Architecture for Mapping Relational Database to OWL Ontology: An

Approach to Enrich Ontology Terminology Validated with Mutation Test

Cristiane A. G. Huve

1,2 a

, Alex M. Porn

1 b

and Leticia M. Peres

1 c

Department of Informatics, Federal University of Paran

a, Av. Cel. Francisco H. dos Santos, 100, Curitiba, Brazil

Polytechnic School, Uninter, Rua Luiz Xavier, 103, Curitiba, Brazil

Keywords:

Mapping, Ontology, Relational Database, Mutation Test.

Abstract:

Ontologies are structures used to represent a speciﬁc domain. One well-known method to simplify the on-

tology building is to extract domain concepts from a relational database. This article presents an architecture

which enables an automatic mapping process from a relational database to OWL ontology. It proposes to en-

rich the terminology of ontology elements and it was validated with mutation tests. The architecture mapping

process makes use of new and existent mapping rules and overcome lacks not previously addressed, such as

the use of database logic model to eliminate duplicated elements of ontology and mapping inheritance rela-

tionships from tables and records. We stand out the structure of element mapping, which allows maintaining

source-to-target traceability for veriﬁcation. We validate our approach with two experiments: the ﬁrst one fo-

cuses on architecture validation applying an experiment with three scenarios and the second one uses a testing

engine applying a mutation test methodology to OWL ontology validation.

1 INTRODUCTION

In computing, an ontology is deﬁned based on a set of

concepts in which a domain of speciﬁc knowledge is

modeled (Gruber, 1995). Ontologies offer advantages

in their use, such as: providing an exact description

and an exact vocabulary for representation and shar-

ing of knowledge (Guarino, 1995). The process of its

elaborating is a task which requires a great amount of

effort (Staab and Studer, 2013; Telnarova, 2010).

Several approaches aim to convert relational

databases into ontologies. Most parts of these so-

lutions develop a mapping process from a set of

rules that considering a relational database (RDB)

and physical model. Michel et al. (2014), Spanos

et al. (2012) and Sequeda et al. (2011) surveyed the

motivations and the beneﬁts of a mapping process

from relational database to ontology, considering the

challenges, and different application purposes. Al-

though some authors use the R2RML language (Se-

queda et al., 2012; Das et al., 2012; Arenas et al.,

2012) and it is an important advance for the commu-

nity, the R2RML language has restrictions and does

https://orcid.org/0000-0002-2038-9450

https://orcid.org/0000-0003-0832-5750

https://orcid.org/0000-0002-8922-6975

not support to record during the mapping the relation-

ships between RDB and ontology concepts.

Concerning the creation of an ontology from

scratch since an RDB, we analyzed related work as

Astrova (2009); B

umans and

Cer

ans (2010); Cullot

et al. (2007); Gherabi et al. (2012); Laclavik (2006);

Li et al. (2005); Louhdi et al. (2013); Ramathilagam

and Valarmathi (2013); Ren et al. (2012); Telnarova

(2010); Vavliakis et al. (2010); Zhang and Li (2011)

and Jain and Singh (2013). Tissot et al. (2019) de-

scribes in detail such related work mentioned above,

being explained rules commonly used in the map-

ping process. Huve (2017) explores related work and

developed experiments with Astrova (2009) work,

which has made a considerable contribution to this re-

search area. Astrova (2009) proposed QUALEG DB,

a tool to deal with hierarchy, constraints, and restric-

tions of elements, however, it works with direct map-

ping. More recently, Jain and Singh (2013) compared

different approaches developed to convert RDB to on-

tology, and they proposed adding new features to an

existing framework. Nevertheless, this proposal pro-

vides a direct mapping between RDB and ontology

elements, limiting the possibilities of ontology mod-

eling.

In general, these works do not expose details

about the terminology of naming ontological el-

320

Huve, C., Porn, A. and Peres, L.

Architecture for Mapping Relational Database to OWL Ontology: An Approach to Enrich Ontology Terminology Validated with Mutation Test.

DOI: 10.5220/0007752803200327

In Proceedings of the 21st International Conference on Enterprise Information Systems (ICEIS 2019), pages 320-327

ISBN: 978-989-758-372-8

ements, an important issue to ontology legibility.

