NOSOLAP: Moving from Data Warehouse Requirements to NoSQL

Databases

Deepika Prakash

Department of Computer Engineering, NIIT University, Neemrana, Rajasthan, India

Keywords: Data Warehouse, NoSQL Databases, Star Schema, Early Information Model, ROLAP, MOLAP,

NOSOLAP.

Abstract: Typical data warehouse systems are implemented either on a relational database or on a multi-dimensional

database. While the former supports ROLAP operations the latter supports MOLAP. We explore a third

alternative, that is, to implement a data warehouse on a NoSQL database. For this, we propose rules that

help us move from information obtained from data warehouse requirements engineering stage to the logical

model of NoSQL databases, giving rise to NOSOLAP (NOSql OLAP). We show the advantages of

NOSOLAP over ROLAP and MOLAP. We illustrate our NOSOLAP approach by converting to the logical

model of Cassandra and give an example.

1 INTRODUCTION

Traditionally, Data Warehouse (DW) star schemas

are implemented either using a relational database

which allows ROLAP operations or on a multi-

dimensional database that allows MOLAP

operations. While the data in the former is stored in

relational tables, the data in multidimensional

databases (MDB) are either in the form of multi-

dimensional array or hypercubes. A number of

RDBMS offer support for building DW systems and

for ROLAP queries. MOLAP engines have

proprietary architectures. This results in niche

servers and is often a disadvantage.

Another emerging approach is to use NoSQL

databases for a DW system. Data of a NoSQL

database is not modelled as tables of a relational

database and thus, NoSQL systems provide a storage

and retrieval mechanism which is different from

relational systems. The data models used are key-

value, column, document, and graph.

The motivation of using a NoSQL database lies

in overcoming the disadvantages of relational

database implementations. These are:

i.Today, there is a need to store and process large

amounts of data which the relational databases

may find difficult (Chevalier et al., 2015;

Stonebraker, 2012). Further, relational databases

have difficulties in operating in a distributed

environment. However, there is a need to deploy

DWs on the cloud (Dehdouh et al., 2015), in a

distributed environment (Duda, 2012). A relational

database does not provide these features while

guaranteeing high performance.

ii.It may be the case that some piece of data is not

present in underlying data sources at the time of

extraction (ETL). In a relational database engine

this is handled by using a NULL ‘value’. This

causes major difficulties particularly in the use

NULL as a dimension value and also as a foreign

key value in fact tables. Rather than use NULL

values, star schema designers use special values

like -1, 0, or ‘n/a’ in dimensions. It may also be

required to use multiple values like ‘Unknown’

and ‘Invalid’ to distinguish between the different

meanings of NULL. For facts that have NULL

values in their foreign keys, introduction of special

dimension rows in dimension tables is often

proposed as a possible solution to ease the NULL

problem.

Designers of star schemas have outlined a number

of problems associated with these practical

solutions to the problem of NULL values. Some of

these are, for example, difficulty of forming

queries, and misinterpretation of query results.

The problem of NULL values can be mitigated in a

NoSQL database because these systems

452

Prakash, D.

NOSOLAP: Moving from Data Warehouse Requirements to NoSQL Databases.

DOI: 10.5220/0007748304520458

In Proceedings of the 14th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2019), pages 452-458

ISBN: 978-989-758-375-9

completely omit data that is missing. Thus, the

problem of NULLS in the data cube is removed.

iii.DW 2.0 (Inmon, 2010) states that DW is to cater to

storing text, audio, video, image and unstructured

data “as an essential and granular ingredient”. A

relational database fails when it comes to

unstructured, video, audio files. A NoSQL

database can provide a solution to this

disadvantage.

iv.ETL for a relational implementation of a DW is a

slow, time consuming process. This is because

data from disparate sources must be converted into

one standard structured format of the fact and

dimension tables. We believe that since structured

data is not mandated by NoSQL databases, ETL

will be faster.

v.ROLAP has heavy join operations making the

performance of the system slow. We believe

performance of DW systems can be improved if

implemented in a NoSQL database.

vi.Relational databases focus on ACID properties

while NoSQL databases focus on BASE

properties. Since a DW largely caters to a read-

only, analytic environment with changes restricted

to ETL time, enforcement of ACID is irrelevant

and the flexibility of BASE is completely

acceptable and, indeed, may lead to better DW

performance.

