Dealing with Permanent Agent Failure in Dynamic Agents Organisations

Asia Ali Salman Al-karkhi

and Maria Fasli

Computer Science Department, University of Technology, Alsina’a Street, Baghdad, Iraq

Institute of Data Analytics and Data Science, University of Essex, Wivenhoe Park, Colchester CO4 3SQ, U.K.

Keywords:

Agent Organisations, Self-organisation, Organisation Recovery, Task Failure.

Abstract:

This paper is an exploratory study that focuses on the creation of open and dynamic agent organisations

which can sustain the provision of services to requesting customers in the presence of agent failure. In a

distributed environment, agents within networks and organisations are prone to failure. This can inevitably

lead to decreases in the individual agents’ utilisation as well as in the whole system’s and to the loss of

tasks. Here, we present an approach to tackling this challenge by enabling agents to prevent these kinds

of disruptions. In an environment where agents create organisations to increase the execution of tasks, we

employ the Henchman Recovery Protocol (HRP) within each organisation; this enables the agents within an

organisation to maintain its functionality in the presence of agent failures and in particular in the case of the

lead (Head) of the organisation failing. Furthermore, we explore the stability and evolution of organisations

over a period of time and when agents drop out of organisations (due to permanent failure) while new agents

may enter the environment and either join existing organisations or create new ones. We conduct our study

in the context of a grid-like computing system which was implemented in the Repast Simphony agent-based

simulation environment.

1 INTRODUCTION

Dealing with failure in distributed systems is a signi-

ﬁcant challenge as such systems are large, open and

complex. Therefore, providing methods for automa-

tic failure detection is important, and this is still con-

sidered an open problem (łgorzata Steinder and Sethi,

2004). However, agent or node failure is unpredicta-

ble and therefore a non-trivial problem to tackle.

In order to provide seamless services in a num-

ber of domains such as grid environments and cloud

computing, a number of often heterogeneous service

providers, actors/nodes are clustered behind an inter-

face that is providing access to these services to cu-

stomers. The main goal of creating grid computing

systems has been to be able to provide services and

to share resources as fast as possible, just as power is

shared across an electric power grid, as noted by Ian

Foster in (Foster and Kesselman, 2003).

To study the problem and explore potential so-

lutions, we have simulated a grid-like environment

through the use of multi-agent systems. In our system,

each agent is essentially a node providing services and

resources, i.e. a services provider, to requesting cus-

tomers. To improve their own utilisation, agents can

organise themselves in groups or organisations when

certain conditions arise in the system. As we show,

through organising the agents in organisations, the sy-

stem utilisation as a whole improves. Nevertheless,

agents within the organisations and within the system

as a whole can fail. An agent’s failure will almost cer-

tainly affect the stability and performance of the orga-

nisations that it belongs to. One solution for open and

dynamic systems, can be the use of self-organising

technique so that depending on the circumstances in

the environment, the available agents can still provide

the system with the required services. These kinds

of techniques are becoming ever more prevalent with

respect to networked systems and hence we are in-

terested in exploring techniques that will enable the

agents to maintain the effectiveness of the organisati-

ons and task execution. Although we show how agent

organisations can cope in the presence of failure of

individual agents and are able to maintain task execu-

tion, the problem of agent failure is more acute in the

event where the lead agent of an organisation, termed

Head, fails. In this paper, we explore the use of the

Henchman Recovery Protocol (HRP) to enable orga-

nisations to continue to function even in the event of

the Head failing.

In grid computing, solutions for the problems cau-

sed by faults, include methods to increase fault tole-

Al-Karkhi, A. and Fasli, M.

Dealing with Permanent Agent Failure in Dynamic Agents Organisations.

DOI: 10.5220/0007399907150723

In Proceedings of the 11th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2019), pages 715-723

ISBN: 978-989-758-350-6

715

rance, recovery, and removal. The main fault tole-

rance techniques which have been used in cluster sy-

stems and grid computing are checking points, mes-

sage logging, replication and retry (Haider and An-

sari, 2012). A more recent study of agent failure in

distributed MAS is (Hayashi, 2017) where the author

has addressed agent failure in situations where disas-

ter repeatedly occurs. Consecutive or simultaneous

agent failures may occur in the future as a result of

the disaster event. A comparison has been carried out

to ﬁnd a viable method for decreasing the number of

failed agents in the system.

