Towards a Data Warehouse Architecture for Managing Big Data

Evolution

Darja Solodovnikova and Laila Niedrite

Faculty of Computing, University of Latvia, Raina blvd. 19, Riga, Latvia

Keywords: Data Warehouse, OLAP, Big Data, Evolution, Adaptation, Architecture.

Abstract: The problem of designing data warehouses in accordance with user requirements and adapting its data and

schemata to changes in these requirements as well as data sources has been studied by many researchers

worldwide in the context of relational database environments. However, due to the emergence of big data

technologies and the necessity to perform OLAP analysis over big data, innovative methods must be

developed also to support evolution of data warehouse that is used to analyse big data. Therefore, the main

objective of this paper is to propose a data warehousing architecture over big data capable of automatically

or semi-automatically adapting to user needs and requirements as well as to changes in the underlying data

sources.

1 INTRODUCTION

Data warehousing and OLAP technologies have

been used to analyse data stored in relational

databases to support decision making for several

decades. During this time, the majority of research

problems related to traditional data warehousing

have been solved. However, during the course of

time, data that should be processed and analysed in

the decision-making process have become so

enormous and heterogeneous that traditional

solutions based on relational databases have become

unusable to process all these data volumes. Besides,

new data sources (bio-medical data, social networks,

sensor data, log files, etc.) that may be used for

decision making have emerged. In most cases, data

obtained from such sources are semi-structured or

unstructured, therefore special methods must be

applied to store, process and analyse them.

The increase of volume, variety and velocity of

data to be stored and processed induced the

emergence of new big data technologies that employ

distributed data storage techniques where special

methods are used to process data in parallel. The

demand to analyse data stored in such systems is

increasing and one of the analysis options is to use

data warehousing and OLAP methods. Traditional

methods applied in relational databases may not be

used anymore for big data analysis, therefore, new

modern technologies (Shvachko et al., 2010),

(Zaharia et al., 2010), tools (George, 2011), (Olston

et al., 2008) and frameworks (White, 2009) have

been proposed recently to support Big Data

analytics, including OLAP-like analysis (Thusoo et

al., 2010), (Apache Kylin Overview, n.d.). These

tools mainly support just the data warehouse

maintenance when volume of the underlying source

data is growing, but the problem of data expansion

when the structure of data evolves or new data items

are added to data records remains an unsolved yet

challenging task. Besides, to handle changes in user

requirements, a great developer effort must be

devoted to manually adapt the system to underlying

changes, inasmuch as the existing solutions do not

support automatic or semi-automatic handling of

evolution of a data warehouse over big data.

Since big data is a new technology, there are a

number of research directions and challenges that

have been outlined in several recent articles (Kaisler

et al., 2013), (Cuzzocrea et al., 2013), (Abaker et al.,

2015). The authors of the paper (Kaisler et al., 2013)

mention dynamic design challenges for big data

applications, which include data expansion that

occurs when data becomes more detailed. Another

review paper (Cuzzocrea et al., 2013) is more

specific and indicates research directions in the field

of data warehousing and OLAP. Among others, the

authors also mention the problem of designing

OLAP cubes according to user requirements.

Solodovnikova, D. and Niedrite, L.

Towards a Data Warehouse Architecture for Managing Big Data Evolution.

DOI: 10.5220/0006886100630070

In Proceedings of the 7th International Conference on Data Science, Technology and Applications (DATA 2018), pages 63-70

ISBN: 978-989-758-318-6

To address the evolution problem, we propose a

system architecture for warehousing and performing

various kinds of analysis, including OLAP analysis,

over structured and unstructured big data at different

granularity levels that are loaded into the system

with different velocity. The unique feature of our

proposed architecture is that it is capable of

automatically or semi-automatically adapting to

changes in requirements or data expansion.

The rest of the paper is organized as follows. In

Section 2 the related work is discussed. The main

contribution of this paper is presented in Section 3,

where the data warehouse architecture is described

and the process of handling evolution in the

proposed architecture is outlined. We conclude with

directions for future work in Section 4.