There is some amount of work that has been done in

implementing the DW as XML databases and also

on NoSQL platform. The basic idea is to arrive at

facts and dimensions and then convert, in the latter,

the resulting multi-dimensional structure into

NoSQL form. By analogy with ROLAP and

MOLAP we refer to this as NOSOLAP. The NoSQL

databases considered so far, in NOSOLAP, are

column, and document databases.

(Chevalier et al., 2015) converted the MD

schema into a NoSQL column oriented model as

well into a document store model. We will consider

each of these separately. Regarding the former, each

fact is mapped to a column family with measures as

the columns in this family. Similarly each dimension

is mapped to separate column families with the

dimension attributes as columns in the respective

column families. All families together make a table

which represents one star schema. They used HBase

as their column store.

The work of (Dehdouh et al., 2015) is similar to

the previous work but they introduce simple and

compound attributes into their logical model.

(Santos et al., 2017) transforms the MD schema into

HIVE tables. Here, each fact is mapped to a primary

table with each dimension as a descriptive

component of the primary table. The measures and

all the non-key attributes of the fact table are

mapped to the analytical component of the primary

table. As per the query needs and the lattice of

cuboids, derived tables are constructed and stored as

such.

Now let us consider the conversion of (Chevalier

et al., 2015) into document store. Each fact and

dimension is a compound attribute with the

measures and dimension attributes as simple

attributes. A fact instance is a document and the

measures are within this document. Mongodb is the

document store used.

Since the foregoing proposals start off from a

model of facts and dimensions, they suffer from

limitations inherent in the former. Some of these are

as follows:

i.Since aggregate functions are not modelled in a

star schema, the need for the same does not get

translated into the model of the NoSQL database.

ii.Features like whether history is to be recorded,

what is the categorization of the information

required, or whether a report is to be generated are

not recorded in a star schema

Evidently, it would be a good idea to start from a

model that makes no commitments to the structural,

fact-dimension, aspects of a data warehouse and yet

captures the various types of data warehouse

contents. In going to NOSOLAP, we now state our

position in this position paper: we propose to move

from a high-level, generic, information model to

NoSQL databases directly, without the intervening

star schema being created. The consequence of this

direct conversion is the elimination of the step of

converting to a star schema.

To realize our position, we will need to reject all

Data Warehouse Requirements Engineering,

DWRE, techniques that produce facts and

dimensions as their output. Instead, we will look for

a DWRE approach that outputs data warehouse

contents in a high-level information model that

captures in it all the essential informational concepts

that go into a data warehouse.

In the next section, section 2, we do an overview

of the different DWRE approaches and identify a

generic information model. This model is described

in section 3. Thereafter, in section 4, we identify

Cassandra as the target NoSQL database and present

some rules for conversion from the generic

information model to the Cassandra model. Section

5 is the concluding section. It summarizes our

position and contains an indication of future work.

NOSOLAP: Moving from Data Warehouse Requirements to NoSQL Databases

453

2 OVERVIEW OF DWRE

In the early years of data warehousing, the

requirements engineering stage was de-emphasized.

Indeed, both the approaches of Inmon (Inmon, 2005)

and Kimball (Kimball, 2002) were for data

warehouse design and, consequently, do not have an

explicit requirements engineering stage. Over the

years, however, several DWRE methods have been

developed. Today, see Figure. 1, there are three

broad strategies for DWRE, goal oriented (GORE)

approaches, process oriented (PoRE) techniques and

DeRE, decisional requirements engineering.

Some GORE approaches are (Prakash and

Gosain, 2003; Prakash et al., 2004; Giorgini et al.,

2008). In the approach of (Prakash and Gosain,

2003; Prakash et al., 2004) there are three concepts,

goals, decisions and information. Each decision is

associated with one or more goals that it fulfils and

also associated with information relevant in taking

the decision. For this, information scenarios are

written. Facts and dimensions are identified from the

information scenarios in a two step process.

In GrAND (Giorgini et al., 2008) Actor and

Rationale diagrams are made. In the goal modelling

stage, goals are identified and facts associated as the

recordings that have to be made when the goal is

achieved. In the decision-modeling stage, goals of

the decision maker are identified and associated with

facts. Thereafter dimensions are associated with

facts by examining leaf goals.

