Solving the Social Golfers Problems by Constraint Programming in

Sequential and Parallel

Ke Liu

, Sven L

ofﬂer and Petra Hofstedt

Brandenburg University of Technology Cottbus-Senftenberg, Germany

Department of Mathematics and Computer Science, MINT,

Konrad-Wachsmann-Allee 5, 03044 Cottbus, Germany

Keywords:

Constraint Programming, Constraint Satisfaction, Parallel Constraint Solving, Sports Scheduling, Social

Golfer Problem.

Abstract:

The social golfer problem (SGP) has received plenty of attention in constraint satisfaction problem (CSP)

research as a standard benchmark for symmetry breaking. However, the constraint satisfaction approach has

stagnated for solving larger SGP instances over the last decade. We improve the existing model of the SGP

by introducing more constraints that effectively reduce the search space, particularly for instances of special

form. Furthermore, we present a search space splitting method to solve the SGP in parallel through data-level

parallelism. Our implementation of the presented techniques allows us to attain solutions for eight instances

with maximized weeks, in which six of them were open instances for the constraint satisfaction approach, and

two of them are computed for the ﬁrst time. Besides, super-linear speedups are observed for all the instances

solved in parallel.

1 INTRODUCTION

The social golfer problem (SGP), i.e., 010 problem

in CSPLib (Harvey, 2002), is a typical combinatorial

optimization problem that has attracted signiﬁcant at-

tention from the constraint programming community

due to its highly symmetrical and combinatorial na-

ture. The computational complexity of the SGP is

yet unknown. However, determining whether a par-

tial assignment can be extended to a solution is NP-

complete (Colbourn, 1984). The problem consists of

scheduling n=g ∗ s golfers into g groups of s golfers

for w weeks so that any two golfers are assigned to

the same group at most once in w weeks. By the con-

vention, an instance of the SGP is denoted by a triple

g-s-w, where g is the number of groups, s is the num-

ber of golfers within a group, and w is the number of

weeks in the schedule.

The SGP can be viewed as an optimization pro-

blem which seeks a schedule (solution) for a given

g and s with the maximum number w

∗

weeks (w

∗

≤

n−1

s−1

). Obviously, a solution for an instance g-s-w

∗

im-

plies the solutions for all instances g-s-w with w < w

∗

In light of this, this paper considers only solving the g-

s-w

∗

instances with maximized weeks, which we call

https://orcid.org/0000-0002-5256-9253

the full instance. For example, Table 1 depicts one

solution for the full instance 7-3-10 social golfer pro-

blem.

The SGP is a simple-sounding question, and it

can be modeled by several common constraints de-

rived from the problem deﬁnition. The constraint sa-

tisfaction approach, however, still has enormous dif-

ﬁculties in obtaining the solution even for some small

instances (e.g. 8-4-10, 9-3-13), which are mainly cau-

sed by the following two reasons (difﬁculties):

• The inherent highly symmetrical nature of the

SGP cannot be entirely known before solving pro-

cess. Despite the symmetries, which are caused

by interchangeable players inside groups (s!), in-

terchangeable groups inside weeks (g!), and ar-

bitrarily ordered weeks (w!), can be removed

through model reformulation and static symme-

try breaking constraints, it is difﬁcult to eliminate

all symmetries among golfers caused by renum-

bering n golfers (n!).

Consequently, the unneces-

sary symmetrical search space is explored redun-

dantly (Barnier and Brisset, 2002).

For example, if golfers [16, 17,18,19,20, 21] in Table 1

replace with [19, 20,21, 16,17, 18] in turn, an isomorphism of

the solution depicted in Table 1 will be generated even if the

ﬁrst row of the solution is ﬁxed with [1,2,3, ...,19, 20,21].

Liu, K., Löfﬂer, S. and Hofstedt, P.

Solving the Social Golfers Problems by Constraint Programming in Sequential and Parallel.

DOI: 10.5220/0007252300290039

In Proceedings of the 11th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2019), pages 29-39

ISBN: 978-989-758-350-6

Table 1: A solution for 7-3-10 (transformed from the solution depicted in Table 2.). The text in bold indicates that the values

have been initialized before the search.

Week

Group

1 2 3 4 5 6 7

1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21

2 1 4 7 2 10 13 3 16 19 5 8 17 6 11 14 9 12 20 15 18 21

3 1 10 14 2 4 17 3 9 11 5 7 21 6 12 16 8 15 19 13 18 20

4 1 17 21 2 6 19 3 4 12 5 10 20 7 15 16 8 11 13 9 14 18

5 1 8 12 2 5 16 3 7 13 4 14 21 6 9 15 11 17 20 10 18 19

6 1 9 16 2 11 15 3 10 21 4 8 20 5 14 19 6 13 17 7 12 18

7 1 13 19 2 9 21 3 6 20 4 11 18 5 12 15 8 10 16 7 14 17

8 1 5 11 2 8 18 3 15 17 4 9 19 6 7 10 14 16 20 12 13 21

9 1 6 18 2 7 20 3 8 14 4 10 15 5 9 13 11 16 21 12 17 19

10 1 15 20 2 12 14 3 5 18 4 13 16 6 8 21 9 10 17 7 11 19

• A large proportion of partial assignments that can-

not lead to a solution is likely to cause the back-

track search to trap in a sizeable fruitless subspace

and therefore waste valuable computation time.

More importantly, it is often hard to determine the

usefulness of a partial assignment until almost all

variables are instantiated.

The research on the SGP is meaningful not only

in itself but also for other constraint satisfaction pro-

blems (CSPs), such as balanced incomplete block de-

sign (BIBD) (Prestwich, 2001) and steel mill slab de-

sign (Miguel, 2012), etc. The reason is that we are

likely to face the same difﬁculties as the SGP when

solving other CSPs through the constraint satisfaction

approach.

In this paper, we ﬁrst classify the researches on the

SGP by how they resolve the two difﬁculties mentio-

ned above and also survey the studies related to the

SGP outside the context of constraint programming

(Section 2). Next, Section 3 present a modeling ap-

proach improved on the model proposed by Barnier

and Brisset (2002). Then, some instance-speciﬁc con-

straints are introduced in Section 4. After that, we ela-

borate on how to employ Embarrassingly Parallel Se-

arch (EPS) (R

egin et al., 2013) to solve the SGP in

Section 5. Finally, we conclude in Section 6. The

contributions of this paper are twofold. First, the per-

formance of the CP approach on the SGP is impro-

ved by the introduction of additional problem-speciﬁc

constraints. Second, it shows that the two-stage mo-

dels with static partitioning are well-suited for solving

the SGP in parallel since the instances which are un-

solvable for a single model can be solved in parallel.

2 RELATED WORK

There is a considerable body of work available on

symmetry breaking for the SGP from the constraint

programming community, including model reformu-

lation, static symmetry breaking constraints, and dy-

namic symmetry breaking.

