Enhancing Knowledge Graphs with Data Representatives

Andr

e Pomp

, Lucian Poth

, Vadim Kraus

and Tobias Meisen

Institute of Information Management in Mechanical Engineering, RWTH Aachen University, Aachen, Germany

Computer Science, RWTH Aachen University, Aachen, Germany

Chair of Technologies and Management of Digital Transformation, University of Wuppertal, Wuppertal, Germany

Keywords:

Semantic Model, Knowledge Graph, Ontologies, Semantic Similarity, Machine Learning.

Abstract:

Due to the digitalization of many processes in companies and the increasing networking of devices, there is

an ever-increasing amount of data sources and corresponding data sets. To make these data sets accessible,

searchable and understandable, recent approaches focus on the creation of semantic models by domain experts,

which enable the annotation of the available data attributes with meaningful semantic concepts from knowl-

edge graphs. For simplifying the annotation process, recommendation engines based on the data attribute

labels can support this process. However, as soon as the labels are incomprehensible, cryptic or ambiguous,

the domain expert will not receive any support. In this paper, we propose a semantic concept recommendation

for data attributes based on the data values rather than on the label. Therefore, we extend knowledge graphs

to learn different dedicated data representations by including data instances. Using different approaches, such

as machine learning, rules or statistical methods, enables us to recommend semantic concepts based on the

content of data points rather than on the labels. Our evaluation with public available data sets shows that

the accuracy improves when using our ﬂexible and dedicated classiﬁcation approach. Further, we present

shortcomings and extension points that we received from the analysis of our evaluation.

1 INTRODUCTION

Growing digitalization in companies results in an in-

creasing amount of generated data. For using the

potential of machine learning approaches and realiz-

ing visions such as the Internet of Production (IoP)

(RWTH Aachen University, 2017), which pursues

the goal of guaranteeing the availability of (applica-

tion dependant) real-time information at any time and

place, companies start to collect and store these data

sets. With growing amounts of sensors and applica-

tions within a production facility, such visions will

lead to an improved quality management as goods can

be checked much faster, easier and more reliably in

the production line (Li et al., 2017).

In order to store and process the generated amount

of data, recent solutions rely on data lakes, which al-

low to store structured and unstructured data by fol-

lowing a schema-on-read approach. Compared to pre-

vious approaches like data warehouses, data lakes of-

fer the ﬂexibility that modern data analytics and ma-

chine learning processes require. However, to en-

able data scientists to access, ﬁnd and understand the

stored data sets, metadata has to be created for every

data set as there exists no global schema like in data

warehouses. (Terrizzano et al., 2015) propose to use

a curated data lake where the data does not need to

be fully transformed and cleansed before integration,

but has a data manager for annotating the data with

meta-information to improve the processing steps and

make the data valuable. In order to keep a consistent

semantic meaning and common understanding of the

metadata over multiple data sets, companies start to

establish knowledge bases in the form of ontologies,

business glossaries or knowledge graphs. The pur-

pose of such a knowledge base is to offer semantic

concepts that can be annotated as metadata to a data

set. By adding these concepts to data sets and putting

them in relation to each other, one can describe a data

set in more detail. This process is called semantic

modeling.

However, creating semantic models is a cumber-

some task that is very time consuming and requires

a lot of domain knowledge. The amount of concepts

in ontologies can easily extend a size feasible to be

manageable by humans as shown by the compared on-

tologies of (Groß et al., 2016) under consideration of

the bio-medical domain. With numbers over 300,000

Pomp, A., Poth, L., Kraus, V. and Meisen, T.

Enhancing Knowledge Graphs with Data Representatives.

DOI: 10.5220/0007677400490060

In Proceedings of the 21st International Conference on Enterprise Information Systems (ICEIS 2019), pages 49-60

ISBN: 978-989-758-372-8

concepts, it becomes increasingly difﬁcult for a data

steward to select the right concept for the data at-

tributes of a data set. To support the data steward,

concepts can be recommended based on a deep anal-

ysis of the data. For instance, (Paulus et al., 2018)

proposed a solution for recommending semantic con-

cepts that uses the combination of data labels from

a data set together with additional information ex-

tracted from other knowledge bases.

Although Paulus et al. achieve very good results

on data sets that have conventional data labels, they

also identiﬁed a class of data labels, called random la-

bels, in which their recommendation framework will

never be able to identify the correct concept by just

analyzing the labels of a data set. In these cases, the

label may be just a random number of characters that

is auto-generated, e.g., by a database management

system. This implies that the concept recommenda-

tion has to be performed based on the data instances

rather than on the data labels.

Thus, the goal of our work is to exploit which

data-driven approaches are suitable for different types

of data and how those approaches can be used to learn

the data representation of semantic concepts. We

therefore develop a data-driven recommendation ap-

proach which is based on the knowledge graph pro-

vided by the semantic data platform ESKAPE (Pomp

et al., 2017). We show that our approach is capable

of learning multiple data representations, called data

representatives, for concepts and is able to use those

learned representations to recommend concepts. Each

data representative is based on a deﬁned classiﬁcation

approach, which can be a machine learning model,

a rule or a statistical method. The idea of learning

multiple representatives and equip them with differ-

ent classiﬁcation approaches for a single concept is

motivated by an analysis of public data sets in which

we identiﬁed different types of Data Classes. These

classes are built on a combination of different metrics,

such as data type, number of possible values, etc. We

expect multiple recommendation strategies to achieve

different accuracies based on the data class in which

a set of values is grouped.

To analyze the accuracy of our data-driven rec-

ommendation approach, we annotated real-world data

sets with semantic models and evaluated the quality of

the semantic concept recommendation under the con-

dition of the different data classes. Altogether, the

main contributions of this paper are

1. an approach that makes it possible to learn seman-

tic concept representations for dynamic knowl-

edge bases which are not yet considered by related

work, since knowledge bases are always consid-

ered static here,

2. an extension of the knowledge graph model pro-

posed by (Pomp et al., 2017) for equipping knowl-

edge graphs with data representations,

3. an approach that maintains multiple data repre-

sentatives and classiﬁcation approaches for a sin-

gle semantic concept,

4. a more detailed identiﬁcation of different types of

data classes compared to related work which just

considers numbers or text,

5. an evaluation that compares the performance of

the different classiﬁcation approaches for the

identiﬁed data classes.

