Multi-Label Network Classiﬁcation via Weighted Personalized

Factorizations

Ahmed Rashed, Josif Grabocka and Lars Schmidt-Thieme

Information Systems and Machine Learning Lab, University of Hildesheim, Hildesheim, Germany

Keywords:

Multi-relational Learning, Network Representations, Multi-Label Classiﬁcation, Recommender Systems,

Document Classiﬁcation.

Abstract:

Multi-label network classiﬁcation is a well-known task that is being used in a wide variety of web-based and

non-web-based domains. It can be formalized as a multi-relational learning task for predicting nodes labels

based on their relations within the network. In sparse networks, this prediction task can be very challenging

when only implicit feedback information is available such as in predicting user interests in social networks.

Current approaches rely on learning per-node latent representations by utilizing the network structure, howe-

ver, implicit feedback relations are naturally sparse and contain only positive observed feedbacks which mean

that these approaches will treat all observed relations as equally important. This is not necessarily the case

in real-world scenarios as implicit relations might have semantic weights which reﬂect the strength of those

relations. If those weights can be approximated, the models can be trained to differentiate between strong and

weak relations. In this paper, we propose a weighted personalized two-stage multi-relational matrix factori-

zation model with Bayesian personalized ranking loss for network classiﬁcation that utilizes basic transitive

node similarity function for weighting implicit feedback relations. Experiments show that the proposed mo-

del signiﬁcantly outperforms the state-of-art models on three different real-world web-based datasets and a

biology-based dataset.

1 INTRODUCTION

The classiﬁcation of multi-label networks is one of

the widely used tasks in network analysis such as

in predicting or ranking user interests in social net-

works (Grover and Leskovec, 2016; Perozzi et al.,

2014; Krohn-Grimberghe et al., 2012), classifying

documents (Tang et al., 2015) in citation networks,

predicting web-page categories in large network of

websites and also in some biological domains such as

predicting protein labels in protein-protein interaction

networks (Grover and Leskovec, 2016).

The typical approach to predict node labels is by

extracting a set of informative features from each

node and train a classiﬁcation model on them. This

typical way of feature processing has two main sig-

niﬁcant drawbacks. First, to extract such informative

features, one needs a prior expert domain knowledge

to develop the features engineering process required

to preprocess the raw data. Second, to extract useful

features, a decent amount of raw information should

be embedded with each node such as user proﬁle de-

tails in social networks or document contents in cita-

tion networks. This kind of node embedded informa-

tion might not always be available or accessible due

to privacy settings.

Alternatively, current approaches rely on learning

latent features for each node by analyzing the net-

work structure and optimizing an objective function

that will increase the accuracy of predicting node la-

bels (Cai et al., 2018). Multi-relation matrix facto-

rization (Krohn-Grimberghe et al., 2012; Jamali and

Ester, 2010; Singh and Gordon, 2008) is one famous

example that follows this approach. This model re-

presents network relations as matrices, and it factori-

zes the target relation matrix into two smaller matri-

ces that represent the latent features of the interacting

nodes. The main advantage of these alternative ap-

proaches is that they can be better generalized to al-

most all network classiﬁcation tasks without any need

for feature engineering or expert domain knowledge.

However, they face signiﬁcant challenges with very

sparse networks and especially if these networks have

implicit feedback relations. These implicit relations

are dominantly very sparse, and relation edges are

either observed or unobserved without explicit weig-

Rashed, A., Grabocka, J. and Schmidt-Thieme, L.

Multi-Label Network Classiﬁcation via Weighted Personalized Factorizations.

DOI: 10.5220/0007681203570366

In Proceedings of the 11th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2019), pages 357-366

ISBN: 978-989-758-350-6

357

hts. In various real-world scenarios, those implicit

relations have hidden semantic weights (Lerche and

Jannach, 2014) which are not directly quantiﬁable but

can be approximated using different weighting functi-

ons such as similarity measures. Current approaches

that utilize the network structure to learn latent node

representations fail to realize these hidden weights of

implicit relations. A famous example of such relati-

ons is the friendship relation in social networks. This

relation is a type of implicit feedback relations that

models the interaction between nodes that have same

types, and it is expressed as sparsely observed edges

connecting those nodes. This kind of friendship rela-

tions frequently occurs in multi-relational settings and

it is not only for representing a relation between users,

but it can also represent a relation between any same

type nodes. In networks data, all of the friendship ob-

served edges would have the same importance weight

while in real-life, some friendship relations are stron-

ger than others. The real-life weights of such relati-

ons can be approximated by measuring the similarity

between each two interacting nodes. The main ad-

vantage of using similarity is that it can be calculated

using simple information from network structure such

as nodes degrees without any need of complex auxili-

ary information which might not be available such as

frequency interaction or timestamps.

In this work, we introduce a similarity based per-

sonalized two-stage multi-relation matrix factoriza-

tion model(Two-Stage-MR-BPR) for multi-label net-

work classiﬁcation and ranking. It utilizes the ba-

sic transitive node similarity for weighting implicit

friendship relations and a two-stage training protocol

to optimize the Bayesian personalized ranking loss.

