A Formal Modeling Scheme for Analyzing a Software System Design

against the GDPR

Evangelia Vanezi, Georgia M. Kapitsaki, Dimitrios Kouzapas and Anna Philippou

Department of Computer Science, University of Cyprus, Nicosia, Cyprus

Keywords:

GDPR, Privacy Protection, π-calculus, Static Analysis, Privacy by Design.

Abstract:

Since the adoption of the EU General Data Protection Regulation (GDPR) in May 2018, designing software

systems that conform to the GDPR principles has become vital. Modeling languages can be a facilitator for

this process, following the principles of model-driven development. In this paper, we present our work on the

usage of a π-calculus-based language for modeling and reasoning about the GDPR provisions of 1) lawfulness

of processing by providing consent, 2) consent withdrawal, and 3) right to erasure. A static analysis method

based on type checking is proposed to validate that a model conforms to associated privacy requirements. This

is the ﬁrst step towards a rigorous Privacy-By-Design methodology for analyzing and validating a software

system model against the GDPR. A use case is presented to discuss and illustrate the framework.

1 INTRODUCTION

Privacy protection is now more crucial than ever, and

this is reﬂected in the new EU General Data Protec-

tion Regulation (GDPR) (European Parliament and

Council of the European Union, 2015). The GDPR

has been applied since May 25th, 2018 not only to or-

ganizations established in the EU, but also to non-EU

established organizations that process personal data

of individuals who are located in the EU. The GDPR

deﬁnes multiple principles and rights for EU residents

in regard to personal data collection, storage and pro-

cessing. All existing systems must be reviewed and

adapt their processes accordingly, and new systems

must be built and function in a way that ensures their

GDPR compliance.

As this change is recent, there have only been few

attempts to understand the GDPR, mainly from the

legal perspective, and even fewer discussing mech-

anisms to support GDPR compliance (Gjermundrød

et al., 2016; Hintze and LaFever, 2017). In the con-

text of this work, our aim is to discuss the GDPR with

regard to data collection and processing as this need

arises in software systems, and to propose a rigor-

ous methodology for embedding GDPR compliance

into a software engineering development methodol-

ogy, speciﬁcally into the design and modeling phase,

As deﬁned in GDPR Article 4(1), personal data is any

information relating to an identiﬁed or identiﬁable natural

person (’data subject’)

using a π-calculus (Milner et al., 1992) based for-

mal modeling scheme exploiting the Privacy calcu-

lus (Kouzapas and Philippou, 2017). Additionally,

we present an extension to the Privacy calculus in-

tegrating the notion of granting and withdrawing con-

sent. The ulterior, long-run objective of our work is to

provide a rigorous framework for developing GDPR-

compliant systems that can support the entire soft-

ware development methodology, thus pursuing con-

formance to Privacy by Design (PbD) or, as referred

to in the GDPR, Data Protection By Design (Rubin-

stein, 2011).

Speciﬁcally, in this paper we describe the integra-

tion of the following principles of the GDPR within a

formal framework for reasoning about privacy-related

properties: lawfulness of processing by providing

consent, consent withdrawal, and right to erasure. In

particular, we build on the Privacy calculus, a pro-

cess calculus based on the π-calculus with groups

extended with constructs for reasoning about private

data (Cardelli et al., 2000). We extend the Privacy

Calculus syntax and semantics, in order to include

the aforementioned GDPR principles. Furthermore,

we associate the calculus with a type system that

validates the proper processing of data inside a sys-

tem and we prove that a well-typed system satisﬁes

the above mentioned GDPR requirements. We argue

that the resulting framework can be used for provid-

ing models of software systems while supporting the

static analysis of GDPR compliance during the design

Vanezi, E., Kapitsaki, G., Kouzapas, D. and Philippou, A.

A Formal Modeling Scheme for Analyzing a Software System Design against the GDPR.

DOI: 10.5220/0007722900680079

In Proceedings of the 14th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2019), pages 68-79

ISBN: 978-989-758-375-9

phase. Furthermore, we discuss the possibility for fu-

ture additions to the framework, incorporating more

GDPR provisions, in order to support an almost fully

compliant software model design and veriﬁcation.

We consider the type system accompanying our

framework to be a promising dimension of our ap-

proach, since it enhances the methodology with the

ability to statically validate models against formally-

deﬁned privacy policies. This approach is comple-

mentary to veriﬁcation by model-checking and has

the advantage that it does not require the construction

of a system’s state space, which may yield the state-

space explosion problem. Moreover, this dimension

of our proposal can be transferred to the development

phase of software systems through proper tools to-

wards the generation of GDPR-compliant code. Thus,

as future work we envision the development of the

framework into programming semantics and analy-

sis tools for supporting the software engineering de-

velopment phase and the construction of privacy-

respecting code following the Privacy by Design prin-

ciple.

The remainder of the paper is structured as fol-

lows. In Section 2, we discuss some background

work: we present the Principle of Data Protection by

Design and the use of modeling languages during the

design phase of the software development cycle. We

then provide a quick overview of the π-calculus and

the Privacy calculus. In Section 3, we introduce the

Privacy calculus as a language to model a software

system handling private data, and in Section 4 we pro-

pose an extension to the Privacy calculus that incorpo-

rates the GDPR principles of lawfulness of processing

by providing consent, consent withdrawal and right to

erasure into the software’s model. Section 5 presents

this framework formally and it develops a type system

for guaranteeing compliance to privacy-related prop-

erties pertaining to the GDPR principles under inves-

tigation. Finally, Section 6 concludes the paper and

discusses possible directions for future work. Due to

lack of space, proofs of results are omitted. Further-

more, for the complete exposition to the Privacy cal-

culus the reader is referred to (Kouzapas and Philip-

pou, 2017).

2 BACKGROUND AND RELATED

WORK

2.1 Data Protection by Design

Privacy by Design was introduced by the Dutch Data

Protection Authority (Data Protection and Privacy

Commissioners, 2010) and the former Information

and Privacy Commissioner of Ontario, Canada, Ann

Cavoukian (Cavoukian, 2008) having as a result of

their joint project a published report (Hes and Bork-

ing, 1998) as explained in (Hustinx, 2010). It advo-

cates that privacy should be incorporated into systems

by default and should be a priority from the beginning

of a system’s design. Similarly, the GDPR (European

Parliament and Council of the European Union, 2015)

deﬁnes Data Protection by Design in Article 25(1) as

“implementing the appropriate technical and organi-

zational measures in order to meet the requirements

of the Regulation and protect the rights of data sub-

jects”. Consequently, the obligation of software de-

velopers to build systems designed to be compliant to

the GDPR becomes apparent.

