Fuzzy Logic Decision based Collaborative Privacy Management

Framework for Online Social Networks

Gulsum Akkuzu, Benjamin Aziz and Mo Adda

School of Computing, University of Portsmouth, Portsmouth, U.K.

Keywords:

Privacy Management, Online Social Networks, Data Security Features, Fuzzy Logic.

Abstract:

Online Social Networks (OSNs) have become one of the most popular implement for interacting with people

all over the world and sharing data with them. These data sometimes may be a co-owned data which involves

multiple users, sharing co-owned data can cause privacy violation if co-owners are not happy with the owner’s

sharing privacy settings. To tackle privacy issues on co-owned data, collaborative privacy management has

become a popular research area in recent years. In this work, we provide a fuzzy logic decision based col-

laborative privacy management framework for OSNs. We use data sensitivity value and conﬁdence value in

targeted group as input variables of fuzzy system. We also use trust values between users since our framework

needs to calculate trust loss and gains for reputation value.

1 INTRODUCTION

Online Social Networks (OSN) are popular all over

the world, since they offer information sharing, social

communications, and attractive interactions among

people. There are various social networking sites in

the Internet such as Facebook, Google+, Twitter, We-

Chat, Linked-In, etc. Facebook is one of the social

network sites in which people are allowed to share dif-

ferent types of context such as video, photo, message,

event, etc. These contents may include their personal

life information, private information and the content

may be disclosed to wider audience than they actu-

ally intended for. Sensitive information of users are

stored in OSNs, however, most users are unaware of

shared contents’ features. Protecting information is

one of crucial concerns, therefore OSNs need to pro-

vide mechanisms for protecting users’ data.

Users can upload content to their own space and

other users’ spaces also. They are allowed to tag

users, which may cause privacy leakage. Current

OSNs allow users to regulate access to the data that

is on their own space, however, they can not control

or take precaution for contents that are shared by ot-

her users and include their information. It is most li-

kely to see the leakage of sensitive information while

data is being publicised (Hu et al., 2015). Beside the

service providers of OSNs take precaution to prevent

data breach, users can also adjust their data access

control by using the privacy setting function imple-

mented in OSNs (Xu et al., 2011). Facebook has

provided users different levels of privacy protection

countermeasure that users can decide who is allowed

to contact them, see their stuff, and search them. A

access to other user’s data. OSNs use user relations-

hips and group membership to distinguish trusted and

untrusted users (Hu and Ahn, 2011). OSNs provide

simple access control that allows users to control in-

formation on their own spaces, however, users can-

not control or in other words have no rights to control

data, that is related to them, outside of their space.

Current Online Social Networks have provided

restrictions on users who can access data, however,

there is no restrictions who posts data. There is one

side data restriction on data even if data is co-owned

data which involves more than one user. However,

privacy management of co-owned data requires col-

laborative privacy management. Even though some

online social networks provide chances to co-owners,

who have rights to manage permissions of a co-owned

data, which is related to them, either with tagging or

face-recognition techniques we do not see any beneﬁt

for those who are not tagged or notiﬁed.

In this work, we provide a collaborative privacy

management on the shared data from multiple asso-

ciated users. Different from previous studies, which

assume all users are tagged by owner or use identiﬁ-

cation technique, we assume the owner who intends

to share co-owned data notiﬁes co-owners and allows

674

Akkuzu, G., Aziz, B. and Adda, M.

Fuzzy Logic Decision based Collaborative Privacy Management Framework for Online Social Networks.

DOI: 10.5220/0007702206740684

In Proceedings of the 5th International Conference on Information Systems Security and Privacy (ICISSP 2019), pages 674-684

ISBN: 978-989-758-359-9

fuzzy decision system to make a decision based on

co-owners’ privacy requirements on the data. We

use fuzzy logic on decision making process in which

decision is not restricted with the Boolean decision

’Yes’ or ’No’. We deﬁne multi-value set in decision

making with Fuzzy Logic Decision Making System

’Yes’, ’Maybe’, ’No’. Based on the owner’s ﬁnal de-

cision on data co-owners’ trust in owner either incre-

ases or decreases, end of the sharing process our fra-

mework updates the owner’s reputation. In short, the

main contributions of this work as follows:

• A fuzzy decision making system is proposed for

making decision in OSNs. The result of fuzzy de-

cision making system affects the privacy loss cal-

culation and changes on owner’s reputation value.

• Exploring the connection between data sensitivity

and trust in targeted group for sharing sensitive

data. The sensitivity value of data and conﬁdence

value in targeted group are gathered together for

making decision of fuzzy system .