By optimizing the BPR loss, the model will output a

ranked list of labels instead of only one label for any

target node which means it will be suitable for recom-

mender system problems and node classiﬁcation pro-

blems if we just assume the top label as the predicted

class.

The weighted Two-Stage-MR-BPR overcomes the

drawbacks of MR-BPR and outperforms it in all of

our experiments as it can distinguish between obser-

ved and unobserved relations along with learning the

different strength weights of the observed relations.

Our contributions can be summarized as follows :

• We utilize the transitive node similarity to approxi-

mate the semantic weights of all implicit relations

that have interacting nodes of the same type to al-

low the Two-Stage-MR-BPR model to learn the

strength weights of relations.

• We propose a generalized two-stage learning algo-

rithm that utilizes all available implicit and weig-

hted relations for training the MR-BPR model.

• We conduct multiple experiments on four real-

world datasets. The results show that the pro-

posed weighted Two-Stage-MR-BPR outperform

the MR-BPR and current state-of-art models in

multi-label and single-label classiﬁcation pro-

blems.

The rest of the paper is organized as follows. In

Section 2, we summarize the related work. We dis-

cuss the problem formulation of the multi-label clas-

siﬁcation task in section 3. In section 4, we present

and discuss the technical details of the Two-Stage-

MR-BPR model. We present the experiential results

in section 5. Finally, we conclude with discussing

possible future work in section 6.

2 RELATED WORK

Current approaches for multi-label node classiﬁcation

automate the process of features extraction and engi-

neering by directly learning latent features for each

node. These latent features are mainly generated ba-

sed on the global network structure and the connecti-

vity layout of each node. In earlier approaches such

as (Tang and Liu, 2009a; Tang and Liu, 2009b), they

produce k latent features for each node by utilizing

either the ﬁrst k eigenvectors of a generated modula-

rity matrix for the friendship relation (Tang and Liu,

2009a) or a sparse k-means clustering of friendship

edges (Tang and Liu, 2009b). These k features are

fed into an SVM for labels predictions.

Recently, semi-supervised (Thomas and Welling,

2016) and unsupervised approaches (Grover and Le-

skovec, 2016; Perozzi et al., 2014; Yang et al., 2015)

have been proposed to extract latent node represen-

tations in networks data. These models are inspi-

red by the novel approaches for learning latent repre-

sentations of words such as the convolutional neural

networks and the Skip-gram models (Mikolov et al.,

2013) in the domain of natural language processing.

They formulate the network classiﬁcation problem as

discrete words classiﬁcation problem by representing

the network as a document and all nodes as a sequence

of words. The Skip-gram can then be used to predict

the most likely labels for each node based on the as-

sumption that similar nodes will have same labels.

In (Krohn-Grimberghe et al., 2012), MR-BPR was

proposed as learning to rank approach for tackling the

multi-label classiﬁcation problem by extending the

BPR (Rendle et al., 2009) model for multi-relational

settings. This approach expresses the problem as a

multi-relational matrix factorization trained to opti-

mize the AUC measure using BPR loss. Each net-

work relation is represented by a sparse matrix and

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

358

the relation between nodes and labels will be the tar-

get being predicted. Because of the BPR loss, this

model is considered suitable for sparse networks with

implicit feedback relations; however, since all impli-

cit feedback connections are only observed or unob-

served, the MR-BPR fail to realize that some implicit

links are stronger than others in real-life. To solve this

drawback in the original single relation BPR model,

(Lerche and Jannach, 2014) proposed BPR++ an ex-

tended version of the BPR model for user-item rating

prediction. They utilized multiple weighting functi-

ons to approximate the logical weights between users

and items. Those functions relied on the frequency of

interaction and timestamps to weight each edge. In

the training phase, they randomly alternate between

learning to distinguish observed and unobserved re-

lations and learning to rank weighted observed rela-

tions. This learning approach expands the BPR ca-

pacity to differentiate between strong and weak con-

nections.

Finally, our proposed Two-Stage-MR-BPR mo-

del follow a similar intuition to that of BPR++ and

it considers the more general multi-relational set-

tings which allow it to be used for any multi-label

and single-label network classiﬁcation problems. The

proposed model utilizes the basic transitive node si-

milarity for approximating the weights of implicit re-

lations that have interacting nodes of the same type.

In this work, we also propose MR-BPR++ an ex-

tended version of BPR++ for multi-relational set-

tings. The learning algorithm for Two-stage-MR-

BPR is different from MR-BPR++; it relies on two

consecutive non-overlapping learning stages instead

of random alternation. In the ﬁrst stage, it allows the

model to sufﬁciently learns to differentiate between

strong and weak relations and in the second stage, it

allows it to learns to differentiate between observed

and unobserved relations.

3 PROBLEM DEFINITION

The problem can be formulated similarly to (Krohn-

Grimberghe et al., 2012) as a relational learning set-

ting on network data. Let G = (V,E) be a network

where V is a set of heterogeneous nodes, and E is the

set of edges. Each node can be seen as an entity and

each edge represents a relation between two entities.