By its deﬁnition, Data Protection by Design needs

no speciﬁc distinct analysis, handling and mecha-

nisms in order to be fulﬁlled. If all principles and

rights are correctly embedded in a system’s speciﬁ-

cations model and are transferred into the succeeding

implementation, then Data Protection by Design will

also be guaranteed. Moreover, Data Protection by

Design advocates the proactive consideration of pri-

vacy issues: ensuring a software’ compliance should

take place from the design phase and possible pitfalls

should be anticipated and prevented before they can

materialise, rather than remedied on a reactive basis.

In the literature, different approaches to PbD have

been proposed. PriS is a security requirements engi-

neering method that integrates privacy requirements

in the early stages of the system development pro-

cess (Kalloniatis et al., 2008). It focuses on the impact

of privacy requirements onto the organizational pro-

cesses and on suggesting implementation techniques

for realizing these requirements. privacyTracker con-

siders the GDPR and proposes a framework that sup-

ports some of its basic principles including data trace-

ability and allowing a user to get a cryptographically

veriﬁable snapshot of her data trail (Gjermundrød

et al., 2016). PbD for Internet of Things and relevant

steps that should be followed for assessing applica-

tions is discussed in (Perera et al., 2016).

2.2 Software Design and Modeling

During the design phase, a software system model is

usually developed capturing the requirements speci-

ﬁed during the requirements analysis step. Such a

model presents a view of the software at a suitable

level of abstraction by visualizing, specifying and

documenting all artifacts and aspects of software sys-

tems. To this effect, modeling languages have been

developed and are employed for providing system

A Formal Modeling Scheme for Analyzing a Software System Design against the GDPR

models, a notable example being the Uniﬁed Mod-

eling Language (UML) (Fowler, 2004). Extensions

to UML have been proposed, such as UMLsec that

allows to express security relevant information for

a system speciﬁcation (J

urjens, 2002), the Privacy-

aware Context Proﬁle (PCP) that can be exploited in

context-aware applications (Kapitsaki and Venieris,

2008) and the Privacy UML proﬁle that can be used

to capture the privacy policies of a software sys-

tem (Basso et al., 2015). These models can be sub-

sequently used to test whether the design meets the

system speciﬁcations, but also to produce the sys-

tem source code skeleton following the paradigm of

Model Driven Engineering (MDE) (Schmidt, 2006;

Kapitsaki et al., 2008). A previous work using mod-

eling to analyze the system design and propose secu-

rity and privacy controls that can improve it can be

found in (Ahmadian et al., 2018). In this framework,

a privacy impact assessment (PIA) methodology is in-

troduced. Other works rely on ontologies and model-

ing in the Web Ontology Language (OWL) or the Re-

source Description Framework (RDF), such as Linked

USDL Privacy (Kapitsaki et al., 2018). However, due

to their semi-formal nature and lack of precise seman-

tics, modeling languages as the above do not support

the formal veriﬁcation of property satisfaction of sys-

tem models.

Formal methods aim to address this challenge by

providing languages and tools for the rigorous speci-

ﬁcation, development and veriﬁcation of systems. In

this paper, we focus on one such formalism, namely

the π-calculus and we argue that it can provide the

basis of a modeling language for software systems

that may additionally support veriﬁcation, including

the validation of conformance to privacy requirements

from the design phase of a software system therefore

fulﬁlling the Data Protection by Design GDPR re-

quirement. The π-calculus has been used for formal-

izing aspects of the UML modeling language (Lam,

2008), as well as for transforming the basic work-

ﬂow patterns of Business Process Model and Nota-

tion (BPMN) into equivalent π-calculus code (Bous-

setoua et al., 2015). It has also formed the theo-

retical basis of the Business Process Modeling Lan-

guage (BPML) (Havey, 2005) and of Microsoft’s

XLANG (Thatte, 2001).

2.3 Modeling Software in a π-calculus

based Language

The π-calculus is a simple, concise but very expres-

sive process calculus that can describe concurrent pro-

cesses whose conﬁguration may evolve during com-

putation, such as mobile and web applications (Mil-

Table 1: Privacy Calculus Basic Syntax.

Functionality π-Calculus Term

Concurrency P|Q (1)

Input c?(x).P (2)

Output c!hvi.P (3)

Restriction (ν n)P (4)

Replication ∗P (5)

Matching if e then P else Q (6)

Nil (stopped) process 0 (7)

Store

r  [ι ⊗δ] (8)

Systems G[P] | G[S] | S || S | (ν n)S (9)

ner et al., 1992). It is associated with formal se-

mantics which precisely deﬁne the behavior of a sys-

tem, based on which dynamic (e.g. model checking)

and static (e.g. type checking) analyses of systems

properties can be performed (Sangiorgi and Walker,

2003). A software system model expressed in a π-

calculus based language will include representations

of all components and entities of the system as pro-

cesses that are able to interact and communicate with

each other through communication channels. Chan-

nels can by dynamically created and even sent from

one process to another creating new communication

links between the processes, thus enabling the dy-

namic evolution of a system.

The core functionalities provided by the basic π-

calculus syntax are summarized in Table 1, lines (1)-

(7). Concurrent composition P | Q allows the parallel

execution of processes, i.e. system entities. Simi-

larly to software systems, concurrent processes may

proceed independently, each executing its own code,

while communicating with each other on shared chan-

nels referred to as names. In its basic form, the π-

calculus supports synchronous communication which

occurs through input and output of messages on chan-

nels. The input term, c?(x).P, describes a process

waiting to receive a message on channel c, result-

ing in variable substitution storing the message in

x, before proceeding as P. The output construct,

c!hvi.P, describes a process sending v as a message

on channel c and then proceeds as P. Restriction,

or new-name creation, (ν n)P, allows for the allo-

cation of a new name n inside the scope of process

P. Replication, ∗P, allows the creation of multiple

copies of process P. Matching or conditional con-

struct, if e then P else Q, can evolve as P if the

condition e is evaluated as true, or as Q otherwise. Fi-

nally, the terminated process, 0, deﬁnes a process that

has no interactions.