2 RELATED WORKS

Collaborative Privacy Management is a challenge for

OSNs since all users have different privacy require-

ments. Hence, it is very possible to see conﬂicts on

shared contexts in OSNs. Although privacy manage-

ment mechanism has restrictions on users who want

to access data, there is no restriction on users who

post data. However, users who post data may vio-

late other users’ privacy. Recent works have focused

on conﬂicts among users’ privacy policies, they ﬁrst

have aimed to detect the conﬂicts, then generate an

aggregation policy that resolves the conﬂicts. The ag-

gregated policies are not the solution since there are

still privacy loss issues in OSNs.

Researchers have worked on the problem of col-

lective privacy management of co-owned data even

though OSNs do not yet set restrictions on the co-

owned data. This problem was addressed by Squic-

ciarini et al.(Squicciarini et al., 2009), they proposed

a solution for privacy management for photo sharing

in OSNs, this means that each co-owner can specify

their own privacy preference for the shared content.

They adopt the Clarke-Tax mechanism to provide col-

lective enforcement in shared content, they evaluate

their work with Game Theory. The usability is an is-

sue for this work, they do not take all stockholders’

privacy preferences.

Wishart et al.(Wishart et al., 2010) provided a

collaborative privacy policy authoring in the context

of social networking, they allowed the originator of

the data to specify policies for the content, however,

their work does not consider co-owners’ privacy po-

licy speciﬁcations.

Hu (Hu et al., 2015) proposed a collaborative ma-

nagement of shared data in OSNs, it is a simple but

ﬂexible mechanism. The mechanism provides con-

ﬂict resolution that considers both the privacy risk and

data sharing loss.

Suvitha (Suvitha.D, 2014) formulated a multi-

party access control and policies, he used voting me-

chanism for making decision on co-owned data. Col-

laborative privacy management issue might be descri-

bed mother of the privacy conﬂicts. Therefore, it is an

inevitable point to be involved while the co-privacy

management of shared data is considered.

Joseph (Joseph, 2014) proposed a solution for

privacy risk and sharing loss for collaborative data

sharing in online social network. The work proposes

an algorithm to identify conﬂict segments in accessor

space.

A framework was developed for protecting and

securing co-owned data for public OSN by Shaukat

et al. (Ali et al., 2017). They pointed that the pri-

vacy risk is seen not only from unauthorized users

but also from the OSNs service providers, they used

cartographic-based technique in their framework to

overcome privacy concerns.

Recently, a work has been proposed to address

collaborative privacy management with an agent-

model (Ulusoy, 2018). He has proposed to modify

Clarke-Tax mechanism that was used in (Squicciarini

et al., 2009). Du et al, proposed an evolutionary game

model that analyses how a user’s data privacy pro-

tection is affected by other users’ privacy decisions

(Du et al., 2018).

All given above studies generally assume that

there is a service provider (mediator) that knows each

users’ privacy policies for data items. However, there

are studies that consider mediator is unnecessary and

not taking trust into consideration. In the literature

there are also studies which exclude service provi-

der from the scope, and they use involved users feed-

backs for making owner’s ﬁnal decision (Xu et al.,

2019; Rathore and Tripathy, 2017). We use the same

approach with those studies which consider media-

tor is unneeded, however, we use fuzzy logic decision

making system to help co-owners (in other words sta-

keholders who are involved to data). In the previous

studies, owner of data asks co-owners opinion on the

data whether they want to share data with decision=1

or they do not want to share the data with decision=0.

The decision does not have just Boolean value, de-

cision would be between 0=no and 1=yes which can

be named maybe. We take this point into our consi-

Fuzzy Logic Decision based Collaborative Privacy Management Framework for Online Social Networks

675

deration, also in the previous works data sensitivity

has been decided by the owner, however, data sensiti-

vity would be different for each co-owners, therefore,

we develop a system which asks to each co-owners

opinions on the data sensitivity value. We think such

a system is more realistic and practical, considering

collaborative privacy management in OSNs.

3 SYSTEM MODEL

A social network structure involves a set of actors and

a set of connection between these actors. An OSN

is represented as a directed-graph G = (V, E), where

V is the set of nodes (actors, users) and E is the set

of relationships among actors. A simple online so-

cial network has nodes and edges, where nodes repre-

sent users and edges present a relationship between

users in the graph representation of online social net-

works. User relationships are divided into two groups,

namely symmetric and asymmetric (Rathore and Tri-

pathy, 2017). In our case, we use both symmetric and

asymmetric discrimination for trust value adjustment,

i.e., we use t

(

i j

)

∈ [0,1], which shows u

’s trust in u

For instance, if u

has the symmetric relation to u

then t

(

i j

)

could have a high value, most possibly full

trust.

3.1 Overview of Fuzzy-decision based

Framework

We provide our proposed algorithm and its explanati-

ons in this section (see Algorithm 1).

• An owner starts the process by uploading data.