Let N := {N

,...,N

|N |

} be a set of node types

and each type has a set of nodes as instances N

(1)

(2)

,...,n

(|N

}. Let R := {R

,...,R

|R |

} be a

set of relations and each relation represents interacti-

ons between two speciﬁc node types N

and N

such

that R ⊆ N

× N

Our primary task in this paper is to predict mis-

sing edges in a primary target relation Y, and all other

relations will be considered auxiliary relations that

can be used to improve the prediction accuracy. In

multi-label network classiﬁcation, the relation Y re-

presents the relation between a set of nodes and la-

bels Y ⊆ N

Target

× N

Label

, such as the relationship

between multiple interests and users in social net-

works or document-labels and documents in citation

networks. Examples of auxiliary relations are the

friendship relation in social networks or citation links

in citation networks.

The task of predicting missing edges in the tar-

get relation can be formulated as a ranking problem

where we try to drive a ranked list of labels that re-

present the likelihood that a speciﬁc node belongs to

each of them.

In case of sparse auxiliary relations with implicit

edges, the current multi-relational matrix factoriza-

tion model with BPR loss (Krohn-Grimberghe et al.,

2012) does not exploit the full potential of the BPR

loss because it only distinguishes between observed

and unobserved edges without considering the edges

weights (Lerche and Jannach, 2014).

Our proposed approach addresses the shortco-

mings of the current multi-relational matrix factori-

zation model by ﬁrstly using transitive node simila-

rity for weighting the implicit auxiliary relations and

using a Two-Stage-MR-BPR learning algorithm that

can rank observed edges and distinguish between ob-

served and unobserved edges. The proposed approach

is also suitable for cold-start scenarios where only the

auxiliary relations information are available for the

target nodes.

4 PROPOSED MODEL

The proposed model can be formulated as a two-stage

multi-relational matrix factorization using basic tran-

sitive node similarity for weighting implicit relati-

ons. Initially, the transitive node similarity is used to

weight all observed edges in any implicit auxiliary re-

lations that has interacting nodes of the same type. In

the ﬁrst stage of learning, the model is trained to rank

edges based on their weights. In the second stage, the

model is trained to differentiate between observed and

unobserved edges. Figure 1 illustrates the workﬂow

of the Two-Stage-MR-BPR model and each step will

be discussed in details in the following subsections.

Multi-Label Network Classiﬁcation via Weighted Personalized Factorizations

359

1 1

1 1  1

1    

1   1 1

 1  

1  1  

TargetRelation

Nodes

Labels

AuxiliaryRelation

Nodes

? ? ?

1 1

0.33 0.2  0.25

0.33    

0.2   0.33 0.25

 0.33  

0.25  0.25  

TargetRelation

Nodes

Labels

AuxiliaryRelation

Nodes

? ? ?

1 1

TargetRelation

Nodes

Labels

5 3 0

0 3 1

TransitiveNodeSimilarity TwoStageMRBPR

TestData TrainData

Figure 1: Two-Stage-MR-BPR workﬂow. Initially, the transitive node similarity is used to weight all implicit relations with

same type interacting nodes followed by learning a two stage multi-relational matrix factorization on all relations using the

BPR loss to rank all labels with respect to each test node.

4.1 Basic Transitive Node Similarity for

Implicit Feedback Relations

In the relational learning setting, in order to apply

the two-stage MR-BPR learning technique we need

ﬁrst to convert all possible implicit feedback relati-

ons into weighted relations. To convert implicit re-

lations into weighted relations, one needs a suitable

weighting function that approximate relation weig-

hts by utilizing the available embedded information

in each relation such as frequency or timestamps of

interactions in user-item relations, or similarity mea-

sures in friendship relations. In the most basic case

where there is no available embedded information, an

implicit relation can be considered a relation that was

weighted by a constant weighting function which out-

puts only one value if it encounters an observed edge.

Friendship relations are one of the prominent ty-

pes of implicit relations in networks data. It can

represent any relation between nodes of the same

type such as users friendships in social networks or

web links between web pages or citation links be-

tween documents. For weighting edges in general

friendship relations, the similarity measures such as

Adamic/Adar, common neighbors, Jaccard index and

friend transitive node similarity FriendTNS (Symeo-

nidis et al., 2010) are considered the best candida-

tes to act as weighting functions (Symeonidis et al.,

2010; Liben-Nowell and Kleinberg, 2007). In our

proposed approach we used the FriendTNS function

because it provided superior accuracy over other si-

milarity functions (Symeonidis et al., 2010; Ahmed

et al., 2016) in link prediction tasks and it requires mi-

nimum auxiliary information from the network struc-

ture. FriendTNS was used for weighting all the obser-

ved edges in all available implicit friendship relations

and it was calculated only for observed edges because

it is computationally expensive to calculate weights

for all possible node pairs in very sparse networks.

The FriendTNS similarity between two nodes is cal-

culated using equation (1).

FT NS(n

) :=

(

deg(n

)+deg(n

)−1

, if (n

) ∈ R

0, if (n

) /∈ R

(1)

where deg(n

) and deg(n

) is the degree of nodes n

and n

respectively. In case of directed graphs, we

used the summation of the node’s in-degree and out-

degree as the total degree.

