Convolutional Neural Network for Detection and Classiﬁcation with

Event-based Data

Joubert Damien

, Konik Hubert

and Chausse Frederic

DEA-SAR, Groupe Renault, 1 Avenue du Golf, Guyancourt, France

Universit Clermont Auvergne, CNRS, SIGMA Clermont, Institut Pascal, F-63000 Clermont-Ferrand, France

Univ Lyon, UJM-Saint-Etienne, CNRS, Tlcom Saint-Etienne, Laboratoire Hubert Curien UMR 5516, F-42023,

Saint-Etienne, France

Keywords:

Event-based Sensor, Convolutional Neural Network, SSD, Faster-RCNN, Transfer Learning.

Abstract:

Mainly inspired by biological perception systems, event-based sensors provide data with many advantages

such as timing precision, data compression and low energy consumption. In this work, it is analyzed how

these data can be used to detect and classify cars, in the case of front camera automotive applications. The

basic idea is to merge state of the art deep learning algorithms with event-based data integrated into artiﬁcial

frames. When this preprocessing method is used in viewing purposes, it suggests that the shape of the targets

can be extracted, but only when the relative speed is high enough between the camera and the targets. Event-

based sensors seems to provide a more robust description of the target’s trajectory than using conventional

frames, the object only being described by its moving edges, and independently of lighting conditions. It is

also highlighted how features trained on conventional greylevel images can be transferred to event-based data

to efﬁciently detect car into pseudo images.

1 INTRODUCTION

Embedded applications still face major issues such

as world perception, energy consumption, learning in

uncontrolled environments, among many others. The

recent progresses made by deep learning approaches

seem promising at ﬁrst sight as the performance of

many systems have been dramatically increased. But

when these systems have to be implemented in em-

bedded hardware, in order to obtain a sufﬁcient speed

and energy consumption with lower computing po-

wer, some applications are no longer improved. Con-

cerning issues of target detection and classiﬁcation,

the diversity of user cases make the validation and the

comparison of systems difﬁcult. Most of the time,

some databases such as KITTI (Geiger et al., 2013)

are shared to compare different algorithms. This neg-

lects the sensor, and because of lighting conditions

often make the system misbehave, performances me-

asured on these databases is biased compared to these

of the ﬁnal system. Currently, the main solution is

to increase the size of the database, but it does not

guarantee that every scenarios are tackled. This issue

can be addressed if the sensor used to acquire data

is independent of the environment. Many conventio-

nal grey level sensors now support an high dynamic

range (HDR) response, but most of the time this latter

dynamically depends on the radiometry of the scene.

Event-based sensors provide a response independent

of the lighting conditions, then it must be investigated

if features they provide can be efﬁciently used to des-

cribe targets robustly. Detection and classiﬁcation in

automotive scenarios is one of the most challenging

issue nowadays, with the prospect of the autonomous

vehicle. This paper investigates how event-based sen-

sor can be used with state of the art deep learning

techniques to detect cars, as proposed in a recent work

(Chen, 2017). Our approach will be compared to it

latter. Our main contributions are :

• An analysis of the dynamic of automotive scena-

rios and how it must inﬂuence the design of an

event-based detector.

• An event-based data processing technique desig-

ned to build representative features, also used to

train state of the art convolutional neural net-

works.

• An annotation of state of the art dataset to measure

the performances of our method.

This paper is organized as follows : the ﬁrst

200

Damien, J., Hubert, K. and Frederic, C.

Convolutional Neural Network for Detection and Classiﬁcation with Event-based Data.

DOI: 10.5220/0007257002000208

In Proceedings of the 14th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2019), pages 200-208

ISBN: 978-989-758-354-4

section shows how event-based systems can increase

detection and classiﬁcation performances. The se-

cond section explains the process to adapt two state

of the art convolutional neural networks to detect and

classify data provided by an event-based sensor, and

ﬁnally the third section presents the results and draws

the conclusions.

2 EVENT-BASED SENSORS

2.1 Neuromorphic Systems

From decades, it is commonly accepted that numeric

sensors and computing systems are mostly synchro-

nous : cameras acquire images with a given framerate

or computers process it with a given clock. One re-

cently popularized embedded application is advanced

driver assistance systems (ADAS), thanks to the de-

velopment of autonomous driving prototypes. Today,

the performance achieved by these systems is not suf-

ﬁcient enough. Every year, the computing power and

the number of sensors (cameras, lidars, radars..) in-

creases, but the human, ﬁtted with ”only” two eyes

and a brain, both being less powerful and less energy

consuming, is still better. The neuromorphic commu-

nity tries to inspire from biology to build smarter sy-

stems with reasonable energy consumption. A funda-

mental difference is how data are processed over time.

