Usability of Policy Authoring Tools: A Layered Approach

Stephanie Weinhardt

and Olamide Omolola

Institute for Human Factors Engineering, University of Stuttgart, Nobelstrasse 12, Stuttgart, Germany

Institute of Applied Information Processing and Communications, Graz University of Technology,

Inffeldgasse 16a, Graz, Austria

Keywords: Policy Authoring, Usability, Layered Approach, Trust Policy.

Abstract: Many policy authoring tools lack usability, and this deficiency often deters new users from using the tools. In

this paper, we propose an approach to make policy authoring more usable and enable novice users to create

policies. The process of creating a trust policy using a trust policy language has different levels of complexity

for different users. This paper identifies three categories of such users and introduces a three-layered approach

to cater to each user group. The approach intuitively reduces the functionalities available based on the

capability of each group of users and therefore making policy creation more usable.

1 INTRODUCTION

Although a lot of work on usability in IT-Security has

been conducted (Zurko et al., 1996; Cranor and

Garfinkel, 2004; Bonatti, 2006; Meland and Jensen,

2008; Ferreira et al., 2009; Kirlappos and Sasse,

2014; Prieto et al., 2017; Iacono et al., 2018), policy

authoring tools still lack usability (Reeder et al.,

2007; Fischer-Hübner et al., 2010; Coi et al., 2011;

Rudolph, 2014; Caputo et al., 2016). We believe that

this is a multi-layered problem. On the one hand, the

tools themselves lack usability, on the other hand, the

policy languages are too complex and too hard to

understand for people with little or no knowledge in

policy authoring (Coi et al., 2011; Rudolph, 2014).

Especially for novice users policy authoring is a

complex and complicated topic. The need for usable

security has been addressed quite extensively, but

within that usable policy authoring is still

unaddressed (Caputo et al., 2016) and solutions for

usable policy authoring need to be developed.

Especially because Reeder et al., (2007) discovered

that there is an uprising need for all kinds of users to

formulate different types of policies. This need is

increasing because policy authoring is not limited to

administrators anymore (Bonatti, 2006; Cao and

Iverson, 2006; Fischer-Hübner et al., 2010). Recent

developments, such as the Internet of Things and

automation, increases the need for non-programmers

and novice users to formulate policies. But end users

will not purchase and will not use security software

they cannot understand (Zurko et al., 1996).

This paper aims to show an approach to designing

usable policy authoring. In the field of policy

authoring different user groups with varying levels of

knowledge and different goals, need different sets of

functionalities and a tailored user interface to not

overstrain novice users and still provide full

functionality to expert users (Bishop, 2005; Cao and

Iverson, 2006; Fischer-Hübner et al., 2010). So far,

there was no possibility for novice and expert users to

work within the same tool. Beyond that, Clare-Marie

Karat et al., (2005) found in their evaluation of the

SPARCLE tool that it is beneficial to let users choose

the way they want to create their policy, no matter to

which user group they belong.

In this paper, we introduce a 3-layer approach.

The 3-layers combine several methods and principles

to meet all the identified requirements, plus

increasing usability and user adoption. Each layer has

a specific target user group for which it is designed.

They also address user friendliness on their own by

implementing well-known usability and usable

security design principles. Moreover, these different

layers gradually introduce users to the topic and

ideally enable them to become experts in it and create

policies that are more complex.

We implemented the 3-layer-approach in a high-

fidelity prototype created in the framework of the

LIGHTest. This European funded research project

implements a global trust infrastructure that can be

used by anyone. The challenge of enabling all kinds

Weinhardt, S. and Omolola, O.

Usability of Policy Authoring Tools: A Layered Approach.

DOI: 10.5220/0007355003010308

In Proceedings of the 5th International Conference on Information Systems Security and Privacy (ICISSP 2019), pages 301-308

ISBN: 978-989-758-359-9

301

of users to formulate trust policies with a tool and

enhancing its usability is the focus of this

contribution. Although the approach is shown within

the European project using trust policies, we strongly

believe that the method can be adapted to any policy

authoring tool.

The structure of the paper is as follows: first, we

give a short outline of related work as well as on

literature that deals with usable security design

principles. Then, we introduce the approach and show

how it is implemented in the high-fidelity prototype.

Finally, we provide an outlook on the following

evaluation and future work.