4.2 Multi-eelational Matrix

Factorization with Basic Transitive

Node Similarity

To formulate the problem as a multi-relational matrix

factorization, each node type N

can be represented by

a matrix E

∈ R

|×k

where the rows are the latent fe-

ature vectors for all instances in the node type, and k

represents the number of latent factors deﬁned in the

model. Similarly, each implicit relation R can be re-

presented by a matrix R ∈ R

|×|N

where N

and

are the two types of the interacting nodes inside

relation R. Each entry in the relation matrix is given

R(n

(i)

( j)

) :=











Weight(n

(i)

( j)

), if(n

(i)

( j)

) ∈ R

unobserved, if(n

(i)

( j)

) /∈ R

(2)

where Weight(n

(i)

( j)

) is the weighting function

used to approximate the weights of implicit relation

between any two nodes such as similarity functions

in case of friendship relations or frequency of inte-

raction in case of user-item relations. If no available

embedded information can be used to weight relati-

ons, a constant weighting function is assumed.

Finally, each relation R can be approximated by

multiplying the latent matrices of the two relation

node types E

and E

such that R ≈ E

× E

. For

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

360

simplicity, we deﬁne a set of all the model parameters

Θ := {E

,...,E

|N |

} which contain the matrices of

all nodes types and our general objective will be to

ﬁnd the set of matrices Θ that minimize the sum of

losses over all relations.

4.3 Two-stage MR-BPR

The original BPR model (Rendle et al., 2009) assu-

mes that for a given user u, any item i this user in-

teracted with should be ranked higher than any item

j he did not interact with. In order to do so, the BPR

model learns to maximize the difference ˆx

u,i, j

between

the predicted rating ˆr(u, i) for an observed item i and

the rating ˆr(u, j) for an unobserved item j.

To follow the same notation in a multi-relational

setting, for any given relation R, the user u will repre-

sent a node of type N

, while i and j will represents

two nodes of type N

. For each relation R the base-

line MR-BPR model samples a set of triples D

which

is deﬁned as follows:

:= {(u, i, j)|(u,i) ∈ R ∧ (u, j) /∈ R}

The sampling is done using bootstrap sampling

with replacement. The model is then trained to max-

imize the difference between the predicted ratings of

the observed edges and unobserved edges for all rela-

tion using equations (2) and (3).

BPR-Opt(R,E

) =

∑

(u,i, j)∈R

lnσ( ˆx

u,i, j

) (3)

MR-BPR(R,Θ) =

∑

R∈R

BPR-Opt(R,E

)

∑

E∈Θ

||E||

(4)

where σ is the sigmoid logistic function and α

is the

loss weight for relation R. By following this learning

approach, the MR-BPR model learns to distinguish

between observed edges and unobserved edges over

iterations. This approach is not optimal as it fails to

realize the different semantic weights of the implicit

relations. In (Lerche and Jannach, 2014) they pro-

posed a new learning technique for the original BPR

model called BPR++ which extend the BPR to learn

weighted relations. There proposed extension allow

the BPR model to provide better rankings for item

ratings by utilizing the timestamps and frequency of

user interactions to weight user-item edges. BPR++

is randomly alternating between learning to rank ob-

served weighted edges and learning to distinguish be-

tween observed and unobserved edges. Instead of

using such random alternation between the two lear-

ning tasks for multi-relational settings, we propose a

two-stage learning approach that decouple the two le-

arning tasks and learn them sequentially to avoid in-

formation overwrites across iterations. When applied

to multi-relational settings, the proposed two-stage le-

arning protocol and BPR++ will utilize a separate set

of triples D

beside the original set D

. This new

set contains observed weighted edges sampled using

bootstrap sampling with replacement for each availa-

ble weighted relation as follows:

:= {(u, i, j)|Weight(u,i) > Weight(u, j)∧

(u,i) ∈ R ∧ (u, j) ∈ R}

The main difference between the proposed two-

stage learning protocol and BPR++ is that the later

will rely on random alternating sampling from D

and

which introduce the risk of having information

loss as some iterations might overwrite the previously

learned information, e.g. if an node was selected ﬁrst

as an observed item from D

and in the next itera-

tion it was selected as the lower weighted item from

, the second iteration will overwrite the informa-

tion gained in the ﬁrst iteration as it will decrease the

score of the item after it has been increased. On the

other hand, Two-Stage-MR-BPR overcome such pro-

blem by learning to rank all weighted edges ﬁrst then

it learns to distinguish observed and unobserved ed-

ges afterward with no overlap between the two stages

in each epoch. This means that the second stage will

shift the learned scores of the observed edges away

from the unobserved ones while maintaining the lear-

ned rankings between the weighted observed edges.

In our experiments, we applied both learning pro-

tocols on the MR-BPR model for performance com-

parison and we used the basic FriendTNS similarity

as weighting function for all implicit relations where

the participating nodes have the same type. In each

learning epoch during the training phase, the num-

ber of sampling steps for D

and D

is equal to the

number of observed edges ObsEdges

in R, similar to

the original BPR (Rendle et al., 2009) and MR-BPR

(Krohn-Grimberghe et al., 2012) models. The genera-

lized algorithms for training the Two-Stage-MR-BPR

and MR-BPR++ are described in Figures 2 and 3.