In nature, the information is carried asynchronously,

and data bandwidth depends on the relevance of the

data provided. Following these principles, some key

achievements (Liu et al., 2015) have been made re-

cently in the neuromorphism community, and it sup-

poses that the scale of the industrialization will be re-

ached in next years.

2.2 Dynamic Vision Sensors

Many researches have been driven in the medical ﬁeld

to understand and model how eyes acquire and trans-

fer data to the brain. For example, cat eyes are sensi-

tive to the gradient of the light stimulus, preproces-

sing light information with ﬁlters similar to Gabor

ones (Hubel and Wiesel, 1962). The human eye ap-

proximately works alike: some ganglion cells process

in several ways the light collected by rods and co-

nes in order to extract spatio temporal patterns (Mas-

land, 2012). Many attempts have been made to im-

plement these functionalities into chips, some adding

analog spatial ﬁlters at pixel level (Ruedi et al., 2003)

while others analogically detect temporal contrast of

light (Delbr

uck and Mead, 1989). A key achievement

was realized with the DVS128 prototype (Lichtstei-

ner et al., 2008), which spread into many applications

domains such as high speed tracking (Delbruck and

Lang, 2013), trajectory estimation (Mueggler et al.,

2015) and pattern detection and classiﬁcation (Bichler

et al., 2012). Each pixel belonging to this sensor has

the ability to detect and timestamp temporal contrast

variation according to its polarity, and to transfer this

information outside the camera with a microsecond

latency precision.

Figure 1: Event-based pixel process to subsample light sig-

nal.

As described in Fig. 1, pixels only react if the ﬂux

they collect will change enough at its surface. Sen-

sors characteristics were analyzed (Lichtsteiner et al.,

2008) (Posch and Matolin, 2011) and directly inﬂu-

ence the quantiﬁcation of the light signal. When a

pixel detects a change, it generates a spike containing

the change information (x, y, t, p), where (x, y) is the

position in the imager, t the timestamp and p the po-

larity of the change. An example of artiﬁcial retina

(or event-based) data is provided in Fig 2. A grey

level measurement has been added to the next gene-

ration of artiﬁcial retina to provide more information.

Figure 2: Events generated during 50 ms when the camera

is approaching a road sign. Positive events are in red and

negative in green.

Convolutional Neural Network for Detection and Classiﬁcation with Event-based Data

201

Two different architectures were proposed: the DA-

VIS (Brandli et al., 2014) and the ATIS (Posch et al.,

2011). Nowadays, these families of sensors beneﬁt

of new manufacturing process such as color ﬁlters (Li

et al., 2015) and backside illuminated CMOS archi-

tecture (Son et al., 2017) (Taverni et al., 2018).

3 THE EVENT-BASED

DETECTOR

Since the DVS128, many algorithms have been pro-

posed to detect and track targets in many application

domains. We address the issue of both classify and

detect targets in the same algorithm.

3.1 Related Work

In this section the design of the event-based cars de-

tector and classiﬁer is explained. Such problems have

been massively tackled in conventional grey level

images. The ﬁrst approaches consisted in extracting

spatial features such as Haar wavelets (Viola et al.,

2003), HOG (Dalal and Triggs, 2005) or SIFT (Lowe,

1999) based descriptor, and then applying a classiﬁer

in the feature space, for example a SVM (Scholkopf

and Smola, 2001) or a boosting tree (Freund et al.,

1996). The features computation and classiﬁcation

process is no more competitive against new deep le-

arning techniques. Neural networks were studied in

the end of the 90s, but recent improvements in com-

puting capacities make them available for a large part

of the research community in many ﬁelds of applica-

tion. Deep learning mostly consists in training a deep

network of artiﬁcial neurons backpropagating the er-

ror gradient through the layers. (LeCun et al., 1998).