The operational semantics of the π-calculus con-

sists of a set of rules that describe the behavior of

each of the above constructs, thus allowing to con-

struct the possible executions of a deﬁned system. For

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

instance, in the case of the parallel composition con-

struct, it speciﬁes that whenever two processes are

able to send/receive a message respectively on the

same channel, then computation proceeds by the ex-

change of the message in a synchronized step after

which the processes will evolve to their subsequent

state. As an example, consider the following com-

munication implementing the transmission of value

42 on channel a between two concurrent processes,

where −→ captures the evolution and where τ speci-

ﬁes the name of the transition being an internal com-

munication.

a!h42i.P| a?(x).Q

−→ P |Q{

}

Note that, on the receiving side after the interaction

the value 42 is substituted in the process continuation

on variable x as described by the notation Q{

2.4 The Privacy Calculus

Many different extensions of the π-calculus have been

considered in the literature. Among these works, nu-

merous studies have focused on security and privacy

properties. One such extension created with the pur-

pose of describing and analyzing cryptographic pro-

tocols is the spi-calculus (Abadi and Gordon, 1997),

whereas in (Cardelli et al., 2000) the π-calculus is ex-

tended with the notion of groups as types for chan-

nels which are used to statically prohibit the leakage

of secrets. Type systems have also been employed

in process calculi to reason about access control that

is closely related to privacy. For instance, the work

on the Dπ-calculus has introduced sophisticated type

systems for controlling the access to resources ad-

vertised at different locations (Hennessy et al., 2005;

Hennessy and Riely, 2002; Hennessy, 2007). Further-

more, discretionary access control has been consid-

ered in (Bugliesi et al., 2009) which similarly to our

work employs the π-calculus with groups, while role-

based access control (RBAC) has been considered

in (Braghin et al., 2006; Dezani-Ciancaglini et al.,

2010; Compagnoni et al., 2008). In addition, autho-

rization policies and their analysis via type checking

has been considered in a number of papers includ-

ing (Fournet et al., 2007; Backes et al., 2008; Bengt-

son et al., 2011).

In this paper, we extend the work of (Kouzapas

and Philippou, 2017), where the authors propose a

formal framework, the Privacy calculus, for captur-

ing privacy requirements. This framework is based

on (Cardelli et al., 2000). Speciﬁcally, as shown in

Table 1, lines 8 and 9, the Privacy calculus introduces

the notion of personal data, id ⊗ c that associate iden-

tities, id, with values, c. It also extends process terms

with stores of private data r  [id ⊗ c], which are pro-

cesses that store and provide access to private data.

These stores are accessed through names, r, called

references. Processes are organized in groups, G[P],

which associate each entity P with an identiﬁer/role G

in the system.

As such, personal data as deﬁned in the GDPR can

be represented in the Privacy calculus by associating

each piece of plain data with an identiﬁer value, id⊗c.

The privacy calculus also enables the form ⊗ c to

associate data with a hidden identity. The collection

of stores in a system can be thought of as a database

table, managed by a database manager process. Other

processes can hold a reference to a store, to access,

read, and process the data. The type system ensures

that data manipulation conforms to a system policy,

which speciﬁes how each process/role in the system

may process private date.

Furthermore, the Privacy calculus provisions al-

low the analysis of privacy-related requirements. To

begin with, the notion of a group ensures secrecy.

This is achieved by associating channels with groups,

which are types for channels. No channel of a cer-

tain group can be communicated to processes outside

the scope of the group, as in (Cardelli et al., 2000).

This task can be checked statically. The Privacy cal-

culus goes a step further by associating processes with

groups, and uses the group memberships of processes

to distinguish their roles within systems. The frame-

work is accompanied by a type system for capturing

privacy-related notions and a privacy language for ex-

pressing privacy policies. The policies enable to spec-

ify how the various agents, who are referred to by

their groups, or roles, may or may not handle the sys-

tem’s sensitive data. In the current work we will not

be deﬁning privacy policies in contrast to (Kouzapas

and Philippou, 2017). Instead, the proposed valida-

tion by type checking will speciﬁcally analyze con-

formance to the speciﬁc GDPR principles and rights

under discussion.

3 A SOFTWARE SYSTEM

SPECIFICATION MODEL CASE

In order to present the rationale of our approach, as-

sume that we want to build a part of an online banking

system with the following speciﬁcations:

1. The system waits to receive the following data

from the user: her phone number.

2. The user’s phone number is classiﬁed as personal

data.

A Formal Modeling Scheme for Analyzing a Software System Design against the GDPR

3. The system receives and saves the data provided

by the user to the system database.

4. When a transaction occurs, a notiﬁcation system

process reads the user’s phone number from the

database and sends a text message to the number.

The system’s functionality is then terminated.

These speciﬁcations can be modeled in the Privacy

calculus as follows. A user component will provide

a private data input. The system entities will receive

the input, manage the input’s storage, read the data

stored, and manipulate them. Initial communication

between the user and the system is realized through

channel c. Groups will be used in order to deﬁne the

distinct system entities, i.e. the interacting subsys-

tems expressing different functionality. A user entity

process, U, of group User, creates the private session

communication channel a, and shares it with the sys-

tem. Next, she waits to receive on channel a a store

reference and, when received, she writes her phone

number on it.

The functionalities of writing and reading data

directly to or from the store are considered black

boxes. This is a typical practice during the modeling

phase, when some aspects of a system are abstracted

and only become concrete during the implementation

phase. As such, the abstractions of writing and read-

ing directly from the store will be implemented during

the system development, for instance, by calling a re-

spective RESTful service that offers an interface for

communicating with the system data store. In addi-

tion, these abstractions enable the Right of Access of

the data subject to her private data as required by the

GDPR. The behavior of the user can thus be modeled

as follows:

U ::= (ν a)(User[c!hai.a?(x).x!hid ⊗ phonei.P

])

The system entity DBase of group DBaseService

is responsible for holding and managing the data stor-

age, i.e. the user’s store. For the purpose of the ex-

ample we will assume that a store already exists for

the speciﬁc user, ﬁlled with the user identiﬁer and a

placeholder for the phone number:

DBase ::= DBaseService[r  [id ⊗ ∗]]

Another system entity S

of group

InterfaceService, already considered to be hold-

ing a reference to the store, waits for an input from

the user on the public communication channel c to

be used for establishing a private communication

session between the two entities. It then proceeds

to send the store reference to the user through that

channel:

::= InterfaceService[c?(x).x!hri.0]

Finally, the system entity S

of group

NotiﬁcationService, also considered to be hold-

ing the reference to the user’s store, takes as input

from the store the respective data, and uses it to send

a text notiﬁcation to that phone number. This process

will be triggered when a new transaction occurs and

can be modeled as follows:

::= NotiﬁcationService[r?(x ⊗ y).

y!hnotificationi.0]

The whole system is deﬁned as the parallel com-

position of the above processes comprising a system

of group

System ::= Sys[U |DBase |S

]

To further understand how the Privacy calculus

models interact, we proceed to provide an execution

of the system.