These mapping processes are quite abstract and there

is no source-to-target relationship among the ele-

ments. An exception is presented by Ren et al. (2012),

which append the database relation name to the col-

umn name when mapping columns. In related work,

the name of database elements comes from database

schema and the name of ontology elements retain the

source name of database elements. When there is a

type of encoding or abbreviation on the database ele-

ment name are more difﬁcult to understand the mean-

ing of target ontology elements. This encoding is

commonly declared to arrange the database elements

in the source RDB schema. Another point to empha-

size is the ontology validation of these mapping pro-

cess, not being presented a solution that uses a testing

engine, only being validated the mapping process.

Given the above context, the following motiva-

tions for the present study are: a) the existing map-

ping processes only perform a direct mapping of the

elements and do not reuse pre-existent deﬁnitions for

enriching the ontology terminology; b) the proposed

solutions do not consider the information from the

RDB physical and logical model at the same time;

c) in face of different contributions, we identify the

opportunity to consolidate the proposed functionali-

ties of different works in a unique architecture; and

d) we consider validate not only the mapping process

but also the ﬁnal result of generated ontology apply-

ing mutation test for owl ontology validation.

This paper is organized as follows: Section 2

presents the mapping process architecture and its set

of components and mapping rules. Section 3 depicts

the experiments performed in order to validate our ap-

proach and the produced OWL ontology. Finally, sec-

tion 4 concludes with considerations and future work.

2 MAPPING ARCHITECTURE

In this section, we present our architecture to per-

form the mapping process between RDB-to-ontology.

We developed a mapping architecture based on re-

lated work mentioned in section 1 and from observed

needs. It allows store the mapping between RDB

and ontology elements, offering a more complete so-

lution than the one proposed by Cullot et al. (2007)

and B

umans and

Cer

ans (2010). We rewrite rules

mentioned in related work and we considered 3 rules

proposed by Tissot et al. (2019). Our main contri-

bution consists in the architecture modeling and in

the adequacy of rules to overcome lacks not previ-

ously addressed. One of them consists in the use

of database logic model rather than using uniquely

database schema or physical model. The terminol-

ogy used in the logic model is more related to the

real world deﬁnitions than the terminology used in the

physical model, improving the semantics produced

in the target ontology. Another concerning in the

mapping of hierarchy relationships from tables and

records is the elimination of produced duplicated on-

tology elements, however, maintaining the traceabil-

ity between RDB and ontology elements. From these

considerations, in Figure 1 we present our mapping

architecture capable of overcoming all of these needs.

In the next subsection, we describe the main ar-

chitecture components and second, we present a set

of mapping rules handling the issues argued as our

motivation.

2.1 Architecture Components

The architecture is divided into two parts: External

and Internal Components. The External components

is related to the source data to support the mapping

process, being composed by the database schema,

records and logic model. All data extract from the Ex-

ternal Component process (being this a manual pro-

cess), it is inserted into a single ﬁle, that we call as

Conﬁguration Template. Once the ﬁle is created, it is

used as input of the Mapping process, being this pro-

cess conducted automatically from the input of con-

ﬁguration template ﬁle, being this ﬁle analyzed by a

set of rules, detailed in section 2.2, to perform the

mappings. The input data and the mappings results

are automatically stored in the Mapping Model, be-

ing it a metamodel prepared to produce a database

schema from it and keep the database and ontology

elements as well as the mapped relations. The Gen-

eration of Ontology process uses the data stored in

Mapping Model containing the mapped ontology ele-

ments to produce the target OWL ontology.

2.2 Architecture Mapping Rules

In this section we present an set of mapping rules used

to map each RDB element to the corresponding on-

tology element, being deﬁned more than one rule to

map each RDB element. We also considering crite-

ria to name the ontology elements, which enables to

establish conventions to be used by the community

and which contribute to a greater legibility and under-

standing of the target ontology.

2.2.1 Mapping Rules

The mapping process consider the Conﬁguration

Template to get information from tables, columns,

Architecture for Mapping Relational Database to OWL Ontology: An Approach to Enrich Ontology Terminology Validated with Mutation

Test

321

Figure 1: Architecture components.

records, check constraint and hierarchies. Thus, we

separate the rules accord these database elements.