The network is characterized by its architecture and

topology, but also with the cost function used in the

training process to be adapted to a given task. Deep

learning addressed image classiﬁcation issues (LeCun

et al., 1998) (Krizhevsky et al., 2012) (Zeiler and Fer-

gus, 2014). In these convolutional neural networks

(CNN) architectures, the ﬁrst convolutional layers ex-

tract information with Gabor like features (Zeiler and

Fergus, 2014), as works biological vision systems

(Hubel and Wiesel, 1962). In the training process,

both feature extraction and classiﬁcation are optimi-

zed at the same time. CNN-based networks such as

the VGG (Simonyan and Zisserman, 2014) and the

Inception (Szegedy et al., 2016) model achieve state

of the art results at classifying objects. But classiﬁ-

cation is not enough in automotive applications. The

3D or at least the 2D position of the target is also cru-

cial as it determines how dangerous a scenario can be.

Classiﬁcation with a neural network is an expensive

operation in computation time and it is not possible

to run classiﬁcation in a pyramid of multi scale ima-

ges. New architectures were developed to both detect

and classify. One part of the network is dedicated to

object detection and the other part is dedicated to ob-

ject classiﬁcation. In the R-CNN architecture (Girs-

hick et al., 2014), a region proposal network selects

some relevant regions on which a classiﬁer network

is applied. This entire network is trained with a cost

function taking into account both classiﬁcation and

detection errors. Many architectures have been pro-

posed to decrease the execution time (Girshick, 2015)

(Ren et al., 2015). In order to address the region pro-

posal and classiﬁcation at the same time, two network

architectures are now popular : the SSD (Liu et al.,

2016) and the YOLO (Redmon et al., 2016).

Each previous network is efﬁcient with conventional

images, but seems unﬁtted to use with artiﬁcial re-

tina data at ﬁrst sight because no frames are provi-

ded by DVS sensors. The task of classiﬁcation in

event based-data is an active ﬁeld of research. In-

spired by works on conventional images, retina data

space can be projected into spatio temporal feature

space. An interesting work led to descriptors inspi-

red from HOG (Dalal and Triggs, 2005) : the HOTS

(Lagorce et al., 2017) and its improvement, HATS

(Sironi et al., 2018). Some neural network appli-

cations were adapted to process asynchronous retina

data. Asynchronous networks have been developed

in order to manage both spatial and temporal infor-

mation. Biological neurons present a great diversity

of transfer functions (Izhikevich, 2004), then most

of the time a standard simpliﬁed leaky integrate and

ﬁre neuron model is implemented. It must be noti-

ced that these Spiking Neural Networks (SNN) were

studied before ﬁrst artiﬁcial retina appeared, and that

they achieve good performances at classifying and

detecting spatio-temporal patterns (Masquelier et al.,

2008). The main difﬁculty is to implement these net-

works and dedicated hardware, which are still at the

prototype stage.

Another not bio-inspired method consists in building

pseudo images with event-based data, and applying

frame based approach on it (Moeys et al., 2016) (Ma-

queda et al., 2018). In the work of (Chen, 2017),

a reduced version of the Yolo network is trained to

achieve car detection and classiﬁcation. Let us inves-

tigate how the preprocessing step must be elaborated

in order to train efﬁciently CNNs.

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

202

3.2 Images of Event Activity

Our method does not use the precision of the tem-

poral information encoded into events. We believe

this information is not necessary here, as it could be

in other applications such as spatiotemporal pattern

detection and classiﬁcation, for example gesture re-

cognition (Amir et al., 2017). The purpose here is to

tackle automotive scenarios where it is crucial to ro-

bustly detect incoming targets. In our approach, the

speed of targets is constant during the detection stage,

it is considered that no relevant information can be ex-

tracted from timing information to detect and classify.

However, after the detection and classiﬁcation, the ti-

ming information could be used to estimate the tra-

jectory and potential time to collision. In automotive

scenarios, the diversity of target relative speeds is im-

portant then several timing scales must be used. For

example, concerning slow targets, it is not necessary

to quickly detect them, but rather to precisely detect

them and estimate their trajectory.