The rest of the paper is organised as follows.

Section 2 Scenario description; section 3 creation of

organisations and roles of agents; section 4 presents

explanations about HRP, and also introduces the al-

gorithm that is used by each Henchman inside the

created organisation to monitor the Head. Sections

5 presents the experimental work. Section 6 evalua-

tion of HRP; section 7 discusses the related work in

the literature Finally, the paper ends in section 8 with

the conclusions and proposal for future work.

2 SCENARIO DESCRIPTION

There are two types of agents in the system under

consideration: the customer agent, which is used to

simulate task requests emanating from multiple cus-

tomers that may exist in reality, and service providers

which possess the resources to execute tasks, which

we will simply refer to as agents here on.The agents

have diverse resources and can execute heterogene-

ous tasks and provide services; these match the re-

quirements of the customers to various extents. The

customer agent simulates the existence of several cu-

stomers which need to ﬁnd services or have tasks exe-

cuted and sends its requests to the network of agents

via messages describing the tasks requiring execution

and associated resources as well as other conditions

such as a deadline by which the result of the task is

required.

2.1 Tasks and Resources

In a distributed environment, resources would be he-

terogeneous. There are different methods for repre-

senting resources (Carroll and Klyne, 2004), however,

for the purposes of this research the resources associ-

ated with a task have been represented in a simpler

way as this is not the main focus of the research and

using the format:

RV = < r1, r2, r3 >.

An agent in the network that receives a task will

check whether the task’s resources match with its re-

sources. Given the simple way of representing resour-

ces, proximity of requested with available resources is

calculated between the customer resource vector and

an agent’s resources using the well-known Manhattan

Distance (Manhattan Dis) Equation 2:

Manhattan Dis(RV, AR) =

x=2

∑

x=0

− AR

(1)

Where:

: the requested resources vector for the task.

: the matched agent resources that performs task

successfully.

x = 0 to 2: the index of the requested resource vector,

, r

The resulting matching value should meet the

task’s required accuracy; this is a speciﬁc value be-

tween (0 − 12). Therefore, in the task delegation pro-

tocol as shown in (AL-Karkhi and Fasli, 2017) an

agent accepts a task if a matching has occurred bet-

ween the customer resources and its resources. For

example, where a customer issues a task with RV is

<0, 0, 0> and has required accuracy (RA) equal to 6,

and the recipient agent’s RV is <2, 2, 2>, then when

applying the Manhattan Distance equation, the match

will be positive.

In addition to resources, tasks have Time To Live

(T T L) and a Time Deadline (T D). T T L indicates

the number of hops among agents that a message can

make in advancing throughout the network, while T D

indicates the deadline for the execution of the task. If

T T L = 0, the task will be considered to have failed,

otherwise, the receiving agent will check the T D of

the task; if this is sufﬁcient then the task will be exe-

cuted, but if it is not sufﬁcient (either because the re-

ceived agent is currently executing a task or its queue

of tasks already contains a number of tasks) the agent

will then delegate the task to a neighbour agent in the

network. Hence, if an agent cannot satisfy at least

one of the conditions described above, the task will be

either failed or delegated to another agent in the net-

work. The agents are autonomous and self-interested

and have the desire to maximise the beneﬁt to them-

selves; therefore, agents will keep the accepted tasks

in their Accepted Tasks Queue (ATQ) for as long as

they are currently busy executing task.

2.2 Initial Network Formation

We assume a system where agents are created and

start execution and as part of this they formulate an

initial network through connections with each other.

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

716

This initial network formation occurs within the ﬁrst

few simulation cycles. In the initial phase, the agents

acquire partial knowledge of their surrounding envi-

ronment by creating a contact list. A network model

of 300 agents visualized using Gephi (Bastian et al.,

2009) with (the Force Altas 2) layout which is useful

to visualise Small-World network and scale free net-

works is illustrated in Figure 1. The various colours

represent the degree of each node i.e the number of

connections for each agent.

Figure 1: Visualisation of network size: 300 agents. The

various colours represent the degree of each node; purple=1

connection, light green=2, blue=3, black=4, orange=5,

green=6,red=7, light pink=8, grey=9 or more.