2 RELATED WORK

Policy authoring is the process of creating a set of

rules combined either with the goal to regulate access,

make systems more secure or in our case to define

trust relationships. There are several existing

contributions on the topic of usable policy authoring

from the last decade. Most of them focus on authoring

access or security policies (Chadwick and Sasse,

2006; Karat et al., 2006; Reeder et al., 2007; Bauer et

al., 2008; Beznosov et al., 2009; Johnson et al., 2010;

Rudolph, 2014). We know of no significant research

that has been done on usable trust policy authoring

tools.

No matter what kind of policy users create, they are

all formulated using a programming policy language.

One effort in making policy authoring more user-

friendly was to implement it with a natural language.

Natural language is believed to shorten the “distance”

(Pane et al., 2001) between the user’s real-world

needs and its expression within a computer.

Furthermore, some contributions suggest natural

language should be controlled, i.e. its semantics

should be limited because it is less ambiguous in

comparison to free natural language (Chadwick and

Sasse, 2006). Although the controlled natural

language introduced in (Karat et al., 2005; Brodie,

2006; Vaniea et al., 2008; Johnson et al., 2010; Coi et

al., 2011; Shi and Chadwick, 2011) makes a big step

towards usability, it still requires some coding

knowledge that makes it hard for users without any

programming experience to use it.

Most research focuses on a specific tool, an area

of expertise or a particular experienced user group

(Machado et al., 2015) that cannot be adapted to the

European project topic because it addresses a

different issue as well as a diverse user group and

cannot utilise the substantive, limited knowledge of

the problem. A lot of contributions focus on a specific

set of users and try to make policy authoring more

usable by adding usability on top of an already

existing policy language or tool. Little contributions

consider a user-centred design from the very

beginning. With the approach presented here, we

incorporate user-centred design from the very

beginning.

Also, the authors of (Coi et al., 2011; Rudolph,

2014) mention that most of the policy tools and

languages are too complex to be understood by

novice users – therefore, complexity should be

reduced.

Despite rare contributions that address usable

policy authoring on the next level, there have been

two significant contributions that form the basis of

our approach.

The authors of (Karat and Brodie, 2005; Brodie,

2006) focused on usable (security) policy authoring.

They evaluated three different possibilities to

formulate security policies: a guided natural

language, a structured format and an unconstrained

natural language. Their evaluation showed that the

guided natural language and the structured format

helped users formulate policies. The quality of the

policies with the unconstrained natural language was

not as high as with the guided natural language and

the structured format. There was no significant

difference between the guided natural language and

the structured format considering usability and user

satisfaction. They also indicate that it adds value to

the user interface if the users can select in which form

they create their policy in.

In (Cao and Iverson, 2006), the authors identified

three user groups: novice users, intermediate users

and expert users. They stated the necessity of

designing the tool or interaction differently for each

user group. They also identified three different

possibilities (levels) of how the user could formulate

an access control (policy). The first possibility guides

the user systematically through the creation process

of a policy; the user only needs to select from the

given choices. The second possibility provides the

users with the alternative in formulating their access

control policy based on their mental model. Although

this provides the user with more

functionality/possibilities, it also leaves the user

without guidance and introduction.

The last possibility provides the users, which are

most likely system administrators, with the full

functionality that also includes managing multiple

systems, not hindering their work.

Other contributions are design guidelines for

designing usable policy authoring tools (Yee, 2002;

Patrick et al., 2005; Lanford, 2006; Reeder et al.,

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

302

2007; Johnson et al., 2010; Atwater et al., 2015). Ever

since usable security became a topic in security

research, new design principles have been introduced

by various authors. A lot of them are basic usability

guidelines that have been adapted to the topic(Iacono

et al., 2018). As the design of our approach considers

common usability guidelines, we only mention the

ones that we took under special consideration:

- A professional look and feel are beneficial in

establishing trust (Lanford, 2006; Atwater et al.,

2015), (Patrick et al., 2005)

- Transparency to an extent aids trust and

understand ability (Atwater et al., 2015)

- Attractive design helps in building trust (Patrick

et al., 2005)

- Support object grouping (Johnson et al., 2010),

(Reeder et al., 2007)

- Communicate and enforce rule structure (Johnson

et al., 2010), (Reeder et al., 2007)

- Support appropriate limitation of expressivity

(Johnson et al., 2010)

However, we firmly believe that all of those

principles still will not make trust policy authoring

usable for a large group of users, instead of a specific

set of users. Therefore, we see the need for an abstract

interaction concept that allows all kinds of users to

formulate policies matching their needs.