3.2.1 Integration of Events over Time

In order to track both fast and slow incoming targets,

the activity of the sensor is integrated by using se-

veral temporal windows, as the opposite of the work

of (Chen, 2017), where the integration lasts 10 ms in

order to obtain results at 100 Hz. The number and

the duration of the temporal windows are estimated

depending on the application. In the work presented

here, the constraints of automotive applications obli-

ged us to process the event stream using three diffe-

rent temporal windows : one of 40 ms, t

, one of

100 ms, t

100

, and one of 200 ms, t

200

. Detection are

processed in the three pipelines in parallel, in order

to detect fast, normal and slow targets. We suppose

that the detection time is less than the shorter tempo-

ral window (40 ms) in order to start a new detection as

soon as the last t

is available. One up to three tempo-

ral windows are used to compute ﬁnal detection. This

latter is obtained taking the maximum of the detecti-

ons realized in each temporal window. This behavior

is illustrated in Figure 3 to sum up how data are pro-

cessed in our method.

When a pixel detects a change, several events are

generated depending on the slope of the change or

on the parameters of the sensor, as illustrated in Fig.

1. Then targets detected in t

200

may generate more

events in one pixel compared to those of t

. We chose

to not count the number of events on each pixel, but

rather to simply set the grey level to one if the last

spike is positive, to zeros if it is negative, and 0.5 if

nothing happened in the time window. Contrary to

(Chen, 2017), we think that preserving the polarity

Figure 3: Schematic of the proposed detection architecture

to both detect fast and slow targets. Time windows (in Yel-

low) and detections (in Grey) are obtained in parallel.

will help to detect a shape of car. Fig. 4 shows ima-

ges of events considering two temporal windows.

3.2.2 Network Architecture

It is now investigated how these images can be used

with standard CNN architectures. The well-known

SSD (Liu et al., 2016) and Faster-RCNN (Ren et al.,

2015) networks are here adapted to event-based data.

Both architectures are kept identical. Concerning the

SSD, 11 convolutional layers are trained, the ﬁrst ones

being initialized as the ﬁrst layers of the VGG net-

work. From 6 layers at different scale levels, features

are extracted through a convolutional layer whose ﬁl-

ters have a given spatial shape called anchor. These

latter are linked to a softmax classiﬁer to obtain the

class: car or not car, and also adjust the ﬁnal bounding

box of the object. Then, for each anchor is trained

C +4 ﬁlters where C is the number of classes. Concer-

ning the Faster RCNN, the region proposal network

(RPN) which proposed potential regions of interest is

initialized with layers of VGG or ZF networks. Af-

ter the RPN, a small network maps RPN features into

a smaller feature space where two sliding fully con-

nected layers predict both class and position of ob-

jects. A similar anchor process is used to generate the

new feature space.

3.3 Datasets

When applications were developed using the DVS128

sensor, databases were needed to train and test al-

gorithms. The ﬁrst ones were small (Serrano-

Gotarredona and Linares-Barranco, 2015) or artiﬁ-

cial (Orchard et al., 2015). Larger databases are now

available, but sometimes provided without annotati-

ons. For automotive applications, the DDD17 data-

base (Binas et al., 2017) has been recently proposed,

and contains 12 hours of acquisitions synchronized

with several information of the car such as the steer-

Convolutional Neural Network for Detection and Classiﬁcation with Event-based Data

203

(a) Grey level Image (b) Image t

100

(d) Image t

200

Figure 4: Image of events in different time windows for the same scene. In this case, where the speed between the two cars is

low, only longer temporal window contains the shape of the car.

ing angle or the GPS position. Our ﬁrst contribution

was to annotate a part of this dataset in the same man-

ner as (Chen, 2017). A dedicated network, different

from the ﬁnal detection network, is specially trained

on grey level images from the DDD17 dataset. Du-

ring initialization, a SSD network pre-trained on RBG

images is applied on grey level images in order to

keep only scenes containing cars to obtain a ﬁrst set

of annotation A

Around each target detection, 500 ms of event data

are kept in order to generate time windows. Detection

are made every second of the videos acquired by day.

We also annotated 800 grey level images by hand to

build the database A

. A ﬁrst version of the annota-

tion network was trained on A

: W

and in ﬁnetuning

the initial multi-class SSD trained on RGB images on

. The network W

is then applied on the database

to provide a new set of annotations which deﬁnes a

new database A

. The performance of the network W

is also evaluated on A

. An iterative specialization

process is then used to increase the performance of

the annotation network. We iterate this process until

the performance of the network into the database A

stops to increase and get W

. In practice, it takes 3 ite-

rations to converge, and the ﬁnal network does not de-

tect each car in A

, mostly because of lighting condi-

tions (grey level images have a small dynamic range),

and because of small targets. Using W

the ﬁnal da-

tabase is annotated. In this latter, no information is

provided about the scenario, but the diversity of rela-

tive speeds seems not representative enough.