As agents receive requests for tasks from the cu-

stomer, they will check whether these can be servi-

ced or not. They then use their contacts to essenti-

ally propagate the tasks that they are unable to exe-

cute for different reasons (unable to execute because

they are busy; not in possession of required resources,

etc.). An agent in the network may fail randomly and

permanently. An agent can detect other failed agents

through the task delegation process. When an agent

delegates a message to another agent, if it does not

receive a response from that agent for a number of

cycles, then that agent will be considered failed. The-

refore, the sender agent will delete its contact infor-

mation related to that failed agent. Hence, the net-

work could gradually reduce and eventually even col-

lapse. However, as agents may fail, new agent(s) may

be created and inserted in the system. A new agent

will send messages to randomly-selected other agents

– to obtain at least partial knowledge of its surroun-

ding environment – and get connected to the network.

New agents can offer their services either directly to

the customer or via the task delegation protocol as

described in see (AL-Karkhi and Fasli, 2017).

2.3 Agent Failure Modelling

In order to model agent failing in the network, agents

are equipped with a parameter that enables them to be

switched on/off for a period of time, and when they

are off they, in essence, they create the impression to

the system that they are ofﬂine and unable to execute

tasks or respond to messages. We have a probability

distribution between[0,1] such that a lower (nearer 0)

probability value produces fewer failed agents and a

higher probability value (nearer 0.9) will produce a

larger number of failed agents in the system. During

the initialization step of the simulation, all agents are

assigned the same probability of failure. Applying a

high failure rate simulates the harsh operational con-

ditions which exist in some systems and enables us

to study effects on the system overall and individual

agent behaviour in extreme circumstances.

3 CREATION OF

ORGANISATIONS AND ROLES

OF AGENTS

While the initial network formation enables agents to

create links and propagate tasks to each other that they

are unable to execute themselves through this network

and therefore increase task execution, it still leaves

the system fairly under-utilised with tasks remaining

un-executed or failing due to the unfocused propaga-

tion of task messages through an agent’s essentially

random connections. In order to increase the system

utilisation, we are creating organisations within the

network to enable more targeted and faster task dele-

gation. To enable the creation of organisations, agents

are taking on roles. An agent role can be deﬁned

as an agent behaviour that can affect, enhance and/or

change a system’s structure. Typically a role will po-

sit expectations, skills and duties and hence an agent

which takes on a particular role must be able satisfy

these requirements (Ferber et al., 2003). Each agent

, at any one time, has a number of roles R

• R

is deﬁned as a set of roles, < R

, R

• An agent a

can assume a role in relation to at least

one other agent, which can be an individual or an

organisation.

• The roles an agent may take on within an orga-

nisation are {Member, Henchman, Head}, each

agent may have one of these roles or more than

one, depending on a set of conditions.

• If a

has a role it may accept consequential role(s),

this means that an agent that is a Member in an

Dealing with Permanent Agent Failure in Dynamic Agents Organisations

717

organisation later on may accept the Head

s mes-

sage to be the organisation’s Henchman agent.

• If Org

and Org

are two created organisations,

then a

can belong to both of them. In turn,

any two or more organisations in the network can

share a number of Members, so an agent can have

different or the same Roles: if the overlapped or-

ganisations( Org

, Org

1. a

can be Member in Org

, Member in Org

2. a

can be Head in Org

, Member in Org

3. a

can be Henchman in Org

, Member in Org

4. a

can be Head in Org

, Not Henchman in

Org

5. a

can be Henchman in Org

, Not Henchman

in Org

6. a

can be Henchman in Org

, Not Head in

Org

• The Head of each organisation is responsible for

the activities of its agents. The presence of a Head

in an organisation of agents is necessary in order

to coordinate the work.

• A Henchman in an organisation will become a

temporary Head when the Head of its organisa-

tion has failed.

• Agents are expected to take on and change roles

while they are operating in the environment.