System

−→ Sys[(ν a)(User[a?(x).x!hid ⊗ phonei.P

]

|InterfaceService[a!hri.0])| DBase|S

]

−→ Sys[(ν a)(User[r!hid ⊗ phonei.P

]

|InterfaceService[0]) |DBase| S

]

−→ Sys[(ν a)(User[P

]| InterfaceService[0])

|DBaseService[r  [id ⊗phone]]|S

]

−→ Sys[(ν a)(User[P

]| InterfaceService[0])

|DBaseService[r  [id ⊗phone]]

|NotiﬁcationService[phone!hnotificationi.0]]

The ﬁrst step captures the synchronization be-

tween the user process and S

, where the former send

the fresh channel a through public channel c result-

ing in a substitution within S

of variable y by name

a. In the second step, S

sends the store reference r

to the user process, with reference r substituting vari-

able x and subsequently used by the user to update

her private information on the store managed by the

DBaseService. After the interaction we can observe

that the empty store now contains the phone of the

user. Finally, process S

receives the phone number

of the user from the database and is ready to send a

notiﬁcation to the user via her phone number.

4 GDPR AND THE PRIVACY

CALCULUS

The GDPR deﬁnes multiple principles and rights re-

garding personal data collection, storage, and pro-

cessing. While these principles were mostly wel-

comed, various challenges have been recognized in

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

terms of effectively integrating the new requirements

into computing infrastructures. Furthermore, a ques-

tion that arises is how to verify that a system adheres

to privacy requirements as enunciated by the GDPR.

In this work, we address this challenge by providing

an initial step towards a formal framework for rea-

soning about privacy-related concepts. On the one

hand, such a framework would provide solid foun-

dations towards understanding the notion of privacy

while, on the other hand, it would provide the basis

for system modeling and analysis tools for privacy-

respecting code. Beyond proposing the incorpora-

tion of such a framework into a software’s engineer-

ing methodology, we concentrate on GDPR Article 6,

Lawfulness of Processing, and the requirements de-

ﬁned therein regarding consent, Article 7(3), Consent

Withdrawal and Article 17, The Right to Erasure. We

then evaluate the Privacy calculus as a formalism to

reason about the GDPR, we discuss necessary addi-

tions to address the above articles and we demonstrate

them with the use of examples. In the next section we

formally deﬁne these extensions and present a static

methodology for assessing the conformance of a sys-

tem to these requirements.

4.1 Storing and Processing Personal

Data

We recall that according to the ﬁrst principle of Ar-

ticle 5 (“Lawfulness, fairness and transparency”),

Article 6 (“Lawfulness of Processing (1)”), and in

Recital 40 (“Lawfulness of data processing”), pri-

vate data may be collected, stored, and processed by

a system, only if the users (data owners) have given

their consent for the intended collection and process-

ing. The consent should be given explicitly, freely and

willingly by the user, based on one or more speciﬁc

purposes stated and described in the privacy policy.

In order to reason about the above concepts, a for-

malism should contain the notion of private data as

a basic entity. This is already the case in the Privacy

calculus, where private data are considered to be data

structures representing pieces of information related

to individuals along with the identities of the associ-

ated individuals. Furthermore, the formalism should

provide a clear deﬁnition of the notion of consent and

ensure that consent is given before any storage or pro-

cessing of the data is performed. Naturally, this con-

sent should be given by the owner of the data to be

processed.

In order to enable the above, we propose the fol-

lowing extension in Privacy calculus. Initially, the

calculus should enable the provision (and withdrawal)

of consent, whereas the notion of a user’s identiﬁer

should become a ﬁrst-class entity to allow the veriﬁ-

cation that a consent (or withdrawal of consent) for

a piece of private data is indeed given by the appro-

priate party. To achieve this, we extend the Privacy

calculus with (i) additional constructs for providing

consent, receiving consent and creating an associated

store upon the receipt, and withdrawing consent and

emptying the associated store, and (ii) the introduc-

tion of special identiﬁers and their association with

system processes. The implementation of the con-

sent construct should ensure that provision of consent

should precede any storage of personal data in a store,

except when the system is handling anonymized data.

No processing of private data will be enabled before

the consent of the user. As such, we associate the

grant of consent by a user with the creation of a store

within the software. Once consent is obtained, the

data is saved within the store and its reference can be

communicated to other entities in the system, which

may in turn process the data as needed by the software

speciﬁcation and speciﬁed by its privacy policy. Fur-

thermore, the store reference is shared with the con-

senting entity, i.e. the user, giving the user direct ac-

cess to the data associated with her within the system

at any point in time.

To ensure the association between a process entity

and its associated data, a user process is annotated by

a unique identiﬁer value, {P}

, where id is embedded

within all communications requiring the matching be-

tween a data owner and their data. Note that while

the actions of providing consent and writing personal

data to the store are implemented by single constructs

within the calculus, they should be thought of as

black boxes including functionality that will be im-

plemented in detail at coding level. We point out that

this abstraction will need to be appropriately imple-

mented for safeguarding identiﬁers and channel com-

munication from potential hostile entities, possibly by

embedding a communication protection mechanism,

such as a public-private key cryptography scheme, as

in (Abadi and Gordon, 1997). We illustrate the above

concepts by extending the example of Section 3.

Example 4.1. Section 3 model case with the follow-

ing additions:

1. The user should provide consent for the storage

and usage of her phone number by the system

prior to any storage and processing of the phone

number by the system.

2. No store will be associated with the user within

the system before the user explicitly provides her

consent.

To model these additions, we extend the descrip-

tion of the various entities as follows.

A Formal Modeling Scheme for Analyzing a Software System Design against the GDPR

User entity process U is annotated by its identiﬁer.

Furthermore, once a private session is achieved with

the database manager it provides its consent via chan-

nel a while simultaneously receiving a reference to

its newly-created store. This is achieved via construct

a  consent(x). As in the previous version of the ex-

ample, the user proceeds to write her data to the store.

This is modeled as follows:

{U}

::= (ν a)(User[c!hai.a  consent(x).

x!hid ⊗ phonei.0])

Moving on to the process of receiving and stor-

ing the private data of the user by the software sys-

tem, in the proposed extension a new entity S

group DBInterfaceService is deﬁned, combining the

database and the interface service. This process dy-

namically creates a new reference for a store and pro-

vides it to the disposal of the user as soon as she gives

her consent (the actual store created is not present in

the deﬁnition below since it will be dynamically cre-

ated once consent is given, as implemented by the se-

mantics of our calculus presented in the next section).

The fresh store reference needs also to be communi-

cated to the notiﬁcation service, which is the purpose

of the communication on channel d below. This is

modeled as follows:

::= DBInterfaceService[c?(y).