Another similar work has been proposed to build

an annotated event-based automotive database (Sironi

et al., 2018). Authors apply almost the same anno-

tation process to pick relevant data from automotive

scenarios, but they only provide 100 ms of event data

in bounding boxes, half belonging to cars and half be-

longing to the environment. Also, grey level images

are not provided. The aim of this database is to eva-

luate classiﬁcation performances. In order to adapt

it to measure detection and classiﬁcation performan-

ces, we randomly positioned these boxes containing

cars in images to generate a pseudo artiﬁcial database.

This work has been conducted only for testing pur-

poses. As our network is trained with real images,

we ensure that cars are close to image sensor (in the

range [20% , 80%] of image’s height. Two images of

40 ms are built for each acquisition, then 8790 pseudo

images contain cars and 8790 contains background.

4 EXPERIMENTS

The ﬁnal detection networks R

SDD

, R

FZF

and R

F V G

are trained on the labeled DDD17 database (Binas

et al., 2017), using ZF or VGG weights at initializa-

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

204

tion for the ﬁrst layers. These ﬁlters layers are com-

monly used on color images, and are effective to ex-

tract spatial patterns with high level of abstraction.

For the SSD, the learning rate is set to 0.001 and expo-

nentially decreases with a 0.97 factor. Instead of using

a momentum solver as proposed in the original SSD

architecture, an Adam solver (Kingma and Ba, 2014)

was preferred as it does not diverge at the beginning

with the same learning rate. Using Adam, ε = 0.1, and

the weight decay is 5e

−5

. Data augmentation techni-

ques were not used during the training. The Faster-

RCNN inspired network uses the same training pro-

cesses, as they both converge quickly and efﬁciently.

We decided to only train the network for car detection,

the resolution of DDD17 image being approximately

a quarter VGA ((346*260 pixels) we estimated that

there are not enough information to separate car from

truck classes.

4.1 DDD17

The ﬁnal database contains 120k images for training

and validation, and 15k images for testing. One main

drawback of our annotation method is that it also an-

notates event-based data when there is no relative mo-

tion between targets and camera. In this case, there is

almost no event data in each time window.

Figure 5: Integration of cumulative distribution function

(CDF) of the percentage of spiking pixels into the bounding

boxes for the training and testing database. Average preci-

sion of the SSD(15 %) on the testing database according to

the activity is also computed: if activity is equal to x %, AP

is computed for BB whose activity is inside ]x − 10%; x].

Figure 5 reveals that most of the pseudo images do

not contain signiﬁcant information: 75 % of bounding

boxes contains less than 35 % of spiking pixels inside.

In theory, 35% pixels spiking in the box may repre-

sent a 35 % occluded target. We trained the network

with bounding boxes containing more than 35% or 15

% spiking pixels. This method decreases the number

of images in the training database. At the end, 9000

training and 2000 testing images remain considering

bounding boxes with more than 15 % spiking pixels.

Considering bounding boxes with more than 35 %

spiking pixels, it remains 7000 training and 1500 tes-

ting images. Network are trained on both datasets.

The average precision (AP) is computed for each net-

work using the VOC 2007 standard, and is presented

in Table 1. These results not show a signiﬁcant perfor-

mance difference between the two databases concer-

ning the SSD network. Thus, R

FZF

and R

F V G

have

not been trained on bounding box containing more

than 35 % spiking pixels. The network using the

Faster-RCNN architecture with the ZF weights pro-

vide best AP results, but as illustrated in Figure 6, it

also generates more false detections. However, if a

target generating 14% of spikes inside its bounding

box is detected, it is considered as a false positive in

the previous results. The inﬂuence of the activity on

AP is analyzed in Fig. 5 and seems to evolve similarly

to the CDF.

Table 1: Average precision of CNN-inspired networks on

two DDD17 testing databases with different number of

active pixels in bounding boxes.