Typically an agent will initiate the process of crea-

ting an organisation when certain circumstances in the

system arise and the agent essentially becomes overly

busy and unable to handle additional requests. The

initiator agent, becomes the Head of the organisation

and start asking other agents in the network to join its

organisation, see (AL-Karkhi and Fasli, 2017). Orga-

nisations can be created as either consisting of a set of

agents holding similar resources (within boundaries

speciﬁed by the Head) or heterogeneous resources,

leading to heterogeneous organisations. The Head is

responsible for delegating tasks to the Member agents

and keeping track of task execution within the system

communicating with the customer. The creation of

organisations in the system can lead to increased uti-

lisation of the resources of the agents(Dignum et al.,

2004), but as has been noted in an organisation that

is part of a grid computing system, a computational

node may still be underutilised and not fulﬁl its po-

tential; this can be only 5% or even less of the time

(Haider and Nazir, 2016). This motivated us to create

overlapped organisations; we aimed to increase the

agents’ resource utilisation by allowing agents to join

more than one organisation. However, in practice, de-

pending on how busy it is, an agent can only be com-

mitted to a limited number of organizations at any one

time. We also limit the maximum number of organisa-

tions that an agent can join by setting a parameter and

this varies from agent to agent. So, this will lead to the

creation of overlapping communities/organisations as

shown in Figure 2 (a) and Figure 2 (b).

(a) Several overlapped or-

ganisations structure.

(b) Simpliﬁed structure,

an example of overlapping

organisations where q=3

Figure 2: Illustration of the concept of overlapping organi-

sations. In Figure (b), the Blue organisation overlaps with

the Green and the Red organisations in terms of a single

node, whereas the Green overlaps with the Red in relation

to two nodes. These overlapping regions are in the inter-

section of the large circles.

4 HENCHMAN RECOVERY

PROTOCOL (HRP)

Although agent utilisation may improve through the

creation of organisations, agents within organisati-

ons may fail. The failed agent could be a Head or

a Member. If it is a Head, then when a Member

wants to send messages to the Head and there is no re-

sponse from the Head and after a number of attempts,

the Member will consider the Head to have failed.

When a Member agent has failed, the Head will de-

tect this after a number of attempts at sending messa-

ges; in this latter situation, the Head will remove the

Member from its database (DB). Although task exe-

cution will be affected by a Member failing, the case

of Head failure is more acute as it essentially means

that the organisation becomes disconnected and this

leads to further task failures and under-utilisation of

resources. In this section, we describe how we have

deployed the HRP protocol in each organisation in or-

der to recover more of the customer tasks. In the li-

terature, most of the available methods that provide

fault tolerance, use reactive techniques; these provide

solutions to failure only after its occurrence. In con-

trast, we argue that using multi-agent systems with

self-organising capabilities represented by HRP can

provide a proactive methodology which can improve

task execution in open, dynamic and distributed envi-

ronments.

The Head is the agent which is responsible for

distributing the tasks to its Members in an organisa-

tion, so that if the Head fails, the tasks will also fail,

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

718

and this will affect the performance of the system as a

whole and lead to the loss of more tasks. To avoid this

loss of tasks and enhance the performance of the sy-

stem, a new role, that of the Henchman is used to ad-

dress this problem. When a Head fails, the role of the

Henchman is to detect the failure of its Head and act

as a substitute to the failed Head, providing further

self-organised capability to the system, maintaining

the functionality of the organisation. Each Member

has the ability to decide to accept a new role or to re-

ject it. The following describes the mechanism of the

Henchman role in more detail.

The ﬁrst stage of the HRP is performed during

the runtime process of the gossip algorithm – Algo-

rithm 1, which is based on the multi-cast “Push Gos-

sip” algorithm (Serugendo et al., 2011). The process

is started by the Head agent sending out a message

to the ﬁrst agent a

that joined the Head

s organi-

sation, asking the agent whether it will agree to be

its (the Head

s) Henchman (HM). The Head will

send the same message to all the other agents that

joined in sequence until one of the Members accept

the Head

s message and becomes the organisation’s

Henchman and this is what we called it “BeMyHen-

chman” acknowledgement messaging technique.

After assigning a Henchman for its organisation,

the Head has the responsibility to synchronize its

database DB with that of the Henchman; this con-

tains the contact details of the Members, and will,

of every newly joined agent. This means that the

Henchman

s DB will always be maintained to be

identical to the Head

s DB. When the Head goes

ofﬂine, the Henchman will immediately replace the

Head to maintain the functionality of the organisa-

tion.