Although all the contributions are essential for

usable policy authoring, none of them explicitly deals

with trust policy authoring as well designing for a

diverse user group.

Taking all these aspects under consideration, we

designed a new approach, i.e., the 3-layer approach

that allows us to address different users’ needs.

3 PROTOTYPE ANALYSIS

The first interaction concept was designed based on

related work and further analysis in the field of trust

policy authoring. This first concept, shown in Figure

Low-fidelity prototype

was implemented in a low-

fidelity prototype for visualisation and evaluation

purposes.

With the prototype, a usability evaluation was

conducted. The main goal of the evaluation was to get

a first impression on the overall usability, as well as

the mental model of the users while interacting with

such a tool.

In the description below, we briefly go into this

evaluation to explain the key findings. Ten

participants took part in the evaluation that were

acquired randomly from a pool of participants. The

only criteria they had to meet was to be over 18. Eight

of the participants stated that they had primary to

good programming skills with mostly, one participant

did not have experience in programming at all, and

one had advanced knowledge. Considering creation

of policies, only one participant ever created a policy

before.

The participants had to create a new trust policy

using a controlled natural language approach with a

Figure 1: Low-fidelity prototype.

Usability of Policy Authoring Tools: A Layered Approach

303

combination of typing and dynamic dropdowns with

suggestions.

Results from the evaluation show that most of the

users were able to create a trust policy, as the task

completion rate was 94% overall tasks. Lowest task

completion rate was 90%. Although this rates hint

towards a success, most of the participants showed

signs of mental stress and indisposition. Although

they succeeded in creating a trust policy, they did not

feel good about it and were unsure about the quality

of the trust policy they created and its impact.

Therefore we believe that the high success rates is

because of the guidance given through the whole

creation process, rather than good usability of the

tool. In the follow-up interview participants

mentioned, their discomfort while creating the policy

because they were unsure what was actually asked

and how the systems functions. Considering those

results, we concluded that the approach of the low-

fidelity prototype is not satisfactory. Tools like these

need to have high usability, as well as meeting the

knowledge level of the users to make them feel good

while interacting with the tool and not overstraining

them.

During the follow-up interview, participants also

expressed their need for either more complex or

simpler interaction possibilities. These results are

backed up by the findings from (Cao and Iverson,

2006; Beznosov et al., 2009). Both suggest putting

users into three categories.

1. Novice users with no to little knowledge

2. Intermediate users with low to intermediate

knowledge

3. Expert users with intermediate to expert

knowledge

These different aspects led us to the conclusion that

we not only have differently skilled user groups, but

we also need a different set of functionalities and

guidance for each of them as they also have different

expectations, mental models and goals.

Novice users that were recently introduced to

policy authoring and trust policies are assumed to

state entities they trust or do not trust. Anything

beyond basic functionality would probably result in

cognitive overload and therefore would reduce

usability and understanding of the tool.

Intermediate users that either already know how

other policy authoring tools work, have some program-

ming skills or have already created some simple trust

policies, might want to integrate some conditions into

their Trust Policies. They should have more functions

to create policies that are more complex.

Expert users that have profound programming skills

or good knowledge in (trust) policy authoring want to

create complex policies with several conditions and

operations. The whole set of functionalities should be

available to them. In addition, they do feel

comfortable using a programming editor to create

their policies.

Figure 2: High Fidelity Prototype.

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

304

However, trying to incorporate all these different

requirements into one user interface always led to low

usability, too much content and a bad structure. It

became clear that designing for different user groups

would not only mean reducing complexity but also

decreasing functionality and providing the various

user groups with different user interfaces, which lead

us to the development of the 3-layer approach.

4 THE THREE LAYER

APPROACH

The 3-layer approach is based on previous

contributions (Karat and Brodie, 2005; Beznosov et

al., 2009) and contributions that stated that most

policy authoring tools are too complicated for novice

users and that the complexity of those tools should be

reduced to improve usability (Coi et al., 2011;

Rudolph, 2014; Caputo et al., 2016). To achieve a

holistic approach to the problem of usable policy

authoring for all user groups we combined several

methods, guidelines and principles. The overall

concept and each layer within that concept was

developed by considering Usability Design Principles

(ISO9241-110:2006(en), 2006; Norman, 2013;

Shneiderman, 2016), Usable Security Design

Principles (Sasse et al., 2001; Yee, 2002; Garfinkel,

2005; Whitten and Tygar, 2005; Braz and Robert,

2006; Atwater et al., 2015; Prieto et al., 2017) and

Usable Policy Authoring Design Principles (see

chapter 2 Related Work).