2 RELATED WORK

The problem of data warehouse evolution has been

studied extensively in relational database

environments. The approaches for handling

evolution at the extraction, transformation and

loading (ETL) level is proposed in the paper

(Wojciechowski, 2018). Schema evolution

approaches, e.g., (Bentayeb et al., 2008), update data

warehouse schemata to reflect changes that have

occurred. Another direction is schema versioning

and temporal data warehouses. According to these

approaches, not only schema of a data warehouse is

updated, but also the history of previous schemata is

kept, e.g., (Golfarelli et al., 2006), (Ahmed et al.,

2014), (Malinowski and Zimányi, 2008). These

works do not describe formally how the information

requirements affect the evolution changes. Some

research is done to get such methods (Thenmozhi

and Vivekanandan, 2014), (Thakur and Gosain,

2011).

All the above-mentioned approaches target data

warehouses implemented in relational database

environments, thus, they cannot be utilized directly

to perform adaptation of big data warehouses. Only

few big data solutions are considering the evolution

aspect of big data. The paper (Olston et al., 2011)

presents a workflow manager deployed at Yahoo.

The paper also explains the approach to data schema

specification and schema evolution processing. The

objective of the presented system is not data analysis

and it does not employ data warehouse.

A solution to handling data source evolution

problems in the integration field was presented in

the paper (Nadal et al., 2017). The authors propose

the use of big data integration ontology to define the

integrated schema, source schemata, their versions

and local-as-view mappings between them. When a

change at a data source occurs, the system steward

supplements the ontology with a new release and a

new wrapper that allows unchanged and new

attributes to be added to the changed source. Our

approach differs in that the proposed architecture is

OLAP-oriented and is capable of handling not only

changes in data sources, but also requirements.

There are several studies devoted to

multidimensional analysis of big data. The paper

(Song et al., 2015) presents an OLAP system for big

data implemented with Hadoop. The authors propose

a data model utilized in the system and algorithms

for execution of aggregate queries, roll-up and drill-

down operations and for data distribution among

multiple nodes of the system. The solution leverages

“share-nothing” architecture, which consists of a

Hadoop cluster where OLAP cubes are calculated by

an ETL tool, metadata server, job node for query

management, OLAP service facade and OLAP client

used for query specification and visualization of

query results.

A distributed OLAP system is presented in the

paper (Chen et al., 2017). The system architecture is

composed of 4 modules. Data acquisition module is

responsible for obtaining data from structured and

unstructured data sources. Data storage module

maintains source data in HDFS, key-value store and

relational database. OLAP analysis module performs

OLAP cube calculation and SQL-like query

execution. Data visualization module allows

definition of OLAP cubes to be calculated,

visualization of query results and specification of

user privileges.

The paper (Santos et al., 2017) studies the

problem of migration of a traditional data warehouse

to a data warehouse over big data. The authors

propose a big data warehousing architecture where

data from data sources are obtained by ETL tools

and initially accumulated in the HDFS staging area,

then data are transformed and loaded into the big

data warehouse implemented in Hive. Data analytics

and visualization is available in Tableau that uses

Impala for querying data warehouse data.

All the previously discussed studies on data

warehouses for big data analysis do not address the

problem of big data evolution. We found only a few

researches that consider that problem. One of them

is the paper (Tardio et al., 2015) that proposes a

methodology for a construction of a system for big

data analysis. One of the methodology steps is a

design of a multidimensional model, which involves

analysis of data sources, construction of separate

DATA 2018 - 7th International Conference on Data Science, Technology and Applications

models for each source and data integration into a

unified multidimensional model. The authors also

discuss a model enrichment process, which may take

place when a new data source is added to the system

or additional data are discovered by means of data

mining methods. To handle changes in big data, the

authors propose iterative execution of the model

design step until such a model is obtained that can

satisfy all information requirements. The proposed

approach is complimentary to ours, however, it

cannot be applied in case when some previously

available data become unavailable.