SSD

(35 %) 0.693 R

FZF

(15 %) 0.834

SSD

(15 %) 0.698 R

F V G

(15 %) 0.846

4.2 PropheseeNcar

The database is generated as explained in previous

section. SSD results must be ﬁltered to address only

classiﬁcation. Bounding boxes whose intersection

with the data from Prophesee is more than 50% are

kept. In Table 2 are compared the accuracy: the

SSD

(15 %) does not perform the best result on this

database, but this network was not specialized to this

database. Being generated with a different sensor,

using different settings, the average precision result

obtained on this pseudo dataset is almost identical

(0.68) to the average precision obtained on the DV17

database. This indicates that event-based sensors pro-

vide an object representation independent of the sen-

sor, which conﬁrms the assumption that event-based

data can provide more robust and generic target mo-

dels. A more sensitive sensor will be more robust to

low contrast scenes, but the obtained feature repre-

sentation would be the same using our preprocessing

method.

Table 2: Accuracy of the proposed networks versus state of

the art classiﬁers on the PropheseeNCar database.

SSD

0.746 HOTS 0.561

H-ﬁrst 0.683 HATS 0.902

Convolutional Neural Network for Detection and Classiﬁcation with Event-based Data

205

Figure 6: The ﬁrst column contains grey level images, and the second one draws the ground truth labels on t

images. The

red boxes contain less than 15 % of event activity, while in green boxes more than 15 %. Some testing results obtained with

SSD

(15 %) are displayed in the third column while the fourth columns contained results from R

FZF

(15 %). The two ﬁrst

lines correspond to the DDD17 database, while the last lines corresponds to the PropheseeNCar database. Further results are

available online https://youtu.be/r1GqjE0jz58.

5 DISCUSSION

In the evaluation of our networks, the ability to solve

every automotive scenarios is not really estimated.

In order to measure the performance of the network

regarding to the relative speed of targets, it should

be measured performance regarding to relative speed.

This work will be conducted in a future work by rea-

lizing tests on EURO NCAP user cases.

Many layers were used to process the information into

the networks, and it may be studied if a more reasona-

ble number of parameters can be used to achieve de-

tection and classiﬁcation task at a same performance

level. Finally, the main drawback of our approach is

to determine when the sensor is providing enough in-

formation to realize classiﬁcation. The true advantage

of event-based sensor, the time information, is neg-

lected in our work, and the pseudo images could also

be obtained by computing the difference between two

conventional frames, and applying a threshold.

6 CONCLUSION

An adaptation of the SSD and the Faster-RCNN archi-

tectures has been proposed in order to process event-

based data for automotive scenarios. The data of a re-

cent published database acquired with a state of the art

silicon retina is labelled with an iterative process. Au-

tomotive constraints inﬂuence the way data are packa-

ged before to be processed by the network, in order to

maintain a sufﬁcient level of performance for each re-

lative speed between the camera and the targets. De-

tection performances are measured and conﬁrm re-

sults of how transferable are CNN ﬁlters to event-

based pseudo images. It has also been highlighted that

the spiking ﬂow must be carefully analyzed to process

the classiﬁcation with enough data.

REFERENCES

Amir, A., Taba, B., Berg, D., Melano, T., McKinstry, J.,

Di Nolfo, C., Nayak, T., Andreopoulos, A., Garreau,

G., Mendoza, M., et al. (2017). A low power, fully

event-based gesture recognition system. In Procee-

dings of the IEEE Conference on Computer Vision and

Pattern Recognition, pages 7243–7252.

Bichler, O., Querlioz, D., Thorpe, S. J., Bourgoin, J.-P.,

and Gamrat, C. (2012). Extraction of temporally

correlated features from dynamic vision sensors with

spike-timing-dependent plasticity. Neural Networks,

32:339–348.

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

206

Binas, J., Neil, D., Liu, S.-C., and Delbruck, T. (2017).

Ddd17: End-to-end davis driving dataset. arXiv pre-

print arXiv:1711.01458.

Brandli, C., Berner, R., Yang, M., Liu, S.-C., and Delbruck,

T. (2014). A 240× 180 130 db 3 µs latency global

shutter spatiotemporal vision sensor. IEEE Journal of

Solid-State Circuits, 49(10):2333–2341.

Chen, N. F. (2017). Pseudo-labels for supervised

learning on event-based data. arXiv preprint

arXiv:1709.09323.