The remainder of this paper is organized as follows:

Section 2 motivates the necessity to develop a recom-

mendation approach that uses data instances and can

deal with knowledge bases that are extended at run-

time. Afterwards, Section 3 provides an overview of

related work and Section 4 deﬁnes the data classes

which we identiﬁed when reviewing real-world data

sets. Based on these classes, we present our identiﬁed

classiﬁcation approaches and the implementation of

our approach in Section 5. Section 6 gives an evalua-

tion of our approach before we conclude with a sum-

mary and a short outlook in Section 7.

2 MOTIVATING EXAMPLE

In this section, we provide a motivating example il-

lustrating the necessity for developing a recommen-

dation framework that supports a user during the cre-

ation of semantic models with giving recommenda-

tions which are not solely relying on data labels but

also on data values.

In the following scenario, we consider a large

global enterprise that is active in many different in-

dustries with multiple sites in different countries. For

instance, it develops mobility solutions as well as con-

sumer goods. Thus, the company has a lot of different

production processes. Due to the digitalization strat-

egy of the company, for some years now, the company

is already storing the collected data in their data lake.

For each production process, the company is planning

to setup a digital twin which virtually models the be-

haviour of the involved machines. Those digital twins

are later used for optimizing the operation and main-

tenance of the production processes. Since the de-

velopers, such as data scientists, who are involved in

the construction of the digital twins, have to ﬁnd and

access the data they are looking for, the company es-

tablished a metadata-management solution. This ap-

proach uses an enterprise ontology and user-deﬁned

semantic model to describe the data sources in more

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

Table 1: Exemplary data set for which a data steward wants

to create a semantic model.

prodID tmp tinms e-mail sta

313-16 856 1476912300 x@cp.com OK

215-14 857 1476922300 y@cp.com NOK

513-31 845 1476932300 x@cp.com OK

... ... ... ... ...

detail. The semantic models are created by data stew-

ards, who are employees that are domain experts and

know the semantics of the data very well.

Since data sources in industrial environments can

contain hundreds of data attributes (Paulus et al.,

2018), creating sophisticated semantic models is a

complex and time-consuming task. In order to im-

prove the quality of the semantic models, it is there-

fore important to support the data steward during the

creation process. We assume that a data steward

wants to create a semantic model for the simpliﬁed

data set in Table 1, which shows a product that has

been dried in an oven at a certain temperature and was

later manually checked for proper functioning by an

employee. The data steward selects concepts from the

underlying ontology and maps them to the columns

of the table. For instance, the column prodID would

be mapped to the concept Identiﬁer and the column

tinms to the concept Timestamp. In addition, the data

steward can specify more details, like the unit Sec-

onds in which the timestamp is measured. Later on,

these detailed information will help the developers of

the digital twin application to understand the data and

implement their application correctly (e.g., consider-

ing the correct unit for timestamps).

Examining this table and the presented task of the

data steward shows that, if the data sets become much

larger, the creation of semantic models will be a com-

plex and time-consuming task, which requires impor-

tant domain knowledge. Supporting the user with rec-

ommendations based on labels would already help to

reliably identify concepts, like E-Mail for the column

e-mail but would fail for all other columns. Examin-

ing the data instances of the columns raises the sus-

picion that a recommendation based on the data in-

stances can lead to better results. For instance, the

columns prodID as well as e-mail follow a ﬁxed pat-

tern whereas the temperature values in column temp

are limited to a certain range (845-857

◦

C) and the sta

column only consists of two valid values (OK, NOK).

However, the diversity of the different kinds of data

instances also shows that it is not possible to develop

a solution that solely relies on a single classiﬁcation

approach. For instance, training a machine learning

classiﬁer that detects a valid temperature is possible

whereas the training for product identiﬁer will not

work since each entry is unique. However, deﬁning

rules for the product identiﬁer, e.g., by using regular

expressions, would result in a valid data representa-

tion for this concept. Nevertheless, only assigning a

single data representative to a semantic concept will

also lead to wrong results. Depending on the pro-

duction process and its context, the data instances for

a semantic concept may differ. For example, there

might exist production processes in which the values

of valid temperatures are not between 845-857

◦

C but

between 12-15

◦

C. In these cases, it will be necessary

to learn a different data representation for the same

semantic concept.

Beside these examples, the scenario also relies on

a ﬁxed underlying vocabulary provided by the under-

lying ontology. In this case, one could also try to con-

vert the use case with all its data to a multi-class clas-

siﬁcation problem where each data representation for

each semantic concept will result in one class. While

this would be a ﬁrst solution, it leads to a very static

scenario. In cases where the underlying vocabulary of

the ontology will be extended or where new machines

with different data representatives for the same con-

cept are introduced, it becomes necessary to re-train

the whole machine learning model which is very time-

consuming and not manageable in a company with

multiple sites and a very diverse product portfolio.

It is therefore necessary to develop an approach

that takes into account not only the names of the data

attributes, but also the data instances. In addition,

this approach should be independent of the number

of available concepts. If new concepts are introduced

or data instances with different representation forms

are added, it must be possible to learn these as well.

3 RELATED WORK

The research areas of semantic annotation, labeling or

modeling have the goal to assign semantic concepts

to data attributes of structured data sources. In order

to simplify the ﬁnding, accessing and storing of data,

several attempts have been made to support the data

annotation. Strategies on how data sets can be ana-

lyzed to suggest concepts ﬁtting to their attributes are

elaborated by different researchers. First approaches

focused on the analysis of the labels attached to the

attributes in order to suggest concepts. Other ap-

proaches take the relations of those labels into ac-

count and recent papers also focus on the analysis of

the instances the attributes are assigned to. Current

approaches perform this task by either suggesting se-

mantic concepts based on the label or by exploiting

the data instances of the corresponding data attributes.