A data warehouse solution for big data analysis

that is implemented using MapReduce paradigm is

described in the paper (Chen, 2010). In this solution,

virtual views that join dimensions and fact tables of

a data warehouse are built and processed by SQL-

like queries. The presented system is used for

advertisement data analysis and the author mentions

that because of the system nature, schema changes in

it occur frequently. Therefore, the system supports

two kinds of changes: slowly changing dimensions

are managed with methods proposed by Ralph

Kimball (Kimball and Ross, 2013) and fact table

changes are handled by schema versions in

metadata. Unlike our proposal, the system does not

process changes in big data sources that may

significantly influence analysis process and results.

An architecture that exploits big data

technologies and is used for large-scale data

processing and OLAP analytics at LinkedIn is

presented in the paper (Sumbaly et al., 2013). The

architecture supports also source data evolution by

means of maintaining a schema registry and

enforcing the schema to remain the same or

compatible to the desired structure. OLAP

functionality is provided by the distributed system

Avatara described in the paper (Wu et al., 2012).

Avatara consists of two sub-systems: batch

processing engine for sharded small OLAP cube

calculation and incremental update implemented in

Apache Hadoop and online SQL-like query engine.

Such an architecture provides that user-defined

queries are executed with very low latency, but data

used for queries are updated less frequently. Authors

mention also the problem of cube evolution when a

new dimension is added to the cube. In contrast to

our proposed architecture, in Avatara evolution is

handled by means of manual redefinition of cube

schema and cube data re-calculation.

3 BIG DATA WAREHOUSE

ARCHITECTURE

To solve the topical issue of adaption of a data

warehouse over big data to changing user

requirements and expanding data sources, we

propose the use of a big data warehousing

architecture to analyse data stored and processed by

big data technologies. The architecture is an adapted

version of the data warehouse evolution framework

presented in (Solodovnikova, 2007). The data

warehouse evolution framework is capable of

automatically detecting and handling changes in data

sources or a traditional data warehouse as well as

adapt a data warehouse to changes in user

requirements (Solodovnikova et al., 2015) utilizing a

schema versioning approach.

The architecture proposed in this paper will be

able to provide big data analysis capabilities and

handle big data evolution. The big data warehouse

architecture is depicted in Figure 1.

3.1 Components of the Architecture

The architecture consists of several components:

source layer, data highway, metastore, cube engine,

metadata management tool and adaptation

component. The functionality of each component is

described in the following subsections.

3.1.1 Source Layer

In the source layer, data from various heterogeneous

data sources are obtained and loaded into the system

for further analysis. Because of the variety of big

data that may be required for the analysis, the

proposed architecture must process not only data

structured in rows and columns, but also semi-

structured data, for example, in XML or JSON

formats, and even unstructured data, for example,

log file records, user posts, photographs or video.

In the architecture, wrappers obtain data from

data sources and load them into the system.

Wrappers implement interfaces for data acquisition

supported by corresponding data sources (for

example, web services, API, etc.). Data are coming

into the system at different rates. For example, data

from RDBMS may be loaded in batches, but sensor

measurements or log file records are incoming as a

stream. All data are loaded in their original format

into the raw source data storage of the data highway

explained in the next subsection.

Towards a Data Warehouse Architecture for Managing Big Data Evolution

Figure 1: Big data warehouse architecture.

3.1.2 Data Highway

In the big data warehouse architecture, we adopt the

idea behind the architecture best practices for big

data proposed by (Kimball & Ross, 2013) to build a

highway of data at different levels of latency.

Starting from the raw source data, each next level

data are obtained from the previous level data and

are updated less often. Apart from different update

frequency, the latter level data from multiple

heterogeneous sources are integrated and

aggregated, so to support lower query latency. The

number of levels and their update frequency is

determined by requirements of a particular system.

Finally, source data are transformed into a

structured data warehouse schema (star or

snowflake). Since data in the raw source level and

intermediate levels of the highway are stored in the

original format and are only fairly integrated, we

propose to utilize a data lake repository (Terrizzano

et al., 2015) for storage and management of these

data.

Before being loaded into each next level of the

highway and finally a data warehouse, raw source

data need to be transformed. Since data in the

proposed architecture are firstly copied in their

original format and transformed at the later stage,

ELT (Extract, Load, Transform) rather than ETL

processes (Cohen et al., 2009) are responsible for

pre-processing data incoming from heterogeneous

data sources. Existing metadata-oriented ETL

methods based on mappings of source elements to

Source Layer

RDBMS Data

Source

Wrapper WrapperWrapper

Semi-

structured

Data Source

Unstructured

Data Source

...

