Evaluating Use Cases Suitability for Conversational User Interfaces

Pedro Ferreira and André Vasconcelos

INESC-ID, Instituto Superior Técnico, Avenida Rovisco Pais 1, Lisbon, Portugal

Keywords: Use Cases, Chatbot, Conversational User Interface, Natural Language Understanding and Dialog Systems.

Abstract: The developments in Natural Language Understanding (NLU) are enabling tasks that were typically

performed interacting with humans to be now performed interacting with dialog systems, using the same

natural language. Dialog systems can also be used in alternative to more traditional graphic user interface

(GUI) applications. A review of the intrinsic differences and benefits of humans interacting with dialog

systems in alternative to other humans or GUI applications is performed. It is also reviewed the types of use

cases that are now being performed by chatbots. This paper aims to identify the factors that influence the

selection of use cases suitable for conversational user interfaces, enabling organizations to make more

informed decisions regarding chatbots implementations. The factors identified are grouped in three categories:

(i) general factors, (ii) factors to be considered to implement a chatbot over a human operator; and (iii) factors

that should be considered when implementing a chatbot over a traditional GUI application. Finally, an

assessment to the scheduling a medical appointment use case is performed, using the defined factors. This use

case is considered suitable to a conversational user interface according to the factors.

1 INTRODUCTION

The developments in the artificial intelligence field

have been responsible to the rise of new, more

intelligent systems. Specifically, the developments in

the Natural Language Processing, drive the

development of chatbots. Chatbots are systems that

interact with the user using natural language, as if the

user were talking with another human. Today people

are using chat platforms as one of the main channels of

communication, using applications such as Facebook

Messenger or WhatsApp. The heavy usage of chat

platforms allied with the developments in NLP create

a favourable scenario to organizations to offer their

services using conversational user inter-faces. Services

can be accessed directly from the chat platforms the

users already use, in a more natural way, instead of

requiring the users to install a specific app or access the

organization website.

The goal of this paper is to create an evaluation tool

that can be used by any business to evaluate the

suitability of a use case to be implemented in a chatbot.

2 BACKGROUND AND RELATED

WORK

2.1 Dialog Systems

Conversational agents or dialog systems are

programs that communicate with users in natural

language. This kind of systems can be classified in

two categories (Jurafsky and Martin, 2008):

 Task-oriented Dialog Agents: are designed for a

particular task and set up to have short

conversations to get information from the user to

help complete the task. These include the digital

assistants that can give travel directions, control

home appliances, find restaurants, or help make

phone calls or send texts.

 Chatbots: Chatbots are systems designed for

extended conversations, set up to mimic the

unstructured conversational characteristic of

human-human interaction, rather than focused on

a particular task. These systems often have an

entertainment value. Chatbots are also often

attempts to pass the Turing test. Chatbots can also

have some practical uses such as testing theories of

psychological counselling.

The word “chatbot” is often used in the media and

in industry as a synonym for conversational agent

Ferreira, P. and Vasconcelos, A.

Evaluating Use Cases Suitability for Conversational User Interfaces.

DOI: 10.5220/0007732904310437

In Proceedings of the 21st International Conference on Enterprise Information Systems (ICEIS 2019), pages 431-437

ISBN: 978-989-758-372-8

431

(Jurafsky and Martin, 2008). In this paper the term

“chatbot” is used in that same more general sense. In

reality, the kind of systems explored in this paper are

typically task-oriented dialog agents, even though we

may refer them using the word “chatbot” instead of

“task-oriented dialog agent”.

It is also important to notice that even though

dialog systems communicate with users in natural

language, other form of GUI elements are often used

such as predefined quick replies that the user can click

in order to make the interaction faster and easier.

2.2 Natural Language Processing

Natural language processing (NLP) is a subfield of

computer science concerned with using

computational techniques to learn, understand, and

produce human language content (Hirschberg and

Manning, 2015). Some applications of NLP include:

information extraction, transforming unstructured

data found in texts into structured data (Jurafsky and

Martin, 2008); conversational agents, that aid

human-machine communication (Hirschberg and

Manning, 2015); or machine translation, the use of

computers to automate the process of translating

from one language to another, aiding human-human

communication (Hirschberg and Manning, 2015)

(Jurafsky and Martin, 2008).

The factors that have allowed the development of

NLP in the last years twenty years, according to

(Hirschberg and Manning, 2015) , are: (i) increase in

computing power, (ii) the availability of large

amounts of linguistic data, (iii) the development of

successful machine learning methods, and (iv) a

richer understanding of the structure of human

language and its deployment in social context.