Smith (2001) presented the integer set model with

extra auxiliary variables that automatically eliminates

the symmetries inside of groups. Moreover, Symme-

try Breaking During Search (SBDS) with symmetry

breaking constraints is employed to break renaming

symmetry but not entirely, where SBDS is essentially

a search space reduction technique by adding con-

straints to remove symmetrical search space during

the search. Law and Lee (2004) introduced the Pre-

cedence constraint to break the symmetries of groups

inside of weeks for the integer model and the sym-

metries caused by renaming golfers for the set mo-

del. Symmetry Breaking via Dominance Detection

(SBDD), another dynamic symmetry breaking techni-

que, was developed separately by Focacci and Milano

(2001) and by Fahle et al. (2001); Rossi et al. (2006).

SBDD utilizes no-good learning to avoid exploring

search space that is symmetrical of previously explo-

red nodes recorded on the no-goods. As with SBDD,

Fahle & Milano discovered 7 non-symmetric soluti-

ons for the 5-3-7 instance in less than 2 hours on a

computer with an UltraSparc-II 400 MHz processor.

Barnier and Brisset (2002) proposed SBDD+ for

the SGP, which computes isomorphism not only for

leaves of the search tree but also on current non-

leaves node. The experimental results showed that

SBDD+ only takes around 8 seconds to compute all 7

non-symmetric solutions for 5-3-7, which is a signiﬁ-

cant improvement compared with (Fahle et al., 2001).

However, they also point out that SBDD+ has to

tackle the explosion of node store and the time over-

head due to nodes dominance checking if one wants

to apply SBDD+ to a larger instance and we also be-

lieve this is the common problem for other dynamic

symmetry breaking techniques, including SBDS. Pu-

get (2005) combined SBDD with Symmetry Breaking

Using Stabilizers (STAB) to obtain a solution of the

instance 5-5-6 in 38 seconds on a laptop with a Pen-

tium M 1.4 GHz processor, where STAB is a vari-

ant of SBDS that adds symmetry breaking constraints

without changing the speciﬁed partial assignment. To

tackle the second difﬁculty, Sellmann and Harvey

(2002) developed the Vertical constraints and Hori-

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

zontal constraints for propagation, which can check

whether a given partial assignment is extensible to a

solution. They obtained all unique solutions of the

5-3-7 instance in 393.96 seconds on a computer with

Pentium III 933 MHz processor by imposing verti-

cal constraints and horizontal constraints on the deci-

sion variables. But the constraints are developed for

the original naive model, and no efﬁcient algorithm

for ﬁnding the golfers who have conﬂicting residual

graphs is given.

Despite its elegant and sophisticated search space

reduction techniques such as SBDS, SBDD, etc., the

CP approach, a systematic search method, cannot

compete with metaheuristic approaches on the SGP if

the goal is to obtain one solution instead of all non-

symmetric solutions. Please note that the problem

grows much faster even from 5-3-7 to 6-3-8 than the

performance boost out of the processors. Dot

u and

Van Hentenryck (2005) employed tabu search with

a constructive seeding heuristic and good starting

points to achieve signiﬁcant results on the instances of

the form prime-prime-(prime+1) (e.g. 43-43-44, 47-

47-48). They also found a solution 9-9-10 and 6-3-8

by using tabu search with a good starting point in 0.01

second and 51.93 seconds on a Pentium IV 3.06 GHz

processor (Dot

u and Van Hentenryck, 2007). Besi-

des, Cotta et al. (2006) used an evolutionary appro-

ach to solve 6-3-8 on a computer with a Pentium IV

3.06 GHz processor (no CPU time is given). Triska

and Musliu (2012a) are the only computer scientists

who successfully solved the 8-4-10 instance publis-

hed so far. They employed a greedy heuristic for tabu

search with the well-designed greedy initial conﬁgu-

ration to solve the instances 8-4-10 in 11 minutes on

a computer with an Intel Core 2 Duo 2.16 processor.

Besides, they also explored a SAT encoding for the

SGP (Triska and Musliu, 2012b). Unfortunately, their

SAT encoding is not competitive with other approa-

ches.

In addition to these approaches mentioned above

which address the SGP head-on, Harvey and Winte-

rer (2005) used the Mutually Orthogonal Latin Rec-

tangle (MOLR) solutions found to construct solutions

to the SGP. The most notable instance they solved is

20-16-6, which indicates that this is probably the most

efﬁcient method so far. However, no full instance g-

s-w

∗

was resolved since this method relies heavily on

the construction of MOLR.

Finally, some instances which have not been sol-

ved by computer at present have already been con-

structed by combinatorics (e.g., 7-4-9, 9-3-13). For

a detailed introduction, please refer to (de Resmini,

1981; Rees and Wallis, 2003).

3 THE BASIC MODEL

There are various ways to model the SGP, which

is one of the reasons why the problem is so com-

pelling. We use a model improved on the model

presented in (Barnier and Brisset, 2002), and more

constraints are added into the model to tackle lar-

ger instances piece by piece. The present paper invol-

ves the use of several types of constraints, including

the GCC, AllDifferent, Count, Table, and Arithme-

tic constraints (Beldiceanu et al., 2012).

The decision variables in our model is a w×n ma-

trix G, where the ﬁrst row (week) and ﬁrst s columns

(golfers) of the matrix are ﬁxed (cf. Table 2). An

element G

i, j

of the matrix G stands for golfer j is as-

signed to group G

i, j

in week i. The domain of the

decision variable G

i, j

is a set of integers consisting of

{1..g}, where 0 ≤ i < w, 0 ≤ j < n. (In the present

paper, the index of each subscript of a matrix starts

from 0.) The main advantage of the decision vari-

ables used in this model is the range of the variables

reduced from {1..n} to {1..g} and the number of deci-

sion variables is unchanged, compared with the naive

model that derived from the problem deﬁnition. In

addition to this, the elements of the ﬁrst row and ﬁrst

s columns without the ﬁrst element are initialized to:

0 ≤ j < n, G

0, j

= j/s + 1 (1)

0 < i < w, 0 ≤ j < s, G

i, j

= j + 1 (2)

Equation 1 produces a sequence of integers from 1

to g in non-descending order, and each integer repe-

ats exactly s times. Freezing the ﬁrst row by this se-

quence of integers in our model can partially mitigate

the symmetries caused by renumbering the golfers.

Applying Equation 2 amounts to assigning the ﬁrst s

golfers to the ﬁrst s groups after the ﬁrst week, which

can signiﬁcantly reduce the search space, as well as a

part of symmetries caused by interchangeable groups

inside of weeks (cf. Table 1 and 2).

