An Uniﬁed Representation of Source Code Authoring Workﬂows

Dmitrii Timofeev

and Alexander Samochadin

1,2

Mobile Device Management Laboratory, Peter the Great St. Petersburg Polytechnic University,

Polytechnicheskaya 29, St. Petersburg, Russia

Higher School of Software Engineering, Peter the Great St. Petersburg Polytechnic University,

Polytechnicheskaya 21, St. Petersburg, Russia

Keywords:

Process Modeling, Source Code Analysis, Software Development Process, Source Code Authoring.

Abstract:

Existing approaches to modeling software development processes mostly deal with high-level processes at the

level of project management. There are speciﬁc tasks that involve the analysis of processes at the level of

writing and modifying the program code, but they lack a common reusable modeling framework. We suggest

that a model of source code editing workﬂow would be beneﬁcial for many tasks, from defect prediction to

teaching programming to novices. We propose a uniﬁed approach that combines several levels of annotations,

from keyboard events to task tracker issues and project planning.

1 INTRODUCTION

Software development comprises multiple workﬂows

that result in a set of artifacts, with the main being

the source code. Its principal use is the compilation,

optimization, and execution of the program. At the

same time, the source code serves an input for other

tasks, including authorship detection and defect pre-

diction. Reading source code, and writing it to be read

by others, also plays a signiﬁcant role in teaching pro-

gramming.

The defect prediction task is usually deﬁned as a

supervised learning problem where the goal is to as-

sociate source code fragments with the probability or

an error-proneness class of a defect. There are two

kinds of features for the learning problem: code me-

trics like method size or complexity of a control ﬂow

graph, and process metrics, that measure the proper-

ties of the development process. Examples of process

metrics are the frequency of changes and the num-

ber of developers working on the same piece of code.

As Rahman and Devanbu (2013) have shown, process

metrics are signiﬁcantly more informative than code

metrics for the defect prediction task. The standard

practice to collect process metrics is to parse the com-

mit history in the project version control system, and

to associate commits with defect reports in the bug

tracker. Unfortunately, the commit history provides

only the data about the state of the code at the speciﬁc

checkpoints and hides the way the programmer writes

the code. At the same time, the code editing workﬂow

itself often contains clues about possible bugs. For

example, a well-known source of defects is the copy-

paste programming that increases the probability of

bug duplication and context-related errors (Kim et al.,

2004). As Hou et al. (2009) note, static analysis algo-

rithms cannot provide the same copy-paste clone de-

tection quality as the dynamic process analysis met-

hods. Integration of these low-level process metrics

would improve the quality of defect prediction sys-

tems.

Another application of process analysis is tea-

ching the novice programmers. Learning the right

workﬂows of writing and maintaining the source

code is a necessary part of programmers education.

While checking the coding standards conformance

and paying attention to compiler warnings helps to

get rid of several bad habits the students tend to de-

velop, the more subtle code editing patterns, like the

excessive copy-pasting mentioned before, are much

harder to detect without surveying how the student

works on the task. The typical workﬂow employed

by a programmer also classiﬁes developers by expe-

rience level and preferred style. Several styles may

be more or less desirable in a production environment

than others. For example, developers may tend to in-

vent new solutions, to adopt standard solutions from

their knowledge base, or to search and reuse solutions

from sites like StackOverﬂow

Logging and analysis of actions performed by a

https://stackoverﬂow.com/

228

Timofeev, D. and Samochadin, A.

An Uniﬁed Representation of Source Code Authoring Workﬂows.

DOI: 10.5220/0007229902280232

In Proceedings of the 10th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2018) - Volume 3: KMIS, pages 228-232

ISBN: 978-989-758-330-8

developer in an integrated development environment

(IDE) is a widely used technique. At the same time,

each tool implements this method independently and

tune it to a speciﬁc task. In this position paper, we dis-

cuss an approach to a code editing process model and

a set of action capturing tools that could be reused for

solving particular problems like defect prediction, de-

veloper performance analysis, or teaching good pro-

gramming practices. Our approach is to represent dif-

ferent aspects of the software development process as

a hierarchical set of annotated events in a single time

scale.

2 RELATED WORK

The document authoring workﬂows have been stu-

died in multiple research areas, from psychology and

human-computer interaction (HCI)to software engi-

neering. A particular process that is widely represen-

ted in psychology and HCI papers is writing or modi-

fying documents using text editing software. In these

cases, researchers are most interested in the ways

users interact with a computer system, their mental

models, and the factors that inﬂuence the interaction,

like user interface complexity (Card et al., 1980), user

experience (Rosson, 1983), or interruptions (Burmis-

trov and Leonova, 2003). The experimental data is

usually collected using video recording or by logging

keys and user commands. The process is described

with one or more quantitative characteristics, e.g., the

number of operations per a time unit.