(ν r)(y  consent(r).d!hri.0)]

System process S

receives the reference to the

store and then continues to perform its task as in the

previous example:

::= NotiﬁcationService[d?(p).p?(x ⊗ y).

y!hnotificationi.0]

The system deﬁnition as a whole is comprised of

the parallel composition of the three processes:

System ::= Sys[{U}

]

4.2 Withdrawing Consent and

Forgetting Personal Data

The Right to Erasure is stated in Article 17 of the

GDPR, deﬁning the right of a user to have her per-

sonal data erased from a system without any undue

delay, if one of multiple reasons stated is applied, in-

cluding consent withdrawal. As deﬁned in GDPR Ar-

ticle 7 (3): ”the data subject shall have the right to

withdraw his or her consent at any time”. In this case,

the individual’s personal data should be deleted or be-

come anonymized in a way that the data subject can

no longer become identiﬁed by them.

In this work, we examine consent withdrawal as

the cause for erasure enforcement, though the ma-

chinery can be easily applied to other erasure causes.

In this case, we may assume that consent withdrawal

originates directly from the user process and, given

such a directive, the software is obliged to forget the

user’s data. Thus in the Privacy calculus, when a

deletion instruction is given, the associated store will

be emptied with the consequence of having its refer-

ence leading to no data. Subsequently, no data will be

available to any entity possessing a reference to the

store and attempting to read or write to it. The above

mentioned functionality is implemented by appropri-

ate rules added to the Privacy calculus semantics, and

specifying an abstraction of a GDPR-compliant be-

havior to be appropriately instantiated in the imple-

mentation process.

Example 4.2. Let us consider Example 4.1 where a

user provided consent and sent her phone number to

a system. To implement the Right to Erasure, let us

assume that the user has the right at a later stage to

withdraw her consent. As such, the example must be

expanded with the following speciﬁcations:

1. The user should be able to withdraw her consent.

2. When a user’s consent is withdrawn all her per-

sonal data should be deleted.

3. No further storage or processing of the speciﬁc

user’s personal data is allowed unless the user

provides again her consent.

The model of a user process {U}

as in Example

4.1 who withdraws her consent at some point after

submitting her data can be modeled as follows:

{U}

::= (ν a)(User[c!hai.a  consent(x).

x!hid ⊗ phonei.x withdraw.0])

The semantics of consent withdrawal instruction

ensure that such an instruction will synchronize with

the associated store resulting in the automatic dele-

tion of all content within the store causing all attempts

to process the store futile (again through appropriate

enunciation of the semantics rules for store process-

ing). Note that system entities S

and S

require no

change in their deﬁnitions. Furthermore, the entire

system’s deﬁnition remains unaltered.

5 THE EXTENDED PRIVACY

CALCULUS

In this section we describe formally the Extended Pri-

vacy calculus and its operational semantics and we

propose a type-checking methodology for ensuring

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 2: Extended Syntax of the Privacy Calculus.

Name Deﬁnition

(identity values) ι ::= id | | x

(data values) δ ::= c | ∗ | x

(private data) ι ⊗ δ where ι 6= x ⇒ δ = c and ι = x ⇒ δ = y

(identiﬁers) u ::= a | r | x

(terms) t ::= a | r | ι ⊗δ | d | x

(constants) v ::= a | r | id ⊗ d | d

(placeholders) k ::= x | x ⊗ y | ⊗ x

(processes) P ::= 0 | u!hti.P | u?(k).P | (ν n)P

| P|P | ∗ P | if e then P else P

| r [ι ⊗ δ] | u  consent(x).P

| u  consent(r).P | u  withdraw.P

(systems) S ::= G[P] | G[{P}

] | G[S] | S ||S | (ν n)S

that well-typed processes respect the GDPR require-

ments pertaining to consent, as discussed in the previ-

ous section. Due to the lack of space we only present

the extensions we propose to the Privacy calculus and

we refer the reader to (Kouzapas and Philippou, 2017)

for its complete exposition.

5.1 Formal Deﬁnition

The extended syntax of the Privacy calculus proposed

for our modeling scheme can be found in Table 2. The

syntax ﬁrst deﬁnes the values used. Assume a set of

constants c ∈ C, and a set of variables x,y ∈ V . A

special case of values denoted by ι refer to identities.

Symbol ι ranges over (i) identities, id, (ii) the hidden

identity,

, denoting anonymized data, and (iii) vari-

ables x. Data values ranged over by δ include con-

stants, c, the empty constant, ∗, and variables. Private

data ι ⊗ δ associate identities id with data c. Variable

placeholders for private data are written as x ⊗ y.

The set of identiﬁers used for the deﬁnition of the

Privacy calculus are deﬁned next. Assume a set of

names n ∈ N that are partitioned over names, a, and

store references, r. We use meta-variable u to range

over names or variables. Values, ranging over v, in-

clude names, private data, or data; placeholders, rang-

ing over k, include the variable structures of the calcu-

lus, whereas terms, ranging over t, include both val-

ues and placeholders.

The syntax of processes follows. It includes

the Privacy calculus constructs together with con-

structs for creating private data stores upon consent

and emptying private data stores upon consent with-

drawal. Term u consent(x).P deﬁnes the term, where

a process provides with consent on creating a new

store on channel u. The dual operation is term u 

consent(r).P, where the process receives a consent

request on channel u and creates a new store on ref-

erence r. During such an interaction the consenting

process (u  consent(x).P) will receive the new store

reference on variable x. Term, uwithdraw.P denotes

a process ready to withdraw consent on a store refer-

ence u.

The syntax of systems is also extended with sys-

tem G[{P}

] that denotes a system that runs on a

process with an identity. Processes with identities

are used to abstract individual users within a system,

whose private data are being processed.

The computation steps of the Privacy calculus are

deﬁned using a relation called labeled transition re-

lation. Speciﬁcally, we write S



−→ S

to denote that

a system S can take a step and evolve into system S

by executing the action indicated by label . When-

ever two parallel processes/systems can execute two

dual actions then they synchronize with each other

and their composition executes a computation inter-

action, indicated by τ, as follows:



−→ S



−→ S



dual 

−→ S

The labels of the Privacy calculus are extended

with the labels:

a consent(r) a consent(r)@id a  consent(r)@id

r  withdraw r  withdraw@id r  withdraw@id

where

a  consent(r)@id dual a  consent(r)@id

r  withdraw@id dual r  withdraw@id

Label a  consent(r) denotes the basic action for pro-

viding consent on channel a and receiving a refer-

ence on channel r, whereas label a  consent(r)@id

is the same action lifted to a user identity, id. Du-

ally action a  consent(r)@id is the acceptance of a

consent on channel a and the creation of a new store

with reference r and identity id. Withdraw labels are

r  withdraw that denotes a withdraw on reference

r; r  withdraw@id that lifts a withdraw at the user

level; and r  withdraw@id that denotes the receipt of

a withdraw on reference r with identity, id.