If the Henchman does not receive any acknow-

ledgement back from the Head, the Henchman will

declare to all the other Members and the customer

agent that the Head has failed and the new Head is

the Henchman; this is in order to redirect the trafﬁc

to itself instead. When the Head recovers, i.e. the

Henchman receives an “I’m alive” messages again

from the Head, the Henchman will inform the organi-

sation Members as well as the customer that the Head

is now alive and the organisation should be back to its

normal condition. However, there is also the chance

that a disruption will affect both the Head and its

Henchman at the same time. Here, if the customer

agent sends tasks while this is the case, these tasks

will fail – until the Head and/or the Henchman return

to an active state.

If the failed agent is one which has a Henchman

role in one of the existing organizations, the Head

will remove it from its DB and the Members will be

informed by the Head that the Henchman is no longer

functioning. The Head agent will then assign a new

Henchman for its organisation.

If both the Head and then the Henchman of the

organisation have failed, the organization will have

neither a Head nor a Henchman, and in such cases,

when the Members want to access them by sending

messages they will receive no reply, and after a num-

ber of attempts the Members will consider the organi-

sation to have been disbanded.

Algorithm 1: Gossip Protocol.

Input: a

: is the most busy agent (Head) that will

create an organisation, a

is one of the a

con-

tacted list neighbour, T T L > 0.

Output: a

completed organisation.

1: Cycle e

2: a

.SendMessage (Contactlist(1,N))

3: if ( a

! = busy ) then

4: a

infected with the gossip message of a

5: // a

has the option to join or not to the created

organisation.

6: applying “BeMyHenchman” acknowledge-

ment messaging technique to select aMember

to be aHenchman.

7: else if ( a

== busy ) then

8: a

.SendMessage (1,(N))

9: end if

10: if (T T L > 0) then

11: T T L = T T L − 1

12: end if

13: Cycle e + 1

14: End

5 EXPERIMENTAL WORK

We have developed three models (HRP, Organisa-

tion Ver1 and No Organisation) which all use the set-

ting parameters, as in Table 1. In relation to these

three models, we have shown the results of various

network sizes (500, 5000) agents, task distributions

(the task distribution is used to specify the number of

tasks sent from customer to the network of agents in

each cycle) and simulation times. For all of the three

models, the number of tasks sent from the customer

agent follows a normal distribution with speciﬁc va-

lues for the mean and variance. The simulation time

was set at 7000 cycles for all of the three models.

• No Organisation model is a network model with

only task delegation property.

• Organisation Ver1 model is a model that contains

the organisations of agents.

Dealing with Permanent Agent Failure in Dynamic Agents Organisations

719

• HRP model is the organisations model with HRP

protocol capability.

Table 1: Experimental Setting Parameters.

Agent Network Size Task distribution

500 Mean=1000,variance=10

2500 Mean=1000,variance=10

5000 Mean=1000,variance=10

ANSET =

∑

i=1

x=2

∑

x=0

− AR

(2)

Where:

: the number of runs = 10.

: the requested resources vector for the task.

: the matched agent resources that performs task

successfully.

x = 0 to 2 : the index of the tuple that represent the

requested resource vector <r

, r

Figure 3 (a) and Figure 3 (b) show the average

number of successfully executed tasks, ANSET,

within the cycles, for each of the three models which

have been implemented, see Equation 2. Note that the

two models (Organisation Ver1 and HRP) have a spe-

ciﬁc structure in terms of their organisations and also

have gradual responsibilities for their agents: agents

have different roles(Head, Henchman, Member).

However, the roles of agents may change over the si-

mulation time and agents disappear and new agents

appear; these changes will affect the execution of

tasks and the system’s ability to schedule tasks.

(a) (b)

Figure 3: Average numbers of successfully executed tasks

computed across 7000 simulation cycles, p= 0.9 and p= 0.6.

