical terms,

the Shadow DOM introduces the concept of parallel

”shadow” subtrees in the Document Object Model.

These subtrees can be viewed conceptually as ”ice-

bergs” that expose only their tip while the imple-

mentation details remain invisible (and inaccessible)

under the surface. Unlike regular branches in the

DOM tree, shadow trees provide support for scoped

styles and DOM encapsulation, thus obeying the well-

known separation of concerns and modularity princi-

ples that encourage strong decoupling between public

Web User Interface Implementation Technologies: An Underview

133

interfaces and implementation details (Parnas, 1972).

Utilizing the Shadow DOM, the programmer can bun-

dle CSS with HTML markup, hide implementation

details, and create self-contained reusable compo-

nents in vanilla JavaScript without exposing the im-

plementation details or having to follow awkward

naming conventions to ensure unique naming.

At the technical level, a shadow DOM tree is just

a normal DOM tree with two differences: 1) how it is

created and used, and 2) how it behaves in relation to

the rest of the web page. Normally, the programmer

creates DOM nodes and appends those nodes as chil-

dren of another element. With shadow DOM, the pro-

grammer creates a scoped DOM tree that is attached

to the element but that is separate from its actual chil-

dren. The element it is attached to is its shadow host.

Anything that the programmer adds to the shadow

tree becomes local to the hosting element, including

the <style> attributes. This is how shadow DOM

achieves CSS style scoping.

The following listing presents a minimal web

component example that creates a text editor that au-

tomatically resizes itself as text is entered in the text

area. Note that this example only describes the use of

the component – not its deﬁnition.

<!DOCTYPE h t ml>

</ h e a d><body>

A u t o m a t i c a l l y r e s i z i n g t e x t i n p u t c o mp o ne n t:

E d i t me !

</ body></ h tm l>

Up until recently, many browsers did not

support Web Components. Rather, they had

to be emulated in the form of polyﬁll li-

braries that implement the missing function-

ality (http://webcomponents.org/polyﬁlls/).

For latest implementation status, refer to

http://caniuse.com/#feat=shadowdom/.

4 COMPARISON

Table 1 provides a comparison of the technologies in-

troduced in the previous section. The table covers

topics such as the overall development paradigm (im-

perative vs. declarative), rendering architecture (re-

tained/managed vs. immediate), information hiding

support, primary intended usage domain and current

popularity.

In the original version of this paper (Taivalsaari

et al., 2017), we discussed the topics presented in Ta-

ble 1, as well as examined the characteristics and typ-

ical use cases of the presented technologies in more

depth. Refer to the earlier paper for more details.

Table 1: Comparison of Built-In Client-Side Rendering

Technologies.

DOM /

DHTML

Canvas WebGL SVG Web Compo-

nents

Year of In-

troduction

1998 2004 2011 2001 2011

Development

Paradigm

Declarative

and imper-

ative

Imperative Imperative Declarative

and im-

perative

Declarative

and im-

perative

Rendering

Architecture

Retained Immediate

(explicit

repainting

required)

Immediate

(explicit

repainting

required)

Retained Retained

Information

Hiding

No No No No (except

when creating

multiple SVG

images)

Yes (Shadow

DOM encap-

sulation and

scoped styles)

Primary Us-

age Domain

Documents

and forms

2D graph-

ics (e.g., in

games)

3D/2D graph-

ics especially

in games and

VR/AR

2D image ren-

dering

Web appli-

cations and

graphical user

interfaces

Popularity Ubiquitous Popular in

speciﬁc use

cases

Limited Popular in

speciﬁc use

cases

Growing

Technology

Maturity

Mature Mature Mature Mature Emerging

(standard-

ization

underway)

Abstraction

Level

Medium Very low Low Medium High

Ease of

Code Reuse

Low to

medium

Low Medium

(shaders)

Low to high

(high as an

image format)

High

Declarative

Animation

Support

Yes No No Yes Yes

Mobile

Browser

Support

Yes Yes Not in An-

droid (add-

ons required)

Yes Not in iOS

(polyﬁll add-

ons required)

5 BROADER ARCHITECTURAL

DISCUSSION

According to MacLennan’s classic software design

principles (Schummer et al., 2009), some of the most

fundamental principles in engineering aesthetics are

simplicity and consistency: There should be a mini-

mum number of concepts with simple rules for their

combination; things that are similar should also look

similar, and different things should look different

(MacLennan, 1999). Unfortunately, the web browser

violates these and several other key principles in a

number of ways, as evidenced by the above observa-

tions.

Overlapping Capabilities. Ideally, in a software

development environment there should be only one,

clearly the best and most obvious, way to accomplish

each task. However, in web development – even in

a generic web browser without add-on components

or libraries – there are several overlapping ways to

accomplish even the most basic rendering tasks. It

is not easy to provide recommendations on speciﬁc

technologies to use, except for those tasks in which

immediate-mode graphics are required (in which case

either the Canvas or WebGL API will have to be uti-

lized). In most cases, developers will end up using the

basic DOM/DHTML approach, complemented with

various libraries.