Since each group is composed of s number of gol-

fers in every week, the constraint imposed on each

row of the matrix G can be stated as:

0 < i < w, V = {1..g}, O = [s,..,s],

GCC(G

i,∗

,V,O)

(3)

where GCC is an acronym for the Global Cardina-

lity Constraint and the length of the list of variables

O is g. The constraints ensure that each value in the

set {1..g} must occur exactly s times in each row of

the matrix G. In other words, there are the n distinct

golfers divided into g groups in each week via these

constraints. The restriction, which says that no golfer

meets the same golfer more than once, can be inter-

preted as no two columns of the matrix G have the

Solving the Social Golfers Problems by Constraint Programming in Sequential and Parallel

Table 2: A solution is obtained by our model for 7-3-10 instance, and it is equivalent to the solution depicted in Table 1. The

text in bold indicates that the values have been initialized before the search.

Week

Golfers

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21

1 1 1 1 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6 7 7 7

2 1 2 3 1 4 5 1 4 6 2 5 6 2 5 7 3 4 7 3 6 7

3 1 2 3 2 4 5 4 6 3 1 3 5 7 1 6 5 2 7 6 7 4

4 1 2 3 3 4 2 5 6 7 4 6 3 6 7 5 5 1 7 2 4 1

5 1 2 3 4 2 5 3 1 5 7 6 1 3 4 5 2 6 7 7 6 4

6 1 2 3 4 5 6 7 4 1 3 2 7 6 5 2 1 6 7 5 4 3

7 1 2 3 4 5 3 7 6 2 6 4 5 1 7 5 6 7 4 1 3 2

8 1 2 3 4 1 5 5 2 4 5 1 7 7 6 3 6 3 2 4 6 7

9 1 2 3 4 5 1 2 3 5 4 6 7 5 3 4 6 7 1 7 2 6

10 1 2 3 4 3 5 7 5 6 6 7 2 4 2 1 4 6 3 7 1 5

same value at the same row more than once, which

can be expressed as:

0 ≤ j

< j

< n,

∑

0≤i<w

| G

i, j

− G

i, j

= 0 |≤ 1 (4)

Constraints 3 and 4 are the only two constraints that

are the same as the model presented in (Barnier and

Brisset, 2002). In particular, unlike Barnier and Bris-

set (2002), we realize the Constraint 4 in a different

way to avoid using the Reiﬁed constraints because

these constraints slow down the resolution speed.

Speciﬁcally, the need for the Reiﬁed constraints can

be replaced by introducing a w×m matrix C, where

m =





. We subtract each column from all other co-

lumns in the matrix G and the differences between

two columns of the matrix G are assigned to a column

of the matrix C. Simply put, the two matrices are lin-

ked by the Arithmetic constraints, which is given by:

0 ≤ i < w, 0 ≤ j

< j

< n, 0 ≤ j





∀ j

, G

i, j

− G

i, j

= C

i, j

(5)

Then, we realize the restriction deﬁned by Con-

straint 4 by imposing the Count constraint on each

column of the matrix C, which can be stated as:

0 ≤ j < m, occ = {0, 1}, count(C

∗, j

, occ, 0) (6)

where occ is an integer variable whose domain is

{0,1}. Constraint 6 restricts the number of occurren-

ces of value 0 on each column is no more than once.

Until now, the constraints presented have already

stated all the restrictions deﬁned by the SGP and can

be used to solve some small instances (e.g., 3-3-4, 5-

3-7). However, we can further shrink the search space

by placing implied constraints, which do not change

the set of solutions, and hence are logically redun-

dant (Smith, 2006). As we mentioned earlier, the ﬁrst

row of the matrix G is ﬁxed with a sequence of inte-

gers by Equation 1, which implies that those golfers

who have met in the ﬁrst week cannot be assigned

to the same group in the subsequent weeks. Thus,

the AllDifferent constraint can be used to enforce the

group numbers of these golfers are pairwise distinct

after the ﬁrst week, given by:

∀0 < i < w,∀ j 6= j

∧ j/s = j

/s,G

i, j

6= G

i, j

(7)

In summary, the basic model is composed of Con-

straints 1, 2, 3, 5, 6, and 7. Nevertheless, the perfor-

mance of this model can be greatly improved by the

introduction of additional constraints, such as sym-

metry breaking constraints, and the constraints deri-

ved by instance-speciﬁc information. On the basis of

this model, in the subsequent sections, we will pre-

sent the additional constraints dedicated to different

instances and how to solve these instances in parallel

if the instance cannot be solved sequentially.

4 INSTANCES SOLVED

SEQUENTIALLY

For a given number of groups g and a group size s,

our goal is to compute the ﬁrst solution for a full in-

stance g-s-w

∗

, where w

∗

maximizes the number of

weeks. In this section, we consider a particular type

of instance s −s − (s + 1), which means that the num-

ber of groups in each week is equal to the number of

golfers in the groups within each week, and the num-

ber of weeks is maximized because

−1

s−1

= s +1. The

exclusive properties of the instances of the form s-s-

(s+1) enable us to discover the instance-speciﬁc con-

straints. Furthermore, we utilize the observed pattern

from the relatively small instances to deduce more

instance-speciﬁc constraints for the instances of the

form odd-odd-(odd+1) (o-o-(o+1)) and prime-prime-

(prime+1) (p-p-(p+1)). We also give our experimen-

tal results of the models executed sequentially.

4.1 7-7-8

Since s ∗ s-1 is divisible by s-1, every golfer must

play with every other exactly once. Thus, golfers

whose number is greater than s must meet every gol-

fer whose number is less than or equal to s exactly

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

once in every week except the ﬁrst week because the

ﬁrst s golfers have played together in the ﬁrst week

since Equation 1 freezes the ﬁrst week.

Based on the above analysis, we can place the fol-

lowing constraints on the columns of the matrix G:

0 < i < i

, s ≤ j, ∀i∀i

∀ j, G

i, j

6= G

, j

(8)

Constraint 8 states that starting with s-th column,

every column in the matrix G except its ﬁrst element

must be pairwise different, which can be implemented

by the AllDifferent constraint. For the sake of illus-

tration, we solved the instance 5-5-6 as an example.

Begin with the sixth golfer, each column of Table 3

is a permutation of the 5-element array [1, 2, 3, 4, 5].

Therefore, apart from the ﬁrst s columns, all the pos-

sible values of columns (column space) of the matrix

G is reduced from s

to s! by introducing the Con-

straint 8, which is a signiﬁcant search space reduction.

In Section 3 we have presented Constraint 1 to ﬁx

the ﬁrst row of the Matrix G. We can also ﬁx the se-

cond row of the instances of the form s − s − (s + 1)

for the following reason. The s number of golfers as-

signed in the same group cannot meet again in the

subsequent weeks, and the domain of these golfers

is the set of integers {1..s}, which implies that the

possible values assigned to these s golfers must be

a permutation of s-element array [1,2,..,s]. More-

over, arbitrary swapping two columns that have the

same ﬁrst elements leads to an isomorphism when the

ﬁrst row is ﬁxed by the Constraint 1; hence, to avoid

exploring the isomorphisms, we can choose a ﬁxed

column ordering. Therefore, for the instances of the

form s− s −(s +1), we can initialize the variables re-

presenting the golfers who have met in the ﬁrst week

with the array [1,2, .., s] in the second week (cf. the

second row of Table 3), which can be expressed as:

s ≤ j < n, G

1, j

= j%s + 1 (9)

The symmetries caused by renumbering the golfers in

the second row can be eliminated by imposing Con-

straint 9. Summary: The constraints of the basic mo-

del and the Constraints 8 and 9 forms the model used

to tackle 5-5-6, 6-6-7, and 7-7-8.