The No Organisation model consistently delivers

lower numbers of successfully executed tasks over

the simulation time (than the other two). So, using

this model, the system loses a signiﬁcant number of

tasks due to frequent agent failures and the restricti-

ons imposed by the messages’ Time To Live (T T L)

and the tasks’ deadlines. In this model, the resources

are distributed and the delegation for the task mes-

sage may take more time to reach a desired agent that

(a) (b)

Figure 4: Average numbers of successfully executed tasks

computed across 7000 simulation cycles, p= 0.9 and p= 0.6.

can accept the task. Hence, the other two models, Or-

ganisation Ver1 and HRP, show better performance;

in these cases, fewer hops are required in order to

ﬁnd agents which can accept the tasks because, even

though there is a probability of failure, the organisati-

ons are created with heterogeneous resources and the-

refore, in the event of failure, other agents are readily

available to execute the tasks. The ANSETs of these

two models ﬂuctuate due to the presence of the proba-

bility of failure, which causes disruption in the system

such that agents will start to fail inside the created or-

ganisations leading to signiﬁcant changes in the exe-

cution rates of the tasks. The No organisations model

shows a smaller percentage of variation in its ANSET

as compared to the other two models. It is clear that

the No Organisation model executes tasks within the

same ranges of time, on average, in each and every

simulation cycle. This is because the model con-

tains no structure and new agents may connect rand-

omly with other existent individual agents. Where the

task may be executed is dependant only on delegation

across the entire network, and this quickly consumes

the tasks’ T T L values. Hence, the Organisation Ver1

and HRP models perform better on average than does

the “No Organisation” model.

In Figure 4 (a) and Figure4 (b), it is noteworthy

that, with network size 2500, the system activity beco-

mes more stable, showing less ﬂuctuation in the AN-

SET values than in a network size of 500 agents. Even

in the presence of signiﬁcant numbers of failures, the

HRP model achieves the highest average number of

successfully executed tasks. This is because, ﬁrst, the

higher the number of agents in the system the more

organisations can be created with a greater variety of

resources. Second, when failures occur in the system,

there are other agents which are able to join the net-

work structure and so can also join the existing orga-

nisations.

In Figure 5 (a), and Figure 5 (b), where increasing

the network size leads to there being higher numbers

of tasks executed within the simulation cycles: the

ANSET is more than with the other two network sizes

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

720

(2500, 500). In models Organisation Ver1 and HRP,

the created organisations consist of a large number

of heterogeneous agents, so even with the failure of

an agent the Head will probably still able to ﬁnd a

Member that can satisfy the required resources. Mo-

reover, the existence of the Henchman in the HRP has

added beneﬁt to the system.

(a) (b)

Figure 5: Average numbers of successfully executed tasks

computed across 7000 simulation cycles, p=0.9 and p=0.6.

6 EVALUATION OF THE HRP

MODEL

We have compared HRP with other methods from

the literature. The results from the HRP model with

network sizes (500, 2500, 5000). However, due to

the limited space we have included only the experi-

mental work of 5000 agents. were compared against

the master-standby system (Chen, 2007). The Master

(MAS)/standby (SBS) model is a fault tolerance mo-

del in which the system has two servers. The ﬁrst one

is called the MAS and all the clients are connected

to it. The second is called the SBS – the clients are

only connected to this when the MAS has failed. Furt-

hermore, there is a checking message transmitted be-

tween the MAS and the SBS which enables the SBS

to switch to active mode and serve the clients’ reque-

sts in place of a failed MAS. We have implemented

this architecture within our simulation set-up, and the

results are depicted in the following Figures:

(a) (b)

Figure 6: Average number of successfully executed task ra-

tio in/out organisations with probability p= 0.9 and p= 0.6.

In Figure 6 (a), and Figure 6 (b), we have com-

puted the number of executed tasks ratio, ANETR, in

relation to the following: various different required

accuracies; execution inside and outside of organisa-

tions; a network size of 5000 agents; and two pro-

babilities of failure – 0.9 and 0.6. As shown, a net-

work where HRP operates within organisations out-

performs the MAS/SBS model. This is because the

MAS/SBS model depends for its operation on its de-

legation process, and a smaller number of tasks have

been executed inside its organisations as a result of

the fact that this model has no structural roles such

as those in the HRP model’s organisations. Members

inside the organisations have roles and they can dele-

gate tasks to the Head

s of organisations that they are

part of. Also, the Head and the Henchman of an orga-

nisation each have a signiﬁcant role to perform within

it. However, in MAS/SBS the nodes delegate tasks to

other nodes in the emerged organisations, and if no

agent can accept the task the task will be delegated

across the network which consumes its T T L values.