PoRE approaches include Boehnlein and

Ulbricht (Boehnlein and Ulbrich-vom, 1999;

Boehnlein and Ulbrich-vom, 2000). Their technique

is based on the Semantic Object model, SOM,

framework. The process involves goal modelling,

modelling the business processes that fulfil the goal.

Entities of SERM are identified which is then

converted to facts and dimensions; facts are

determined by asking the question, how can goals be

evaluated by metrics? Dimensions are identified

from dependencies of the SERM schema.

Another approach is by Bonifati (Bonifati et al.,

2001). They carry out goal reduction by using the

Goal-Quality-Metric approach. Once goal reduction

is done, abstraction sheets are built from which facts

and dimensions are identified. In the BEAM*

approach (Corr and Stagnitto, 2012) each business

event is represented as a table. The attributes of the

table are derived by using the 7W framework. 7

questions are asked and answered namely, Who is

involved in the event? (2) What did they do? To

what is done? (3) When did it happen? (4) Where

did it take place? (5) Why did it happen? (6) HoW

did it happen – in what manner? (7) HoW many or

much was recorded – how can it be measured? Out

of these, the first six form dimensions whereas the

last one supplies facts.

Whereas both GORE and PORE follow the

classical view of a data warehouse as being subject

oriented, DeRE takes the decisional perspective.

Since the purpose of data warehouse is to support

decision-making, this approach makes decision

identification the central issue in DWRE. The

required information is that which is relevant to the

decision at hand. Thus, DeRE builds data warehouse

units that cater to specific decisions. Information

elicitation is done in DeRE using a multi factor

approach (Prakash, 2016; Prakash and Prakash,

2019). For each decision its Ends, Means, and

Critical Success Factors are determined and these

drive information elicitation

Figure 1 shows the two approaches to

representation of the elicited information, the multi-

dimensioned and the generic information model

approaches. The former lays emphasis on arriving at

the facts and dimensions of the DW to-be. The latter,

on the other hand, is a high level representation of

the elicited information. The dashed vertical lines in

the figure show that in both GORE and PoRE the

focus of the requirements engineering stage is to

arrive at facts and dimensions. On the other hand,

the DeRE approach represents the elicited

information in a generic information model.

Figure 1: DWRE Techniques and their Outputs.

(Prakash and Prakash, 2019) model information

as early information. Information is early in the

sense that it is not yet structured into a form that can

be used in the DW to-be. An instantiation of this

model is the identified information contents of the

DW to-be.

Since the model is generic, it should be possible

to produce logical models of a range of databases

from it. This is shown in Figure 2. As shown, this

range consists of the multi-dimensional mode, XML

schema, and NoSQL data models. Indeed, an

algorithmic approach was proposed in (Prakash,

2018) to identify facts, dimensions and dimension

hierarchies from the information model.

Requirements

engineering

PoRE

Multi‐dimensio nal (MD)

structures:Facts,

dimensions

GOREDeRE

Output

GenericInformation

model

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

454

Figure 2: Converting the Information Model.

We propose to use the information model of

(Prakash, 2018) to arrive at the logical schema of

NoSQL databases.

3 THE INFORMATION MODEL

The information model of (Prakash and Prakash,

2019), shown in Figure 3, tries to capture all

information concepts that is of interest in a data

warehouse. Thus, instead of just focusing on facts

and dimensions, it details the different kinds of

information.

Information can either be detailed, aggregate or

historical. Detailed information is information at the

lowest grain. Aggregate information is obtained by

applying aggregate functions to either detailed or

other aggregate information. For example, items that

are unshipped is detailed information whereas total

revenue lost due to unshipped items is aggregate

information as function sum need to be applied to

the revenue lost from each unshipped item.

Information can also be historical. Historical

information has two components, time unit that

states the frequency of capturing the information and

duration which states the length of time the data

needs to be kept in the data warehouse.

Information can be computed from other

detailed, aggregate or historical information.

Information is categorized by category which can

have one or more attributes. A category can contain

zero or more categories. Information takes its values

from a value set.

Let us consider an example from the medical

domain. The average waiting time of the patients is

to be analysed. This is calculated as the time spent

by the patient between registration and consultation

by a doctor. Let us say that waiting time has to be

analysed department wise and on a monthly basis.

Historical data of 2 years is to be maintained and

data must be captured daily. Instantiation of the

information model gives us:

Figure 3: Information model.