4.2 9-9-10

The additional constraints for 7-7-8 are insufﬁcient to

solve 9-9-10 in an appropriate time since the size of

the problem grows signiﬁcantly. One possible way

to tackle the larger instance is to shrink the overall

The % (modulo) operator yields the remainder from the

division of the ﬁrst operand by the second.

search space by imposing more instance-speciﬁc con-

straints.

Before introducing the constraints, we ﬁrst de-

ﬁne the submatrix GS of the decision variables ma-

trix G. In the present paper, a submatrix GS of G is

a (w − 1)×s matrix formed by deleting the ﬁrst row

of G and selecting columns [ j, .., ( j + s − 1)], where j

must be divisible by s. Hence, G has exactly s number

of such submatrices with w − 1 rows and s columns,

and the i-th submatrix of G is denoted by GS

, where

1 ≤ i ≤ s (Table 3).

We observe the solutions of the 4-4-5, 5-5-6, and

7-7-8 instances; and discover that GS

is always a

symmetric matrix, namely GS

= GS

. Hence, we

conjecture that 9-9-10 also has a symmetric subma-

trix and then impose the following constraints on the

decision variables G:

0 < i < w, s ≤ j < 2 ∗ s, G

i, j

= G

( j−s),(i+s)

(10)

Constraint 10 states that the entries of GS

are sym-

metric with respect to the main diagonal. Besides, the

main diagonal of the sub-matrix GS

is pairwise dis-

tinct for 5-5-6 and 7-7-8, given by:

0 < i < w, s ≤ j < 2s, ∀i∀ j, G

i, j

6= G

(i+1),( j+1)

(11)

Apart from the ﬁxed pattern of GS

, there is also

a ﬁxed pattern among the sub-matrices of G. Because

the second row has already been ﬁxed by Constraint 9,

we can impose the AllDifferent constraints on the

subsequent rows for those golfers who have played

together in the second week since any two columns

of G can only have identical values in exactly one

row (e.g. AllDifferent(G

3,5

3,10

3,15

3,20

) in Ta-

ble 3). These constraints are implied constraints and

can be expressed as:

1 < i < w, s ≤ j < j

< n, j%s = j

%s,

∀i∀ j∀ j

, G

i, j

6= G

i, j

(12)

We notice that for 5-5-6 and 7-7-8, there is always

a type solution in which the second row of GS

ﬁxed by the array [2,s,1,3,4,..,s − 1] (cf. the third

row of Table 3). We therefore assume that 9-9-10

also exists such solution, and use it to solve 9-9-

10. In conclusion, we solve 9-9-10 by adding Con-

straints 10, 11, and 12 to the model of 7-7-8, as well

as the ﬁxed values for the second row of GS

4.3 13-13-14 etc.

We have discovered some common features of the in-

stances of the form s-s-(s+1), particularly the instan-

ces of the form o-o-(o+1), for the solution expressed

by the number of groups; and these common features

are mostly focused on the second submatrix GS

Solving the Social Golfers Problems by Constraint Programming in Sequential and Parallel

Table 3: A solution of 5-5-6 expressed by the number of groups. It can be converted to the solution expressed by the number

of golfers easily; we don’t provide it due to lack of space. The submatrices GS

and GS

are surrounded in the dotted line.

Week

Golfers

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

1 1 1 1 1 1 2 2 2 2 2 3 3 3 3 3 4 4 4 4 4 5 5 5 5 5

2 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5

3 1 2 3 4 5 2 5 1 3 4 3 1 4 5 2 4 3 5 2 1 5 4 2 1 3

4 1 2 3 4 5 3 1 4 5 2 2 5 1 3 4 5 4 2 1 3 4 3 5 2 1

5 1 2 3 4 5 4 3 5 2 1 5 4 2 1 3 3 1 4 5 2 2 5 1 3 4

6 1 2 3 4 5 5 4 2 1 3 4 3 5 2 1 2 5 1 3 4 3 1 4 5 2

G. It is also interesting to observe that the submatrix

, 2 < i ≤ s, consists of s number of s-tuples that

are derived from the second submatrix GS

on the 5-

5-6 and 7-7-9 but 9-9-10 (cf. Table 3). Simply put,

the rest of submatrices can be obtained by interchan-

ging rows of GS

on these instances. Note that we

do not consider GS

since it is ﬁxed by Constraint 2.

Thus, we can solve larger instances of the form p-p-

(p+1) by restricting row space of the submatrix GS

2 < i ≤ s, to the rows of the submatrix GS

. Formally:

PT = {(G

i, j

i, j+1

,...,G

i, j+s−1

s ≤ j < 2 ∗ s, 2 ≤ i < w} (13)

2 ≤ i < w, 2 ∗ s ≤ j < n, j%s = 0,

i, j

i, j+1

,...,G

i, j+s−1

) ∈ PT (14)

where Constraint 13 deﬁnes the potential combination

of values of columns of GS

as PT. Then we can limit

the row space of the submatrices except GS

and GS

to PT by Constraint 14, which can be realized through

the Table constraint. Hence, the problem is transfer-

red to ﬁnding the GS

that can lead to a solution of

the instance.

To ﬁnd the correct GS

, we create a separate

model deﬁned on a s×s matrix (s must be a prime

number), which consists of Constraints 10 and 11,

and the Alldifferent constraint imposing on each row

and each column of the matrix. We also ﬁx the

ﬁrst row and the second row with [1,2,...,s] and

[2,s,1,3,4,..,s − 1] respectively, as we did for the 9-

9-10 instance. Moreover, the last row (i = s − 1) star-

ting with the third element ( j = 2) to the last element

is ﬁxed with the array [2, 1, 3, 4, 5,...,s − 2], and the

element at the tail of the array is removed with the

row number decrementing (i--) and the starting po-

sition of the ﬁrst element of the array incrementing

( j++) until the array is reduced to containing exactly

one element {2}, as illustrated in Table 4.

Having this observed pattern and aforementioned

separated model, we can obtain exactly one GS

for

the instance of the form p-p-(p+1), and then utilize it

as an input for Constraint 14 with the model of 7-7-8

to solve 11-11-12 and 13-13-14. Note that since GS

has already initialized before the solving process, we

do not use the model of 9-9-10 because it is unne-

Table 4: The second matrix GS

for the instance 13-13-14.

