Distributed Kanban with Limited Geographical Distance: Analyzing

Lean Principles Pull, Work in Progress and Kaizen

Raoul Vallon, Stefan Strobl, Martin Ras, Mario Bernhart and Thomas Grechenig

Research Group for Industrial Software, Vienna University of Technology, Vienna, Austria

Keywords:

Software Development Methodologies, Distributed Software Development, Kanban, Lean, Software Process

Improvement.

Abstract:

Although the software development methodology Kanban, which refers and relates to the concepts and ideas

of Lean Manufacturing originating in the Japanese automobile industry, was initially developed and used

within distributed teams, correlating research is lacking, incomplete and relatively young as a ﬁeld. This paper

addresses the need for research in this ﬁeld and investigates three speciﬁc aspects of Kanban in distributed

teams: Pull System, Work In Progress Limit and the concept of Kaizen culture (continuous improvement)

narrowed by the distribution, size and life cycle of the team. Our qualitative methodology is based on a case

study where empirical data was collected through the use of semi-structured expert interviews. The evaluative

strategy is qualitative content analysis. The results of this study show that challenges and complications result

from the use of Kanban, but it is effective within distributed teams. The observed challenges are discussed

in detail and we conclude with eight recommendations for practicing Kanban in a distributed team as well as

indicators for future research directions.

1 INTRODUCTION

In 2001 Kent Beck et al. created the foundations

of today’s agile practices with the ”Agile Manifesto”

(Beck et al., 2001). Scrum is probably the most

prominent representative of this group of approaches.

However, in parallel Poppendieck and Poppendieck

(Poppendieck and Poppendieck, 2003) started bor-

rowing ideas from Lean Manufacturing practices and

adapting them to the ﬁeld of software engineering.

Based on this work David J. Anderson pioneered the

Kanban (Anderson, 2010) methodology in the mid

2000s.

In addition to the evolution of software develop-

ment processes the typical consistency of a develop-

ment team also changed fundamentally. Distributed

teams, frequently over multiple locations, are already

a common reality (Ebert, 2001). However, while there

has been signiﬁcant research on distributed Scrum

with multiple case studies and experience reports

(Jalali and Wohlin, 2010; Paasivaara and Lassenius,

2011; Kajko-Mattsson et al., 2010; Dorairaj and No-

ble, 2013; Smite et al., 2010) on both applicability and

limitations, this is not the case for distributed Kanban.

Vallon et al. have conducted a systematic literature re-

view for the time range of 2010 to 2016 ﬁnding only

8 examples of Kanban in a distributed environment,

contrasting with 53 representing Scrum (Vallon et al.,

2018).

Based on the identiﬁed lack of research in the

ﬁeld, the main motivation of the work presented in

this paper is exploratory research to ﬁnd out if and

how Kanban can be applied in a distributed organiza-

tional environment. As a ﬁrst step towards that end,

the objective of this paper is to analyze lean principles

Pull, Work in Progress (WIP) and Kaizen (continuous

improvement) using Distributed Kanban with teams

working in a limited geographical distance.

2 BACKGROUND

The origins of Kanban can be traced back to the lean

production practices implemented at Toyota in the

1940s and 1950s developed by Taiichi Ohno (Ohno,

1988). The basic idea behind the concept is to pro-

duce only exactly what is needed at the time when it is

needed (Leopold and Kaltenecker, 2013). To achieve

this, all forms of waste have to be eliminated.

Based on these foundations and ideas Pop-

pendieck and Poppendieck (Poppendieck and Pop-

pendieck, 2003) developed with their ”agile toolkit”

210

Vallon, R., Strobl, S., Ras, M., Bernhart, M. and Grechenig, T.

Distributed Kanban with Limited Geographical Distance: Analyzing Lean Principles Pull, Work in Progress and Kaizen.

DOI: 10.5220/0007626302100217

In Proceedings of the 14th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2019), pages 210-217

ISBN: 978-989-758-375-9

a software development methodology, with the goal

of eliminating waste and bureaucracy and establish-

ing a continuous learning and improvement processes

through short iterations, regular feedback and fre-

quently delivered product increments. Over-boarding

planning and written requirements on the other hand

were to be limited (Poppendieck and Cusumano,

2012).