2.2.1 Natural Language Understanding in

Dialog Systems

There are various possible structures to represent the

meaning of linguistic expressions. Modern task-based

dialog systems are based on a domain ontology, a

knowledge structure representing the kinds of

intentions the system can extract from user sentences

(Jurafsky and Martin, 2018). The ontology defines a

frame-based representation, with one or more frames,

each a collection of slots, and defines the values that

each slot can take.

Dialog agents typically have a natural language

understanding module. NLU is responsible for the

semantic parsing of user utterance, i.e., it gives

semantic meaning to user utterances. This module is

responsible for selecting the appropriate frames and

filling the slots of the beforementioned domain

ontology structure. This module objective is therefore

to extract three things from the user’s utterance

(Jurafsky and Martin, 2018):

 Domain Classification: if the systems is not

single-domain, there is the need to determine what

domain is the user referring to.

 Intent Determination: what general task or goal

is the user trying to accomplish. For example, the

task could be to Find a Movie, or Show a Flight, or

Remove a Calendar Appointment.

 Slot Filling: extract the particular slots and fillers

that the user intends the system to understand from

their utterance with respect to their intent.

Consider the sentence “Book me a table for two for

Friday night at Sushi Place”. The NLU module

would recognize the domain as “restaurant”; the

intent as “book table” and would fill the time slots

with “night” and “Friday”; the restaurant name slot as

“Sushi Place”; and finally, the slot for the number of

seats as “two”.

The domain and intent determination are usually

treated as a semantic utterance classification (SUC)

problem and the slot filling as a sequence labelling

problem (Zhang and Wang, 2016).

Possible methods used by for domain/intent

recognition and slot filling include: (i) hand-written

rules; (ii) semantic grammars, that are context-free

semantic grammar in which the left-hand side of each

rule corresponds to the slot names; and (iii)

supervised machine learning, using a training set that

associates each sentence with the semantics, we can

train a classifier to map from sentences to intents and

domains, and for slot filling a sequence model can be

used (Jurafsky and Martin, 2018).

Training machine learning models requires

having access to rare expertise, large datasets, and

complex tools, which presents a barrier to smaller

companies (Raman and Tok, 2018). The availability

of NLU services in the cloud has powered the

widespread use of chatbots.

2.3 Uses of Chatbots

There are several tasks that can be performed by

chatbots. This set of tasks make possible a panoply of

use cases that can be supported by bot interaction.

The main tasks performed by a chatbot are: send

alerts; take action; retrieve information and answer

questions.

It is possible to identify some categories of uses

cases that are already being implemented by some

companies taking advantage of the previously

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

432

mentioned set of tasks. (Shevat, 2017) identifies the

following major use cases.

2.3.1 Conversational Commerce

Conversational bots offer the ability to order and

explore services or goods directly by a conversational

interface. This has the advantage of removing the

need to install the specific app of the business, calling

services directly from the preferred conversational

channel.

2.3.2 Bots for Business

Bots are not only being used for external customers

but also internally by businesses, in order to support

their internal business processes. This can improve

productivity by facilitating short, contextual and

actionable tasks.

2.3.3 Notification Bots

Notification through chat platform are being used as

an alternative to more traditional notifications such as

email. One of the advantages of this type of use is that

traditional notifications usually redirect the user to

another platform, while chatbots, taking advantage of

its “take action” capability, can perform some related

action directly from the conversational UI. For

instance, a client can receive some appointment

reminder, and can confirm/cancel it directly from the

chat platform.

2.3.4 Bots as Routers between Humans

Bots can also help connecting humans to humans. By

using chatbots we can by identifying the intent of the

user and connect him or her to the most suitable

human. This can act as a replacement of the

traditional IVR systems, providing a more natural

experience until a human takes the place.

2.3.5 Customer Service and FAQ Bots

Bots helping answering questions to clients are a very

common use case. The fact that most questions are

usually asked several times, and the answer is

standard, make bots a great way to replace humans in

this repetitive task, reducing costs and usually being

faster.

2.3.6 Productivity and Coaching

There are also various examples of bots focused on

reminders, to-do lists, personal and team task

management completion, that help people be more

productive. Bots can also be used for personal

coaching to assist in areas such as weight loss and

finance. By providing a more personal experience,

bot users are more willing to provide information to

the bot than to fill forms in an app.

2.3.7 Third-Party Integration Bots

Third party integrations make possible to bring

external apps used in someone workflow to some chat

app like slack. This avoids that users have to context-

switch between apps to gather the information needed

to their workflow.