Enhancing Knowledge Graphs with Data Representatives

For instance, (Syed et al., 2010) or (Wang et al.,

2012) suggest semantic concepts based on external

knowledge bases. Therefore, they evaluate if the data

label matches a semantic concept in one of the knowl-

edge bases WordNet, Wikipedia or Probase. Another

approach that also relies on external knowledge bases

is presented by (Paulus et al., 2018). They improve

the semantic concept suggestion by examining not

only single data labels but by considering them in

their complete context. Therefore, the authors send

all data attributes to multiple knowledge bases. The

returned results are then automatically merged and

rated with a corresponding algorithm. Another ap-

proach which also solely focuses on the analysis of

data labels is presented by (Goel et al., 2011) and

(Goel et al., 2012). Goel et al. make use of condi-

tional random ﬁelds (CRF) to annotate the labels of

a data set with semantic labels. In order to improve

the semantic labeling, Goel et al. do not only make

use of the labels themselves but divide them into to-

kens, based on the instances in the ﬁelds of the data

set (e.g, a value 70

◦

F with the key TempF is divided

into the tokens 70,

◦

and F, which all separately get a

token label). The newly created tokens are combined

with the original ﬁeld labels in order to create a se-

quence CRF graph. Results of experiments in which

data from three different domains was used showed

an accuracy between 89% and 98%. In distinction

to our work, both approaches exploit the same clas-

siﬁcation strategy (CRF) for the annotation process

whereas our approach considers multiple classiﬁca-

tion approaches per semantic concept. In addition,

the authors always rely on meaningful labels whereas

(Paulus et al., 2018) argued that there exist many data

sets where a label-based strategy cannot work.

Thus, in (Ramnandan et al., 2015), the authors

present a further enhancement of the approach that

has been made by Goel in (Goel et al., 2011). In

comparison to the previously presented papers, the fo-

cus for the assignment of semantic labels is shifted

from the analysis of attribute and key names to the in-

stances of a data set. They do not take every value

of an attribute by itself into context but the set of

all instances mapped to that attribute as a whole to

analyze which characteristics describe that attribute.

Those characteristics are then linked to semantic con-

cepts of an ontology. The authors differentiate be-

tween textual and numerical data as they use different

analysis techniques on them. To suggest a label for

the attribute of a new text document, the cosine sim-

ilarity between all indexed documents and the new

document is calculated to present the top k elements

with the highest similarity score. For numerical in-

stances, a statistical hypothesis testing is used, which

is performed between a new data set that should be la-

beled and every numerical data sample used for train-

ing. As a new data set is compared with every already

learned characteristics, the system is adoptable to new

semantic labels without any effort. Ramnandan et al.

evaluate their implementation on data from ﬁve dif-

ferent domains (museum, city, weather, ﬂight status,

and phone directory). With the size of the test data

sets being quite small (9 different labels in the ﬂight

status domain), they achieve a maximal Mean Recip-

rocal Rank score ranging from 0.421 up to 0.943 for

the ﬁrst four concept suggestions. The basic idea of

this approach is similar to ours as it is also rather fo-

cused on the exploitation of the data instances than the

attribute names. However, the authors only differenti-

ate between text and numerical instances whereas our

approach focuses on more ﬁne-granular data classes.

In addition, we allow to learn multiple data represen-

tations for the same semantic concept.

In (Pham et al., 2016), the authors present an ap-

proach that does not focus on the pure data instances

but the similarity of the metadata (respectively sim-

ilarity metrics) of these instances, whereby their ap-

proach becomes independent of the domain the model

was trained upon. As similarity metrics, the au-

thors use Attribute Name Similarity, Value Similar-

ity, Distribution Similarity for numerical instances,

Histogram Similarity for textual instances and Ratio

for cases where a mixture of numerical and textual

instances is available. For every attribute of a set

, a

, ...a

}, a feature vector f

i j

(i 6= j) is computed.

Every similarity metric in dimension k is thereby cal-

culated for itself, with f [k] representing the similarity

of a

and a

under metric k. Every calculated vector is

annotated manually, whether the attributes are seman-

tically similar or not. Based on the identiﬁed feature

vectors, they train a machine learning classiﬁer. They

evaluated their approach for data sets of four differ-

ent domains under the usage of two different classi-

ﬁers, respectively Logistic Regression and Random

Forest, with Logistic Regression showing the better

performance. Compared to our approach, Pham et

al. only train one classiﬁer whereas our work per-

mits multiple data representations per concept where

each representation can be based on different classi-

ﬁcation approaches. Similar to our approach, Pham

et al. already take the data class into account to cal-

culate similarity metrics differently, but they restrict

their differentiation merely to textual and numerical

instances, with the classiﬁer handling them similar.

The data classes evaluated in our work offer a broader

variety and the impact of different classiﬁcation ap-

proaches is evaluated on all data classes.

While these approaches provide good results for

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

extending the recommendation of semantic concepts

for data attributes, we believe that it is not possible

to cover all different concepts with a single approach

just as label recommendation, similarity measures or

machine learning. Instead, we believe that the quality

of the recommendation for data instances depends on

the data class the instances belong to.

4 DATA CLASSES

Since our approach is targeting semantic concept sug-

gestion based on the concrete data values, we need

to consider the basic properties of data values. We

identiﬁed a certain categorization which groups these

properties in data classes. These classes are later

used as an additional feature or criteria for the selec-

tion of the suggestion method. This section gives an

overview of the data classes we identiﬁed and we dis-

cuss their specialties. The overview is based on a se-

lection of data sets also used by (Paulus et al., 2018),

mainly in the domain of publicly available, municipal

data sets as well as the data set used by (Pham et al.,

2016) from the domain of soccer and museums. Pham

et al. already divide their data sets into textual and nu-

merical values to perform different suggestion algo-

rithms based on the data type, but we expect that fur-

ther gradations of the data properties might improve

the accuracy of suggestion strategies.

We do not claim that the following list of prop-

erties and classes is exhaustive, however, all assump-

tions can be validated and they cover the most seen

properties. Also, video, picture, sound and any more

complex data is not covered by this classiﬁcation, as

the assumption is made that they can be transformed

into numerical values for semantic analysis.

The following data properties were observed. The

ﬁrst deﬁning property of a data point is the Data

Type. A data type deﬁnes the most basic limitation to

the expressiveness to one single data value. The ob-

served types range from numbers (discrete and ﬂoat-

ing) to a sequence of any characters. Other properties

are deﬁning the relation between two data points. A

Scale provides the possibility to interpret the distance

between two data points. Scales can be either categor-

ical or numerical, whereby the categorical scale can

be divided into nominal or ordinal scales. In a nom-

inal scale there is no relation between the instances,

they are comparable to labels. In an ordinal scale, the

difference between two values is still not quantiﬁable

or has no speciﬁc meaning, however, values can be

Sorted. Finally, in a numerical scale, even the dis-

tance between two values has a meaning.