Then choose the trust threshold and the priority

criteria. The priority choice is either Co-owner

Trust Preferential, in which co-owners’ trust value

in owner is in priority, or Owner Trust Preferential

in which owner trust values in co-owners is prefer-

red for data sharing process and trust-reputation

calculations.

• Once the owner chooses requirements for the ﬁrst

step then s/he needs to notify co-owners by giving

them details for which data s/he intends to share

and the group of people (targeted group) who will

access the data.

• Fuzzy Decision Making Step: It allows co-owners

to rate on data CIA properties for the sensitivity

value, and conﬁdence value for targeted group

which is calculated based on relations that are

between co-owners and members of the targeted

group people.

Result: Updated Reputation value of owner

while Owner upload the data, adjust the

privacy settings,notify co − owners do

if Co-owners:rate CIAPP features ;

then

activate the fuzzy decision

mechanism;

Result of Fuzzy decision making

system;

else

Wait till CIAPP ratings are completed

end

if preference: co-owner trust then

Pl → equation11;

TrustlossandTrustgain → Equations 13

and 12;

if valueo f equation12 ≤

valueo f equation13 then

share data with full permission

else

if T h

t r

≤ Avg

t r

then

share data with like and view

permission

else

Do not share

end

else

if fuzzy decision Yes or Maybe then

if 0.7 ≤ dec

then

share data with full permission

else

share data with like and view

permission

end

else

Do not share

end

Algorithm 1: Algorithm of FuLoBaF.

• After a fuzzy system gives the decision value on co-

owned data, the second part of framework works

through.

∗ if the co-owner trust was chosen by the owner in

step 1, then the privacy loss is calculated with the

given equation 9. Trust gain and trust loss are cal-

culated with the privacy loss, according to equa-

tion 10 and equation 11. If the trust gain is hig-

her than the trust loss, then the data can be shared

with no access restriction on data. Otherwise, the

average of co-owners’ trust in owner is calculated

and compared with the threshold that needs to be

ForSE 2019 - 3rd International Workshop on FORmal methods for Security Engineering

676

decided by the owner in step 1. If the average trust

value is greater than the threshold value, then the

data is shared with some access restrictions on it-

self (i.e. viewers (targeted group of people) can

view and like it but can not share it). The ﬁnal

need is to update owner reputation and gained or

decreased trust values of co-owners in the owner.

∗ if the owner’s trust was chosen in step 1 by the ow-

ner, then the system chooses at least half of the

co-owners who have the highest trust values in

owner. If choosing co-owners’ rates on the sensi-

tivity (CIA properties) without concerns, then the

data are shared with a full permission. Otherwise,

the framework checks the fuzzy membership de-

gree, i.e., the intensity score of the decision.

3.2 Details of Fuzzy Decision Making

Procedure

In the framework, co-owners’ decisions are taken

with the fuzzy system. The system has two inputs and

one output, where the data sensitivity and conﬁdence

in the targeted group are deﬁned as the inputs and the

decision is deﬁned as the output. A fuzzy decision is

based on the fuzzy logic in which the decision values

are ranged from 0 to 1 rather than binary values (0 or

1).

A fuzzy set is deﬁned as (U, µ) in which U repre-

sents the universe set of elements and µ represents the

membership function with the membership degrees of

the elements to the set U, i.e., x ∈ U → µ(x) ∈ [0, 1].

Based on the system and data, the shapes of the

membership functions are chosen. There are various

shapes of membership functions that can be chosen

for a fuzzy set, such as triangle, trapezoid, and rec-

tangle. It can be clearly seen that trapezoid functions

can be viewed as a generalization of triangular and

rectangular membership functions. As shown in Fi-

gure 1, if a=b and c=d, then the shape of the members-

hip function would become rectangle. On the other

hand, if b=c, then the shape would become triangle.

Figure 1: Trapezoid Membership Function.

The membership function of the trapezoidal fuzzy

set is deﬁned by a function,f(x), and essentially de-

pends on four parameters a,b,c,d as given below.

(x) =











0, x ≤ a or x ≥ d (1)

x − a

b − a

, a ≤ x ≤ b (2)

1, b ≤ x ≤ c (3)

d − x

d − c

, c ≤ x ≤ d (4)

There are two ways to deﬁne membership functions,

either expert knowledge can be used to deﬁne mem-

bership functions (Mamdani and Assilian, 1999) or

data can be used to induce the membership functions

using machine learning techniques (Hosseini et al.,

2012), (Jamsandekar and Mudholkar, 2014).

A fuzzy rule based system mainly involves three

operations, namely, fuzziﬁcation, inference, and de-

fuzziﬁcation. In the fuzziﬁcation step, a numerical

value is mapped into a membership degree according

to a membership function. In the inference stage, ru-

les are deﬁned with the linguistic terms of input va-

riables and the linguistic term of the output variable.