Adaptation

Component

Metadata

Management

Tool

BI &

Visualization

Tools

Business Analyst

Developer

Cube Engine

Data Analyst

Analytics Tools

Level

Raw Source

Data

Pre-

computed

OLAP Cubes

Data Warehouse

Level

Near Real

Time Data

Level

Top Line

Data

ELT

ELTELT

Data

Highway

(data lake)

ELT

Data flow Metadata flow

Data Highway

Metadata

Source Change

Metadata

Adaptation Rules

Potential Change

Metadata

Mapping

Metadata

Cube Metadata

Metastore

DATA 2018 - 7th International Conference on Data Science, Technology and Applications

data warehouse elements may be utilized in case of

structured or semi-structured data sources loaded in

batch mode. In contrast, data incoming from

unstructured data sources need to be pre-processed

quite highly. For example, data mining or sentiment

analysis techniques may be applied on them to gain

structured information that is later to be loaded into

the data warehouse.

After being loaded into the data warehouse, the

data at each level of the highway are supplemented

by the generated surrogate keys of dimensions to

ensure data provenance and enable handling of

evolution. Since ELT processes augment data at the

lower level by information obtained during the

processing and transformations performed at the

higher level, it is possible to join data from different

levels of the data highway to perform a more

valuable analysis.

3.1.3 OLAP Cube Computation

The main objective of the architecture is to support

OLAP analysis of big data. Since the volume of data

stored in the data warehouse may be too large to

provide a reasonable performance of data analysis

queries, it is possible to pre-calculate certain OLAP

cubes and execute queries on pre-computed data

sets. To speed up queries, the cube engine

component of the architecture pre-computes various

dimensional combinations and aggregated measures

for them according to the developer specification

and saves computation results in the distributed

storage. Furthermore, the cube engine manages

execution of queries by routing the query to one of

these pre-computed cubes.

3.1.4 Metadata Management

The operation of the architecture is highly based on

the metadata in the metastore. The metadata

management tool is used by a developer to define

metadata in the metastore. The metastore

incorporates six types of interconnected metadata.

Data highway metadata store information about the

schemata of each level of the data highway as well

as of the data warehouse.

Cube metadata are used to specify the

dimensions, measures and other metadata of pre-

computed cubes. This information is used during the

pre-computation process as well as for execution of

queries.

Mapping metadata define the logics of ELT

processes. They store the correspondences between

data obtained from the sources and data items of the

data highway as well as necessary transformations

that must be made during the data loading process.

Information about changes in data sources is

accumulated in the source change metadata. Such

information may be obtained from wrappers or

during the execution of ELT processes.

Adaptation rules specify adaptation options that

must be implemented for different types of changes.

Finally, the metastore also includes the potential

change metadata, which accumulate proposed

changes in the data warehouse schema.

To maintain the information in the metastore, a

developer utilizes the metadata management tool. In

addition, the metadata management tool allows the

developer to initiate changes in the data highway

and ELT procedures to handle new or changed

requirements for data. The history of chosen changes

that are implemented to propagate evolution of data

sources, as well as changes performed directly via

the metadata management tool, are also maintained

in the potential change metadata.

3.1.5 Adaptation Component

The core element of the big data warehouse

architecture responsible for handling changes in data

sources and information requirements is the

adaptation component. The main idea of the

adaptation component is to generate several

potential changes in a data warehouse or other levels

of the data highway for each change in a data source

and to allow a developer to choose the most

appropriate change that must be implemented. To

achieve the desired functionality, the adaptation

component uses metadata from the metastore.

To implement certain kinds of changes,

additional data may be necessary that cannot be

identified automatically, for example,

transformations for missing properties of source data

records. In such a case, these data are supplied by

the developer via the adaptation component and are

saved in the adaptation rules in the metastore. The

process of handling changes in data sources by the

adaptation component is detailed in subsection 3.2.2.