David J. Anderson can be seen as inventor of

the modern Kanban software development process,

which he successfully implemented at Microsoft (An-

derson and Dumitriu, 2005). Anderson describes the

process as an evolutionary system to enable change

which uses a Kanban based pull system, visualiza-

tion and further tools. Kanban therefore achieves

a context-speciﬁc process optimization, minimizing

friction and opposition to change by introducing

change in small increments (Anderson, 2010).

3 RELATED WORK

Tanner and Dauane (Tanner and Dauane, 2017) per-

formed a study with the focus on application of Kan-

ban principles to alleviate the challenges and prob-

lems in communication and collaboration imposed by

GSD. A main contribution was the highlighting of the

Kanban board as a central tool for communication

as well as creating transparency regarding progress,

shifting priorities and changing requirements. In ad-

dition it was noted that rules for communication had

to be formalized.

The three evaluated case studies and ﬁve experi-

ence reports have contributed the following main ﬁnd-

ings:

Kanban is seen as a metabolism for naturally

fostering change and continuous improvement (Ma-

jchrzak and Stilger, 2017). However the introduction

of Kanban in general needs the commitment of all in-

volved stakeholders including management as well as

an open environment (Prochazka et al., 2011). Teams

need the necessary level of empowerment to function

properly and to be able to solve challenges on its own.

However this can also be a major motivational factor

for individual team members (Govindaraj and Tadipa-

tri, 2011). In general obstacles have to be addressed

rapidly in order to avoid blockades (Paasivaara et al.,

2014). Shorter time to market or release cycles can

be the most tangible results of introducing Kanban

(Viswanath, 2014).

An electronic Kanban board is a must in a dis-

tributed environment. It helps to make progress vis-

ible and positively reinforces participation (Tripathi

et al., 2015). Centralized, electronic documentation

furthermore facilitates communication and prioritiza-

tion of work items.

The WIP limit imposes a major challenge when

introducing Kanban. It requires both compromise and

continuous improvement to adjust to the speciﬁc local

setting (Tripathi et al., 2015).

Finding a communication strategy that ﬁts both

the individuals and the corporate culture is a must

(Bocock and Martin, 2011). In a distributed environ-

ment the distance needs to be minimized by utiliz-

ing technical aids like video-conferencing. However,

whenever possible, face to face communication, also

in an informal context, are invaluable assets and nec-

essary to build trust.

Waste should be addressed both preemptively (e.g.

pre-implementation call) or retro-actively (e.g. Code

Reviews). The latter is also a key technique for

knowledge transfer. Highly prioritizing code review

tasks has the beneﬁt of keeping feedback cycles short

therefore reducing the need for context switches (Moe

et al., 2015; Bocock and Martin, 2011). Pair program-

ming and actively encouraging team members to take

on tasks from other areas can be seen as an investment

in a more even knowledge distribution.

4 CASE STUDY

Based on the previous sections, we formulate our re-

search objective, case study design and provide back-

ground on the units of analysis.

4.1 Research Objective

As shown in Section 3 available research into Kanban

in a distributed setting is limited to one study, three

case studies and ﬁve experience reports. To achieve

the necessary depth, the scope of the research has to

be limited in terms of selecting cases and principles

of Kanban.

The selection criteria for Kanban teams starts

with their location and distribution. Only teams

with a distance classiﬁcation of Onshore-Insourcing-

Close-Similar, Onshore-Insourcing-Distant-Similar

and Offshore-Insourcing-Near-Small (

Smite et al.,

2014) are selected to minimize the effect of travel

times, time differences and cultural distance. At least

25% of the team members have to be distributed. The

size of a team has to be between 7 and 15 members

to eliminate anomalies by sub-optimal team sizes

(Rodr

ıguez et al., 2012).

Concerning the Kanban software development

process in place the following criteria are applied: A

Kanban board has to be present and accessible from

Distributed Kanban with Limited Geographical Distance: Analyzing Lean Principles Pull, Work in Progress and Kaizen

211

all locations. A pull principle has to be in place. At

least one of the process steps needs to have a WIP

limit in place. While elements of other agile method-

ologies might be present, the key characteristics of

Kanban need to be preserved. Neither the presence

of a Kaizen culture nor the usage of the term Kaizen

itself can be strictly enforced. However regular mea-

sures for process improvements must take place.