The following data classes are a result of the com-

bination of the previously described properties:

Full Text: This class (text-class) is the least re-

strictive. Many of the reviewed data sets contained

attributes whose values consisted of longer texts (e.g.,

a description or an abstract). As most of the ma-

chine learning techniques we use are based on numer-

ical values, their application for values that consist of

longer texts is quite challenging. Also, histograms are

insufﬁcient as the variety of the texts is too high. One

possible solution for this issue is assumed to be a dic-

tionary of n-grams in order to have a look up for cer-

tain phrases occurring in a longer text.

Identiﬁer: This class (id-class) restricts the ﬁrst

class in two aspects. First, it contains less charac-

ters and second, the characters follow a more or less

strict pattern. Names are a typical representative of

this class. However, determining whether an arbitrary

sequence of characters is conceptually a name is hard,

as names do not follow any predictable pattern. Same

holds true for other identiﬁcation strings or numbers,

which can also occur in a combination of characters

and numbers. Other identiﬁers like an IBAN or ISBN

on the other hand have a ﬁxed pattern by which they

are created. Email addresses make up a set in between

as all of the contain an ”@”, which is rarely used in

a different context, but the rest of the address is quite

arbitrary.

Bag-of-words: The next class also consists of

limited character sequences, however, in this case the

structure of the character sequence is of secondary

importance. The deﬁning criteria of this class is that

the attributes are composed only from a ﬁxed set of al-

lowed values called a bag-of-words (bow). Examples

for this are soccer player positions (”Goalkeeper”,

”Left-back”, ”Centre midﬁeld”, ”Striker”, ...) or nom-

inal scales (”good”, ”average”, ”bad”). A direct trans-

fer from values with a similar semantic meaning but

different representations is not possible. For example

a ﬁxed set of words cannot be recognized by the ab-

breviation of the words (e.g., for soccer ”GK”, ”LB”,

”CM”, ”ST”) or one nominal scale by another (e.g.,

English to German grades). The new set has to be

attached to the corresponding concept in order to sug-

gest the concept to new data.

Numerical Values: The last class consists of only

numbers (discrete or ﬂoating point). Numerical val-

ues (num-class) occur in any form of measurement or

calculated results. The possible values in a data set

with real values cannot be grouped with a ﬁxed set as

there are arbitrary many valid values. In difference

to the identiﬁers that may also be composed of num-

bers, real numbers can be put in a relation to each

other which allows different evaluations as they can

be placed on numerical scale.

Enhancing Knowledge Graphs with Data Representatives

5 DATA REPRESENTATION

In this section, we present our developed approach

which we integrated into the semantic data platform

ESKAPE (Pomp et al., 2017), which offers Ontology-

Based Data Access (OBDA). The idea of ESKAPE

is that data stewards publish data sources and de-

scribe the additional required and interesting meta-

information with semantic models. Based on the se-

mantic models, other users like data scientists, can

query and access these data sources later on. In or-

der to support the data steward during the seman-

tic model creation, ESKAPE identiﬁes semantic con-

cept recommendations based on the framework pre-

sented by (Paulus et al., 2018). Data stewards can

then create the semantic models with the graphical

user interface of ESKAPE (Pomp et al., 2018) where

they can choose from the recommendations or browse

through all existing semantic concepts and relations

provided by ESKAPE’s underlying knowledge graph,

which encourages them to make choices upon that

shared terminology. Compared to traditional OBDA

approaches, users can extend the knowledge graph’s

vocabulary by introducing new concepts or relations

on-demand directly to the knowledge graph to make

them available for others. This circumstance is very

crucial for the design of our approach as it excludes

the possibility of using a multi-class classiﬁcation ap-

proach. If we would use this method, the approach

would require re-training after a new semantic con-

cept has been added to the knowledge base. How-

ever, this would be very time- and resource-intensive.

Hence, the goal of our approach is to enhance each se-

mantic concept with data representatives that capture

or describe the characteristics of the data instances

that are annotated with this concept.

We therefore identiﬁed different approaches, such

as statistical methods, regular expressions and ma-

chine learning methods that can be used for represent-

ing the instances of a semantic concept. The goal of

these approaches is to evaluate later on if a number of

data instances are valid or invalid representatives of

this semantic concept. We call these approaches clas-

siﬁcation approaches. Each semantic concept can be

represented by one or more classiﬁcation approaches.

For instance, one could have different machine learn-

ing models or statistic methods that are used for iden-

tifying if a data value is a representative of this seman-

tic concept. We decided to link a semantic concept to

different classiﬁcation approaches as the instances of

data attributes can belong to different data classes. We

then integrated our framework into the semantic data

platform ESKAPE and modiﬁed the semantic model-

ing approach of ESKAPE. In the following, we give

an overview of the identiﬁed classiﬁcation approaches

(cf. Section 5.1), the modiﬁcations which we made

for the knowledge graph model provided by ESKAPE

(cf. Section 5.2) and the process of how the recom-

mendation and training works (cf. Section 5.3 and

5.4).

5.1 Classiﬁcation Approaches

Classiﬁcation approaches represent the idea that we

can describe a semantic concept based on the sum of

all of its data instances. However, since the same se-

mantic concept can be represented by different kinds

of data instances (e.g., as a textual representation or

as a number), we identiﬁed that it is not possible to

solely ﬁnd a single classiﬁcation approach that is ca-

pable of capturing all characteristics of the semantic

concept. Based on the data classes and their charac-

teristics that we identiﬁed in Section 4, we selected

classiﬁcation approaches which match these. As clas-

siﬁcation approaches, we chose a rule-based approach

based on regular expressions, a histogram approach as

statistical method and one machine learning approach

in the form of a one-class classiﬁer.

Regular Expression: The analysis of the given data

sets showed that certain attributes contain instances,

which follow a ﬁxed set of syntactic rules. For ex-

ample, the attribute dim of a data set with informa-

tion to paintings contain instances like 135.7x55.3cm,

44.2x55.0cm and 62.8x81.9cm. The concept of the

attribute is ”dimension”, which can be described

by a representative based on a regular expression

(RegEx) as the instances follow a ﬁxed pattern. The

RegEx sufﬁcient to characterize this instances would

be (\d)*.\d x (\d)*.\dcm. The disadvantage of

this approach is that the user has to come up with the

RegEx by hand in order to describe the instances. It is

also necessary to keep the RegEx as speciﬁc as possi-

ble in order to prevent it ﬁtting to other concepts. The

RegEx .* would also cover the top example, but ev-

ery other value would also be veriﬁed by this pattern.