Dalal, N. and Triggs, B. (2005). Histograms of oriented gra-

dients for human detection. In Computer Vision and

Pattern Recognition, 2005. CVPR 2005. IEEE Com-

puter Society Conference on, volume 1, pages 886–

893. IEEE.

Delbruck, T. and Lang, M. (2013). Robotic goalie with 3 ms

reaction time at 4% cpu load using event-based dyna-

mic vision sensor. Frontiers in neuroscience, 7:223.

Delbr

uck, T. and Mead, C. (1989). An electronic photore-

ceptor sensitive to small changes in intensity. In Ad-

vances in neural information processing systems, pa-

ges 720–727.

Freund, Y., Schapire, R. E., et al. (1996). Experiments with

a new boosting algorithm. In Icml, volume 96, pages

148–156. Bari, Italy.

Geiger, A., Lenz, P., Stiller, C., and Urtasun, R. (2013). Vi-

sion meets robotics: The kitti dataset. The Internatio-

nal Journal of Robotics Research, 32(11):1231–1237.

Girshick, R. (2015). Fast r-cnn. arXiv preprint

arXiv:1504.08083.

Girshick, R., Donahue, J., Darrell, T., and Malik, J. (2014).

Rich feature hierarchies for accurate object detection

and semantic segmentation. In Proceedings of the

IEEE conference on computer vision and pattern re-

cognition, pages 580–587.

Hubel, D. H. and Wiesel, T. N. (1962). Receptive ﬁelds,

binocular interaction and functional architecture in

the cat’s visual cortex. The Journal of physiology,

160(1):106–154.

Izhikevich, E. M. (2004). Which model to use for cortical

spiking neurons? IEEE transactions on neural net-

works, 15(5):1063–1070.

Kingma, D. P. and Ba, J. (2014). Adam: A method for sto-

chastic optimization. arXiv preprint arXiv:1412.6980.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012).

Imagenet classiﬁcation with deep convolutional neu-

ral networks. In Advances in neural information pro-

cessing systems, pages 1097–1105.

Lagorce, X., Orchard, G., Galluppi, F., Shi, B. E., and Be-

nosman, R. B. (2017). Hots: a hierarchy of event-

based time-surfaces for pattern recognition. IEEE

transactions on pattern analysis and machine intelli-

gence, 39(7):1346–1359.

LeCun, Y., Bottou, L., Bengio, Y., and Haffner, P. (1998).

Gradient-based learning applied to document recogni-

tion. Proceedings of the IEEE, 86(11):2278–2324.

Li, C., Brandli, C., Berner, R., Liu, H., Yang, M., Liu, S.-

C., and Delbruck, T. (2015). An rgbw color vga rol-

ling and global shutter dynamic and active-pixel vi-

sion sensor.

Lichtsteiner, P., Posch, C., and Delbruck, T. (2008). A 128×

128 120 db 15 µs latency asynchronous temporal con-

trast vision sensor. IEEE journal of solid-state cir-

cuits, 43(2):566–576.

Liu, S.-C., Delbruck, T., Indiveri, G., Douglas, R., and

Whatley, A. (2015). Event-based neuromorphic sys-

tems. John Wiley & Sons.

Liu, W., Anguelov, D., Erhan, D., Szegedy, C., Reed, S., Fu,

C.-Y., and Berg, A. C. (2016). Ssd: Single shot mul-

tibox detector. In European conference on computer

vision, pages 21–37. Springer.

Lowe, D. G. (1999). Object recognition from local scale-

invariant features. In Computer vision, 1999. The pro-

ceedings of the seventh IEEE international conference

on, volume 2, pages 1150–1157. Ieee.

Maqueda, A. I., Loquercio, A., Gallego, G., Garcıa, N.,

and Scaramuzza, D. (2018). Event-based vision meets

deep learning on steering prediction for self-driving

cars. In Proceedings of the IEEE Conference on Com-

puter Vision and Pattern Recognition, pages 5419–

5427.

Masland, R. H. (2012). The neuronal organization of the

retina. Neuron, 76(2):266–280.

Masquelier, T., Guyonneau, R., and Thorpe, S. J. (2008).

Spike timing dependent plasticity ﬁnds the start of re-

peating patterns in continuous spike trains. PloS one,

3(1):e1377.