The central aspect of the concept is that it offers

the user the possibility to create a trust policy in three

different ways:

- using a graphical editor

- create it in a controlled natural language

- and programming a policy using a trust policy

language

The most basic layer is the Graphical Layer (GL)

providing just basic functionality, designed for novice

users. The Natural Language Layer (NLL) has more

features and is intended for intermediate users. The

Trust Policy Language Layer (TPLL) has full

functionality and is designed for experts. When

creating a new trust policy, the tool provides the users

with the three different possibilities and explains each.

By providing the users with three different

possibilities to create a trust policy, the tool becomes

more usable for each user group because each layer is

customised for their needs. As a result, the needs

established in chapter 3 are met. Also, novice users can

learn and maybe create a policy in the programming

language at some point (Yee, 2002; Trojer et al., 2011;

Rudolph, 2014; Caputo et al., 2016).

Figure 3: The Three-layer Approach.

Figure 3

: The Three-layer Approach

shows the

concept of the 3-layer approach.

It shows that the users always can change from

either the GL or the NLL to the TPLL, giving them

the possibility to get full functionality for an already

existing policy.

Each layer implements design principles in its

context by considering the user group and the user

goals. The following sections will discuss each layer

separately and emphasize the conceptual aspects that

have been developed explicitly to make the layers

more usable.

4.1 Graphical Layer

The Graphical Layer is designed for novice users and

offers basic functionality. Users are only able to state

entities they trust or do not trust. This concept is

commonly referred to as blacklisting and whitelisting.

In this layer, the user is given the possibility to

select entities from a searchable list and either add it

to the trusted list (whitelist) or the not trusted list

(blacklist). The user can also create entities and assign

them to the list it deems correct.

The design is aided by giving the user visual

feedback through drag and drop colours, icons and

text to highlight which is the trusted list (whitelist)

and which is the not trusted list (blacklist). The

trusted list has a white background colour and a

closed padlock icon. The untrusted list has a grey

background and an opened padlock icon. For some

users it might be more intuitive to edit just one side or

the other, others may also want to edit both lists. This

capacity could cause some problems when users are

putting the same entity on both sides. In that case, it

is unclear whether the user wants to trust the entity –

or not. The tool detects such inconsistencies, and the

user is informed about it by a dialog box.

Despite limited functionality, this layer covers the

main feature of the tool and is probably sufficient for

a large set of users.

Usability of Policy Authoring Tools: A Layered Approach

305

4.2 Natural Language Layer

The Natural Language Layer is designed for users

with intermediate knowledge of policy creation or

basic programming knowledge. It gives the users the

possibility to create policies more naturally, by using

a controlled natural language rather than a

programming language.

Previous research has shown that giving users the

possibility to create policies in the natural language

improves usability. We believe that there is potential

to this approach and it can be made even more user-

friendly. Thereby providing different user groups that

have varying needs with varying possibilities while

using it.

To create the policy, the users can structure their

policy by creating several statements within the

policy. A policy consists of at least one statement.

Each statement is displayed as a separate design

element.

Each statement starts with the words "if input" to

hint a possible way of formulating a proper statement.

This snippet can be deleted if the users choose to

begin their sentence differently. In addition, the tool

provides different ways to add elements to a

statement.

One way to add content to a statement in the NLL

is to write plain text within the statement. The tool

will support the user by highlighting words it cannot

interpret and by giving suggestions on how and what

can be formulated. This interaction concept was

adopted from the first usability study described in

section 3. Another way for the user to develop the

policy is to use predefined building blocks that the

tool provides in this layer. After defining the set of

functionality for the Natural Language Layer,

possible building blocks and their parameters were

analysed and determined. Those are provided on top

of the editing area of the tool for the ease of access.

By clicking on a building block the parameters and

options that are available for this block are shown on

a sidebar at the right. Therefore, the users can see

what types of building blocks are available to them

and what content they have. The parameters of the

building blocks are displayed with different UI

elements to fit the content.