2.3.8 Games and Entertainment Bots

Bots are also being used in the entertainment area by

using a conversation as a fun activity. One of the

advantages of using bots in this area, is that bots can

reengage with the users and encourage them back to

the service in a less intrusive and more customizable

and friendly way than app notifications, for example.

2.3.9 Brand Bots

Business are using the chat channels to create brand

awareness and engagement. One of the major

incentives to use bots in this area is app fatigue,

creating this way a new way to engage with users.

2.4 Chatbots, Humans and GUI

Applications

This section explores what are the chatbots benefits,

when replacing human interaction and traditional

graphical user interface applications (GUI). It is also

explored the intrinsic differences of the interactions.

2.4.1 Human-human vs Human-Chatbot

Interaction

There are some differences in the way that people

interact with a bot compared to a human. A study

(Hill et al., 2015) concluded that people communicate

with the chatbot for longer durations, using shorter

messages, than they did with another human.

Additionally, human–chatbot communication used

simpler vocabulary than what is found in

conversations among people and exhibited greater

profanity. Factors such as number of words per

conversation, shorthand terms, and emoticons were

found to have no statistically significant differences.

The usage of chatbots in some scenarios bring

advantages over humans, namely (Janarthanam,

2017):

Evaluating Use Cases Suitability for Conversational User Interfaces

433

 Consistency: chatbots can be consistent in

services, which is important in certain sectors

and may be hard to achieve with human

operators.

 Scalability: chatbots can easily scale up to handle

periods of unregular increased traffic, which is

much harder with human operators.

With good design and implementation, Accenture

(Accenture, 2016) reports more than 80% of chat

sessions resolved by a chatbot, that would otherwise

been a human in a chat session or call.

2.4.2 Human-Traditional GUI vs

Human-Chatbot Interaction

A report (Ask et al., 2016) by Forrest identifies the

following factors that foster chatbots adoptability

over traditional applications:

 Chatbots Promise a More Convenient and

Natural User Interface: Typically, users must go

to the process of discover, download, and install

apps. Then, apps provide touch graphical

interfaces to help consumers perform tasks. The

experience isn’t natural, but it is effective.

Conversations offer are more natural experience.

 Mobile Moment Ownership is Plateauing for

Enterprises: Mobile is the first screen for

consumers; however, consumers use only 25 to

30 apps on average each month and spend 88%

of their time in just five downloaded apps.

 Heavy use of Instant Messaging Platforms:

Consumers spend 78% of their time on

smartphones within apps. The median usage of

instant messaging apps is 21.47 minutes per day

among users of those apps and the pace of

adoption is accelerating.

The fact that we are living an app fatigue moment,

allied with the heavy usage of messaging apps,

present an opportunity to replace traditional

applications with chatbots available on the messaging

applications that users are already using.

3 CHATBOT USE CASE

EVALUATOR

In order to enable the evaluation of use cases, several

factors are identified, reflecting the characteristics a

use case should have in order to be appropriate to be

implemented in a chatbot.

Chatbots lie between human operators and

traditional graphical user interfaces (GUI)

applications. In one hand, they can be used in the

place of a human, offering a similar way of

interaction, by using natural language. On the other

hand, they can also be used instead of a traditional

application, replacing a traditional graphical user

interface with natural language.

The factors are divided in three major groups:

1. General Factors: general factors that are

essential to be considered to assure the suitability

of the use case to be implemented in a

conversational UI.

2. Factors over GUI Application: this group of

factors reflect characteristics of a use case that

can indicate that a chatbot is more adequate to

expose it, instead of a traditional GUI

application.

3. Factors over Human: factors that reflect

characteristics of a use case that can indicate that

the use case would benefit from being

implemented by a chatbot instead of a human

operator.

The analysis of such factors for each category yielded

the following result.

3.1 General Factors

 Business Rules Well Defined: Chatbots perform

better solving specific requests were the process

to solve it is standard (Sengupta and Lakshman,

2017). This facilitates the creation of the flow of

the conversation based on that business rules.

 Integration with Existing Systems: concerns if

it’s possible to integrate the bot with the

organization systems, via existing APIs. This

factor guarantees that the chatbot can access the

business logic and data required to the use case

in question.

3.2 Factors over GUI Applications

 Multiple Steps or Multiple Input Parameters

(Accenture, 2016): A simple traditional UI might

be more practical to use cases that are simple and

require only one step, but for tasks that require

several user data, using NLU we can sometimes

get all the information that the user would input

in a form, for instance, in a simple sentence.