For example,

· x is A: antecedent

· Rule: If x is A then y is B

· y is B: consequent

In a given fuzzy rule x is A and y is B can be true

to a degree, instead of being entirely true or false

(Koyuncu and Yazici, 2005), the antecedent may be

composed of one condition or multiple conditions

connected by the AND or OR logical operators. For

example;

· Rule 1: If x

is A

AND x

is A

THEN decision=

· Rule 2: If x

is A

OR (x

is A

AND x

is A

)

THEN decision=D

· Rule m: If x

is A

AND x

is A

THEN

decision=D

is an indication of a linguistic term in which n

represents A’s input attribute and m represents the rule

index. D

represents a decision label, k is the decision

index.

This fuzzy rule based system can be seen in Figure

2. The system basically has three steps: fuzziﬁcation,

inference process, and

• Fuzziﬁcation: Obtains membership degree values

mapped from crisp values, i.e., it aims to map the

Fuzzy Logic Decision based Collaborative Privacy Management Framework for Online Social Networks

677

Figure 2: Fuzzy Expert System with proposed work sample

rules.

value of each continuous attribute to the members-

hip degrees to the fuzzy sets deﬁned for the conti-

nuous attribute.

• Inference Process: Obtains the membership degree

to the consequent of each rule, i.e. a fuzzy output

from each rule is derived, and then combines the

fuzzy outputs of all the rules by using a fuzzy ag-

gregation operator, in order to derive the overall

membership degree.

• Defuzziﬁcation: Converts the derived overall

membership degree into a crisp value as the out-

put of the fuzzy system.

4 DATA GENERATION

Dataset: We conduct our work on both real world

data and synthetic data. We use the Facebook data

from Stanford large network data set collection (snap

Facebook Data, 2016). We also generate a network

by using the network packages supported by Harberg

et al. (Hagberg et al., 2008). The generated network

has 1000 nodes and 20000 undirected edges.

To test our equations and proposed system usabi-

lity, we have simulated data for sensitivity and conﬁ-

dence values. An owner decides the sensitivity value

in all the previous work. However, the data sensiti-

vity value may not be the same one for co-owners as

owner’s concern. In our work, co-owners decide how

sensitive the co-owned data is for them. To do simula-

tion, we formulate the sensitivity value with ﬁve fea-

tures of Evolutionary Circles of Information Security

(Cherdantseva and Hilton, 2012) which considers that

data security is based on fourteen features. The Evo-

lutionary Circles of Information Security model has

ﬁve circles that are separated with regard to subject of

protection and security goals. We choose ﬁve features

that are related to information security in the network

area. The equation of data sensitivity is as follows;

∑

i=1

∗ (w

))

∑

j=1

( f

)

(5)

represents the data sensitivity, it ranges [0,1].

The numerator gives the summation of the data CI-

APP probabilities, in which P − i indicates the proba-

bility of CIAPP concerns that is voted by co-owners

and w

is the weight of the properties. The denomina-

tor indicates the total number of features.

We also formulate the conﬁdence value based on

the owner trust relation with targeted group members,

co-owners’ trust relations with targeted group mem-

bers, and sensitivity value that is given in equation 1.

We ﬁrst show the calculation of the trust relation;

: f (r

, r

, ...., r

osi

) =

∑

j=1

o j

)

(6)

represents the owner’s trust in each member of tar-

geted group and S

represents the size of the targeted

group.

: f (r

, r

, ...., r

csi

) =

∑

j=1

c j

)

(7)

represents the co-owner’s trust in each mem-

ber of the targeted group and S

represents the size of

the targeted group.

From equations 2 and 3, we ﬁnalize the trust rela-

tion with the following formula;

R = R

∗

∏

k=1

(8)

R is the trust in the targeted group with the owner’s

trust in the group i R

, also with the each co-owner’s

trust in group i.

With the equations 1,2 and 3, we can now calcu-

late the Conﬁdence value in targeted group as follows;

= 1 − S

∗ (1 − R) (9)

Below ﬁgure shows the changes of Conﬁdence va-

lue based on the sensitivity and relation values (see

equation 9.

Our dataset (see Table 1) has sensitivity value and

conﬁdence value, these two variables values are obtai-

ned with the above equations (see 5 and 9). The data-

set is used for fuzzy logic decision.

Our Fuzzy Inference System has two inputs varia-

bles and one output variable. We used triangular and

ForSE 2019 - 3rd International Workshop on FORmal methods for Security Engineering

678

Figure 3: 3D graph of Conﬁdence value with the Sensitivity

and Conﬁdence value.