Histogram: Opposed to the rule-based approach,

which takes every value separately into account, the

histogram-based method is chosen to use the fre-

quency of every value as metadata. This frequency

is intended to provide a better insight into the data

set, as it provides an opportunity to distinguish con-

cepts that inherit similar instances, but are semanti-

cally different. As a histogram does not consider the

order of the instances, a distribution of the instances

is not taken into account. As mentioned in Section 4,

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

the order of the instances might include further infor-

mation on a data set if the instances are denoted in a

ﬁxed order which is often encoded in the instances of

a different attribute. For real numbers we also con-

sider binning strategies based on a rounding factor.

For textual instances, this binning is not implemented

(e.g., to group instances with a similar meaning).

One-Class Classiﬁer: In order to detect boundaries

between instances that represent one concept and in-

stances representing another one, a one class classiﬁer

(OCC) is used. The usage of an OCC provides the ad-

vantage over other classiﬁcation techniques that it is

restricted to a training set containing only valid in-

stances. For the classiﬁcation approaches of the con-

cepts, this is useful as each classiﬁcation approach

becomes independent for the other. New classiﬁca-

tion approaches can be added without the need for

re-training of previously trained models. Currently,

we use a support vector machine (SVM) as one-class

classiﬁer. However, other solutions, like AutoEn-

coder would also be possible.

5.2 Knowledge Graph Model

For our implementation, we ﬁrst extended an exist-

ing knowledge graph model provided by the semantic

data platform ESKAPE (Pomp et al., 2017) to be ca-

pable of linking semantic concepts to data representa-

tions.

The original graph model described by (Pomp

et al., 2017) describes a basic model for semantic con-

cepts, called Entity Concepts, and the relations be-

tween them. To additionally enable the learning of

data representations for those Entity Concepts, we

extended the graph model. Therefore, we extended

each Entity Concept node ec

with an additional data

representation node drn

. The data representation

node drn

is linked to the different data representa-

tives drc

that were trained for the entity concept ec

We introduce for each new data representative j, a

new node drc

and attach it to the corresponding drn

node. Depending on the type of the data representa-

tive (Histogram, Regex, OCC, etc.), each of those drn

nodes has different properties. For histograms, we

save the data class for which this histogram was cre-

ated, a location where we store the histogram model

and the rounding which describes on how many dec-

imal places we round, or −1 if it is a text-based his-

togram. For the one class classiﬁer, we store the loca-

tion where the trained model is stored and for which

data class it was trained. Finally, for a regular ex-

pression, we store the data class, the pattern and a ﬁt

percentage which describes the percentage of data in-

Figure 1: Example for the concept Temperature. Based on

the currently annotated data, four different data representa-

tions were created. The weights w show that most of the

annotated data attributes were trained with the One Class

Classiﬁer.

stances of the annotated data attributes on which this

regular expression matched.

Since the number of possible data representations

per semantic concept potentially increases with the

number of new data sources, we added a weighting

factor w to the edge e

i j

between the data represen-

tation node drn

i and the corresponding data repre-

sentative drc

. This weighting factor describes how

many percent of all annotated data attributes were

used with this concept to train this data representa-

tive. Figure 1 shows an example. For the semantic

concept Temperature, ten data attributes were anno-

tated with this concept, but only four different data

representatives were trained. Two of those represen-

tatives are Histograms, one OCC and one regular ex-

pression. The weighting factor shows how many data

attribute columns were used for the different data rep-

resentatives. For instance, the 0.6 for the OCC indi-

cates that the instances of six out of ten data attributes

were currently used to train the OCC model, whereas

for the regular expression representative the instances

of only one data attribute were used. In the later rec-

ommendation process, the data representatives with

the higher weight will be evaluated ﬁrst.

5.3 Recommending Concepts

The recommendation and the training or updating

of existing data representatives is done during the

schema analysis and the semantic model creation in

the ESKAPE platform. During the schema analysis,

ESKAPE identiﬁes the best ﬁtting semantic concept

for a corresponding data attribute. Previously, this

process was based on the recommendation framework

provided by (Paulus et al., 2018). We extended this

process to additionally evaluate the already existing

data representatives. First, we randomly sample ten

Enhancing Knowledge Graphs with Data Representatives

EC2

Attribute

Value 1

Value 2

Value 3

New data set

EC3

EC1

calculate a fitting coefficient of every

characteristic for the new data set

return top 5 chars

with their concept

Figure 2: Model of the concept suggestion based on differ-

ent classiﬁcation approaches. The instances of a new data

set are analyzed and compared with every existing classi-

ﬁcation approach and a similarity score is calculated. The

concepts with the highest score are returned.

percent of the available data instances dv from the

data attribute da. For each available concept that has

already attached data representatives in the knowl-

edge graph, we check how well this concept repre-

sents the data instances. Therefore, we calculate for

each data representative drc a similarity score s be-

tween the set of randomly extracted data instances and

the drc. This similarity score deﬁnes how well the

data instances ﬁt the current representation of the se-

mantic concept. To speed-up the ﬁnding of a match,

we ﬁrst evaluate the data representatives that have a

higher weight. If a data representative with a high

similarity score, i.e., at least 80% , was identiﬁed, the

concept is marked as relevant and the other data repre-

sentatives of this concept are not evaluated anymore.

As soon as all semantic concepts were evaluated, the

top ﬁve concepts with the highest similarity score are

returned as recommendations. Figure 2 shows this ap-

proach for a small example.

Similarity Score: The calculation of the similar-

ity score depends on the different classiﬁcation ap-

proaches. For the rule-based approach based on reg-

ular expressions and for the one class classiﬁer, the

strategies are quite similar. In both cases, for every

data value of the attribute that is about to be anno-

tated, it is checked whether they ﬁt into the given data

representation or not. For the rule-based approach,

the RegEx pattern is evaluated on every value and for

the OCC-based method every value is classiﬁed by the

OCC algorithm and the percentage of instances ﬁtting

the class is used for evaluation. The higher the per-

centage of ﬁtting instances is, the more it is assumed

that the concept associated with the respective data

representation ﬁts to the attribute of the instances. To

suggest a concept based on a histogram classiﬁcation

approach, the histogram for the instances of the data

set is calculated. The histogram is normalized as the

amount of instances should not effect the calculation.

Afterwards, the histogram of every available repre-

sentative is compared with the one from the new data

set and the intersection for them is calculated. Due

to the normalization, results between 0 and 1 occur

with the highest rated intersections being used for the

suggestion of their respective concepts.