There are two possible interactions with these

building blocks. One is to click on a building block,

set the parameters on the right sidebar and add them

to the statement by clicking the “select”-button that is

provided within the sidebar. The other possibility is

to drag and drop a building block into the statement.

The drag and drop action causes a placeholder to

appear as well as the parameters in the right sidebar.

The users can then set the parameters and add them to

the statement by clicking the "select"-button. These

two possibilities enable the user to create their

statements with the building blocks systematically or

defining the statement first and then fill it with the

parameters. The building blocks improve usability as

they give the users more guidance on what they can

formulate but still provide them with the freedom on

how they want to create their statement. The building

blocks take away some of the cognitive load for

intermediate users.

Users can choose anytime what type of interaction

they prefer and can seamlessly switch between all the

before mentioned interactions. Therefore, this layer

provides freedom in formulating the policy

supporting different mental models and expectations

towards this layer, resulting in better usability.

A similar approach was evaluated by (Johnson et

al., 2010), with the result that users produced higher-

quality policies in comparison to an unguided

approach.

Figure 2 shows an example of a Trust Policy

created in the Natural Language Layer.

4.3 Trust Policy Language Layer

The Trust Policy Language Layer is aimed for expert

users with intermediate to high level of knowledge in

programming and creating trust policies. The layer

provides the full set of functionalities to the users by

letting them create the policies in the programming

language (Trust Policy Language). Creation of a

policy is done in a programming editor that has the

standard functionality as well as look and feel of

common programming tools.

We decided not to change anything from the

standard editor look and functionalities because we

aimed at giving the users a familiar programming

interface. There is no drag and drop function in this

layer. However, the tool evaluates the statements in

the editor and provides feedback while the users are

writing statements. In this layer, the users have total

freedom to define and create different constructs.

However, the expert users are expected to know how

to write policies directly in the Trust Policy

Language.

5 DISCUSSION

Although this is not the first contribution to the topic,

it is the first contribution that deals with usable trust

policy authoring tools from the very beginning of the

development. The 3-layer concept is based on

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

306

previous works, and a usability evaluation carried out

initially when the project began. This contribution not

only augments principles and approaches from earlier

contributions to the topic of trust policy authoring but

also combines several mechanisms to give a wide

range of possible users the possibility in creating their

own (trust) policies. As a result, it contributes to the

issue of explainable security and gives more research

perspective on how to make such security

mechanisms usable for users. We see potential of

such a tool especially in the area of IoT as well as in

automation. In those domains (and possibly others),

users have to make a lot of (trust) decisions but cannot

always decide on the spot.

If the results from future usability evaluations are

positive, this approach and its successful

implementation into products can contribute to the

research on information system trust, security and

privacy.

6 CONCLUSION

In this paper, we have shown an approach to make

policy authoring usable for a diverse user group. Key

aspects that we have been demonstrated are a

reduction in complexity by reducing functionality and

offering three different layers to create a trust policy.

Those are also meeting different mental models and

user goals. By implementing usability design

principles and security design principles in each of

the various layers, we designed for improved

usability, too.

The Graphical Layer and Trust Policy Layer have

a more straightforward design as the user groups can

be better defined. The user group for the Natural

Language Layer is assumed to be more diverse with

different levels of experience with policies creation

and programming knowledge. Therefore, we

implemented different interaction concepts and

different guidance models in the Natural Language

Layer, giving the users various possibilities for policy

creation.

The presented mechanism and concepts can be

implemented in any policy authoring tool.

As part of the future work, we will evaluate the 3-

layer approach in an extensive usability evaluation and

optimise it based on the results. Furthermore, we will

research and design a wizard that introduces the user to

the topic and the tool. Visualisation of the authored

policies and their outcome will be integrated too.

Recent research shows that user acceptance of a

tool does not only have to do with good usability but

also with a good user experience design. Therefore,

future work aims at not only investigating, how to

make such policy authoring tools user-friendly but

also how to improve the underlying user experience

in these tools.

ACKNOWLEDGEMENTS

This research is part of the LIGHT

est

project funded

from the European Union’s Horizon 2020 research

and innovation programme under G.A. No 700321.

REFERENCES

Atwater, E. et al. (2015) ‘Leading Johnny to Water:

Designing for Usability and Trust’, Eleventh

Symposium On Usable Privacy and Security (SOUPS

2015), pp. 69–88. Available at: https://www.usenix.

org/conference/soups2015/proceedings/presentation/at

water.