Mismatching Development Styles. When

composing web applications even using the basic

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

134

DOM/DHTML approach, the developers commonly

face a mixture of declarative and imperative program-

ming styles. Recent trends (e.g., CSS in JS) attempt

to reduce everything to JavaScript at the expense of

the conciseness of the declarative approaches. They

may also have to use a combination of retained and

immediate-mode graphics especially when aiming at

applications that are usable across different screen

sizes – following responsive web design (Marcotte,

2011).

Incompatible and Incoherent Abstractions.

The abstractions and programming patterns supported

by Canvas and WebGL APIs are very different from

DOM/DHTML and SVG programming. Web Com-

ponents introduce yet another abstraction layer that

has been patched on top of the DOM/DHTML. In

general, the features supported by the browser reﬂect

organic evolution of features over the years rather

than any carefully master-planned architectural de-

sign.

Nevertheless, given the organic evolution of the

web ecosystem, it is fairly safe to predict that we

will not go back to a less diverse web ecosystem or

have a chance to radically simplify the feature set of

the web browser. For example, the latest versions of

the JavaScript language – ECMAScript 6, 7 and 8 –

have introduced a lot of new language functionality

(promises, generators and decorators, to list a few),

thus ensuring that library rewriting and evolution will

be swift in the coming years. This will further fuel

some of the most problematic characteristics of web

development, addressed in the following.

Fashion-driven Development. Over the past

years there has been a notable trend in the library area

towards fashion-driven development. By this we re-

fer to the developers’ tendency to surf on the wave

of newest and most dominant ”alpha” frameworks.

For instance, the once hugely popular Prototype.js

and JQuery.js libraries are nowadays mostly forgot-

ten, replaced by Knockout.js and Backbone.js in 2012.

Back in 2014, Angular.js was by far the most domi-

nant alpha framework, while in 2018 it is the React.js

+ Redux.js ecosystem that seems to be capturing the

majority of developer attention. As witnessed by the

somewhat unfortunate recent evolution of the Angu-

lar ecosystem, the alpha frameworks have a tendency

to evolve very quickly once they get developers’ at-

tention, leading into compatibility issues. To make

matters worse, once the next fashionable alpha frame-

work emerges and hordes of developers start jump-

ing ship onto the new one, it becomes questionable

to what extent one can build long-lasting business-

critical applications and services, e.g., for the medi-

cal industry in which products must commonly have

a minimum lifetime of twenty years. With the present

pace of upgrades, the browser and the web server as

the runtime environment would be almost completely

replaced by patches, upgrades, and updates; similarly,

most of the libraries would be replaced several times

by newer, fancier ones.

Opportunistic Design and ”Cargo Cult” Pro-

gramming. In web development there has histori-

cally been a strong tradition of mashup-based devel-

opment: searching, selecting, pickling, mashing up

and glueing together disparate libraries and pieces of

software (Hartmann et al., 2008). Often such devel-

opment has the characteristics of cargo cult program-

ming: ritually including code and program structures

that serve no real purpose or that the programmer has

chosen to include because hundreds of other develop-

ers have done so – without really understanding why.

While this approach can save a lot of work and open

up interesting opportunities for large-scale code reuse

(Salminen and Mikkonen, 2012), this approach does

not foster development of reliable, long-lasting ap-

plications, because even the smallest changes in the

constituent components – each of which evolves sep-

arately and independently – can break applications

(Salminen et al., 2010).

Violation of Established Software Engineering

Principles. Although many web developers may

not realize this, the web browser violates many es-

tablished software engineering principles, including

the lack of information hiding, lack of manifest in-

terfaces, lack of orthogonality, and lack of (afore-

mentioned) simplicity and consistency (MacLennan,

1999) (Mikkonen and Taivalsaari, 2008). The absence

of these principles is easy to understand given that the

web browser was originally designed to be a docu-

ment distribution environment rather than an appli-

cation execution environment. However, the current

popularity of the Web as a software platform makes it

unfortunate that these important principles have been

ignored. Currently Web Components are the best –

and arguably also the only – chance to reintroduce

some of these important principles to the heart of the

Web.

In the broader picture, the deﬁciencies of the web

browser as a software platform are being tackled with

an abundance of libraries. As of this writing, there are

more than 1,300 ofﬁcially listed JavaScript libraries

in javascripting.com, with new ones being introduced

at a rapid pace. Although many of the libraries are

domain-speciﬁc, a lot of them are aimed squarely

at solving the architectural limitations of the web

browser, e.g., to provide a consistent set of manifest

interfaces to perform all the programming tasks. Over

the years, JavaScript libraries have evolved from mere

Web User Interface Implementation Technologies: An Underview

135

convenience function libraries to full-ﬂedged Model-

View-Controller (MVC) frameworks providing exten-

sive UI component sets, application state manage-

ment, network communication and database inter-

faces, and so on. In general, these will not help in

tackling the above characteristics but rather add a new

layer of complexity on top of them.