5.4 Training Concepts

With each new data set and the corresponding cre-

ated semantic model, the concept representations are

updated and/or extended. For training classiﬁcation

approaches for semantic concepts, we have to differ-

entiate between different cases.

No Representation Available: In this case, we al-

low the user, who is creating the semantic model, to

select a classiﬁcation approach that should be used

for learning the semantic concept. Hence, if the user

selects the histogram or one class classiﬁcation ap-

proach, the system will calculate a histogram or train

a SVM classiﬁer for the annotated data attribute and

store them on the underlying storage system. For

the histogram, the user has to additionally deﬁne the

rounding factor. For the SVM classiﬁer, the user does

not have to deﬁne anything. Currently, all SVM pa-

rameters are set to default. However, in the future we

plan to perform an automatic grid search with a differ-

ent parameter set. With the help of cross-validation,

we will then select the best ﬁtting parameters for the

available data instances. If the user selects a regular

expression, he has to deﬁne it and provide it to the

system. Our approach will then create a new data rep-

resentative for the used semantic concept.

Representation Available but Inappropriate: If a

semantic concept has already assigned classiﬁcation

approaches but none of those were valid candidates

for the recommendation, then we request the user to

deﬁne the same information as if no representation

would be available. This means a user has to choose a

classiﬁcation approach and has to deﬁne the required

parameters. Our approach will then create a new data

representative for the used semantic concept.

Appropriate Representation Available: If an ap-

propriate representation is available, i.e., the similar-

ity score was larger than 80%, this representation will

be extended with the new instances. In case of a regu-

lar expression classiﬁcation approach, the ﬁt percent-

age value will be updated. In case of histogram, we

will create a new histogram and store it. The one class

classiﬁer will be re-trained with the old and new data

instances.

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

6 EVALUATION

This section evaluates the three implemented classiﬁ-

cations approaches (histogram-, rule-based and OCC-

based approach) and how accurate their suggestions

of concepts are compared to manually annotated con-

cepts. All evaluations are conducted with respect to

the data classes (cf. Section 4). This means that

we considered the four identiﬁed data classes (bag-

of-words (bow), Numerical values (num), identiﬁers

(id) and textual (text)). The results are compared with

the ones achieved by (Pham et al., 2016). To achieve

compatibility with Pham et al., we limit our evalua-

tion to the data sets of the domains museum and soc-

cer. The source data sets museum and soccer can

be summarized with following distribution: The mu-

seum data set contains 4132 entries over 28 different

semantic concepts in total. Most frequently, the bow

class can be observed with 18 entries. The other con-

cepts are evenly distributed among the other classes.

For the soccer data set, the bow class and the numeric

class are the most prominent with 14 and 13 out of

33 respectively. The other classes are also evenly dis-

tributed. There are 9443 entries in total in this set.

The other domains provided either only ten data val-

ues or provided only ﬁve attributes.

6.1 Evaluation Method

All measurements are conducted on a knowledge

graph, which contains all concepts that are manually

assigned to the attributes of the data sets.

Two varieties of hit ranks are measured. The Mean

Reciprocal Rank (MRR) of the top four elements

(MMR4) is evaluated beside the top-rating (T1). The

top four elements are evaluated as they are also used

by (Pham et al., 2016) for their evaluation. The MRR

is deﬁned by (Craswell, 2009) as followed:

Mean Reciprocal Rank. The Reciprocal Rank

(RR) information retrieval measure calculates the re-

ciprocal of the rank at which the ﬁrst relevant docu-

ment was retrieved. RR is 1 if a relevant document

was retrieved at rank 1, if not it is 0.5 if a relevant

document was retrieved at rank 2 and so on. When

averaged across queries, the measure is called the

Mean Reciprocal Rank (MRR). Mathematically de-

scribed as followed for all queries Q:

MRR =

|Q|

∑

i=1

rank

After the hit rank is evaluated, the current accu-

racy of the suggestion process is evaluated and a rep-

resentation that is created based on the values of the

Figure 3: Box plot diagrams of the measurement series’

over the different data classes with different classiﬁcation

approaches on the museum data set.

Figure 4: Box plot diagram for the evaluated accuracy on

the soccer data sets. The data class text is left out as the

amount of attributes associated with that class is too low.

current attribute is attached to manually labeled con-

cept.

Since we propose an evolutionary learning ap-

proach, the order in which the data representatives are

added to the concepts might affect the quality of the

suggestion process. Therefore, we perform a ten-fold

cross validation using a random shufﬂe of the labeled

attributes.

6.2 Classiﬁcation Methods

To evaluate which of the classiﬁcation approaches

suits best for which kind of data class, we ﬁrst com-

pare our suggestions in their basic form on single do-

mains. In the next step we increase the complexity by

considering multiple domains.

Single Domain. Figure 3 (museum data set) and

Figure 4 (soccer data set) show the domain depen-

dent results of the evaluation of which classiﬁcation

approach suits best for which kind of data class, a

cross evaluation of all approaches on the data sets

from the domain museum and soccer is conducted.

As the number of attributes associated with the data

class text in the soccer domain data sets are too few,

they were left out of the evaluation. The data set con-

tained only seven entries, which are all labeled with

”date”.

Enhancing Knowledge Graphs with Data Representatives

For the museum data set, the OCC approach is

only evaluated on the data class num, since the map-

ping process from text values to numerical values is

too expensive, i.e., the suggestion of a single concept

takes on average 10 minutes, even if only a few rep-

resentatives are available. The OCC accuracy is eval-

uated for the data set from the soccer domain, since

the number of data values per attribute is much lower

than those for the museum data set. However, the cal-

culation of the OCC approach is still slower than that

of the other approaches.

In the museum data, the best results for numerical

data could be achieved through a rule-based approach

with a measured accuracy of T1: 0.9182 (MRR4:

0.9575). For the soccer data set, the OCC-based

approach performed better with accuracies of only

0.7353 (0.8480), however. While the histogram ap-

proach achieves reasonable results for the museum

set, it has a very low accuracy in the soccer case

0.3744 (0.3902).

The bow-class is similarly well predicted by the

histogram- and rule-based approach in the museum

case, with accuracies of 0.7137 (0.7640) for the

histogram-based and 0.6583 (0.7436) for the rule-

based approach. The histogram result can be re-

produced in the soccer case 0.7462 (0.7831), how-

ever, the rule-based approach performs badly 0.2795

(0.5057).