Bauer, L. et al. (2008) ‘A user study of policy creation in a

flexible access-control system’, Proceeding of the

twenty-sixth annual CHI conference on Human factors

in computing systems - CHI ’08, p. 543. doi:

10.1145/1357054.1357143.

Beznosov, K. et al. (2009) ‘Usability meets access control:

challenges and research opportunities’, SACMAT

Proceedings of the 14th ACM symposium on Access

control models and technologies, 09, pp. 73–74. doi:

http://doi.acm.org/10.1145/1542207.1542220.

Bishop, M. (2005) ‘Psychological Acceptability Revisited’,

in Security and Usability: Designing Secure Systems

That People Can Use, pp. 1–11.

Bonatti, P. A. (2006) ‘Flexible and Usable Policies’, W3C

Workshop on Languages for Privacy Policy

Negotiation & Semantics Driven Enforcement in

REWERSE, pp. 1–5.

Braz, C. and Robert, J. (2006) ‘Security and Usability : The

Case of the User Authentication Methods’, Proceedings

of the 18th International Conferenceof the Association

- IHM ’06, pp. 199–203. doi: 10.1145/1132736.

1132768.

Brodie, C. A. (2006) ‘An Empirical Study of Natural

Language Parsing of Privacy Policy Rules Using the

SPARCLE Policy Workbench’, Public Policy, pp. 8–

19.

Cao, X. and Iverson, L. (2006) ‘Intentional access

management: making access control usable for end-

users’, SOUPS Proceedings of the second symposium

on Usable privacy and security, 149(06), pp. 20–31.

doi: http://doi.acm.org/10.1145/1143120.1143124.

Caputo, D. D. et al. (2016) ‘Barriers to Usable Security?

Three Organizational Case Studies’, IEEE Security and

Privacy, 14(5), pp. 22–32. doi: 10.1109/MSP.2016.95.

Chadwick, D. and Sasse, A. (2006) ‘The virtuous circle of

expressing authorization policies’, CEUR Workshop

Proceedings, 207.

Usability of Policy Authoring Tools: A Layered Approach

307

Clare-Marie Karat, Carolyn Brodie, J. K. (2005) ‘Usability

Design and Evaluation for Privacy and Security

Solutions’, in Security and Usability: Designing Secure

Systems That People Can Use, pp. 47–74.

Coi, J. L. de et al. (2011) ‘Controlled Natural Language

Policies’, Seventh Framework Programme, pp. 9–11.

Available at:

http://homes.esat.kuleuven.ac.be/~decockd/tas3/final.d

eliverables/pm42/TAS3_D06p3_CNLPolicies_Final.p

df%5Cnpapers2://publication/uuid/11346F46-D413-

4250-9D89-2287E40D13DF.

Cranor, L. F. and Garfinkel, S. (2004) ‘Secure or usable?’,

IEEE Security and Privacy, 2(5), pp. 16–18. doi:

10.1109/MSP.2004.69.

Ferreira, A., Rusu, C. and Roncagliolo, S. (2009) ‘Usability

and security patterns’, Proceedings of the 2nd

International Conferences on Advances in Computer-

Human Interactions, ACHI 2009, pp. 301–305. doi:

10.1109/ACHI.2009.21.

Fischer-Hübner, S., Iacono, L. and Möller, S. (2010)

‘Usable Security und Privacy’, Datenschutz und

Datensicherheit - DuD, 34, pp. 773–782. doi:

10.1007/s11623-010-0210-4.

Garfinkel, S. L. (2005) ‘Design Principles and Patterns for

Computer Systems That Are Simultaneously Secure

and Usable by’, Gene, 31(1987), pp. 234–239.

Available at:

http://dspace.mit.edu/handle/1721.1/33204.

Iacono, L. Lo et al. (2018) ‘Consolidating Principles and

Patterns for Human-centred Usable Security Research

and Development’, in European Workshop on Usable

Security. London.

ISO9241-110:2006(en) (2006) Ergonomics of human-

system interaction - Part 110: Dialogue principles.

Johnson, M. et al. (2010) ‘Optimizing a policy authoring

framework for security and privacy policies’,

Proceedings of the Sixth Symposium on Usable Privacy

and Security - SOUPS ’10, p. 1. doi:

10.1145/1837110.1837121.