1 2 3 4 5 6 7 8 9 10 11 12 13

2 13 1 3 4 5 6 7 8 9 10 11 12

3 1 4 5 6 7 8 9 10 11 12 13 2

4 3 5 6 7 8 9 10 11 12 13 2 1

5 4 6 7 8 9 10 11 12 13 2 1 3

6 5 7 8 9 10 11 12 13 2 1 3 4

7 6 8 9 10 11 12 13 2 1 3 4 5

8 7 9 10 11 12 13 2 1 3 4 5 6

9 8 10 11 12 13 2 1 3 4 5 6 7

10 9 11 12 13 2 1 3 4 5 6 7 8

11 10 12 13 2 1 3 4 5 6 7 8 9

12 11 13 2 1 3 4 5 6 7 8 9 10

13 12 2 1 3 4 5 6 7 8 9 10 11

cessary to impose Constraints 10, 11, and 12 on the

model.

All the instances we have introduced so far con-

form to the form of o-o-(o+1); now we consider the

form of instances even-even-(even+1), we solved 8-

8-9 by the following conjectures derived from 4-4-5

with the model for 7-7-8:

0 < i < w, G

i,(i+s−1)

= 1 (15)

0 < i < i

< w, 2 ∗ s ≤ j < j

< n,

∀ j/s = j

/s ∧ j%s + 1 = i ∧ j

%s + 1 = i

i, j

6= G

, j

(16)

Constraint 15 states that the main diagonal of the ma-

trix GS

contains the ﬁxed values [1,1,...,1]; and the

rest of submatrices have the main diagonal whose va-

riables must be pairwise distinct (Constraint 16).

Table 5: The second matrix GS

for a solution the instance

8-8-9.

1 2 3 4 5 6 7 8

2 1 4 3 6 5 8 7

3 4 1 2 7 8 5 6

4 3 2 1 8 7 6 5

5 6 7 8 1 2 3 4

6 5 8 7 2 1 4 3

7 8 5 6 3 4 1 2

8 7 6 5 4 3 2 1

Table 5 depicts the submatrix GS

of the solution

of 8-8-9 we solved. It is interesting to observe that

the GS

matrix of 4-4-5 and 8-8-9 are composed of

four symmetric matrices. Moreover, we discover that

their solutions also satisfy the Constraints 13 and 14.

Unfortunately, we could not take advantage of these

features to solve 10-10-11 and 12-12-13, and it is still

unclear whether or not the 16-16-17 instance shares

these common features with 4-4-5 and 8-8-9.

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

4.4 Experimental Results

To conﬁrm our theoretical discussion and the conjec-

ture for the instances of 9-9-10 and 11-11-12 etc., we

implemented the model as described in this section

via the Choco Solver 4.0.6 (Prud’homme et al., 2017)

with JDK version 10.0.1. All experiments were per-

formed on a laptop with an Intel i7-3720QM CPU,

2.60GHz with 4 physical and 8 logical cores, and 8

GB DDR3 memory running Linux Mint 18.3. Table 6

shows the experimental results of above mentioned

instances.

Table 6: Results on the s − s − (s + 1) Instances. A su-

perscript ”c” means that the instance was open for constraint

satisfaction approach; ”dom” and ”min” denote the predeﬁ-

ned search strategies domOverWDegSearch and minDom-

LBSearch in Choco Solver, respectively.

Instance Time(s) Nodes Backtracks Fails Strategy

5-3-7 0.095 111 179 94 dom

5-5-6 0.069 7 1 0 min

6-6-7

25 1.38e5 2.77e5 1.38e5 min

7-7-8

111 3.62e5 723e5 3.62e5 min

8-8-9

12 15,370 30,680 15,350 min

9-9-10

2559 2.08e6 4.16e6 2.08e6 min

11-11-12

62 3,150 6,279 3,144 min

13-13-14

2563 5.80e4 1.16e5 5.79e4 min

Using the models presented in this section, we

were able to prove 6-6-7 has no solution and sol-

ved 6 open instances for constraint satisfaction ap-

proach (but not for metaheuristic approach (Dot

u and

Van Hentenryck, 2005)). It is interesting to relate

no solution for 6-6-7 to no Mutually Orthogonal La-

tin Squares (MOLS) of order 6 Benad

e et al. (2013).

The results also show that more instance-speciﬁc con-

straints can shorten the execution time even if the size

of instances increases. For example, 11-11-12 took

much less time than 9-9-10 since more constraints are

posted.

5 INSTANCES SOLVED IN

PARALLEL

In the previous section, we have presented the in-

stances that can be solved sequentially via our mo-

deling approach. We now turn to more difﬁcult in-

stances which must deal with through parallel proces-

sing to obtain one solution. The term difﬁcult refers

to no ﬁxed pattern discovered so far, which implies

no instance-speciﬁc constraints to shrink search space

for these instances and hence there are large search

spaces even for relatively small size.

Our idea is to partition the search tree of the SGP

into independent subtrees; then each worker that is

associated with a thread works on distinct subtrees

using the same CP model. Thus, this approach can

be classiﬁed as data-level parallelism based on the

taxonomy for parallelism in applications from Hen-

nessy and Patterson (2011). Moreover, since no com-

munication is required during the solving process, to

some extent, our parallel approach can also be seen as

Embarrassingly Parallel Search (EPS) (R

egin et al.,

2013). R

egin et al. deﬁnes that the EPS assigns the

task to worker dynamically (Palmieri et al., 2016).

Our parallel approach differs from the EPS due to the

use of a separate model that is used to generate the

sub-problems instead of Depth-bounded Depth First

Search. The generic procedure can be summarized as

follows:

1. A subset of the decision variables of the model is

selected.

2. All the partial assignments over selected variables

in the subset are generated by a separate model

before the search process.

3. The partial assignments are mapped to the wor-

kers so that each worker can work on its own inde-

pendent search space by using its own constraint

solver.

4. Once a solution is found, the worker that ﬁnds the

solution notiﬁes other workers to stop.

Step 1 is crucial to the search space splitting be-

cause it determines the subtrees explored by each

worker. We adhere to the following principles when

selecting the subset of the decision variables: ﬁrst,

they should be easy to generate by a separate model.

Second, each worker should not be assigned too many

partial assignments because one partial assignment

might take a long time to evaluate for a large instance.

Because of the usage of the separate model, the partial

assignments are consistent with the propagation (i.e.,

running the propagation mechanism on them does not

detect any inconsistency). Besides, the number of so-

lutions of the separate model can help us decide the

workload of each worker and workload distribution.

In the following section, we will gradually des-

cribe CP models for generating partial assignments

for search-space splitting and the constraints imposed

on the basic model for the 6-3-8, 6-4-7, and 7-3-10

instances in detail.