The histogram-based approach performed well for

the id-class and text-class, while the text-class has

generally a bad accuracy for the museum data sets.

In the soccer set, the rule-based approach performs

best with accuracies of 0.9737 (0.9868), while the

histogram-based approach also has reasonably ﬁne

and even signiﬁcantly better results than for the mu-

seum case, i.e., 0.8684 (0.8989) vs. 0.7137 (0.7640).

These results indicate that no single approach is

a universal winner, the proper approach seems to be

highly dependant on the individual data points.

Mutliple Domains. As the previous tests where re-

stricted to only one domain, the evaluation of this sec-

tion measured the accuracy for the mixture of soccer

and museum based data sets. This enlarges the set of

possible concepts that can be suggested to an attribute

and creates a broader variety of concepts within one

knowledge graph. The results of the evaluation are

depicted in the box plot diagram of Figure 5.

The results of the analysis show that the developed

framework holds up the measured accuracy for mostly

all combinations of data classes and classiﬁcation ap-

proaches. The only signiﬁcant drops of quality oc-

curred with the rule-based approach being conducted

to the data classes bow and id. For the bow-class, the

Figure 5: Box plot diagram for the accuracy measured over

all data classes and classiﬁcation methods with data sets

from the museum and soccer domain being included into

the knowledge graph and annotated randomly mixed.

quality dropped from 0.6583 (0.7436) in the museums

domain to 0.4020 (0.5570) in the overall approach.

The range of the box plot diagram is also enlarged

indicating the importance of the order in which the

representatives are added to the concepts. This might

be explained with the low quality of the rule-based

approach achieved on the soccer domain for data sets

that are assigned to the bow-class.

One signiﬁcant improvement of the accuracy

could be measured for the combination of the data

class num and the histogram-based classiﬁcation ap-

proach. The quality was enhanced from 0.2795

(0.5057) in the soccer domain based data sets to

0.7244 (0.7572) in the domain mixed approach. Also

the range of the box blot scale shrinks drastically for

the histogram-based approach.

The results of this test show that the enlargement

of the concept variety does not impact the accuracy of

the classiﬁcation methods as long as the boundaries

of the added concepts stay disjointed.

Comparison to Pham. This section provides a dis-

cussion of the measured results. As the accuracy mea-

sured on the data sets from the domains soccer and

museum is based on the same data sets as the eval-

uation of Pham et al., the results will be set into the

context of their evaluation. Unfortunately, the results

presented in their paper could not be reproduced by

the provided code, so the results denoted in their out-

line will be used as a comparison.

Table 2: MRR scores of different classiﬁers when training

on soccer by (Pham et al., 2016).

soccer museum

Logistic Regression 0.814 0.863

Random Forest 0.794 0.799

As our evaluation was only conducted of the data

sets from the domains soccer and museum, only those

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

Table 3: MRR scores of different classiﬁers when training

on museum by (Pham et al., 2016).

soccer museum

Logistic Regression 0.815 0.845

Random Forest 0.820 0.778

Table 4: MRR scores of the classiﬁcation approaches on

soccer. Bold marked values scored higher than the best re-

sult of Pham et al. on the soccer data.

bow num id text average

Histogram 0.783 0.390 0.899 0.954 0.757

Rule 0.506 0.771 0.987 0.983 0.812

OCC 0.687 0.848 0.907 0.950 0.848

Table 5: MRR scores of the classiﬁcation approaches on

museum. Bold marked values scored higher than the best

result of Pham et al. on the museum data.

bow num id text average

Histogram 0.764 0.877 0.793 0.783 0.804

Rule 0.752 0.974 0.457 0.200 0.596

OCC 0.843 0.843

results are relevant for comparison with the results of

Pham et al. and presented in Table 2 and 3. Since

Pham et al. present the results of a MRR of the top

four suggestions, the same measured results are pre-

sented in Table 4 and Table 5.

The results of this paper are achieved by a dif-

ferent approach than the one used by Pham et al.,

but show a similar accuracy like the one measured

by Pham et al. Certain combinations of classiﬁcation

approach and data class showed to be more efﬁcient,

while other performed worse.

As the provided data sets and number of concepts

is not that high, with 12 data sets of soccer and 28

data sets of museum data, the results can be described

as equally accurate. Since the actual concepts used by

Pham et al. are not all listed in their paper, the same

ones could not be annotated to the attributes, evalu-

ated by this paper. As the used concepts are unknown,

the variety of annotated concepts is also slightly dif-

ferent. Pham et al. distinguish 20 concepts in the

museum domain and 14 in the soccer domain. In this

paper, for the museum domain 28 concepts and for

the soccer domain 33 concepts have been identiﬁed.

However, as described in Section 4 they are split up

into the different data classes in this paper.

Both methods are domain independent but follow

different strategies to achieve this goal. The method

presented by Pham et al. relies on the training of

one ML model, trained to tell whether two attributes

can be associated with the same concept based on

the metadata of the data instance. While Pham et

al. distinguish between textual and numerical values,

the here presented method focuses further on the data

class a set of values can be described by. Textual data

is split into the data class bow, id and text and nu-

merical data is split into the data classes num, bow

and id. The numerical values are mapped to the class

bow or id if their semantic meaning does not focus

on the numerical comparison of the values, but could

be replaced by text (e.g., replace a rating from one to

ten in a survey or replace a numerical id by a textual

unique identiﬁer). The implementation of this paper

offers individual classiﬁcation approaches for every

concept. Similar to the method of Pham et al. the

here presented implementation follows the suggestion

strategy, which compares the representatives of an at-

tribute that should be annotated with every previously

integrated representative.

The results of the comparison between the differ-

ent data classes and classiﬁcation approaches show

that for certain combinations one or the other is more

efﬁcient. While the histogram underperformed on the

data class num on the data sets of the soccer domain,

the rule-based approach showed to be inefﬁcient on

the classes id and text of the museum data.

7 CONCLUSION AND FUTURE

WORK

In this paper, we presented a novel approach on the

process of concept suggestion for data sets in order

improve the quality and duration it takes to integrate

them into a semantic model. We discussed different

existing strategies and methods, which revealed that

only a few approaches make use of the data instances

to recommend semantic concepts. Most research fo-

cuses on the evaluation of the attribute labels.