Table 1: Sample of Sensitivity and Conﬁdence Input Values

of Fuzzy System.

sensitivity conﬁdence

0.5 0.5

0.1 0.9

0.2 0.9

0.3 0.9

0.4 0.8

0.9 0.5

0.9 0.1

0 1

0.12 1

0 0.98

1 0

trapezoidal membership functions. To generate tri-

angular membership functions of Figure 4 and 5, we

used the fuzzy c-means clustering algorithm to gene-

rate clusters and to construct membership functions.

• Input variables’ values and output variable values

are formed into three clusters, and these three

clusters’ centers are used the centers of triangu-

lar fuzzy membership functions.

• The maximum and minimum values of each cluster

are used as two vertexes values of each of triangu-

lar membership functions.

• The maximum and minimum values for the trian-

gular membership functions are formed by incre-

asing and decreasing b vertex values.

• In trapezoidal membership functions, the values of

variables are calculated by increasing the mini-

mum vertex value of the triangular membership

function and decreasing the maximum vertex va-

lue of triangular membership function .

We have twelve rules for our fuzzy system, and

the rules are given in Table 2.

As it is seen on the table, we use the ‘AND’ opera-

tor in which the minimum value among membership

functions is picked up, while the ‘OR’ operator picks

up the maximum value among the membership functi-

ons.

Figure 4 and 5 illustrate transformation of the lin-

guistic variables x

and x

to numerical values.

Figure 4: Linguistic terms’ membership functions for sen-

sitivity input.

Figure 5: Linguistic terms’ membership functions for con-

ﬁdence input.

5 EXPERIMENTS AND RESULTS

In this section, we ﬁrst give the experiments in the

framework’s fuzzy part. After getting the decision re-

sult from the fuzzy decision making part, we give use

cases to show the applicability of the proposed frame-

work.

Table 3 presents the decision output depending

on two input values, which are sensitivity and con-

ﬁdence. The decision is given with its decision calcu-

lation.

Figure 6 and Figure 7 are the presentations of

the decision making computation. Figure 6 indica-

tes that the decision is ‘maybe’ if the sensitivity value

is low

0.2

and the conﬁdence value is medium

. Si-

milarly, Figure 7 shows the decision is ‘no’ if the sen-

sitivity is high

0.8

and the conﬁdence is verylow

0.1

Examples. In this section, we present the usability of

our framework.

Let us assume Daniel has a photo with Alice, Bob,

and Dan. Daniel notiﬁes those people to solicit their

ideas for sharing. She aims to share the photo with a

group of her friends, which consists of ﬁve hundred

people.

Fuzzy Logic Decision based Collaborative Privacy Management Framework for Online Social Networks

679

Table 2: The proposed work rules.

Rule number Rule

1 If x

is low AND x

is verylow then decision=maybe

2 If x

is low AND x

is low then decision=maybe

3 If x

is low AND x

is medium then decision=maybe

4 If x

is low AND x

is full then decision=yes

5 If x

is medium AND x

is verylow then decision=no

6 If x

is medium AND x

is low then decision=maybe

7 If x

is medium AND x

is medium then decision=maybe

8 If x

is medium AND x

is full then decision=yes

9 If x

is high AND x

is verylow then decision=no

10 If x

is high AND x

is low then decision=no

11 If x

is high and x

is medium then decision=maybe

12 If x

is high AND x

is full then decision=yes

Table 3: Decision Making Fuzzy System with Input and Output Variables’ Values.

Input 1 (sensitivity) Input 2 (conﬁdence) Output (decision)

medium

low

0.33

maybe

high

0.8

verylow

0.1

low

0.2

medium

maybe

low

0.2

high

0.8

yes

.84

high

0.9

medium

maybe

high

0.9

low

0.3

0.17

high

medium

0.1

Figure 6: Maybe Decision Value.

Figure 7: No Decision Value.

Example 1: Our framework continues with the co-

owner trust preferential because Daniel chooses this

option at the beginning.

We calculate the privacy loss with the data sensi-

tivity and the number of authorised people by owner

but unauthorised people by co-owners.

(co) = S

∗ |

| (10)

The privacy loss is calculated for co-owners who

think their privacy is violated by the owner. Data

security features choices show whether they worry

about their privacy. If a co-owner chooses any of the

data security features, then s/he shows her/his con-

cern on the privacy. If there is no selection on the data

security features, then we do not consider s/he wor-

ries about her privacy. We use the following rules for

classifying users based on their concerns.

f ull − worry : ∀i ∈ 1, 2, ......, n : rate

= 1

partly − worry : ∃i ∈ 1, 2, ......,n : rate

= 1

no − worry : ∀i ∈ 1, 2, ......, n : rate

= 0

(co) = S

∗ |

coi

| (11)

Equation 12 indicates the co-owners trust loss in

owner if they are worried about any of the CIAPP data

security features. It depends on the privacy loss if a

co-owner does not have privacy loss, it means privacy

loss means is 0, then we do not calculate the trust loss

for them. If the privacy loss is not equal to 0, then

trust loss is as follows;

T l(pl) =

1 − pl

1 + pl

(12)

In equation 12, n is the mood of co-owners, where

n belongs to N. The mood refers to states of co-

owners’ mind on the data sharing process.