3.1.6 Data Analysis

In our proposed architecture, we plan to support

different kinds of analysis. OLAP cubes may be

explored by business analysts in the form of

dashboards, charts or other reports and by

performing OLAP operations using business

intelligence and visualization tools. In addition,

experienced data analysts may apply advanced

analysis techniques (for example, data mining) to

Towards a Data Warehouse Architecture for Managing Big Data Evolution

gain insight into data or discover new information

useful for decision-making by means of utilizing

existing analytics tools or implementing ad-hoc

analysis procedures.

3.2 Handling Evolution

The proposed architecture is able to handle source

changes that can influence any level of the data

highway as well as changes in requirements for data

necessary for analysis.

3.2.1 Changes in Requirements

Because data lake repositories allow to flexibly store

heterogeneous data in their original format incoming

from various data sources, such repositories are very

suitable to provide new analysis opportunities that

may become required in the course of time. In the

big data warehouse architecture, we plan to support

such changes in requirements that imply addition of

new data to the system, as well as removal of no

longer required data. The examples of supported

changes include an addition of a new dimension

attribute or measure to the data warehouse schema,

addition of a new property to data records of an

intermediate level of the data highway or removal of

such attributes, measures or properties.

All changes in requirements must be handled by

the metadata management tool. A developer must

make changes in the data highway metadata so to

specify new data items that are necessary for

analysis or to remove no longer required data items

from the metadata. The history of changes made to

the schemata of each updated level of the data

highway is also preserved. Furthermore, the

developer must make changes to the ELT procedures

affected by the changes in requirements. The

information about correspondences between data

items of the sources and new or modified data items

of each level of the data highway must be also

updated in the mapping metadata to continue

supporting handling of possible changes in data

sources. Finally, changes in the schema of the data

warehouse must be also propagated in the cube

metadata so that cube engine could re-create OLAP

cubes according to the changed requirements.

3.2.2 Changes in Data Sources

Data are incoming in the system from multiple

heterogeneous data sources that can change

independently. Many of such changes can invalidate

existing ELT processes as well as data required for

the analysis. Thus, it is necessary to handle changes

in data sources automatically or semi-automatically.

To implement the adaptation of ELT processes

and possible schemata of the data highway levels

affected by the change, source wrappers must be

capable of tracking changes in views of source data

provided by interfaces. This functionality may be

unavailable, especially in case of unstructured data

sources. Therefore, certain changes in data sources

can be discovered only during the execution of ELT

processes by means of verification of source data

correspondence to the desired format and constraints

and discovering any inconsistencies caused by

changes in the data structure. All changes discovered

by wrappers or ELT processes must be registered in

the source change metadata. The list of supported

changes in data sources is highly dependent on the

ability of the corresponding wrappers or ELT

processes to track changes.

The processing of source changes is performed

by the adaptation component. Initially it analyses the

changes in the source change metadata and detects

changes that affect the schemata of the data highway

and ELT processes. The adaptation component

handles these changes using data from the adaptation

rules available in the metastore and provided by the

developer and for each change generates potential

solutions that adapt the schemata of the data

highway and ELT processes. The adaptation may

affect one or several levels of the data highway,

including a data warehouse.

The developer is informed about all discovered

changes and their potential adaptation options, so

then he/she may approve the most suitable solutions

that are later implemented by the adaptation

component. Such approach involves developer effort

only occasionally when changes occur and does not

require a developer to manually adapt ELT

procedures and schemata, however it also minimizes

the possibility of errors since no adaptation options

are implemented automatically and they all need to

be approved by a developer.

If schemata of the data warehouse are also

adapted after implementing the chosen solutions, the

adaptation component must also update cube

metadata to reflect changes in the data warehouse

and launch the cube engine to re-compute cubes

after re-definition.

3.3 Potential Implementation

For the implementation of the big data warehouse

architecture, we intend to utilize the existing tools

and technologies as well as to implement the

DATA 2018 - 7th International Conference on Data Science, Technology and Applications

original solutions. We plan to use HDFS for storage

of raw source data and intermediate levels of the

data highway and Apache Hive for a data

warehouse. Apache Kylin will be suitable to

implement the functionality of the cube engine since

it is capable of producing cubes from Hive data

structures. Cubes pre-computed by Kylin need to be

stored in Apache HBase database. We plan to

employ a RDBMS for the metastore and possibly

Pentaho software to implement ELT processes.