The labeled transition semantics deﬁnition fol-

lows in Table 3. The ﬁrst rule extends structural

congruence with a garbage collection rule to collect

stores that do not contain useful private data. Rule

[SConsentU1] describes the interaction of a process

giving consent on channel a; the process observes the

a  consent(r) label. Next, rule [SConsentU2] lifts a

consent action to a process associated with an identity,

using label a  consent(r)@id. The dual action of re-

ceiving consent is done via label a  consent(r)@id.

After the label is observed a new store, r  [id ⊗ ∗]

A Formal Modeling Scheme for Analyzing a Software System Design against the GDPR

Table 3: Additions to Privacy Calculus Labeled Transition Semantics.

Rule Name Structure

[GarbageC] (ν r)(r  [ ⊗∗] ≡ 0)

[SConsentU1] a  consent(x).P

aconsent(r)

−→ P{

}

[SConsentU2]

aconsent(r)

−→ P

{P}

aconsent(r)@id

−→ {P

}

[SConsentS1] a  consent(r).P

aconsent(r)@id

−→ P| r  [id ⊗ ∗]

[SWithdraw1] r  withdraw.P

rwithdraw

−→ P

[SWithdraw2]

rwithdraw

−→ P

{P}

rwithdraw@id

−→ {P

}

[SWithdraw3] r  [id ⊗ c]

rwithdraw@id

−→ r  [id ⊗ ∗]

[PId]



−→P

6=aconsent(r),rwithdraw

{P}



−→{P

}

[SId]

{P}



−→{P}

S[{P}

]



−→S[{P}

]

[SOut2] r  [ ⊗ ∗]

r!h ⊗∗i

−→ r  [ ⊗ ∗]

[SInp2] r  [ ⊗ ∗]

r?(id⊗c)

−→ r  [ ⊗∗]

is created on reference r with identity id. Follow-

ing the dual deﬁnition of labels, a process that gives

consent interacts with a process that receives consent

to create a new store and exchange the correspond-

ing reference. Withdraw follows a similar fashion.

A process with a withdraw preﬁx observes a with-

draw label r  withdraw (rule [SWithdraw1]), and it

is lifted to a user process via label r  withdraw@id

(rule [SWithdraw2]). Finally, rule [SWithdraw3] ob-

serves a store receiving a withdraw request via label

r  withdraw@id and as a result it deletes the cor-

responding private data and assigns the anonymous

identity and the empty value to its memory. The next

two rules bridge the gap between the new process

{P}

and System S[{P}

] and the rest of the calcu-

lus. Finally, two new rules deﬁne the interaction of

the empty store.

5.2 Typing GDPR Compliance

As we have already discussed, the objective of this

work is to propose a formal framework for modeling

software systems and associated analysis techniques

for guaranteeing that systems comply to privacy-

related requirements. In this section, we discuss such

an analysis technique and we show that the intended

requirements we have discussed regarding the pro-

vision and withdrawal of consent can be statically

checked by typechecking.

For instance, consider the following system:

User[a!hid ⊗ ci.P]|| Sys[a?(x ⊗y).Q]

This system describes the situation, where pri-

vate data are sent (resp. received) via a non-reference

channel. However, this leads to the dissemination

and processing of private data without proper permis-

sion and consent and, while it is a legal process, it

clearly fails to satisfy the GRPR requirements. Note

that exchange of private data can instead be achieved

by communicating the reference to the associated pri-

vate data store. A similar error would have occurred,

if upon acquisition of private data from a store, a

subcomponent of a system created a new store and

thereby copied the data. However, this would lead to a

situation, where the withdrawal of consent by the user

would not reach the newly-deﬁned store and thus, the

system would continue to hold the data violating the

right of the user for her data to be forgotten. This

suggests that copying of private data should (if car-

ried out) be done with care and ensuring that a link is

maintained between the various copies of user data.

In the sequel, we propose an approach for recognizing

these and other undesirable situations via typecheck-

ing, and we prove that well-typed processes do not

present error, such as the ones discussed above. We

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 4: Typing Rules.

Rule Structure

[TCons]

Γ,x:G[t[g]];Λ `P Γ `u:G

[G[t[g]]]

Γ;Λ ` uconsent(x).P

[TStore]

Γ,r:G[t[g ]];Λ ` P Γ ` u:G

[G[t[g]]]

Γ;Λ,r `uconsent(r).P

[TWithdraw]

Γ;Λ ` P Γ `u:G[t[g ]]

Γ;Λ ` uwithdraw.P

[TId]

Γ;Λ ` P

Γ;Λ,id ` {P}

ﬁrst deﬁne the set of types that are used to character-

ize the channels and the values that are used by the

typing system. A type, T , is of the following form:

g ::= nat | bool | (g

,. .., g

) | ...

T ::= t[g] | G[T] | g

A type g is a primitive data type, e.g. natural num-

bers and boolean, or a structure of primitive data

,. .., g

). A type t[g] is used to type private data

values id ⊗c, where constant c is of type g. Channels

are typed the G[T ] type, that denotes a channel that

can only send channels or values of type T between

participants beloning to group G.

Our type system extends the one of the Privacy

calculus by the rules in Table 4. It is based on the

notion of a typing context deﬁned as follows:

Γ ::= Γ,t : T |

0 Λ ::= Λ,r | Λ,id |

A typing context Γ, or shared typing environment,

maps values and variables to types. Operator Γ

,Γ

is deﬁned as Γ

∪ Γ

. A typing context Λ, or linear

typing environment, includes store references r and

identiﬁers id. It is used to track names in a system and

ensure that store references and identities are unique

in a system. Operator Λ

,Λ

is deﬁned as Λ

∪ Λ

whenever Λ

∪ Λ

0 and undeﬁned otherwise. Typ-

ing judgments are of the following form:

Γ ` t : T Γ;Λ ` P Γ;Λ ` S

The ﬁrst judgment states the a meta-variable t has a

type T following a typing context. The second judg-

ment states that a process P is well typed given in

the typing contexts Γ and Λ. Similarly for the typing

judgment for systems.