Therefore, we focus on the suggestion of concepts

based on the data instances of a data set, whose se-

mantic meaning is encapsulated in a characteristic

that is added to the concept via a representative. In

order to exploit the metadata of values, the attributes

of the values are associated with different data classes,

before concepts are suggested. The classes were de-

termined based on the evaluation of different real-

world data sets and consist of bag-of-words, numer-

ical, identiﬁer and full text.

The concept classiﬁcation approaches developed

are rule-, histogram- and one-class-classiﬁer-based.

As a foundation for the implementation, certain parts

of the ESKAPE platform by (Pomp et al., 2017) are

used, with the goal to extend it by the named func-

tionality. To do so, the knowledge graph used by

ESKAPE is extended by the possibility of adding

data representatives to the concepts. Next, the named

Enhancing Knowledge Graphs with Data Representatives

classiﬁcation approaches are implemented and cross

tested on the discussed data classes. The results show

that there are signiﬁcant differences in the accuracy

of the classiﬁcation approaches in context of speciﬁc

data classes. The use of a ﬂexible and dedicated clas-

siﬁcation of semantic concepts, like we presented in

this paper allows for better suggestions and improves

the semantic labeling process massively. To improve

our approach, we already started to evaluate the use

of a summarized representative, using a combination

of multiple classiﬁcation approaches. In this con-

text, we envision the use of a hierarchical approach

for the classiﬁcation, i.e., creating a global classi-

ﬁer which contains a selection of specialized ones.

Creating specialized classiﬁcations would result in a

self optimized adaptation of the look up strategies of

a global method. However, at the moment, the re-

sults of our summarized representatives are only sim-

ilar to the ones achieved without the creation of sum-

marized representatives. Hence, further research is

needed. Beside summarizing representatives, another

direction of research includes the enhancement of the

approaches applied to the different classes, such as us-

ing further machine learning methods for dealing with

full texts. Another important point is the evaluation

of different classiﬁcation approaches. Preliminary re-

sults of using machine learning-based approaches like

Autoencoders promise better classiﬁcation results. In

addition, it must be examined to what extent the re-

sults of our approach can be generalized in larger real

applications. It will therefore be necessary to carry

out evaluations with a larger number of data sets with

similar yet different concepts and data attributes. In

these cases it might be helpful to additionally support

the classiﬁcation by considering label-based sugges-

tions with methods like (Paulus et al., 2018). Finally,

the determination of the data classes is currently lim-

ited to the identiﬁed ones and is a manual process. An

extension would include the implementation of a fea-

ture that allows for any granularity in data classes and

an automated identiﬁcation of those.

REFERENCES

Craswell, N. (2009). Mean Reciprocal Rank. In LIU, L.

and

OZSU, M. T., editors, Encyclopedia of Database

Systems, page 1703. Springer US, Boston, MA.

Goel, A., Knoblock, C. A., and Lerman, K. (2011). Using

Conditional Random Fields to Exploit Token Struc-

ture and Labels for Accurate Semantic Annotation. In

Proceedings of the 25th National Conference on Arti-

ﬁcial Intelligence (AAAI-11), San Francisco, CA.

Goel, A., Knoblock, C. A., and Lerman, K. (2012). Ex-

ploiting Structure within Data for Accurate Labeling

Using Conditional Random Fields. In Proceedings of

the 14th International Conference on Artiﬁcial Intelli-

gence (ICAI).

Groß, A., Pruski, C., and Rahm, E. (2016). Evolution

of biomedical ontologies and mappings: Overview

of recent approaches. Computational and structural

biotechnology journal, 14:333–340.

Li, X., Tu, Z., Jia, Q., Man, X., Wang, H., and Zhang,

X. (2017). Deep-level Quality Management Based

on Big Data Analytics with Case Study. In Pro-

ceedings 2017 Chinese Automation Congress (CAC),

pages 4921–4926, Piscataway, NJ. IEEE.

Paulus, A., Pomp, A., Poth, L., Lipp, J., and Meisen, T.

(2018). Gathering and Combining Semantic Concepts

from Multiple Knowledge Bases. In Proceedings of

the 20th International Conference on Enterprise In-

formation Systems, pages 69–80. SCITEPRESS - Sci-

ence and Technology Publications.

Pham, M., Alse, S., Knoblock, C. A., and Szekely, P.

(2016). Semantic Labeling: A Domain-Independent

Approach. In Groth, P., editor, The semantic web -

ISWC 2016, Lecture note in computer science, pages

446–462. Springer, Cham.

Pomp, A., Paulus, A., Jeschke, S., and Meisen, T. (2017).

ESKAPE: Information Platform for Enabling Seman-

tic Data Processing. In Proceedings of the 19th

International Conference on Enterprise Information.

SCITEPRESS - Science and Technology Publications.

Pomp, A., Paulus, A., Klischies, D., Schwier, C., and

Meisen, T. (2018). A Web-based UI to Enable Se-

mantic Modeling for Everyone. In SEMANTiCS 2018

14th International Conference on Semantic Systems.

Ramnandan, S. K., Mittal, A., Knoblock, C. A., and

Szekely, P. (2015). Assigning Semantic Labels to

Data Sources. In Gandon, F., Sabou, M., Sack, H.,

d’Amato, C., Cudr

e-Mauroux, P., and Zimmermann,

A., editors, The Semantic Web. Latest Advances and

New Domains: 12th European Semantic Web Confer-

ence, ESWC 2015, Portoroz, Slovenia, May 31 – June

4, 2015. Proceedings, pages 403–417. Springer Inter-

national Publishing, Cham.

RWTH Aachen University (2017). Digital Connected

Production. https://www.rwth-campus.com/

wp-content/uploads/2015/01/Broschuere-Cluster-

Productionstechnik-20170508-web.pdf.

Syed, Z., Finin, T., Mulwad, V., and Joshi, A. (2010). Ex-

ploiting a web of semantic data for interpreting tables.

In Proceedings of the Second Web Science Confer-

ence, volume 5.

Terrizzano, I. G., Schwarz, P. M., Roth, M., and Colino,

J. E. (2015). Data Wrangling: The Challenging Your-

ney from the Wild to the Lake. In CIDR.

Wang, J., Wang, H., Wang, Z., and Zhu, K. (2012). Un-

derstanding tables on the web. Conceptual Modeling,

pages 141–155.

ICEIS 2019 - 21st International Conference on Enterprise Information Systems