Rules 1 and 2 are related to database table elements.

Rules 3 and 4 are related to database columns ele-

ments. Rules 5 and 6 consider database columns ele-

ments marked as check constraint and at last, rules 9

and 10 deal with hierarchies. In Huve (2017) is for-

mal described the rules using pseudocode and also in

it is presented details of the sequence of mappings and

Conﬁguration Template. In the rules speciﬁcation al-

ways is mentioned the logic model. However, when

the logic name of database elements are not inserted,

the mapping is performed considering the physical

name of the database elements. The 10 mapping rules

are presented below:

• Rule 1 - Mapping Non-associative Tables: each

non-associative table is mapped to one ontological

class, wherein the class name is composed of: a)

it starts with a capital letter and b) the value which

correspond to the logic table name.

• Rule 2 - Mapping Associative Tables: we map the

primary key columns of associative tables to an

object property (mutually inverse) for each pri-

mary key column, unless the table columns are

only foreign key. The ﬁrst object property name

is composed of: a) it starts with ﬁxed value has

- with lowercase letter; and b) the corresponding

value for the logic column name - it starts with

a capital letter. The second object property name

is composed of: a) it starts with ﬁxed value is -

with lowercase letter; b) the corresponding value

for the logic column name - it starts with a capital

letter; and c) the ﬁxed value of - with a capital let-

ter. For each object property is speciﬁed minimum

cardinality, declared as inverse, and the domain

and range are assigned. The range is speciﬁed us-

ing the created class to the foreign key of the ref-

erenced table; and domain is speciﬁed using the

created class to the referenced table to the other

foreign key which compose the associative table.

We can identify in the Mapping Model database

schema whether an non-associative table has ad-

ditional columns, ﬁnding a column which is not

checked as a primary key. Whether the result re-

turns a value we apply the steps above, and to-

gether with it these steps: a) we create a class to

the non-associative table, according to Rule 1; and

b) we create a datatype property for each non pri-

mary key column, according to Rule 3.

• Rule 3 - Mapping Columns to Datatype Proper-

ties: Table columns that are not part of these col-

umn types (primary, unique, foreign key or check

constraint) are mapped to a datatype property, at

ﬁrst moment, wherein the datatype property name

is composed of: a) it starts with lowercase letter;

and b) the value corresponding to the logic col-

umn name.

• Rule 4 - Mapping Columns to Object Proper-

ties: primary or unique key columns are mapped

to two functional object properties (mutually in-

verse), wherein the ﬁrst object property name is

composed of: a) it starts with ﬁxed value has

- with lowercase letter; and b) the value corre-

sponding to the logic column name - it starts with

a capital letter. The second object property name

is composed of: a) it starts with ﬁxed value is -

with lowercase letter; b) the value corresponding

to the logic column name - it starts with a capital

letter; and c) the ﬁxed value of - with a capital let-

ter. Each object property is declared as functional,

inverse and its range is speciﬁed using the created

class from the table column. Each object property

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

322

has minimum cardinality of restriction assigned.

• Rule 5: Mapping Records to Instances: Every tu-

ple from tables classiﬁed as speciﬁc concepts of a

domain (D) are mapped to instances. For this, the

instance name is composed of: a) tuple values,

whereby we recommend the value corresponding

to the primary key column and the column con-

tent (or columns) - with a capital letter. In case of

instance name, as we can have many values, we

separate the values with underscore.

• Rule 6 - Mapping Records to Classes: A propor-

tion of tables in the database have a small num-

ber of tuples which represent speciﬁc deﬁnitions

of a particular domain. Considering classes are

concrete representations of concepts, we classi-

ﬁed tables with speciﬁc deﬁnitions of a domain

as common concepts of multiple domains (C) and

all tuples from these tables are mapped to classes,

wherein the class name is the tuple content - it

starts with a capital letter.

• Rule 7 - Mapping Check Constraint Concept: The

check constraint concept represents a term which

we use to represent a set of values deﬁned in a

check constraint. We propose to map the database

check constraints and create a class to represent

the set of values deﬁned in the check constraint.