Kanban is deﬁned by a set of six fundamental

principles (shown here in abbreviated form) from

which the following aspects can be derived (Ander-

son, 2010; Hammarberg and Sunden, 2014).

1. Visualization

2. Work In Progress

3. Manage Flow

4. Make Policies Explicit

5. Implement Feedback Loops

6. Improve collaboratively, evolve experimentally,

using models and the scientiﬁc method

The individual aspects are evaluated against the fol-

lowing criteria to decide if they should be in the scope

of this research:

1. Distributed teams are confronted and have to

solve challenges imposed by distance that are not

present in collocated environments.

2. The aspect has to have a direct effect on the work

and behaviour of the individual team members.

The aspect Kanban board can be excluded because

of the existence of prior research (Tanner and Dauane,

2017). The aspects performance indicators, evalua-

tion of improvement and customer feedback only af-

fect the team indirectly or in a differed manner and

can therefore be excluded as well. Having explicit

rules rather supports than imposes challenges on dis-

tributed teams. This results in the selection of pull

principle, WIP limits and continuous improvement

(Kaizen culture) as the aspects for in-depth evalua-

tion.

We deﬁned a research question to cover each as-

pect as well as a set of propositions for further reﬁne-

ment. The propositions have been designed with the

possibility of falsiﬁcation in mind under the follow-

ing general hypothesis: The Kanban method can be

applied for distributed teams in a setting with limited

geographic distance without negative effect.

RQ 1: What are the challenges and possible mit-

igations of applying the pull principle in distributed

teams?

RP 1.1: In distributed teams the pull principle re-

quires communication when taking over a task from

the previous steps.

RP 1.2: The communication over distance does

not have a negative effect on the application of the

pull principle.

RQ 2: What are the challenges and possible miti-

gation of deﬁning WIP limits in distributed teams?

RP 2.1: For setting a WIP limit distributed teams

have to ﬁnd their own equation.

RP 2.2: The application of a WIP limit on indi-

vidual process steps depends on the task at hand, the

process design and the team composition.

RP 2.3: A change in the composition of the dis-

tributed team affects the WIP limits

RQ 3: What are the challenges and possible miti-

gation of establishing a Kaizen culture in distributed

teams?

RP 3.1: The establishment of a Kaizen culture

does not follow a predeﬁned rule-set.

RP 3.2: Trust between team members, superiors

and in the organization itself are fundamental require-

ments for the establishment of a Kaizen culture.

RP 3.3: Open and direction communication are

necessary preconditions for a Kaizen culture.

RP 3.4: The distance in communication does not

have a negative effect on a Kaizen culture.

4.2 Case Study Design

The case study in this paper was designed after the

guidelines and recommendations by Runeson et al

(Runeson et al., 2012). It has both a descriptive as

well as exploratory research purpose. We are look-

ing at a total of four cases which have been selected

according to the criteria as laid out in Section 4.1.

The goal of this case study is to obtain insights on

how the previously mentioned three aspects of Kan-

ban are applied in a distributed setting. In addition

perceived challenges and proposed solutions are to be

analyzed. Distilled from these ﬁndings a set of rec-

ommendations for future applications of Kanban in

similar settings are to be elaborated.

The case study has been designed as an embed-

ded, single case study with the context of applying

selected aspects of Kanban in distributed software de-

velopment teams. The units of analysis are the indi-

vidual, distributed software development teams. The

case study design and applied research in this paper

allows us to falsify the research propositions by ﬁnd-

ing counter examples. A proof of general applicabil-

ity of the propositions on the other hand is not possi-

ble with the limited data set available.

The data collection is primarily based on the exe-

cution of semi-structured interviews representing ﬁrst

degree contact as deﬁned by Lethbridge et al. (Leth-

bridge et al., 2005). The semi-structured nature of the

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

212

interviews was chosen to account for the exploratory

part of the research. In addition the Kanban board and

here especially the general structure of the board is

used as a complementary data source. The interview

guideline was developed based on the research ques-

tions and propositions. It begins by inquiring about

team composition and distribution and how Kanban

has been implemented at this organization. In the

main part it focuses on the selected aspects of Kanban

and goes into detail there. Interviews were conducted

in German language, therefore the interview guideline

as well as the transcripts were also written in German.