Information: waiting time of patients

Computed from: registration time, consultation time

Aggregate functions: average

Category: Department wise, Month-wise

Category Attributes: Department: code, name

Month: Month

History: Time Unit: Daily

Duration: 2 years

4 MAPPING RULES

Having described the information model to be used

as input to our conversion process, it is now left for

us to identify the target database model and the

mapping rules that produce it.

We use Cassandra as our target NoSQL database.

First, since it belongs to the class of NoSQL

databases, Cassandra does not suffer from the

deficiencies of the relational model identified earlier.

Cassandra, a blend of Dynamo and BigTable, gets

its distributed feature from Dynamo. Cassandra uses

a peer-to-peer architecture, not master/slave

architecture and handles replication through

asynchronous replication.

Cassandra is column-oriented and organizes data

into tables with each table having a partitioning and

clustering key. The language to query the tables is

CQL which has aggregate functions like min, max,

sum, average.

Cassandra has the possibility of supporting

OLAP operations. In this paper, our concern is the

conversion to the Cassandra logical model and we

do not take a position on OLAP operations.

However, we notice that the SLICE OLAP operation

can be defined as a set of clustered columns in a

partition that can be returned based on the query.

Cassandra does indeed support the SLICE operation

well. This is because it is very efficient in ‘write’

operations having its input/output operations as

Requirements

engineering

Information Model

Column

Document XML

Gr aph

Key‐value

Multi‐dimensional

structure

InformationCategory

Contains

Categorisedby

Attribute

Property

1..*

Aggregate Detailed

Historical

TimeUnit

Duration

Computed

from

0..*

1..*

0..*

1..*

ValueSet

1..*

Takes Value

from

Function

1..*

NOSOLAP: Moving from Data Warehouse Requirements to NoSQL Databases

455

sequential operations. This property can be used for

the SLICE operation.

We give a flavour of our proposed rules that

convert the information model of the previous

section to the logical model of Cassandra. These are

as follows:

Rule 1: Each Information, I, of the information

model, becomes a table of Cassandra named I. In

other words, each instantiation of the information

model of figure 2 gives us one table.

Rule 2: Each ‘Computed from’ Ɛ I is an attribute of

the Cassandra table, I.

Rule 3: Each category attribute, attr, of the

information model, becomes attributes of Cassandra

table, I.

Rule 4: Let us say that category C contains category

c. In order to map a ‘contains’ relationship, two

possibilities arise:

a) There is only one attribute of the category c.

We propose the use of set to capture all the

instances of c. The set, s, thus formed is an

attribute of Cassandra table, I. For example,

consider that a Department contains Units

and Units has one attribute unit-name. Set,

named say unit_name, will be an attribute of

table I. Set unit_name is defined as

unit_name set <text>

where, each name is of data-type text.

The set ‘unit_name’ will capture all the units

under the department.

Notice that since Sets are used to store a

group of values, it is a suitable data structure

for this case.

b) There is more than one attribute of the

category c. Since a Map is used to store key-

value pairs, we propose to use Map data

structure of Cassandra. The Map created will

form an attribute of the Cassandra table, I.

Consider the same example of a Department

contains Units. But this time let Units have

attributes, code, name and head. A Map will

be defined as

Units map<int, text, text>

where each code, name and head can be

stored using data-type int, text and text

respectively.

Rule 5: The category of the information model

makes up the primary key of table I. Notice, that the

model allows more than one category for

information, I. Now, the primary key of Cassandra

has two components namely, partitioning key and

clustering key. Therefore, we need to specify which

category maps to which key of Cassandra. There are

two possibilities:

a) If there is only one category, then that category

is the partitioning key.

b) In the second case, there may be more than one

‘category’. Note that the partitioning key is used

to identify and distribute data over the various

nodes. The clustering key is used to cluster

within a node. Thus, the decision on which

category or pair of ‘category’ becomes the

partition key and which becomes the clustering

key influences the performance of the DW

system. We recommend that all the categories

should become partitioning keys. However,

notice that after selecting a category as the

partitioning key, a specific attribute of the

category must be selected to designate it as a

key. This task will have to be done manually.

For deciding on the clustering key, any attribute of

the Cassandra table can be a clustering key. This

will have to be determined by the requirements

engineer in consultation with domain experts.

There is a special case to (b). There can be

certain categories for which the value of their

attribute is taken from the system date and time.