For this, in the Conﬁguration Template can be

ﬁlled the check constraint concept and can be

ﬁlled the set of values deﬁned for this check con-

straint. For the check constraint concept we map

this information to one ontological class, wherein

the class name is composed of the value corre-

sponding to the check constraint concept - with

a capital letter. Every possible value of this check

constraint is mapped to an instance, wherein the

instance name is composed of: a) the value corre-

sponding to the class constraint name - with low-

ercase letter; b) we separate the values with un-

derscore; and c) the value corresponding to the

constraint name - with a capital letter.

• Rule 8 - Mapping Check Constraint Column: In

the Conﬁguration Template, the ﬁeld checked as

check constraint is mapped to one object property,

wherein the object property name is composed of:

a) the value corresponding to the logic column

name - it starts with lowercase letter. For this ob-

ject property the domain and range are assigned,

where the domain is speciﬁed using the class cre-

ated from the table column; range is speciﬁed us-

ing the class created with the Rule 7, which repre-

sents the global concept of this set of check con-

straints values.

• Rule 9 - Mapping Inheritance Relationships from

Tables: For each foreign key which is equivalent

to the primary key in non-associative tables, the

class representing the referenced table is deﬁned

as a superclass of the class representing the non-

associative table.

• Rule 10 - Mapping Table Record Hierarchy: In

Rule 6 the mapping of all tuples to classes, from

tables of common concepts of multiple domains

(C), was proposed. These tables have relation-

ships with another tables and to their relation, as

we describe in Rule 9, for each related table we

create a subclass hierarchy based on foreign keys

deﬁnition. Creation of class hierarchy based on

classes mapped from tuples of these tables is pro-

posed in this rule. The table record hierarchy can

be mapped when both related tables belong to ta-

bles classiﬁed as (C). We performed this mapping

for non-associative tables and for tables in which

the foreign key columns number is not greater

than one in the referenced table.

3 VALIDATION

First, we present the obtained results executing the

mapping process to validate the rules and the proto-

type. For this, we use a Database Schema and Logic

Model from dental care domain. Second, we use a

testing engine to apply mutation operators and exe-

cuting mutation tests methodology, proposed by Porn

and Peres (2017), to validate the owl ontology auto-

matically generated by architecture.

3.1 Experiment 1: Prototype Validation

We develop a tool to put into operation our architec-

ture. Then, we evaluate our tool and check whether

the ontology was correctly built, using a reasoner to

infer logical consequences. For this, we consider

three different scenarios: a) in the ﬁrst one we used

only the database schema; b) in the second one we

used the database schema and logic model; and c) in

the third one an analysis by a specialist was performed

to remove from second scenario RDB elements that

were not part of the application domain, such as in-

formation about system conﬁguration and logs. We

used a Database Schema (private source) from a den-

tal care system, containing a scenario of 25 tables,

45 primary keys, 1 unique key, 19 foreign keys, 28

check constraints, 225 columns with no constraints in

the ﬁrst two scenarios and 74 at the third, and 696

tuples. The logic model of this database schema has

232 columns with the logical name in the ﬁrst two

Architecture for Mapping Relational Database to OWL Ontology: An Approach to Enrich Ontology Terminology Validated with Mutation

Test

323

scenarios and 140 columns with the logical name at

the third.

Each scenario was manually extracted and it was

submitted to the architecture prototype. Then we per-

formed an ontology veriﬁcation in two steps: ﬁrst,

an analysis of mapped elements enable verifying

whether the deﬁned mapping rules were applied cor-

rectly by the Mapping Process; and second a veriﬁ-

cation applying in each OWL ﬁle using the reasoner

Pellet

. The inferences carry out the ontology clas-

siﬁcation, the computation of inferred instances and

the validation of ontology consistency. Both activi-

ties were performed using the Prot

e tool (Musen,

2015).

Table 1 presents the number of generated ontology

elements for each scenario (columns) and in four cate-

gories of ontology elements (lines). In the Class cate-

gory we presented the total of Class and Subclass that

were generated. The elements of the Class category

were generated from Rules 1, 2, 6, 7, 9 and 10, as cov-

ered in the 2.2.1 section. We also presented the total

number of Object property elements and their deﬁni-

tions of Functional, Inverse, Domain, Range and Min

cardinality for Object property. The elements of the

Object property category were generated from Rules

2, 4 and 8. In the Datatype property category we pre-

sented the total number of Datatype property elements

and their SubProperty, Domain and Range deﬁnitions.