The units of analysis were contacted through one

of two means. Direct contact was established through

exhibitions, conferences and user groups. Other orga-

nizations were reached through contacting them on-

line. Pre-selection here was done by ﬁnding com-

panies with job postings for software developers for

different locations. A total of 97 organizations were

contacted, out of which four were part of the ﬁnal se-

lection. The overall response rate was 13%.

The data analysis was done applying a structur-

ing technique described by Mayring (Mayring, 2015)

to inductively create categories. However the pro-

cess was adjusted to the individual needs of this study.

The transcribed interviews were then coded with a set

of a priori deﬁned keywords. Additional key words

were added during the analysis as more insights were

gained. The coding was therefore done iteratively.

Due to the relatively small set of raw data the cod-

ing was done entirely manually. The main categories

were Kanban process design, continuous improve-

ment, pull principle, WIP limits and communication

and trust. Among all ﬁve of them there were a total of

36 key words. Figure 1 illustrates the coding process

described by example of the Kanban Process Design.

Table 1 gives an overview of the units of analysis.

4.3 Alpha

Alpha specializes in business process digitaliza-

tion and provides software products and services to

achieve their digital transformation goals. Software

development is therefore primarily project driven.

The composition of the teams also varies depending

on the individual projects needs. The main work item

is called story and is handled in a 3 level stage-gate-

process. The levels are conception, development and

acceptance. The current progress is visible through

an electronic Kanban board. A short daily standup

is conducted each day utilizing a video conferencing

solution.

Kanban Process

Design

Kanban board*

Agile techniques

Backlog

Team self-organisation

Daily standup

Continuous

Improvement

Work environment*

Improvement

Corporate culture*

Retrospective

Feedback

Hierarchy

Process knowledge

Communication

and Trust

Events encouraging

communcation

Communication*

Communication channel*

Language*

Face-to-Face Meeting*

Behavior

Coordination*

Trust*

Qualification

Continuing education

On-Boarding

Corporate event

Virtual event

Pull Principle

Pull Principle*

Documentation*

Requirements

Knowledge transfer*

WIP Limit

Process costs

Commitment

Process design

Pro / Contra Kanban

WIP Limit*

Blockade

Kaizen

Term "Kaizen"

Kanban board

Extension through

agile techniques

WIP formula

Retrospective

Continuing education

Communication

channels

Team building*

Events building trust

WIP formula

Figure 1: Code words and categories for Kanban process

design.

4.4 Beta

Beta is an agency specialized in e-commerce.

Through a merger the agency now has ﬁve locations

across two countries. Teams size and composition

is geared towards the current project and therefore

varies between ﬁve and 11 members. Again a three

level process is used with development preceded by

an analysis phase and concluded by a delivery stage.

Daily stand ups are done using video conferencing,

retrospectives on an ”as needed” basis. The Kanban

board exists in electronic form.

4.5 Gamma

Gamma is a highly specialized system provider com-

bining hardware and software development to provide

optimal, integrated solutions to both government and

industrial customers. Out of a total of 19 locations

across three countries, 2 are mainly focused on soft-

ware development. Teams are either focused on prod-

uct development or customization for individual cus-

tomers, which affects both team composition and life

span. The interview was done with a group of two in-

dividuals (P1, P2), one heading product development,

the other a team lead for two development teams with

a team size of 10 to 12. A Zero-Bug-Policy with a

dedicated swim lane ensures bugs are prioritized over

feature development. The board only exists in elec-

tronic form.

Distributed Kanban with Limited Geographical Distance: Analyzing Lean Principles Pull, Work in Progress and Kaizen

213

Table 1: Overview of the units of analysis.

Unit of Analysis Role Interviewee Team Size

Locations

(Countries)

Distribution

Alpha Agile Coach, Scrum Master 4 to 9 2 (2) variable

Beta CEO, Business Unit Manager 5 to 11 5 (2) variable

Gamma P1: Divisional Head; P2: Team Lead 10 to 12 2 (1) 30% : 70%

Delta Agile Coach, Scrum Master 6 to 11 2 (1) variable

4.6 Delta

Delta provides individualized solutions in the ﬁelds of

e-commerce and digital marketing. There are an av-

erage of three times distributed over two locations in

one country with a varying team size of six to 11. A

preparation phase with detailed analysis of the work

items precedes development. Team members individ-

ually subdivide work items into tasks in the electronic

Kanban board. This allows team members with spe-

cialized skills to work in their area of expertise. Both

daily stand ups and retrospectives are held.