The most common workﬂow model used in these

studies is the chronologically ordered sequence of

actions. Burmistrov and Leonova (2003) replaced

atomic operations with the events start and stop marks

so that their model could describe nested and postpo-

ned activities. Polson and Kieras (1985) proposed a

generative model where a set of production rules des-

cribes the user behavior. When the editing context

matches a rule, this rule ﬁres and the model generates

a sequence of higher-level editing commands.

In software engineering, human behavior models

are widely used for task automation and functional

testing. Tools like Expect

and Selenium

allow de-

velopers to describe the interaction process as a pro-

gram in a domain-speciﬁc or a general purpose pro-

gramming language. When these programs are run,

they interact with the system by analyzing its output

and providing necessary input.

At the same time, the workﬂows that software de-

velopers themselves are using have been studied to a

https://core.tcl.tk/expect/index

https://www.seleniumhq.org/

much lesser extent. Although there is a lot of rese-

arch on project management, individual processes of

writing the code aren’t in focus. Well-known books

on best programming practices (Hunt and Thomas,

1999; McConnell, 2004; Martin, 2008) deal mos-

tly with software architecture and coding techniques.

The process of programming is to some extent discus-

sed by Carter and Sangler (1997). The book concerns

with the mental models and strategies (“mapping” and

“packing”) that programmers use while working on

the code.

The main problem of experimental studies of pro-

gram authoring processes is their cognitive nature that

makes difﬁcult to trace workﬂow states and transiti-

ons as they are hidden from the observer. One way to

overcome this difﬁculty is to ask programmers to ex-

plicitly describe the actions they perform, including

purely mental tasks (Jeffries et al., 1981; Bennedsen

and Caspersen, 2005). The possible states and transi-

tions may be modeled as Markov processes (Kamma,

2014).

At the higher level, the workﬂow states may be

linked to the tasks the developer solves. These tasks

and their connections to the project issues (bugs or

features) are usually tracked using a version control

system. Each task results in a commit annotated with

a description of the changes and with optional refe-

rences to the issue tracker. Additionally, the source

control repository provides data on the timeline and

history of modiﬁcations and on developers involved.

Commit logs seems to be the main source of informa-

tion on programming workﬂows at the time present

(Hassan and Holt, 2003; Hassan, 2009; D’Ambros

et al., 2010; Rahman and Devanbu, 2013; Rubin et al.,

2014).

The main artifact of the software developer’s work

is the source code. Modern IDEs provide rich code

processing features including incremental parsing,

type checking, and control ﬂow graph analysis. Alt-

hough these features are often available for plugins,

there is just a limited number of process logging tools

that make use of the source code, mostly for defect

prediction. Although the set of employed features

is usually limited, like the code fragments that have

been copied and pasted (Kim et al., 2004; Hou et al.,

2009), other structured features (adding and removal

of code, modiﬁcation of types or function arguments)

may be worth logging as well (Lehnert, 2011).

As this review shows, the task of modeling work-

ﬂows used by software developers, and other specia-

lists whose operations are hard to observe due to their

mental nature, is far from being solved. Although

analysis tools exist for capturing speciﬁc process fe-

atures (e.g., tracking code copying or extracting in-

An Uniﬁed Representation of Source Code Authoring Workﬂows

229

formation from commit logs), events captured at dif-

ferent levels (key presses, program structure changes,

code base modiﬁcation, project status updates) are not

linked together or used in combination.

3 MODELING THE CODE

AUTHORING PROCESS

We propose to address the problem of modeling pro-

gramming workﬂows by introducing a uniﬁed repre-

sentation of programming activities.

There are three main aspects of the code authoring

process.

• Activity: how the programmer writes the code.

• Contents: how is the code modiﬁed.

• Context: what is the purpose of these changes for

the software project.

The process is recorded by tracking user actions.

Different tasks require event logs to be recorded with

a speciﬁc resolution. For example, in a defect pre-

diction task, it might be interesting to search for met-

hods or functions that were modiﬁed but not tested

after the change. The event log should contain data

about actions of types “modify the code,” and “run

unit tests”. At the same time, to evaluate IDE ergo-

nomics, we may need to count the number of mouse

clicks required to complete a speciﬁc task.

To enable simultaneous representation of the

events at several levels, we adopt the approach widely

used in text and multimedia processing. We record

the stream of directly observed actions and label event

spans (continuous ﬁnite sequences of events) with an-

notations corresponding to higher-level events. For

example, the action “run the application in debug

mode” might match a span containing the speciﬁc se-

quence of mouse clicks and key presses. An annota-

tion may be attached not only to low-level events but

any other event span.

At the lowest level, we record atomic actions like

key presses, mouse clicks, menu item activation, or

window switching. We suggest using at least the fol-

lowing set of annotations (note that speciﬁc events

here are examples, and the set of events at each level

is not complete).