The elements of the Datatype property category were

generated from Rules 3. Finally, we presented the to-

tal number of Instances and Class assertion generated

from Rules 5 and 7.

Scenarios 1 and 2 has the same number of

database elements. The difference is on the name on

the output elements for scenario 2 since we used the

RDB logic model as additional input. However, we

can observe in Table 1 a different number of ontology

elements that were generated. On the one hand, the

logical name can present speciﬁcation which differen-

tiates the elements, generating a greater amount, such

as the elements of Object property, which go from

68 in the ﬁrst scenario to 74 in the second scenario.

On the other hand, the logical name of few elements

can be the same, generating a smaller number of ele-

ments, such as the Datatype property elements, which

go from 142 in the ﬁrst scenario to 122 in the second

scenario. We noticed that the naming of the elements

using Logic Model increase the ontology legibility.

During the analysis by a specialist in the third sce-

nario, out of the 151 columns that were excluded: 75

controlled the security of database tuples and 76 con-

trolled operations of the system which populates data

in the database. As a result of this, RDB columns with

https://www.w3.org/2001/sw/wiki/Pellet

no constraints in the third scenario is 74, resulting in a

smaller amount of data properties. However, besides a

domain representation with greater legibility and deﬁ-

nitions more coherent than ﬁrst and second scenarios,

which produced a large amount of information not re-

lated to the domain.

The prototype validation was performed in each

of the architecture components. We then executed

the Pellet reasoner and there was no identiﬁcation

of inference errors in target ontologies. Other ap-

proaches Astrova (2009); Jain and Singh (2013) per-

formed only 1:1 mapping, but our architecture can

map 1:N. Due to this structure, n database elements

can be mapped to 1 element in the ontology, and

vice versa. A practical example is the representation

of a property generated from a primary key column.

This column may exist in different tables, being rep-

resented by a foreign key column. We understand that

it does not make sense to represent n times the same

element that represents the same concept, but inserted

in different domains.

This experiment allowed to analyze the coherence

of the deﬁned rules and regarding the well function-

ing of the proposed architecture. Through this, we

observed a greater clarity in the name of ontology el-

ements in the second scenario compared to the ﬁrst

scenario, highlighting the obtained beneﬁt from the

use of the logic model, which increases the ontology

legibility.

3.2 Experiment 2: OWL Ontology

Validation using Mutation Test

Mutation testing is a technique for software testing

to evaluate the quality of a set of test cases (DeMillo

et al., 1978; Jia and Harman, 2011). This technique

has been shown effective in detecting faults (DeMillo

et al., 1978; Budd, 1980) through systems evaluation

and their sets of tests in various domains (Jia and Har-

man, 2011). Recent studies (Porn and Peres, 2014,

2017; Bartolini, 2016) adopted Mutation testing to

ontology evaluation.

The ontology evaluation is an important process of

ontology engineering that allows identifying whether

the objectives have been reached and whether there

are no occurrences of failures. From this, we applied

the mutation test for evaluating the ontologies ob-

tained through the mapping process aiming to identify

the existence of faults. Based on this, we performed

the mutation test for ontologies in this experiment us-

ing the generated ontologies of the three scenarios of

Experiment 1, as presented in Table 1.

We performed the mutation test for ontologies as

proposed by Porn and Peres (2017): 1) Mutation op-

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

324

Table 1: Number of ontology elements.

Number of elements

Ontology elements First scenario Second scenario Third scenario

Class 109 109 108

SubClass 121 121 121

Object property 68 74 73

Functional 50 54 54

Inverse 30 32 32

Domain 105 107 107

Range 84 86 85

Min cardinality 76 76 76

Datatype property 142 122 64

SubProperty 5 5 5

Domain 141 128 67

Range 142 128 66

Instances 668 668 668

Class assertion 668 668 668

erator selection; 2) Mutants generation; 3) Test data

generation; 4) Original ontology execution; 5) Mu-

tants ontology execution; and 6) Result analysis. We

used 12 mutation operators, as detailed below:

• ACSD: it changes to DisjointWith the deﬁnition

of an axiom deﬁned as SubClassOf;

• AEDN: it adds the operator “not” in the deﬁnition

of an axiom;

• CEUO: it removes the operator “OR” in the deﬁ-

nition of an axiom;

• CIS: it changes to SubClassOf the deﬁnition of an

individual;

• CUC: it changes the superclass of a subclass;

• PDD: it changes the properties domain to a sub-

class of the domain class;

• PDUP: it changes the properties domain to a su-

perclass of the domain class;

• ACMiEx: it replaces the “minCardinality” opera-

tor with the “Cardinality”;

• ACMiMA: it replaces the “minCardinality” oper-

ator with the “maxCardinality”;

• PDU: it removes the domain deﬁnition in proper-

ties;

• PRU: it removes the range deﬁnition in properties;

• PDC: it converts a primitive class to a deﬁned

class.

As presented in Porn and Peres (2017), the test data

set used was generated from each existing Descriptive

Logic (DL) constraint of the ontology under test, and

from each mutated DL constraint.

Table 2 presents the results of mutation test for

each scenario. In the ﬁrst scenario (Scen. 1) 2846

mutants were obtained to the 12 mutation operators,

941 mutants were killed with the test data used and

1905 mutants remained alive. Based on these results

it was possible to obtain a mutation score of 33%.

In the second scenario (Scen. 2) the obtained re-

sults were similar to the ﬁrst scenario, because there

were few changes between the ontologies from each

scenario. In it, 2791 mutants were obtained, 941

killed and 1850 mutants that remained alive, thus ob-

taining a mutation score of 34%.

Table 1 presents a smaller number of ontology el-

ements in the third scenario than the ﬁrst two scenar-

ios. This smaller amount of ontology elements gener-

ates less mutants during the mutation test execution.

Thus, in the third scenario (Scen. 3), 2136 mutants

were generated, with 898 killed and 1238 remaining

alive, resulting in a mutation score of 42%.

This analysis made it possible to identify a lack of

rules for the creation of logical axioms and associa-

tions between classes and individuals into ontologies.

However, we do not consider this occurrence as a type

of fault existing in the ontology, but as implementa-

tions to be made in the mapping process. Therefore,

for the mutation score calculation, we consider the

quotient between the number of killed mutants and

the remainder between the number of generated mu-

tants and the number of equivalent mutants (DeMillo

et al., 1978). In this case, we obtained a mutation

score of 100% in each scenario, thus validating the

set of test data used and the absence of faults in the

tested ontologies.

All of the mutants shown in Table 2 that remained

alive have been changed in the deﬁnitions of domain

Architecture for Mapping Relational Database to OWL Ontology: An Approach to Enrich Ontology Terminology Validated with Mutation

Test

325

Table 2: Mutation test results.

Mutation

Operator

Mutants Kill Alive

Scen. 1 Scen. 2 Scen. 3 Scen. 1 Scen. 2 Scen. 3 Scen. 1 Scen. 2 Scen. 3

ACSD 121 121 121 121 121 121 0 0 0

AEDN 109 102 21 0 0 0 109 102 21

CEUO 109 102 21 0 0 0 109 102 21

CIS 686 686 668 686 686 668 0 0 0

CUC 101 101 101 15 15 15 86 86 86

PDD 921 889 642 0 0 0 921 889 642

PDUP 168 159 124 0 0 0 168 159 124

ACMiEx 126 126 76 0 0 0 126 126 76

ACMiMa 126 126 76 0 0 0 126 126 76

PDU 107 107 107 0 0 0 107 107 107

PRU 153 153 85 0 0 0 153 153 85

PDC 119 119 94 119 119 94 0 0 0

TOTAL 2846 2791 2136 941 941 898 1905 1850 1238

Mutation Score 0,33 0,34 0,42

and range of object and data properties. As in none

of the 3 scenarios the object and data properties were

used in the deﬁnition and representation of classes, all

the mutants that remained alive were deﬁned as equiv-

alent, due to the fact that these mutations did not have

an effect on the ontologies. The criteria used to de-

ﬁne the mutants as equivalent must it is because there

are no rules in the mapping process for the creation

of descriptive logical axioms that deﬁne the ontology

conceptual representation.