In the experiments section, we compared the two

models against each other and the original MR-

BPR model. The results showed that the proposed

two-stage model provides better accuracy for multi-

relational settings where we have multiple sparse rela-

tions without timestamps or frequency of interactions

that can be used to weight relations.

Multi-Label Network Classiﬁcation via Weighted Personalized Factorizations

361

Table 1: Datasets Statistics.

Type Nodes Labels Edges Features Sparsity

BlogCatalog Undirected 10312 39 667966 - 99.37%

PPI Undirected 3890 50 76584 - 99.49%

Wiki Directed 2405 19 17981 - 99.68%

Cora Directed 2708 7 5429 1433 99.92%

1: procedure TWO-STAGE-MR-BPR(D, R , Θ)

2: Initialize All E ∈ Θ

3: repeat

4: for R ∈ R do

5: // (Stage One)

6: if D

6= φ then

7: for ObsEdges

times do

8: draw (u,i,j) from D

9: Θ ← Θ + µ

∂(MR-BPR(R,Θ))

∂Θ

10: end for

11: end if

12: // (Stage Two)

13: for ObsEdges

times do

14: draw (u,i,j) from D

15: Θ ← Θ + µ

∂(MR-BPR(R,Θ))

∂Θ

16: end for

17: end for

18: until convergence

19: return Θ

20: end procedure

Figure 2: Two-Stage-MR-BPR algorithm with learning rate

µ and L2 regularization λ

1: procedure MR-BPR++(D, R ,Θ)

2: Initialize All E ∈ Θ

3: repeat

4: for R ∈ R do

5: r = random(0, 1)

6: if r ≤ β ∧ D

6= φ then

7: draw (u,i,j) from D

8: else

9: draw (u,i,j) from D

10: end if

11: Θ ← Θ + µ

∂(MR-BPR(R,Θ))

∂Θ

12: end for

13: until convergence

14: return Θ

15: end procedure

Figure 3: MR-BPR++ algorithm with learning rate µ, pro-

bability threshold β and L2 regularization λ

5 EXPERIMENTS

5.1 Datasets

We applied the Two-Stage MR-BPR and MR-BPR++

on four network classiﬁcation datasets from four dif-

ferent domains. The ﬁrst three datasets contain two

relations while the fourth dataset is a citation network

where nodes have an embedded feature vector that

can be considered as third relations.

• BlogCatalog (Zafarani and Liu, 2009) : This da-

taset represents a large social network from the

BlogCatalog website. It has two relations, a tar-

get relation which represents the relation between

groups and users, and an auxiliary relation repre-

senting the friendship between users.

• Wiki (Tu et al., 2016) : This dataset represents a

network of Wikipedia web pages. It also has two

relations, a target relation which represents the ca-

tegories of the web pages, and an auxiliary rela-

tion that represents links between the web pages.

• Protein-Protein Interactions (PPI) (Breitkreutz

et al., 2007) : This dataset is a network of protein-

protein interactions for homo sapiens. It has two

relations, a target one which represents the rela-

tion between protein-labels and proteins, and an

auxiliary relation that represents the interactions

between proteins and other proteins. This dataset

was used to check how well our proposed model

performs in non-web-based domains.

• Cora (Sen et al., 2008) : This dataset represents a

citation network where each document has 1433

binary feature vector representing words occur-

rence. This dataset can be considered as having

three relations, a target relation which represents

the class label of a document, an auxiliary relation

that represents citation links between documents

and a ﬁnal auxiliary relation that represents a re-

lation between a document and words that exist in

this document.

Table 1 shows the detailed statistics of the datasets.

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

362

5.2 Baselines

• MR-BPR (Krohn-Grimberghe et al., 2012) : The

original MR-BPR model that utilizes implicit

auxiliary relations for ranking node labels. This

model does not utilize transitive node similarities.

• DeepWalk (Perozzi et al., 2014) : One of the well-

known models for multi-label network classiﬁca-

tion. This model learns node latent representati-

ons by utilizing uniform random walks in the net-

work.

• Node2Vec (Grover and Leskovec, 2016) : This is

one of the state-of-art models for multi-label net-

work classiﬁcation and can be seen as a generali-

zed version of DeepWalk with two guiding para-

meters p and q for the random walks.

• GCN (Thomas and Welling, 2016) : This model is

one of the state-of-art models for document clas-

siﬁcation in citation networks. It relies on multi-

layered graph convolutional neural network for le-

arning network representation with text features.

• TADW (Yang et al., 2015) :This model is also one

of the state-of-art models for document classiﬁca-

tion in citation networks. It is an extended version

of the original Deep Walk model for learning net-

work representation with text features.

On Cora dataset, our proposed model was compared

only against GCN and TADW because they require

nodes with embedded textual features which is mis-

sing in the ﬁrst three datasets. On the other hand

DeepWalk and Node2Vec where not used on Cora da-

taset because they can’t represent nodes with embed-

ded features.