7 RELATED WORK

Real world networks can consist of multi-layers that

can all be affected by unpredictable changes (disrup-

tions) in their structure (De Domenico et al., 2014).

Therefore, to investigate the tolerance to failure of our

system, we created three different models: the ﬁrst

is a straightforward network of agents model; the se-

cond model implements a virtual layer of organisati-

ons which provides a self-organised multi-agent and

the application of roles and protocols for the agents;

and the third is the HRP model.

In the literature, many studies have used bio-

inspired methods to solve NP hard problems be-

cause they are considered an appropriate mechanism

to study complex systems. In (Stamatopoulou et al.,

2004) studies have used bio-inspired, bird ﬂocking,

method in creating dynamic organisations of multi-

agents with the ability to reconﬁgure the system indi-

vidual connections. The authors have used two formal

mechanisms, ﬁrst P-systems (Nematollahi Mahani,

2012) with active members and second software en-

gineering communication language X-machines with

active membranes in order to model ﬂocking agents.

Agents can have various roles (leader, donor, incuba-

tor). The produced system is very complex and cannot

be animated.

Researches in (Dignum et al., 2004) have discus-

sed the different organisational structure: social or-

ganisations and emerging organisations; that can be

deployed to organise agents. They have also explai-

Dealing with Permanent Agent Failure in Dynamic Agents Organisations

721

ned how it is difﬁcult to describe at what point the

organisations may reorganise for better performance

and utilization but without showing any solution. In

our work the dynamic organisations may re-organise

because of agents failure which may lead to create

another organisation or participate in already existed

ones and with the aid of the HRP the task execution

output has increased.

Many works in literature, such as (Kota et al.,

2009) that use the agent organisations and the cre-

ated organisations reconﬁgured again depend on the

type of task been sent to the organisations without

claiming and type of technique that will lead to this

action of creation. Unlike our work the organisations

are created based on triggering conditions to provide

proactive solution to the failure case. In our work, the

created organisations have the ability to reconﬁgure

themselves as an occurrence with critical event (fai-

lure). Hence, organisations may be created or disban-

ded depending on the network real problems whatsoe-

ver are the types of coming tasks.

Researcher in (Ferber et al., 2003) presented a

method to reorganise organisations by applying a met-

hod that can be carried by the individual agents in the

system. A pair of agent can decide when to reorganise

and with whom they can create the new organisation

based on their utility values. The new connections

will not change the inner characteristic of agents. In

our work when new agents are added to the system

some new roles will emerge in the system. The update

to the already existed organisations can lead to better

performance since the new agents can be Henchman,

Member or they can be Heads of new organisations

when the triggering conditions met.

In (Mathieu et al., 2002) the authors have presen-

ted self-adaptation of a multi-agent systems for orga-

nisations. The dynamic interaction between agents

and their decision-making capabilities may lead to

either an agent decision to keep itself connected to its

organisation or change its connection for better per-

formance with other organisations. Aiming to reduce

the message ﬂow in the organisations to enhance the

system behaviour. In our work, agents may be added

to the system leading to update the existing connecti-

ons and enhancing the system output.

8 CONCLUSIONS

This paper focuses on studying the creation of open

and dynamic agent organisation formations which can

provide services to requesting customers in the pre-

sence of failure. This can lead to the loss of tasks

and to decreases in the effectiveness and utilisation

of agent networks. We have presented a framework

whereby agents and organisations can be counted on

to provide remedies which can avert these kinds of

disruptions. Our aim was to deploy the Henchman

Recovery Protocol. HRP, within each organisation;

this is a viable solution for maintaining the functio-

nality of the organisations. After that, we explore the

performance and stability of the created organisations

in the situation where we have agents malfunctioning

and others appearing. The new agents may simply be-

come part of existent organisations or their presence

may result in the emergence of new organisations.