The ﬁrst typing rule in Table 4 checks for the cor-

rect usage of the u  consent(x).P term. It ﬁrst checks

that process P is correctly typed under a typing envi-

ronment. It then checks whether the type of variable

x can carry private data, i.e. it is of store reference

type. Moreover, it checks that the type of channel u

can carry an x variable type. In the premise of the

rule variable x is not present because x is bounded in

process P. Rule [TStore] follows a similar logic to

the previous rule. However, it is checked that name r

does not already have a store present in P by adding

r in environment Λ. If r was already present in Λ it

means that a store (or a consent for a store) is already

present in process P. Rule [TWithdraw] performs a

check that a withdraw can be performed on a channel

that carries private data, i.e. it is a reference channel.

The ﬁnal rule, rule [TId], types a process which is

equipped with an identity. The rule tracks the identity

in the Λ environment. The presence of the identity in

the Λ environment ensures that it cannot be used by

another process as an identity in the system, because

Λ cannot be composed with another linear environ-

ment that contains the same identity.

A main property of the system is that the execu-

tion of computations steps by a statically-typed sys-

tem, yields systems that are also well typed.

Theorem 5.1 (Type Preservation). Let S be a system

such that Γ;Λ ` S for some Γ and Λ. Whenever S −→

then there exists Γ

,Λ

such that Γ

;Λ

` S

Type preservation is an important theorem that

states the soundness of the typing system. Moreover,

as we discussed above, the cases of mishandling pri-

vate data are not allowed in statically checked pro-

cesses. This is formally given by the a type safety

theorem. First, we deﬁne the notion of the error pro-

cess, which are processes that mishandle private data.

Deﬁnition 5.1 (Error Process). A process P is an er-

ror process whenever it is of one of the forms:

r  [ι ⊗ δ]|r  [ι

⊗ δ

a  consent(x).P if r ∈ fn(P),

a!hid ⊗ ci.P, a?(x ⊗ y).P,

r!hvi.P, and r?(x).P

A system is an error system whenever, either it is of

the form G[P] and P ≡ (ν ˜n)(P

| . .. | P

) and ∃i,1 ≤

i ≤ n such that P

is an error processes; or of the

form G[S] and S is an error system; or of the form

(ν ˜n)(S

|| . .. || S

) and ∃i,1 ≤ i ≤ n such that S

is an

error system.

The class of error systems captures cases where

a system mishandles private data. The ﬁrst case is

where a system deﬁnes more than one stores on the

same reference. This can lead to situations where the

two stores have inconsistent private data.

The next case deﬁnes the situation, where one

store is created with consent and another without con-

sent. For example, in the system:

Sys[a  consent(r).(P | r  [id ⊗ c])]

a second store will be created without consent.

A Formal Modeling Scheme for Analyzing a Software System Design against the GDPR

The next two cases deﬁne the situation, where pri-

vate data are sent (resp. received ) via a non-reference

channel with the possibility of leading to data pro-

cessing without consent from the user.

The ﬁnal two cases characterized as errors is when

non private data are sent (resp. received) via a refer-

ence, e.g. the system

User[r!hai.P]|| Sys[r  [id ⊗c]]

cannot observe any meaningful interaction on refer-

ence r.

Based on a sound type system we can statically in-

fer that a system is safe with respect to handling pri-

vate data, i.e. a statically-checked system will never

reduce to an error.

Theorem 5.2 (Type Safety). Let system S be a system

such that Γ ` S for some Γ. Whenever S −→

∗

then

is not an error system.

The proof follows from the fact that error sys-

tems cannot be successfully type checked and Theo-

rem 5.1, that states that reduction preserves the typing

property.

6 CONCLUSIONS

In this paper, we have extended the Privacy calculus

of (Kouzapas and Philippou, 2017) with features to

support the granting and withdrawal of consent by

users, and for checking associated requirements as

enunciated by the GDPR. While we have not con-

sidered privacy policies as in (Kouzapas and Philip-

pou, 2017), where type checking is performed to en-

sure satisfaction of requirements pertaining to the pur-

pose of usage, as well as the permissions endowed

to each user in the system, we believe that the two

approaches can easily be integrated being orthogonal

to each other. Our vision is that a π-calculus-based

framework can be developed and used by software

engineers to model systems during the design phase,

as well as in order to analyze and validate privacy-

related properties, such as the GDPR-based provi-

sions of Lawfulness of Processing, and the Right to

Erasure and Consent Withdrawal. Analyzing and val-

idating a system’s speciﬁcations design model is a re-

quired step of software system creation. The mod-

eling scheme introduced will provide information on

conformance or may reveal any infringements found.

We point out however, that this process cannot guar-

antee that the software engineers will implement the

system to precisely conform to its speciﬁcations de-

sign, unless MDE techniques relying on the Privacy

calculus are employed.

As future work, we intend to embed more GDPR

provisions into the Privacy calculus. We will also

work towards offering tools for easily expressing

a system’s speciﬁcations model in π-calculus-based

formalism. Furthermore, tools for static checking

actual code implementations, and tools for formally

translating veriﬁed models to veriﬁed developed sys-

tems can be created, thus assisting the transition from

the design phase to the development phase, by ex-

ploiting the ability of type-checking techniques at the

coding level. Relevant work, that does not capture pri-

vacy requirements, but was developed in the context

of the π-calculus and applies automated static analysis

techniques to software code can be found in (Yoshida

et al., 2013; Ng et al., 2015). Moreover, in future

work we will focus on the notion of purpose by de-

scribing and validating purpose-based properties us-

ing a purpose-based, customizable privacy policy lan-

guage, providing also a mechanism for privacy policy

validation as embedded in the Privacy calculus. Our

ultimate goal is to provide a holistic approach to pri-

vacy management in software system development.

REFERENCES

Abadi, M. and Gordon, A. D. (1997). A calculus for crypto-

graphic protocols: The spi calculus. In Proceedings of

the 4th ACM Conference on Computer and Communi-

cations Security, pages 36–47. ACM.

Ahmadian, A. S., Str

uber, D., Riediger, V., and J

urjens,

J. (2018). Supporting privacy impact assessment by

model-based privacy analysis. In ACM Symposium on

Applied Computing, pages 1142–1149.

Backes, M., Hritcu, C., and Maffei, M. (2008). Type-

checking zero-knowledge. In Proceedings of the 2008

ACM Conference on Computer and Communications

Security, CCS 2008, pages 357–370.