4 CONCLUSIONS

We have presented an approach for mapping rela-

tional databases to ontologies using database schema

and logical data model. The use of the Logic Model

contributes to the generation of a more legible ontol-

ogy. The Mapping Model contributes to the mapping

traceability and the elimination of duplicate elements.

Our solution takes stock of previous works and it pro-

vides new rules, handling cases uncovered by the lit-

erature and collaborating in a signiﬁcant way for ade-

quate ontology modeling.

We validated our approach with real-world scenar-

ios. We evaluate the target ontology from our proto-

type applying mutation test technique. This method-

ology simulates possible errors which can occur in

OWL ontologies. We did not ﬁnd faults in the target

ontologies, but our evaluation method identiﬁed the

absence of rules in the mapping process for the cre-

ation of logical descriptions and associations between

classes and individuals into ontologies.

As future work, we aim to investigate and propose

new mapping rules for ontology build and consider-

ing new mutation operators as also other techniques

for ontology evaluation. We also intend to work in

the creation of descriptive logical axioms to deﬁne the

conceptual ontology representation. The architecture

is generic enough and could be applied in the back-

ward scenario, using the mapping for bidirectional

transformation and traceability on querying the rela-

tional database through the ontology concepts.

ACKNOWLEDGEMENTS

We thank the partial support provided from CAPES

and Department of Informatics of Federal University

of Paran

a. Leticia M Peres has a grant of PET/MEC.

Cristiane A G Huve was supported by Uninter. This

work was conducted using Prot

e resource, which is

supported by grant GM10331601 from the National

Inst. of General Medical Sciences of the US National

Inst. of Health.

REFERENCES

Arenas, M., Bertails, A., Prud’hommeaux, E., and Se-

queda, J. (2012). A direct mapping of relational data

to rdf. http://www.w3.org/TR/2012/REC-rdb-direct-

mapping-20120927. W3C Recommendation working

draft 27 September 2012.

Astrova, I. (2009). Rules for mapping sql relational

databases to owl ontologies. In Metadata and Seman-

tics, pages 415–424. Springer.

Bartolini, C. (2016). Mutation owls: semantic mutation

testing for ontologies. In Proceedings of the Interna-

tional Workshop on domain speciﬁc Model-based ap-

ICEIS 2019 - 21st International Conference on Enterprise Information Systems

326

proaches to veriﬁcation and validation, pages 43–53,

Rome - Italy.

Budd, T. A. (1980). Mutation Analysis of Program Test

Data. PhD thesis, Yale University, Yale, NH - USA.

umans, G. and

Cer

ans, K. (2010). Rdb2owl: A practical

approach for transforming rdb data into rdf/owl. In

Proceedings of the 6

Int. Conf. on Semantic Systems,

pages 1–3, New York, NY, USA.

Cullot, N., Ghawi, R., and Y

etongnon, K. (2007). Db2owl:

A tool for automatic database-to-ontology mapping.

In Proceedings of the 15

Italian Symposium on Ad-

vanced Database Systems - SEBD, pages 491–494,

Torre Canne - Italy.

Das, S., Sundara, S., and Cyganiak, R. (2012). R2rml:

Rdb to rdf mapping language. www.w3.org/TR/r2rml.

W3C Recommendation 27 September 2012.

DeMillo, R. A., Lipton, R. J., and Sayward, F. G. (1978).

Hints on test data selection: Help for the practicing

programmer. Computer, 11(4):34–41.

Gherabi, N., Addakiri, K., and Bahaj, M. (2012). Map-

ping relational database into owl structure with data

semantic preservation. Int. Journal of Computer Sci.

and Inform. Security - IJCSIS, 10(1):42–47.

Gruber, T. R. (1995). Toward principles for the design of

ontologies used for knowledge sharing. Int. Journal

of human-computer studies, 43(5-6):907–928.

Guarino, N. (1995). Formal ontology, conceptual analysis

and knowledge representation. Int. Journal of human-

computer studies, 43(5):625–640.

Huve, C. A. G. (2017). An architecture for mapping rela-

tional database to ontology. Master’s thesis.