5 RESULTS

Based on the responses from our units of analysis we

will now try to falsify our research propositions and

answer the research questions. Subsequently we dis-

cuss the threats to validity.

5.1 Research Propositions

RP 1.1: All interviewees conﬁrmed the need for thor-

ough and detailed documentation, speciﬁcation and

requirements analysis to make the pull principle work

in practice. This avoids additional round trips in di-

rect communication as well as down times through

blockades. This reduces the overall communication

overhead and avoids misunderstandings. However

the additional effort and cost for preparing this infor-

mation should not be disregarded. Structuring work

items into ﬁne grained tickets in the electronic issue

tracking system helps create transparency in terms of

progress and problem areas. It also facilitates commu-

nication through comments and enables traceability in

the form of linking the discussion to a speciﬁc issue.

Other observed methods of communication were in-

stant messaging, phone calls and video calls. This

proposition was not falsiﬁed by our observations.

RP 1.2: The pull principle requires communica-

tion when taking over a task from the previous step.

Communication is facilitated through instant messag-

ing and video telephony as well as screen sharing sys-

tems. The electronic Kanban board enables traceabil-

ity and makes transparent who was responsible for

which step. The negative effect of distance on com-

munication has been proven by the empirical data. A

good ﬂow of communication can only mitigate these

effects. This proposition has therefore been falsiﬁed.

RP 2.1: All units of analysis set their WIP limit

through mathematical equations. Alpha and Beta only

take the team size as a variable into account. Gamma

also tries to reﬂect pair programming and Delta gives

its teams more liberty by not imposing a limit on sub

tickets. With the collected data the proposition was

not falsiﬁed.

RP 2.2: All of the interviewed organizations limit

the amount of tasks that are actively being developed.

Only two units (Gamma and Delta) also limit subse-

quent process steps in quality assurance to ensure is-

sues identiﬁed by quality assurance are rectiﬁed in a

timely manner. One subject also indicates that WIP

limit are dynamically adjusted if a speciﬁc work item

requires such a step. The proposition can therefore

not be falsiﬁed.

RP 2.3: Long term changes in the teams compo-

sition are reﬂected in the WIP limit in all cases. Short

team absences like sickness or holidays and additions

(e.g. reﬂecting a specialized need) do not trigger a

change in the WIP limit. Therefore the proposition

can not be falsiﬁed.

RP 3.1: All units of analysis conduct regular ret-

rospectives as well as daily, short exchanges. Alpha

and Delta see ﬂat hierarchies as the main enabler for

a Kaizen culture. Gamma sees beneﬁts in an open

and informal atmosphere and company culture. Beta

has a slightly different view with two dedicated roles

agile coach and development lead at each location re-

sponsible for detecting and mitigating process related

respectively technical issues. Apart from meeting on

a regular basis no rule-set was elicited, therefore this

proposition was not falsiﬁed.

RP 3.2: All units of analysis have measures in

place to nurture trust. New hires are supported by

a multi-week on-boarding process (Alpha, Gamma,

Delta). Delta has designated, local points of con-

tact for every employee to facilitate personal commu-

nication. All cases furthermore enable face to face

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

214

meetings of all contacts. This can be in the form of

workshops (Alpha, Gamma) at one location or com-

pany events (Beta, Delta). Apart from building trust

these measures are designed to facilitate communica-

tion and sometimes also to incentivize. This proposi-

tion was not falsiﬁed.

RP 3.3: Direct personal communication is stated

as a key enabler for trust and building long term re-

lationships. However since meetings in person are

not always possible and do incur signiﬁcant cost in

a distributed environment, additional events are held

to mitigate. Beta and Delta do hold regular events

presenting news and innovations to their employees.

Beta, in addition, enables all employees to participate

in events with a focus on technical exchange and shar-

ing of experiences. The data shows that all partici-

pants recognize the need to support direct communi-

cation. Therefore the proposition cannot be falsiﬁed.

RP 3.4: All units of analysis see the need to take

additional measures to facilitate direct communica-

tion to mitigate a perceived negative effect due to the

distributed nature of their team setups. Digital direct

communication like instant messaging and video or

audio conferencing are not seen as fully equivalent.

This proposition can therefore be regarded as falsi-

ﬁed.