Such attributes get mapped to Cassandra’s

timestamp/timeuuid datatype. Assigning such a

category/category attribute as a partitioning key

creates as many partitions as the number of dates

and time. To minimize the number of partitions we

recommend to not use such attributes as the

partitioning key. This is because such partitions

provide no real value. Instead, we recommend that

such a category attribute be assigned as a clustering

key.

Applying our broad rules to the example taken in

section 3 above, we get a table named waiting time.

There are two ‘computed from’ information pieces,

registration time and consultation time. Thus, these

two become attributes of table waiting time. Further,

category attributes: department code and department

name belonging to category department also become

attributes of the table.

Based on Rule 5, department and month are the

partitioning keys. Let us say, department_code

attribute represents the department. So, the

partitioning key will be (department code,

dateMonth). Registration time is the clustering key.

The table is created with the CQL statement shown

below in Table 1. Notice that there is a column

dateMonth that represents month wise category.

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

456

Table 1: Table generated after applying Rules 1 to 5.

CREATE TABLE hospital.waiting_time (

department_code text,

dateMonth int,

registration_time timeuuid,

consultation_time timestamp,

department_name text,

PRIMARY KEY (( department_code, dateMonth),

registration_time)

)

The following table, Table 2, shows the sample

of the data inserted.

Table 2: CQL commands for insertion of data.

INSERT INTO hospital.waiting_time

(department_code, dateMonth

,registration_time,consultation_time,department

_name) VALUES ('Sur',201901,33e90fc0-1efa-11e9-

8ca9-0fdba4c6d409,1547265902000,'Surgery');

INSERT INTO hospital.waiting_time

(department_code,dateMonth,registration_time,co

nsultation_time,department_name) VALUES

('Sur',201901,4317a0b0-1efa-11e9-8ca9-

0fdba4c6d409,1547267162000,'Surgery');

INSERT INTO hospital.waiting_time

(department_code,dateMonth,registration_time,co

nsultation_time,department_name) VALUES

('Med',201901,1599f7a0-1efa-11e9-8ca9-

0fdba4c6d409,1547264902000,'Medicine');

INSERT INTO hospital.waiting_time

(department_code,dateMonth,registration_time,co

nsultation_time,department_name) VALUES

('Med',201901,216427e0-1efa-11e9-8ca9-

0fdba4c6d409,1547265902000,'Medicine');

In order to clearly understand the partition based

on department code and month of registration, let us

look at the partition token obtained when rows are

inserted into the table. Partition tokens can be

obtained by CQL:

Select token (department_code, dateMonth) from

hospital.waiting_time

The result of running the above statement can be

seen in Figure 4. For all rows that have the same

partition token Cassandra creates one row for each

department and each month. So, for example,

Medicine department and month of January will be

one row. All the associated attributes will be stored

as columns of the row.

Figure 4: Partition tokens obtained for the data inserted in

Table 2.

Now, the aggregate function of the example of

section 3 is to be mapped. Aggregate functions of

the information model can be directly mapped to the

aggregate functions of Cassandra. In our example,

waiting time is calculated as the difference between

registration and consultation time. Since there is no

difference operator in Cassandra, we wrote a

function, minus_time, to calculate the same. Once

this was done, the aggregate function, avg, was

applied and group by department code and month.

Figure 5 shows the CQL code for the same.

Figure 5: Obtaining the final aggregate information

department wise and monthly.

Suppose we want information about waiting time

but with a different categorization say, patient wise

in addition to department wise and month wise. For

the information model of figure 3, a completely new

piece of information, compared to the earlier one, is

generated. Thus, when we map this new information

to Cassandra, a new table will be created with its

own attributes and partition keys. In other words,

each Cassandra table caters to one instantiation of

the information model.

A tool to map the information model to

Cassandra logical model based on the rules proposed

is being developed.

5 CONCLUSION

There are traditionally two ways in which a DW

system is implemented. One way is to directly use

the data cube in a multi-dimensional database. Even

though these systems give high performance, the

databases are proprietary databases making a server

niche. The other way to implement a DW is to use a

relational database. Here, facts and dimensions are

implemented as relational tables.

Relational databases suffer from the

disadvantages of not being distributed, being

sensitive to NULLs, not catering to all the different

types of data that is to be stored, involving heavy

join operations which impacts system performance.