Basso, T., Montecchi, L., Moraes, R., Jino, M., and

Bondavalli, A. (2015). Towards a uml proﬁle for

privacy-aware applications. In Proceedings of the

IEEE International Conference on Computer and In-

formation Technology; Ubiquitous Computing and

Communications; Dependable, Autonomic and Se-

cure Computing; Pervasive Intelligence and Com-

puting (CIT/IUCC/DASC/PICOM, 2015), pages 371–

378. IEEE.

Bengtson, J., Bhargavan, K., Fournet, C., Gordon, A. D.,

and Maffeis, S. (2011). Reﬁnement types for secure

implementations. ACM Transactions on Program-

ming Languages and Systems, 33(2):8.

Boussetoua, R., Bennoui, H., Chaoui, A., Khalfaoui, K.,

and Kerkouche, E. (2015). An automatic approach to

transform bpmn models to pi-calculus. In Proceedings

of the International Conference of Computer Systems

and Applications (AICCSA, 2015), pages 1–8. IEEE.

Braghin, C., Gorla, D., and Sassone, V. (2006). Role-based

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

access control for a distributed calculus. Journal of

Computer Security, 14(2):113–155.

Bugliesi, M., Colazzo, D., Crafa, S., and Macedonio, D.

(2009). A type system for discretionary access con-

trol. Mathematical Structures in Computer Science,

19(4):839–875.

Cardelli, L., Ghelli, G., and Gordon, A. D. (2000). Secrecy

and group creation. In International Conference on

Concurrency Theory, pages 365–379. Springer.

Cavoukian, A. (2008). Privacy by design. Information

Commissioner’s Ofﬁce.

Compagnoni, A. B., Gunter, E. L., and Bidinger, P. (2008).

Role-based access control for boxed ambients. Theo-

retical Computer Science, 398(1-3):203–216.

Data Protection and Privacy Commissioners (2010). Res-

olution on privacy by design. In Proceedings of

ICDPPC’10.

Dezani-Ciancaglini, M., Ghilezan, S., Jaksic, S., and Pan-

tovic, J. (2010). Types for role-based access control

of dynamic web data. In Proceedings of WFLP’10,

LNCS 6559, pages 1–29. Springer.

European Parliament and Council of the European Union

(2015). General data protection regulation. Ofﬁcial

Journal of the European Union.

Fournet, C., Gordon, A., and Maffeis, S. (2007). A type

discipline for authorization in distributed systems. In

20th IEEE Computer Security Foundations Sympo-

sium, CSF 2007, 6-8 July 2007, Venice, Italy, pages

31–48.

Fowler, M. (2004). UML distilled: a brief guide to the stan-

dard object modeling language. Addison-Wesley Pro-

fessional.

Gjermundrød, H., Dionysiou, I., and Costa, K. (2016).

privacytracker: A privacy-by-design gdpr-compliant

framework with veriﬁable data traceability controls.

In Proceedings of the International Conference on

Web Engineering, pages 3–15. Springer.

Havey, M. (2005). Essential business process modeling. ”

O’Reilly Media, Inc.”.

Hennessy, M. (2007). A distributed Pi-calculus. Cambridge

University Press.

Hennessy, M., Rathke, J., and Yoshida, N. (2005). safedpi:

a language for controlling mobile code. Acta Infor-

matica, 42(4-5):227–290.

Hennessy, M. and Riely, J. (2002). Resource access control

in systems of mobile agents. Information and Compu-

tation, 173(1):82–120.

Hes, R. and Borking, J. (1998). Privacy enhancing tech-

nologies: the path to anonymity. ISBN, 90(74087):12.

Hintze, M. and LaFever, G. (2017). Meeting upcoming gdpr

requirements while maximizing the full value of data

analytics.

Hustinx, P. (2010). Privacy by design: delivering

the promises. Identity in the Information Society,

3(2):253–255.

urjens, J. (2002). Umlsec: Extending uml for secure

systems development. In Proceedings of the Inter-

national Conference on The Uniﬁed Modeling Lan-

guage, pages 412–425. Springer.

Kalloniatis, C., Kavakli, E., and Gritzalis, S. (2008). Ad-

dressing privacy requirements in system design: the

pris method. Requirements Engineering, 13(3):241–

255.

Kapitsaki, G., Ioannou, J., Cardoso, J., and Pedrinaci, C.

(2018). Linked usdl privacy: Describing privacy poli-

cies for services. In 2018 IEEE International Confer-

ence on Web Services (ICWS), pages 50–57. IEEE.

Kapitsaki, G. M., Kateros, D. A., Pappas, C. A., Tselikas,

N. D., and Venieris, I. S. (2008). Model-driven devel-

opment of composite web applications. In Proceed-

ings of the 10th International Conference on Informa-

tion Integration and Web-based Applications & Ser-

vices, pages 399–402. ACM.

Kapitsaki, G. M. and Venieris, I. S. (2008). Pcp: privacy-

aware context proﬁle towards context-aware applica-

tion development. In Proceedings of the 10th Inter-

national Conference on Information Integration and

Web-based Applications & Services, pages 104–110.

ACM.

Kouzapas, D. and Philippou, A. (2017). Privacy by typing in

the π-calculus. Logical Methods in Computer Science,

13(4).

Lam, V. S. (2008). On π-calculus semantics as a formal

basis for uml activity diagrams. Prooceedings of the

International Journal of Software Engineering and

Knowledge Engineering, 18(04):541–567.

Milner, R., Parrow, J., and Walker, D. (1992). A calculus

of mobile processes, parts I and II. Information and

Computation, 100(1):1–77.

Ng, N., de Figueiredo Coutinho, J. G., and Yoshida, N.

(2015). Protocols by default - safe MPI code gener-

ation based on session types. In Proceedings of Inter-

national Conference on Compiler Construction, CC

2015, pages 212–232.

Perera, C., McCormick, C., Bandara, A. K., Price, B. A.,

and Nuseibeh, B. (2016). Privacy-by-design frame-

work for assessing internet of things applications and

platforms. In Proceedings of the 6th International

Conference on the Internet of Things, pages 83–92.

ACM.

Rubinstein, I. S. (2011). Regulating privacy by design.

Berkeley Technology Law Journal, 26:1409.

Sangiorgi, D. and Walker, D. (2003). The pi-calculus: a

Theory of Mobile Processes. Cambridge University

Press.

Schmidt, D. C. (2006). Model-driven engineer-

ing. COMPUTER-IEEE COMPUTER SOCIETY-,

39(2):25.

Thatte, S. (2001). Xlang: Web services for business process

design. Microsoft Corporation, 2001.

Yoshida, N., Hu, R., Neykova, R., and Ng, N. (2013). The

Scribble protocol language. In Proceedings of TGC

2013, Revised Selected Papers, pages 22–41.

A Formal Modeling Scheme for Analyzing a Software System Design against the GDPR