5.2 Research Questions

RQ 1: The main challenge in applying the pull princi-

ple is to provide sufﬁcient amounts of information and

detail about each task for the team to be able to do its

work. All units of analysis have therefore established

a preceding speciﬁcation and analysis phase with a

strong focus on written artifacts which concludes with

a joint meeting to present the planned feature to all

participants. The ﬂow of information during handover

between individual steps is another challenge. Apart

from the documentation produced by the initial phase

a key mitigation strategy is the consistent use of the

electronic Kanban board and the underlying ticket-

ing system to provide a history for each work item.

We observed that some units saw beneﬁcial value in

letting the team break down a work item into indi-

vidual tasks by themselves. Apart from a stronger

personal ownership of the resulting tasks the structur-

ing was optimized towards the teams distributed com-

position to minimize communication over distance.

However, although the amount of necessary commu-

nication can be reduced by above-mentioned mea-

sures, direct communication is a key ingredient for

successfully applying the pull principle. Eliminating

it might rapidly lead to the creation of local silos with

all associated issues.

RQ 2: Three main challenges were identiﬁed.

First the team needs to decide which steps of the

process actually need limits to ensure a continuous

ﬂow of work items and this avoid bottlenecks. Sec-

ond the composition of the teams concerning the in-

dividual skills is a key factor with respect to the ﬁrst

challenge. If a skill is rare, a higher limit might be

needed to ensure ﬂow. If on the other hand a task can

be done by the majority of team members (e.g. re-

views) a low limit can ensure timely execution of cer-

tain tasks. Third a correlation with established work

patterns (e.g. pair programming) needs to be reﬂected

when setting the WIP limit. On a related matter the

granularity of the work items also has a direct effect

on the limit. Lower granularity requires lower lim-

its, higher granularity might warrant more generous

limits. As all these challenges are interdependent, a

formula and ﬁne-tuning through experimentation is

necessary to achieve good results in each individual

case.

RQ 3: Open and direct communication and trust

can be seen as preconditions for establishing a Kaizen

culture. Distance impedes both and therefore counter-

measures are necessary. These can range from com-

pany events, over technical exchanges to technolog-

ically supported communication and additional pos-

sibilities for employee training. Retrospectives and

daily standups are established tools in distributed soft-

ware development to foster a Kaizen culture. These

tools establish a setting where perceived problems

can openly be discussed. However it is important

to also facilitate direct follow up communication to

make sure identiﬁed issues are being understood and

addressed properly by all sides.

5.3 Threats to Validity

To ensure internal validity different approaches for

analysis have been applied as recommended by Tan-

ner and Dauane (Tanner and Dauane, 2017) by em-

ploying a cross-case result analysis, grouping and

comparing the data from multiple sources. The ex-

ternal validity is limited by the constraints employed

while selecting the cases. Therefore the presented

results cannot be fully generalized to all distributed

software development settings. In addition using job

postings to select the units of analysis might intro-

duce a bias towards settings with a high degree of

employee ﬂuctuation. Furthermore three out of four

units of analysis are working in the ﬁeld of contract

work resulting in relatively short project duration and

therefore frequent team transformations. Cultural dif-

ferences have been mostly eliminated by the choice

of limitations in distance. Finally although recom-

Distributed Kanban with Limited Geographical Distance: Analyzing Lean Principles Pull, Work in Progress and Kaizen

215

mended otherwise (Mayring, 2015), the interviews

and subsequent coding had to be conducted by a sin-

gle person due to limitations of the research team

setup at the time of execution.

6 RECOMMENDATIONS

The answers to our research questions in the previous

section have provided possible solutions to a series

of challenges. From these results we can derive the

following recommendations:

(1) Carefully analyze and thoroughly document

upcoming work items. This will ensure proper ﬂow

through the process stages by pull principle and avoid

additional, late communication overhead. Compre-

hensive documentation is a welcomed side product.

(2) Allow self organizing teams. If the team has

the ability to break down work items into tasks by it-

self and decide their distribution, the amount of tran-

sitions can be reduced. This requires well qualiﬁed

and empowered team members.

(3) Apply WIP limits cautiously. Only apply lim-

its where needed, primarily factoring in team size, but

also observing established practices and patterns of

work distribution.

(4) Utilize technology to disseminate information.

Communication in a distributed environment is hard.