Karat, C.-M. et al. (2006) ‘Evaluating interfaces for privacy

policy rule authoring’, Proceedings of the SIGCHI

conference on Human Factors in computing systems -

CHI ’06, p. 83. doi: 10.1145/1124772.1124787.

Karat, J. et al. (2005) ‘Designing Natural Language and

Structured Entry Methods for Privacy Policy

Authoring’, pp. 671–684.

Kirlappos, I. and Sasse, M. A. (2014) ‘What Usable

Security Really Means : Trusting and Engaging Users’,

Human Aspects of Information Security, Privacy, and

Trust HAS. Lecture Notes in Computer Science, (8533),

p. 11.

Lanford, P. (2006) ‘E-Commerce: A Trust Perspective’,

International Conference on Internet Computing, pp.

64–70.

Machado, C. C. et al. (2015) ‘Policy Authoring for

Software-Defined Networking Management’,

IFIP/IEEE International Symposium on Integrated

Network Management (IM)

Meland, P. H. and Jensen, J. (2008) ‘Secure Software

Design in Practice’, 2008 Third International

Conference on Availability, Reliability and Security,

pp. 1164–1171. doi: 10.1109/ARES.2008.48.

Norman, D. A. (2013) The Design of Everyday Things. 2nd

edn. Edited by B. Books. New York: Perseus Books

Group.

Pane, J. F., Ratanamahatana, C. A. and Myers, B. A. (2001)

‘Studying the language and structure in non-

programmers’ solutions to programming problems’,

International Journal of Human Computer Studies,

54(2), pp. 237–264. doi: 10.1006/ijhc.2000.0410.

Patrick, A., Marsh, S. and Briggs, P. (2005) ‘Designing

systems that people will trust’, Security and Usability:

Designing Secure Systems That People Can Use,

(January), pp. 75–100. Available at: http://nparc.cisti-

icist.nrc-cnrc.gc.ca/npsi/ctrl?action=shwart&inde

x=an&req=8913238&lang=en.

Prieto, L. P. et al. (2017) ‘Maybe poor Jhonny Really

Cannot Encrypt - The Case for a Complexity Theory for

Usable Security’, CEUR Workshop Proceedings, 1828,

pp. 53–59. doi: 10.1145/1235.

Reeder, R. W. et al. (2007) ‘Usability Challenges in

Security and Privacy Policy-Authoring Interfaces’,

IFIP Conference on Human-Computer Interaction, pp.

141–155. doi: 10.1007/978-3-540-74800-7_11.

Rudolph, M. (2014) ‘User-friendly and Tailored Policy

Administration Points’, (076).

Sasse, M. A., Brostoff, S. and Weirich, D. (2001)

‘Transforming the “Weakest Link”: A Human-

Computer Interaction Approach for Usable and

Effective Security’.

Shi, L. and Chadwick, D. W. (2011) ‘A controlled natural

language interface for authoring access control

policies’, Proceedings of the 2011 ACM Symposium on

Applied Computing - SAC ’11, p. 1524. doi:

10.1145/1982185.1982510.

Shneiderman, B. (2016) Designing the User Interface. 6th

edn. Edinburgh: Pearson Education Limited.

Trojer, T. et al. (2011) ‘An authoring framework for

security policies: A use-case within the healthcare

domain’, Lecture Notes of the Institute for Computer

Sciences, Social-Informatics and Telecommunications

Engineering, 69 LNICST, pp. 1–9. doi: 10.1007/978-3-

642-23635-8_1.

Vaniea, K. et al. (2008) ‘Evaluating assistance of natural

language policy authoring’, Proceedings of the 4th

symposium on Usable privacy and security - SOUPS

’08, p. 65. doi: 10.1145/1408664.1408674.

Whitten, A. and Tygar, D. (2005) ‘Why Johnny Can ’ t

Encrypt’, Security, 1999(October), pp. 679–702. doi:

169-184.

Yee, K.-P. (2002) ‘User Interaction Design for Secure

Systems’, Proceedings of the 4th International

Conference on Information and Communications

Security, pp. 278–290. doi: 10.1007/3-540-36159-

6_24.

Zurko, M. E., Simon, R. T. and Street, S. (1996) ‘User-

Centered Security’, 1(212), pp. 1–9.

ICISSP 2019 - 5th International Conference on Information Systems Security and Privacy

308