NOSOLAP: Moving from Data Warehouse Requirements to NoSQL Databases

457

ETL for a relational implementation is very time

confusing and a slow process.

Therefore, we propose to use a NoSQL database.

After all the information needs of the DW to-be have

been identified by the requirements engineering

phase, we propose mapping rules to take us to the

logical model of NoSQL databases. For this, the

information model is examined. Our preliminary

work is for Cassandra, a column oriented database.

Once the mapping is complete, OLAP operations

can be performed.

Future work includes:

a) Defining the way in which OLAP operations will

be implemented in Cassandra

b) Applying our mapping rules to a real-world

example and evaluating our rules

c) Developing mapping rules for a document store.

We have selected Mongodb as the database.

d) Developing mapping rules for XML databases.

REFERENCES

Boehnlein, M. and Ulbrich-vom Ende, A., 1999,

November. Deriving initial data warehouse structures

from the conceptual data models of the underlying

operational information systems. In Proceedings of the

2nd ACM international workshop on Data

warehousing and OLAP (pp. 15-21). ACM.

Böhnlein, M. and Ulbrich-vom Ende, A., 2000. Business

process oriented development of data warehouse

structures. In Data Warehousing 2000 (pp. 3-21).

Physica, Heidelberg.

Bonifati, A., Cattaneo, F., Ceri, S., Fuggetta, A. and

Paraboschi, S., 2001. Designing data marts for data

warehouses. ACM transactions on software

engineering and methodology, 10(4), pp.452-483.

Chevalier, M., El Malki, M., Kopliku, A., Teste, O. and

Tournier, R., 2015, April. How can we implement a

Multidimensional Data Warehouse using NoSQL?. In

International Conference on Enterprise Information

Systems (pp. 108-130). Springer, Cham.

Corr, L. and Stagnitto, J., 2011. Agile data warehouse

design: Collaborative dimensional modeling, from

whiteboard to star schema. DecisionOne Consulting.

Dehdouh, K., Bentayeb, F., Boussaid, O. and Kabachi, N.,

2015, January. Using the column oriented NoSQL

model for implementing big data warehouses.

In Proceedings of the International Conference on

Parallel and Distributed Processing Techniques and

Applications (PDPTA) (p. 469). The Steering

Committee of The World Congress in Computer

Science, Computer Engineering and Applied

Computing (WorldComp).

Duda, J., 2012. Business intelligence and NoSQL

databases. Information Systems in Management, 1(1),

pp.25-37.

Giorgini, P., Rizzi, S. and Garzetti, M., A Goal-Oriented

Approach to Requirement Analysis in Data

Warehouses. Decision Support Systems (DSS) jounal,

Elsevier, pp.4-21.

Inmon, W.H., 1995. What is a data warehouse?. Prism

Tech Topic, 1(1).

Inmon, W.H., Strauss, D. and Neushloss, G., 2010. DW

2.0: The architecture for the next generation of data

warehousing. Elsevier.

Kimball, R., 1996. The data warehouse toolkit: practical

techniques for building dimensional data warehouses

(Vol. 1). New York: John Wiley & Sons.

Prakash, D. and Prakash, N., 2019. A multifactor approach

for elicitation of Information requirements of data

warehouses. Requirements Engineering, 24(1),

pp.103-117.

Prakash, N. and Gosain, A., 2003, June. Requirements

Driven Data Warehouse Development. In CAiSE Short

Paper Proceedings (Vol. 252).

Prakash, D., 2016. Eliciting Information Requirements for

DW Systems. In CAiSE (Doctoral Consortium).

Prakash, D., 2018, September. Direct Conversion of Early

Information to Multi-dimensional Model.

In International Conference on Database and Expert

Systems Applications (pp. 119-126). Springer, Cham.

Prakash, N., Singh, Y. and Gosain, A., 2004, November.

Informational scenarios for data warehouse

requirements elicitation. In International Conference

on Conceptual Modeling (pp. 205-216). Springer,

Berlin, Heidelberg.

Santos, M.Y., Martinho, B. and Costa, C., 2017.

Modelling and implementing big data warehouses for

decision support. Journal of Management Analytics,

4(2), pp.111-129.

Stonebraker, M., 2012. New opportunities for new sql.

Commun. ACM, 55(11), pp.10-11.

ENASE 2019 - 14th International Conference on Evaluation of Novel Approaches to Software Engineering

458