Technology can help overcome some of these ob-

stacles. A mix of an electronic Kanban board and

synchronous as well as asynchronous communication

technology is highly recommended.

(5) Enable the team to communicate outside of

the process context. Targeted measures to facilitate

communication outside of the day to day develop-

ment context in the form of informal or special topic

events will lower the barrier for initiating communi-

cation and help foster trust.

(6) Enable continuing education as part of contin-

uous improvement. Employees will contribute more

when they get the time and opportunity to critically

reﬂect on established practices by obtaining outside

views. Done in groups educational measures can also

be seen as events outside of the development context.

(7) Apply retrospectives modestly and purpose-

fully. Depending on the maturity of the team and

their individual drive to continuous improvement ret-

rospectives might be needed regularly or just occa-

sionally.

(8) Regard the corporate culture as the counterpart

to continuous improvement. We observed an open

culture and ﬂat hierarchies as the primary enablers for

continuous improvement. Both should encourage the

team members to speak up and address problems as

they arise.

7 CONCLUSION

Kanban as proposed by Anderson has roots in a dis-

tributed environment. However established literature

hardly takes note of distributed settings even though

the current global setting increasingly demands glob-

ally distributed software development setups. Dis-

tance on a cultural, temporal as well as geographi-

cal level impose additional challenges in these sce-

narios. The main research goal of this work is the

investigation of applied Kanban in a distributed envi-

ronment limited to the aspects of pull principle, Work

in Progress limits and Kaizen culture. Based on ex-

tensive research of the current state-of-the-art in dis-

tributed Kanban, a case study was designed and ex-

ecuted with a total of four units of analysis. The

main source of empirical data were a series of semi-

structured interviews.

All three selected aspects need good communi-

cation and established trust as a basis. Most chal-

lenges as well as the resulting recommendations re-

volve around this topic. Mitigating action like addi-

tional team events, a sophisticated on-boarding or ad-

ditional communication technology are necessary to

counteract the negative effects of distance. Empow-

ering the teams and individual members is another

crucial aspect to successfully applying Kanban in a

distributed environment. A Kaizen culture of contin-

uous improvement, although not commonly used as

a term, is consistently present and understood as one

of the main motivations and drivers behind applying

a lean development approach.

Overall the case study has shown that Kanban and

speciﬁcally the selected aspects of pull principle, WIP

limits and Kaizen culture are being successfully ap-

plied in a distributed environment. However the chal-

lenges around communication, omnipresent in soft-

ware development projects, are ampliﬁed by team dis-

tribution and therefore need additional attention to

mitigate negative effects.

One direction of future research is to eliminate

the self-imposed limitations introduced in this work

to ensure wider applicability. Additional cases and

quantitative studies are required to further validate

and reﬁne the results of this case study. Furthermore

two cases have indicated observations that Kanban

projects are perceived to be more cost-effective than

projects applying Scrum. Research is needed to ﬁnd

out if there is actual correlation or if this is a side ef-

fect of the speciﬁc projects selected for a Kanban de-

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

216

velopment methodology.

REFERENCES

Anderson, D. J. (2010). Kanban: successful evolutionary

change for your technology business. Blue Hole Press,

e-book edition.

Anderson, D. J. and Dumitriu, D. (2005). From Worst to

Best in 9 Months: Implementing a Drum-Buffer-Rope

Solution in Microsoft’s IT Department. Barcelona.

Beck, K., Beedle, M., Bennekum, A. v., Cockburn, A., Cun-

ningham, W., and Fowler, M. (2001). Manifesto for

Agile Software Development.

Bocock, L. and Martin, A. (2011). There’s Something about

Lean: A Case Study. In 2011 Agile Conference, pages

10–19.

Dorairaj, S. and Noble, J. (2013). Agile Software Devel-

opment with Distributed Teams: Agility, Distribution

and Trust. Nashville, Tennessee, USA. IEEE.

Ebert, C. (2001). Global Software and IT: A Guide to Dis-

tributed Development, Projects, and Outsourcing. Wi-

ley.

Govindaraj, S. and Tadipatri, S. (2011). Use of Kanban in

Distributed Offshore Environments. Cutter IT Jour-

nal, 24:29–33.

Hammarberg, M. and Sunden, J. (2014). Kanban in Action.

Manning.