5.1 6-3-8

The 6-3-8 instance is a representative example to il-

lustrate the effectiveness of our parallel approach for

the SGP. As shown in Section 4, the 5-3-7 instance

can be solved in less than one second using con-

straint satisfaction approach, but 6-3-8 was open for

Solving the Social Golfers Problems by Constraint Programming in Sequential and Parallel

sequential constraint solving. For our modeling ap-

proach, the number of decision variables grows from

5 ∗ 3 ∗ 7 = 105 to 6 ∗ 3 ∗ 8 = 144, and the domain size

of each variable is increased by one, which implies

the overall underlying search space greatly increased

when the target instance switches from 5-3-7 to 6-3-8

105

to 6

144

Thus, we freeze a part of the decision variables

so that the size of the sub-problem is shrunk to sol-

vable, hence the original problem is likely to be sol-

ved. For 6-3-8, since the ﬁrst row is always ﬁxed in

our modeling approach, we select the second row for

the search space splitting and use a separate model to

generate them, which is composed of the following

constraints:

0 ≤ j < s, F

= j + 1 (17)

V = {1..g}, O = [s..s], GCC(F,V,O) (18)

∀ j 6= j

∧ j/s = j

/s, F

6= F

(19)

∀ j%s = 0, F

≤ F

( j+s)

(20)

∀ j/s = ( j + 1)/s, F

≤ F

( j+1)

(21)

where F is an array of decision variables, and

the domain of each variable is also {1..g}. Con-

straints 17, 18, and 19 are identical to Constraints 2,

3, and 7 stated in the basic model respectively. Con-

straints 20 and 21, which are not included in the ba-

sic model, are static symmetry breaking constraints.

Constraint 20 breaks the symmetries caused by inter-

changeable submatrices GS

, 1 ≤ i ≤ s. We remove

these symmetries by arranging the elements in the

ﬁrst column of the ﬁrst row of all submatrices of G

in non-decreasing order. Additionally, interchanging

any two columns of a submatrix GS

generates a solu-

tion symmetrical with the original one, which entails

Constraint 21 to remove these symmetries.

Apart from the constraints of the separate model

we also place the constraints to break the symmetries

caused by interchangeable weeks partially.

0 ≤ i < w − 1, G

i,s

≤ G

(i+1),s

(22)

Constraint 22 cannot fully remove the symmetries

among weeks because there are still symmetries whe-

never G

i,s

= G

(i+1),s

. For example in Table 2, inter-

changing the 5

week with 9

week results in a sym-

metrical solution.

Finally, the results of the above model are equally

distributed to each worker that runs the basic model.

5.2 6-4-7

The separate model for 6-3-8 produces 424 solutions

for the second row, while it produces 351 for the se-

cond row of 6-4-7. Nonetheless, we amend the sepa-

rate model for 6-3-8 to produce less number of solu-

tions for the second row of 6-4-7. The separate mo-

del for 6-4-7 is formed by adding the following con-

straints to the separate model of 6-3-8:

0 ≤ j < n, j%s = 0,

j = (s − 1) ∗ s ⇒ j + s 6= s ∗ s,

∀ j(F

j+1

≤ F

j+s+1

) (23)

∀ j(F

j+1

= F

j+s+1

⇒ F

j+2

≤ F

j+s+2

) (24)

∀ j(F

j+1

= F

j+s+1

∧ F

j+2

= F

j+s+2

⇒ F

j+3

≤ F

j+s+3

) (25)

In short, Constraints (23-25) ensure that the ele-

ments occupying the same position in the ﬁrst row

of the ﬁrst s submatrices (GS

,GS

) and

the latter two submatrices (GS

,GS

) are in non-

decreasing order respectively (Table 7). These additi-

onal constraints also reduce search space by removing

symmetries. For example, if we do not impose Con-

straint 23 on the separate model, a second row such

like [1 2 3 4 1 4 5 6 1 2 3 4 1 4 5 6 2 3 5 6 2 3 5

6] would be generated. In that case, we would require

more workers to work on these fruitless search trees

due to symmetries.

As with the 6-3-8 instance, we map the solutions

of the separate model to different workers before the

solving process. Moreover, we add the following con-

straints to the basic model:

s ≤ j < 3s, 0 < ∗ < w,

V = {1..s}, O = {1..1},

GCC(G

∗, j

,V,O)

(26)

where G

∗, j

denotes the columns from the s

column

to the (3s-1)

column of the matrix G, each of which

deletes its ﬁrst element. For the 6-4-7 instance, this

constraint guarantees that every column without the

ﬁrst element indexed between s to 3 ∗ s − 1 contains

every value in the set {1,2,3,4} exactly once (Table 7).

We impose Constraint 26 on only 2 ∗ s number of co-

lumns because (24 − 1)%(4 − 1) = 2, which implies

that each golfer only plays with other 21 golfers; thus

not every column contains the set {1,2,3,4}. Though

the columns imposed Constraint 26 do not include

all columns containing the values {1,2,3,4}, it redu-

ces much search space; experiments show we cannot

solve 6-4-7 without these constraints.

5.3 7-3-10

The problem size of 7-3-10 is much larger than 6-4-

7 and 6-3-8, we must harness more instance-speciﬁc

constraints. Just as we imposed many constraints on

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

Table 7: A solution of 6-4-7. The numbers with the same superscript are in non-decreasing order in the second row.

Week

Golfers

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

1 1 1 1 1 2 2 2 2 3 3 3 3 4 4 4 4 5 5 5 5 6 6 6 6

2 1

3 1 2 3 4 2 4 6 5 5 3 6 1 6 2 4 5 3 4 1 2 5 1 3 6

4 1 2 3 4 3 6 4 5 4 2 1 3 6 1 5 2 5 1 2 6 3 6 4 5

5 1 2 3 4 4 6 1 2 3 5 2 6 5 6 3 1 1 5 4 3 5 2 6 4

6 1 2 3 4 6 3 5 1 2 6 3 4 4 5 6 3 4 2 5 1 5 6 1 2

7 1 2 3 4 6 1 2 3 5 1 4 2 3 5 2 6 5 6 3 4 4 5 6 1

for 13-13-14 etc., we impose the following con-

straints on the model for 7-3-10:

0 < i ≤ s , G

i,s

= i + 1 (27)

s + 1 < i < w , G

i,s

= s + 1 (28)

V = {1,2,3,6,7}, O = [1,1,1,0,0],

0 < ∗ < w, GCC(G

∗,(s+1)

,V,O) (29)

V = {1,2,3,6}, O = [1,1,1,0],

0 < ∗ < w, GCC(G

∗,(s+2)

,V,O) (30)

s + s ≤ j < n, V = {1..s}, O = [1..1],

0 < ∗ < w, GCC(G

∗, j

,V,O) (31)

We strictly limit the positions of golfer 4 so that

he/she will never be assigned to group 5 and 6. The

reason is that golfer 4 is always the smallest gol-

fer in a group after week 4 (Table 1) and golfer 4

also must be less than the smallest golfer in other

groups except the ﬁrst s groups. Therefore, Con-

straint 27 and 28 remove the symmetries caused by

swapping the group containing golfer 4 with other

groups after week 4. Since golfer 4 cannot appear

in group 5, 6 and 7, golfer 5 is impossible to be as-

signed to group 6 and 7, because then there would

be no golfer assigned in group 5. Similarly, golfer

6 cannot appear in group 7 and can only appear in

group 6 once. Thus, we use Constraints 29 and 30

to limit the number of occurrences of values 6 and 7.