Jain, V. and Singh, M. (2013). A framework to convert rela-

tional database to ontology for knowledge database in

semantic web. Int. Journal of Scientiﬁc & Technology

Research, 2:9–12.

Jia, Y. and Harman, M. (2011). An analysis and survey of

the development of mutation testing. IEEE Transac-

tions on Software Engineering, 37(5):649–678.

Laclavik, M. (2006). Rdb2onto: Relational database data to

ontology individuals mapping. Tools for Acquisition,

Organisation and Presenting of Inform. and Knowl-

edge, pages 86–89.

Li, M., Du, X., and Wang, S. (2005). A semi-automatic

ontology acquisition method for the semantic web.

In Advances in Web-Age Inform. Management, pages

209–220. Springer.

Louhdi, M. R. C., Behja, H., and Alaoui, S. O. E. (2013).

Transformation rules for building owl ontologies from

relational databases. Computer Sci. & Inform. Tech-

nology (CS & IT), 3:271–283.

Michel, F., Montagnat, J., and Faron-Zucker, C. (2014). A

survey of rdb to rdf translation approaches and tools.

Technical Report ISRN I3S/RR 2013-04-FR, Labora-

toire d’Informatique, Signaux et Syst

emes de Sophia-

Antipolis, Universit

e Nice, Sophia Antipolis, France.

Research Report.

Musen, M. A. (2015). The prot

e project: a look back

and a look forward. AI Matters. Association of Com-

puting Machinery Speciﬁc Interest Group in Artiﬁcial

Intelligence, 1(4):4–12.

Porn, A. M. and Peres, L. M. (2014). Mutation test to

owl ontologies. In 13

Int. Conf. on WWW/Internet

- ICWI, pages 123–130, Porto - Portugal.

Porn, A. M. and Peres, L. M. (2017). Semantic mutation

test to owl ontologies. In 19

Int. Conf. on Enterprise

Inform. Systems - ICEIS, volume 2, pages 434–431,

Porto - Portugal.

Ramathilagam, C. and Valarmathi, M. (2013). A framework

for owl dl based ontology construction from relational

database using mapping and semantic rules. Int. Jour-

nal of Computer Applications, 76(17):31–37.

Ren, Y., Jiang, L., Bu, F., and Cai, H. (2012). Rules and im-

plementation for generating ontology from relational

database. In 2

Int. Conf. on Cloud and Green Com-

puting - CGC, pages 237–244. IEEE.

Sequeda, J. F., Arenas, M., and Miranker, D. P. (2012). On

directly mapping relational databases to rdf and owl.

In Proceedings of the 21

Int. Conf. on World Wide

Web, pages 649–658. ACM.

Sequeda, J. F., Tirmizi, S. H., Corcho, O., and Miranker,

D. P. (2011). Survey of directly mapping sql databases

to the semantic web. The Knowledge Engineering Re-

view, 26(4):445–486.

Spanos, D.-E., Stavrou, P., and Mitrou, N. (2012). Bringing

relational databases into the semantic web: A survey.

Semantic Web, 3(2):169–209.

Staab, S. and Studer, R. (2013). Handbook on ontologies.

Springer Sci. & Business Media.

Telnarova, Z. (2010). Relational database as a source of

ontology creation. In International Multiconference

on Computer Sci. and Inform. Technology - IMCSIT,

pages 135–139.

Tissot, H., Huve, C. A. G., Mara, P. L., and Del Fabro,

M. D. (2019). Exploring logical and hierarchical in-

formation to map relational databases into ontologies.

Int. Journal of Metadata, Semantics and Ontologies,

(ISSN 1744-2621 - to appear).

Vavliakis, K. N., Grollios, T. K., and Mitkas, P. A. (2010).

Rdote - transforming relational databases into seman-

tic web data. In Polleres, A. and Chen, H., ed-

itors, 9

International Semantic Web Conference -

ISWC Posters&Demos, volume 658 of CEUR Work-

shop Proceedings. CEUR-WS.org.

Zhang, L. and Li, J. (2011). Automatic generation of on-

tology based on database. Journal of Computational

Inform. Systems, 7:4:1148–1154.

Architecture for Mapping Relational Database to OWL Ontology: An Approach to Enrich Ontology Terminology Validated with Mutation

Test

327