Finally, since no existing products support big data

evolution to the full extent, we will implement the

original solutions for the metadata management tool

and the adaptation component.

4 CONCLUSIONS

The main contribution of this paper is a data

warehouse architecture that on one hand allows to

perform different kinds of analytical tasks, including

OLAP-like analysis, on big data loaded from

multiple heterogeneous data sources with different

latency. On the other hand, our proposed

architecture is capable of processing changes in data

sources as well as evolving analysis requirements.

We described the components of the architecture,

the necessary metadata and gave examples of

changes that are supported by the architecture

together with their implementations within the

architecture.

Our future research directions include a

construction of metadata models to describe

schemata of the data highway, requirements for data,

source data and changes. The main challenge here

would be to determine metadata of non-structured or

semi-structured big data and the possible solution is

to leverage meta-learning.

To enable handling of big data evolution,

algorithms for automatic and semi-automatic change

detection and treatment are necessary. Since change

detection may be impossible at the data source layer,

the possible solution would be to specify constraints

on data items incoming from data sources and detect

violation of such constraints to discover evolution.

ACKNOWLEDGEMENTS

This work has been partly supported by the

European Regional Development Fund (ERDF)

project No. 1.1.1.2./VIAA/1/16/057 “Handling

Adaptation of Big Data Warehouse” and by

University of Latvia project No. AAP2016/B032

“Innovative information technologies".

REFERENCES

Abaker, I., Hashem, T., Yaqoob, I., Anuar, N.B., Mokhtar,

S., Gani, A., Khan, S.U., 2015. The rise of “big data”

on cloud computing: Review and open research issues.

In Information Systems, 47(C), pp. 98-115.

Ahmed, W., Zimányi, E., Wrembel, R., 2014. A Logical

Model for Multiversion Data Warehouses. In 16th

International Conference on Data Warehousing and

Knowledge Discovery, pp. 23-34.

Apache Kylin Overview [Online]. Available at:

http://kylin.apache.org (Accessed: 27 April 2018).

Bentayeb, F., Favre, C., Boussaid, O., 2008. A User-

driven Data Warehouse Evolution Approach for

Concurrent Personalized Analysis Needs. In

Integrated Computer-Aided Engineering, 15(1), pp.

21-36.

Chen, S., 2010. Cheetah: A High Performance, Custom

Data Warehouse on Top of MapReduce. In VLDB

Endowment, 3(2), pp. 1459-1468.

Chen, W., Wang, H., Zhang, X., 2017. An optimized

distributed OLAP system for big data. In 2nd IEEE

International Conference on Computational

Intelligence and Applications, pp. 36-40.

Cohen, J., Dolan, B., Dunlap, M., Hellerstein, J.M.,

Welton, C., 2009. MAD Skills: New Analysis

Practices for Big Data. In VLDB Endowment, pp.

1481-1492.

Cuzzocrea, A., Bellatreche, L., Song, I., 2013. Data

Warehousing and OLAP over Big Data: Current

Challenges and Future Research Directions. In 16th

international workshop on Data warehousing and

OLAP, pp. 67-70.

George, L., 2011. HBase: the definitive guide. O’Reilly

Media Inc.

Golfarelli, M., Lechtenbörger, J., Rizzi, S., Vossen, G.,

2006. Schema versioning in data warehouses:

Enabling cross-version querying via schema

augmentation. In Data & Knowledge Engineering,

59(2), pp. 435-459

Kaisler, S., Armour, F., Espinosa, J.A., Money, W., 2013.

Big Data: Issues and Challenges Moving Forward. In

46th Hawaii International Conference on System

Sciences, pp. 995-1004.

Kimball, R., Ross, M., 2013. The Data Warehouse

Toolkit: The Definitive Guide to Dimensional

Modeling. John Wiley & Sons, Inc., 3rd edition.

Malinowski, E., Zimányi, E., 2008. A Conceptual Model

for Temporal Data Warehouses and Its Transformation

to the ER and the Object-Relational Models. In Data

& Knowledge Engineering, 64(1), pp. 101-133.