5.3 Experimental Protocol and

Evaluation

We followed the same experimental protocol in

(Krohn-Grimberghe et al., 2012; Perozzi et al., 2014;

Grover and Leskovec, 2016). We used 10-fold cross-

validation experiments on each target relation. These

experiments were applied using different percentages

of labeled nodes ranging from 10% to 90%. In each

experiment, we only used the deﬁned percentage of

labeled nodes for training along with all the auxiliary

relations, while the remaining percent of nodes were

used for testing. We used Micro-F1 and Macro-F1

measures for performance evaluation on Blog Cata-

log, PPI and Wiki Dataset, and Accuracy on Cora Da-

taset.

We used the same hyper-parameters that were

used in the original baselines’ papers, and grid-search

was used to ﬁnd the best hyper-parameters if none

were mentioned for the target dataset.

5.4 Results

The experimental results on the four datasets are

shown in Tables 2, 3, 4, 5, and Figure 4. The re-

sults shows that Two-Stage-MR-BPR with transitive

node similarity outperformed the original MR-BRP

model in all train-splits. In comparison with other

well-known models for multi-label network classiﬁ-

cation, the Two-Stage-MR-BPR model outperformed

the state-of-art Node2Vec over all trains-splits on Blo-

gCatalog, PPI and Wiki datasets. It is worthy to note

that all improvements over Node2Vec are statistically

signiﬁcant with a p-value less than 0.01 using pai-

red t-test. Two-Stage-MR-BPR also outperformed

DeepWalk over all trains-splits on BlogCatalog and

PPI, while on Wiki, DeepWalk only achieved bet-

ter Macro-F1 scores on the 20%, 30%, and 40%

trains-splits. The results also show that Two-Stage-

MR-BPR outperformed all other models in terms of

Micro-F1 with 40% less data using the 50% train-split

on the BlogCatalog dataset. On PPI, It outperformed

all other models in terms of Micro-F1 and Macro-

F1 with 30% less data using the 60% train-split. On

the other hand, the document classiﬁcation results on

the Cora datasets show that Two-Stage-MR-BPR out-

performed the state-of-art models on 10% and 90%

splits, while it achieves comparable results on the

50% train-splits.

In comparison with Two-Stage-MR-BPR, MR-

BRP++ also outperformed MR-BRP on BlogCatalog

over most of the train splits, but it had minimal per-

formance gains in some train-splits on PPI, Wiki and

Cora. These results demonstrate the importance of

using transitive node similarity to weight implicit re-

lations, and they show that using two sequential non-

overlapping stages to train the BPR loss is better than

randomly alternating between ranking observed edges

and distinguishing them from unobserved edges.

5.5 Reproducibility of the Experiments

For each model we used the following hyper-

parameters during in experiments.

• MR-BPR: The hyper-parameters are k = 500, µ =

0.02, λ

user

= 0.0125, λ

item

= 0.0005, 300 ite-

rations and α = 0.5 for BlogCatalog; k = 500,

µ = 0.01, λ

protein

= 0.0125, λ

label

= 0.0005, 400

iterations and α = 0.5 for PPI; k = 600, µ =

0.02, λ

page

= 0.0125, λ

label

= 0.0005, 1000 ite-

rations and α = 0.5 for Wiki; and k = 900, µ =

Multi-Label Network Classiﬁcation via Weighted Personalized Factorizations

363

Table 2: Mutli-lable classiﬁcation results on BlogCatalog dataset.

%Lable Nodes 10% 30% 50% 70% 90%

Micro-F1(%) DeepWalk 33.71 38.22 39.37 40.64 41.11

Node2Vec 33.72 38.33 39.98 40.75 42.16

MR-BPR 36.16 39.24 40.68 40.39 40.64

MR-BPR++ 35.47 39.49 40.84 40.99 41.14

Two-Stage-MR-BPR 37.27** 40.49** 42.22** 42.03** 42.51*

Macro-F1(%) DeepWalk 18.19 23.61 25.32 27.20 27.84

Node2Vec 19.24 24.70 26.80 27.80 29.15

MR-BPR 22.21 26.20 27.95 28.49 29.13

MR-BPR++ 22.03 26.55 28.19 29.12 29.62

Two-Stage-MR-BPR 23.18** 26.91** 28.69** 29.54** 30.55*

Signiﬁcantly outperforms MR-BPR at the: ** 0.01 and * 0.05 levels.

Table 3: Mutli-lable classiﬁcation results on PPI dataset.

%Lable Nodes 10% 30% 50% 70% 90%

Micro-F1(%) DeepWalk 15.89 18.68 20.85 22.35 24.11

Node2Vec 15.09 17.52 20.38 22.02 22.65

MR-BPR 17.11 20.87 22.61 23.55 23.44

MR-BPR++ 16.97 20.62 22.46 23.33 23.56

Two-Stage-MR-BPR 18.21** 21.88** 23.31** 24.78** 25.38**

Macro-F1(%) DeepWalk 12.73 15.41 18.50 18.49 19.15

Node2Vec 12.17 14.51 18.01 18.89 18.76

MR-BPR 12.88 16.83 18.81 19.54 19.48

MR-BPR++ 12.71 16.58 18.66 19.54 19.66

Two-Stage-MR-BPR 13.96** 17.96** 19.43** 20.72** 21.41**

Signiﬁcantly outperforms MR-BPR at the: ** 0.01 and * 0.05 levels.