Weeding out failure from distributed systems

requires sound theories and efﬁcient solutions that

can be applicable in order to maintain systems sta-

bilities (Bao and Garcia-Luna-Aceves, 2003),(Haider

and Nazir, 2016). Grid computing is the target dom-

ain for this work because it can provide researchers

with a suitable environment in which to apply our vir-

tual organisations as well as in which to study node

failure. Our solution is to apply a heuristic protocol,

HRP, in order to recover customer tasks and preser-

ves the organisations’ formation structure. HRP has

been shown to have a more acceptable performance

as compared to the MAS/SBS model. The existence

of roles inside the heterogeneous organisations plays

an important role in the self-organisation of the sy-

stems and provides a pro-active technique for dea-

ling with failure. The experiments have shown that

the HRP produces fewer trafﬁc messages than the

other models: (No Organisation, Organisation Ver1,

MAS/SBS). As part of future work, we will explore

adding the ability to learn to the agents in the emer-

ging organisations to explore how this can affect sy-

stem performance.

REFERENCES

AL-Karkhi, A. and Fasli, M. (2017). Deploying self-

organisation to improve task execution in a multi-

agent systems. In 2017 3rd IEEE International Con-

ference on Cybernetics (CYBCONF), pages 1–8.

Bao, L. and Garcia-Luna-Aceves, J. J. (2003). Topology

management in ad hoc networks. In Proceedings of

the 4th ACM international symposium on Mobile ad

hoc networking & computing, pages 129–140. ACM.

Bastian, M., Heymann, S., Jacomy, M., et al. (2009). Gephi:

an open source software for exploring and manipula-

ting networks.

Carroll, J. J. and Klyne, G. (2004). Resource description

framework ({RDF}): Concepts and abstract syntax.

Chen, C.-W. (2007). Dual redundant server system for

transmitting packets via linking line and method the-

reof.

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

722

De Domenico, M., Sol

e-Ribalta, A., G

omez, S., and Are-

nas, A. (2014). Navigability of interconnected net-

works under random failures. Proceedings of the Na-

tional Academy of Sciences, 111(23):8351–8356.

Dignum, M., Sonenberg, E., and Dignum, F. (2004). Dyna-

mic reorganization of agent societies. In Proceedings

of workshop on coordination in emergent agent socie-

ties.

Ferber, J., Gutknecht, O., and Michel, F. (2003). From

agents to organizations: an organizational view of

multi-agent systems. In International Workshop on

Agent-Oriented Software Engineering, pages 214–

230. Springer.

Foster, I. and Kesselman, C. (2003). The Grid 2: Blueprint

for a new computing infrastructure. Elsevier.

Haider, S. and Ansari, N. R. (2012). Temperature based

fault forecasting in computer clusters. In Multitopic

Conference (INMIC), 2012 15th International, pages

69–77. IEEE.

Haider, S. and Nazir, B. (2016). Fault tolerance in com-

putational grids: perspectives, challenges, and issues.

SpringerPlus, 5(1):1991.

Hayashi, H. (2017). Comparing repair-task-allocation stra-

tegies in mas. In Proceedings of the 9th Internatio-

nal Conference on Agents and Artiﬁcial Intelligence -

Volume 1: ICAART,, pages 17–27. INSTICC, SciTe-

Press.

Kota, R., Gibbins, N., and Jennings, N. R. (2009). Self-

organising agent organisations. In Proceedings of The

8th International Conference on Autonomous Agents

and Multiagent Systems-Volume 2, pages 797–804. In-

ternational Foundation for Autonomous Agents and

Multiagent Systems.

łgorzata Steinder, M. and Sethi, A. S. (2004). A survey

of fault localization techniques in computer networks.

Science of computer programming, 53(2):165–194.

Mathieu, P., Routier, J.-C., and Secq, Y. (2002). Dynamic

organization of multi-agent systems. In Proceedings

of the ﬁrst international joint conference on Autono-

mous agents and multiagent systems: part 1, pages

451–452. ACM.

Nematollahi Mahani, M. (2012). Strategic structural reor-

ganization in multi-agent systems inspired by social

organization theory. PhD thesis, University of Kan-

sas.

Serugendo, G. D. M., Gleizes, M.-P., and Karageorgos, A.

(2011). Self-organising software: From natural to ar-

tiﬁcial adaptation. Springer Science Business Media.

Stamatopoulou, I., Gheorghe, M., and Kefalas, P. (2004).

Modelling dynamic organization of biology-inspired

multi-agent systems with communicating x-machines

and population p systems. In International Workshop

on Membrane Computing, pages 389–403. Springer.

Dealing with Permanent Agent Failure in Dynamic Agents Organisations

723