Nadal, S., Romero, O., Abelló, A., Vassiliadis, P.,

Vansummeren, S., 2017. An integration-oriented

ontology to govern evolution in big data ecosystems.

Towards a Data Warehouse Architecture for Managing Big Data Evolution

In Workshops of the EDBT/ICDT 2017 Joint

Conference.

Olston, C., Reed, B., Srivastava, U., Kumar, R., Tomkins,

A., 2008. Pig Latin: A Not-So-Foreign Language for

Data Processing. In 2008 ACM SIGMOD international

conf. on Management of data, pp. 1099-1110.

Olston, C., Chiou, G., Chitnis, L., Liu, F., Han, Y.,

Larsson, M., Wang, X., 2011. Nova: continuous

Pig/Hadoop workflows. In ACM SIGMOD

International Conference on Management of data, pp.

1081-1090.

Santos, M.Y., Martinho, B., Costa, C., 2017. Modelling

and implementing big data warehouses for decision

support. In Journal of Management Analytics, 4(2),

pp. 111-129.

Shvachko, K., Kuang, H., Radia, S., Chansler, R., 2010.

The Hadoop distributed file system. In MSST’2010,

IEEE 26th Symposium on Mass Storage Systems and

Technologies. pp. 1–10.

Solodovnikova, D., 2007. Data Warehouse Evolution

Framework. In Spring Young Researchers Colloquium

on Database and Information Systems SYRCoDIS,

pp. 4.

Solodovnikova, D., Niedrite, L., Kozmina, N., 2015.

Handling evolving data warehouse requirements. In

19th East-European Conference on Advances in

Databases and Information Systems, pp. 334-345.

Song, J., Guo, C., Wang, Z., Zhang, Y., Yu, G., Pierson,

J., 2015. HaoLap: A Hadoop based OLAP system for

big data. In Journal of Systems and Software, 102, pp.

167-181.

Sumbaly, R., Kreps, J., Shah, S., 2013. The “Big Data”

Ecosystem at LinkedIn. In ACM SIGMOD

International Conference on Management of Data, pp.

1125-1134.

Tardio, R., Mate, A., Trujillo, J., 2015. An Iterative

Methodology for Big Data Management, Analysis and

Visualization. In BIG DATA'15 Proceedings of the

2015 IEEE International Conference on Big Data, pp.

545-550.

Terrizzano, I., Schwarz, P., Roth, M., Colino, J.E., 2015.

Data wrangling: The challenging journey from the

wild to the lake. In Conference on Innovative Data

Systems Research.

Thakur, G., Gosain, A., 2011. DWEVOLVE: a

Requirement Based Framework for Data Warehouse

Evolution. In ACM SIGSOFT Software Engineering

Notes, 36(6), pp. 1-8.

Thenmozhi, M., Vivekanandan, K., 2014. An Ontological

Approach to Handle Multidimensional Schema

Evolution for Data Warehouse. In International

Journal of Database Management Systems, 6(3), pp.

33-52.

Thusoo, A., Sarma, J.S.., Jain, N., Shao, Z., Chakka, P.,

Zhang, N., Antony, S., Liu, H., Murthy, R., 2010.

Hive - a petabyte scale data warehouse using Hadoop.

In International Conference on Data Engineering, pp.

996–1005.

White, T., 2009. Hadoop: The Definitive Guide, first ed.,

O’Reilly Media, Inc.

Wojciechowski, A., 2018. ETL workflow reparation by

means of case-based reasoning. In Information

Systems Frontiers, 20(1), pp.21-43.

Wu, L., Sumbaly, R., Riccomini, C., Koo, G., Kim, H.J.,

Kreps, J., Shah, S., 2012. Avatara: OLAP for Web-

scale Analytics Products. In VLDB Endowment, 5(12),

pp. 1874-1877.

Zaharia, M., Chowdhury, M., Franklin, M.J.,

Shenker, S., Stoica, I., 2010. Spark: Cluster

Computing with Working Sets. In HotCloud'10, 2nd

USENIX

DATA 2018 - 7th International Conference on Data Science, Technology and Applications