Table 4: Mutli-lable classiﬁcation results on Wiki dataset.

%Lable Nodes 10% 30% 50% 70% 90%

Micro-F1(%) DeepWalk 56.04 63.52 65.03 66.73 66.27

Node2Vec 57.24 61.40 62.45 63.76 62.61

MR-BPR 58.10 65.54 68.66 70.24 71.71

MR-BPR++ 59.56 65.61 68.56 69.99 70.34

Two-Stage-MR-BPR 60.40** 66.16 69.21 71.18 72.84

Macro-F1(%) DeepWalk 44.33 57.16 56.21 58.71 61.20

Node2Vec 42.95 51.96 52.25 53.25 55.04

MR-BPR 44.41 53.23 57.50 59.17 63.99

MR-BPR++ 46.58 54.01 57.62 59.29 62.79

Two-Stage-MR-BPR 47.35** 54.41* 58.33 60.32 65.16

Signiﬁcantly outperforms MR-BPR at the: ** 0.01 and * 0.05 levels.

Table 5: Document classiﬁcation results on Cora dataset.

%Lable Nodes 10% 50% 90%

Accuracy(%) GCN 78.37 86.53 86.39

TADW 75.24 85.99 85.60

MR-BPR 75.03 78.76 81.66

MR-BPR++ 76.24 78.10 81.10

Two-Stage-MR-BPR 79.30** 84.20 86.86

Signiﬁcantly outperforms GCN at the: ** 0.01 and * 0.05 levels.

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

364

0.2 0.4 0.6 0.8

Micro F1(%)

BlogCatalog

0.2 0.4 0.6 0.8

PPI

0.2 0.4 0.6 0.8

Wiki

0.2 0.4 0.6 0.8

Macro F1(%)

0.2 0.4 0.6 0.8

Two-Stage-MR-BPR Node2Vec MR-BPR MR-BPR++. DeepWalk.

0.2 0.4 0.6 0.8

Figure 4: Evaluation of the Two-Stage-MR-BPR model against other baseline models. The x axis denotes the percent of

labeled nodes used in the training phase, while the y axis denotes the Micro-F1 and Macro-F1 scores.

0.03, λ

document

= 0.005, λ

label

= 0.0001, λ

words

0.0001, 1400 iterations and α = 0.33 for Cora.

• MR-BPR++: The hyper-parameters are β = 0.75,

k = 500, µ = 0.02, λ

user

= 0.0125, λ

item

= 0.0005,

300 iterations and α = 0.5 for BlogCatalog; β =

0.75, k = 500, µ = 0.01, λ

protein

= 0.0125, λ

label

0.0005, 400 iterations and α = 0.5 for PPI; β =

0.75, k = 600, µ = 0.02, λ

page

= 0.0125, λ

label

0.0005, 1000 iterations and α = 0.5 for Wiki; and

k = 900, µ = 0.03, λ

document

= 0.005, λ

label

0.0001, λ

words

= 0.0001, 1400 iterations and α =

0.33 for Cora.

• Two-Stage-MR-BPR: We used the same hyper-

parameters of MR-BPR

• DeepWalk: The hyper-parameters are d = 128, r =

10, l = 80 and k = 10 for all datasets.

• Node2Vec: The hyper-parameters are d = 128, r =

10, l = 80, k = 10, p = 0.25 and q = 0.25 for

BlogCatalog; d = 128, r = 10, l = 80, k = 10,

p = 4 and q = 1 for PPI and Wiki.

• GCN: We used the same hyper-parameters from the

original paper. Dropout rate = 0.5, L2 regulariza-

tion = 5.10

−4

and 16 (number of hidden units)

• TADW: We used the same default hyper-

parameters from the original papers which

are k = 80 and λ = 0.2

6 CONCLUSIONS

In this paper, we proposed the similarity based Two-

Stage-MR-BPR model that exploits the full poten-

tial of the Bayesian personalized ranking as a loss

function. Two-Stage-MR-BPR relies on converting

all implicit feedback relations into weighted relations

using basic transitive node similarity to approximate

Multi-Label Network Classiﬁcation via Weighted Personalized Factorizations

365

the semantic weights of relations in the real world.

This conversion step allows the Two-Stage-MR-BPR

to learn ranking edges based on their weights and to

learn to distinguish observed edges from unobserved

ones. Experiments on four real-world datasets sho-

wed that Two-Stage-MR-BPR outperformed the ori-

ginal MR-BPR and other state-of-art models in the

task of multi-label network classiﬁcation and docu-

ment classiﬁcation. In future work, we are planning to

explore and integrate several possible approaches to

further expand the capacity of the BPR models. Two

of those possible approaches for expansion are lear-

ning nonlinear latent representation and using non-

uniform samplers (Rendle and Freudenthaler, 2014).

ACKNOWLEDGEMENTS

The authors gratefully acknowledge the fun-

ding of their work through the

UberDax project

(https://www.ismll.uni-hildesheim.de/projekte/

UberDax.html) which is sponsored by the Bundesmi-

nisterium fr Bildung und Forschung (BMBF) under

the grant agreement no. 01IS17053.