Consider the sentence “Can you rebook my flight

to Madrid to the following Monday after 3pm

and get me a window seat”. A traditional GUI

would require the user to insert the different

pieces of information in different steps of the

process, while a chatbot would recognize all the

information parameters directly from the natural

language sentence. This presents one of the main

advantages of chatbots using NLU.

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

434

 Notifications Required: Messaging

applications already include an efficient and

functional push notification system, which is

available by default without any additional

implementation effort (Klopfenstein et al., 2017).

 Authentication Required (Klopfenstein et al.,

2017): Usually, for each new application, users

must create a new account to be uniquely

identified. With bots, user authentication is not

necessarily needed. The messaging platform

used already provides a reliable identification of

the user. Users are uniquely identified by default.

This reduces the effort asked to the user to start

using the service, not requiring to create an

additional account.

3.3 Factors over Humans

 High Volume, Simple Tasks, Performed by

Humans: For simple, well defined, repetitive

tasks, a chatbot can be more suitable than a

human, in the sense that is more economical and

frees the HR for another tasks (Accenture, 2016).

 Consistency Required: For use cases that is

important consistency in the performance, i.e.,

the use case must be performed the same way in

every occurrence, chatbots can be more suitable

than a human operator (Janarthanam, 2017). Bots

are intrinsically more consistent than human

operators.

 Scalability Required (Janarthanam, 2017):

some use cases have unstable loads of requests

from users. Bots can scale-up to fulfil the

requests. Using human operators, is hard to

handle sudden increases of requests.

4 APPLICATION

In this section, the previously defined factors will be

applied to a concrete use case, in order to demonstrate

how these factors can be used in practice.

The use cases is in the context of MedClick, a

company in the healthcare field, that will provide a

one-stop platform to book a medical appointment in a

fast and user-friendly way, across multiple medical

service providers

The use case of Scheduling an Appointment is

assessed.

4.1 Scheduling Appointment Use Case

4.1.1 Use Case Definition

In order to schedule an appointment, the user must

select the speciality needed; choose one of the

available doctors; and finally choose one of the

available time slots. This use case is typically

performed with clerks, either by phone or in person,

or in the case of some clinics, an application is

available to the user schedule the appointment

independently. Users are notified of the appointment

close to the scheduled date, in order to confirm the

presence or optionally reschedule.

4.1.2 Use Case Evaluation

In this section an analysis to the suitability of the

scheduling an appointment use case is performed,

using the factors defined in section 3.

General Factors: Scheduling an appointment is a

common use case, that has business rules well

defined. In the case of MedClick, an API is available

in order to request all the information needed to

perform this use cases, including list of doctors,

available time slots, and scheduling the appointment.

Table 1: General factors assessment for scheduling

appointment UC.

Factor

Assessment

Business Rules Well

Defined

Yes

Integration with existing

Systems

Yes

Factors Over GUI Application: Scheduling an

appointment has multi input parameters, namely the

desired medical specialty, the name of the doctor and

the time slot. The identification of the user must also

be known. The user must be notified close to the date

of the appointment, in order to confirm its presence

or, optionally, reschedule the appointment.

Table 2: Factors over GUI application assessment for

scheduling appointment UC.

Factor

Assessment

Multiple Steps/ Multiple

Input parameters

Yes

Notifications Required

Yes

Integration with existing

Systems

Yes

Factors Over Humans: Hospitals and clinics usually

address high volume requests for appointment

scheduling. The volume of requests may vary in an

unpredictable way, requiring scalability. This use

case is still commonly performed by human

operators.

Evaluating Use Cases Suitability for Conversational User Interfaces

435

Table 3: Factors over Humans assessment for scheduling

appointment UC.

Factor

Assessment

High Volume, Simple

Tasks, performed by

humans

Yes

Consistency required

Scalability required

Yes

4.1.3 Evaluation Conclusions

The fact that this use case meets the two general

factors indicates the viability to implement it in a

chatbot. Furthermore, it is possible to conclude that

the use case is might benefit from the implementation

in a chatbot over a traditional GUI application,

meeting the three factors. It might also be adequate to

implement it in a chatbot over a human.

5 CHALLENGES IN DIALOG

SYSTEMS AND NATURAL

LANGUAGE PROCESSING

It is important to consider that the Natural Language

Processing (NLP) field is in constant development but

faces some challenges that are still open to date. The

quality of a dialog system is linked to the quality of

its natural language understanding module. It is

therefore important to acknowledge current issues in

NLP.