ForSE 2019 - 3rd International Workshop on FORmal methods for Security Engineering

680

Table 4: Co-owners’ rates on data security features.

Co-owner’s id Conﬁdentiality Integrity Availability Privacy Possession

Alice 1 0 0 0 0

Bob 0 0 1 0 0

Dan 0 0 0 1 0

Alice 0 0 1 1 1

Bob 1 1 1 0 0

Dan 0 1 1 0 0

Table 5: Co-owners’ relations with the targeted group’s pe-

ople.

The number of known

Co-owner’s id people in targeted group

(NKP)

Alice 200

Bob 100

Dan 500

Equation 13 is used for co-owners who do not con-

sider that sharing the data cause the privacy violation

(Xu et al., 2011). If someone is in the no-worry class

and has the privacy loss value which is equal to 0, then

the owner gains trust in them by sharing the data.

h(t

) = t

, (0 < a < 1)(Xuet al., 2011) (13)

rep(u

) =

∑

6=u

)

∑

i=n

i=1

)

(14)

Equation 14 gives the calculation the owner’s repu-

tation. It is calculated with the summation of co-

owners’ trust in owner and the number of co-owners

on the data. We can calculate the Daniel’s reputation

after he shared the data. The reputation value beco-

mes rep(Daniel)= 0.33. Let us assume that his repu-

tation value was 1 before he shared the data, and the

new reputation value is calculated as follows;

Nrep(u

) = |rep(u

)

− rep(u

)| (15)

Nrep(u

) represents the new reputation value,

rep(u

)

indicates the reputation value after sharing

the data, and rep(u

) is the reputation value before

the data was shared. Nrep(Daniel) = 0.7.

Case: Alice is Owner of a Data and Chooses Co-

owner Trust Preferential: Let us assume Alice plans

to have an event. She wants Daniel and Bob to parti-

cipate for organizing it. Therefore, she notiﬁes them

and solicits their opinions to share event invitations.

The targeted group for the event is Alice’s friends,

which consists of seven hundred people in it.

Table 11 shows the choices of Bob and Daniel on

the data security features (CIAPP) .

The following tables show values of S

, R,C f , P

, ht

. Based on the rates of the data security featu-

res, they are both in partly-worry and full-worry class.

Therefore, the trust loss value needs to be calculated

for both of co-owners.

Case: Alice is Owner of a Data and Chooses Ow-

ner Trust Preferential: In this case, Our framework

goes through with owner’s trust preferential. The de-

gree of a fuzzy decision is important. The fuzzy sy-

stem involve two inputs: s

and C

. Table 13 repre-

sents the values of s

and C

. With regard to our fuzzy

rules, the decision degree becomes no

0,2

. This means

that the framework will not share the data, since the

degree of a decision does not belong to Yes or Maybe.

Alice will not loss values on her reputation.

Example 2: The framework checks the fuzzy deci-

sion whether is maybe or yes. If it is not, then the sy-

stem ends the process without sharing the data. If the

decision is maybe or yes, then the framework checks

the degree of decision if it is greater than 0.7, which is

the transition value between yes and maybe, then the

co-owned data is shared with no restricted permissi-

ons on it. However, if it is less than 0.7, then the data

is shared with the ‘like’ and ‘view’ permissions. The

reputation value is an updated end of the sharing pro-

cesses.

6 DISCUSSION

The important point of the proposed framework is that

it involves using a fuzzy system and trust values be-

tween the owner and their co-owners . It encourages

users to solicit co-owners’ opinions before sharing the

data. It has a kind of punishment and reward system

in which if the owner shares data with the decision

which is against the co-owners’ decision, then s/he

losses value on her reputation, otherwise, s/he gains

value for her reputation.

Fuzzy logic is applied to remove bivalent decisi-

ons from decision making process in OSNs, this is

because the real life situations and human thought are

not restricted to bivalent logic (yes/no). With fuzzy

logic based decision system we can have the degree of

the decision and use the degrees. It can help owners

to ﬁnalise the decision that helps to make sufﬁcient

decision on data sharing process.

Fuzzy Logic Decision based Collaborative Privacy Management Framework for Online Social Networks

681

Table 6: The values of Sensitivity, Relation, and Conﬁdence.

Case id Sensitivity (sd) Relations (R) conﬁdence (cf)

Case1 0.2 0.533 0.906

Case2 0.53 0.533 0.47

Table 7: Trust values before sharing the data.