REFERENCES

Ahmed, C., ElKorany, A., and Bahgat, R. (2016). A super-

vised learning approach to link prediction in twitter.

Social Network Analysis and Mining, 6(1):24.

Breitkreutz, B.-J., Stark, C., Reguly, T., Boucher, L.,

Breitkreutz, A., Livstone, M., Oughtred, R., Lackner,

D. H., B

ahler, J., Wood, V., et al. (2007). The bio-

grid interaction database: 2008 update. Nucleic acids

research, 36(suppl 1):D637–D640.

Cai, H., Zheng, V. W., and Chang, K. (2018). A compre-

hensive survey of graph embedding: problems, techni-

ques and applications. IEEE Transactions on Know-

ledge and Data Engineering.

Grover, A. and Leskovec, J. (2016). node2vec: Scalable

feature learning for networks. In Proceedings of the

22nd ACM SIGKDD international conference on Kno-

wledge discovery and data mining, pages 855–864.

ACM.

Jamali, M. and Ester, M. (2010). A matrix factorization

technique with trust propagation for recommendation

in social networks. In Proceedings of the fourth ACM

conference on Recommender systems, pages 135–142.

ACM.

Krohn-Grimberghe, A., Drumond, L., Freudenthaler, C.,

and Schmidt-Thieme, L. (2012). Multi-relational ma-

trix factorization using bayesian personalized ranking

for social network data. In Proceedings of the ﬁfth

ACM international conference on Web search and

data mining, pages 173–182. ACM.

Lerche, L. and Jannach, D. (2014). Using graded implicit

feedback for bayesian personalized ranking. In Pro-

ceedings of the 8th ACM Conference on Recommen-

der systems, pages 353–356. ACM.

Liben-Nowell, D. and Kleinberg, J. (2007). The link-

prediction problem for social networks. journal of the

Association for Information Science and Technology,

58(7):1019–1031.

Mikolov, T., Chen, K., Corrado, G., and Dean, J. (2013).

Efﬁcient estimation of word representations in vector

space. arXiv preprint arXiv:1301.3781.

Perozzi, B., Al-Rfou, R., and Skiena, S. (2014). Deepwalk:

Online learning of social representations. In Procee-

dings of the 20th ACM SIGKDD international confe-

rence on Knowledge discovery and data mining, pages

701–710. ACM.

Rendle, S. and Freudenthaler, C. (2014). Improving pair-

wise learning for item recommendation from implicit

feedback. In Proceedings of the 7th ACM internatio-

nal conference on Web search and data mining, pages

273–282. ACM.

Rendle, S., Freudenthaler, C., Gantner, Z., and Schmidt-

Thieme, L. (2009). Bpr: Bayesian personalized ran-

king from implicit feedback. In Proceedings of the

twenty-ﬁfth conference on uncertainty in artiﬁcial in-

telligence, pages 452–461. AUAI Press.

Sen, P., Namata, G., Bilgic, M., Getoor, L., Galligher, B.,

and Eliassi-Rad, T. (2008). Collective classiﬁcation in

network data. AI magazine, 29(3):93.

Singh, A. P. and Gordon, G. J. (2008). Relational learning

via collective matrix factorization. In Proceedings of

the 14th ACM SIGKDD international conference on

Knowledge discovery and data mining, pages 650–

658. ACM.

Symeonidis, P., Tiakas, E., and Manolopoulos, Y. (2010).

Transitive node similarity for link prediction in social

networks with positive and negative links. In Procee-

dings of the fourth ACM conference on Recommender

systems, pages 183–190. ACM.

Tang, J., Qu, M., Wang, M., Zhang, M., Yan, J., and Mei,

Q. (2015). Line: Large-scale information network

embedding. In Proceedings of the 24th International

Conference on World Wide Web, pages 1067–1077.

International World Wide Web Conferences Steering

Committee.

Tang, L. and Liu, H. (2009a). Relational learning via latent

social dimensions. In Proceedings of the 15th ACM

SIGKDD international conference on Knowledge dis-

covery and data mining, pages 817–826. ACM.

Tang, L. and Liu, H. (2009b). Scalable learning of col-

lective behavior based on sparse social dimensions. In

Proceedings of the 18th ACM conference on Informa-

tion and knowledge management, pages 1107–1116.

ACM.

Thomas, N. K. and Welling, M. (2016). Semi-supervised

classiﬁcation with graph convolutional networks.

arxiv preprint. arXiv preprint arXiv:1609.02907, 103.

Tu, C., Zhang, W., Liu, Z., and Sun, M. (2016). Max-margin

deepwalk: Discriminative learning of network repre-

sentation. In IJCAI, pages 3889–3895.

Yang, C., Liu, Z., Zhao, D., Sun, M., and Chang, E. Y.

(2015). Network representation learning with rich text

information. In IJCAI, pages 2111–2117.

Zafarani, R. and Liu, H. (2009). Social computing data re-

pository at asu.

ICAART 2019 - 11th International Conference on Agents and Artiﬁcial Intelligence

366