• Atomic operations: selecting an item in the cur-

rent window, copying an item into the clipboard,

pasting an item, running a program, starting a test

suite and so on.

• Operations on text: selection, copying, pasting,

inserting, removing and replacing the fragments

of text. The logging of text operations is like the

“track changes” feature of modern document edi-

tors like Microsoft Word.

• Operations on programs: modiﬁcation of the pro-

gram (module) syntax tree. Depending on the

programming language, the set of operations may

contain adding, removing, renaming of packages,

classes, methods, functions and types, modiﬁca-

tion of their bodies and argument lists, adding

or removing control structures (loops, conditions,

sequences of operators).

• Operations on programs in an intermediate lan-

guage: the same operations as in the previous

list, but mapped not to the speciﬁc programming

language but to an intermediate language to ena-

ble the creation of language-independent analysis

tools. There may be several intermediate langua-

ges for different families of programming langua-

ges (procedural, functional, object-oriented, etc.)

• Process state: design, coding, debugging, testing.

• Project activity: implementing new features, ﬁx-

ing bugs, merging revisions, doing code reviews,

committing to the source control repository.

• Project management activity: opening, modifying

and closing tasks in a tracker, meeting, planning.

An example of this hierarchy is represented in the

ﬁgure 1.

Note that annotations like “planning” or “meet-

ing” may be added to the log even they don’t have

any corresponding low-level event (e.g., a developer

is participating in a meeting and not using the compu-

ter until the meeting is over). To allow this behavior,

we allow spans to be empty. An empty span is deﬁned

by its start and stop time labels.

There is another possible view of the same model.

We may regard annotations as protensive events deﬁ-

ned by speciﬁc content and a time span on the com-

mon time scale. Annotations may have explicit links

to the inner events and vice versa, but they are not

required. Events not linked to lower-level events cor-

respond to annotations deﬁned on empty spans.

To make the process representation less language-

dependent, we suggest using a family of metalan-

guages. For most object-oriented programming lan-

guages we suggest representing the program structure

in terms of FAMIX 3.0 metamodel (Ducasse et al.,

2011). In this case, the program or component mo-

del is a tree whose nodes represent structural ele-

ments like packages, classes, interfaces, and methods.

As the FAMIX metamodel does not include procedu-

ral facilities like operator and control structures, we

may need to extend the common representation with

the necessary features. In a similar way, higher-level

KMIS 2018 - 10th International Conference on Knowledge Management and Information Sharing

230

time

atomic actions

insert text replace text

text actions

add class change method

code actions

process states

coding

add method

debug coding

project activity

new functionality

coding

fixing bugs

PM activity

working on issue #

commit

Figure 1: Combined log example.

events, e.g., project phases, may be mapped to OMG

SPEM 2.0 metamodel (OMG, 2008).

For now, an early prototype has been developed

that can log events generated by a user working in

Microsoft Visual Studio IDE as well as lower-level

events like key presses, mouse movements and clicks,

and window switching. All these events are stored in

a database using a common time scale. The current

representation does not use explicit links to the inner

events.

The problem of restoring these links is interes-

ting by itself. Usually we have several sources of in-

formation about the event, for example, we may log

the “open ﬁle” action either from a speciﬁc event pu-

blished by Visual Studio or by parsing the sequence

of pressed and released keys or mouse buttons. The

main difference between these two approaches, besi-

des the complexity of parsing the sequence of low-

level keyboard and mouse events, is that parsing key

presses restores links between higher-level and lower-

level events while the independent event logging mis-

ses that information.

If the direct information about event linking, and

about an event at a whole (e.g., on the process state

level), is missing, there are three ways to infer it.

• Parse lower-level events to obtain links.

• Ask the user to annotate events.

• Restore links using machine learning techniques.

In this case, the task may be stated as an event

classiﬁcation problem.

The latter case worth researching by itself, as the

classiﬁcation algorithm may be used to solve end-user

tasks such as tracking user time, detecting the process

state, or evaluating the user attention level and efﬁ-

ciency.

4 CONCLUSION AND FUTURE

WORK

In this paper we propose an approach to modeling

software development processes by tracking and an-

notating activities at several levels, from operations

performed by an individual developer to the states

of the entire projects. These events are linked toget-

her and also mapped to artifacts such as the software

source code and commit messages. The model is de-

signed to be used as input for higher-level analysis

algorithms. We expect that the hierarchical log of

developers’ actions and their timings will be beneﬁ-

cial for understanding software development proces-

ses, giving feedback to programmers and managers,

and getting better results in program analysis tasks

like defect prediction.

The concept described in this position paper is on

the early stage of development. The primary research

and implementation directions are the following.