Moeys, D. P., Corradi, F., Kerr, E., Vance, P., Das, G., Neil,

D., Kerr, D., and Delbr

uck, T. (2016). Steering a

predator robot using a mixed frame/event-driven con-

volutional neural network. In Event-based Control,

Communication, and Signal Processing (EBCCSP),

2016 Second International Conference on, pages 1–8.

IEEE.

Mueggler, E., Gallego, G., and Scaramuzza, D. (2015).

Continuous-time trajectory estimation for event-based

vision sensors. In Robotics: Science and Systems XI,

number EPFL-CONF-214686.

Orchard, G., Jayawant, A., Cohen, G. K., and Thakor, N.

(2015). Converting static image datasets to spiking

neuromorphic datasets using saccades. Frontiers in

neuroscience, 9:437.

Posch, C. and Matolin, D. (2011). Sensitivity and unifor-

mity of a 0.18µm cmos temporal contrast pixel ar-

ray. In 2011 IEEE International Symposium of Cir-

cuits and Systems (ISCAS), pages 1572–1575. IEEE.

Posch, C., Matolin, D., and Wohlgenannt, R. (2011). A

qvga 143 db dynamic range frame-free pwm image

sensor with lossless pixel-level video compression and

time-domain cds. IEEE Journal of Solid-State Cir-

cuits, 46(1):259–275.

Redmon, J., Divvala, S., Girshick, R., and Farhadi, A.

(2016). You only look once: Uniﬁed, real-time object

detection. In Proceedings of the IEEE conference on

computer vision and pattern recognition, pages 779–

788.

Ren, S., He, K., Girshick, R., and Sun, J. (2015). Faster

r-cnn: Towards real-time object detection with region

proposal networks. In Advances in neural information

processing systems, pages 91–99.

Convolutional Neural Network for Detection and Classiﬁcation with Event-based Data

207

Ruedi, P.-F., Heim, P., Kaess, F., Grenet, E., Heitger, F.,

Burgi, P.-Y., Gyger, S., and Nussbaum, P. (2003).

A 128/spl times/128 pixel 120-db dynamic-range

vision-sensor chip for image contrast and orienta-

tion extraction. IEEE Journal of Solid-State Circuits,

38(12):2325–2333.

Scholkopf, B. and Smola, A. J. (2001). Learning with ker-

nels: support vector machines, regularization, optimi-

zation, and beyond. MIT press.

Serrano-Gotarredona, T. and Linares-Barranco, B. (2015).

Poker-dvs and mnist-dvs. their history, how they were

made, and other details. Frontiers in neuroscience,

9:481.

Simonyan, K. and Zisserman, A. (2014). Very deep con-

volutional networks for large-scale image recognition.

arXiv preprint arXiv:1409.1556.

Sironi, A., Brambilla, M., Bourdis, N., Lagorce, X., and

Benosman, R. (2018). Hats: Histograms of avera-

ged time surfaces for robust event-based object clas-

siﬁcation. In Proceedings of the IEEE Conference

on Computer Vision and Pattern Recognition, pages

1731–1740.

Son, B., Suh, Y., Kim, S., Jung, H., Kim, J.-S., Shin, C.,

Park, K., Lee, K., Park, J., Woo, J., et al. (2017). 4.1 a

640× 480 dynamic vision sensor with a 9µm pixel and

300meps address-event representation. In Solid-State

Circuits Conference (ISSCC), 2017 IEEE Internatio-

nal, pages 66–67. IEEE.

Szegedy, C., Vanhoucke, V., Ioffe, S., Shlens, J., and Wo-

jna, Z. (2016). Rethinking the inception architecture

for computer vision. In Proceedings of the IEEE Con-

ference on Computer Vision and Pattern Recognition,

pages 2818–2826.

Taverni, G., Moeys, D. P., Li, C., Cavaco, C., Motsnyi, V.,

Bello, D. S. S., and Delbruck, T. (2018). Front and

back illuminated dynamic and active pixel vision sen-

sors comparison. IEEE Transactions on Circuits and

Systems II: Express Briefs, 65(5):677–681.

Viola, P., Jones, M. J., and Snow, D. (2003). Detecting

pedestrians using patterns of motion and appearance.

In null, page 734. IEEE.

Zeiler, M. D. and Fergus, R. (2014). Visualizing and under-

standing convolutional networks. In European confe-

rence on computer vision, pages 818–833. Springer.

VISAPP 2019 - 14th International Conference on Computer Vision Theory and Applications

208