Daniel’s Trust in Co-i Co-id Co-i s Trust in Daniel

0.5 Alice 0.7

0.8 Bob 0.6

0.3 Dan 1

Table 8: Privacy loss for each co-owner who are in class

full-worry or partly-worry and co-owners’ trust loss in ow-

ner.

Case 1 Co-owner-id privacy-loss Trust-loss

Case1 Alice 0.12 0.78

Bob 0.16 0.72

Dan 0 NA

For the experimental study on the fuzzy decision

making part, we use simulated data as mentioned in

the data preparation section. The ranges of values are

given in the same section. The data set includes data

sensitivity S

, which is simulated with the equation 8,

the conﬁdence value for the targeted group, and de-

cision that is taken with the fuzzy system. The result

of a fuzzy decision making system is shown in Table

3. Our data set is based on the subjective evaluations,

i.e., the experts make the evaluations and the rules’

deﬁnitions are based on experts’ knowledge. While

the decision making system was built upon trust and

share rules, in this context, the phenomenon is that if

you trust someone, then you share your data. Howe-

ver, you do not trust your data with untrusted people.

In comparison with the previous studies on col-

laborative privacy management in OSNs, our frame-

work involves various approaches for collaborative

privacy management in OSNs. Previous studies either

allow owner to share co-owned data without asking

co-owners’ opinions , or they ask co-owners whet-

her their decision is yes or no. However, a real deci-

sion is generally not, Fuzzy Logic allows an intensity

score of the decision to be ranged from 0 to 1. In our

case, we used the fuzzy logic context on the decision

making part and use the outcome value in the data

sharing process. In addition, co-owned data sensiti-

vity is settled only by the owner in the previous stu-

dies. However, the sensitivity is also co-owners’ con-

cerns. Therefore, our framework allows co-owners to

express their concerns on data sensitivity with CIAPP

security features. Our framework encourages owners

to solicit their co-owners opinions when the co-owned

data is intent to share. At the end of the data process,

if the owner makes a decision in favour of co-owners,

Table 9: Co-owners’ trust gain in owner.

Case 1 Co-owner-id Trust-gain

Case1 Dan 1

Table 10: Trust values after sharing the data.

Daniel’s Trust Co-id Co-i s Trust

in Co-i in Daniel

0.5 Alice 0

0.8 Bob 0

0.3 Dan 1

then most possibly the reputation of the owner is not

damaged. Otherwise, the owner looses the value on

reputation.

This work proposes an effective fuzzy decision ba-

sed collaborative privacy management framework for

Online Social Networks. The fuzzy approach is used

for making decision based on the data sensitivity and

the conﬁdence value in the targeted group in Online

Social Networks. One of the aims is to use a fuzzy

decision making system instead of asking co-owners’

decision whether the data is shared, i.e., we ask co-

owners which data security features (CIAPP) are in

threat if the data is shared with people who will access

the data. Another aim of this work is to encourage

users to preserve co-owners privacy. The trust gain

and the trust loss values are used for the beneﬁt of

owner and co-owners. In example 1 and example 2,

we show the effects of trust gain and trust loss values

on owner’s reputation.

7 CONCLUSION

In this paper, we have proposed an effective frame-

work which has a fuzzy logic based decision system

and provides a collaborative privacy management on

co-owned data in OSNs. To help the co-owners on de-

cision of sharing co-owned data, we use related data

security features (CIAPP) and ask co-owners con-

cerns on CIAPP. In our work, co-owners are not for-

ced to give their Boolean (i.e. Non-fuzzy) decision

(0 or 1), all they need to do is to choose CIAPP fea-

tures that may be a reason for their information vi-

olation. When an owner wants to share data, it is

needed to set the privacy policy on the data i.e tar-

geted group, co-owners of the data, owner trust or

co-owner trust preferential. Then the owner notiﬁes

co-owners and asks their opinions on the CIAPP fea-

ForSE 2019 - 3rd International Workshop on FORmal methods for Security Engineering

682

Table 11: Co-owners’ rates on data security features.

Co-owner’s id Conﬁdentiality Integrity Availability Privacy Possession NKP

Bob 1 1 1 0 0 100

Daniel 1 1 1 1 1 0

Table 12: Trust values before sharing the data.

Alice’s Trust in Co-i Co-id Co-i s Trust in Alice p − loss T − loss ﬁnal-trust-in Alice

0.6 Bob 0.7 0.68 0.47 0.23

0 Daniel 0.5 0.8 0.21 0.29

Table 13: Co-owners’ rates on data security features.