Furthermore, because (21−1)%(3−1) = 0, each gol-

fer must play with other golfers exactly once. Hence,

we guarantee every golfer other than the ﬁrst s gol-

fers meet the ﬁrst s golfers once, which are ensu-

red by Constaints 29, 30, and 31. Incidentally, Con-

straint 31 can be applied to any full instance that sa-

tisﬁes (n − 1)%(s − 1) = 0 in our modeling approach

(e.g. 7-4-9).

In the concrete implementation of parallelism for

7-3-10, we also use the same separate model as the

model for 6-4-7 to generate solutions of the second

row and distribute them to the workers. Moreover, we

combine the search space splitting with the portfolio,

where a partial assignment is distributed to several

different workers, and these workers use the same

model with different search strategies, including fail-

ﬁrst (Rossi et al., 2006) and dom/wdeg (Boussemart

et al., 2004). Since we employ two different parallel

constraint approaches including search space splitting

and portfolio, our parallel approach for 7-3-10 can be

viewed as a hybrid parallel constraint solving.

5.4 Experimental Results

To validate our parallel approach for the SGP, we

switch to a computer with 250 GB DDR3 1066 me-

mory and 4 Intel Xeon CPU E7-4830 2.13GHz pro-

cessors running on Linux with kernel release 2.6.32-

431.17.1.el6.x86 64, where each processor has 8 phy-

sical cores. The versions of Choco Solver and the

JDK are unchanged.

Table 8: Results on the Instances solved in parallel. A su-

perscript ”f” means that the instance is solved by computer

for the ﬁrst time. A ”-” sign means the program was still

running after a time span which equals to the number of

workers multiplied by the execution time in parallel.

Instance Workers Time(s) Nodes Backtracks Fails Strategy

6-3-8

1 2.95e4 2.91e8 5.83e8 2.91e8 min

8 50.2 2.09e5 4.18e5 2.09e5 min

16 2.62e4 2.50e8 5.13e8 2.31e8 min

6-4-7

1 - - - - min

48 8.59e3 1.66e7 3.32e7 1.66e7 min

7-3-10

1 - - - - dom

32 7.61e4 1.86e8 3.73e8 1.86e8 dom

Table 8 reports the experimental results for com-

paring parallel and sequential execution when using

the same model to solve the same instance. For paral-

lel execution, the number of workers we used varies

from instance to instance. For 6-3-8, we speciﬁed 8,

16 and 32 workers to execute in parallel, but super-

liner speedup was only observed when using 8 wor-

kers, because the partial assignment that can extend

to a solution does not happen to be evaluated ﬁrst ot-

herwise.

Then, for 6-4-7, we use 48 workers because there

are only 48 solutions generated by the separate model.

Finally, the result of 7-3-8 is given by selecting the

ﬁrst 8 solutions of the separate model, and every solu-

tion is allocated to 4 different workers, each of which

employs their respective search strategies that are

predeﬁned in Choco Solver, including minDomUB-

Search, minDomLBSearch, defaultSearch and domO-

verWDegSearch. Besides, we also performed three

more experiments in which the separate model was

speciﬁed with above mentioned search strategies. As

Solving the Social Golfers Problems by Constraint Programming in Sequential and Parallel

a consequence, the ﬁrst 8 solutions are different from

the ﬁrst experiment, and we obtained three more non-

isomorphic solutions for the 7-3-10 instance.

The experimental results show that parallel con-

straint solving through search space splitting is a very

effective means to prevent backtrack search getting

stuck into the fruitless search area; without surprise,

the super-linear speedup was observed since only one

invalid partial assignment is enough to cause instan-

ces such as 6-4-7 unable to be solved when solving

sequentially. In other words, super-linear speedups in

parallel implementations are not in contradiction with

Amdahl’s law because workers can evaluate the par-

tial solutions that can lead to a solution in early reso-

lution process.

6 CONCLUSION AND FUTURE

WORK

In this paper, we have presented a combination of

techniques which allows us to ﬁnd solutions for eight

open instances, where six of these instances are sol-

ved sequentially, and three of these instances are sol-

ved in parallel. In particular, we have shown the

constraints derived from the relatively small instances

can be used to solve larger instances which are in the

same form as the smaller ones. Besides, we have also

shown that it is not uncommon for solving the SGP

in parallel via search space splitting or with portfo-

lio to gain super-linear speedups and parallel solving

the SGP can be an effective method to address the

instances that cannot be solved serially. The results

show that our method is much more successful, even

if we consider that the computers used for the other

methods are up to 10 times slower than ours. As a re-

ference point, the individual core performance of i7-

3720QM and E7-4830 is around three and two times

faster than Pentium IV 3.06, respectively.

Unlike the earlier researches on the SGP which

mainly focus on dynamic symmetry breaking, we at-

tribute the effectiveness of the instance-speciﬁc con-

straints and parallelism to mitigating the two pro-

blems mentioned in the Introduction. Speciﬁcally,

the instance-speciﬁc constraints imposed on the se-

cond sub-matrix of the matrix of the decision vari-

ables prune a large number of the sub-search trees

near the root, including some symmetries. And since

many partial assignments are extended simultane-

ously, fruitless partial assignments have no impact

on overall execution time. Besides, we also remove

http://cpu.userbenchmark.com/, Accessed: August

2018

the symmetries of the second row when generating

the partial assignments, which is helpful because no-

des near the root contain much more symmetries than

the nodes near the leaves of the search tree (Puget,

2005). Not only that, but search space splitting can

result in the partial assignments that can extend to a

solution to be proceeded much earlier than serial se-

arch. Therefore, with the trend of integrating more

and more cores on a single chip, we regard the pa-

rallel constraint solving via search space splitting as

an excellent alternative to fast restart policies (Perron,

2003) and discrepancy search (Shaw, 1998) for con-

straint solving. Moreover, as we emphasized before,

research on the SGP is not restricted to the problem

itself, we believe the parallel approach can be gene-

ralized to deal with other combinatorial optimization

problems.