Jalali, S. and Wohlin, C. (2010). Agile Practices in Global

Software Engineering - A Systematic Map. Princeton,

New Jersey, USA. IEEE.

Kajko-Mattsson, M., Azizyan, G., and Magarian, M. K.

(2010). Classes of Distributed Agile Development

Problems. Orlando, Florida. IEEE.

Leopold, K. and Kaltenecker, S. (2013). Kanban in der IT -

eine Kultur der kontinuierlichen Verbesserung schaf-

fen. Hanser M

unchen, 2. auﬂ. edition.

Lethbridge, T. C., Sim, S. E., and Singer, J. (2005). Study-

ing Software Engineers: Data Collection Techniques

for Software Field Studies. Empirical Software Engi-

neering, 10(3):311–341.

Majchrzak, M. and Stilger, L. (2017). Experience Re-

port: Introducing Kanban Into Automotive Software

Project. e-Informatica Software Engineering Journal,

11(1):41–57.

Mayring, P. (2015). Qualitative Inhaltsanalyse: Grundla-

gen und Techniken. Beltz, Weinheim, 12 edition.

Smite, D., Wohlin, C., Galvin¸a, Z., and Prikladnicki, R.

(2014). An empirically based terminology and taxon-

omy for global software engineering. Empirical Soft-

ware Engineering, 19(1):105–153.

Moe, N. B., Cruzes, D. S., Dyb

a, T., and Engebretsen, E.

(2015). Coaching a Global Agile Virtual Team. In

2015 IEEE 10th International Conference on Global

Software Engineering, pages 33–37.

Ohno, T. (1988). Toyota Production System: beyond large-

scale production. Cambridge.

Paasivaara, M., Behm, B., Lassenius, C., and Hallikainen,

M. (2014). Towards Rapid Releases in Large-Scale

XaaS Development at Ericsson: A Case Study. In

2014 IEEE 9th International Conference on Global

Software Engineering, pages 16–25.

Paasivaara, M. and Lassenius, C. (2011). Scaling Scrum in

a Large Distributed Project. Banff, Alberta, Canada.

IEEE.

Poppendieck, M. and Cusumano, M. A. (2012). Lean

Software Development: A Tutorial. IEEE Software,

29(5):26–32.

Poppendieck, M. and Poppendieck, T. (2003). Lean Soft-

ware Development: An Agile Toolkit. Addison Wes-

ley.

Prochazka, J., Kokott, M., Chmelar, M., and Krchnak, J.

(2011). Keeping the Spin – From Idea to Cash in

6 Weeks: Success Story of Agile/Lean Transforma-

tion. In 2011 IEEE Sixth International Conference on

Global Software Engineering, pages 124–130.

Rodr

ıguez, D., Sicilia, M. A., Garc

ıa, E., and Harrison, R.

(2012). Empirical ﬁndings on team size and produc-

tivity in software development. Journal of Systems

and Software, 85(3):562 – 570.

Runeson, P., Host, M., Rainer, A., and Regnell, B. (2012).

Case Study Research in Software Engineering: Guide-

lines and Examples. Wiley.

Smite, D., Moe, N. B., and

Agerfalk, P. J. (2010). Agility

Across Time and Space. Springer-Verlag Berlin Hei-

delberg.

Tanner, M. and Dauane, M. (2017). The use of Kanban to

alleviate collaboration and communication challenges

of global software development. Issues in Inform-

ing Science and Information Technology Education,

14:177–197.

Tripathi, N., Rodr

ıguez, P., Ovais Ahmad, M., and Oivo, M.

(2015). Scaling Kanban for Software Development

in a Multisite Organization: Challenges and Potential

Solutions. In Agile Processes in Software Engineering

and Extreme Programming, pages 178–190. Springer

International Publishing.

Vallon, R., Est

acio, B. J. d. S., Prikladnicki, R., and

Grechenig, T. (2018). Systematic literature review on

agile practices in global software development. Infor-

mation and Software Technology, 96:161–180.

Viswanath, U. (2014). Lean Transformation: How Lean

Helped to Achieve Quality, Cost and Schedule: Case

Study in a Multi Location Product Development

Team. In 2014 IEEE 9th International Conference on

Global Software Engineering, pages 95–99.

Distributed Kanban with Limited Geographical Distance: Analyzing Lean Principles Pull, Work in Progress and Kaizen

217