6 CONCLUSIONS

Web development today presents a cornucopia of

choices on many fronts. Both on the client side and

the server side, there exist a large number of compet-

ing, overlapping technologies, and new libraries and

tools become available almost on a daily basis. The

rapid pace of innovation has put the developers in a

complex position in which there are numerous ways

to build applications on the Web – many more than

most people realize, and also arguably more than are

really needed.

In this paper, we have investigated one of the

perhaps most overlooked areas in web development:

the client-side web rendering architectures that have

been built into the web browser. We summarized ﬁve

built-in rendering and application development mod-

els (DOM/DHTML, Canvas, WebGL, SVG, and Web

Components), followed by some broader architectural

discussion.

REFERENCES

Anttonen, M., Salminen, A., Mikkonen, T., and Taivalsaari,

A. (2011). Transforming the Web into a Real Appli-

cation Platform: New Technologies, Emerging Trends

and Missing Pieces. In Proceedings of the 2011 ACM

Symposium on Applied Computing, pages 800–807.

ACM.

Berners-Lee, T. and Fischetti, M. (2000). Weaving the

Web: The Original Design and Ultimate Destiny of

the World Wide Web by its Inventor. HarperInforma-

tion.

Bitworking.org (2014). Zero Framework Manifesto: No

More JS Frameworks. https://bitworking.org/news/

2014/05/zero framework manifesto.

Casteleyn, S., Garrig

os, I., and Maz

on, J.-N. (2014). Ten

Years of Rich Internet Applications: A Systematic

Mapping Study, and Beyond. ACM Trans. Web,

8(3):18:1–18:46.

Charland, A. and Leroux, B. (2011). Mobile Application

Development: Web vs. Native. Communications of

the ACM, 54(5):49–53.

Daniel, F. and Matera, M. (2014). Mashups: Concepts,

Models and Architectures. Springer.

Flanagan, D. (2011). JavaScript: The Deﬁnitive Guide, 6th

Edition. O’Reilly Media.

Gallidabino, A. and Pautasso, C. (2017). Maturity Model

for Liquid Web Architectures. In 17th International

Conference on Web Engineering (ICWE 2017), vol-

ume 10360, pages 206–224, Rome, Italy. Springer.

Hartmann, B., Doorley, S., and Klemmer, S. R. (2008).

Hacking, Mashing, Gluing: Understanding Oppor-

tunistic Design. IEEE Pervasive Computing, 7(3):46–

54.

Holdener, A. T. (2008). Ajax: The Deﬁnitive Guide: Inter-

active Applications for the Web. O’Reilly Media.

Jadhav, M. A., Sawant, B. R., and Deshmukh, A. (2015).

Single Page Application using AngularJS. Interna-

tional Journal of Computer Science and Information

Technologies, 6(3).

MacLennan, B. J. (1999). Principles of Programming Lan-

guages: Design, Evaluation, and Implementation, 3rd

edition. Oxford University Press.

Marcotte, E. (2011). Responsive Web Design. Editions Ey-

rolles.

Meijer, E. (2007). Democratizing the Cloud. In Companion

Proc. of OOPSLA’07, pages 858–859.

Mikkonen, T. and Taivalsaari, A. (2008). Web Applications

– Spaghetti Code for the 21st Century. In Proc. Int’l

Conf. Software Engineering Research, Management

and Applications (SERA’2008, Prague, Czech Repub-

lic, August 20-22, 2008), pages 319–328. IEEE Com-

puter Society.

Parnas, D. L. (1972). On the Criteria to be Used in Decom-

posing Systems into Modules. Communications of the

ACM, 15(12):1053–1058.

Salminen, A. and Mikkonen, T. (2012). Mashups: Software

Ecosystems for the Web Era. In IWSECO@ ICSOB,

pages 18–32.

Salminen, A., Mikkonen, T., Nyrhinen, F., and Taivalsaari,

A. (2010). Developing Client-Side Mashups: Experi-

ences, Guidelines and the Road Ahead. In Proc. 14th

Int’l Academic MindTrek Conference: Envisioning

Future Media Environments, pages 161–168. ACM.

Schummer, J., MacLennan, B., and Taylor, N. (2009). Aes-

thetic Values in Technology and Engineering Design.

In Philosophy of Technology and Engineering Sci-

ences, Handbook of the Philosophy of Science, pages

1031 – 1068. North-Holland, Amsterdam.

Taivalsaari, A. and Mikkonen, T. (2011). The Web as an Ap-

plication Platform: The Saga Continues. In 37th EU-

ROMICRO Conference on Software Engineering and

Advanced Applications, pages 170–174. IEEE.

Taivalsaari, A., Mikkonen, T., Ingalls, D., and Palacz, K.

(January 2008). Web Browser as an Application Plat-

form: the Lively Kernel Experience, Sun Labs Tech-

nical Report TR-2008-175.

Taivalsaari, A., Mikkonen, T., Syst

a, K., and Pautasso, C.

(2017). Comparing the Built-In Application Archi-

tecture Models in the Web Browser. In International

Conference on Software Architecture (ICSA). IEEE.

W3C (2011). Scalable Vector Graphics (SVG) Speciﬁcation

1.1 (Second Edition). https://www.w3.org/TR/SVG/.

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

136