NLP must deal with the ambiguity of natural

languages, i.e., the multiple meaning that the same

sentence or word can have and with linguistic

variability, i.e., the fact that the same idea can be

expressed in multiple forms.

Co-reference is another challenge in NLP. It is a

core task in NLP far for being solved despite the

significant progress observed on learning-based

coreference research (Ng, 2017).

When considering dialog systems that require

speech recognition, other challenges arise such as

speaker variability, channel variability and

environment variability (Petkar, 2016).

This section references only some of the problems

in NLP. Even though improvements in these

problems are active research topics, they must be

considered in the sense that they are not fully

addressed and may compromise the quality of the

dialog agent.

6 CONCLUSIONS

Conversational user interfaces lie between the

traditional user interfaces interactions and human

interaction using natural language. Chatbots present

an opportunity to automate use cases performed by

human operator, offering the same natural way of

communication, and can also be used in place of

traditional applications offering a more natural

interaction. It is important to evaluate if a use case is

suitable to the characteristics of conversational UI

before deciding to implement in a chatbot over a GUI

application or human. In this paper were identified

factors that can be used to facilitate this evaluation,

aiming to contribute to more informed decisions and

more successful chatbot implementations. The

application of this factors to the particular use case of

scheduling a medical appointment indicates this use

case as a good candidate to implement in a chatbot.

7 FUTURE WORK

In order to evaluate the use case evaluator, a chatbot

for the use case of scheduling a medical appointment

will be developed. Users will interact with the bot and

also with a traditional GUI application for the same

end of scheduling an appointment. Metris of both

interactions will be compared, such as efficiency

(measured in time), and task completion success. The

goal is to determine if the use case selected by the

evaluator is indeed appropriate to a chatbot, when

compared with a traditional GUI application.

ACKNOWLEDGEMENTS

This work was supported by national funds through

Fundação para a Ciência e a Tecnologia (FCT) with

reference UID/CEC/50021/2019 and by the European

Commission program H2020 under the grant

agreement 822404 (project QualiChain)

REFERENCES

Accenture, 2016. Chatbots in Costumer Service, s.l.: s.n.

Ask, J., Facemire, M. and Hogan, A., 2016. The State Of

Chatbots, s.l.: s.n.

Hill, J., Ford, R. and Farreras, I., 2015. Real conversations

with artificial intelligence: A comparison between

human–human online conversations and human–

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

436

chatbot conversations. Computers in Human Behavior,

Volume 49, pp. 245-250.

Hirschberg, J. and Manning, C., 2015. Advances in natural

language processing. Science, 349(6245), pp. 261-266.

Janarthanam, S., 2017. Hands-On Chatbots and

Conversational UI Development. s.l.:Packt Publishing.

Jurafsky, D. and Martin, J., 2008. Speech and Language

Processing. 2nd ed. New Jersey: Prentice Hall.

Jurafsky, D. and Martin, J. H., 2018. Speech and Language

Processing (Third Edition draft). s.l.:s.n.

Klopfenstein, L., Delpriori, S., Malatini, S. and Bogliolo,

A., 2017. The Rise of Bots: A Survey of Conversational

Interfaces, Patterns, and Paradigms. s.l., s.n., pp. 555-

565.

Ng, V., 2017. Machine Learning for Entity Coreference

Resolution: A Retrospective Look at Two Decades of

Research. Proceedings of the Thirty-First AAAI

Conference on Artificial Intelligence, pp. 4877-4884.

Petkar, H., 2016. A Review of Challenges in Automatic

Speech. International Journal of Computer

Applications , 151(3), pp. 23-26.

Raman, A. and Tok, W. H., 2018. A Developer's Guide to

Building AI Applications. s.l.:O’Reilly Media.

Sengupta, R. and Lakshman, S., 2017. Conversational

Chatbots – Let's chat. [Online]

Available at:

https://www2.deloitte.com/content/dam/Deloitte/in/Do

cuments/strategy/in-strategy-innovation-

conversational-chatbots-lets-chat-final-report-

noexp.pdf

[Accessed 25 September 2018].

Shevat, A., 2017. Designing Bots. Birmingham: O'Reilly

Media.

Zhang, X. and Wang, H., 2016. A Joint Model of Intent

Determination and Slot Filling for Spoken Language

Understanding. Proceedings of the Twenty-Fifth

International Joint Conference on Artificial

Intelligence, pp. 2993-2999 .

Evaluating Use Cases Suitability for Conversational User Interfaces

437