1. Deﬁne an external representation of the process

log.

2. Advance the current prototype by logging more

high-level annotations, especially the annotations

on program code level.

3. Deﬁne the set of statistical metrics to compare

models, such as patch source frequency distribu-

tion or change localization.

4. Design and implement the model clustering al-

gorithm to detect similar coding workﬂows and

compare results to the externally estimated pro-

grammers’ efﬁciency.

An Uniﬁed Representation of Source Code Authoring Workﬂows

231

ACKNOWLEDGEMENTS

This research is a part of the joint project by Intelin

LLC (Moscow, Russia) and Peter the Great St. Peters-

burg Polytechnic University (St. Petersburg, Russia).

This work is ﬁnancially supported by the Ministry

of Education and Science of the Russian Federation

(state contract 03.G25.31.0247 from 28.04.2017).

REFERENCES

Bennedsen, J. and Caspersen, M. E. (2005). Revealing the

programming process. In ACM SIGCSE Bulletin, vo-

lume 37, pages 186–190. ACM.

Burmistrov, I. and Leonova, A. (2003). Do interrupted users

work faster or slower? the microanalysis of compute-

rized text editing task. Human-Computer Interaction:

Theory and Practice (Part I)–Proceedings of HCI In-

ternational, 1:621–625.

Card, S. K., Moran, T. P., and Newell, A. (1980). The

keystroke-level model for user performance time with

interactive systems. Communications of the ACM,

23(7):396–410.

Carter, A. and Sangler, C. (1997). The Programmers

Stone. Available at https://www.datapacrat.com/

Opinion/Reciprocality/r0/index.html.

D’Ambros, M., Lanza, M., and Robbes, R. (2010). An ex-

tensive comparison of bug prediction approaches. In

Mining Software Repositories (MSR), 2010 7th IEEE

Working Conference on, pages 31–41. IEEE.

Ducasse, S., Anquetil, N., Bhatti, M. U., Hora, A. C., La-

val, J., and Girba, T. (2011). Mse and famix 3.0: an

interexchange format and source code model family.

Hassan, A. E. (2009). Predicting faults using the complex-

ity of code changes. In Proceedings of the 31st Inter-

national Conference on Software Engineering, pages

78–88. IEEE Computer Society.

Hassan, A. E. and Holt, R. C. (2003). The chaos of software

development. In null, page 84. IEEE.

Hou, D., Jablonski, P., and Jacob, F. (2009). Cnp: To-

wards an environment for the proactive management

of copy-and-paste programming. In Program Com-

prehension, 2009. ICPC’09. IEEE 17th International

Conference on, pages 238–242. IEEE.

Hunt, A. and Thomas, D. (1999). The Pragmatic Program-

mer: From Journeyman to Master. Addison-Wesley

Longman Publishing Co., Inc., Boston, MA, USA.

Jeffries, R., Turner, A. A., Polson, P. G., and Atwood, M. E.

(1981). The processes involved in designing software.

Cognitive skills and their acquisition, 255:283.

Kamma, D. (2014). Study of task processes for improving

programmer productivity. In Companion Proceedings

of the 36th International Conference on Software En-

gineering, pages 702–705. ACM.

Kim, M., Bergman, L., Lau, T., and Notkin, D. (2004). An

ethnographic study of copy and paste programming

practices in oopl. In null, pages 83–92. IEEE.

Lehnert, S. (2011). A taxonomy for software change im-

pact analysis. In Proceedings of the 12th International

Workshop on Principles of Software Evolution and the

7th annual ERCIM Workshop on Software Evolution,

pages 41–50. ACM.

Martin, R. C. (2008). Clean Code: A Handbook of Agile

Software Craftsmanship. Prentice Hall PTR, Upper

Saddle River, NJ, USA, 1 edition.

McConnell, S. (2004). Code Complete, Second Edition. Mi-

crosoft Press, Redmond, WA, USA.

OMG (2008). Software & systems process engineering me-

tamodel speciﬁcation (v2.0).

Polson, P. G. and Kieras, D. E. (1985). A quantitative model

of the learning and performance of text editing know-

ledge. ACM SIGCHI Bulletin, 16(4):207–212.

Rahman, F. and Devanbu, P. (2013). How, and why, process

metrics are better. In Software Engineering (ICSE),

2013 35th International Conference on, pages 432–

441. IEEE.

Rosson, M. B. (1983). Patterns of experience in text editing.

In Proceedings of the SIGCHI conference on Human

Factors in Computing Systems, pages 171–175. ACM.

Rubin, V., Lomazova, I., and van der Aalst, W. M. (2014).

Agile development with software process mining. In

Proceedings of the 2014 international conference on

software and system process, pages 70–74. ACM.

KMIS 2018 - 10th International Conference on Knowledge Management and Information Sharing

232