R C f

0.8 0.07 0.256

tures. Once co-owners choose which CIAPP features

are their worries, then the fuzzy logic based decision

system infers the decision. After getting the decision

from the fuzzy logic based system, our system goes

through the sharing process. If the owner choose the

co-owner trust preferential when they set their privacy

policy up on the data, then our system calculates the

privacy loss, the trust loss, and the trust gain values. If

the owner shares the data with targeted group without

considering the co-owners’ choices on the CIAPP fe-

atures, the the owner looses the value on their reputa-

tion. However, if the owner chooses the owner trust

preferential in the beginning, then they do not loss

value on their reputation, since the fuzzy decision is

based on the co-owners choices on CIAPP features.

It is clearly seen that the fuzzy logic decision based

system helps users to make trade-off sharing the data

and getting beneﬁts out of sharing data with incre-

ment on the reputation value.

REFERENCES

Ali, S., Rauf, A., Islam, N., and Farman, H. (2017). A fra-

mework for secure and privacy protected collaborative

contents sharing using public osn. Cluster Computing.

Cherdantseva, Y. and Hilton, J. (2012). The evolution of

information security goals from the 1960s to today.

Unpublished.

Du, J., Jiang, C., Chen, K.-C., Ren, Y., and Poor, H. V.

(2018). Community-structured evolutionary game

for privacy protection in social networks. IEEE

Transactions on Information Forensics and Security,

13(3):574–589.

Hagberg, A., Swart, P., and S Chult, D. (2008). Explo-

ring network structure, dynamics, and function using

networkx. Technical report, Los Alamos National

Lab.(LANL), Los Alamos, NM (United States).

Hosseini, R., Qanadli, S. D., Barman, S., Mazinani, M., El-

lis, T., and Dehmeshki, J. (2012). An automatic appro-

ach for learning and tuning gaussian interval type-2

fuzzy membership functions applied to lung cad clas-

siﬁcation system. IEEE Transactions on Fuzzy Sys-

tems, 20(2):224–234.

Hu, H. and Ahn, G.-J. (2011). Multiparty authorization fra-

mework for data sharing in online social networks. In

Li, Y., editor, Data and Applications Security and Pri-

vacy XXV, pages 29–43, Berlin, Heidelberg. Springer

Berlin Heidelberg.

Hu, V. C., Kuhn, D. R., and Ferraiolo, D. F. (2015). At-

tribute based access control. IEEE Computer Society,

48(1):85–88.

Jamsandekar, S. S. and Mudholkar, R. R. (2014). Fuzzy

classiﬁcation system by self generated membership

function using clustering technique. BVICA M’s Inter-

national Journal of Information Technology, 6(1):697.

Joseph, N. S. (2014). Collaborative data sharing in online

social network resolving privacy risk and sharing loss.

IOSR-JCE) eISSN, pages 2278–0661.

Koyuncu, M. and Yazici, A. (2005). A fuzzy knowledge-

based system for intelligent retrieval. IEEE Transacti-

ons on Fuzzy Systems, 13(3):317–330.

Mamdani, E. and Assilian, S. (1999). An experiment

in linguistic synthesis with a fuzzy logic control-

ler. International journal of human-computer studies,

51(2):135–147.

Rathore, N. C. and Tripathy, S. (2017). A trust-based colla-

borative access control model with policy aggregation

for online social networks. Social Network Analysis

and Mining, 7(1):7.

snap Facebook Data, S. (2016). Stanford large network

dataset collection. www.kaggle.com/lightcc/stanford-

snap-facebook-data.

Squicciarini, A. C., Shehab, M., and Paci, F. (2009). Col-

lective privacy management in social networks. In

Proceedings of the 18th international conference on

World wide web, pages 521–530. ACM.

Suvitha.D (2014). Mechanisms of multiparty access cont-

rol in online social network. International Journal of

Recent Development in Engineering and Technology,

2, (3).

Ulusoy, O. (2018). Collaborative privacy management in

online social networks. In Proceedings of the 17th

International Conference on Autonomous Agents and

MultiAgent Systems, pages 1788–1790. International

Foundation for Autonomous Agents and Multiagent

Systems.

Wishart, R., Corapi, D., Marinovic, S., and Sloman, M.

(2010). Collaborative privacy policy authoring in a

Fuzzy Logic Decision based Collaborative Privacy Management Framework for Online Social Networks

683

social networking context. In Policies for distributed

systems and networks (POLICY), 2010 IEEE interna-

tional symposium on, pages 1–8. IEEE.

Xu, L., Jiang, C., He, N., Han, Z., and Benslimane, A.

(2019). Trust-based collaborative privacy manage-

ment in online social networks. IEEE Transactions

on Information Forensics and Security, 14(1):48–60.

Xu, S., Li, X., Parker, T. P., and Wang, X. (2011). Exploi-

ting trust-based social networks for distributed pro-

tection of sensitive data. IEEE Transactions on In-

formation Forensics and Security, 6(1):39–52.

ForSE 2019 - 3rd International Workshop on FORmal methods for Security Engineering

684