Indeed, there is still a lot of potential to improve

the performance of our approach. In particular, we

have not removed the symmetries among weeks af-

ter week s, though we employ Constraints 22 when

solving 6-3-8, 6-4-7, and 7-3-10. In fact, we have

resolved it by enforcing the indices of the ﬁrst ”1”

of all the weeks in ascending order, which means

that the second golfers assigned in the ﬁrst group

are in ascending order. But the performance is not

satisfactory. Future work should ﬁgure out whet-

her the performance degradation is due to the use

of the IfThen constraints or removal of symmetries

which also simultaneously removes solutions. Besi-

des, despite better than using the Reiﬁed constraints,

Constraints 5 and 6 introduce too many auxiliary vari-

ables; thus, we have also implemented our dedicated

constraint to replace them. However, our constraint

increases the difﬁculty of variable-selection since the

constraint requires an additional variable to shift the

equality relationship from row to row of the matrix

C. We would also like to resolve this problem in the

future work. To solve larger instances, in addition to

using more processors and discovering more instance-

speciﬁc constraints, we would like to investigate com-

bining the dynamic symmetry breaking and parallel

constraint solving for the SGP.

And ﬁnally, we must regretfully admit that even if

we have made some progress, some interesting instan-

ces are are still open (e.g. 7-4-9, 8-3-11, 9-3-13, 10-

10-11, and 12-12-13); notably, the original SGP 8-4-

10 (Harvey, 2002) is still unsolved for constraint satis-

faction approach, despite many efforts from the con-

straint programming community. Constraint techno-

logy should be amenable to solve these instances to

demonstrate itself as the ﬁrst choice for solving com-

binatorial problems.

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

REFERENCES

Barnier, N. and Brisset, P. (2002). Solving the kirkmans

schoolgirl problem in a few seconds. In Internatio-

nal Conference on Principles and Practice of Constraint

Programming, pages 477–491. Springer.

Beldiceanu, N., Carlsson, M., and Rampon, J.-X. (2012).

Global constraint catalog, (revision a).

Benad

e, J., Burger, A., and van Vuuren, J. (2013). The enu-

meration of k-sets of mutually orthogonal latin squares.

In Proceedings of the 42th Conference of the Operati-

ons Research Society of South Africa, Stellenbosch, pa-

ges 40–49.

Boussemart, F., Hemery, F., Lecoutre, C., and Sais, L.

(2004). Boosting systematic search by weighting con-

straints. In Proceedings of the 16th Eureopean Con-

ference on Artiﬁcial Intelligence, ECAI’2004, including

Prestigious Applicants of Intelligent Systems, PAIS 2004,

Valencia, Spain, August 22-27, 2004, pages 146–150.

Colbourn, C. J. (1984). The complexity of completing

partial latin squares. Discrete Applied Mathematics,

8(1):25–30.

Cotta, C., Dot

u, I., Fern

andez, A. J., and Van Hentenryck,

P. (2006). Scheduling social golfers with memetic evo-

lutionary programming. In International Workshop on

Hybrid Metaheuristics, pages 150–161. Springer.

de Resmini, M. J. (1981). There exist at least three

non-isomorphic s (2, 4, 28)’s. Journal of Geometry,

16(1):148–151.

Dot

u, I. and Van Hentenryck, P. (2005). Scheduling social

golfers locally. In International Conference on Integra-

tion of Artiﬁcial Intelligence (AI) and Operations Rese-

arch (OR) Techniques in Constraint Programming, pages

155–167. Springer.

Dot

u, I. and Van Hentenryck, P. (2007). Scheduling social

tournaments locally. AI Communications, 20(3):151–

162.

Fahle, T., Schamberger, S., and Sellmann, M. (2001). Sym-

metry breaking. In International Conference on Prin-

ciples and Practice of Constraint Programming, pages

93–107. Springer.

Focacci, F. and Milano, M. (2001). Global cut framework

for removing symmetries. In International Conference

on Principles and Practice of Constraint Programming,

pages 77–92. Springer.

Harvey, W. (2002). CSPLib problem 010: Social golfers

problem. http://www.csplib.org/Problems/prob010.

Harvey, W. and Winterer, T. (2005). Solving the molr and

social golfers problems. In International Conference on

Principles and Practice of Constraint Programming, pa-

ges 286–300. Springer.

Hennessy, J. L. and Patterson, D. A. (2011). Computer ar-

chitecture: a quantitative approach. Morgan Kaufmann.

Law, Y. C. and Lee, J. H. (2004). Global constraints for in-

teger and set value precedence. In International Confe-

rence on Principles and Practice of Constraint Program-

ming, pages 362–376. Springer.

Miguel, I. (2012). CSPLib problem 038: Steel mill slab

design. http://www.csplib.org/Problems/prob038.

Palmieri, A., R

egin, J.-C., and Schaus, P. (2016). Paral-

lel strategies selection. In International Conference on

Principles and Practice of Constraint Programming, pa-

ges 388–404. Springer.

Perron, L. (2003). Fast restart policies and large neighbor-

hood search. Principles and Practice of Constraint Pro-

gramming at CP, 2833.

Prestwich, S. (2001). CSPLib problem

028: Balanced incomplete block designs.

http://www.csplib.org/Problems/prob028.

Prud’homme, C., Fages, J.-G., and Lorca, X. (2017). Choco

Documentation. TASC - LS2N CNRS UMR 6241, COS-

LING S.A.S.

Puget, J.-F. (2005). Symmetry breaking revisited. Con-

straints, 10(1):23–46.

Rees, R. S. and Wallis, W. (2003). Kirkman triple systems

and their generalizations: A survey. In Designs 2002,

pages 317–368. Springer.

egin, J.-C., Rezgui, M., and Malapert, A. (2013). Em-

barrassingly parallel search. In International Conference

on Principles and Practice of Constraint Programming.

Lecture Notes in Computer Science, volume 8124, pages

596–610. Springer, Berlin, Heidelberg.

Rossi, F., van Beek, P., and Walsh, T., editors (2006). Hand-

book of Constraint Programming, volume 2 of Foundati-

ons of Artiﬁcial Intelligence. Elsevier.

Sellmann, M. and Harvey, W. (2002). Heuristic constraint

propagation–using local search for incomplete pruning

and domain ﬁltering of redundant constraints for the so-

cial golfer problem. In CPAIOR’02. Citeseer.

Shaw, P. (1998). Using constraint programming and local

search methods to solve vehicle routing problems. In In-

ternational conference on principles and practice of con-

straint programming, pages 417–431. Springer.

Smith, B. M. (2006). Modelling. In Foundations of Artiﬁ-

cial Intelligence, volume 2, pages 377–406. Elsevier.

Smith, B. M. (April 2001). Reducing symmetry in a combi-

natorial design problem. In CPAIOR’01, pages 351–359.

http://www.icparc.ic.ac.uk/cpAIOR01.

Triska, M. and Musliu, N. (2012a). An effective greedy heu-

ristic for the social golfer problem. Annals of Operations

Research, 194(1):413–425.

Triska, M. and Musliu, N. (2012b). An improved sat formu-

lation for the social golfer problem. Annals of Operations

Research, 194(1):427–438.

Solving the Social Golfers Problems by Constraint Programming in Sequential and Parallel
